A Novel Versatile Precursor Suitable for 18F- Radiolabelling via “Click-Chemistry”
B. Lugato,1 S. Stucchi,1 S. Ciceri,2 M. N. Iannone1, E.A. Turolla,1 L. Giuliano,1 C. Chinello,3
S. Todde,1 P. Ferraboschi* 2
1 University of Milano-Bicocca, Department of Medicine and Surgery, Tecnomed Foundation,
Monza, Italy
2 Università degli Studi di Milano, Dipartimento di Biotecnologie Mediche e Medicina
Traslazionale, Milan, Italy
3
University of Milano-Bicocca, Department of Medicine and Surgery, Mass Spectrometry
unit, Monza, Italy
* Prof. Patrizia Ferraboschi, e-mail: patrizia.ferraboschi@unimi.it, Tel. +39 02 50316052
ABSTRACT
As an effort to improve 18F radiolabelling of biomolecules in terms of method robustness and
versatility, we report the synthesis and radiolabelling of a new azido precursor potentially
useful for the so called “click-reaction”, in particular the ligand-free version of the copper(I)-
catalyzed alkyne-azide cycloaddition (CuAAC). The new azido precursor may help to
overcome problems sometimes exhibited by most of the currently used analogues, as it is safe
to handle and it displays long term chemical stability, thus facilitating the development of
new radiolabelling procedures. Moreover, the formed 18F labelled 1,2,3-triazole is potentially
metabolically stable, and could enhance the in vivo circulation time. The above azido
precursor was successfully radiolabelled with 18F, with 51% radiochemical yield (non-decay-
corrected). As a proof of concept, the 18F labelled azide was then tested with a suitable alkyne
functionalized aminoacid (L-propargylglycine), showing 94% of conversion, and a final
radiochemical yield of 27% (>99% radiochemical purity), non-decay-corrected, with a total
preparation time of 104 min.
Keywords:
18F-radiolabelling; click chemistry; 1,2,3-triazole; PET; CuAAc; L-propargylglycine
INTRODUCTION
18F is the most widely used radionuclide in Positron Emission Tomography (PET). It is a
positron emitting radionuclide that can be produced in high yields with cyclotrons with
proton beam energy in the range 10-19 MeV; it shows favorable characteristics in terms of
decay and emission properties, including high positron abundance (97%), and a physical half-
life of 109.8 min, that allows for time-consuming multi-step radiosynthesis, and the use of
PET tracers with moderately slow pharmacokinetics. Moreover, its low positron energy
(maximum 635 KeV), ensures high image resolution. Another advantage in 18F radiolabelling
is that, although fluorine is absent in most biologically active compounds, its introduction via
the replacement of protons, hydroxyl, and amino groups, does not alter significantly the steric
hindrance. Fluorine, the most electronegative element, is isosteric with a hydroxyl group, the
This article has been accepted for publication and undergone full peer review but has not
been through the copyediting, typesetting, pagination and proofreading process which may
lead to differences between this version and the Version of Record. Please cite this article as
doi: 10.1002/jlcr.3529
This article is protected by copyright. All rights reserved.

C-F bond length (1.35 Å) being similar to the C-O length (1.43 Å). In addition, it is the
second smallest atom and it can mimic hydrogen in a modified structure; its van der Waals
radius (1.47 Å) is intermediate between that of hydrogen (1.20 Å) and that of oxygen (1.52
Å). The strength of the C-F bond (105.4 kcal mol-1 ) exceeds that of C-H bond (98.8 kcal mol-
-1
1) and of C-O bond ( 84.0 kcal mol ) and for this reason fluorine is often used to replace
hydrogen in medicinal chemistry.1,2,3
In the last decade, there has been increasing interest in the 18F radiolabelling of biomolecules
18
such as peptides, proteins, nucleic acids, oligomers, etc. As direct F radiolabelling of the
above biomolecules is usually not feasible, due to both the lack of functional groups suitable
for direct nucleophilic substitution, and harsh conditions often used during this reaction type,
a variety of indirect methods were developed, the most common of which has long been the
radiofluorination of small molecules to achieve a prosthetic group, which is then conjugated
to the biomolecule under mild conditions.3,4,5,6 To this regard, the Cu(I)-catalyzed Huisgen
3+2 cycloaddition between terminal alkynes and azides, the so called Copper-Catalyzed
Azide Alkyne Cycloaddition (CuAAC) was widely used in recent years, because of its
regioselectivity, mild aqueous organic conditions, reduced reaction times, and high yields.
Moreover, the produced 1,2,3-triazoles usually show biological stability, and polarity and
size similar to amide or peptide bonds. Finally, as alkynes and azides are inert towards classic
biomolecules functionalities, there is no need for protection strategy during CuAAC. 3, 4
Therefore, a new class of precursors for the 18F radiolabelling of biomolecules such as
aminoacids, peptides, and oligomers was developed.7
As CuAAC is alkyne-rate dependent,8, 9 our attention was focused on azido precursor, the
18
best strategy to save time and resources being the F radiolabelling of such a precursor, and
the subsequent cycloaddition with an alkynyl-modified biomolecule.
However, there is still a need of optimized azido precursors. In fact, some of the azido
compounds used as precursors for 18F radiolabelling described in the literature show
significant drawbacks, such as marked instability, and they bear the leaving group for the
introduction of 18F, the azido group or a polar chain directly linked to an aromatic ring, with a
potential loss of reactivity and chemical stability during radiofluorination and click-reaction.
Furthermore, most of the azido precursors display poor UV absorption, that can be a
disadvantage during the development of new radiolabelling methods, as monitoring of
reaction and purification steps is often performed using HPLC equipped with UV detectors.
The aim of this work is the synthesis of a new, general purpose, azido precursor, optimized
18
for F radiolabelling of biomolecules via “click” chemistry. The proposed compound has
proved to be safe, versatile, stable, polar, reactive, and with good UV absorbance, and it may
potentially be used in combination with any alkynyl-modified biomolecule. Moreover, the
concentration of copper catalyst, as well as the amount of alkynyl-modified biomolecule,
could be lower than those usually requested, and the radiolabelled biomolecule might
potentially display improved metabolic stability.
18
The precursor was radiolabelled with F, and the ability to efficiently react with alkynil-
functionalized moieties via CuAAC of the resulting [18F]fluoroazide was verified with a
suitable test compound, namely propargylglycine.
During the development of the proposed CuAAC method, the use of “click” accelerating
ligands such as tris[(1-benzyl-1H-1,2,3-triazol-4-yl)methyl]amine (TBTA) was avoided,
because they make the reaction more pH and solvent sensitive, potentially affecting the
versatility.10
This article is protected by copyright. All rights reserved.

RESULTS AND DISCUSSION
Our purpose dealt with the development and standardization of a general and versatile
procedure for the radiolabelling of biomolecules with 18F. With the aim to simplify and speed
up the method development, we initially selected commercially available and well-known
azido precursors useful for CuAAC, such as azidoethyltosylate11 or diaryliodonium salt
precursors12. However, hazards associated with their shipment and storage, together with
their poor UV absorption, prompted us to design a new, general purpose, safe and reliable
18F-labelled azide 18F1, and to synthesize a useful set of precursors (2-5) possessing the
suitable characteristics discussed above (Figure 1).
Figure 1 – 18F1 and its precursors 2-5
The arene ring was chosen to give high UV absorbance to the molecule, thus allowing HPLC
monitoring of radiolabelling reactions and implementation of efficient purification
procedures. The azido group in benzylic position instead of directly bound to the arene ring is
more accessible, and thus more reactive during the subsequent click reaction. Triethylene
glycol residue was chosen with the aim to reduce molecule volatility13 and potentially
improve the in vivo behavior of the labelled molecule by increasing its circulation time
because of the reduced renal clearance.14, 15. Longer polyethylene glycol (PEG) chains were
discarded to avoid excessively bulky structures.
The synthetic pathway, designed to achieve the desired set of precursors 2-5 and the
fluorinated “cold” reference molecule 1, was focused on an orthogonal protection-
deprotection strategy of substrate functionalities, as both the final products and the synthetic
intermediates are polyfunctional compounds. The critical point to be considered is that azido
group is labile in acidic media;16 thus, the removal of the protecting group PEG moiety,
which is the last step before the introduction of the leaving group for subsequent 18F
radiolabelling, had to be feasible under conditions alternative to acidic. For this reason, the
protecting group for azide moiety had to be orthogonal to the protecting group on PEG chain.
Thus, a bifunctional benzylic compound was investigated as starting substrate, namely
methyl 4-(bromomethyl) benzoate 6 (Scheme 1). After selective reduction of the ester
function to the corresponding alcohol 7 (DIBAL-H, 92% yield), either the protection of
hydroxyl group as methoxymethyl ether (MOM) 8 or tetrahydropyranyl ether (THP) 9 were
successfully performed (70 and 94% yields, respectively), and both the derivatives were
evaluated as possible starting material for the next steps of the synthesis.
This article is protected by copyright. All rights reserved.

Scheme 1
Methoxymethylether 8 was reacted with both protected and not protected PEG chains;
however, only the latter proved to work well; the subsequent introduction of acetate function
was successful, but it was not possible to avoid the simultaneous removal of MOM and acetyl
moiety, finalized to the achievement of benzylic alcohol (Scheme 2).
Scheme 2
This article is protected by copyright. All rights reserved.

The same synthetic pathway depicted in Scheme 2, was then applied to THP ether 9, and in
this case the selective deprotection from tetrahydropyranyl group after acetylation of PEG
chain was successful, and the resulting compound 14 (Scheme 3) was used for the subsequent
steps (Scheme 4), that led to the desired set of precursors and the fluorinated reference
compound 1.
Scheme 3
This article is protected by copyright. All rights reserved.

Scheme 4
Indeed, the next step was the functionalization of the benzylic alcohol with a suitable leaving
group for the subsequent introduction of azido moiety. Reaction of compound 14 with mesyl
chloride proceeded smoothly in mild conditions, yielding the desired product 15 with a 93%
This article is protected by copyright. All rights reserved.

yield. The subsequent substitution with the azido group also took place without problems,
leading to compound 16 in high yields.
The last step necessary to obtain the desired precursor was the functionalization of PEG
hydroxyl group. To this aim, acetyl group was first removed under basic conditions, yielding
compound 17, which was then tested with the suitable leaving groups tosylate, mesylate,
triflate, and iodine. Using tosylchloride in anhydrous pyridine, a mixture of products was
obtained. After chromatographic purification, tosylate 2 was obtained in 16% yield. Reaction
with mesyl chloride took place in a shorter time and with nearly quantitative yields of
compound 3. Compared with the mesylation reaction, the functionalization of compound 17
as triflate derivative showed to be more troublesome, with a degradation of PEG chain.
Finally, from mesylate 3 both the iodo precursor 4 and the fluorinated reference standard 1
were prepared in good yield (95% and 71%, respectively).
To verify the effectiveness of precursors 2-4, [18F]F- nucleophilic substitution tests were
performed to achieve the desired radiolabelled azide 18F1 (Scheme 5). The results are
summarized in Table 1.
Scheme 5
Precursor
Reaction temperature
100° C
100° C
RCY (non-decay corrected)
1%
57%
61%
2
3
4
100° C
Table 1 – Radiolabelling of precursors 2-4
All the radiolabelling tests were performed using a fully automated system (GE Tracerlab Fx-
FN Pro), where the original setup was modified and adapted to the proposed preparation
process. As shown, the best precursor revealed to be iodo compound 4. This precursor
brought not only to the highest non-decay-corrected radiochemical yield (RCY), but it also
presented the best impurity profile, which was of utmost importance in view of the
subsequent purification step (Figure 2a). Tosyl group was shown to give elimination rather
than nucleophilic substitution reaction, with negligible radiochemical yield, while mesylate
precursor reacted efficiently with [18F]fluoride, with a 57% RCY at 100° C; unfortunately, in
the optimized HPLC analysis conditions, precursor 3 eluted with a retention time very similar
to that of the product [18F]1, making the post-labelling purification very difficult. During the
radiolabeling procedure, iodo precursor 4 showed marked degradation, yielding hydrolysis
product 17 as the most abundant “cold” by-product, but this occurred only after quenching of
the reaction mixture, so that nucleophilic substitution reaction was not affected. As the
separation of the above by-product from the desired radiolabelled product [18F]1 was easier
This article is protected by copyright. All rights reserved.

compared to precursor 4, the next purification step was straightforward, using simple Sep-Pak
cartridges. Indeed, [18F]1 was achieved with 51% RCY (non-decay corrected) and 93%
radiochemical purity, with a radiosynthesis time of 30 min (Figure 2b).
a
[18F]1
Radiochemical detector
UV detector
17
b
[18F]1
Radiochemical detector
UV detector
Figure 2 – RP-HPLC profile of crude (a) and purified 18F1 (b), obtained from precursor 4. 18F1
retention time was 10.2 min (water/acetonitrile gradient from 60:40 to 20:80 in 20 min, 1 ml/min flow, 220
nm/radiochemical detector).
As a proof of concept, to verify its effectiveness as a useful radiolabelled intermediate for
CuAAC we then tested compound 18F1 with a simple, cost-effective, alkynyl-modified
amino acid, namely L-propargylglycine. With the aim to minimize the well-known copper
complexation with glycine residues,17,18 which may strongly affect the final radiolabelled
aminoacid purification, the “click” reaction was initially performed adapting experimental
conditions originally described by Glaser and Årstad,11 but employing much lower reagent
This article is protected by copyright. All rights reserved.

concentrations (from 4 to 30 folder less, depending on the reagents).19 This is a disadvantage
of using not protected glycine, considering that with other biological molecules, such as
cyclic peptides, this kind of complexation normally does not occur, so that a higher
concentration of copper catalyst might be used, with a consequently increased CuAAC yield.
With the aim to minimize radiation exposure to the operators, the above reaction was tested
using non-radioactive [19F]1 and L-propargylglycine, and it was performed in water with a
variety of co-solvents (ethanol, acetonitrile, dimethylsulfoxide, dimethylformamide), with
acetonitrile being the best choice. The proposed reaction was then tested using radioactive
[18F]1 (Scheme 6).
Scheme 6
Reaction was carried out at 40°C for 30 minutes. During the first 10 minutes, the mixture
volume was reduced under a combination of helium stream and reduced pressure, in order to
accelerate the conversion rate. However, volume should not be reduced below 50 l, as lower
volumes lead to precipitation of copper aggregates., Under these conditions, a 94%
conversion of compound 18F1 in the desired labelled glycine 18F18 was obtained. (Figure
3).
Radiochemical detector
[18F]18
[18F]1
UV detector
Figure 3 – RP-HPLC profile of pre-purified product 18F18 from catalyst system. 18F18 retention time
was 8.9 min, 18F1 retention time was 20.9 min. (water/acetonitrile gradient from 90:10 to 30:70 in 24
min, 1 ml/min flow, 220 nm/radiochemical detector).
This article is protected by copyright. All rights reserved.

After purification using Sep-Pak cartridges, the radiolabelled product 18F18 was obtained in
27% RCY, non-decay corrected, and with a >99% radiochemical purity.
In order to improve the “cold” impurities profile , a different purification method, using semi-
preparative HPLC was tested: also in this case the radiochemical purity was confirmed to be
>99%, and a higher “cold” chemical purity was obtained (Figure 4). Overall synthesis time
was of 104 min, average specific activity of 18F18 was found to be 55 GBq/mole.
[18F]1285
Radiochemical detector
UV detector
Figure 4 – RP-HPLC profile of purified product 18F18 by semipreparative RP-HPLC. 18F18 retention
time was 8.9 min (water/acetonitrile gradient from 90:10 to 30:70 in 24 min, 1 ml/min flow, 220
nm/radiochemical detector).
The final product was dissolved in phosphate buffered saline (PBS, pH=7.2) to make it
available for in vivo preclinical testing. Chemical and radiochemical stability of 18F18 in the
final formulation were then tested, by HPLC analysis of samples of the purified compound up
to eight hours after the end of radiosynthesis, at time intervals of 2 hours and storing the vial
at room temperature. 18F18 proved to be stable in the above conditions, and no significant
loss of radioactivity due to radiolytic degradation was detected. In vitro serum stability was
also evaluated, incubating 18F18 in human serum for 4 hours at 37°C and analyzing samples
using HPLC two and four hours later, respectively. It has been found that the labelled
compound does not significantly bind to plasma proteins, and after 4 hours only the
radioactive peak attributable to the desired compound was detected, prompting for in vitro
stability of the radiotracer. Finally, the predicted logP for [18F]18 was -1.64, calculated using
a standard, freeware software, which confirmed the expected polarity of the radiolabeled
compound.
This article is protected by copyright. All rights reserved.

In conclusion, a novel, versatile, stable, safe and easy to handle azido precursor for the
18
general purpose F radiolabelling via “click-chemistry” was successfully synthesized. The
synthetic pathway started from a cost effective, bifunctional commercial substrate, and a
series of precursors was prepared via an orthogonal protection-deprotection strategy, that
18
allowed substrate selective functionalization. Precursor effectiveness was confirmed by F
radiolabelling tests; in particular, iodo precursor 4 proved to efficiently react with
[18F]fluoride, while at the same time yielding the intermediate 18F1 with good
radiochemical purity, which made it suitable for the subsequent CuAAC with alkynil-
modified propargyl glycine without the need for additional, time consuming, purification
steps. Overall radiosynthesis time and yield were satisfactory, prompting for its use for future
developments with new potentially interesting biomolecules.
EXPERIMENTAL PROCEDURES
Materials and Methods
All reagents and solvents were purchased from Sigma-Aldrich.
TLC analysis were performed on silica gel 60 F254 pre-coated plates with a fluorescent
indicator (Merck) and on ALUGRAM RP-18W/UV254 pre-coated sheets with a fluorescent
indicator (Macherey-Nagel), with detection by a 5% phosphomolybdic acid solution in
ethanol, and heating at 110 °C. DSC (Differential Scanning Calorimetry) was registered on a
Perkin Elmer instrument (Mod. DSC7), using a heating rate of 10° C/min, from 40° C to 120°
C. Infrared spectra were recorded on a Perkin Elmer instrument (Mod. Spectrum One FT-IR)
equipped with the ATR sampling device. Mass spectra were acquired by AmaZon ETD
(Bruker Daltonics) ion trap mass spectrometer equipped with ESI source in positive mode;
the samples were dissolved in methanol or water/acetonitrile at a final concentration of 0.1
mg/ml and directly infused into the mass spectrometer (at a rate of 3 µl/min) or separated by
LC coupled online with MS. Separation on LC were performed using two Jasco PU 980
Intelligent HPLC pump modules connected to an analytical reverse phase column (XTerra
C18 250x4.6 mm, 5 m, Waters). Parameters for the electrospray source were set as follows:
capillary -4500 V, end plate offset -500 V, nebulizer 20 psi, dry gas 9 l/min at 200° C. Ions
from the source were detected in a mass range of 70 to 1000 m/z, with 200000 ICC, and 50
ms as maximum accumulation time. A target mass of 300 m/z and a trap drive of 100% were
employed. Spectra were acquired using MRM modality and by optimizing both the isolation
window and the fragmentation energy for each analyte. Data results were processed by
DataAnalysisTM 4.0 (Bruker Daltonics) software.
NMR spectra were recorded on a Bruker AVANCE 500 spectrometer equipped with a 5mm
1
broadband reverse probe with field z-gradient operating at 500.13 and 125.76 MHz for H
13
and C, respectively. NMR spectra were recorded at 298 K in CDCl3 (isotopic enrichment
99.95%) solution, unless otherwise reported, and the chemical shifts were reported on a 
(ppm) scale. The data were collected and processed by XWIN-NMR software (Bruker)
running on a PC with Microsoft Windows 7. The samples (10 mg), were dissolved in the
appropriate solvent (0.7 mL) in a 5 mm NMR tube. Acquisition parameters for 1D were as
1
follows: H spectral width of 5000 Hz and 32K data points providing a digital resolution of
13
ca. 0.305 Hz per point, relaxation delay 2 s; C spectral width of 29,412 Hz and 64 K data
points providing a digital resolution of ca. 0.898 Hz per point, relaxation delay 2 s (unless
1
13
otherwise indicated). Chemical shifts () of the H NMR and C NMR spectra are reported
in ppm using the signal of residual solvent protons resonance as internal standard. 1H NMR:
This article is protected by copyright. All rights reserved.

CDCl3 7.26 ppm, D2O acidified with DCl (solution 38% in D2O) 4.79 ppm (298 K, pH=1.0);
13C NMR: CDCl3 77.0 ppm (central line), D2O acidified with DCl (solution 38% in D2O)
referenced to external TSP-d4 (3-(trimethylsilyl)propionic-2,2,3,3-d4 acid sodium salt) at 0.00
ppm. The splitting pattern abbreviations are as follows: s, singlet; d, doublet; t, triplet; q,
quartet; m, multiplet, and br, broad signal. For two-dimensional experiments, Bruker
microprograms using gradient selection (gs) were applied. All two-dimensional spectra
(COSY, HSQC) were acquired with 2048 data points for t2 and 256 for t1 increments.
18
[18F] Fluoride was produced by a cyclotron (Cyclone 18/9, IBA) via the O(p,n)18F nuclear
reaction, by proton beam irradiation of a target containing 2 mL of >97% enriched [18O]water
(Rotem).
Radioactive tests were carried out on a commercially available radiochemistry automated
module (GE TracerLab FX N Pro) located in a suitably shielded hot cell (MIP-2, Comecer).
Sep-Pak Light Waters Accel Plus QMA, Sep-Pak alumina N light, and SepPak tC18
cartridges were from Waters Corp.
Radiolabelled preparations and “cold” references were analyzed by RP-HPLC on a Jasco PU-
2089i system equipped with an automated injector, DAD detector, and radiochemical
detector Raytest Gabi Star. Semipreparative purification was carried out on a RP-HPLC
equipped with a Perkin Elmer Flexar system quaternary pump and a Knauer WellChrom
mod. K-2501 UV detector, connected to the automated module for radiosynthesis, and a
“built-in” radioactivity detector. Wavelenght was set at 220 nm.
Analytical RP-HPLC column (Xterra C18 250x4.6 mm, 5 m) was purchased from Waters
Corp, while semi-preparative RP-HPLC column (Clarity Oligo-RP C18, 250x10 mm, 5 µm)
from Phenomenex.
Chemical procedures
[4-(Bromomethyl)phenyl]methanol (7)
The synthesis was carried out similarly as described in literature.20 A solution of 1M
diisobutylaluminum hydride in tetrahydrofuran (50 ml) was added dropwise under nitrogen
to a cooled-down solution (-78° C) of methyl 4-(bromomethyl)benzoate 6 (3.48 g, 15.2
mmol) in anhydrous dichloromethane (90 ml). The mixture was stirred at -78° C for 4 h, and
then an additional amount of diisobutylaluminum hydride solution (5 ml) was added. The
reaction progress was monitored by TLC (toluene/ethyl acetate 9:1). After 1 h the reaction
went to completion. The mixture was kept at 0° C while quenching with water, then it was
allowed to warm to room temperature. The organic layer was separated, and the aqueous one
was extracted with dichloromethane (2 x 50 ml). The combined organic extracts were dried
over anhydrous sodium sulfate, filtered, and concentrated under reduced pressure to afford
the desired product 7 (2.82 g, 14.0 mmol, 92% yield) as a white solid.
Rf 0.28
1H-NMR  1.87 (br s, 1H, exchangeable with D2O), 4.50 (s, 2H, ArCH2Br), 4.68 (s, 2H,
ArCH2O), 7.33 (d, 2H, Ar), 7.39 (d, 2H, Ar)
13C  33.23, 64.82, 127.28, 129.22, 137.13, 141.14
These product 7 NMR data are in agreement with the reported ones.21
IR:  3320, 1419, 1224, 1194, 1006, 831 cm-1
DSC: endothermic peak at 86.8° C
ESI-MS: m/z 104, 183 [M-17]
This article is protected by copyright. All rights reserved.

2-{[4-(Bromomethyl)benzyl]oxy}tetrahydro-2H-pyran (9)
The synthesis was carried out similarly as described in literature.22 A solution of compound 7
(2.0 g, 9.95 mmol, 1 eq) and 3,4-dihydro-2H-pyran (2.4 ml, 26.3 mmol, 2.6 eq) in anhydrous
dichloromethane (50 ml) was cooled-down to 0° C with an ice bath. After the addition of
monohydrate p-toluensulfonic acid (0.010 g, 0.05 mmol, 0.005 eq), the reaction mixture was
stirred 10 min at 0 °C, and then at room temperature for 1.5 h. The completion of the reaction
was monitored by TLC (hexane/ethyl acetate 9:1). The organic layer was washed with a
mixture of saturated brine/saturated sodium hydrogen carbonate/water 1:1:2 (50 ml), and with
saturated brine (10 ml x 2). The organic layer was then dried over anhydrous sodium sulfate,
filtered, and concentrated under reduced pressure. The obtained yellow oil (3.2 g) was
purified by column chromatography on silica gel (silica/crude product 8:1, gradient elution
from hexane 100% to hexane/ethyl acetate 95:5), to afford the desired product 9 (2.7 g, 9.5
mmol, 94% yield) as an yellow oil.
Rf 0.59
1H-NMR  1.44-1.95 (m, 6H, 3CH2), 3.49-3.61 (m, 1H, CHaOCHO), 3.87-3.95 (m, 1H,
CHbOCHO), 4.50 (s, 2H, ArCH2Br), 4.50 (d, 1H, ArCHaOTHP), 4.71 (t, 1H, OCHO), 4.78
(d, 1H, ArCHbOTHP), 7.34 (d, 2H Ar), 7.38 (d, 2H, Ar)
13C-NMR  19.29, 25.43, 30.52, 33.35, 62.11, 68.33, 97.80, 128.11, 129.07, 136.95, 138.73
These NMR data are in agreement with the reported ones.23
2-{2-[2-({4-[(tetrahydro-2H-pyran-2-yloxy)methyl]benzyl}oxy)ethoxy]ethoxy}ethanol
(12)
A solution of triethylene glycol (1.29 g, 8.6 mmol, 1 eq) in anhydrous tetrahydrofuran (70
ml), under nitrogen, was cooled-down to 0° C. Sodium hydride (0.21 g, 8.75 mmol) was
added, and the reaction mixture was stirred for 10 min at 0 °C, then it was allowed to warm to
room temperature, and it was finally stirred for 30 min. After cooling-down to 0° C, a
solution of compound 9 (2.46 g, 8.6 mmol, 1 eq) in tetrahydrofuran (30 ml) was added
dropwise, and the reaction mixture was then stirred at room temperature overnight. The
reaction progress was monitored by TLC (toluene/ethyl acetate 9:1 to verify the
disappearance of compound 9, and hexane/ethanol 8:2 to monitor the presence of the
product). Sodium hydride was quenched with water, cooling the reaction mixture in an ice
bath; the mixture was concentrated under reduced pressure. After dilution with
dichloromethane, the organic layer was washed twice with water, dried over anhydrous
sodium sulfate, and filtered. The solvent was finally evaporated under reduced pressure, to
obtain the crude product (3,0 g), that was then purified by column chromatography on
aluminum oxide (4.7% water content) (10:1), gradient elution from hexane/ethyl acetate 9:1
to 100% ethyl acetate, to afford the desired product 12 (1.3 g, 3.7 mmol, 43% yield).
Rf 0.61
1H-NMR  1.44-1.93 (m, 6H, 3CH2), 2.64 (br s, 1H, exchangeable with D2O), 3.71-3.77 (m,
12H, CH2O), 3.72 (dt, 2H, CH2OCHO), 4.48 (d, 1H, ArCHaOTHP), 4.55 (s, 2H, ArCH2O),
4.76 (d, 1H, ArCHbOTHP), 4.69 (m, 1H, OCHO), 7.28-7.37 (m, 4H, Ar)
13C-NMR  19.29, 25.42, 30.51, 61.69, 62.06, 68.49, 69.29, 70.34, 70.57, 70.62, 72.46,
72.98, 97.62, 127.76, 127.82, 137.39, 137.68
IR:  3449, 2867, 1016, 811 cm-1
ESI-MS: m/z 325, 361 [M+H+-17+23], 375, 445
2-{2-[2-({4-[(tetrahydro-2H-pyran-2-yloxy)methyl]benzyl}oxy)ethoxy]ethoxy}ethyl
acetate (13)
To a solution of 12 (1.3 g, 3.7 mmol, 1 eq) in anhydrous pyridine (5 ml) acetic anhydride was
added (1.2 g, 11.8 mmol, 3.2 eq). The reaction mixture was stirred at room temperature for 2
This article is protected by copyright. All rights reserved.

h, and monitored by TLC (hexane/ethanol 8:2). After dilution with water (water/pyridine
5:1), extraction with dichloromethane was carried out (25 ml x 3). The organic layer was
dried over anhydrous sodium sulfate, filtered, and the solvent was evaporated under reduced
pressure. The obtained crude product 13 (1.45 g, 3.66 mmol, 99% yield) was employed in the
following step without further purifications.
Rf 0.82
1H-NMR  1.46-1.92 (m, 6H, 3CH2), 2.07 (s, 3H, CH3CO), 3.55 (m, 1H, CHaOCHO), 3.59-
3.74 (m, 10H, CH2O), 3.85-3.98 (m, 1H, CHbOCHO), 4.22 (t, 2H, CH2OCO), 4.50 (d, 1H,
ArCHaOTHP), 4.56 (s, 2H, ArCH2O), 4.70 (t, 1H, OCHO), 4.78 (d, 1H, ArCHbOTHP), 7.32
(d, 2H, Ar), 7.34 (d, 2H, Ar)
2-[2-(2-{[4-(hydroxymethyl)benzyl]oxy}ethoxy)ethoxy]ethyl acetate (14)
A solution of compound 13 (1.26 g, 3.2 mmol, 1 eq) in methanol (10 ml) was cooled-down to
0° C. A solution of monohydrate p-toluensulfonic acid (0.11 g, 0.55 mmol, 0.17 eq) in
methanol (10 ml) and water (1 ml) was added dropwise. After 10 min, the mixture was
allowed to warm to room temperature, and it was stirred for 1.5 h. The removal of the
protecting group was monitored by TLC (hexane/ethanol 8:2). The reaction mixture pH was
adjusted to 7 with saturated potassium hydrogen carbonate aqueous solution, then the
solution was concentrated under reduced pressure. Dichloromethane (20 ml) was added, then
the organic layer was washed twice with water (10 ml), dried over anhydrous sodium sulfate,
filtered, and concentrated under reduced pressure, to afford the crude product (0.69 g), which
was finally purified on column on silica gel chromatography (silica/crude product 10:1,
gradient elution from hexane/ethyl acetate 9:1 to 100% ethyl acetate), to afford the desired
product 14 (0.88 g, 2.8 mmol, 88% yield) as an oil.
Rf 0.25
1H-NMR  1.85 (t, 1H, exchangeable with D2O), 2.06 (s, 2H, CH3CO), 3.59-3.72 (m, 10H,
CH2O), 4.19 (t, 2H, CH2OCO), 4.56 (s, 2H, ArCH2O), 4.67 (d, 2H, ArCH2OH), 7.33 (br s,
4H, Ar)
13C-NMR  20.91, 63.61, 65.09, 69.14, 69.42, 70.57, 70.66, 70.68, 72.96, 127.02, 127.95,
137.69, 140.35, 171.07
IR:  3452, 2867, 1735, 1232, 1092, 1048 cm-1
ESI-MS: m/z 295 [M-17], 335 [M+23]
2-(2-{2-[(4-{[(methylsulfonyl)oxy]methyl}benzyl)oxy]ethoxy}ethoxy)ethyl acetate (15)
To a solution of compound 14 (0.88 g, 2.8 mmol, 1 eq) in anhydrous dichloromethane (20
ml), under nitrogen, triethylamine (585 l, 4.2 mmol, 1.5 eq) was added, and the temperature
was cooled down to 0° C. Methanesulfonylchloride (0.39 g, 3.4 mmol, 1.2 eq) was slowly
added, and the reaction mixture was stirred at 0° C for 2 h. The reaction progress was
monitored by TLC (hexane/ethanol 8:2). The reaction mixture was diluted with
dichloromethane (20 ml), and the organic layer was washed twice with saturated brine (40
ml), once with water (40 ml), dried over anhydrous sodium sulfate, and filtered. The solvent
was evaporated under reduced pressure, to afford the crude product 15 (1.02 g, 2.6 mmol,
93% yield) as an oil.
Rf 0.13
1H-NMR  2.07 (s, 3H, CH3CO), 2.92 (s, 3H, CH3SO2), 3.60-3.74 (m, 10H, CH2O), 4.22 (t,
2H, CH2OCO), 4.59 (s, 2H, ArCH2O), 5.24 (s, 2H, CH2OSO2), 7.39 (br s, 4H, Ar)
2-[2-(2-{[4-(azidomethyl)benzyl]oxy}ethoxy)ethoxy]ethyl acetate (16)
A solution of compound 15 (1.02 g, 2.6 mmol, 1 eq) in anhydrous dimethylformamide (3 ml),
kept under nitrogen, was cooled-down to 0° C. Sodium azide (0.18 g, 2.7 mmol) is then
This article is protected by copyright. All rights reserved.

added, and the reaction mixture was stirred at room temperature for 2h. The reaction progress
was monitored by TLC (hexane/ethanol 8:2). The reaction mixture was diluted with water (30
ml) and extracted with ethyl acetate (3 x 15 ml). The collected organic phases were washed
with saturated brine (2 x 15 ml), then dried over anhydrous sodium sulfate, and filtered. The
solvent was evaporated under reduced pressure to afford the crude product 16 (0.85 g, 2.5
mmol, 97% yield) as an oil.
Rf 0.79
1H-NMR  2.07 (s, 3H, CH3CO), 3.60-3.73 (m, 10H, CH2O), 4.22 (t, 2H, CH2OCO), 4.32 (s,
2H, CH2N3), 4.57 (s, 2H, ArCH2O), 7.29 (d, 2H, Ar), 7.36 (d, 2H, Ar)
13C-NMR  20.93, 54.54, 63.59, 69.14, 69.57, 70.59, 70.64, 70.68, 72.81, 128.10, 128.27,
134.66, 138.51, 171.02
IR:  2868, 2095, 1233, 1096, 1051 cm-1
ESI-MS: m/z 360 [M+23]
2-[2-(2-{[4-(azidomethyl)benzyl]oxy}ethoxy)ethoxy]ethanol (17)
Compound 16 (0.80 g, 2.4 mmol, 1 eq) was suspended in a solution of sodium hydroxide
(0.12 g) in 15 ml aqueous methanol, and stirred for 15 min at room temperature. The reaction
progress was monitored by TLC (hexane/ethanol 8:2). The pH was adjusted to 7-8 with a
solution of hydrochloric acid 1 M. The solvent was evaporated, and dichloromethane (50 ml)
was added. The organic layer was washed with water (3 x 8 ml), then dried over anhydrous
sodium sulfate, and filtered. The solvent was evaporated under reduced pressure, to obtain the
crude product (0.67 g), which was finally purified by column chromatography on silica gel
(silica/crude product 10:1, gradient elution from hexane/ethyl acetate 9:1 to 100% ethyl
acetate), to afford the desired product 17 (0.61 g, 2.06 mmol, 86% yield) as a colorless oil.
Rf 0.49
1H-NMR  2.22 (br s, 1H, exchangeable with D2O), 3.57-3.78 (m, 12H, CH2O), 4.32 (s, 2H,
CH2N3), 4.57 (s, 2H, ArCH2O), 7.29 (d, 2H, Ar), 7.37 (d, 2H, Ar)
13C  54.52, 61.74, 69.49, 70.34, 70.57, 70.65, 72.48, 72.83, 128.15, 128.28, 134.69, 138.37
IR:  3454, 2867, 2094, 1248, 1090, 1065, 806 cm-1
ESI-MS: m/z 290, 318 [M+23], 438, 485
2-[2-(2-{[4-(azidomethyl)benzyl]oxy}ethoxy)ethoxy]ethyl 4-methylbenzenesulfonate (2)
A solution of compound 17 (0.043 g, 0.15 mmol, 1 eq) in anhydrous pyridine (2 ml) was
cooled-down to 0° C. p-Toluensulfonyl chloride (0.044 g, 0.23 mmol, 1.5 eq) was added and
after 24h at room temperature, under stirring, an additional amount of p-toluensulfonyl
chloride (0.044 g) was added, and the reaction mixture was kept under stirring at room
temperature for 24 h. The reaction progress was monitored by TLC (hexane/ethanol 8:2). The
reaction mixture was diluted with water/ice (10 ml), and extracted with dichloromethane (3 x
10 ml). The collected organic layers were washed with water (3 x 10 ml), dried over
anhydrous sodium sulfate, filtered, and concentrated under reduced pressure, to afford the
crude product (0.042 g), that was finally purified by column chromatography on silica gel
(silica/crude product 20:1, gradient elution from hexane/ethyl acetate 95:5 to 6:4), to afford
the desired product 2 (0.011 g, 0.024 mmol, 16% yield) as a colorless oil.
Rf 0.54
1H-NMR  2.43 (s, 3H, CH3Ar), 3.56-3.74 (m, 10H, CH2O), 4.15 (t, 2H, CH2OTs), 4.33 (s,
2H, CH2N3), 4.56 (s, 2H, ArCH2O), 7.27-7.41 (m, 6H, Ar), 7.79 (d, 2H, Ar)
LC-MS: m/z 472 [M+23], 523
This article is protected by copyright. All rights reserved.

2-[2-(2-{[4-(azidomethyl)benzyl]oxy}ethoxy)ethoxy]ethyl methanesulfonate (3)
Compound 17 (0.41 g, 1.39 mmol, 1 eq) was suspended in anhydrous dichloromethane (10
ml), under nitrogen. Triethylamine (0.3 ml, 2.15 mmol, 1.5 eq) was added, and the solution
was cooled-down to 0° C. Mesyl chloride (0.19 g, 1.67 mmol, 1.2 eq) was added dropwise,
and the reaction mixture was stirred for 2 h at 0° C. The reaction progress was monitored by
TLC (hexane/ethanol 8:2). The reaction mixture was diluted with dichloromethane (10 ml),
and the organic layer was washed once with saturated brine (20 ml), and once with water (20
ml), then dried over anhydrous sodium sulfate, filtered, and concentrated under reduced
pressure, to afford the desired product 3 (0.52 g, 1.39 mmol, 100% yield) as a colorless oil.
Rf 0.40
1H-NMR  3.04 (s, 3H, CH3SO2), 3.58-3.72 (m, 8H, CH2O), 3.77 (br s, 2H, CH2O), 4.33 (s,
2H, CH2N3), 4.37 (br s, 2H, CH2OMs), 4.57 (s, 2H, ArCH2O), 7.30 (d, 2H, Ar), 7.36 (d, 2H,
Ar)
13C-NMR  37.70, 54.53, 69.04, 69.23, 69.57, 70.60, 70.64, 70.67, 72.84, 128.14, 128.31,
134.75, 138.42
IR:  2919, 2095, 1348, 1249, 1172, 1095, cm-1
ESI-MS: m/z 346, 396 [M+23]
1-(azidomethyl)-4-({2-[2-(2-iodoethoxy)ethoxy]ethoxy}methyl)benzene (4)
To a solution of compound 3 (0.16 g, 0.43 mmol, 1 eq) in anhydrous tetrahydrofuran (5 ml),
under nitrogen, lithium iodide (0.29 g, 2.17 mmol, 5 eq) was added. The reaction mixture was
stirred at room temperature overnight and monitored by TLC (hexane/ethanol 8:2). Water
was added to quench the reaction, and tetrahydrofuran was evaporated. Dichloromethane (10
ml) was added, the organic layer was washed with water (3 x 10 ml), then dried over
anhydrous sodium sulfate, filtered, and concentrated under reduced pressure, to afford the
desired product 4 (0.17 g, 0.41 mmol, 95% yield) as a yellow oil.
Rf 0.80
1H-NMR  3.26 (t, 2H, CH2I), 3.62-3.73 (m, 8H), 3.76 (t, 2H, OCH2CH2I), 4.33 (s, 2H,
CH2N3), 4.58 (s, 2H, ArCH2O), 7.30 (d, 2H, Ar), 7.37 (d, 2H, Ar)
13C-NMR  2.87, 54.57, 69.62, 70.27, 70.68, 70.74, 72.02, 72.85, 128.12, 128.26, 134.68,
138.55
IR:  2863, 2094, 1251, 1090, 805, 672 cm-1
ESI-MS: m/z 315, 396, 406 [M+H+], 428 [M+23], 496, 503
1-(azidomethyl)-4-({2-[2-(2-fluoroethoxy)ethoxy]ethoxy}methyl)benzene (1)
Compound 3 (0.18 g, 0.48 mmol, 1 eq) was dissolved in anhydrous tetrahydrofuran (2 ml),
and the solution was cooled-down to 0° C under nitrogen stream. A solution of 1M
tetrabutylammonium fluoride in tetrahydrofuran (1 ml, 1 mmol, 2 eq) was added, and after
the reaction mixture was allowed to warm to room temperature, it was stirred for 4 h. The
reaction progress was monitored by TLC (hexane/ethanol 8:2). The solvent was evaporated,
and dichloromethane (10 ml) was added. The organic layer was washed twice with water (10
ml), once with saturated brine (10 ml), then dried over anhydrous sodium sulfate, filtered, and
concentrated under reduced pressure, to afford the crude product (0.19 g). Column
chromatography on silica gel (silica/crude product 20:1, gradient elution from hexane/ethyl
acetate 9:1 to 7:3) was performed to afford the desired product 1 (0.10 g, 0.34 mmol, 71%
yield) as colorless oil.
Rf 0.60
1H-NMR  3.62-3.71 (m, 8H, CH2O), 3.75 (dt, 2H, CH2CH2F), 4.33 (s, 2H, CH2N3), 4.56 (dt,
2H, CH2F), 4.58 (s, 2H, ArCH2O), 7.29 (d, 2H, Ar), 7.37 (d, 2H, Ar)
This article is protected by copyright. All rights reserved.

13C-NMR  54.57, 69.60, 70.34, 70.50, 70.70, 70.86, 72.82, 82.47, 83.81, 128.11, 128.27,
134.67, 138.57
IR:  2952, 2095, 1248, 1096, 1046, 806 cm-1
ESI-MS: m/z 320 [M+23], 336, 524
3-{1-[4-({2-[2-(2-fluoroethoxy)ethoxy]ethoxy}methyl)benzyl]-1H-1,2,3-triazol-4-
yl}alanine (18)
A freshly-prepared solution of copper(II) sulfate pentahydrate (10.7 mg, 0.043 mmol, 1.8 eq)
in 150 l water and a freshly-prepared solution of sodium ascorbate (25.7 mg, 0.130 mmol,
5.4 eq) in 150 l water were mixed together under helium. After 2 min a solution of
propargylglycine (3.3 mg, 0.029 mmol, 1.2 eq) in 450 l water was added. After 2 min a
solution of compound 1 (7.1 mg, 0.024 mmol, 1 eq) in 200 l acetonitrile and 100 l
dimethylsulfoxide was added. The reaction mixture was stirred at room temperature for 3 h.
The completion of the reaction was monitored by RP-TLC (water/acetonitrile 9:1), and by
RP-HPLC (XTerra C18 column, water/acetonitrile gradient from 90:10 to 30:70 in 24 min, 1
ml/min, 220 nm). The reaction mixture was solubilized by adding some drops of HCl 1M,
and suspended in 20 ml water/acetonitrile 95:5. The solution was passed through a Sep-Pak
tC18 plus cartridge, which was then washed with water (10 ml), and with a solution of
water/acetonitrile 95:5 (10 ml). The desired compound 18 (6.1 mg, 0.015 mmol, 62% yield)
was obtained from elution with pure acetonitrile or ethanol (3 ml), and final evaporation of
the solvent.
Rf 0.41
Rt 8.7 min
1H-NMR (D2O+DCl)  3.37 (d, 2H, CH2triazole), 3.55-3.66 (m, 8H, CH2O), 3.71 (dt, 2H,
OCH2CH2F), 4.37 (t, 1H, CHNH2), 4.52 (dt, 2H, CH2F), 4.54 (s, 2H, ArCH2O), 5.58 (s, 2H,
CH2N), 7.30 (d, 2H, Ar), 7.38 (d, 2H, Ar), 7.96 (s, 1H, triazol)
13C-NMR (125.76MHz, D2O+DCl)  25.37, 52.21, 53.94, 68.83, 69.41, 69.53, 69.67, 69.78,
69.93, 72.24, 82.61, 83.91, 125.38, 128.33, 129.00, 134.31, 137.88, 140.62, 170.44
ESI-MS: m/z 225, 411 M+H+, 433 [M+23], 449, 458, 467 [M+39+18]
Radiochemistry
1-(azidomethyl)-4-({2-[2-(2-18F-fluoroethoxy)ethoxy]ethoxy}methyl)benzene
from precursor 2
(18F1)
~21 GBq of 18F fluoride were trapped by passing the cyclotron irradiated target solution
through a Sep-Pak light QMA cartridge. A solution of potassium carbonate (2.51 mg, 0.018
mmol) in water (500 l) was passed through the QMA cartridge to elute the activity in the
K+18F- form directly in the reactor vial. A solution of Kryptofix 2.2.2 (15 mg, 0.04 mmol) in
acetonitrile (1 ml) was added, and the solvent was azeotropically distilled at 85° C, under
helium stream. The reactor was cooled-down to 30° C, and a solution of compound 2 (1 mg,
0.002 mmol) in anhydrous acetonitrile (1 ml) was added. The reaction mixture was stirred at
100° C for 30 min under helium pressure (220 KPa). The reactor was cooled-down to room
temperature, and the excess pressure released. Acetonitrile (0.5 ml), and water (1 ml) were
added; the mixture was then passed through two Sep-Pak Al light N cartridges connected in
series, previously conditioned with ethanol (10 ml) and water (10 ml), and directly collected
into the final container. The cartridges were washed with water (2 ml), also collected into the
final container. The obtained final activity was 350 MBq. Analysis by RP-HPLC (XTerra
This article is protected by copyright. All rights reserved.

C18 column, water/acetonitrile gradient from 60:40 to 20:80 in 20 min, 1 ml/min flow, 220
nm/ radiochemical detector) revealed that the product 18F1 was formed (RCY non corrected
for the decay ~1%, 52% radiochemical purity).
18F1:Rt 9.5 min.
Elimination product: Rt 11.6 min, LC-MS m/z 336 [M+18+18+23], 387
1-(azidomethyl)-4-({2-[2-(2-18F-fluoroethoxy)ethoxy]ethoxy}methyl)benzene
from precursor 3
(18F1)
~20 GBq of 18F fluoride were trapped by passing the cyclotron irradiated target solution
through a Sep-Pak light QMA cartridge. A solution of potassium carbonate (2.51 mg, 0.018
mmol) in water (500 l) was passed through the QMA cartridge to elute the activity in the
K+18F- form directly in the reaction vial. A solution of Kryptofix 2.2.2 (15 mg, 0.04 mmol)
in acetonitrile (1 ml) was added, and the solvent was azeotropically distilled at 85° C, under
helium stream. The reactor was cooled-down to 30° C, and a solution of compound 3 (10 mg,
0.027 mmol) in anhydrous acetonitrile (1 ml) was added. The reaction mixture was stirred at
100° C for 20 min under helium pressure (220 KPa). The reactor was cooled-down to room
temperature, and the excess pressure released. Acetonitrile (0.5 ml), and water (1 ml) were
added, and the mixture was then passed through two Sep-Pak Al light N cartridges connected
in series, previously conditioned with ethanol (10 ml) and water (10 ml), and directly
collected into the final container. The cartridges were washed with water (2 ml), and the
volume was collected in the final vial. The obtained final activity was 15 GBq. Analysis by
RP-HPLC (XTerra C18 column, water/acetonitrile gradient from 60:40 to 20:80 in 20 min, 1
ml/min, 220 nm/ radiochemical detector) revealed that the product 18F1 was formed (RCY
non corrected for the decay ~57%, 74% radiochemical purity). The UV spectra showed the
partial degradation of the precursor to afford the hydrolysis product, as confirmed by HPLC
injection of compound 17, and the elimination product.
18F1: Rt 10.0 min.
Hydrolysis product: Rt 5.6 min.
Elimination product: Rt 12.1 min.
1-(azidomethyl)-4-({2-[2-(2-18F-fluoroethoxy)ethoxy]ethoxy}methyl)benzene
from precursor 4
(18F1)
~20 GBq of 18F fluoride were trapped by passing the cyclotron irradiated target solution
through a Sep-Pak light QMA cartridge. A solution of potassium carbonate (2.51 mg, 0.018
mmol) in water (500 l) was passed through the QMA cartridge to elute the activity in the
K+18F- form directly in the reaction vial. A solution of Kryptofix 2.2.2 (15 mg, 0.04 mmol)
in acetonitrile (1 ml) was added, and the solvent was azeotropically distilled at 85° C, under
helium stream. The reactor was cooled-down to 30° C, and a solution of compound 4 (10 mg,
0.025 mmol) in anhydrous acetonitrile (1 ml) was added. The reaction mixture was stirred at
100° C for 20 min under helium pressure (220 KPa). The reactor was cooled-down to room
temperature, and the excess pressure released. Acetonitrile (0.5 ml), and water (1 ml) were
added, and the mixture was then passed through two Sep-Pak Al light N cartridges connected
in series, previously conditioned with ethanol (10 ml) and water (10 ml), and directly
collected into the final container. The cartridges were washed with water (2 ml), and the
volume was also collected in the final container. The obtained final activity was 14.4 GBq.
Analysis by RP-HPLC (XTerra C18 column, water/acetonitrile gradient from 60:40 to 20:80
in 20 min, 1 ml/min, 220 nm/ radiochemical detector) revealed that the product 18F1 was
formed (RCY non corrected for the decay ~61%, 85% radiochemical purity). The UV spectra
showed the precursor complete degradation to afford the hydrolysis product.
This article is protected by copyright. All rights reserved.

18F1: Rt 10.2 min.
Hydrolysis product: Rt 5.7 min.
With the aim of further characterize it, crude compound 18F1 as obtained at the end of the
above described procedure was diluted in water/acetonitrile 90:10 (18 ml) and passed through
a Sep-Pak tC18 Plus cartridge previously conditioned with 10 ml ethanol and 10 ml water.
The cartridge was washed with a solution of water/acetonitrile 80:20 (10 ml), and eluted with
3 ml acetonitrile, to afford the purified 18F1 (~51% RCY non-corrected for the decay, 93%
radiochemical purity), as confirmed by RP-HPLC analysis (XTerra C18 column,
water/acetonitrile gradient from 60:40 to 20:80 in 20 min, 1 ml/min, 220 nm/ radiochemical
detector).
3-{1-[4-({2-[2-(2-18Ffluoroethoxy)ethoxy]ethoxy}methyl)benzyl]-1H-1,2,3-triazol-4-
yl}alanine (18F18)
18F1 reaction mixture, prepared as previously described, was concentrated by heating up to
85°C for 2 min under a helium steam. Then, the mixture was diluted with 5 ml of
water/acetonitrile 90:10 and passed through a Sep-Pak tC18 Plus cartridge previously
conditioned with 10 ml ethanol and 10 ml water. The cartridge was washed with 10 ml of
water/acetonitrile 80:20, the product 18F1 was recovered eluting the cartridge with 1 ml of
acetonitrile and transferred in a second reaction vial. The solution was concentrated to 50 l
by heating up to 85° C for 5 min under a helium stream. After cooling to rt, 150 l of a L-
propargylglycine solution (1.0 mg, 0.009 mmol, 1 eq in 50 l water) and a freshly-prepared
sodium ascorbate solution (3.6 mg, 0.018 mmol, 2 eq in 100 l water) were added, followed
by a freshly-prepared solution of copper(II) sulfate pentahydrate (1.5 mg, 0.006 mmol, 0.7
eq) in 100 l water, and then stirred at 40° C for 30 min. The reaction was quenched with 1
M hydrochloric acid (0.5 ml) and eluted with 3.4 ml water/acetonitrile 90:10 + 0.1% TFA.
Then, to further purify the desired 18F18, reaction mixture was submitted to semi-
preparative RP-HPLC. The intended fraction was collected in a flask filled with 30 ml of
water. The solution was then passed through a Sep-Pak tC18 Plus cartridge previously
conditioned with 10 ml ethanol and 10 ml water. The cartridge was washed with water (10
ml), and the desired product 18F18 was eluted with 1 ml of 10 mM HCl in ethanol and
collected into the final container where it was diluted with 8.7 ml of saline physiological
solution and 0.3 ml of 150 mM phosphate buffer saline (PBS), pH 7.2. The final activity was
in the range 6.6-7.5 GBq, starting from 24-28 GBq of [18F]fluoride activity (>99%
radiochemical purity, ~27% RCY non-decay corrected). Total time synthesis was 104 min.
Conditions for gradient semi-preparative RP-HPLC were as follows: Clarity Oligo RP 5µm,
250x10mm; water +0.1%TFA/acetonitrile +0.1%TFA for 30 seconds, water
+0.1%TFA/acetonitrile +0.1%TFA gradient from 90:10 to 80:20 in 10 min, water
+0.1%TFA/acetonitrile +0.1%TFA 80:20 isocratic for 8 min, water +0.1%TFA/acetonitrile
+0.1%TFA from 80:20 to 30:70 in 10 min, water +0.1%TFA/acetonitrile +0.1%TFA 30:70
isocratic for 10 min; 5 ml/min, 220 nm, UV and radiochemical detector).
18F18: Rt 16.3 min
Analytical RP-HPLC (XTerra C18 column, water/acetonitrile gradient from 90:10 to 30:70 in
24 min, 1 ml/min, 220 nm, radiochemical detector).
18F18: Rt 8.9 min
This article is protected by copyright. All rights reserved.

Plasma stability study
The stability of the radiolabeled compound in plasma was evaluated using human, freshly
drawn heparinized blood samples, that were initially centrifuged at 2800 x g for 15 min to
separate cells, while plasma was stored at 4°C until use. Then, 200 l of plasma were pipetted
into a borosilicate culture tube and 20 l of [18F]18 solution were added (~2 GBq/ml), and
the vials were incubated for 2 and 4 hours at 37°C, respectively. Plasma proteins were then
extracted with 200 l of acetonitrile, and the mixture was both vortexed and centrifuged at
2800 x g for 5 min. Finally, the supernatant was analyzed by RP-HPLC, in the conditions
above described.
ACKNOWLEDGEMENTS
Financial support, as well as the laboratories and radiochemistry equipment were provided by
Tecnomed-Milano-Bicocca University Foundation and Università degli Studi di Milano.
Organic syntheses were performed at the laboratories of Prof. Patrizia Ferraboschi at
Università degli Studi di Milano, Dipartimento di Biotecnologie Mediche e Medicina
Traslazionale, Milan, Italy.
IR analysis were performed by Nicola Colombo.
Mass analysis were performed by Prof. Fulvio Magni group from University of Milano-
Bicocca, Department of Medicine and Surgery, Mass Spectrometry unit, Monza, Italy.
REFERENCES
1. Banister S, Roeda D, Dollé F, Kassiou M. Fluorine-18 Chemistry for PET: A Concise
Introduction. Curr. Radiopharm. 2010;3:68-80.
2. Coenen HH. Fluorine-18 Labeling Methods: Features and Possibilities of Basic Reactions.
Ernst Schering Res. Found. Workshop 2007;62:15-50.
3. Roeda D, Dolle F. Recent Developments in the Chemistry of 18FFluoride for PET. Chem.
Mol. Imaging. 2015;55-77.
4. Pretze M, Pietzsch D, Mamat C. Recent Trends in Bioorthogonal Click-Radiolabeling
Reactions Using Fluorine-18. Molecules. 2013;18:8618-8665.
5. Vaidyanathan G. Zalutsky M. Synthesis of N-succinimidyl 4-[18F]fluorobenzoate, an agent
for labeling proteins and peptides with 18F. Nature Protocols 2006;1:1655-166.
6. Wuest F, Berndt M, Bergmann R, Van der Hoff J, Pietzsch J. Synthesis and Application of
[18F]FDG-Maleimidehexyloxime ([18F]FDG-MHO): A [18F]FDG-Based Prosthetic Group for
the Chemoselective 18F-Labeling of Peptides and Proteins., Bioconjugate Chem.
2008;19:1202-1210
7. Kettenbach K, Schieferstein H, and Ross TL. 18F-Labeling Using Click Cycloadditions.
BioMed Research International. Volume 2014. 2014.
8. Rodionov VO, Fokin VV, Finn MG. Mechanism of the ligand-free CuI-catalyzed azide-
alkyne cycloaddition reaction. Angew. Chem. 2005;117:2250-2255; Angew. Chem. Int. Ed.
44:2210-2215.
9. Zhou D, Chu W, Dence CS, Mach RH, Welch M. Highly efficient click labeling using 2-
[18F]fluoroethyl azide and synthesis of an 18F N-hydroxysuccinimide ester as conjugation
agent. J. Nuclear Medicine and Biology. 2012;39:1175-1181.
This article is protected by copyright. All rights reserved.

10. Rodionov VO, Presolski SI, Diaz DD, Fokin VV, Finn MG Ligand-accelerated Cu-
catalyzed azide-alkyne cycloaddition: a mechanistic report. J. Am. Chem. Soc.
2007;129:12705-12712.
11. Glaser, M., Årstad, E. "Click Labeling" with 2-[18F]Fluoroethylazide for Positron
Emission Tomography. Bioconjugate Chem. 2007;18:989-993.
12. Chun JH, Pike, VW. Single-step Radiosyntheses of '18F-Labeled Click Synthons' from
Azide-functionalized Diaryliodonium Salts. Eur. J. Org. Chem. 2012;24:4541-4547.
13. Wang L, Maskali F, Jacobson O, Avdic D, Rotstein B. Ortho-stabilized 18F-azido click
agents and application in PET imaging of single-stranded DNA aptamer. Angw.Chem. 2015;
59:54-62.
14. Caliceti P, Veronese FM Pharmacokinetic and biodistribution properties of
poly(ethyleneglycol)-protein conjugates. Adv. Drug Delivery Rev. 2003;55:1261-1277.
15. Sezer AD, Yagci, AF Overview of peptide and protein PEGylation properties and general
strategies. Acta Pharm. Sci. 2010;52:376-388.
16. r se , Gil C, Knepper K, Zimmermann V. Organic azides: an exploding diversity of a
unique class of compounds. Angew. Chem. Int. Ed. 2005;44,5188-5240.
17. Borsook H, Thimann, KV. The cupric complexes of glycine and of alanine. J. Biol.
Chem. 1932;98:671-705.
18. Monk CB. Electrolytes in solutions of amino acids. Part II. – The cupric complexes of
glycine, alanine and glycyl-glycine. Trans. Faraday Soc. 195;47:285-291.
19. Li J, Shi L, Jia L, Jiang D, Zhou W, Hu W, Qi Y, Zhang L. Radiolabeling of RGD
peptide and preliminary biological evaluation in mice bearing U87MG tumors. Bioorg. Med.
Chem. 2012;20:3850-3855.
20. Bridger GJ, Boehringer EM, Wang Z, Schols D, Skerlj RT, Bogucki DE. Antiviral
Compounds. 2003;US6506770 B1
21. Vassiliou S, Xeilari M, Yiotakis A, Grembecka J, Pawelczak M, Kafarski P, Mucha A. A
synthetic method for diversification of the P1' substituent in phosphinic dipeptides as a tool
for exploration of the specificity of the S1' binding pockets of leucine aminopeptidases.
Bioorg. Med. Chem. 2007;15:3187-3200.
22. Bernady KF, Floyd MB, Poletto JF, Weiss MJ. Prostaglandins and congeners. 20.
Synthesis of prostaglandins via conjugate addition of lithium trans-1-alkenyltrialkylalanate
reagents. A novel reagent for conjugate 1,4-additions. J. Org. Chem. 1979; 44:1438-1447.
23. Schwede W, Schmees N, Moeller C, Schmidt A, Fuhrmann U. Nonsteroidal progesterone
receptor modulators. PCT Int. Appl. 2009; WO 2009071252 A1.
Precursor
Reaction temperature
100° C
100° C
RCY (non-decay corrected)
1%
57%
61%
2
3
4
100° C
Table 1 – Radiolabelling of precursors 2-4
This article is protected by copyright. All rights reserved.

A Novel Versatile Precursor Suitable for 18F- Radiolabelling via “Click-Chemistry”
B. Lugato, S. Stucchi, S. Ciceri, M. N. Iannone, E.A. Turolla, L. Giuliano, C. Chinello, S.
Todde, P. Ferraboschi*
A new azido precursor useful for the so called “click-reaction”, (alkyne-azide cycloaddition,
18
CuAAC) was prepared and successfully radiolabelled with F (51% radiochemical yield).
The 18F labelled azide was reacted with L-propargylglycine ( 94% of conversion, 27%
radiochemical yield, >99% radiochemical purity).
This article is protected by copyright. All rights reserved.
