Unique magnetic behaviour of coexistence of single ion magnet and spin crossover

Article abstract of DOI:10.1016/j.inoche.2019.01.032

Herein, we report a highly rare magnetic phenomenon that is composed of both single ion magnet and spin crossover. To our knowledge, the current single ion magnet exists in a unique manner as it should be the first one only coordinated by carboxylate liga

Full text of DOI:10.1016/j.inoche.2019.01.032

Accepted Manuscript
Unique magnetic behaviour of coexistence of single ion magnet
and spin crossover
Xuefeng Feng, Lixiao Yang, Feng Luo
PII:
S1387-7003(18)31094-3
DOI:
Reference:
https://doi.org/10.1016/j.inoche.2019.01.032
INOCHE 7248
To appear in:
Inorganic Chemistry Communications
Received date:
Revised date:
Accepted date:
14 December 2018
23 January 2019
23 January 2019
Please cite this article as: X. Feng, L. Yang and F. Luo, Unique magnetic behaviour
of coexistence of single ion magnet and spin crossover, Inorganic Chemistry
Communications, https://doi.org/10.1016/j.inoche.2019.01.032
This is a PDF file of an unedited manuscript that has been accepted for publication. As
a service to our customers we are providing this early version of the manuscript. The
manuscript will undergo copyediting, typesetting, and review of the resulting proof before
it is published in its final form. Please note that during the production process errors may
be discovered which could affect the content, and all legal disclaimers that apply to the
journal pertain.

ACCEPTED MANUSCRIPT
Unique magnetic behaviour of coexistence of single ion magnet and spin
crossover
Xuefeng Feng, Lixiao Yang, and Feng Luo*
Fundamental Science on Radioactive Geology and Exploration Technology Laboratory and School
of Biology, Chemistry and Material Science, East China University of Technology, Nanchang
344000, JiangXi, China
*e-mail: ecitluofeng@163.com
Abstract
Herein, we report a highly rare magnetic phenomenon that is composed of both single ion
magnet and spin crossover. To our knowledge, the current single ion magnet exists in a unique
manner as it should be the first one only coordinated by carboxylate ligands plus water
molecule.
Keywords: magnetic properties; single ion magnet; spin crossover; dual function
1. Introduction
In the light of functionality, selecting functional module for bottom-up molecule design should
be one of rational choices in coordination chemistry, as this will gain more chance to maintain the
functionality from the pre-designed functional module[1-6].This, often, requires us to focus our
attentions on some familiar and easy-preparing functional modules like that of paddle-wheel units
{M2(O2C)4} (M=Cu, Ni, Zn, Co, Mo)[7], trigonal {M3(μ3-O)(O2C)6} clusters (M=Sc, Cr, Fe, Ni, Al,
In)[8], 1D {M(O2C)2}n rods (M=Mg, Zn, Co, Ni, Fe, Cu, Mn)[9], all of which contain open metal
site and have been extensively utilized for constructing various metal-organic frameworks (MOFs)

ACCEPTED MANUSCRIPT
aiming at in the applications of gas storage, separation, heat transfer, catalysis, sensing, magnet and
biomedicine. During the assembly process of functional molecules, especially different functional
molecules, maintaining the predesigned functionalities for each other in the finally resulted
materials is still a great challenge, as there, in nature, exists two contrary processes, isolation and
coexistence of different functional modules[10-13]. Thereby, establishing certain balance between
them will be crucial for the purpose. For example, for magnetic purpose, a large number of 3d-4f
magnetic compounds have been prepared[14-17]. However, as we know, the famous performance
for 3d metal like that of Co(II), Fe(II) should be spin crossover[18-19], which is never maintained
in these 3d-4f magnetic compounds.
Herein, we show how coordination competition and preference can be used to trace the balance
of isolation and coexistence processes of difference functional modules and further to assembly of
various functional modules in single crystal.
One effective approach of N-,O-donor mixed ligands ever have been extensively employed to
produce 3d-4f magnetic compounds, mainly dependent on the coordination preference of them,
where 3d metal ions prefer to attract N-donor ligands, by contrast, 4f metal ions is sensitive to
O-donor ligands[20]. On the other hand, one key to maintain the [CoN6]2+ spin-crossover (SCO)
function could be facile by employing two tridentate terpyridine ligands to play chelating effect on
Co(II) ion[19]. In this regard, to isolate and coexist of both 3d SCO and 4f slow magnetism
relaxation, it is proposed here that we first assembly [Co(4-Br-PH-terpy)2]2+ segment as cationic
template and spin-crossover (SCO) functional module, then via charge balance the
Dy(III)-carboxylate segment would be in situ generated and expected to make a contribution of
slow magnetism relaxation. As expected, we obtained compound 1, namely

ACCEPTED MANUSCRIPT
[Co(4-Br-PH-terpy)2][Dy(PHCOO)4·H2O]2(4-Br-PH-terpy=4'-(4-bromophenyl)-2,2':6',2''-terpyridin
e) and found that the 3d SCO and 4f slow magnetism relaxation can be not only well maintained but
also coexist.
2. Experimental detail
2.1 Materials and General Methods
Reagents and solvents were commercially available (Alfa) and were used without further
purification. X-ray powder diffraction were collected by a Bruker AXS D8 Discover powder
diffractometer at 40 kV, 40 mA for Cu Kα, (λ = 1.5406Å). The simulated powder patterns were
calculated by Mercury 1.4 which can be obtained freely from the Cambridge Crystallographic Data
Centre (CCDC). The purity of the bulk samples were determined by element analysis (EA) and
powder X-ray diffraction (PXRD) researches.
2.2 The synthesis of 4-Br-PH-terpy
The synthsis of this ligand is according to the reported method[21]. 4.49 mL (0.04 mol)
2-acetylpyridine, 2.81 g (0.02 mol) 4-bromobenzaldehyde were dissolved in 100 mL ethanol
solution of KOH 3.08 g(0.055 mol) under stirring. Then 58 mL strong ammonia solution was added,
the initially yellow solution immediately turned red-brown. The mixture was stirred for 24 h at
room temperature, and the resulting yellow solid was collected by filtration subsequently washed
with ethanol and water. The compound was purified by dissolving it in methanol, and slowly
removing the methanol, colorless crystals suitable for X-ray diffraction were obtained. Yield 2.8 g
(36%). The single crystal X-ray diffraction studies reveal that it was the organic molecule of
4-Br-PH-terpy. Elemental analysis (%) for 4-Br-PH-terpy (C21H14N3Br): Calc. C/64.96; H/3.63;
N/10.82; Exp.: C/65.12; H/3.65; N/10.86.

ACCEPTED MANUSCRIPT
2.3 The synthesis of [Co(4-Br-PH-terpy)2][Dy(PHCOO)4·H2O]2.
A mixture of CoCl2•6H2O 11.9mg (0.05 mmol) and 4'-(4-bromo phenyl)-2,2':6',2''-terpyridine
40.6mg (0.1 mmol) were added in 10 mL water, stirring for ten minutes after dissolving completely,
then transferred to 25ml Teflon-lined stainless steel vessel. Subsequently Dy2O 318.65mg (0.05
mmol), PHCOOH 36mg (0.4 mmol) and Na2CO3 21.2mg (0.2 mmol) were added. Finally, the
mixture was heated at 180℃ for three days, after which the reaction system was cooled to room
temperature. Red purple stick crystals were obtained. Yield 88% based on Co. Elemental analysis
(%): Calc.: C/54.36, H/3.35, N/3.88. Exp.: C/54.44, H/3.25, N/3.75. The Y(III) replaced compound
is synthesized as that used in synthesis of corresponding Dy(III) compound, except for the
replacement of Dy2O3 by equal Y2O3. Yield 85% based on Co. Elemental analysis (%): Calc.:
C/58.32, H/3.59, N/4.16. Found: C/58.74, H/3.54, N/4.15.
2.4 X-ray crystal structure determination.
Unit cell measurements and intensity data were collected at room temperature on a
Bruker-AXS SMART Breeze CCD diffractometer using graphite monochromated MoKα radiation
(λ=0.71073 Å). The data reduction included a correction for Lorentz and polarization effects, with
an applied multiscan absorption correction (SADABS). The crystal structure was solved and refined
using the SHELXL–97 program suite[22]. Direct methods yielded all non-hydrogen atoms, which
were refined with anisotropic thermal parameters. All hydrogen atom positions were calculated
geometrically and were riding on their respective atoms.
The X-ray crystallographic coordinates for structures reported in this study are deposited at the
Cambridge Crystallographic Data Centre (CCDC) under deposition numbers CCDC 1007379 and
1402732 for compounds 1, and 1-Y. These data can be obtained free of charge
(http://www.ccdc.cam.ac.uk/ data_request/cif ).

ACCEPTED MANUSCRIPT
3. Results and Discussion
3.1 Structural descriptions.
Single X-ray diffraction reveals that 1 crystallizes in the monoclinic P21/c space group and a
ionic structure composed of one cationic [Co(4-Br-PH-terpy)2]2+ segment and two anionic
[Dy(PHCOO)4·H2O]- segments (Fig.
1a).
The asymmetric unit contains two
crystallography-independent Dy(III) sites and one crystallography-independent Co(II) site. Both
Dy1 and Dy2 are nine-coordinated by four chelated PHCOO- ligands plus one water molecules
(O18 for Dy1 and O9 for Dy2), creating a tri-capped triprism, where for Dy1, O1, O2, O6, O4, O7,
O18 atoms made the triprism and O3, O5, O8 act as capped atom, for Dy2, the corresponding is O9,
O10, O12, O15, O16, O17 atoms and O11, O13, O14 (Fig. 1b). Notably, due to all PHCOO- ligands
are chelate towards one Dy(III) site, then resulting in the single Dy(III) ion. To our knowledge, the
combination of Dy(III) and PHCOO- ligands often produce 1D compounds, and only under the
assistance of N-donor ligands, it could produce multi-nuclear compounds.1[23], Thereby, the
present structure of single Dy(III) ion is extremely rare, and maybe, providing a distinct type for
Dy(III) single ion magnet constructed by PHCOO- ligands. The Co(II) site maintains the expected
CoN6 coordination surrounding and shows a disordered octahedral geometry, where N1, N2, N3,N5
atoms form an irregular equatorial plane and N4, N6 offset from the axis with the angle of
N4-Co1-N6/160.4° (Fig. 1c). Moreover, the overall 4-Br-PH-terpy ligand is not coplanar with
dihedral angel of ca. 33.5° and 36.2° between phenyl and terpyridine. Furthermore, the hydrogen
bond interactions between two [Dy(PHCOO)4·H2O]- units can create a supramolecular dinuclear
structure (Fig. 1d).

ACCEPTED MANUSCRIPT
a)
b)
c)
d)
Fig. 1. The structure of 1: a) the coordination surrounding of Co(II) and Dy(III) ions; b)
the geometry of Dy(III) ions; c) the geometry of Co(II) ion; d) the hydrogen bonds between
two [Dy(PHCOO)4·H2O]- units.
To facilitate the next magnetic investigation, we also prepared Y(III)-replaced compound.
However, interestingly, the Y(III)-replaced compound give the same space group and comparable
parameter of unit cell as that observed in Dy(III) compound, but the resulted structure shows some
difference in the aspect of anionic segment (Fig. 1a). As shown in Fig. 2a, we can find that Y1 site
reserves the coordination and geometry feature like that of Dy1 site, whereas Y2 site becomes
eight-coordinated finished only by PHCOO- ligands, giving a geometry of bi-capped triprism. This
change directly results in the formation of binuclear structure for Y2 and Y2A (A: 1-x, 1-y, -z) and
the coordination mode of two PHCOO- ligands become bridging.

ACCEPTED MANUSCRIPT
a)
b)
Fig. 2. The structure of Y(III) replaced compound: a) the coordination surrounding of
Co(II) and Y(III) ions; b) the geometry of Y(III) ions.
3.2 Characterization of XRD.
It can be seen from the XRD image that the characteristic diffraction peaks of the materials we
synthesized are consistent with the simulated diffraction peaks. There are no other hybrid peaks,
which proves that the materials have been successfully synthesized and the purity is very high.
b)
a)
Fig. 3. a)The simulated XRD patterns/black from the single crystal data and the XRD patterns
of the as-synthesized bulk crystals of 1/blue; b)The simulated XRD patterns/black from the single
crystal data and the XRD patterns of the as-synthesized bulk crystals of Y(III) replaced
compound/red.
3.3 Magnetic Properties.
The magnetic properties of 1 is measured at 1000 Oe and 1.8-300K in the heating and cooling
mode, giving no detectable hysteretic phenomenon (Fig. 4). The χMT value at 300K is 30.92
-1
-1
cm3mol K, bigger than the theoretical value (30.12 cm3mol K) of the sum (per Dy2Co), mainly
due to the spin-orbit coupling that often encountered for Dy(III) ions and high-spin octahedral Co(II)
io ns[24]. The low-temperature χMT products show rapid decrease as a result of significant
magnetic anisotropy and/or anti-ferromagnetic interactions between Dy(III) ions, whereas the slow

ACCEPTED MANUSCRIPT
decrease below room temperature is derived from the depopulation of the spin-orbit coupling of
octahedral Co(II) ion and/or Stark sublevels of Dy(III) ions[24]. Seen form these results, we can
confirm that the Co(II) ions in 1 at room temperature is high-spin, and however, could not further
confirm whether it is low-spin for Co(II) ions at low temperature, due to the presence of significant
magnetic anisotropy for Dy(III) ions at low temperature. By contrast, this can be further attested by
magnetic saturation at 2K. As shown in Fig. 4 (inset), the M value of 11.10 Nβ at 70000 Oe is close
to the value of 11 of the sum (per Dy2Co) with Co(II) in low-spin state (S=1/2), and smaller than the
value of 13 of the sum (per Dy2Co) with Co(II) in high-spin state (S=3/2), implying low-spin state
for Co(II) ions at 2K. In this regard, and combining with the above discussion like that of high-spin
state of Co(II) ions at room temperature, we can conclude spin crossover of Co(II) ions in 1.
Fig. 4. The χMT vs. T plot of 1 and inset is the M vs. H plot of 1 at 2K.
Furthermore, to disclose molecule magnet property derived from Dy(III) ions,
temperature-dependent ac magnetic susceptibility was employed. As shown in Fig. 5, it shows
temperature-dependent out-of-phase (χ΄΄) component under zero dc field below 10K, suggesting the
slow relaxation of the magnetization in 1[25]. But, the lack of peaks in the χ΄΄ signal prevents us to
evaluate the relaxation energy barrier via the conventional Arrhenius plot method, mainly due to the
existence of quantum tunnelling of the magnetization (QTM) at low temperature and zero dc
field[25]. Then, another method, recently developed by Bartolomé el al, is applied, giving
Ueff=1.0±0.2 K, τ0=(3.97±0.2)×10−6 s (Fig. 6)[26]. This suggests very small relaxation energy

ACCEPTED MANUSCRIPT
barrier due to strong quantum tunnelling.
Seen from the above results, we can conclude that compound 1 perform both spin crossover
and single ion magnet. To further disclose the spin-crossover behaviour, the magnetic properties of
Y(III) replaced compound was measured at 1000 Oe and 1.8-300K in the heating and cooling mode
(Fig. 7). Similarly, no detectable hysteretic phenomenon was observed. Notably, the χMT value of
-1
-1
1.6 cm3mol K at 300K is less than the expected value of 1.875 cm3mol K for high-spin Co(II) ion,
most likely, due to the onset of spin crossover at this temperature[27]. Below room temperature, the
χMT value first decreases sharply until 150 K, and then gradually until 2K, giving the value of 0.38
-1
cm3mol K at 2K, suggesting a gradual, complete spin transitions from S=3/2 to S=1/2, with
decreasing temperature. This is further convinced by the plots of magnetic saturation, which gives
the saturation value of 0.91 Nβ at 70000 Oe and 2K, very close to the expected value of 1 Nβ for
low-spin Co(II) ion.
Fig. 5. Temperature dependence of the in-phase and out-of-phase (χ΄΄) components of the
ac magnetic susceptibility data for 1 at ac=3 Oe, dc=0 Oe.
Fig. 6. Natural logarithm of the ratio of χ΄΄ to χ΄ vs. 1/T for compound 1 derived from the
above ac magnetic susceptibility data. The solid red line corresponds to a linear fit to the
data.

ACCEPTED MANUSCRIPT
Fig. 7. The χMT vs. T plot of 1-Y and inset is the M vs. H plot of Y(III) replaced
compound at 2K.
Conclusions
In conclusion, taking advantage of coordination competition and preference, we have
successfully isolated one novel [3d][4f] ionic compounds and achieved the maintenance, isolation,
and coexistence of various functional modules. Corresponding to this is that the results provide a
deep insight for understanding the coordination chemistry of 3d and 4f metal ions and a useful
model for understanding the bottom-up assembly process of modules. To some extent, the synthesis
approach used here would be an effective pathway towards the exploration of compounds with the
coexistence of various magnetic functions. The results also suggest the diamagnetic ion replaced
method is very effective to characterize this special magnetic phenomenon.
Acknowledgements
This work was supported by the NSF of China (21661002, 21661001), and the Young scientist
training program of Jiangxi Province of China (no. 20142BCB23018), and the Open Foundation of
Fundamental Science on Radioactive Geology and Exploration Technology Laboratory (East China
Institute of Technology) (RGET1510).
Reference

ACCEPTED MANUSCRIPT
[1] D. N. Woodruff, R. E. P. Winpenny, R. A. Layfield, Lanthanide Single-Molecule Magnets,
Chem. Rev. 113 (2013) 5110-5148.
[2] J. D. Rinehart, J. R. Long, Exploiting single-ion anisotropy in the design of f-element
single-molecule magnets, Chem. Sci. 2 (2011) 2078-2085.
[3] R. Lescouëzec, L. M. Toma, J. Vaissermann, M. Verdaguer, F. S. Delgado, C. Ruiz-Pérez, F.
Lloret, M. Julve, Design of single chain magnets through cyanide-bearing six-coordinate
complexes, Coor. Chem. Rev. 249 (2005) 2691-2729.
[4] O. Waldmann, Magnetic molecular wheels and grids–the need for novel concepts in
“zero-dimensional” magnetism, Coor. Chem. Rev. 249 (2005) 2550-2566.
[5] E. J. L. McInnes, S. Piligkos, G. A. Timco, R. E.P. Winpenny, Studies of chromium cages and
wheels, Coor. Chem. Rev. 249 (2005) 2577-2590.
[6] S. Demir, I.-R. Jeon, J. R. Long, T. D. Harris, Radical ligand-containing single-molecule
magnets, Coor. Chem. Rev. 289 (2015) 149-176.
[7] a) S. S. Y. Chui, S. M. F. Lo, J. P. H. Charmant, A. G. Orpen, I. D. Williams, A chemically
functionalizable nanoporous material, Science. 283 (1999) 1148-1150; b) D. N. Dybtsev, H.
Chun, K. Kim, Rigid and Flexible: A Highly Porous Metal–Organic Framework with Unusual
Guest‐ Dependent Dynamic Behavior, Angew. Chem. Int. Ed. 43 (2004) 5033-5146; c) H.
Wang, J. Getzschmann, I. Senkovska, S. Kaskel, Structural transformation and high pressure
methane adsorption of Co2(1,4-bdc)2dabco, Microporous Mesoporous Mater. 116 (2008)
653-657; (d) M. Kramer, U. Schwarz, S. Kaskel, Synthesis and properties of the metal-organic
framework Mo 3 (BTC) (TUDMOF-1), J. Mater. Chem. 16 (2006) 2245-2248.
2
[8] a)Y. Liu, J. F. Eubank, A. J. Cairns, J. Eckert, V. C. Kravtsov, R. Luebke, M. Eddaoudi,
Assembly of Metal–Organic Frameworks (MOFs) Based on Indium‐ Trimer Building Blocks:
A Porous MOF with soc Topology and High Hydrogen Storage, Angew. Chem. Int. Ed. 46
(2007) 3278-3283; b) S. Ma, X. S. Wang, E. S. Manis, C. D. Collier, H. C. Zhou,
Metal−Organic Framework Based on a Trinickel Secondary Building Unit Exhibiting
Gas-Sorption Hysteresis, Inorg. Chem. 46 (2007) 3432-3434; c) C. Serre, F. Millange, S. Surble,
G. Férey, A Route to the Synthesis of Trivalent Transition‐ Metal Porous Carboxylates with
Trimeric Secondary Building Units, Angew. Chem. Int. Ed. 43 (2004) 6285-6289; d) G. Férey,
C. Mellot-Draznieks, C. Serre, F. Millange, J. Dutour, S. Surblé, I. Margiolaki, A chromium
terephthalate-based solid with unusually large pore volumes and surface area., Science. 309
(2005), 2040-2042.
[9] a) J. A. Mason, K. Sumida, Z. R. Herm, R. Krishna, Long, J. R. Evaluating metal-organic
frameworks for post-combustion carbon dioxide capture via temperature swing adsorption,
Energy Environ. Sci. 4 (2011) 3030-3040; b) N. L. Rosi, J. Kim, M. Eddaoudi, B. L. Chen, M.
O’Keeffe, O. M. Yaghi, Rod Packings and Metal−Organic Frameworks Constructed from
Rod-Shaped Secondary Building Units, J. Am. Chem. Soc.127 (2005) 1504-1518.
[10] R. Ababei, C. Pichon, O. Roubeau, Y. G. Li, N. Bréfuel, L. Buisson, P. Guionneau, C.
Mathonière, R. Clérac, Rational Design of a Photomagnetic Chain: Bridging Single-Molecule
Magnets with a Spin-Crossover Complex, J. Am. Chem. Soc. 135 (2013) 14840-14853.

ACCEPTED MANUSCRIPT
[11] T. Liu, Y. J. Zhang, S. Kanegawa, O. Sato, Photoinduced Metal-to-Metal Charge Transfer
toward Single-Chain Magnet, J. Am. Chem. Soc. 132 (2010) 8250-8251.
[12] S. Wöhlert, J. Boeckmann, M. Wriedt, and C. Näther, Coexistence of Metamagnetism and Slow
Relaxation of the Magnetization in a Cobalt Thiocyanate 2D Coordination Network, Angew.
Chem. Int. Ed. 50 (2011) 6920-6923.
[13] E. Pardo, C. Train, H. B. Liu, L.-M. Chamoreau, B. Dkhil, K. Boubekeur, F. Lloret, K.
Nakatani, H. Tokoro, S-I. Ohkoshi, M. Verdaguer, Multiferroics by Rational Design:
Implementing Ferroelectricity in Molecule‐ Based Magnets, Angew. Chem. Int. Ed. 51 (2012)
8356-8360.
[14] Y. G. Huang, F. L. Jiang, M. C. Hong, Magnetic lanthanide–transition-metal organic–inorganic
hybrid materials: From discrete clusters to extended frameworks, Coor. Chem. Rev. 253 (2009)
2814-2834.
[15] F. Mori, T. Nyui, T. Ishida, T. Nogami, K-Y. Choi, H. Nojiri, Oximate-Bridged Trinuclear
Dy−Cu−Dy Complex Behaving as a Single-Molecule Magnet and Its Mechanistic Investigation,
J. Am. Chem. Soc. 128 (2006) 1440-1441.
[16] C. Aronica, G. Pilet, G. Chastanet, W. Wernsdorfer, J.-F. Jacquot, D. Luneau, A nonanuclear
dysprosium(III)-copper(II) complex exhibiting single-molecule magnet behavior with very
slow zero-field relaxation, Angew. Chem. Int. Ed. 45 (2006) 4659-4662.
[17] M. Mereacre, A. M. Ako, R. Clérac, W. Wernsdorfer, G. Filoti, J. Bartolom, C. E. Anson, A. K.
Powell, A Bell-Shaped Mn11Gd2 Single-Molecule Magnet, J. Am. Chem. Soc. 129 (2007)
9248-9249.
[18] a) G. J. Halder, C. J. Kepert, B. Moubaraki, K. S. Murray, J. D. Cashion, Guest-dependent spin
crossover in a nanoporous molecular framework material, Science. 298 (2002) 1762-1765; b) J.
A. Real, E. Andres, M. C. MuOoz, M. Julve, T. Granier, A. Bousseksou, F. Varret, Spin
crossover in a catenane supramolecular system, Science. 268 (1995) 265-267.
[19] a) M. G. Cowan, J. Olguín, S. Narayanaswamy, J. L. Tallon, S. Brooker, Reversible Switching
of a Cobalt Complex by Thermal, Pressure, and Electrochemical Stimuli: Abrupt, Complete,
Hysteretic Spin Crossover, J. Am. Chem. Soc. 134 (2012) 2892-2894; b) U. Beckmann, S.
Brooker, Cobalt(II) complexes of pyridazine or triazole containing ligands: spin-state control,
Coord. Chem. Rev. 245 (2003) 17-29; c) S. Hayami, Y. Komatsu, T. Shimizu, H. Kamihata, Y.
H. Lee, Spin-crossover in cobalt(II) compounds containing terpyridine and its derivatives,
Coord. Chem. Rev. 255 (2011) 1981-1990; d) G. Juhasz, R. Matsuda, S. Kanegawa, K. Inoue, O.
Sato, K. Yoshizawa, Bistability of Magnetization without Spin-Transition in a High-Spin
Cobalt(II) Complex due to Angular Momentum Quenching, J. Am. Chem. Soc. 131 (2009)
4560-4561.
[20] Y. F. Zhou, M. C. Hong, X. T. Wu, Lanthanide-transition metal coordination polymers based on
multiple N- and O-donor ligands, Chem. Commun, 2 (2006) 135-143.
[21] E. A. Medlycott, G. S. Hanan, T. S. M. Abedin, L. K. Thompson, The effect of steric hindrance
on the Fe(II) complexes of triazine-containing ligands, Polyhedron, 27(2008) 493-501.

ACCEPTED MANUSCRIPT
[22] a) G. M. Sheldrick, SHELXS–97, Program for the Solution of Crystal Structures, University
of Göttingen, Göttingen, Germany, 1990. b) G. M. Sheldrick, SHELXL–97,
Program for the Refinement of Crystal Structures, University of Göttingen,
Göttingen, Germany, 1997.
[23] a) Y. M. Song, F. Luo, M. B. Luo, Z. W. Liao, G. M. Sun, X. Z. Tian, Y. Zhu, Z. J. Yuan, S. J.
Liu, W. Y. Xu, X. F. Feng, The application of single-crystal-to-single-crystal transformation
towards adjustable SMM properties, Chem. Commun, 48 (2012)1006-1008; b) Y. Zhu, F. Luo,
Y. M. Song, H. X. Huang, G. M. Sun, X. Z. Tian, Z. Z. Yuan, Z. W. Liao, M. B. Luo, S. J. Liu,
W. Y. Xu, X. F. Feng, A series of 1D Dy(III) compound showing slow magnetic relaxation:
synthesis, structure, and magnetic studies, Dalton Trans, 41 (2012) 6749-6755; c) Y. Zhu, F.
Luo, M. B. Luo, X. F. Feng, S. R. Batten, G. M. Sun, S. J. Liu, W. Y. Xu, Solvent-induced
reversible single-crystal-to-single-crystal transformations observed in lanthanide complexes,
Dalton Trans, 42 (2013) 8545-8548; d) Y. Zhu, F. Luo, X. F. Feng, Z. W. Liao, Y. M. Song, H.
X. Huang, X. Z. Tian, G. M. Sun, M. B. Luo, Simple Method and Materials to Target
Co(II)-Dy(III) Multi-Nuclear Magnetic Compounds and Single Molecule Magnets (SMMs):
Synthesis, Structure, and Magnetic Studies, Aust. J. Chem. 66 (2013) 75-83.
[24] a) S. Hayami, Y. Shigeyoshi, M. Akita, K. Inoue, K. Kato, K. Osaka, M. Takata, R. Kawajiri, T.
Mitani, Y. Maeda, Reverse Spin Transition Triggered by a Structural Phase Transition, Angew.
Chem. Int. Ed. 44 (2005) 4899-4903; b) S. Hayami, K. Murata, D. Urakami, Y. Kojima, M.
Akita, K. Inoue, Dynamic structural conversion in a spin-crossover cobalt(II) compound with
long alkyl chains, Chem. Commun. 48 (2008) 6510-6512; c) S. Hayami, R. Moriyama, Y.
Shigeyoshi, R. Kawajiri, T. Mitani, M. Akita, K. Inoue, Y. Maeda, Spin-Crossover Cobalt(II)
Compound with Banana-Shaped Structure, Inorg. Chem. 44 (2005) 7295-7297.
[25] a) J. Long, F. Habib, P. H. Lin, I. Korobkov, G. Enright, L. Ungur, W. Wernsdorfer, L. F.
Chibotaru, M. Murugesu, Single-Molecule Magnet Behavior for an Antiferromagnetically
Superexchange-Coupled Dinuclear Dysprosium(III) Complex, J. Am. Chem. Soc. 133 (2011)
5319-5328; b) N. Ishikawa, M. Sugita, T. Ishikawa, S. Y. Koshihara, Y. Kaizu, Lanthanide
Double-Decker Complexes Functioning as Magnets at the Single-Molecular Level, J. Am.
Chem. Soc. 125 (2003) 8694-8695; c) C. De Nadai, A. Mirone, S. S. Dhesi, P. Bencok, N. B.
Brookes, I. Marenne, P. Rudolf, N. Tagmatarchis, H. Shinohara, T. J. S. Dennis, Local
magnetism in rare-earth metals encapsulated in fullerenes, Phys. Rev. B. 69 (2004)
184421-184427; d) F. Bondino, C. Cepek, N. Tagmatarchis, M. Prato, H. Shinohara, A. Goldoni,
Element-specific probe of the magnetic and electronic properties of Dy incar-fullerenes, J. Phys.
Chem. B. 110 (2006) 7289-7295; e) R. Kitaura, H. Okimoto, H. Shinohara, T. Nakamura, H.
Osawa, Magnetism of the endohedral metallofullerenes M@C82 (M=Gd, Dy) and the
corresponding nanoscale peapods: Synchrotron soft x-ray magnetic circular dichroism and
density-functional theory calculations, Phys. Rev. B. 76 (2007) 172409-172412.
[26] J. Bartolomé, G. Filoti, V. Kuncser, G. Schinteie, V. Meracre, C. E. Anson, A. K. Powell, D.
Prodius, C. Turta, Magnetostructural correlations in the tetranuclear series of {Fe3LnO2}
butterfly core clusters: Magnetic and Mössbauer spectroscopic study, Phys. Rev. B. 80 (2009)
014430-014445.
[27] Nielsen, H. Toftlund, A. D. Bond, J. F. Boas, J. R. Pilbrow, G. R. Hanson, C. Noble, M. J. Riley,

ACCEPTED MANUSCRIPT
S. M. Neville, B. Moubaraki, K. S. Murray, Systematic Study of Spin Crossover and Structure
in [Co(terpyRX)2](Y)2 Systems (terpyRX = 4′-alkoxy-2,2′:6′,2′′-terpyridine, X = 4, 8, 12, Y =
−
−
−
−
BF4 ,ClO4 , PF6 , BPh4 ), Inorg. Chem. 48 (2009) 7033-7047.

ACCEPTED MANUSCRIPT
Graphical abstract

ACCEPTED MANUSCRIPT
Highlights
In this work we launch a method to trace the balance of coordination competition and
preference for maintenance, isolation, and coexistence of different functional modules.
Moreover, the current research results also show that this method can produce unique
Dy(III)-carboxylate unit that could not be accessed via common method, thus generating
multi-magnetic materials like that of SIM (single ion magnet)+SCO (spin crossover).
