Binding of these diarylureas to non-telomeric quadruplexes,
for example the two found in the c-kit promoter,9–11 is very
dependent on the nature of the substituents and the particular
quadruplex, suggesting that the compounds may be tuneable
for a given target quadruplex (to be published).
This work was supported by CRUK and the EU (FP6
Project on Molecular Cancer Medicine). We are grateful to
Dr Mekala Gunaratnam for help with cell biology and Dr JE
Moses for much useful advice on click chemistry.
Notes and references
Fig. 2 The FRET-based competition assay where G4 stabilisation is
shown as the percentage of DTm1mM retained upon addition of
CT-DNA.
1 S. Burge, G. N. Parkinson, P. Hazel, A. K. Todd and S. Neidle,
Nucleic Acids Res., 2006, 34, 5402.
2 D. J. Patel, A. T. Phan and V. Kuryavyi, Nucleic Acids Res., 2007,
35, 7429.
3 J. L. Huppert and S. Balasubramanian, Nucleic Acids Res., 2005,
33, 2908.
4 J. L. Huppert and S. Balasubramanian, Nucleic Acids Res., 2007,
35, 406.
5 A. K. Todd, M. Johnston and S. Neidle, Nucleic Acids Res., 2005,
33, 2901.
6 G. N. Parkinson, M. P. Lee and S. Neidle, Nature, 2002, 417, 876.
7 A. T. Phan, K. N. Luu and D. J. Patel, Nucleic Acids Res., 2006,
34, 5715.
8 A. T. Phan, V. Kuryavyi, K. N. Luu and D. J. Patel, Nucleic Acids
Res., 2007, 35, 6517.
9 H. Fernando, A. P. Reszka, J. Huppert, S. Ladame, S. Rankin, A.
R. Venkitaraman, S. Neidle and S. Balasubramanian,
Biochemistry, 2006, 45, 7854.
10 A. T. Phan, V. Kuryavyi, S. Burge, S. Neidle and D. J. Patel, J.
Am. Chem. Soc., 2007, 129, 4386.
11 S. Rankin, A. P. Reszka, J. Huppert, M. Zloh, G. N. Parkinson, A.
K. Todd, S. Ladame, S. Balasubramanian and S. Neidle, J. Am.
Chem. Soc., 2005, 127, 10584.
12 A. T. Phan, V. Kuryavyi, H. Y. Gaw and D. J. Patel, Nat. Chem.
Biol., 2005, 1, 167.
13 A. Siddiqui-Jain, C. L. Grand, D. J. Bearss and L. H. Hurley, Proc.
Natl. Acad. Sci. U. S. A., 2002, 99, 11593.
14 J. Reed, M. Gunaratnam, M. Beltran, A. P. Reszka, R. Vilar and
S. Neidle, Anal. Biochem., 2008, 380, 99.
G4 vs. duplex DNA selectivity was also assessed by FRET-
based methods, initially screening each of the ligands against a
duplex-forming oligonucleotide containing a range of interca-
lative binding sites [50FAM-(TA)2GC(TA)2T6(TA)2GC-
(TA)2-TAMRA30] (ds DNA). This showed that these ligands
have significantly enhanced G4 over duplex stabilisation
relative to BRACO-19 (Table 1; ESIw). The G4 selectivity of
some of the more potent ligands was further assessed by a
FRET-based competition assay20,24 where the ability of 1 mM of
ligand to retain G4 stabilising affinity was challenged by excess
ratios of calf thymus DNA (CT-DNA). This shows (Fig. 2) that
the ortho-substituted ligands (1–2) retain almost complete G4
selectivity compared to BRACO-19 (B100% vs. B40% selec-
tive) up to a 200-fold excess of base pairs. In addition, the meta-
substituted ligands with 3-substituted side chains (3–4) were
significantly more G4 selective (B70–80%) relative to their
4-substituted analogues (5–6; B30% selective). Altering the
basic group of a side chain had little influence on G4 selectivity
other than for the morpholino analogue (9; B80% selective).
The combined results of these assays demonstrate the impor-
tance of ligand core conformation and side chain substitution
pattern for G4 selectivity over duplex DNA, with the ortho-urea
substitution pattern being optimal.
15 A. De Cian, L. Lacroix, C. Douarre, N. Temime-Smaali, C.
Trentesaux, J. F. Riou and J. L. Mergny, Biochimie, 2008, 90,
131.
16 M. Gunaratnam, O. Greciano, C. Martins, A. P. Reszka, C. M.
Schultes, H. Morjani, J. F. Riou and S. Neidle, Biochem.
Pharmacol., 2007, 74, 679.
17 M. Bejugam, S. Sewitz, P. S. Shirude, R. Rodriguez, R. Shahid and
S. Balasubramanian, J. Am. Chem. Soc., 2007, 129, 12926.
18 H. C. Kolb, M. G. Finn and K. B. Sharpless, Angew. Chem., Int.
Ed., 2001, 40, 2004.
The effects of compounds in this series on short-term cell
proliferation have been examined in two cancer cell lines and
one ‘‘normal’’ fibroblast cell line (Table 1). The majority of
compounds show no toxic cellular effects up to the limits of
aqueous solubility (425 mM), across all three cell lines. Some
activity is observed in the MCF7 breast carcinoma cell line,
generally for those compounds that have some effects on
duplex DNA. The behaviour of the series is in contrast to
that of the trisubstituted acridine compound BRACO-19 and
a number of other G-quadruplex ligands. A desirable property
of such compounds is that their selective effects on cancer cell
growth arise from inhibition of telomerase function and not
from more generalised effects on duplex (i.e. genomic)
DNA.25 It is also desirable from the perspective of potential
therapeutic use that generalised toxicity is minimised. This
study has shown that suitable substituents on the diarylurea
scaffold can give a combination of high telomeric quadruplex
selectivity and low acute toxicity so that for example
compounds 2, 3 or 4 in this present series are suitable for
more detailed studies of their effects on cell growth and
telomere maintenance. These will be reported elsewhere.
19 J. E. Moses and A. D. Moorhouse, Chem. Soc. Rev., 2007, 36,
1249.
20 A. D. Moorhouse, A. M. Santos, M. Gunaratnam, M. Moore, S.
Neidle and J. E. Moses, J. Am. Chem. Soc., 2006, 128, 15972.
21 A. D. Moorhouse, S. Haider, M. Gunaratnam, D. Munnur, S.
Neidle and J. E. Moses, Mol. Biosyst., 2008, 4, 629.
22 A. De Cian, L. Guittat, M. Kaiser, B. Sacca, S. Amrane, A.
Bourdoncle, P. Alberti, M. P. Teulade-Fichou, L. Lacroix and J.
L. Mergny, Methods, 2007, 42, 183.
23 J. L. Mergny and J. C. Maurizot, ChemBioChem, 2001, 2, 124.
24 F. Cuenca, O. Greciano, M. Gunaratnam, S. Haider, D. Munnur,
R. Nanjunda, W. D. Wilson and S. Neidle, Bioorg. Med. Chem.
Lett., 2008, 18, 1668.
25 (a) P. Phatak and A. M. Burger, Br. J. Pharmacol., 2007, 152,
1003–1011; (b) M.-K. Cheng, C. Modi, J. C. Cookson, I.
Hutchinson, R. A. Heald, A. J. McCarroll, S. Missailidis, F.
Tanious, W. D. Wilson, J.-L. Mergny, C. A. Laughton and M.
F. G. Stevens, J. Med. Chem., 2008, 51, 963–975; (c) A. De Cian, L.
Lacroix, C. Douarre, N. Temime-Smaali, C. Trentesaux, J.-F.
Riou and J.-L. Mergny, Biochimie, 2008, 90, 131–155.
ꢀc
This journal is The Royal Society of Chemistry 2008
Chem. Commun., 2008, 5295–5297 | 5297
