C O M M U N I C A T I O N S
five- or six-membered ring interacts most directly with Na+ or K+
is determined by structural as well as electronic factors. In nature,
indole is not attached to a constraining macroring, and it seems
likely that either aromatic subunit of indole may be available for
cation complexation. The abundance of Na+ and K+ ions in all
living systems makes interactions such as those modeled here
probable if not imperative.
Acknowledgment. We thank the NIH (GM-36262) and the PRF
(PRF 37197-AC4) for grants that supported this work.
References
(1) Jeffrey, G. A.; Saenger, W. Hydrogen Bonding in Biological Structures;
Springer-Verlag: Berlin, 1991.
(2) Creighton, T. E. Proteins: Structures and Molecular Properties, 2nd ed.;
W. H. Freeman and Co.: New York, 1993.
(3) Steed, J. W.; Atwood, J. L. Supramolecular Chemistry; John Wiley &
Sons, Ltd.: Chichester, 2000.
(4) Sutor, D. J. Nature 1962, 195, 68-69.
Figure 1.
(5) Houk, K. N.; Menzer, S.; Newton, S. P.; Raymo, F. M.; Stoddart, J. F.;
Williams, D. J. J. Am. Chem. Soc. 1999, 121, 1479-1487.
(6) Ma, J. C.; Dougherty, D. A. Chem. ReV. 1997, 97, 1303-1324.
(7) Sunner, J.; Nishizawa, K.; Kebarle, P. J. Phys. Chem. 1981, 85, 1814-
1820.
Compounds 4 and 5 are isomers of 2 and 3, respectively. The
structures of 4‚NaBPh4 and 5‚KPF6 are shown in Figure 1 (panels
d and e). When the sidearm is attached to indole’s 5- rather than
its 3-position, the cation-to-arene interaction occurs with the benzo,
rather than the pyrrolo, subcyclic unit. Even so, the isomeric
complexes show similar σ-bond distances (4, Na+-O average 2.38
Å; 5, K+-O average 2.78 Å). The Na+-arene distance in 4‚NaBPh4
is 2.75 Å, but the contact angle is ∼19° from perpendicular. The
K+-arene contact angle in 5‚KPF6 is nearly perpendicular, and
the distance from the metal ion to the centroid is only 2.97 Å. Note
that in both complexes, the M+-C2 distance is >4.5 Å.
(8) Ryzhov, V.; Dunbar, R. C.; Cerda, B.; Wesdemiotis, C. J. Am. Soc. Mass
Spectrom. 2000, 11, 1037-1046.
(9) Cabarcos, O. M.; Weinheimer, C. J.; Lisy, J. M. J. Chem. Phys. 1998,
108, 5151-5154.
(10) Guo, B. C.; Purnell, J. W.; Castleman, A. W., Jr. Chem. Phys. Lett. 1990,
168, 155-160.
(11) Ryzhov, V.; Dunbar, R. C. J. Am. Chem. Soc. 1999, 121, 2259-2268.
(12) Nicholas, J. B.; Hay, B. P.; Dixon, D. A. J. Phys. Chem. A 1999, 103,
1394-1400.
(13) Wouters, J. J. Comput. Chem. 2000, 21, 847-855.
(14) Gallivan, J. P.; Dougherty, D. A. J. Am. Chem. Soc. 2000, 122, 870-
874.
(15) Mecozzi, S.; A. P. West, J.; Dougherty, D. A. Proc. Natl. Acad. Sci. U.S.A.
1996, 93, 10566-10571.
The ionic radii23 of Na+ and K+ are ∼1.0-1.2 and ∼1.4-1.5
Å, respectively, depending on coordination number. The half-
thickness of an arene is reported to be 1.72-1.80 Å.24 Adding these
values, the shortest possible Na+-π and K+-π contacts should
be ∼2.7 and ∼3.1 Å. In 4‚NaBPh4 and 5‚KPF6, the observed
distances are 2.75 and 2.97 Å, respectively. In the previously
reported two-armed complexes, the M+-π contacts were all in the
3.4-3.5 Å range. Moreover, indole was observed to π-complex
exclusively with its pyrrolo, rather than its benzo, subunit.
The new receptor systems presented here show that indole, the
arene terminus of tryptophan, is a versatile π-donor. Whether the
(16) Dougherty, D. Science 1996, 271, 1163-1168.
(17) Wouters, J. Protein Sci. 1998, 7, 2472-2475.
(18) Wouters, J.; Maes, D. Acta Crystallogr. 2000, D56, 1201-1203.
(19) Gokel, G. W.; Wall, S. L. D.; Meadows, E. S. Eur. J. Org. Chem. 2000,
2967-2978.
(20) Meadows, E. S.; De Wall, S. L.; Barbour, L. J.; Gokel, G. W. J. Am.
Chem. Soc. 2001, 123, 3092-3107.
(21) Hu, J.; Barbour, L. J.; Gokel, G. W. Proc. Natl. Acad. Sci. U.S.A. 2002,
99, 5121-5126.
(22) Cram, D. J. Science 1988, 240, 760-7.
(23) Shannon, R. D. Acta Crystallogr. 1976, A32, 751-767.
(24) Bondi, A. J. Phys. Chem. 1964, 68, 441-451.
JA020586K
9
J. AM. CHEM. SOC. VOL. 124, NO. 37, 2002 10941
