NICKEL ELECTRODEPOSITION ON COPPER SUBSTRATE
629
Nonreactive plating vessels are hollow Perspex cyl-
inders (diameter 6 cm, height 20 cm) fitted with an
axial Pt anode wire mounted at the bottom by means of
a tube-end fitting with perforated septum. Four sym-
metrical windows (22.36 or 11.69 cm2) on the vertical
side wall allow positioning of up to four copper cath-
odes (target substrates). Each slot is sealed by an
O-ring fitted window. The slot geometrical shape de-
termines the actual target electrodeposition area. The
liquid-tight sealing of the windows is provided by
stainless steel mechanical pestles mounted on a PVC
ring surrounding the plating vessel and by pressing of
the copper substrate against the O-ring seal. An exter-
nal PVC ring is fitted with four supporting pins to hold
a motor–stirrer combination in position. The stirrer is a
hollow perforated POM cylinder mounted on the axis
of a dc motor and surrounding the platinum anode. The
stirrer rotation speed is set at 600 rpm. Its rotating di-
rection is reversed after each 8 s to improve the deposit
homogeneity. To keep the desired temperature at a pre-
set level, a heater [a series of six isolated 1 Ω/1 W re-
sistors, through which an appropriate direct current is
forced (1.1 A at 40°C, up to 1.8 A at 60°C)] is circu-
larly mounted at the bottom of the vessel. An insulated
sensor, introduced through the stirrer support-plate,
monitors the plating bath bulk temperature. As elec-
trolysis to depletion requires prolonged (up to 24 h)
plating, evaporation of the plating solution occurs. To
maintain a constant liquid volume, 450 ml, a conduc-
tivity glass/graphite sensor monitors the solution level
and actuates a peristaltic pump at the required rate,
supplying distilled water to compensate evaporation
loss.
nickel crystal lattice and/or for their presence in the
carrier/nickel layer interface. In both cases, irradiation
will cause loss of the target material, peeling off, and a
decrease in the 64Cu yield.
Calculations of required deposit thickness. To
take full benefit of the excitation function and to avoid
formation of radionuclidic impurities, the proton en-
trance energy should be 15 MeV [9, 10]. The physical
thickness of the nickel layer is chosen in such a way
that for a given beam/target angle geometry the parti-
cle exit energy should be 3 MeV. According to SRIM
code (The Stopping and Range of Ions in Matter); the
thickness should be 428.15 µm for 90° geometry [11].
To minimize the thickness of the nickel layer, 6° ge-
ometry is preferred, in which case a 43-µm layer is
recommended.
Nickel targets are prepared by dc-CCE (constant
current electrolysis) with deposition of the metal from
acid plating solutions.
Pretreatment of Cu subtsrate. Application of a
voltage before pouring the solution leads to poor adhe-
sion of the nickel deposit. Blistering, cracking, gas
pits, peeling off, and poor adhesion may also be due to
hydrogen evolution in ways not yet identified. Plating
on a dietary or greasy surface inevitably leads to blis-
tering or peeling of. Cathodic cleaning in either acid or
alkaline solutions provides large quantities of hydro-
gen for absorption [14]. In all experiments, the
substrate surface was cleaned with sandpaper of
(1000) grade and immersed in a 2 M nitric acid bath.
Then the surface was washed with water, and oil
contaminations were removed by a mixture of alkali
cleaning powders. Finally the surface was washed with
acetone.
Natural nickel sulfamate was purchased from Fluka
to carry out the initial experiments. The freshly pre-
pared solution of nickel sulfamate was introduced into
the plating vessel. This refined procedure is a result of
several repeated experiments in which the bath acidity,
temperature, and electroplating current were varied.
Influence of current density. Too large amounts
of nickel in the bath cause reduction of deposit adhe-
sion at a low current density, and insufficient amounts
of nickel cause a burn-up of the deposit at a high cur-
rent density. Thus, the optimal current density is com-
pletely determined by the nickel content in the bath.
The morphology of all the electrodeposited Ni tar-
get layers was examined by scanning electron micros-
copy (SEM) using a Jeol model JSM 6400 device at an
accelerating voltage of 20 kV.
According to some publications [12, 13] concerning
concentrations of nickel salts, a bath with 6 g of NiSO4
and 0.5 g of NiCl2 was prepared. Low cathode effi-
ciency was observed at low temperature, high pH, and
high metal content [14]. Too low current density leads
to poor quality of the deposit, whereas too high current
density reduces the overvoltage of hydrogen and de-
creases the quality of the deposit and the current effi-
The thermal shock tests involved heating of the tar-
get to 500°C (the temperature that the nickel layer can
experience during high-current irradiation) for 1 h,
followed by submersion of the hot target in cold water
(15°C). The thermal shock test is a measure for the
incorporation of plating bath compounds into the
