flask and was isolated in 77% yield (1.2 g) after extractive
workup and column chromatography.
Scheme 4. Competition Experiment between an Ester and a
Carboxylic Acid Showing That the Catalyst Is Fully Selective
toward Amidation of the Acid
Anilines are poor nucleophiles in comparison to aliphatic
amines and need high reaction temperatures in order to work
successfully in direct amidations.15,20,29 All attempts to use even
the electron-rich p-anisidine in the amidation of phenylacetic
acid 1a failed using hafnium catalysis. However, the poor
reactivity of anilines under optimized reaction conditions
enabled the selective acylation of the nonaromatic amine of
2-aminobenzylamine, as illustrated in Scheme 2. In contrast,
aliphatic diamines (e.g. p-xylylenediamine and 1,3-diaminopro-
pane) are incompatible with the reaction conditions and result
in no product formation when they are mixed with phenylacetic
acid. In addition, ammonia (NH3 in THF, 0.4 M) failed to form
the corresponding phenylacetamide.
Although the cyclic amine 1,4-dioxa-8-azaspiro[4.5]decane
works well in the amidation reaction (Table 2, entry 21),
secondary acyclic amines fail as coupling partners, which is in
line with what has previously been reported for boronic acid
catalysis at room temperature.17,18 The reason for this is not
clear, but the increased steric hindrance might play a role. The
results from the condensation of a series of benzylamines with
phenylacetic acid under identical reaction conditions are shown
in Figure 1. As can be seen, increasing the size of the
substituents on the amine lead to a dramatic drop in isolated
amide yield. Whereas optimizations of the reaction conditions
could circumvent this steric effect and enable a reasonable yield
for amide 3t (Table 2, entry 20), other amines such as the
secondary N-methylbenzylamine remained unreactive and
failed to form the desired amide 3ab.
Increasing the steric hindrance in a series of carboxylic acids
did not affect the reaction outcome in the same way (Figure 2).
Interestingly, a significant change in reactivity was only seen
when the β position of the amino acid was doubly substituted,
as in the case of Boc-protected valine (3ad) and isoleucine
(3ae), and in these cases the reaction did not proceed at all.
Despite various attempts to optimize the reaction conditions
for the formation of amide 3ad, no product was formed. The
failure of this substrate to react can possibly be explained by
steric interactions, which hinder the acid to adopt an
appropriate binding mode to hafnium in order to enable
amidation.
In addition to direct amidation of carboxylic acids, group IV
metal complexes are known to catalyze other transformations of
carboxylic derivatives. For example, Yamamoto and co-workers
have shown that HfCl4·2THF and Hf(OtBu)4 catalyze the
esterification of carboxylic acids with alcohols in refluxing
toluene with excellent yields (Scheme 3, reaction A).30 In
addition, Collins et al. recently demonstrated that both intra-
and intermolecular esterifications can be performed using
Hf(OTf)4 as a catalyst in refluxing toluene.31 However, when
we used the hafnocene complex under the reaction conditions
optimized for amidation, no esterification between phenylacetic
acid and ethanol was observed. Instead, the catalyst was
reaction (Table 1, entries 3−6). However, in the corresponding
amidation of valeric acid, the acid concentration effectively
influenced the isolated yield of amide 3b (Table 1, entries 7−
10). It was also found that a high yield of amide 3b could be
obtained at an acid concentration of 0.05 M when the reaction
time was prolonged (Table 1, entry 11), as well as when a larger
excess of the amine was used (Table 1, entry 12).
With this knowledge at hand, we investigated the scope of
the hafnium-catalyzed direct amidation protocol at room
temperature. The reaction conditions were optimized for each
substrate with respect to catalyst loading and molar
concentration. A reaction time of 48 h was chosen as standard
to allow even slow-reacting substrates to reach a high
conversion. It should be noted, however, that several substrates
are fully converted long before this time, some already after 90
min (Table 2, entry 14). Moreover, it was found that the
catalyst loading could be decreased from 10 to 5 mol % for a
number of substrates. A further decrease in catalyst loading
resulted in lower isolated yields, and a control experiment
without the hafnium complex present did not give rise to any
product. Vigorous stirring and freshly activated molecular sieves
were in all cases crucial for an efficient reaction outcome. The
substrate evaluation presented in Table 2 shows that several
substrates work well under the catalytic conditions. No
racemization was detected in the amino acid amide products
(Table 2, entries 5−9) after the reaction. Protection groups
such as Boc (tert-butylcarbonyloxy) (Table 2, entries 3 and 5−
9) and Cbz (benzylcarbonyloxy) (Table 2, entry 4) are stable
under the reaction conditions. Benzoic acid and cinnamic acid
were converted into their corresponding benzylamides in
moderate to good yields (Table 2, entries 11 and 12). These
substrates are particularly interesting, since conjugated acids are
known to react poorly in catalytic direct amidation, unless
elevated reaction temperatures are used.15,18,22 In addition,
sterically demanding carboxylic acids and amines were
successfully transformed into the corresponding amides
(Table 2, entries 10 and 18). Good yields were also obtained
using both electron-rich and electron-poor benzylamines
(Table 2, entries 22−24) as well as electron-poor carboxylic
acids (Table 2, entries 13−15). Of the latter, amide 3o is of
special interest, since the α-halo substituent can easily serve as a
handle for further synthetic manipulations. In addition, amide
3e was synthesized on a 5 mmol scale in a round-bottomed
Scheme 5. Amidation of Phenylacetic Acid with the Amino Ester Methyl (4-Methylamino)benzoate
