Synthesis, High-Resolution Infrared Spectroscopy, and Vibrational
Structure of Cubane, C8H8
V. Boudon,*,† M. Lamy,† F. Dugue-Boye,† O. Pirali,*,‡ S. Gruet,‡ L. D’Accolti,*,§,∥ C. Fusco,§,∥
́
C. Annese,§,∥ and M. E. Alikhani*,⊥,#
†Laboratoire Interdisciplinaire Carnot de Bourgogne, UMR 6303 CNRS-Universite
Savary, BP 47870, F-21078 Dijon Cedex, France
́
Bourgogne Franche-Comte,
́
9 avenue Alain
ulaires
‡Ligne AILES − Synchrotron SOLEIL, L’Orme des Merisiers, F-91192 Gif-sur-Yvette, France and Institut des Sciences Molec
́
d’Orsay (ISMO), CNRS, Univ. Paris-Sud, Universite
§Dipartimento di Chimica, Universita
di Bari A. Moro, I-70126 Bari, Italy
∥Istituto di Chimica dei Composti Organometallici ICCOM, Bari Sect, I-70126 Bari, Italy
⊥Sorbonne Universites, UPMC Univ. Paris 06 and #CNRS, MONARIS, UMR 8233, Universite
́
Pierre et Marie Curie, 4 Place Jussieu,
́
Paris-Saclay, F-91405 Orsay, France
̀
́
Case courrier 49, F-75252 Paris Cedex 05, France
ABSTRACT: Carbon-cage molecules have generated a considerable interest
from both experimental and theoretical points of view. We recently per-
formed a high-resolution study of adamantane (C10H16), the smallest hydro-
carbon cage belonging to the diamandoid family (Pirali, O.; et al. J. Chem.
Phys. 2012, 136, 024310). There exist another family of hydrocarbon cages
with additional interesting chemical properties: the so-called platonic hydro-
carbons that comprise dodecahedrane (C20H20) and cubane (C8H8). Both
possess C−C bond angles that deviate from the tetrahedral angle (109.8°) of
the sp3 hybridized form of carbon. This generates a considerable strain in the
molecule. We report a new wide-range high-resolution study of the infrared
spectrum of cubane. The sample was synthesized in Bari upon decarbox-
ylation of 1,4-cubanedicarboxylic acid thanks to the improved synthesis of
literature. Several spectra have been recorded at the AILES beamline of the
SOLEIL synchrotron facility. They cover the 600−3200 cm−1 region. Besides
the three infrared-active fundamentals (ν10, ν11, and ν12), we could record many combination bands, all of them displaying a well-
resolved octahedral rotational structure. We present here a preliminary analysis of some of the recorded bands, performed thanks
the SPVIEW and XTDS software, based on the tensorial formalism developed in the Dijon group. A comparison with ab initio
calculations, allowing to identify some combination bands, is also presented.
Eaton and Cole first synthesized cubane in 1964.2,3 Later on,
I. INTRODUCTION
Barborak and colleagues found an improved synthesis pro-
Carbon-cage molecules like fullerenes have generated consid-
erable interest from both experimental and theoretical points of
cedure.4 This molecule is a spherical-top with Oh octahedral
symmetry. It possesses 18 (nondegenerate and degenerate)
view. Adamantane is the smallest hydrocarbon cage that we could
normal modes of vibration, among which only three (with F1u
study recently at high resolution using the AILES Beamline of
the SOLEIL synchrotron facility.1
symmetry) are infrared active and 8 are Raman-active. It should
be noticed that for such centrosymmetric molecules, the infrared
Platonic hydrocarbons, comprising dodecahedrane (C20H20)
and Raman spectra are mutually exclusive: infrared bands have u
and cubane (C8H8), are another family of hydrocarbon cages
parity, whereas Raman bands have g parity. Thus, both tech-
with additional interesting chemical properties. These species
niques are necessary for a complete spectroscopic character-
possess C−C bond angles that significantly deviate from the
ization. Della and co-workers5 have recorded low-resolution
spectra of C8H8. The only existing high-resolution study is that of
Pine et al.,6 who could record some parts of the three infrared-
active fundamentals using diode lasers. These spectra were
analyzed as isolated bands using a very simple phenomenological
tetrahedral angle (109.8°) of the sp3 hybridized form of carbon,
generating a considerable strain in the molecule. Cubane itself
has the highest density of all hydrocarbons (1.29 g/cm3). This
makes it able to store large amounts of energy, although the
molecule is fully stable. As a matter of fact, cubane and its
derivatives are studied to produce new compact materials for
rocket engines, for instance. From the theoretical chemistry
point of view, this is a very intriguing molecule, because of its
high symmetry combined to these unique bonding properties.
Received: April 29, 2016
Revised: June 7, 2016
© XXXX American Chemical Society
A
DOI: 10.1021/acs.jpca.6b04323
J. Phys. Chem. A XXXX, XXX, XXX−XXX

The Journal of Physical Chemistry A
Article
model. More recently, Vlahacos and co-workers7 or also Jursic8
and Karpushenkava et al.9 made theoretical studies of this mole-
cule, using ab initio calculations.
II.B. Infrared Spectroscopy. All spectra were recorded
using the high-resolution Bruker IFS 125 Fourier transform
interferometer located on the AILES beamline of the SOLEIL
synchrotron facility together with the room temperature White
type cell for which the optics were adjusted to obtain 150 m
absorption path length. This setup has been already used
several times in the past to obtain the IR and far-IR spectra of
many relatively large C-bearing molecules, which are low vapor
pressure solids at room temperature (such as, e.g., adamantane1
and naphthalene10). The vibrational bands of cubane studied in
this work span over a large frequency range (600−3200 cm−1)
and exhibit large intensity differences (e.g., the intensity of the
ν11 fundamental band is calculated to be about 4 km.mol−1 and
that of the ν10 fundamental band to be about 135 km.mol−1).
To provide a relatively complete description of the IR spectrum
of cubane, we recorded six spectra with different experimental
conditions listed in Table 1. Our spectra were calibrated using
residual water absorption lines. We used the frequencies available
from HITRAN database11 concerning the H2O ν2 band.
Over this large range of experimental conditions, the rota-
tional analysis of the ν11 and ν12 bands were obtained by using
the conditions of spectrum 2. The very intense ν10 band
(spectrum 3) was obtained at lower resolution (due to a larger
Doppler broadening than for the ν11 and ν12 bands) and by
reducing the pressure. Increasing the gas pressure allowed the
detection of many combination bands (spectrum 4); their
rotational analysis (using spectra 5 and 6) is still in progress
and will be the subject of a next study.
We have chosen here to reinvestigate in detail the infrared
spectrum of this molecule, thanks to the AILES beamline of the
SOLEIL synchrotron facility. After a careful synthesis and char-
acterization of our sample, we could record many high-resolution
spectra over a wide spectral range. We performed a reanalysis of
the ν11 and ν12 fundamentals, leading to new accurate effective
Hamiltonian parameters. Thanks to new ab initio calculations it
was also possible to assign many combination bands, that were
never observed before.
Section II.A details the synthesis and characterization of our
cubane sample. Section II.B presents the experimental infrared
data. Our new quantum chemistry calculations are detailed in
section II.C, and their results relative to the assignment of com-
bination bands are presented in section III. Section III.A dis-
cusses the ground vibrational state rotational constant value.
Sections III.B, III.C, and III.D present the assignment and analysis
of the ν12 and ν11 fundamentals and discusses the highly perturbed
structures of the ν10 C−H stretching region. Finally, section III.F
compares our preliminary experimental results on combination
bands with the literature data.
II. LABORATORY METHODS
II.A. Synthesis and Characterization. All details con-
cerning the synthesis and characterization of our cubane sample
realized by the Bari group are provided in Appendix A.
Table 1. Experimental Conditions Used To Record Six Infrared Spectra of Cubane
