designed and fabricated a fiber probe based on MAPbX3 (X ¼ Cl, Br
or I) single crystals [21]. In their case, the recorded photo-
luminescence (PL) decreased dramatically by 60%, upon exposure
to NH3 vapor. However, the fabrication of this sensor may require a
complex single-crystal growth process, and the accurate NH3 con-
centration was not mentioned. Herein, it is an urgent need to
develop simple and facile perovskite sensors to detect the low
concentration NH3 with long-term stability.
the perovskite precursor solutions with/without TBA were spin-
coated on GeO2 substrates at 2000 rpm for 60 s Meanwhile, to
induce the crystallization quickly, 100 mL toluene was dropped onto
the substrates at 10 s during the spinning process. Finally, the as-
prepared samples were annealed at 60 ꢀC for 10 h.
2.4. Characterizations
Recently, a long alkyl chain salt tetrabutylammonium-bromide
(TBA) was used as a passivation agent to stabilize the perovskite,
owing to the ability to control crystallization [31]. For the sensing
application, we expected that this capping layer on the surface of
perovskite could increase its stability with suitable gas permeability.
In order to explore this possibility, in this paper, we prepared the
TBA-coated MAPbBr3 films on GeO2 substrates to investigate the
influences of TBA on NH3 sensing. The pre-deposited GeO2 sub-
strates possessed the rough surface which facilitated the adhesion
and dispersion of perovskite crystals compared to the smooth
glasses. The sensing performance of the as-prepared MAPbBr3-TBA-
based sensor was determined that the PL intensity quenched rapidly
upon exposure to NH3 gas and then recovered to the initial PL in-
tensity after removing NH3 gas. The NH3 sensing mechanism was
also studied based on XRD, FT-IR, DTA-TG and PL lifetime measure-
ments. Hence, it paves the way for the application of organic-
inorganic halide perovskite on NH3 detection.
The film morphologies and element distributions were observed
by using a scanning electron microscope combined with an energy-
dispersive X-ray spectroscope (SEM/EDS, Gemini 450). X-ray diffrac-
tion patterns were measured by a rotating Cu K
diffractometer (XRD, Rigaku Ultima IV) under 35 kV and 20 mA. The
scanning range was set as 5ꢀ<2 < 50ꢀ with a speed of 10ꢀ minꢁ1. The
a anode X-ray
q
infrared spectrum was recorded on a Bruker 80 V Fourier Transform
Infrared Spectrometer (FT-IR). The PL spectra data of samples were
collected using the fluorescence spectrophotometer with a slit width
of 2 nm (LengGuang, F97pro). The thermal behaviors were measured
by differential thermal analysis (DTA) and thermogravimetry (TG)
using a Mettler Toledo TGA/SDTA 851e system; measurements were
carried out from 25 to 700 ꢀC (heating rate: 10 ꢀC/min) under N2 flow.
Finally, the PL decay lifetimes were measured by an Edinburgh In-
struments FLS920 fluorescence spectrometer equipped with a pico-
second pulsed diode laser (
time-correlated single-photon counting unit.
l
¼ 371.6 nm, pulse width ¼ 66.3 ps) and a
2. Experimental
2.5. Fabrication of NH3 gas sensors
2.1. Preparation of GeO2 substrates
The schematic measurement setup is shown in Fig. 1. The quartz
cuvette (10*10*40 mm3) was used as a gas chamber to hold perov-
skite samples. The PL spectra of samples were excited by a Xe lamp
source and then recorded by a photomultiplier tube (PMT) detector.
Different concentrations of NH3 gas were obtained via mixing
appropriate pure N2 and NH3 gases. The target gas was blown into
the chamber by gas sampling pump with a constant flow rate of
0.5 L/min. The gas response was determined bycalculating the value
of response (I0eI)/I0ꢂ100%, where the I0 was the initial PL intensity
under NH3-free condition, and I was the PL intensity in the present of
NH3 gas. The response time Tres was defined as the time for the
sensor to reach 90% of maximum PL intensity change upon exposure
to NH3 gas, and the recovery time Trec as the time to recover 90% of
maximum PL intensity change after removing NH3 followed by
exposure of pure N2 gas. To measure the effect of ambient moisture
on the response of this gas sensor, we carried out the PL measure-
ment under different relative humidity (RH) conditions (using the
vapors of saturated salt solutions including MgCl2, K2CO3, NaBr,
NaCl, KCl and K2SO4 at room temperature).
The growth of GeO2 layers was taken by a modified liquid phase
deposition method which reported by Jing et al., previously [32]. In
detail, 0.75 mL of aqueous ammonia (26e28 wt%) was dissolved in
deionized water (25 mL) at 65 ꢀC, followed by adding 1.5 g GeO2
powders. After stirring for 30 min, the transparent solution was
obtained. Then, the nitric acid (36 wt%) was added dropwise to the
above solution until the pH was adjusted to the value of 2. After-
ward, the glass sheets (10*10*1 mm3), sonicated successively in
acetone and ethanol for 20 min, were soaked into the above
aqueous solution. The deposition process was carried out for 36 h at
room temperature. Finally, the white GeO2 layers were observed on
the glass sheets, and then these GeO2 substrates were washed by
deionized water and ethanol, followed by drying at 100 ꢀC for 1 h.
2.2. Synthesis of CH3NH3Br
CH3NH3Br (MABr) was synthesized by mixing methylamine
(MA, 30 wt% in ethanol) with equimolar amounts of aqueous HBr
(40 wt% in water). First, the MA in anhydrous ethanol was stirred
and cooled to 0 ꢀC by adding HBr acid slowly. Subsequently, the
reaction solution was stirred continuously for 2 h under N2 atmo-
sphere and then evaporated by rotary evaporation at 50 ꢀC. The as-
obtained MABr precipitate was washed with diethyl ether several
times to remove the residual HBr and then dried at 60 ꢀC in a
vacuum oven overnight.
3. Results and discussion
Fig. 2 presents the SEM images and EDS maps of the as-prepared
perovskites deposited on glass or GeO2 substrates. It can be seen
that the perovskite MAPbBr3-TBA possesses the piece-like shape
adhered to a smooth glass substrate (Fig. 2a), while the morphol-
ogies of MAPbBr3 and MAPbBr3-TBA on GeO2 layers show the
typical perovskite grains (Fig. 2b and c). It is reasonable that the
GeO2 layer has a rough surface (Fig. 2b), which may facilitate the
heterogeneous nucleation and dispersion of perovskite crystals,
compared to the smooth glass substrate. Clearly, it appears the
cubic-structure grains in the MAPbBr3-TBA sample (Fig. 2d), in
which the grain sizes are smaller than that of MAPbBr3 (Fig. 2c),
indicating the TBA ligand may modify the outer surface perovskite
crystal to reduce grain size [31]. In order to verify whether these
cubic grains are MAPbBr3-TBA, we selected some grains (the rect-
angular area in Fig. 2d) and measured the elemental composition
2.3. Preparation of perovskite films
Initially, the MAPbBr3 (0.3 M) precursor solution was prepared
by dissolving equimolar amounts of MABr (67.2 mg) and PbBr2
(220 mg) in N, N-Dimethylformamide (DMF, 2 mL) under vigorous
stirring. Then, the above solution was divided into 2 equal parts.
The TBA raw material (19.3 mg) was added in one part of them with
the ratio of TBA/MA at 20%. All the solutions were stirred at 50 ꢀC
overnight. For the perovskite film deposition, one droplet (40 mL) of
