Quantitative Effects of Ion Pairing and Sterics on Chain
Propagation Kinetics for 1-Hexene Polymerization Catalyzed by
Mixed Cp′/ArO Complexes
Thomas A. Manz,† Shalini Sharma,‡ Khamphee Phomphrai,‡ Krista A. Novstrup,†
Andrew E. Fenwick,‡ Phillip E. Fanwick,‡ Grigori A. Medvedev,† Mahdi M. Abu-Omar,‡
W. Nicholas Delgass,† Kendall T. Thomson,† and James M. Caruthers*,†
School of Chemical Engineering and Department of Chemistry, Purdue UniVersity,
West Lafayette, Indiana 47907
ReceiVed June 1, 2008
A series of single-site catalysts with mixed cyclopentadienyl/aryloxide ligation were synthesized and
used to polymerize 1-hexene. The effects of solvent, metal, counterion, and ligand structure were
investigated by experiments and by DFT calculations. A solvent with a high dielectric constant led not
only to an increase in the chain propagation rate but also to a change in the reaction order. Catalyst
reactivity was found to be controlled by the difficulty of ion pair separation and steric congestion at the
metal center, which were quantified from DFT simulation by SCF ion pair separation energies and ligand
cone angles. A Cp*Ti(OC6H4-2-Br)Me2/B(C6F5)3 catalyst exhibits unusually high reactivity, which was
correlated to the formation of a partial bond between the aryloxide ortho substituent bromide and Ti
upon ion pair separation. Natural bond orbital analysis was used to quantify the order of this opportunistic
ligation for a series of catalysts. Kinetic analysis and a structure-activity correlation were applied to
interpret the experimental results.
the monomer to reach the catalytic site, the counterion must be
partially displaced; thus, a weakly bound counterion facilitates
monomer coordination and insertion. Ziegler et al. and Fragala
et al. have used computational chemistry to study the effects of
solvent on ion pair formation and separation energies8,9 as well
as on reaction barriers for chain initiation and propagation.10
The presence of solvent was found to dramatically lower the
ion pair separation energies and overall chain propagation
barriers. Since partial separation of the ion pair occurs in the
transition states for chain propagation, the lower barriers to chain
propagation in the presence of solvent were presumably due to
lower ion pair separation energies.
A key question is how to quantitatively model structure-
activity relationships in single-site olefin polymerization ca-
talysis. While it is known that lower ion pair separation energies
and higher solvent dielectric constants can enhance polymeri-
zation activity, only recently Manz et al. presented a quantitative
model explaining how much the chain propagation rate constant
increases for a given change in ligand structure.11 An important
question is whether the structure-activity correlation of Manz
et al. can be extended to include changes in metal, counterion,
and solvent.
Introduction
Homogeneous single-site olefin polymerization catalysts are
commercially important because the catalyst structure can be
engineered to control the polymer molecular weight distribution
and tacticity.1,2 These complexes contain a transition metal
bound to organic ligands and are often used to polymerize
olefins in the condensed phase. Most commonly these complexes
consist of a positively charged metal ion of group IV associated
with a bulky and weakly coordinating counteranion.
It has been established that the nature of the counterion has
a large effect on catalyst reactivity and stereoselectivity,3-5 as
reviewed by Chen and Marks6 and Pedeutour et al.7 Marks and
co-workers have shown that the counterion needs to be weakly
coordinating to achieve high catalyst activity.3,6 In order for
* To whom correspondence should be addressed. E-mail: caruther@
ecn.purdue.edu.
† School of Chemical Engineering.
