Oxidative decarboxylation of levulinic acid by cupric oxides

Article abstract of DOI:10.3390/molecules15117946

In this paper, cupric oxides was found to effectively oxidize levulinic acid (LA) and lead to the decarboxylation of levulinic acid to 2-butanone. The effects of cupric oxide dosage, reaction time and initial pH value were investigated in batch experiments and a plausible mechanism was proposed. The results showed that LA decarboxylation over cupric oxides at around 300 °C under acidic conditions produced the highest yield of butanone (67.5%). In order to elucidate the catalytic activity of cupric oxides, XRD, AFM, XPS and H ₂-TPR techniques was applied to examine their molecular surfaces and their effects on the reaction process.

Full text of DOI:10.3390/molecules15117946

Molecules 2010, 15, 7946-7960; doi:10.3390/molecules15117946
OPEN ACCESS
molecules
ISSN 1420-3049
www.mdpi.com/journal/molecules
Article
Oxidative Decarboxylation of Levulinic Acid by Cupric Oxides
1
1,
1
2,
Yan Gong , Lu Lin *, Jianbin Shi and Shijie Liu *
1
Department of Resources Science and Engineering, State Key Lab of Pulp and Paper Engineering,
South China University of Technology, Guangzhou, 510640, China
2
Department of Paper and Bioprocess Engineering, State University of New York-College of
Environmental Science and Forestry, 1 Forestry Drive, Syracuse, NY 13210, USA
*
Authors to whom correspondence should be addressed; E-Mails: lclulin@scut.edu.cn (L.L.);
sliu@esf.edu (S.L.).
Received: 8 October 2010; in revised form: 31 October2010 / Accepted: 4 November 2010 /
Published: 5 November 2010
Abstract: In this paper, cupric oxides was found to effectively oxidize levulinic acid (LA)
and lead to the decarboxylation of levulinic acid to 2-butanone. The effects of cupric oxide
dosage, reaction time and initial pH value were investigated in batch experiments and a
plausible mechanism was proposed. The results showed that LA decarboxylation over
cupric oxides at around 300 °C under acidic conditions produced the highest yield of
butanone (67.5%). In order to elucidate the catalytic activity of cupric oxides, XRD, AFM,
2
XPS and H -TPR techniques was applied to examine their molecular surfaces and their
effects on the reaction process.
Keywords: decarboxylation; levulinic acid (LA); 2– butanone; cupric oxides (CuO)
1. Inroduction
In recent decades, the demand for natural resources has been increasing at an amazing rate, yet
fossil fuel sources are on course to be depleted rapidly, while environmental pollution and severe
climate changes due to over-exploitation and over-use of fossil fuels gradually become more serious
issues. Thus, renewable chemical/energy resources should be urgently developed. Levulinic acid, a
short chain fatty acid, is a product of acidic hydrolysis of biomass (such as cellulose and starch) and
also one of the extracts from black liquor from paper-making processes [1]. It is a new platform

7
947
Molecules 2010, 15
chemical with various potential uses, such as textile dye, antifreeze, animal feed, coating material,
solvent, food flavoring agent, pharmaceutical compounds and resin, etc [2-4].
Scheme 1. The conversion process of biomass → carbohydrates → fuels.
Biomass
(
C H O )
6 10 5 n
(C H O )
5 8 4 n
Hemicellulose
Cellulose
HOH C
OH
O
2
OH
H
OH H
H
O
HO
H
H
H
H
H
H
OH
OH
OH
Glucose
OH
Xylose
O
O
CHO
HOH C
CHO
2
Furfural
Hydroxymethylfurfural
O
OH
O
Levulinic acid
Decarboxylation
OH
O
O
hydrogenation
Baeyer-Villiger
O
2-Butanol
Ethyl acetate
Butanone
hydrogenation
OH
Ethanol
The reactivity of levulinic acid lies in its molecular structure that contains a carbonyl group and a
carboxyl group. Levulinic acid can be hydrogenated to γ-valerolactone [5] and decarboxylated to
2
-butanone (methyl ethyl ketone). Butanone is an essential component of the distillate (alcohol oil)
derived from the destructive distillation of wood. In industry, it is the product of the dehydrogenation

7
948
Molecules 2010, 15
of sec-butanol and the aqueous oxidation of butene. It is also produced from methyl formate which
reacts with ethylene and carbon monoxide in the presence of a rhodium catalyst with an ionic iodide as
promotor, as reported by Mathe [6]. Butanone is usually used as a solvent in organic synthesis, and it
can be converted through Baeyer-Villiger oxidation to ethyl acetate [7] which is further reduced to
ethanol. Besides, butanone can also be hydrogenated to butanol [8,9], which is a cleaner and superior
fuel to ethanol with octane numbers of 113 and 94 as compared with the 111 and 94 of ethanol [10].
Thus, decarboxylation of levulinic acid to produce butanone might be one of the key conversion steps
from biomass-derived carbohydrates to versatile fuels (Scheme 1).
Decarboxylation of organic molecules refers to the removal of a carboxyl group from its chemical
structure, further replaced by a hydrogen atom. Oxidative decarboxylation of carboxylic acids and
their derivatives has been extensively studied over various oxidants involving supported manganese(Ш)
porphyrin [11], manganese (III) Schiff base complexes [12], active hydroxyl radicals (•OH) [13],
peroxyl radicals [14] and silver(I)/peroxydisulfate [15], etc. Thermal decarboxylations of
perfluoropolyether salts [16], iron hydroxide cetylsulfonyl acetate [17] and tryptophan [18] have
generally received a good deal of attention. Moreover, photolytic decarboxylation (PD) is important in
several areas of study and still an area of active research interest. It was commonly used to prepare
radical intermediates and organic compounds and also applied in pharmaceuticals and agriculture.
Farhadi et al. found that α-arylcarboxylic acids were converted into the corresponding aldehydes and
ketones selectively by HgF under photoirradiation conditions in the presence of oxygen gas [19].
2
To date, efficient and clean methods for decarboxylation of LA have not been previously
investigated. Chum [20] explored the photoelectrochemical reaction of levulinic acid on undoped
2
platinized n-TiO powders, leading to 2-butanone, propionic acid, acetic acid, acetone and
acetaldehyde as major products. Even under the most compatible conditions designed, the butanone
yield was not satisfactory. In this paper, we report for the first time that LA decarboxylation is
catalyzed by CuO and a pathway is proposed for the conversion of LA to butanone.
2
. Results and Discussion
2
.1. Surface structures of CuO(I) and CuO(II) with different surface roughness (Rms)
3 2
CuO(I) was prepared by precipitation of copper nitrate [Cu(NO ) ] solution with sodium hydroxide
(
NaOH), CuO(II) was prepared by mixing stoichiometric amounts of oxalic acid and copper acetate in
distilled water. The surface roughness (Rms) of CuO(I) and CuO(II) was 123.32 nm and 40.75 nm,
respectively. The thermal desorption of hydrogen (H ) adsorbed on CuO(I, II) was investigated first to
2
determine their reduction temperatures. A color change from black (CuO) to dark yellow (Cu O) to
2
metallic-brown (Cu) was observed during their reduction process. The TPR profiles are illustrated in
Figure 1 and both had two reduction peaks: the first one at about 300 °C and the second one at about
2
+
4
50 °C, indicating the existence of two cupric oxide species. The reduction of isolated Cu occurred
by a two-step mechanism:
2
+
+
+
Cu + 1/2H
Cu + H
Cu + H+
2
+
Cu + 1/2H2

7
949
Molecules 2010, 15
The reduction of CuO took place in a one-step mechanism:
+
H O
2
CuO + H2
Cu
2
+
+
Therefore, the former peak was assigned to the reduction of isolated Cu to Cu and CuO to Cu,
+
while the latter peak was attributed to the subsequent reduction of Cu to Cu. By comparing the area of
2
+
two reduction peaks, we observed that the majority of copper was present as isolated Cu , since the
+
2+
areas of the two peaks were close. It was also indicated that Cu was more stable than Cu . The
configuration of extra-nuclear electron of Cu was 1s(2)2s(2)2p(6)3s(2)3p(6)4s(1)3d(10). Consequently,
2
+
+
the outer electronic configuration of Cu and Cu were 3s(2)3p(6)3d(9) and 3s(2)3p(6)3d(10),
respectively. Theoretically, 3d(10) is more stable than 3d(9). Moreover, it was related to the electron
attraction ability of the atom core. Atomic power to attract electron in a molecule is relevant to the
*
ratio of effective nuclear charges of ion and atomic radius, that is Z /r . The more highly oxidized the
i
*
atom is, the more positive charge the atom has, the smaller the atomic radius is, the larger Z /r is, and
i
2
+
the greater ability to attract electrons the atom has. Thus, Cu was more effective in catalyzing the
+
reaction than Cu . When CuO(II) and Cu O were separately used for oxidative decarboxylation of LA
2
at 100 °C for 3 h, the yields of butanone were 0.54% and 0.07%, respectively.
Figure 1. Temperature programmed reduction profiles of CuO(I, II).
CuO(I)
CuO(II)
100
200
300
400
500
Temperature/DC
Figure 2 shows the AFM images of two CuO samples which had different surface morphologies.
One can observe that the surface of CuO(І) was constituted by uniformly distributed particles (Figure
2
a). The surface of CuO(II) seen in Figure 2b was almost entirely composed of agglomerated
nanosized grains. The micro-sized agglomerates of nano-sized granules could be regarded as the
micro-and nano-scale (namely dual-scale) structure. The surface roughness (Rms) of CuO (I) and CuO
(II) was 123.32 nm and 40.75 nm, respectively. This could be attributed to the preparation of CuO (II)
that oxalic acid and copper acetate were separately grinded first.
The surface structures of two CuO samples were characterized by XPS and the corresponding
survey spectra were shown in Figure 3. All the binding energies were referenced to C 1s peak at
2
84.6 eV. It could be seen that the surfaces of these two CuO samples were similar. Different elements,
essentially carbon, oxygen and copper existed [21,22]. The O 1s core-levels revealed the presence of
two components at 529.71 eV and 530.89 eV in Figure 4a and 529.62 eV and 531.22 eV in Figure 4b,

7
950
Molecules 2010, 15
both of which corresponded to CuO and Cu(OH)
2
. The peak shape indicated that the Cu 2p/3 spectrum
of two CuO samples looked similar (Figure 5). The Cu 2p3/2 core-level peak at 933.30 eV could be
assigned to CuO and 940.48–943.39 eV was correlated to Cu(OH) , and the Cu 2p1/2 core-level peak
2
at 953.30 eV and 961.96 eV, respectively.
Figure 2. AFM images of two CuO samples [a: CuO(I); b: CuO(II)].
a
b
Figure 3. XPS survey spectrum of two CuO samples [a: CuO(I); b: CuO(II)]
O 1s
Cu 2P
b
O 1s
C 1s
C 1s
Cu 2P
a
1
000
800
600
400
200
0
Binging Energy (eV)

7
951
Molecules 2010, 15
Figure 4. XPS spectra of O 1s peaks of two CuO samples [a: CuO(I); b: CuO(II)].
6
6
5
5
4
4
3
5000
0000
5000
0000
5000
0000
5000
O 1s
5
29.71
5
30.89
a
5
40
535
530
525
Binding Energy(eV)
40000
35000
30000
25000
O 1s
529.62
531.22
b
540
535
530
525
Binding Energy(eV)
Figure 5. XPS spectra at Cu 2P/3 peaks of two CuO samples [a: CuO(I); b: CuO(II)].
Cu 2p/3
9
33.30eV
961.96eV
9
53.30eV
a
943.39eV
9
40.48eV
b
970
960
950
940
930
Binging Energy(eV)
The XRD patterns of two CuO samples are shown in Figure 6. The patterns showed two strong
peaks at 2θ = 35.5° and 38.6° corresponding to (002) and (111) planes of monoclinic CuO,
respectively [21,23]. The peaks only corresponding to cupric oxides were observed in Figure 6a and

7
952
Molecules 2010, 15
Figure 6b. It showed that single phase CuO was formed in samples of CuO(I) and CuO(II). However,
the peak intensity of CuO(І) in Figure 6a was higher than those in Figure 6b, which indicated that the
crystallinity of CuO(І) was higher than that of CuO(II).
Figure 6. The X-Ray Diffraction spectrum of two CuO samples [a: CuO(I); b: CuO(II)].
CuO (002)
CuO (111)
a
b
2
0
30
40
2
50
θ (°)
60
70
The grain size of CuO can be roughly estimated by using Scherrer’s formula, D = kλ/βcosθ, where β
is the full width half maximum (FWHM) of the strongest diffraction peak, θ is the diffraction angle, λ
is the X-ray wavelength (0.14506 nm), and k (~0.89) is Scherrer’s constant. The crystallite sizes of
CuO(I) and CuO(II) were 442 nm and 169 nm, respectively.
2
.2. Decarboxylation of levulinic acid to butanone catalyzed by CuO(I) and CuO(II)
The LA decarboxylation experiments using these two CuO samples were carried out at 300 °C at
pH 7.0. To determine the effect of CuO(I, II) dosages on LA decarboxylation, mass ratios of LA/CuO
ranging from 0% to 100% were examined. As seen from Figure 7, increasing both CuO dosages had a
positive effect on the reaction that butanone yields increased as the dosage of two CuO samples
increased. From 0% to 40%, the yields of butanone increased sharply and reached about 58.2%
[
CuO(II)] and 48.3% [CuO(I)], respectively. With further increases in CuO dosage, the yields leveled
off. We observed that the grain size of CuO(II) was smaller but the butanone yields from
decarboxylation of LA by CuO(II) were higher than that by CuO(I). It seemed that the decrease in
crystallinity made the CuO(II) more accessible to LA decarboxylation.
The effect of reaction time from 0.5 h to 9 h on LA decarboxyaltion by CuO(I) and CuO(II) was
then investigated. It can be seen from Figure 8A that butanone yields and LA conversions by CuO(II)
were higher than that by CuO(I). During first 2 h, LA conversions reached about 97.6% and 100%,
respectively. As the reaction time increased to 9 h, no distinct changes were observed. It indicated that
the reaction was almost completed within 2 h.

7
953
Molecules 2010, 15
Figure 7. Effect of dosage of two CuO samples on LA decarboxylation.
CuO(II)
CuO(I)
60
45
30
15
0
0
10 20 30 40 50 60 70 80 90 100
CuO (%)
Figure 8. Effect of reaction time (A), initial pH value (B) on LA decarboxylation.
1
00
A
8
7
6
5
4
0
0
0
0
0
Conversion by CuO(I)
Conversion by CuO(II)
95
9
8
8
0
5
0
Yield by CuO(I)
Yield by CuO(II)
0
2
4
6
8
Time (h)
8
0
105
2
2
1
1
1
2
0
8
6
4
Conversion by CuO(II)
Conversion by CuO(I)
7
7
6
6
5
5
5
0
5
0
5
0
Acetone by CuO(II)
Acetone by CuO(I)
100
95
12
1
0
B
2
4
6
8
10
12
14
Initial pH
9
0
Butanone by CuO(II)
Butanone by CuO(I)
85
2
4
6
8
10
12
14
Initial pH
The initial pH value of the reaction solution played a significant role on the reaction. Experiments
were carried out at initial pH values ranging from 3.2 to 12. In Figure 8B, at pH ≤ 7.0, LA conversion
by CuO(II) was about 100%. With the increase of pH value, it decreased to about 92%. Not much

7
954
Molecules 2010, 15
seemed to have changed regarding acetone yields, which fluctuated between 16.7% and 18.5%. CuO(I)
was also used as oxidant for LA decarboxylation at pH of 3.2 for a comparison, but butanone yield,
acetone yield and LA conversion were all lower than that seen with CuO(II). The pH dependence was
similar to that obtained by Chum [20] for the photoelectrochemical reaction of levulinic acid, in which
the optimum pH for LA decarboxylation was 4.0. In our experiments, the maximum butanone yield
(
67.5%) occurred at pH 3.2. It was the lowest pH value as levulinic acid was just mixed with KH PO .
2 4
According to the results, acidic pH was more favorable to LA decarboxylation than neutral and
alkaline pH values. The higher butanone yields at lower pHs were in agreement with the fact that CuO
should be more easily dissolved in acidic systems.
After the experiments, the precipitate was filtered and washed with de-ionized water and then dried
in an oven to give a reddish solid that was subsequently examined by XRD. As seen in Figure 9, the
peaks corresponding to CuO(II) in Figure 6 disappeared and peaks corresponding to Cu appeared
instead [24]. Thus, we can conclude that CuO was completely reduced to Cu at 300 °C.
Based on the TPR profiles of CuO(I, II), the precipitate after the experiments should be a mixture of
Cu and Cu O (in a high proportion). But Figure 9 only showed the peaks corresponding to Cu. Thus,
2
2
how Cu O changed into Cu in this reaction needs further study. Besides, the temperature of 300 °C
seemed extreme. The search for milder reactive conditions together with high catalytic efficiency is
imperative for potential industrial applications and a meaningful organic synthesis method. It was
2 2 3
reported that TPR peak temperatures of CuO/CeO catalyst [25], CuO/Al O catalysts [26] and
copper-exchanged mordenites (CuMOR) [27], etc. were much lower than that of pure CuO. One can
extrapolate that LA may be decarboxylated at lower temperatures using these CuO-modified catalysts
and this is under study.
Figure 9. The X-Ray diffraction spectrum of the precipitate after the reactions.
30000
20000
10000
0
Cu (111)
Cu (200)
20
30
40
50
60
70
2θ(°)
2
.3. Reaction pathway for LA decarboxylation by CuO
According to the experimental analysis by HS-GC-MS shown in Figure 10A and by ion
chromatography in Figure 10B, LA could be oxidatively decarboxylated to butanone by CuO(I, II) and
heat treatment. The oxidative decarboxylation of LA is given by eq. 1. From the butanone yields and

7
955
Molecules 2010, 15
LA conversions at different Initial pH values as shown in Figure 8B, we may deduce that the
mechanism of LA decarboxylation in acid solution is different from that in alkaline solution. Many
organic compounds, such as ethyl stearate and ortho-substituted benzoic acids, etc. [28-30] are
decarboxylated in free radical reactions. Our observations showed that butanone yields and LA
conversions were higher under acidic conditions. In other words, the free radical reaction was much
more compatible with LA decarboxylation under acidic pH. A plausible pathway as shown in Scheme 2
is proposed to explain the experimental observations. We propose that it is the Cu(II) species which is
the agent directly responsible for LA decarboxylation. The initial attack of Cu(II) is by addition of LA
producing hydrogen bond, then the hydrogen atom transfers to a free hydrogen ion and meanwhile a
Cu-oxygen bond is formed. The oxidation may occur via prior incorporation of LA into the Cu(II)
species as a ligand followed by homolysis of the Cu-O bond. Then the acyloxy acyl radical
(
CH COCH CH CO •) is known to undergo a rapid fragmentation with liberation of carbon dioxide
3
2
2
2
(
CO
2
) and an alkyl radical (CH
3
COCH
2
CH
2
3 2 3
•). Butanone (CH COCH CH ) is then derived by
hydrogen atom transfer to solvent (eq. 2). Cu)(II) was firstly reduced to Cu(I) followed in succession
by a second reduction to the elemental form (Cu):
Cu + 2CH COCH CH + 2H+ + 2CO2 (1)
3 2 2
Cu(II) + 2CH COCH CH COOH
3
2
2
CH COCH CH + H-Solv
CH COCH CH
+
3
2
2
3
2
3
Solv
(2)
Figure 10. Head space - gas chromatogram (A) and Ion Chromatogram (B) of samples.
A
B
Butanone
LA
Acetone
Acetic acid
2
3
4
5
2
4
6
8
When the experiments were carried out in alkaline conditions, the covalent bond may be cleaved by
a heterolysis process that is a two-step ionic decarboxylation as indicated in eq. 3. Levulinic acid is
−
first dissociated into a carboxylic anion (CH
3
COCH
2
CH
2
CO
2
) which then undergoes a heterolytic
−
cleavage of the alkyl-carbonyl bond and leads to the formation of an alkyl anion (CH
and CO
-butanone [31,32]. Acetic acid and acetone may be produced by breaking the C-C bond between the
α-carbon and β-carbon because of the electron attraction effect of carboxyl and carbonyl group.
3
COCH
2
CH
2
)
2
. The alkyl anion has strong basicity and it can combine with hydrogen ion to become
2

7
956
Molecules 2010, 15
Scheme 2. The proposed reaction pathway for LA decarboxylation by CuO samples.
O
O
Cu(II)
Cu(II)
OH
O
O
H
Cu(II)
O
O
H+
+
O
O
O
CH2
+
CO2
O
O
O
+
O
O
Cu(I)
O
H
O
Cu(I)
Cu(I)
OH
O
O
O
O
+
Cu
H+
+
O
O
O
CH2
+
CO2
O
O
H+
H CCCH CH
H CCCH CH
3
(3)
H CCCH CH C
3
2
2
3
2
3
2
2
O
O
O
O
3
. Experimental
.1. Preparation of CuO samples
CuO(I) was prepared by precipitating copper nitrate [Cu(NO ) ] solution with sodium hydroxide
3
3
2
(
NaOH). The precipitate was washed with deionized water and then dried in a vacuum oven at 50 °C
for 4 h. The dried sample was calcined in a muffle furnace at 800 °C for 2 h. CuO(II) was prepared by
mixing stoichiometric amounts of oxalic acid and copper acetate in distilled water. The resultant blue
2 4
solid (CuC O ) was washed with deionized water and then dried in a vacuum oven at 70 °C for 4 h.
The prepared sample was ground and subsequently calcined in a muffle furnace at 800 °C for 2 h.
CuO(I) and CuO(II) were used in LA decarboxylation and further analyses.

7
957
Molecules 2010, 15
.2. Procedure for LA decarboxylation
3
All experiments were carried out in a 4576-HP/HT Pressure Reactor (200 mL, Parr Instruments).
Reaction solutions were obtained by adding levulinic acid (0.01 mol) into KH PO -NaOH (0.2 mol/L)
2
4
solution and the initial pH of the reaction solution was adjusted with NaOH (0.2 mol/L). The total
volume was 60 mL. Then a metal oxide or metal-oxides mixture was added into the prepared reaction
solutions. After the reactions were completed, the samples were taken with 5 mL pipette and directly
transferred to a 20 mL headspace vial for GS-GC detection. In view of the volatility of products, three
samples were taken and the average value of the data was recorded. And the samples were filtered
through a 0.25 μm membrane filter for ion chromatography detection.
3.3. Head space – gas chromatography detection
Head space (HSS 86.50)-gas chromatography (QP2010, Shimadzu Japan) (HS-GC) was used
extensively in the separation and identification of mixtures of volatile compounds. LA decarboxylation
samples were analyzed with a HS-GC using a DB-5 column (30 m × 0.25 mm i.d. × 0.25 μm film) at a
column temperature of 120 °C, a flow rate of 4.7 mL/min and with a flame ionization detector at the
temperature of 220 °C. The analysis was performed at 60 °C for 5-min. The component concentrations
were calculated by the area normalization method. The sample vials was shaken for
2
0 min at 75 °C. The temperatures of sampling probe and tube were 85 °C and 95 °C, respectively.
Automatic sampling was employed. The sample analysis was confirmed by the head space-gas
chromatograph-mass spectrometer technique (HS-GC-MS). Some samples were detected with a
HS-GC-MS (Agilent 6890-5975) equipped with a DB-5 column (30 m × 0.25 mm i.d. × 0.25 μm film).
The temperature program was used: 60 °C –(5 min) −10 °C/min −120 °C. The carrier gas was helium
with a flow rate of 1.0 mL/min and the mass spectrometer used an electron impact (EI) ionization
mode with 70 eV of electron energy. The HS-GC of samples shown in Figure 10A confirms that
acetone and butanone were the gas products and the retention times were about 3.26 min and
3.63 min, respectively.
3
.4. Ion chromatography detection
Ion chromatography (ICS-3000, Dionex USA) was used for the analysis of levulinic acid in the
aqueous phase to evaluate the conversion of levulinic acid. Liquid reactant after the reactions was
filtered and diluted before testing. The analysis was conducted in an anion-exchange column
(AS11-HC) with 2 mol/L NaOH leacheate in a conductivity cell of 35 °C. The flow rate was
1
.0 mL/min and the sample size was 50 μL. The calibration was performed using aqueous solutions.
An ion chromatogram of a sample is shown in Figure 10B, where the LA peak was between 3.95 min
and 4.06 min.
3
.5. X-ray diffraction analysis
The grain size of CuO powders was characterized by X-ray diffraction (XRD) (D/max-IIIA, Rigaku,
Japan) (40 kV, 40 mA) using the standard reflection mode with Cu/Ka (λ = 0.154056 nm) in the angle
0° < 2θ < 70° and step angle was 0.02°.
2

7
958
Molecules 2010, 15
.6. Atomic force microscope measurement
3
The surface morphologies of CuO powders were observed by atomic force microscope (AFM)
Nanoscope IIIa Scanning, Digital Instruments, USA) using tapping mode with an RTESP cantilever.
(
3.7. X-ray photoelectron spectrometry
To determine the surface compositions of CuO, X-ray photoelectron spectroscopy (XPS) was
carried out with an Axis Ultra (DLD) spectrometer (Kratos, 5 mA, 15 KV) using Al Kα source and Mg
Kα source. Binding energy was calibrated with hydrocarbon- contaminated C1s peak at 284.6 eV at
ambient temperature.
3.8. Temperature programmed reduction analysis
The temperature programmed reduction (TPR) measurement of CuO powders was carried out using
an AutoChem II 2920 Chemisorb system from room temperature to 500 °C at a heating rate of
0 °C/min by flowing 50 mL/min of H (10 vol.%)/Ar. The amount of H uptake during the reduction
1
2
2
was measured by a thermal conductivity detector (TCD). The water produced during the reduction was
trapped in a 5Å molecular sieve column.
4
. Conclusions
It is shown based on above discussions that butanone can be produced through oxidative
decarboxylation of biomass–derived levulinic acid with CuO. CuO itself was reduced to its elemental
form (Cu). The LA decarboxylation is the result of a combination of CuO’s oxidability, structure
(
transition metal with unoccupied orbital) and external conditions (temperature, pH, etc). An acidic
system helped to facilitate the oxidative decarboxylation of LA. At pH 3.2, the butanone yield reaches
7.5%.
6
Acknowledgements
The authors are grateful for the financial support from Natural Science Foundation of China
(
50776035, U0733001), Foundation of Scientific Research for Universities (20070561038) from
Ministry of Education of China, National High Technology Project (863 project; 2007AA05Z408),
National Key R&D Program (2007BAD34B01) and National Key Basic Research Program
(2010CB732201) from the Ministry of Science and Technology of China.
References and Notes
1
2
3
. He, Z.S. Extraction of Levulinic Acid from Paper - making Black Liquor. Chem. Ind. Eng. 1999, 2,
63–166.
. Chang, C.; Cen, P.L.; Ma, X.J. Levulinic acid production from wheat straw. Bioresour. Technol.
007, 98, 1448–1453.
1
2
. Cha, J.Y.; Hanna, M.A. Levulinic acid production based on extrusion and pressurized batch
reaction. Ind. Crops Products 2002, 16, 109–118.

7
959
Molecules 2010, 15
4
5
6
7
8
. Fang, Q.; Hanna, M.A. Experimental studies for levulinic acid production from whole kernel grain
sorghum. Bioresour. Technol. 2002, 81, 187–192.
. Yan, Z.P.; Lin, L.; Liu, S.J. Synthesis of γ-Valerolactone by Hydrogenation of Biomass-derived
Levulinic Acid over Ru/C Catalyst. Energy Fuels 2009, 23, 3853–3858.
. Mathe, F.; Castanet, Y.; Mortreux, A.; Petit, F. Synthesis of 2-butanone from ethylene and methyl
formate catalysed by rhodium-iodide complexes. Tetrahedron Lett. 1991, 32, 3989–3992.
. Williamd, D.E; George, B.L. Peroxytrifluoroacetic Acid. V. The Oxidation of Ketones to Esters. J.
Am. Chem. Soc. 1955, 77, 2287-2288.
. Lou, Z.Y.; Chen, X.Y.; Qiao, Li, T.M.; Fan, K.N.; Hea, H.Y.; Zhang, X.X.; Zong, B.N. Preparation
and characterization of the chirally modified rapidly quenche skeletal Ni catalyst for
enantioselective hydrogenation of butanone to R-(−)-2-butanol. J. Mol. Catal. A Chem. 2010,
doi:10.1016 /j.molcata.2010.04.018.
9
1
1
1
. Gao, F.; Li, R.J.; Garland, M. An on-line FTIR study of the liquid-phase hydrogenation of
2
-butanone over Pt/Al O in d8-toluene-The importance of anhydrous conditions. J. Mol. Catal. A
2 3
Chem. 2007, 272, 241–248.
0. Qureshi, N.; Saha, B.C.; Cotta, M.A. Butanol production from wheat straw by simultaneous
saccharification and fermentation using Clostridium beijerinckii: Part II—Fed-batch fermentation.
Biomass Bioenergy 2008, 32, 176–183.
1. Mirkhani, V.; Tangestaninejad, S.; Moghadam, M.; Karimian, Z. Efficient oxidative
decarboxylation of carboxylic acids with sodium periodate catalysted by supported manganese(Ш)
porphyrin. Bioor. Med. Lett. 2003, 13, 3433–3435.
2. Mirkhani, V.; Tangestaninejad, S.; Moghadam, M.; Moghbel, M. Rapid and efficient oxidative
decarboxylation o carboxylic acid with sodium periodate catalyzedvby manganese (III) Schiff
base complexes. Bioorg. Med. Chem. 2004, 12, 903–906.
1
1
3. Guitton, J.; Tinardon, F.; Lamrini, R.; Lacan, P.; Desage, M.; Francina, A.F. Decarboxylation of
1
3
[1- C]leucine by hydroxyl radicals. Free Radical Biol. Med. 1998, 25, 340–345.
4. Lamrini, R.; Lacan, P.; Francina, A.; Guilluy, R.; Desage, M.; Michon, J.; Becchi, M.; Brazier, J.L.
Oxidative decarboxylation of benzoic acid by peroxyl radicals. Free Radical Biol. Med. 1998, 24,
2
80–289.
1
1
1
5. Anderson, J.M.; Kochi J.K. Silver(I)-Catalyzed Oxidative Decarboxylation of Acids by
Peroxydisulfate. The Role of Silver(II). J. Am. Chem. Soc. 1970, 92, 1651–1659.
6. Marchionni, G.; Petricci, S.; Spataro, G.; Pezzin, G. A study of the thermal decarboxylation of three
perfluoropolyether salts. J. Fluorine Chem. 2003, 124, 123–130.
7. Zhang, G.; Shen, K.H.; Zhao, D.F.; Yuan, Y.K.; Wang, G.Y. Preparation of uncoated iron oxide
nanoparticles by thermal decarboxylation of iron hydroxide cetylsulfonyl acetate in solution.
Mater. Lett. 2008, 62, 219–221.
1
8. Martins, C.P.B.; Awan, M.A.; Freeman, S.; Herraiz, T.; Alder, J.F.; Brandt, S.D. Fingerprint
analysis of thermolytic decarboxylation of tryptophan to tryptamine catalyzed by natural oils. J.
Chromatogr. A 2008, 1210, 115–120.
1
9. Farhadi, S.; Zaringhadam, P.; Sahamieh, R.Z. Photolytic decarboxylation of a-arylcarboxylic acids
mediated by HgF2 under a dioxygen atmosphere. Tetrahedron Lett. 2006, 47, 1965–1968.

7
960
Molecules 2010, 15
2
2
2
2
2
2
2
2
2
0. Chum, H.L.; Ratcliff, M. Photoelectrochemistry of Levulinic Acid on Undoped Platinized n-TIO ,
Powders. J. Phys. Chem. 1983, 87, 3089–3093.
1. Liu, X.L.; Jiang, Z.H.; Li, J.; Zhang, Z.H.; Ren, L.Q. Super-hydrophobic property of nano-sized
cupric oxide films. Surf. Coat. Technol. 2010, doi: 10.1016/j.surfcoat.2010.03.012.
2. Martinson, C.A.; Reddy, K.J. Adsorption of arsenic(III) and arsenic(V) by cupric oxide
nanoparticles. J. Colloid Interface Sci. 2009, 336, 406–411.
3. Hoa, N.D.; An, S.Y.; Dung, N.Q.; Quy, N.V.; Kim, D.J. Synthesis of p-type semiconducting cupric
oxide thin films and their application to hydrogen detection. Sens. Actuat. B. 2010, 146, 239–244.
4. Jayatissa, A.H.; Guo, K.; Jayasuriya, A.C. Fabrication of cuprous and cupric oxide thin films by
heat treatment. Appl. Surf. Sci. 2009, 255, 9474–9479.
5. Luo, M.F.; Zhong, Y.J.; Yuan, X.X.; Zheng, X.M. TPR and TPD studies of CuO/CeO catalysts for
2
low temperature CO oxidation. Appl. Catal. A Gen. 1997, 162, 121–131.
2 3
6. Luo, M.F.; Fang, P.; He, M.; Xie, Y.L. In situ XRD, Raman, and TPR studies of CuO/Al O
catalysts for CO oxidation. J. Mol. Catal. A Chem. 2005, 239, 243–248.
7. Torre-Abreu, C.; Ribeiro, M.F.; Henriques, C.; Delahay, G. NO TPD and H -TPR studies for
2
characterisation of CuMOR catalysts -The role of Si/Al ratio, copper content and cocation. Appl.
Catal., B: Environ. 1997, 14, 261–272.
2
8. Zhou,Y.Z.; Li, S.; Li, Q.S.; Zhang, S.W. Theoretical investigation of the decarboxylation reaction
3 2
of CH CO radical. J. Mol. Struct. Theochem. 2008, 854, 40–45.
2
9. Snåre, M.; Kubičková, I.; Mäki-Arvela, P.; Eränen, K.; Wärnå, J.; Yu, D. Production of diesel fuel
from renewable feeds: Kinetics of ethyl stearate decarboxylation. Chem. Eng. J. 2007, 134,
2
9–34.
3
3
3
0. Chuchev, K.; BelBruno, J.J. Mechanisms of decarboxylation of ortho-substituted benzoic acids. J.
Mol. Struct. Theochem. 2007, 807, 1–9.
1. Ma, Y.X.; Wu, R.M. Chemistry English; Publishing Company of Wuhan University: Lanzhou,
China, 2003; pp. 126–131.
2. Feng, J.C.; Zhu, Y. Purification and Preparation of Reagent Commonly Used in Organic Labs;
Publishing Company of Science: Beijing, China, 2006; pp. 5–7.
Sample Availability: Samples of the compounds are available from the authors.
©
2010 by the authors; licensee MDPI, Basel, Switzerland. This article is an open access article
distributed under the terms and conditions of the Creative Commons Attribution license
http://creativecommons.org/licenses/by/3.0/).
(
