A Novel PAA Derivative with Enhanced Drug Efficacy
in Pancreatic Cancer Cell Lines
Ali Alsuraifi 1,2 , Paul Kong Thoo Lin 3, Anthony Curtis 1 , Dimitrios A. Lamprou 4,
*
and
Clare Hoskins 1,
*
1
Institute of Science and Technology in Medicine, Keele University, Keele ST5 5BG, UK;
a.t.y.alsuraifi@keele.ac.uk (A.A.); a.d.m.curtis@keele.ac.uk (A.C.)
College of Dentistry, University of Basrah, Basrah 61004, Iraq
School of Pharmacy and Life Sciences, Robert Gordon University, Aberdeen AB10 7GJ, UK;
p.v.s.kong-thoo-lin@rgu.ac.uk
School of Pharmacy, Queen’s University Belfast, Belfast BT9 7BL, UK
Correspondence: d.lamprou@qub.ac.uk (D.A.L.); c.hoskins@keele.ac.uk (C.H.);
Tel.: +44-28-9097-2617 (D.A.L.); +44-17-8273-4799 (C.H.)
2
3
4
*
ꢀꢁꢂꢀꢃꢄꢅꢆꢇ
ꢀꢁꢂꢃꢄꢅꢆ
Received: 8 August 2018; Accepted: 19 September 2018; Published: 22 September 2018
Abstract: Nanoparticles have been shown to be effective drug carriers in cancer therapy.
Pancreatic cancer forms dense tumours which are often resistant to drug molecules. In
order to overcome such multidrug resistance, new drug entities, novel delivery systems and
combination therapy strategies are being explored. In this paper, we report the design and
synthesis of a poly(allylamine)-based amphiphile modified with hydrophobic naphthalimido
pendant groups. Bisnaphthalimide compounds have been shown to possess anticancer activity.
The potential of this polymer to encapsulate, solubilize and enhance drug (5-fluorouricil and
bis-(naphthalimidopropyl)-diaminooctane) cytotoxicity in BxPC-3 cells was evaluated.−O1 ur studies
−1
showed that the insoluble drugs could be formulated up to 4.3 mg mL and 2.4 mg mL inside the
amphiphiles, respectively. Additionally, the novel poly(allylamine)-naphthalimide carrier resulted in
an amplification of cytotoxic effect with drug treatment after 24 h, and was capable of reduction of
50% cell population at concentrations as low as 3 µg mL−1
.
Keywords: nanomedicine; nanopharmaceutics; drug solubilisation; pancreatic cancer; bisnaphthalimide
1. Introduction
Poor aqueous solubility or dissolution of active ingredients is one of the most significant problems
hindering effective drug delivery. More than 40% of new drugs under investigation have poor water
solubility and hence poor bioavailability [
co-solvents, micronization and nanonisation, amorphous solid dispersions (ASDs) [
formation [ ], surfactants [ ], complexation utilizing cyclodextrins [ ] and the use of polymers [
have been utilized to address this problem.
1
,
2
]. A number of solubility-enhancing strategies including
], co-crystal
10
3
4
5
6
7–
]
Amphiphilic polymers have been developed as a first-rate alternative to low molecule weight
surfactants for drug solubilisation. This is due to the lower excipient:drug ratios required
for solubilisation and a higher degree of stability due to the decreased critical aggregation
concentrations [11]. The most unique characteristic of amphiphilic polymers is their wide array
of structures and architectures [11,12]. Amphiphilic polymers may exist as block copolymers [13], graft
polymers [11], dendrimers [14] and star shaped polymers [15]. Each architecture has different physical
properties, but all can be used to solubilise hydrophobic compounds.
Amphiphilic poly(allylamine) (PAA) derivatives have been explored for their potential in drug
delivery [16–19]. Hoskins and colleagues assessed the in vitro and in vivo pancreatic anticancer
Pharmaceuticals 2018, 11, 91; doi:10.3390/ph11040091
www.mdpi.com/journal/pharmaceuticals

Pharmaceuticals 2018, 11, 91
2 of 13
action of a nano-sized novel poly(allylamine) derivative grafted with 5% cholesteryl pendant groups
(CH5-PAA) for the formulation of a novel bisnaphthalimide compound [16]. Bisnaphthalimide based
drugs act as DNA intercalators and have shown huge potential in pancreatic cancer therapy [16,20]
However, their activity is such that with increased drug potency, decreased drug solubility is observed.
Hence careful formulation strategies are required in order to render these potent anticancer agents
as clinically useable. Hoskins reported that after formulation into the CH5-PAA amphiphiles,
bis(naphthalimidopropyl)diaminooctane (BNIPDaoct) resulted in solubility enhancement up to
0.3 mg mL−1 [16]. The CH5-PAA did not demonstrate any significant toxicity, yet the formulation
demonstrated strong in vitro and in vivo anticancer action [16].
.
Here we report the synthesis and evaluation of a novel poly(allylamine) (PAA) derivative which is
grafted with 5% naphthalimide moieties (Figure 1a). The hydrophobic moieties used, are envisaged to
allow for greater insertion and stability within the hydrophobic core through π-π interactions between
the BNIPDaoct drug molecules (Figure 1b) and the planar naphthalimide pendant groups. Additionally,
the use of the naphthalimide pendant groups will confer some inherent anti-cancer activity to the
polymer itself. Ideally, for most drug delivery vehicles, biocompatibility is vital. However, in diseases
such as pancreatic cancer, combined treatment and innovative therapies are required in order to
overcome drug resistance and poor drug penetration. Nanotechnologies have shown to be useful for
this. As such, we propose that a synergistic reduction in cell viability will occur after formulation in
this system. It is proposed that these drug carriers if successful can be further functionalised with
targeting moieties in order to bring the payload cargo to the exact site hence reducing likelihood of
systemic toxicity.
O
O
O
O
N
(a)
TsCl, Pyridine
H N
OH
2
OH
Refluxing EtOH
O
(1)
O
Poly(allylamine), Cs2CO3
]
[
5%
N
O
OTs
H N
H N
H N
H N
2
NH
2
2
2
(2)
(3)
O
N
O
O
O
N
(b)
H
N
N
N
H
O
2HBr
O
Figure 1. Chemical structures for (a) synthesis of poly(allylamine)-propylnaphthalimide (PAA-N) and
(b) bis(naphthalimidopropyl)diaminooctane (BNIPDaoct).
The aggregation ability in aqueous environments and the ability to act as a drug solubilising agent
was determined using novel BNIPDaoct and 5-fluorouricil (5-FU). 5-FU is an anti-cancer drug, which
exerts its effects via inhibition of thymidylate synthase (TS) and the incorporation of its metabolites
into RNA and DNA [21]. Numerous studies have demonstrated the potential use of 5-FU in pancreatic
cancer as single therapy or in combination with the former gold standard treatment gemcitabine [22].
This study will evaluate whether the novel formulations formed, are capable of enhanced drug efficacy
in vitro compared with the free drugs.

Pharmaceuticals 2018, 11, 91
3 of 13
2. Results
2.1. Synthesis and Characterisation of Polymer
1
The structures of intermediates and products were analysed by H-NMR (Figure 2). Peak
assignments for the 1H-NMR spectra of the naphthalimido alcohol product 1 were as follows: 2 ppm
alkyl chain CH2, 3.6 ppm alkyl chain CH2 beside an O atom and O-H, 4.4 ppm alkyl chain CH2
beside a N atom and 7.8–8.6 ppm aromatic protons (Figure 2a). The O-tosyl spectrum (Figure 2b)
showed assigned peaks at 2.2 ppm alkyl chain CH2, 2.5 ppm CH3 attached to an aromatic ring,
4.3 ppm alkyl chain CH2s beside O and N atoms and 7.3–8.5 ppm aromatic protons. The PAA showed
characteristic peaks at 1.3 ppm CH2, 1.7 ppm CH, 2.2 ppm CH2 attached to -NH2 of PAA (Figure 2c).
After modification with the naphthalimide group (PAA-propylnaphthalimide, Figure 2d) the spectrum
showed additional aromatic proton peaks at 7.3–8.5 ppm, while the remaining propylnaphthalimide
peaks were overlapped with the PAA peaks. The peak at 3.3 ppm was due to water.
(a)
(b)
(c)
(d)
Figure 2. 1H-NMR spectra of (
(c) PAA in D2O and (d) PAA-N in D2O carried out using 300 MHz NMR at 25 C.
a
) compound 1 (Figure 1) in CDCl3 (
b
) compound 2 (Figure 1) in CDCl3,
◦
The FTIR spectrum of compound
was assigned to the O-H stretch, in addition to a strong carbonyl group absorption at 1640 cm−1
which confirms the synthesis was successful. In the spectra for compound the disappearance of
the hydroxyl group band suggests the esterification between compound
1
, (Figure S1a) displays a strong band at 3424 cm−1 that
2
1
and para-toluenesulfon−y1l
chloride occurred (Figure S1b). The PAA spectra (Figure S1c) showed characteristic peaks at 3377 cm
and 2846 cm−1 due to the N-H and C-H in the polymer backbone. PAA-N (Figure S1d) possessed
similar peaks to the PAA alone. However, the disappearance of strong peaks between 1410 cm−1 and
1177 cm−1, which related to the sulfonyl of the para-toluenesulfonyl group, confirms that the coupling
had been successful.
2.2. Characterisation of Nano-Aggregates
Hydrodynamic diameter, polydispersity index (PDI) and zeta (
ζ) potential were measured for the
PAA-N aggregates in aqueous solution. The data showed that the self-assemblies formed possessed a

Pharmaceuticals 2018, 11, 91
4 of 13
hydrodynamic diameter of 366
±
14 nm at 1 mg mL−1 (Figure 3a). The polydispersity of the aggregates
formed was 0.37 (Figure 3b), this indicated that the aggregates formed were relatively mono-disperse
in solution. The particle size (after storage in solution) was monitored over a 4-week period (Table S1),
no significant change in size was determined rendering the particles stable over this timeframe. The
amphiphiles possessed a positive surface charge in aqueous solution of +73 ± 1 mV (Figure 3c). This
charge is attributed to the high primary amine content in the backbone of the PAA.
(a)
(b)
PAA-N-BNIPDaoct
PAA-N-BNIPDaoct
PAA-N-5FU
PAA-N
PAA-N-5FU
PAA-N
0
100
200
300
400
0
0.2
0.4
0.6
Size, nm
PDI
(c)
(d)
0.075
0.07
PAA-N-BNIPDaoct
PAA-N-5FU
0.065
0.06
PAA-N
-20
0.055
0.001
30
80
0.01
0.1
1
10
Zeta potential, mV
Polymer concentration, mgmL-1
Figure 3. Characterisation of the nano-aggregates in aqueous media via (
spectroscopy and ( ) polydispersity index, ( ) zeta potential measurement (n = 3,
tension measurement.
a
±
) photon correlation
SD) and (d) surface
b
c
Surface tension measurement was used in order to determine the critical aggregation concentration
(CAC) in aqueous media of the self-assemblies formed. The surface tension graph for PAA-N
(Figure 3d) showed that the surface tension remains unchanged from that of water (0.00726 Nm−1
at very low concentrations (up to 0.065 mg mL−1). However, with increasing polymer concentration,
surface tension decreased dramatically. The CAC value was determined from the surface tension
)
graph to be 0.125 mg mL−1
.
TEM imaging of the PAA-N (Figure S2a) showed nano-aggregates had been formed. The size of
these aggregates was notably smaller compared to the photon correlation spectroscopy. This is due to
the discrete differences in technique and measurement: photon correlation spectroscopy measures the
hydrodynamic diameter in solution, which involves the interaction of the polymeric self-assemblies
with the water molecules, whereas TEM allows for direct measurement of the aggregates in a solid state.
2.3. Drug Loading and Release
Drugs (5-FU and BNIPDaoct) were loaded into the core of the self-assemblies via probe sonication.
The amount of drug encapsulated was quantified using UV-Vis spectroscopy and HPLC.
Figure 4 shows that the PAA-N self-assemblies were capable of solubilizing 2.4 mg mL−1 and
4.3 mg mL−1 of BNIPDacot and 5-FU, respectively (Figure 4a). The difference in drug incorporation
ability between the two drugs is possibly due to difference in molecular weight. The 5-FU exhibited
an encapsulation efficiency of 17% whilst the BNIPDaoct was encapsulated at 10% into the PAA-N
nano-aggregates. The 5-FU is a smaller molecule which may have resulted in greater quantities
physically fitting within the core space of the nano-aggregates. The size of the nano-aggregates after
drug loading was determined via photon correlation spectroscopy (Figure 3a) and TEM imaging

Pharmaceuticals 2018, 11, 91
5 of 13
(Figure S2a,b). Here the loaded particles appeared to undergo core compaction after drug loading
with the hydrodynamic radius reducing from 366 nm of the PAA-N to 159 nm and 220 nm after
drug incorporation (5-FU and BNIPDaoct respectively) (Figure 3a). This is likely due to the increase
in hydrophobicity after drug incorporation pulling the pendant groups closer, resulting in a tightly
packed compact aggregate. This trend was consistent with the smaller aggregates also being observed
in the TEM micrographs (Figure S2b,c). Stability studies over a 4-week period indicated no change in
particle size, as measured by photon correlation spectroscopy (Table S1).
(a)
(b)
100
80
60
40
20
0
5
4
3
2
1
0
*
PAA-N-BNIPDaoct
PAA-N-5FU
*
PAA-N-BNIPDacot
PAA-N-5FU
0
200 400 600 800 1000 1200 1400
Time, mins
Formulation
Figure 4. Drug loading (a) and release (b) studies of 5-FU and BNIPDaoct into and from PAA-N
self-assemblies (n = 3, SD). * denotes a significant increase in aqueous solubility compared to the
±
unformulated drug (p < 0.01). Studies were quantified using UV-Vis spectroscopy (5-FU) and HPLC
(BNIPDoact).
It is not expected that drug loading into the core of polymeric self-assemblies should result
in a change in zeta potential measurement. This is due to the fact that the surface charge of the
aggregates should remain unchanged if a drug has been successfully incorporated into the core. As
evident in Figure 3c, incorporation of 5-FU into the PAA-N did not result in any significant changes in
surface charge. However, the data from the BNIPDaoct loaded PAA-N aggregates showed a dramatic
reduction in surface charge from +73 mV to +3.6 mV. The reason for this is not known. The BNIPDaoct
is a polyamine-based drug and hence when protonated should have an overall net positive charge
and, therefore, should not form charge-charge complexes with the cationic PAA-N. However, the
naphthalimide moieties at each end of the polyamine chain do carry residues with a high electron
density. Therefore it may be possible that the drug molecules BNIPDaoct, have become anchored
into the self-assemblies with one of the naphthalimido groups of the drug sitting exterior to the core.
Further investigation would be needed to confirm this theory.
Drug release studies (Figure 4b) were carried out in water at room temperature over 24 h. The data
showed that the BNIPDaoct loaded aggregates discharged their drug payload more rapidly than the
5-FU loaded aggregates. Both formulations experienced 25% drug release within the first hour. After
24 h the BNIPDaoct had released 73% of drug compared with only 43% of the 5-FU being released.
This may have been due to the internalization mechanism of the drugs. Theoretically, the BNIPDaoct
would have been expected to have been retained within the hydrophobic core of the self-assemblies
for much longer than the 5-FU. This is due to the greater degree of hydrophobicity of the BNIPDaoct
compared with the 5-FU as evidenced by their respective intrinsic solubilities. Additionally, it was
postulated that upon inserting within the hydrophobic core, the BNIPDaoct would be able to stack
in close proximity with little steric hindrance due to the planar nature of the molecule. However,
given the large decrease in zeta potential observed (Figure 2a) after BNIPDaoct incorporation, this
may not be the case, and hence, the more rapid drug release compared to the smaller 5-FU molecule.
This finding does support the suggestion that polymer-drug complexation is occurring which is more
rapidly broken down compared to the time taken for 5-FU to become un-encapsulated.

Pharmaceuticals 2018, 11, 91
6 of 13
2.4. Cytotoxic Activity
The cytotoxic effect of PAA-N, BNIPDaoct, 5-fluorouracil, PAA-N-BNIPDaoct and PAA-N-5FU
was determined by MTT assay in BxPC-3 cells after 24 h exposure (Figure 5). The data showed that
both free drugs did not result in any significant decrease in cell viability over the concentrations tested.
100
90
80
*
70
*
60
PAA-N
5-FU
PAA-N-5FU
BNIPDacot
PAA-N-BNIPDaoct
50
40
30
20
10
0
*
*
*
*
*
*
*
*
*
*
*
*
0
0.02
0.04
0.06
0.08
0.1
Drug concentration, mgmL-1
Figure 5. Cytotoxicity of 5-FU and BNIPDaoct loaded PAA-N in BxPC-3 cells after 24 h exposure (n = 3
,
± SD). * denotes a significant reduction in viability compared with the control cells (p < 0.01).
The PAA-N carrier possessed an IC50 value of approximately 28
to 7.5
g mL−1 after 5-FU incorporation. The BNIPDaoct formulation was more potent with IC50
observed at 3
µ
g mL−1 which was reduced
µ
−1 −1
g mL (10-fold). Interestingly, 0.05 mg mL the PAA-N-5FU appeared less toxic than
µ
the empty carrier (PAA-N). However, upon further increase in concentration this appeared similar.
2.5. Cellular Uptake of Drug
Drug uptake in BxPC-3 cells was measured quantitatively using UV-Vis spectroscopy (5-FU) and
HPLC (BNIPDoact) allowing for the amount of drug per cell to be estimated. Figure 6a shows the
amount of 5-FU internalised into the cells, here it is evident that the 5-FU encapsulated within the
PAA-N resulted in significantly greater (p < 0.001) uptake compared to the free drug. The BNIPDaoct
resulted in greater cellular internalisation (Figure 6b) compared with the 5-FU. The enhancement of
cellular internalisation due to the polymer encapsulation was not as pronounced in these studies.
However, the intrinsic solubility of the free drug was so low that in order to administer to the cells,
DMSO was required to solubilise the drug. This ability to become solubilised in organic solvents, means
the BNIPDaoct is more likely to permeate well into the cells without the use of excipients—however,
in order to be administered intravenously in patients, this highly insoluble drug does need to be
solubilised initially.
Cellular uptake of the BNIPDaoct both free and in formulation can be observed in Figure 6c and
Figure S3. Interestingly the polymer alone did not result in a fluorescent signal despite the presence
of the naphthalimido moieties in its backbone (Figure S3(a1,a2)). This could be due to two reasons
(i) The polymer concentration is so low (below the detection limit) and hence the relative quantity
of the fluorophore is negligible, or (ii) the self-assembly structure of the hydrophobic naphthalimide
pendant moiety into the core of the aggregate has shielded its fluorescence ability. This phenomenon
was observed after both 4 h (Figure S3(a1)) and 24 h (Figure S3(a2)).

Pharmaceuticals 2018, 11, 91
7 of 13
(a)
(b)
30
60
50
40
30
20
10
0
4 h
24 h
4 h
24 h
*
*
25
20
15
10
5
*
0
BNIPDaoct
PAA-N-BNIPDaoct
5-FU
PAA-N-5FU
(c1)
(c2)
(c3)
200 µm
200 µm
200 µm
Figure 6. Intracellular drug uptake of PAA-N loaded aggregates with (
into BxPC-3 cells exposed to 50
g mL−1 for 4 h and 24 h measured by UV-Vis spectroscopy and
HPLC respectively (n = 3, SD). * denotes significant increase compared with the free drug (p < 0.01).
) Fluorescence microscopy of PAA-N-BNIPDaoct internalised within BxPC-3 cells: 1: control, 2: 4 h
a) 5-FU and (b) BNIPDaoct
µ
±
(
c
incubation and 3: 24 h incubation.
A further interesting phenomenon was observed which did not match with the HPLC data for
cellular internalisation: After both 4 h and 24 h images of the drug alone (Figure S3(b1,b2)) showed
minimal fluorescence compared with the polymer loaded samples (Figure 6(c2,c3)). The reason for
this is not known. However, the general trend shows greater internalisation after incorporation
into nanoparticles and is likely to be due to the difference in cellular internalisation mechanism
whereby, consistently across a breadth of studies, intracellular drug concentrations are increased
after incorporation into or onto nanoparticles [23–26]. This is reportedly due to the internalisation
of nanoparticle vehicles via endocytosis, a phenomenon rarely reported for single drug molecules.
Instead, the drug molecules are likely to enter the cells via the tight junction or other diffusion driven
pathways with often take longer compared with endocytosis. However, the reason that this was not
observed in the quantitative study is not known (and perhaps is explained by instrument sensitivity),
although these findings do agree with the cytotoxicity data trend.
3. Discussion
This study highlights the potential of a naphthalimide grafted polyallylamine as a dual functioning
platform for increased efficacy in pancreatic cancer cell lines. Here, we reported the successful
synthesis and characterisation of the comb shaped polymer. We have demonstrated its ability to form
nano-self assemblies capable of incorporation of hydrophobic drug entities into their lipophilic core.
Poly(allyamine) (PAA)-based comb polymers have been reported previously to act as universal drug
solubilising agents [27]. In particular to formulate novel bisnaphthalimide molecules. One previous
study reported 0.3 mg mL−1 solubility of BNIPDaoct within PAA-Ch5 [16]. In another study the
PAA was modified with a hydrophobic oxadiazole pendant group which resulted in 9.88 mg mL−1
BNIPDaoct solubilisation [18]. This highly potent drug has proven effective in vitro as a potential
chemotherapy agent, however, clinical usage is severely hindered by its almost negligible solubility.
Previous solubility studies showed some enhancement; however, the relatively low solubilisation
potential results in higher excipient:drug ratios and, hence, more expensive therapies [16
,18]. In
this study we have shown that by substituting the bulky cholesteryl and oxadiazole moieties used

Pharmaceuticals 2018, 11, 91
8 of 13
previously with a planar naphthalimido moiety, greater quantity of drug compound can be introduced
into the hydrophobic core in a ‘like dissolves like’ manner. Additionally, we believe that the planar
nature of functionalities within the formulation may make the resultant nano-aggregates highly stable
in solution as observed in our stability measurements. Interestingly, we observed that loading both
anticancer drugs 5-FU and BNIPDaoct into the core resulted in particle compaction. This may be
due to the planar nature of both the drug and formulation allowing for a less sterically hindered
system, whereby drug molecules sit closer together forming a hydrophobic ‘strong-hold’. Such size
phenomena has previously been reported elsewhere [28
reduction upon drug loading, which was explained by a lowering in aggregation number, erosion
as well as hydrolysis [28
29]. Using our system, we were able to solubilise up to 2.4 mg mL−1 of
,29]: polymeric micelles experienced size
,
BNIPDaoct which was an 8-fold improvement on previous findings.
Previous reports on the use of aromatic pendant groups attached to PAA had demonstrated a
level of intramolecular and intermolecular aggregations [27]. In this study, we only observed one
aggregation mechanism. This may be due to the smaller size of the naphthalimido moieties not
harnessing enough hydrophobicity to initiate intramolecular aggregation so, therefore, relying solely
on intermolecular aggregation where more than one polymer strand is required for nano self-assembly.
The zeta potential measurement after 5-FU loading was expectedly similar to the unloaded
vehicle. This finding agrees with the principle that if the drug inserts fully into the hydrophobic
core, it will become shielded from the exterior environment—which includes all of its charges and
ability to interact. However, for BNIPDaoct the zeta potential measurement obtained after sonication
was curious. Here, the data appeared to show a dramatic shift in zeta potential. Previously, PAA
amphiphiles have been shown to be effective complexing agents for biological molecules such as
insulin and salmon calcitonin [30–32]. Here, the charge-charge interactions initiate complex formation
and hold the constituents tightly into the nanoparticles. It is possible that complex formation occurred
between the BNIPDaoct, however, we do not think that is likely due to the polyamine chain resulting
in a net positive charge on the molecule, a phenomena which we have previously been able to exploit
for attachment onto negatively charged gold nanoparticle surfaces [20]. Hence, it may be the case
that the linear drug molecules are either experiencing one of the naphthalimido moieties in their
structure anchoring into the lipophilic self-assembly core with the other directed towards the surface.
Alternatively, the naphthalimido moieties are anchored into different cores of two self-assemblies
hence stitching them together—therefore the drug molecules are sitting more towards the surface of
the macromolecules. Looking at the irregular morphology of these aggregates in the TEM (Figure S2c)
compared with those loaded with 5-FU (Figure S2b) this may be likely. However, further investigation
is required to confirm such a hypothesis.
This polymer was intentionally designed not only to allow greater insertion of drug molecules
into its core compared with our previous system [16], but also to possess its own inherent cytotoxic
nature. This may seem counterintuitive for a drug delivery vehicle. However, in diseases such as
pancreatic cancer, extremely harsh therapies are required in order to eradicate the rapidly proliferating
cells. We believe that the more stable particulates formed will result in less breakdown, premature
release of drug and also exposure of hydrophobic pendant group to the external environment. This
study serves as a proof of concept to elucidate whether the naphthalimide moieties could result in an
increase in therapeutic effect in combination with the bisnaphthalimide drugs. This study resulted
in a drug formulation exhibiting an IC50 of 3
studies [16] with the same drug we had achieved slightly lower IC50 values of 0.7
µ
g mL−1 against pancreatic cancer cells. In previous
g mL−1, however,
µ
this was after 48 h drug exposure and not 24 h as in this work. Additionally, in previous reports we
have demonstrated no observable IC50 for the previous gold standard treatment gemcitabine in BxPC-3
cells after 24 h [20], showing that this formulation is notably more rapid in its potency. Therefore,
we believe there is some potential in our findings and currently further investigations are underway
in order to determine whether this formulation may be modified in a manner which will allow for
safe nanoparticle travel in the bloodstream before actively seeking out the pancreatic tumours. We

Pharmaceuticals 2018, 11, 91
9 of 13
must first address the timeliness of drug release in the context of application and time for intracellular
tracking. We will do this by exploiting active targeting mechanisms alongside exploitation of the highly
specific flora within the tumour microenvironment in order to render a stimuli responsive system. In
addition, further in vitro evaluation is required in non-cancerous cell lines in order to estimate the
extent of toxicity to health tissue which will help inform the surface engineering of non-toxic polymers
anchored onto the nano-aggregate surface to render more effective biocompatibility.
4. Materials and Methods
4.1. General Information
Poly(allylamine) (PAA) (MW:17,500), 1,8-naphthalic anhydride, 3-aminopropan-1-ol,
para-toluenesulfonyl chloride and caesium carbonate were purchased from Alfa Aesar (Heysham, UK).
Chloroform, diethyl ether, ethanol and anhydrous pyridine were purchased from Fisher Scientific
(Loughborough, UK). Deuterated chloroform, deuterated dimethyl sulfoxide and deuterium oxide
were purchased from Apollo Scientific Limited (Stockport, UK). Human pancreatic adenocarcinoma
(BxPC-3) cells were obtained from ATCC (Manassas, VA, USA). Foetal bovine serum, Roswell Park
Memorial Institute Medium (RPMI) 1640, trypsin and penicillin streptomycin were purchased from
Life Technologies (Runcorn, UK).
4.2. Synthesis and Characterisation of Polymer
4.2.1. Reaction of 1,8-Naphthalic Anhydride with 3-Aminopropan-1-ol: Synthesis of
N-(3-Hydroxy-propyl)Naphthalimide (1)
1,8-Naphthalic anhydride (3.96 g, 0.02 mmol) was suspended in ethanol (100 mL) in a 250 cm3
round bottom flask. The suspension was stirred using a magnetic stirrer and bar. 3-Aminopropan-1-ol
(1.5 g, 0.02 mmol) was added to the mixture dropwise. The mixture was heated to reflux for 15 h and
was then allowed to cool. A small amount of ethanol was removed using a rotary e◦vaporator until a
solid precipitate began to form. The mixture was then cooled in the refrigerator (3–5 C) until no more
precipitate formed. The mixture was filtered under vacuum (Buchner funnel and flask) and the pale
cream crystalline precipitate was dried on the filter. The dried precipitate was crystallised from ethanol,
filtered and the crystalline product dried in vacuum at 60 ◦C to give pale cream-coloured needles.
4.2.2. Tosylation of N-(3-Hydroxypropyl)Naphthalimide (1): Synthesis of 3-tosyloxypropyl)
naphthalimide (2)
N-(3-Hydroxypropyl)naphthalimide (1, 2.55 g, 10 mmol) was dissolved in anhydrous pyridine
(dried over solid KOH) (80 mL) in a dry 250 cm3 round bottom flask. The reaction solution was left
to stir at 0 ◦C for 10 min. After this time para-toluenesulfonyl chloride (2.86 g, 15 mmol) was added
◦
dropwise over 30 min. The mixture was then stored at 4 C in a refrigerator overnight. The refrigerated
mixture was poured slowly onto 200 mL icy water in a 500 mL beaker, followed by vigorous stirring to
deliver a viscous liquid that solidified quickly on cooling. The solid was filtered through a Buchner
funnel and washed with water several times. The dried precipitate was crystallised from ethanol,
filtered and the crystalline product dried in vacuum at 60 ◦C to give a white powdery precipitate.
4.2.3. Liberation of PAA Free Base
PAA-HCl salt (10 g) was dissolved in deionised water. Sodium hydroxide (8 g) was added into
the solution until pH 13 was achieved. The mixture was subsequently stirred for 1 h. After this time
the PAA solution was exhaustively dialysed against water using 7000 Dalton Visking membrane for
24 h. The resultant solution was freeze-dried to obtain a white solid.

Pharmaceuticals 2018, 11, 91
10 of 13
4.2.4. Synthesis of PAA-Propylnaphthalimide (3)
PAA (1 g) was dissolved in dissolved in 1:1 (v/v) methanol: chloroform (30 mL) with stirring.
N-(3-tosyloxypropyl)naphthalimide (0.605 g) was added to solution followed immediately by caesium
carbonate (1.2 g) and the mixture was stirred at room temperature for 24 h. The solvent was removed
using a rotary evaporator and the polymer residue was washed three times with diethyl ether and
subsequently dried. The product was purified by dissolving in water and exhaustive dialysis (Visking
membrane, molecular weight cut-off = 12–14 kDa) against deionized water (3 L) with six changes over
24 h. The resultant solution was freeze-dried.
4.3. Characterisation of Self-Assemblies
Self-assemblies were formed by dissolving solid polymer in water. The solutions were probe
sonicated for 5 min before filtration through a 0.45 µm syringe filter.
4.3.1. Characterisation Using Photon Correlation Spectroscopy and Zeta Potential Measurement
Nano-aggregate solutions/formulations were formed in water and analysed for their size
and surface charge. The size was monitored over a 4-week period. Hydrodynamic diameter,
polydispersity index (PDI) and zeta (ζ) potential measurements were performed using PCS on a
Zetasizer Nano-ZS (Malvern Instruments, Malvern, UK). The data presented are the averaged values
of three successive measurements.
4.3.2. Transmission Electronic Microscopy (TEM) Imaging
Transmission electron microscopy (TEM) was used to visualise the polymer formulas. Imaging
was performed and processed using a JEOL 1200 EX-FDL5000 microscope (Jeol, Tokyo, Japan)
transmission electron microscope. TEM samples were prepared by placing one drop of the formulations
prepared as described above, onto formvar/carbon-coated 200 mesh nickel grids and dried under a
heat lamp for 3 h.
4.3.3. Surface Tension Measurement
The surface tension of polymer formulation was investigated by a torsion balance (Torsion
Balance Supplies, Weston-super-Mare, UK). In brief, various concentrations (0.00195–3 mg mL−1) of
naphthalimide-PAA were prepared in deionised water. Samples were sonicated for 5 min using a
probe sonicator the samples were cooled to room temperature, after which the surface tension was
measured. All experiments were run in triplicate. Critical aggregation concentration was indicated by
dramatic reduction in surface tension, as observed by inflection in the graph.
4.4. Drug Loading
Polymer was dissolved in deionised water (1 mg mL−1) and probe sonicated for 10 min using
a Soniprep 150 (Wolflabs, Pocklington, UK). The hydrophobic drug (5 mg mL−1) of was added
individually at 5:1 initial drug:polymer weight ratio and the drug-polymer solutions were probe
sonicated for a further 10 min. The polymer solutions were filtered using a 0.45 µm syringe filter. The
drug content was quantified: 5-FU by UV-visible spectroscopy at 256 nm (in DMSO) and BNIPDaoct
using the reverse phase high performance liquid chromatography (HPLC) coupled to a fluorescent
detector using a RP Zorbax ODS 250 mm
×
46 mm
×
5 µm HPLC column (Hichrom, Lutterworth,
UK). The mobile phase was 55:45 (v/v) buffer:acetonitrile and the flow rate was 1 mL min−1. The
buffer for the mobile phase was made up of 0.432 g octane sulfonic acid and 1.64 g anhydrous
sodium acetate made up to 200 mL with deionised water, which the solution was subsequently pH
adjusted to pH 4.5. The flow rate was set at 1 mL min−1, 20
µL injection volume and excitation and
emission wavelengths set to 234 nm and 294 nm respectively. Control samples of polymer alone were
run and subtracted from the data in order to eliminate any fluorescence due to the naphthalimide

Pharmaceuticals 2018, 11, 91
11 of 13
residues within the intrinsic polymer structure (for the BNIPDaoct formulation samples). The solutions
were compared to calibrations of their respective drugs (R2 = 0.999 for 5-FU and R2 = 0.998 for
BNIPDaoct), all experiments were run in triplicate. Encapsulation efficiencies (EE) were calculated to
be: % EE = (drug concentration determined by HPLC/original drug concentration) × 100%.
4.5. Drug Release
Formulations (2 mL) were pipetted into Visking membrane of 12–14 KDaltons and dialysed
against deionised water for 24 h. At set time intervals (e.g., 1 min, 5 min, 10 min etc.), 1 mL of water
was removed and drug content analysed as previously described. The cumulative drug release profile
was calculated in respect to drug loading concentration. All experiments were run in triplicate.
4.6. Cytotoxic Activity
For evaluation of the cytotoxic potential of PAA-N: drug aggregates, an MTT assay was performed
in comparison with PAA-N alone and free drugs, in equivalent weight as in PAA-N: drug aggregates)
at 24 h incubation time. In brief, human pancreatic adenocarcinoma (BxPC-3) cells were cultured in
RPMI medium containing 10% foetal bovine serum (FBS) and 1% penicillin streptomycin (P/S). Cells
were sub-cultured into a 96-well plate at, and then the plates were incubated in the incubator at 37 ◦C
in humidified 5% CO2 atmosphere. Cells were then treated with PAA-N alone, PAA-N-BNIDaoct,
PAA-N-5FU, and free drugs BNIPDaoct and 5-fluorouracil (dissolved in DMSO—Stock solutions
of 20 mg mL−1 were prepared and diluted with cell culture media). Once 70% cell confluence was
achieved the media was removed and replaced with the drugs or formulations (0.00001–0.1 mg mL−1).
Following this, the media was removed and replaced with a 100
incubated for 4 h. After which, the absorbance of the formazan solution is read spectrophotometrically
at 570 nm and cell viability was calculated with respect to the controls. PBS and Triton X (80 L each)
µL solution of 10% MTT in media and
µ
were used as the negative and positive controls respectively. All experiments were run independently
in triplicate.
4.7. Cellular Uptake of Drug
4.7.1. Intracellular Drug Concentration
BxPC-3 cells were seeded at a density of (50,000 cells/well) into 6-well plates and incubated for
24 h. The media was then replaced with 50 µ
g mL−1 solution of formulation, or free drug as well
as the polymer alone (at equivalent concentration) diluted in media. The plates were incubated for
◦
4 h and 24 h at 37 C. Following incubation, the media was removed and the cells were washed
three times with PBS and trypsinised. The cell suspension was counted for viable cells and 100,000
cells transferred into an Eppendorf tube. Deionised water (1 mL) was added to lyse the cells and the
tube was centrifuged at 500 rpm for 5 min in a Z-323 centrifuge (Hermule, Wehingen, Germany) to
remove the cell debris. The supernatant was removed and diluted in DMSO for 5-FU and 55:45 (v/v)
buffer: acetonitrile (previously described) for BNIPDaoct. Control samples of polymer alone were
run and subtracted from the data in order to eliminate any fluorescence due to the naphthalimide
residues within the intrinsic polymer structure (for the BNIPDaoct formulation samples). Drug content
was measured as previously described and calculated per cell. All experiments were carried out
in triplicate.
4.7.2. Fluorescence Microscopy
Cell lines were seeded onto glass cover slip in 6-well plates (50,000 cells/well) and treated as
described above. After washing, the cells were fixed with 2% paraformaldehyde for 10 min and
further washed three times with PBS. The glass slips were fixed on the glass slides and visualised by
fluorescence microscopy (Invitrogen, EVOSTM, Runcorn, UK).

Pharmaceuticals 2018, 11, 91
12 of 13
5. Conclusions
This study highlights the potential of PAA-N as a drug solubilising agent in order to
amplify the therapeutic effect in pancreatic cancer cell lines, particularly in combination with
bisnaphthalimide-based anti-tumour drug molecules. These exciting findings will inform the second
generation of such delivery systems whereby complete physiological protection of the drug molecule
and polymer will be conferred until site specific delivery of drug is achieved. This will be realised
through surface decoration with targeting moieties and additional stimuli responsive residues in order
to ensure safety before reaching the target site.
Supplementary Materials: The following are available online at http://www.mdpi.com/1424-8247/11/4/91/s1,
Figure S1. FTIR spectra of (a) Compound (1), (b) Compound (2), (c) PAA and (d) PAA-N. Spectra an average of 64
scans. Figure S2. Transmission electron micrographs of (a) PAA-N, (b) PAA-N-5FU and (c) PAA-N-BNIPDaoct.
Figure S3. Fluorescence microscopy of BNIPDaoct loaded PAA-N internalised within BxPC-3 cells after (a) 4 h
and (b) 24 h with 1: PAA-N and 2: BNIPDaoct. Table S1. Size of nano-aggregates over 4-week period as measured
by photon correlation spectroscopy.
Author Contributions: A.A. carried out the laboratory work. P.K.T.L., A.C., D.A.L. and C.H. supervised the work.
C.H. wrote the manuscript. All authors read and approved the manuscript before submission.
Funding: This work was funded by the Iraqi Ministry of Higher Education and Scientific Research (MOHSER).
Conflicts of Interest: The authors declare no conflict of interest.
References
1.
2.
3.
4.
5.
6.
7.
8.
9.
Hoskins, C.; Papachristou, A.; Ho, T.M.H.; Hine, J.; Curtis, A.D.M. Investigation into Drug Solubilisation
Potential of Sulfonated Calix[4]Resorcinarenes. J. Nanomed. Nanotechnol. 2016, 7, 2.
Zahari, V.; Petra, D.; Slavka, T. Effect of Surfactant Molecular Structure on Progesterone Solubilisation.
J. Drug Deliv. Sci. Technol. 2018, 43, 44–49.
Teja, S.B.; Patil, S.P.; Shete, G.; Patel, S.; Bansal, A.K. Drug-Excipient Behaviour in Polymeric Amorphous
Solid Dispersions. J. Excipients Food Chem. 2013, 4, 70–94.
Panzade, P.; Shendarkar, G.; Shaikh, S.; Rathi, P.B. Pharmaceutical Cocrystal of Piroxicam: Design,
Formulation and Evaluation. Adv. Pharm. Bull. 2017, 7, 399–408. [CrossRef] [PubMed]
Rangel-Yagul, C.O.; Pessoa Jnr, A.; Tavares, L.C. Micellar Solubilization of Drugs. J. Pharm. Pharmaceut. Sci.
2005, 8, 147–163.
Loftsson, T.; Brewster, M.E. Pharmaceutical Applications of Cyclodextrins. 1. Drug Solubilization and
Stabilization. J. Pharm. Sci. 1996, 85, 1017–1025. [CrossRef] [PubMed]
Lu, Y.; Park, K. Polymeric Micelles and Alternative Nanonized Drug Delivery Vehicles for Poorly Soluble
Drugs. Int. J. Pharm. 2013, 453, 198–214. [CrossRef] [PubMed]
Yu, B.G.; Okano, T.; Kataoka, K.; Kwon, G. Polymeric Micelles for Drug Delivery: Solubilization and
Haemolytic Activity of Amphotericin B. J. Control. Release 1998, 53, 131–136. [CrossRef]
Kulthe, S.S.; Choudhari, Y.M.; Inamdar, N.N.; Mourya, V. Polymeric Micelle: Authorative Aspects for Drug
Delivery. Des. Monomers Polym. 2012, 15, 465–521. [CrossRef]
10. Xu, W.; Ling, P.; Zhang, T. Polymeric Micelles, a Promising Drug Delivery System to Enhance Bioavailability
of Poorly Water-Soluble Drugs. J. Drug Deliv. 2013, 2013, 340315. [CrossRef] [PubMed]
11. Hoskins, C.; Kong Thoo-Lin, P.; Cheng, W.P. A Review on Comb-Shaped Amphiphilic Polymers for
Hydrophobic Drug Solubilisation. Therapeut. Deliv. 2012, 3, 59–79. [CrossRef]
12. Rinkenauer, A.C.; Schubert, S.; Traeger, A.; Schubert, U.S. The Influence of Polymer Architecture on In Vitro
pDNA Transfection. J. Mater. Chem. B 2015, 3, 7477–7493. [CrossRef]
13. Förster, A.; Markus, A. Amphiphilic Block Copolymers in Structure Controlled. Adv. Mater. 1998, 10, 195–217.
[CrossRef]
14. Choudhary, S.; Gupta, L.; Rani, S.; Dave, K.; Gupta, U. Impact of Dendrimers on Solubility of Hydrophobic
Drug Molecules. Front. Pharmacol. 2017, 8, 261. [CrossRef] [PubMed]
15. Ooya, T.; Lee, J.; Park, K. Effects of Ethylene Glycol-Based Graft, Star-Shaped, and Dendritic Polymers on
Solubilisation and Controlled Release of Paclitaxel. J. Control. Release 2003, 93, 121–127. [CrossRef] [PubMed]

Pharmaceuticals 2018, 11, 91
13 of 13
16. Hoskins, C.; Ouaissi, M.; Lima, S.C.; Cheng, W.P.; Loureirio, I.; Mas, E.; Lombardo, D.; Cordeiro-da-Silva, A.;
Ouaissi, A.; Kong Thoo Lin, P. In Vitro and In Vivo Anticancer Activity of a Novel Nano-Sized Formulation
Based on Self-Assembling Polymers Against Pancreatic Cancer. Pharm. Res. 2010, 27, 2694–2703. [CrossRef]
[PubMed]
17. Al-Shakarchi, W.; Alsuraifi, A.; Curtis, A.; Hoskins, C. Dual Acting Polymeric Nano-Aggregates for Liver
Cancer Therapy. Pharmaceutics 2018, 10, 63. [CrossRef] [PubMed]
18. Barnett, C.M.; Martin, L.R.; Curtis, A.; Kong Thoo Lin, P.; Cheng, W.P.; Hoskins, C. Poly(Allylamine)
Magnetomicelles for Image Guided Drug Delivery. Pharmaceut. Nanotechnol. 2013, 1, 224–238. [CrossRef]
19. Zafar, A.; Pilkington, L.I.; Haverkate, N.A.; van Rensburg, M.; Leung, E.; Kumara, S.; Denny, W.A.;
Barker, D.; Alsuraifi, A.; Hoskins, C.; et al. Investigation into Improving the Aqueous Solubility of the
Thieno[2,3-b]Pyridine Anti-Proliferative Agents. Molecules 2018, 23, 145. [CrossRef] [PubMed]
20. Malekigorji, M.; Alfahad, M.; Kong Thoo Lin, P.; Jones, S.; Curtis, A.; Hoskins, C. Thermally Triggered
Theranostics for Pancreatic Cancer Therapy. Nanoscale 2017, 9, 12735–12745. [CrossRef] [PubMed]
21. Harrap, K.R.; Jackman, A.L.; Newell, D.R.; Taylor, G.A.; Hughes, L.R.; Calvert, A.H. Thymidylate Synthase:
A Target for Anticancer Drug Design. Adv. Enzyme Reg. 1989, 29, 161–179. [CrossRef]
22. Wang, W.B.; Yang, Y.; Zhao, Y.P.; Zhang, T.P.; Liao, Q.; Shu, H. Recent Studies of 5-Fluorouricil Resistance in
Pancreatic Cancer. World J. Gastrenterol. 2014, 20, 15682–15690. [CrossRef] [PubMed]
23. Kou, L.; Sun, J.; Zhai, Y.; He, Z. The Endocytosis and Intracellular Fate of Nanomedicines: Implication for
Rational Design. Asian J. Pharm. Sci. 2013, 8, 1–10. [CrossRef]
24. Akinc, A.; Battaglia, G. Exploiting Endocytosis for Nanomedicines. Cold Spring Harb. Perspect. Biol. 2013, 5,
a016980. [CrossRef] [PubMed]
25. Sahay, G.; Alakhova, D.Y.; Kabanov, A.V. Endocytosis of Nanomedicines. J. Control. Release 2010, 145, 182–195.
[CrossRef] [PubMed]
26. Salatin, S.; Khosroushahi, A.Y. Overviews on the Cellular Uptake Mechanism of Polysaccharide Colloidal
Nanoparticles. J. Cell. Mol. Med. 2017, 21, 1668–1686. [CrossRef] [PubMed]
27. Hoskins, C.; Kong Thoo Lin, P.; Tetley, L.; Cheng, W.P. Novel Fluorescent Amphiphilic Poly(Allylamine) and
Their Supramolecular Self-Assemblies in Aqueous Media. Polym. Adv. Technol. 2012, 23, 710–719. [CrossRef]
28. Sharma, P.K.; Bhatia, S.R. Effect of Anti-Inflammatories on Pluronic F127: Micellar Assembly, Gelation and
Partitioning. Int. J. Pharm. 2004, 278, 361–377. [CrossRef] [PubMed]
29. Basak, R.; Bandyopadhyay, R. Encapsulation of Hydrophobic Drugs in Pluronic F127 Micelles: Effects of
Drug Hydrophobicity, Solution Temperature, and pH. Langmuir 2013, 29, 4350–4356. [CrossRef] [PubMed]
30. Thompson, C.J.; Cheng, W.P.; Gadad, P.; Skene, K.; Smith, M.; Smith, G.; McKinnon, A.; Knott, R. Uptake
and Transport of Novel Amphiphilic Polyelectrolyte-Insulin Nanocomplexes by Caco-2 Cells-Towards Oral
Insulin. Pharm. Res. 2001, 28, 886–896. [CrossRef] [PubMed]
31. Cheng, W.P.; Thompson, C.; Ryan, S.M.; Aguirre, T.; Tetley, L.; Brayden, D.J. In Vitro and in vivo
Characterisation of a Novel Peptide Delivery System: Amphiphilic Polyelectrolyte-Salmon Calcitonin
Nanocomplexes. J. Control. Release. 2010, 147, 289–297. [CrossRef] [PubMed]
32. Thompson, C.J.; Uchegbu, I.F.; Tetley, L.; Cheng, W.P. The Use of Novel Combed Shaped Amphiphilic
Polymers for Oral Delivery of Insulin. Int. J. Pharm. 2005, 376, 46–55. [CrossRef] [PubMed]
©
2018 by the authors. Licensee MDPI, Basel, Switzerland. This article is an open access
article distributed under the terms and conditions of the Creative Commons Attribution
(CC BY) license (http://creativecommons.org/licenses/by/4.0/).
