Umpolung reactions in an ionic liquid catalyzed by electrogenerated
N-heterocyclic carbenes. Synthesis of saturated esters from activated
a,b-unsaturated aldehydesw
Marta Feroci,*a Isabella Chiarotto,a Monica Orsini,b Romina Pelagallia and Achille Inesiz*a
Received 16th January 2012, Accepted 3rd April 2012
DOI: 10.1039/c2cc30371j
The umpolung reaction of a,b-unsaturated aldehydes to saturated
esters has been carried out in an ionic liquid by organocatalysis of
electrogenerated NHC. The roles of solvent, precatalyst and proton
donor of the ionic liquid have been verified and good to high yields
of esters have been obtained using a ‘‘green’’ and mild methodology.
use of imidazolium salts in the double role of solvent and
precatalyst,7 we have investigated the possibility to obtain
esters from a,b-unsaturated aldehydes and alcohols, by internal redox
reaction catalyzed by electrogenerated NHC. The advantages of this
methodology reside in the use of a ‘‘green’’ deprotonating reagent, the
electron (cheap, easy to dose, and without byproducts), in a
very polar solvent, the ionic liquid, which should stabilize the
charged intermediates and lead to good yields in products.
Moreover, the use of a solvent with virtually null vapour
pressure allows us to reuse the solvent, limiting the costs for
waste disposal and avoiding air pollution.8
The remarkable versatility of esters as building blocks and as
protecting groups in organic synthesis and their significant
importance for industrial applications have spurred an extensive
investigation aimed to improve the methods for their preparation
as well as to develop new strategies for synthesis.1
The monoelectronic galvanostatic reduction of an imidazolium
salt (at a Pt cathode, in a divided cell) leads to the formation of the
corresponding NHC and H2 (Scheme 1, eqn (1)).7,9 The addition
of cinnamaldehyde 1a to the catholyte, followed by benzyl alcohol
2a, gives the corresponding saturated ester 3aa (Scheme 1, eqn (2)).
In addition, if the NHC–aldehyde adduct reacts with a molecule of
aldehyde, g-butyrolactone 4aa is obtained as a byproduct. In the
absence of current, no ester was isolated from the reaction between
1-butyl-3-methylimidazolium tetrafluoroborate (Bmim-BF4),
aldehyde 1a and alcohol 2a, and the starting material was
recovered (Table 1, entry 1).
The classical procedures for the synthesis of esters involve
the reaction of activated carboxylates with suitable nucleophiles
(esterification) or the exchange of an alkoxy moiety between an
ester and an alcohol (transesterification).2 Recently, the oxidative
esterification of aldehydes, catalyzed by N-heterocyclic carbenes
(NHCs),3 has been proposed as an alternative strategy.4 In this
reaction, the inversion of the normal polarity of the aldehyde
moiety (umpolung) is achieved by addition of an NHC to the
carbonyl group, followed by the H+ shift to yield the ‘‘Breslow
intermediate’’.5 After reaction with the nucleophile (an alcohol),
the corresponding ester is obtained. The organocatalyst
(an NHC) is usually produced by chemical deprotonation of a
suitable imidazolium or thiazolium salt (using DIPEA, DBU,
KOtBu, etc. as bases) in an organic solvent (THF, toluene, etc.).
The oxidation of the aldehyde to ester is accomplished by the
reduction of an external oxidant (O2, MnO2, quinone, azobenzene)4
or by the reduction of a functional group present in the aldehyde
itself (double or triple bond, carbon–halogen bond).6 So, when an
a,b-unsaturated aldehyde is used, after an internal redox reaction a
saturated ester is obtained.
The yield of ester 3aa is affected by many factors (IL,
Faradays per mole of aldehyde, mole ratio alcohol/aldehyde),
as reported in Table 1. When cinnamaldehyde 1a and benzyl
alcohol 2a (in equimolar amounts) were added to previously
electrolyzed (0.5 F molꢀ1 1a) Bmim-BF4, saturated ester 3aa
was isolated in 54% yield (Table 1, entry 2), along with a
significant amount of g-butyrolactone 4aa, a byproduct
obtained due to the reaction of the NHC–aldehyde adduct
with another molecule of aldehyde.7d In order to suppress this
side reaction, an excess of alcohol must be used (Table 1,
entries 3 and 4). A crucial role in this reaction is played by the
As part of efforts focused on the development of ecofriendly
electrochemical methodologies in ionic liquids, based on the
a Dept. SBAI, Sapienza University of Rome, via Castro Laurenziano,
7, I-00161 Rome, Italy. E-mail: marta.feroci@uniroma1.it;
Fax: +39 06 49766749; Tel: +39 06 49766563
b Dept. Elettronica Applicata, University of Roma Tre,
via Vasca Navale, 84, I-00146 Rome, Italy
w Electronic supplementary information (ESI) available: Complete experi-
mental details and spectral data of all products. See DOI: 10.1039/
c2cc30371j
Scheme 1 Scheme for the electrogenerated NHC-catalysed reaction
z Present address: via Antelao, 9, I-00141 Rome, Italy. E-mail:
achille.inesi@uniroma1.it
between cinnamaldehyde and benzyl alcohol.
c
This journal is The Royal Society of Chemistry 2012
Chem. Commun., 2012, 48, 5361–5363 5361
