Photoswitching of Dextro/Levo Rotation with
Axially Chiral Binaphthyls Linked to an Azobenzene
Moreover, reflecting their chirality, some axially chiral
binaphthyls exhibit relatively large optical rotations and
circular dichroism (CD).5 The large positive-negative-rever-
sible changes of such optical properties have been evaluated
with promising results in the development of novel photo-
switching materials. Moreover, optical rotation can be de-
tected at an unabsorbed wavelength, so target compounds
do not degrade during measurement. Hence, a switch for
dextro (positive)/levo (negative) rotation will lead to the
development of noise-cancellation, nondestructive reading
of memory devices.6c Although practical recording-repro-
duction systems have been designed by using optical rota-
tion, practical applications have yet to emerge due to the lack
of appropriate compounds.6d,e Irie, Branda, Wang, and
Yokoyama et al. have independently reported changes using
helicenoids via photochroism,7 but the CD variations are not
large or unreported and the change in optical rotations at the
sodium D-line, the universal wavelength (589 nm), does not
involve a sign inversion. Our research strives to change the
CD variations and optical rotations using axially chiral
binaphthyl derivatives.
Kazuto Takaishi,*,† Masuki Kawamoto,† Kazunori
Tsubaki,‡ and Tatsuo Wada*,†
†Supramolecular Science Laboratory, RIKEN, Hirosawa 2-1,
Wako, Saitama 351-0198, Japan, and ‡Graduate School of
Life and Environmental Science, Kyoto Prefectural
University, Shimogamo Hangi-cho, Sakyo, Kyoto 606-8522,
Japan
ktakaishi@riken.jp; tatsuow@riken.jp
Received May 18, 2009
We have reported basic compound (R)-1 (Figure 1), which
is composed of binaphthyl and azobenzene skeletons.8 Azo-
benzene skeletons are heavily used photochromic parts,9 and
show a significant change in length between the cis and trans
forms. The azobenzene moiety of (R)-1 can be reasonably
cis-trans photoisomerized. Additionally, isomerization can
be detected by the change in CD intensity, which is likely due
to the change in the dihedral angle formed by the two
naphthalene rings because the dihedral angle is related to
the CD intensity. This change is reversible, but the change is
small and sign reversal is not detected. Although we have
attempted to shorten the linkers so that the structural change
of the azobenzene moiety can be more directly transmitted to
the binaphthyl, our attempts have been unsuccessful. As an
alternative, herein we investigate whether the 3,30-substitu-
ents of the binaphthyl moiety can produce large confor-
mation changes between the cis and trans forms as well as
initiate subsequent changes in optical rotation and CD.
To examine the reversible photoisomerization and sub-
sequent change of asymmetric field, we synthesized opti-
cally active 3,30-disubstituted-1,10-binaphthyls with an
azobenzene moiety. Reflecting the structural change,
the specific rotation and circular dichroism underwent
significant variations. Under certain conditions, the po-
sitive-negative signals were reversible. Furthermore, the
magnitude of these changes showed a 3,30-substituent
dependency. Dibenzyloxy or bis(diphenylmethyloxy) de-
rivatives were better suited for sign interconversion of the
optical properties. In contrast, the hydroxy group(s)
lacked both optical signals and durability.
(5) (a) Minatti, A.; Doetz, K. H. Tetrahedron: Asymmetry 2005, 16, 3256–
3267. (b) Tsubaki, K.; Miura, M.; Morikawa, H.; Tanaka, H.; Kawabata, T.;
Furuta, T.; Tanaka, K.; Fuji, K. J. Am. Chem. Soc. 2003, 125, 16200–162001.
(c) Higuchi, H.; Ohta, E.; Kawai, H.; Fujiwara, K.; Tsuji, T.; Suzuki, T.
J. Org. Chem. 2003, 68, 6605–6610.
(6) (a) Murguly, E.; Norsten, T. B.; Brand, N. R. Angew. Chem., Int.
Ed. 2001, 40, 1752. (b) Feringa, B. L. Molecular Switches; Wiley-VCH:
Weinheim, Germany, 2001. (c) Kawata, Y.; Kawata, S. Chem. Rev. 2000,
100, 1777. (d) Yokoyama, Y.; Ubukata, T.; Saito, M. JP Patent 224834, 2008.
(e) Wada, H.; Nishino, K. JP Patent 50317, 2003.
(7) (a) Okumura, T.; Tani, Y.; Miyake, K.; Yokoyama, Y. J. Org. Chem.
2007, 72, 1634–1638. (b) Wang, Z. Y.; Todd, E. K.; Meng, X. S.; Gao, J. P. J.
Am. Chem. Soc. 2005, 127, 11552–11553. (c) Wigglesworth, T. J.; Sud, D.;
Norsten, T. B.; Lekhi, V. S.; Branda, N. R. J. Am. Chem. Soc. 2005, 127,
7272–7273. (d) Irie, M. Chem. Rev. 2000, 100, 1685-1716 and references
cited therein.
Axially chiral binaphthyls have a wide, flexible asym-
metric field. Hence, they have been extensively used in
catalytic asymmetric syntheses,1 specific molecular recogni-
tion,2 and helical twisting of liquid crystallines,3 and have
(1) (a) Fraile, J. M.; Garcia, J. I.; Mayoral, J. A. Chem. Rev. 2009, 109,
360–417. (b) Yamamoto, H.; Abel, J. P. J. Am. Chem. Soc. 2008, 130,
10521–10523. (c) Rabalakos, C.; Wulff, W. D. J. Am. Chem. Soc. 2008, 130,
13524–13525. (d) Brunel, J. M. Chem. Rev. 2005, 105, 857–898.
(2) (a) Ema, T.; Tanida, D.; Hamada, K.; Sakai, T. J. Org. Chem. 2008,
73, 9129–9132. (b) Park, H.; Nandhakumar, R.; Hong, J.; Ham, S.; Chin, J.;
Kim, K. M. Chem.;Eur. J. 2008, 14, 9935–9942. (c) Wang, Q.; Chen, X.;
Tao, L.; Wang, L.; Xiao, D.; Yu, X.-Q.; Pu, L. J. Org. Chem. 2007, 72,
97–101.
(3) (a) Yoshizawa, A.; Kobayashi, K.; Sato, M. Chem. Commun. 2007,
257–259. (b) Akagi, K.; Guo, S.; Mori, T.; Goh, M.; Piao, G.; Kyotan, M. J.
Am. Chem. Soc. 2005, 127, 14647–14654.
(4) (a) Kamberaj, H.; Low, R. J.; Neal, M. P. Mol. Phys. 2006, 104,
335–357. (b) Kranz, M.; Clark, T.; Schleyer, P. v. R. J. Org. Chem. 1993, 58,
3317–3325.
(8) Kawamoto, M.; Aoki, T.; Wada, T. Chem. Commun. 2007, 930–932.
(9) (a) Tamaoki, N.; Mathews, M. J. Am. Chem. Soc. 2008, 130, 11409–
11416. (b) Dri, C.; Peters, M. V.; Schwarz, J.; Hecht, S.; Grill, L. Nature
Nanotechnol. 2008, 3, 649–653. (c) Muraoka, T.; Kinbara, K.; Aida, T.
Nature 2006, 440, 512–515. (d) an Delden, R. A.; Mecca, T.; Rosini, C.;
Feringa, B. L. Chem.;Eur. J. 2004, 10, 61–70.
DOI: 10.1021/jo901030s
r
Published on Web 06/09/2009
J. Org. Chem. 2009, 74, 5723–5726 5723
2009 American Chemical Society

Takaishi et al.
JOCNote
FIGURE 1. (R)-1 and its photoisomerization.
SCHEME 1. Synthetic Route to (R)-4-8a
FIGURE 2. (a, b) CD spectra of (R)-4 and (R)-1. (c, d) Absorption
spectra of (R)-4 and (R)-1 (horizontal scales are common). (R)-4 after
365 nm irradiation (blue solid line), (R)-4 after 436 nm irradiation (red
solid line), (R)-1 after 365 nm irradiation (blue dotted line), and (R)-1
after 436 nm irradiation (red dotted line). Conditions: 1,4-dioxane
(1.0 ꢀ 10-5 M), 20 °C, light path length = 10 mm, irradiation wave-
length= 365nm(10 mW/cm2, 100s)and 436nm(10 mW/cm2, 100s).
aConditions: (a) K2CO3, 36%, (b) TiCl4, 91%, (c) RX, base, 35-64%.
As shown in Scheme 1, 3,30-disubstituted binaphthyl-
azobenzene diads (R)-4-8 were synthesized starting from
optically active (R)-2.10 Williamson synthesis of diol (R)-2
and dibromide 3 afforded cyclic compound (R)-4 in 36%
yield. Then debenzylation of (R)-4 with titanium tetrachlor-
ide for 5 min gave (R)-5 in high yield (91%). Using a higher
temperature, longer reaction time, or another Lewis acid
(e.g., aluminum trichloride or niobium pentachloride) resulted
in an extremely low yield (<5%) because some of the other
O-alkyl bonds of (R)-4 were also disconnected, and subse-
quent polymerization was also detected. Additionally,
generalized deprotection with palladium-activated carbon
(Pd/C) and hydrogen was unsuccessful under the reduction
of the azobenzene moiety. (R)-6-8 were prepared in mod-
erate yields by coupling (R)-5 with the appropriate halide. In
the synthesis of (R)-6 and -7, excess methyl iodide (MeI) and
R-bromodiphenylmethane were used, respectively. Although
in the synthesis of (R)-8, 1.1 equiv (based on (R)-5) of
benzyl bromide was used for preferential monobenzylation,
mixtures of desired (R)-8, unreacted (R)-5, and dibenzylated
(R)-4 were obtained; they were easily separated by gel
permeation chromatography (GPC).
FIGURE 3. 1H NMR spectra of the benzyl protons of (R)-4 after
(A) 365 nm irradiation and (B) 436 nm irradiation. Conditions:
CDCl3 (1 ꢀ 10-3 M), 300 MHz, 22 °C, irradiation 365 nm (10 mW/cm2,
500 s) and 436 nm (10 mW/cm2, 500 s) in an NMR test tube (φ= 5 mm).
cantly, (2) a positive-negative-reversible region was observed
on the long-wavelength side (around 450-500 nm) for the
trans form, which unlike (R)-1, exhibited a positive Cotton
effect, and (3) the Cotton effect at a short wavelength
1
(around 230 nm), which was attributed mainly to the Bb
transition moment and reflected twisting of two naphthalene
rings,12 did not resemble that of (R)-1.13 Meca, et al. have
calculated the racemization barriers of select 2,20-dis-
ubsituted-1,10-binaphthyl derivatives; all the values are
greater than 38 kcal/mol. Hence, racemizations of these
binaphthyls are atypical.14 Racemization or epimerization
Cis-trans isomerization11 was confirmed by the change in
absorption near 360 nm, which indicated a π-π* transition of
the trans form. On the whole, the absorption spectra of (R)-4
and (R)-1 were similar (Figure 2). On the other hand, the CD
spectra differed; the CD spectral shape of (R)-4 was atypical
in three ways: (1) the cis and trans forms differed signifi-
(12) Harada, N.; Nakanishi, K. Acc. Chem. Res. 1972, 5, 257–263.
(13) Although Bari et al. used calculations to determine that the Cotton
effect of the CD was inverted at a naphthalene dihedral angle of 110°, no
exceptions have yet to be reported for this empirical rule: (a) Bari, L. D.;
Pescitelli, G.; Marchetti, F.; Salvadori, P. J. Am. Chem. Soc. 2000, 122, 6395–
6398. (b) Bari, L. D.; Pescitelli, G.; Salvadori, P. J. Am. Chem. Soc. 1999, 121,
7998–8004.
(10) Tsubaki, K.; Morikawa, H.; Tanaka, H.; Fuji, K. Tetrahedron:
Asymmetry 2003, 14, 1393–1396.
(11) ΔHq and ΔSq for cis-trans isomerization of (R)-4 and 7 have been
experimentally determined to be 22 kcal/mol and -13 cal/(mol K) for (R)-4
3
and 20 kcal/mol and -17 cal/(mol K) for (R)-7.
(14) Meca, L.; Reha, D.; Havlas, Z. J. Org. Chem. 2003, 68, 5677–5680.
3
5724 J. Org. Chem. Vol. 74, No. 15, 2009

Takaishi et al.
JOCNote
TABLE 1. CD Data and Cis-Trans Ratio of (R)-4-8a
