Sequential Catalytic Functionalization of Aryltriazenyl Aldehydes for
the Synthesis of Complex Benzenes
Sangwon Seo, Ming Gao, Eva Paffenholz, and Michael C. Willis*
Cite This: ACS Catal. 2021, 11, 6091−6098
Read Online
sı
*
Metrics & More
Article Recommendations
Supporting Information
ACCESS
ABSTRACT: We demonstrate that aryltriazenes can promote
three distinctive types of C−H functionalization reactions, allowing
the preparation of complex benzene molecules with diverse
substitution patterns. 2-Triazenylbenzaldehydes are shown to be
efficient substrates for Rh(I)-catalyzed intermolecular alkyne
hydroacylation reactions. The resulting triazene-substituted ketone
products can then undergo either a Rh(III)-catalyzed C−H
activation, or an electrophilic aromatic substitution reaction,
achieving multifunctionalization of the benzene core. Subsequent
triazene derivatization provides traceless products.
KEYWORDS: hydroacylation, rhodium, triazene, benzene, sequential catalysis
iven the abundance of C−H bonds in organic molecules,
Gthe functionalization of these bonds represents an ideal
method for chemical manipulation.1 Transition-metal catalysis
has played a significant role in the advancement of this field,
providing powerful methods that are comparable to conven-
tional metal-catalyzed cross-coupling reactions.2 In particular,
the use of directing group strategies has been the dominant
approach to achieve regioselective reactions.3 A limitation of
such strategies is that the coordinating group, which, by design,
is present to direct the metal catalyst to specific C−H bonds of
the starting material, will also be present in the final product.
This limits synthetic flexibility, and, thus, the ability to remove
or transform the directing group to other useful functionalities
is advantageous. In addition, it would be beneficial if the
coordinating group was able to promote, not only one, but
multiple C−H functionalization reactions in a selective way.4,5
Metal-catalyzed hydroacylation reactions are examples of
C−H functionalizations in which the C−C multiple bond of an
alkene or alkyne inserts into the formyl C−H bond of an
aldehyde.6,7 Despite the advent of several non-chelation-
controlled methods for hydroacylation reactions,8 intermolec-
ular versions of these processes based on the use of some form
of substrate chelation remain the most common.9 Aldehydes
featuring P-,10 O-,11 N-,12 and S-based chelating groups,13 as
well as chelating alkenes,14 have all been used, and reactions
that proceed under mild reaction conditions and encompass
broad substrate scopes have been achieved. Regio-9e,f,12,15f and
enantioselective16 reactions have also been reported,15b,17 and
applications have been developed.11b,18 With these advances in
place, strategies to mitigate the issues associated with the
presence of chelating-substituents are needed. In this context,
approaches have been developed where the chelating group is
either incorporated into a target structure,18f,19 or transformed
to an alternate functionality.18g,20 For example, our laboratory
has shown that a chelating methyl sulfide employed in
hydroacylation reactions can be directly utilized in subsequent
Rh-catalyzed carbothiolation, arylation, or reduction reactions
(see Scheme 1a).21
Building on these prior reports, we aimed to develop an
alternative chelating group that would provide complementary
transformations and functionalization opportunities. We were
particularly interested in an approach in where the
coordinating group would be capable of promoting further
C−H functionalization reactions, allowing the use of simple
substrates, and access to a variety of substitution patterns. In
this context, Jun has reported a cascade strategy that uses in-
situ-generated picolyl imines for alkene hydroacylation and
ortho-alkylation of benzaldehydes (Scheme 1b).22 This double
C−H functionalization is assisted by a single chelating group.
However, the harsh reaction conditions (170 °C reaction
temperature) result in little regiocontrol, which, in turn, limits
the functionalization at both C−H sites to the same coupling
partner. The synthetic utility of this approach would be
significantly improved if the distinct C−H bonds could be
selectively functionalized using different coupling partners.4 To
achieve these aims, we selected aryl aldehydes substituted with
Received: April 15, 2021
Revised: April 29, 2021
Published: May 5, 2021
© 2021 The Authors. Published by
American Chemical Society
https://doi.org/10.1021/acscatal.1c01722
ACS Catal. 2021, 11, 6091−6098
6091

ACS Catalysis
pubs.acs.org/acscatalysis
Letter
further functionalization processes, allowing access to complex
benzene products.
Scheme 1. (a) Hydroacylation and Subsequent C−S
Functionalization,21 (b) Cascade Hydroacylation/ortho−C-
H Alkylation,22 (c) 2-Triazenyl-benzaldehydes in
Hydroacylation and Sequential C−H, Triazene
Functionalization, and E+ Substitution
2-Triazenylbenzaldehyde starting materials were prepared
from widely available anthranilic acids using simple proce-
dures.29 With the substrates in hand, we began our
investigation by evaluating a range of known hydroacylation
catalysts. It quickly became apparent that the combination of
[Rh(nbd)2]BF4 (nbd = norbornadiene) and bis(diphenylphos-
phinoethane) (dppe), in dichloromethane solvent at room
temperature, was the most efficient catalyst system for the
coupling reaction between the piperidine derivative 1a and a
selection of terminal alkynes (see the Supporting Information
for further details, as well as Scheme 2a). Excellent conversions
Scheme 2. (a) Intermolecular Hydroacylation of 2-
Triazenylbenzaldehyde 1a with Terminal Alkynes, and (b)
Removal of the Triazene Group under Acid Conditions
and yields were achieved with 1-octyne (2a), t-Bu-substituted
alkyne (2b), and phenylacetylene (2c), exclusively delivering
the linear isomers of the hydroacylation adducts 3a−3c.
We next explored how readily the triazene group could be
removed and replaced with a H-atom (see Scheme 2b). Initial
attempts using either known reducing (H-SiCl3)30 or acidic
conditions (TFA)25 were not successful. However, we found
that by using either BF3·OEt2 or triflic acid, the triazene group
could be efficiently removed (Scheme 2b).31 The use of a
THF/water solvent mixture was important for the success of
these reactions, because it presumably aids solubility of the
diazonium salt intermediate.
Next, we examined the scope of sequential hydroacylation/
triazene removal, with respect to different alkynes and 2-
triazenylbenzaldehydes (Scheme 3). The reaction was
generally effective, affording good to excellent yields of the
traceless hydroacylation products. Note that both trans-
formations were performed at ambient temperature. Aldehyde
1a could be combined with a range of terminal alkynes,
including those used in Scheme 2 (4a−4c), as well as
cycloalkyl-substituted alkynes (4d, 4e), enyne (4f), remote-aryl
alkyne (4g), and ferrocenyl (4h) substrates. The reactions also
proceeded well with a variety of different functional groups
positioned around the arene core of the aldehydes; 4-chloro
(4i), 4-trifluoromethyl (4j), 5-trifluoromethoxy (4k), and 5-
fluoro (4l) substituents were all well-tolerated.
2-triazenyl groups (Scheme 1c).23 The triazene group offers
many potential advantages: (1) although not previously
reported, the triazene group should be capable of acting as a
chelating group for metal-catalyzed intermolecular hydro-
acylation, with the first nitrogen atom positioned to form a
stable five-membered acyl-metal-hydride complex;7d (2)
catalyst coordination to the second nitrogen atom would
direct the metal center to the ortho−C−H bond;24 (3) the
electron-donating properties of the triazene would promote
electrophilic aromatic substitution reactions; (4) triazene
groups can be easily removed;25 and (5) triazenes can be
transformed to a wide range of alternative functional
groups.23,24,26 By exploiting just a selection of these activation
modes, it should be possible to access multisubstituted
benzenes; these are motifs that remain of considerable worth
to medicinal chemists.27 Despite the versatility of the triazene
group, its use as a directing group in metal-catalyzed C−H
functionalization is rare and remains challenging.24 This is
mainly due to the difficulty of controlling monofunctionaliza-
tion vs difunctionalization,24a,28 which, in turn, limits synthetic
applications. However, we were confident that our reaction
design, in which a variety of chemically distinct C−H bonds
are present, would alleviate these issues. Herein, we show that
it is indeed possible to use triazene groups in Rh-catalyzed
chelation-controlled alkyne hydroacylation, and in a variety of
The ability of the coordinating triazene group to facilitate
sequential C−H functionalization reactions was evaluated next.
Using the conditions developed by Huang for the ortho−C−H
6092
https://doi.org/10.1021/acscatal.1c01722
ACS Catal. 2021, 11, 6091−6098

ACS Catalysis
pubs.acs.org/acscatalysis
Letter
Scheme 3. Traceless Hydroacylation via Sequential Alkyne
Hydroacylation of 2-Triazenylbenzaldehydes/Removal of
the Triazene Group
Scheme 4. Sequential Hydroacylation/ortho−C−H
a
Functionalization Reactions
a
a
Reaction conditions: 1 (1 equiv), alkyne (1.5 equiv), [Rh(nbd)2]BF4
(5 mol %), dppe (5 mol %), CH2Cl2, 23 °C, 16 h; then, silica filtration
and BF3·OEt2 or TfOH (3.3−10 equiv), THF/H2O, 23 °C, 1 h.
Isolated yields over two steps.
olefination of aryltriazenes as a starting point,24a we found that
a Rh(III)-catalyst system could promote the C−H activation of
the initial hydroacylation products. Further optimization
showed that the original reaction conditions could be
simplified, allowing the reaction to proceed efficiently in the
absence of silver co-catalysts and at lower temperatures. With
the modified conditions in place, we performed the three-
component transformations in a sequential manner, with a
simple filtration through a silica pad separating the two steps
(see Scheme 4). Using two distinctive catalysts, the
combination of 2-triazenylbenzaldehyde 1a and t-Bu-substi-
tuted alkyne 2b, followed by the ortho-olefination with butyl
acrylate, gave the double C−H functionalization product 5a in
an excellent yield with absolute regiocontrol. A range of other
terminal alkynes could also be employed successfully, including
1-octyne (5b), and those substituted with alkyl chloride (5c),
phenyl (5d) and 3-thienyl (5e) groups. In addition, variation
of the aldehyde component was possible; 6-fluoro (5f), 5-
methyl (5g), 5-fluoro (5h), 4-chloro (5i), and 2-naphthyl (5j)
substrates all delivered the final products in good to excellent
yields. Importantly, the reaction could be performed on
increased scale, with the isolation of 1.2 g of benzene 5f
showcasing the excellent practicability of the developed
method.
a
Reaction conditions: 1 (1 equiv), alkyne (1.5 equiv), [Rh(nbd)2]BF4
(5 mol %), dppe (5 mol %), CH2Cl2, 23 °C, 16 h; then, silica filtration
and alkene (2.5 equiv), [RhCp*Cl2]2 (5 mol %), Cu(OAc)2·H2O (2
b
equiv), MeOH, 70 °C, 16 h. Isolated yields over two steps. TfOH
(3.3 equiv), THF/H2O, 23 °C, 1 h; Isolated yields.
noted, the triazene group could subsequently be removed using
triflic acid, providing the meta-substituted products (6a and
6b).
Having explored the utility of the triazene unit as a directing
group in metal-catalyzed sequential C−H functionalization
reactions, we next turned our attention to its potential use as a
controlling substituent in electrophilic aromatic substitution
reactions. We envisioned that the electron-donating ability of
the triazene should allow simple installation of electrophiles
onto the benzene core, which would, when combined with
hydroacylation and triazene removal, give access to additional
The scope, with respect to the alkene component, was also
examined. In addition to tert-butyl acrylate (5k), a selection of
alkenes absent from Huang’s report was also compatible with
the sequential process. These compounds included acrylamide
(5l), phenylsulfone (5m), and styrene (5n), which afforded
the corresponding products in good yields. As previously
6093
https://doi.org/10.1021/acscatal.1c01722
ACS Catal. 2021, 11, 6091−6098

ACS Catalysis
pubs.acs.org/acscatalysis
Letter
substitution patterns. Attracted by the versatility of aryl
bromides in organic synthesis, we selected bromination as
the transformation of choice. We found that one-pot addition
of NBS to the hydroacylation reaction mixture with stirring for
1 h at room temperature resulted in para-selective bromina-
tion, relative to the triazene substituent. In situ removal of the
triazene could be achieved as observed previously, to afford the
meta-substituted bromo enone products 7 (see Scheme 5).
substrates, establishing the high regioselectivity of this reaction.
2-Triazenylbenzaldehydes substituted with 4-fluoro (7f), 4-
chloro (7g), 4-methyl (7h), or 6-fluoro (7i) were also suitable
substrates, affording the meta-bromo products in good yields.
The 3-fluoro (7j) substrate was also well-tolerated for one-pot
hydroacylation/bromination, but triazene removal was in-
efficient. Chlorination could also be achieved if NBS was
replaced with 1-chloro-1,2-benziodoxol-3-one,32 with meta-
chloro-variant (7k) obtained in good yield. The mild reaction
conditions and high yields achieved for these meta-halogenated
products complements recent metal-catalyzed variants,33 which
often require forcing reaction conditions and specific electron-
poor substrates.
Scheme 5. Meta-selective One-Pot Hydroacylation/
a
Bromination, Followed by Removal of the Triazene Group
Until this point, functionalization of the triazene substituent
had only involved conversion to a H atom. However, the full
potential of this group was established by transformation to a
diverse set of products.23 For example, Pd-catalyzed cross-
coupling of triazene-containing hydroacylation adduct 3c with
an aryl boronic acid delivered the arylation product 8 in 88%
yield (Scheme 6).34 Alternatively, treatment of 3c with MeI
Scheme 6. Transformations of the Triazene Group Using
Hydroacylation Adduct 3c
provided the corresponding aryl iodide 9,28 which could either
be isolated, or reacted directly in a Pd-catalyzed Sonogashira-
coupling reaction to deliver alkyne 10. Reaction of 3c with
TMS-N3 afforded the azide-substituted enone 11 in excellent
yield.28 The triazene group could also be converted to a
deuterium atom via treatment with deuterated TFA and
deuterated THF (12).35
Having established a series of transformations that exploit
the triazene substituent of hydroacylation adducts, we then
combined several of these reactions with hydroacylation
(Scheme 7). Because of the importance of polyaromatic
compounds, the Pd-catalyzed detriazenative-arylation reaction
was further studied in a sequential manner (Scheme 7a). 4-
Methyl (13a), 2-methyl (13b), and 3-chloro-4-methoxy (13c)
aryl boronic acids were combined with 3-fluoro, 4-chloro, and
6-fluoro substrates, respectively, following hydroacylation,
giving the biaryl products in excellent yields. Although the
addition of a Pd catalyst is required for the arylation step, the
overall catalyst loading of the Rh(I) complex is reduced, no
oxidant is needed, less-costly reagents are used, and at a lower
temperature, when compared to the earlier reported cascade
a
Reaction conditions: (i) 1 (1 equiv), alkynes (1.5 equiv),
[Rh(nbd)2]BF4 (5 mol %), dppe (5 mol %), CH2Cl2, 23 °C, 16 h;
then NBS (1.5 equiv), 23 or 40 °C, 1−1.5 h, (ii) TfOH (3.3 equiv),
THF/H2O, 23 °C, 1 h; Sequential yields = yields over two steps,
obtained using one silica purification. b1-chloro-1,2-benziodoxol-3-
one used in place of NBS.
Bromination using an isolated hydroacylation product
confirmed that the process was not metal-catalyzed. In
addition, a control reaction established that a simple (E)-
chalcone was unreactive under these reaction conditions,
confirming the requirement for the triazene group. The scope
of the one-pot hydroacylation/bromination was general, and a
range of alkynes and aldehydes could be employed successfully.
tert-Butyl (7a), 1-octyne (7b), and cyclopentyl (7c) substrates
were efficiently transformed to the corresponding sequential
products. Phenyl- (7d) and phthalimide-substituted (7e) alkyl
examples were also compatible. Bromination of the non-
triazene-substituted aromatic rings was not observed in these
6094
https://doi.org/10.1021/acscatal.1c01722
ACS Catal. 2021, 11, 6091−6098

ACS Catalysis
pubs.acs.org/acscatalysis
Letter
of sequential transformations, including ortho-C−H olefina-
tion, para-bromination, and a range of detriazenative
functionalizations. Each class of sequential reaction utilizes
mild reaction conditions and tolerates a broad range of
functional groups, delivering traceless-, ortho- and meta-
substituted hydroacylation products. The ability to link
together multiple distinct transformations in a selective and
efficient manner demonstrates the versatility of triazenyl
aldehyde substrates for the preparation of complex benzenes,
which remain valuable motifs in drug discovery.27
Scheme 7. (a) Sequential Hydroacylation/Detriazenative
Arylation, (b) One-Pot Hydroacylation/1,4-Conjugate
Addition Followed by Arylation, and (c) Multiple C−H
Functionalizations Followed by Suzuki Coupling
ASSOCIATED CONTENT
* Supporting Information
The Supporting Information is available free of charge at
https://pubs.acs.org/doi/10.1021/acscatal.1c01722.
■
sı
Experimental procedures and supporting characteriza-
tion data and spectra (PDF)
AUTHOR INFORMATION
Corresponding Author
■
Michael C. Willis − Department of Chemistry, Chemistry
Research Laboratory, University of Oxford, Oxford OX1
3TA, United Kingdom; orcid.org/0000-0002-0636-
6471; Email: michael.willis@chem.ox.ac.uk
Authors
Sangwon Seo − Department of Chemistry, Chemistry Research
Laboratory, University of Oxford, Oxford OX1 3TA, United
Kingdom; orcid.org/0000-0003-2281-9167
Ming Gao − Department of Chemistry, Chemistry Research
Laboratory, University of Oxford, Oxford OX1 3TA, United
Kingdom
Eva Paffenholz − Department of Chemistry, Chemistry
Research Laboratory, University of Oxford, Oxford OX1
3TA, United Kingdom
Complete contact information is available at:
https://pubs.acs.org/10.1021/acscatal.1c01722
Notes
The authors declare no competing financial interest.
ACKNOWLEDGMENTS
This work was supported by the EPSRC (No. EP/K024205/
1).
■
REFERENCES
■
(1) (a) Lam, N. Y. S.; Wu, K.; Yu, J. Q. Advancing the Logic of
Chemical Synthesis: C−H Activation as Strategic and Tactical
Disconnections for C−C Bond Construction. Angew. Chem., Int. Ed.
2021, in press, DOI: 10.1002/anie.202011901. (b) Gandeepan, P.;
Muller, T.; Zell, D.; Cera, G.; Warratz, S.; Ackermann, L. 3d
Transition Metals for C-H Activation. Chem. Rev. 2019, 119, 2192−
2452. (c) Davies, H. M. L.; Morton, D. Collective Approach to
Advancing C-H Functionalization. ACS Cent. Sci. 2017, 3, 936−943.
(d) Davies, H. M.; Morton, D. Recent Advances in C-H
Functionalization. J. Org. Chem. 2016, 81, 343−350.
C−S activation process.21a Using a single Rh(I) complex, as
previously reported by our laboratory, it was possible to
achieve sequential alkyne hydroacylation and aryl boronic acid
conjugate addition into the enone (Scheme 7b).18c The
triazene group remained intact during these one-pot reactions,
and it could then be exploited in a Pd-catalyzed coupling
reaction with a further aryl boronic acid to afford polyaryl
ketone 14 in a selective manner. Finally, alkyne hydroacylation,
para-bromination, and ortho-olefination could be combined to
achieve three successive C−H functionalization reactions,
delivering complex pentasubstituted benzene 15 in a simple
procedure. The Pd-catalyzed Suzuki-coupling of 15 was also
possible, and it afforded the arylation product 16.
(2) Gensch, T.; Hopkinson, M. N.; Glorius, F.; Wencel-Delord, J.
Mild metal-catalyzed C-H activation: examples and concepts. Chem.
Soc. Rev. 2016, 45, 2900−2936.
(3) (a) Gandeepan, P.; Ackermann, L. Transient Directing Groups
for Transformative C−H Activation by Synergistic Metal Catalysis.
Chem. 2018, 4, 199−222. (b) Engle, K. M.; Mei, T.-S.; Wasa, M.; Yu,
J.-Q. Weak Coordination as a Powerful Means for Developing Broadly
Useful C−H Functionalization Reactions. Acc. Chem. Res. 2012, 45,
In summary, we have shown that a dppe-Rh(I) complex can
catalyze alkyne hydroacylation of 2-triazenylbenzaldehydes.
The versatility of the triazene chelating group enables a variety
6095
https://doi.org/10.1021/acscatal.1c01722
ACS Catal. 2021, 11, 6091−6098

ACS Catalysis
pubs.acs.org/acscatalysis
Letter
788−802. (c) Lyons, T. W.; Sanford, M. S. Palladium-Catalyzed
Ligand-Directed C-H Functionalization Reactions. Chem. Rev. 2010,
110, 1147−1169. (d) Colby, D. A.; Bergman, R. G.; Ellman, J. A.
Rhodium-Catalyzed C-C Bond Formation via Heteroatom-Directed
C-H Bond Activation. Chem. Rev. 2010, 110, 624−655.
(4) Mandal, A.; Dana, S.; Chowdhury, D.; Baidya, M. Recent
Advancements in Transition-Metal-Catalyzed One-Pot Twofold
Unsymmetrical Difunctionalization of Arenes. Chem. - Asian J.
2019, 14, 4074−4086.
Regioselective hydroacylation of 1,3-dienes by cobalt catalysis. J. Am.
Chem. Soc. 2014, 136, 3772−3775. (g) Shibahara, F.; Bower, J. F.;
Krische, M. J. Diene Hydroacylation from the Alcohol or Aldehyde
Oxidation Level via Ruthenium-Catalyzed C-C Bond-Forming
Transfer Hydrogenation: Synthesis of β,γ-Unsaturated Ketones. J.
Am. Chem. Soc. 2008, 130, 14120−14122. (h) Omura, S.; Fukuyama,
T.; Horiguchi, J.; Murakami, Y.; Ryu, I. Ruthenium Hydride-
Catalyzed Addition of Aldehydes to Dienes Leading to β,γ-
Unsaturated Ketones. J. Am. Chem. Soc. 2008, 130, 14094−14095.
(i) Roy, A. H.; Lenges, C. P.; Brookhart, M. Scope and Mechanism of
the Intermolecular Addition of Aromatic Aldehydes to Olefins
Catalyzed by Rh(I) Olefin Complexes. J. Am. Chem. Soc. 2007, 129,
2082−2093. (j) Lenges, C. P.; Brookhart, M. Co(I)-Catalyzed Inter-
and Intramolecular Hydroacylation of Olefins with Aromatic
Aldehydes. J. Am. Chem. Soc. 1997, 119, 3165−3166. (k) Tsuda,
T.; Kiyoi, T.; Saegusa, T. Nickel(0)-catalyzed hydroacylation of
alkynes with aldehydes to alpha, beta.-enones. J. Org. Chem. 1990, 55,
2554−2558. (l) Marder, T. B.; Roe, D. C.; Milstein, D. Transition-
metal-catalyzed carbon-carbon bond formation via carbon-hydrogen
activation. Intermolecular hydroacylation: the addition of aldehydes
to alkenes. Organometallics 1988, 7, 1451−1453.
(5) (a) Sarkar, D.; Gulevich, A. V.; Melkonyan, F. S.; Gevorgyan, V.
Synthesis of Multisubstituted Arenes via PyrDipSi-Directed Unsym-
metrical Iterative C−H Functionalizations. ACS Catal. 2015, 5,
6792−6801. (b) Gulevich, A. V.; Melkonyan, F. S.; Sarkar, D.;
Gevorgyan, V. Double-fold C-H oxygenation of arenes using
PyrDipSi: a general and efficient traceless/modifiable silicon-tethered
directing group. J. Am. Chem. Soc. 2012, 134, 5528−5531. (c) Zhang,
S. Y.; Li, Q.; He, G.; Nack, W. A.; Chen, G. Pd-catalyzed
monoselective ortho-C-H alkylation of N-quinolyl benzamides:
evidence for stereoretentive coupling of secondary alkyl iodides. J.
Am. Chem. Soc. 2015, 137, 531−539. (d) Kim, H. J.; Ajitha, M. J.; Lee,
Y.; Ryu, J.; Kim, J.; Lee, Y.; Jung, Y.; Chang, S. Hydrogen-bond-
assisted controlled C-H functionalization via adaptive recognition of a
purine directing group. J. Am. Chem. Soc. 2014, 136, 1132−1140.
(e) Engle, K. M.; Wang, D. H.; Yu, J. Q. Constructing multiply
substituted arenes using sequential palladium(II)-catalyzed C-H
olefination. Angew. Chem., Int. Ed. 2010, 49, 6169−6173. (f) Li, J.;
Korvorapun, K.; De Sarkar, S.; Rogge, T.; Burns, D. J.; Warratz, S.;
Ackermann, L. Ruthenium(II)-catalysed remote C-H alkylations as a
versatile platform to meta-decorated arenes. Nat. Commun. 2017, 8,
15430. (g) Ghosh, K.; Rit, R. K.; Ramesh, E.; Sahoo, A. K.
Ruthenium-Catalyzed Hydroarylation and One-Pot Twofold Unsym-
metrical C-H Functionalization of Arenes. Angew. Chem., Int. Ed.
2016, 55, 7821−7825.
(10) Lee, H.; Jun, C. H. Hydroacylation of 1-Alkene with 2-
(Diphenylphosphino)Benzaldehyde by Rh(I). Bull. Korean Chem. Soc.
1995, 16, 66−68.
(11) (a) Li, H. S.; Lu, S. C.; Chang, Z. X.; Hao, L.; Li, F. R.; Xia, C.
Rhodium-Catalyzed Ring-Opening Hydroacylation of Alkylidenecy-
clopropanes with Chelating Aldehydes for the Synthesis of gamma,
delta-Unsaturated Ketones. Org. Lett. 2020, 22, 5145−5150.
(b) Murphy, S. K.; Petrone, D. A.; Coulter, M. M.; Dong, V. M.
Catalytic Hydroacylation as an Approach to Homoaldol Products.
Org. Lett. 2011, 13, 6216−6219. (c) Coulter, M. M.; Kou, K. G. M.;
Galligan, B.; Dong, V. M. Regio- and Enantioselective Intermolecular
Hydroacylation: Substrate-Directed Addition of Salicylaldehydes to
Homoallylic Sulfides. J. Am. Chem. Soc. 2010, 132, 16330−16333.
(d) Kokubo, K.; Matsumasa, K.; Miura, M.; Nomura, M. Rhodium-
Catalyzed Coupling Reaction of Salicyl Aldehydes with Alkynes via
Cleavage of the Aldehyde C-H Bond. J. Org. Chem. 1997, 62, 4564−
4565. (e) Imai, M.; Tanaka, M.; Tanaka, K.; Yamamoto, Y.; Imai-
Ogata, N.; Shimowatari, M.; Nagumo, S.; Kawahara, N.; Suemune, H.
Double-Chelation-Assisted Rh-Catalyzed Intermolecular Hydroacyla-
tion between Salicylaldehydes and 1,4-Penta- or 1,5-Hexadienes. J.
Org. Chem. 2004, 69, 1144−1150. (f) Barwick-Silk, J.; Hardy, S.;
Willis, M. C.; Weller, A. S. Rh(DPEPhos)-Catalyzed Alkyne
Hydroacylation Using beta-Carbonyl-Substituted Aldehydes: Mecha-
nistic Insight Leads to Low Catalyst Loadings that Enables Selective
Catalysis on Gram-Scale. J. Am. Chem. Soc. 2018, 140, 7347−7357.
(g) Coxon, T. J.; Fernandez, M.; Barwick-Silk, J.; McKay, A. I.;
Britton, L. E.; Weller, A. S.; Willis, M. C. Exploiting Carbonyl Groups
to Control Intermolecular Rhodium-Catalyzed Alkene and Alkyne
Hydroacylation. J. Am. Chem. Soc. 2017, 139, 10142−10149.
(12) (a) Straker, R. N.; Formica, M.; Lupton, J. D.; Niu, J.; Willis, M.
C. An enamine controlling group for rhodium-catalyzed intermo-
lecular hydroacylation. Tetrahedron 2018, 74, 5408−5414. (b) Zhang,
T.; Qi, Z.; Zhang, X.; Wu, L.; Li, X. Rh(III)-catalyzed hydroacylation
reactions between N-sulfonyl 2-aminobenzaldehydes and olefins.
Chem. - Eur. J. 2014, 20, 3283−3287. (c) Castaing, M.; Wason, S. L.;
Estepa, B.; Hooper, J. F.; Willis, M. C. 2-Aminobenzaldehydes as
Versatile Substrates for Rhodium-Catalyzed Alkyne Hydroacylation:
Application to Dihydroquinolone Synthesis. Angew. Chem., Int. Ed.
2013, 52, 13280−13283. (d) Jun, C.-H.; Lee, H.; Hong, J.-B.; Kwon,
B.-I. Efficient and Selective Hydroacylation of 1-Alkynes with
Aldehydes by a Chelation-Assisted Catalytic System. Angew. Chem.,
Int. Ed. 2002, 41, 2146−2147. (e) Jun, C. H.; Lee, D. Y.; Lee, H.;
Hong, J. B. A highly active catalyst system for intermolecular
hydroacylation. Angew. Chem., Int. Ed. 2000, 39, 3070−3072.
(6) (a) Sakai, K.; Oda, O.; Nakamura, N.; Ide, J. Synthetic Studies
on Prostanoids 1 Synthesis of Methyl 9-Oxoprostanoate. Tetrahedron
Lett. 1972, 13, 1287−1290. (b) Tsuji, J.; Ohno, K. Organic syntheses
by means of noble metal compounds XXI. Decarbonylation of
aldehydes using rhodium complex. Tetrahedron Lett. 1965, 6, 3969−
3971.
(7) (a) Davison, R. T.; Kuker, E. L.; Dong, V. M. Teaching
Aldehydes New Tricks Using Rhodium- and Cobalt-Hydride
Catalysis. Acc. Chem. Res. 2021, 54, 1236−1250. (b) Ghosh, A.;
Johnson, K. F.; Vickerman, K. L.; Walker, J. A.; Stanley, L. M. Recent
advances in transition metal-catalysed hydroacylation of alkenes and
alkynes. Org. Chem. Front. 2016, 3, 639−644. (c) Dong, V. M.; Kou,
K. G. M.; Le, D. N. Transition-Metal-Catalyzed Hydroacylation. In
Organic Reactions; Wiley: Hoboken, NJ, 2018; pp 231−592, .
(d) Willis, M. C. Transition Metal Catalyzed Alkene and Alkyne
Hydroacylation. Chem. Rev. 2010, 110, 725−748. (e) Jun, C.-H.; Jo,
E.-A.; Park, J.-W. Intermolecular Hydroacylation by Transition-Metal
Complexes. Eur. J. Org. Chem. 2007, 2007, 1869−1881.
(8) Leung, J. C.; Krische, M. J. Catalytic intermolecular hydro-
acylation of C−C π-bonds in the absence of chelation assistance.
Chem. Sci. 2012, 3, 2202−2209.
(9) (a) Ding, W.; Ho, Y. K. T.; Okuda, Y.; Wijaya, C. K.; Tan, Z. H.;
Yoshikai, N. Cobalt-Catalyzed Hydroacylative Dimerization of Allenes
Leading to Skipped Dienes. Org. Lett. 2019, 21, 6173−6178.
(b) Yatabe, T.; Mizuno, N.; Yamaguchi, K. Transition-Metal-Free
Catalytic Formal Hydroacylation of Terminal Alkynes. ACS Catal.
2018, 8, 11564−11569. (c) Kim, J.; Yi, C. S. Intermolecular
Markovnikov-Selective Hydroacylation of Olefins Catalyzed by a
Cationic Ruthenium−Hydride Complex. ACS Catal. 2016, 6, 3336−
3339. (d) Xiao, L.-J.; Fu, X.-N.; Zhou, M.-J.; Xie, J.-H.; Wang, L.-X.;
Xu, X.-F.; Zhou, Q.-L. Nickel-Catalyzed Hydroacylation of Styrenes
with Simple Aldehydes: Reaction Development and Mechanistic
Insights. J. Am. Chem. Soc. 2016, 138, 2957−2960. (e) Chen, Q.-A.;
Cruz, F. A.; Dong, V. M. Alkyne Hydroacylation: Switching
Regioselectivity by Tandem Ruthenium Catalysis. J. Am. Chem. Soc.
2015, 137, 3157−3160. (f) Chen, Q. A.; Kim, D. K.; Dong, V. M.
(13) (a) Hooper, J. F.; Seo, S.; Truscott, F. R.; Neuhaus, J. D.; Willis,
M. C. alpha-Amino Aldehydes as Readily Available Chiral Aldehydes
for Rh-Catalyzed Alkyne Hydroacylation. J. Am. Chem. Soc. 2016, 138,
1630−1634. (b) Chaplin, A. B.; Hooper, J. F.; Weller, A. S.; Willis, M.
6096
https://doi.org/10.1021/acscatal.1c01722
ACS Catal. 2021, 11, 6091−6098

ACS Catalysis
pubs.acs.org/acscatalysis
Letter
C. Intermolecular Hydroacylation: High Activity Rhodium Catalysts
Containing Small-Bite-Angle Diphosphine Ligands. J. Am. Chem. Soc.
2012, 134, 4885−4897. (c) Pawley, R. J.; Moxham, G. L.; Dallanegra,
R.; Chaplin, A. B.; Brayshaw, S. K.; Weller, A. S.; Willis, M. C.
Controlling Selectivity in Intermolecular Alkene or Aldehyde
Hydroacylation Reactions Catalyzed by {Rh(L-2)}(+) Fragments.
Organometallics 2010, 29, 1717−1728. (d) Willis, M. C.; Woodward,
R. L. Rhodium-catalyzed reductive aldol reactions using aldehydes as
the stoichiometric reductants. J. Am. Chem. Soc. 2005, 127, 18012−
18013 For an intramoleculer example, see:. (e) Bendorf, H. D.;
Colella, C. M.; Dixon, E. C.; Marchetti, M.; Matukonis, A. N.;
Musselman, J. D.; Tiley, T. A. Chelation-assisted intramolecular
hydroacylation: synthesis of medium ring sulfur heterocycles.
Tetrahedron Lett. 2002, 43, 7031−7034.
(14) (a) Murphy, S. K.; Bruch, A.; Dong, V. M. Mechanistic insights
into hydroacylation with non-chelating aldehydes. Chem. Sci. 2015, 6,
174−180. (b) Murphy, S. K.; Bruch, A.; Dong, V. M. Substrate-
directed hydroacylation: Rhodium-catalyzed coupling of vinylphenols
and nonchelating aldehydes. Angew. Chem., Int. Ed. 2014, 53, 2455−
2459.
(19) Bouisseau, A.; Glancy, J.; Willis, M. C. Two-Component
Assembly of Thiochroman-4-ones and Tetrahydrothiopyran-4-ones
Using a Rhodium-Catalyzed Alkyne Hydroacylation/Thio-Conjugate-
Addition Sequence. Org. Lett. 2016, 18, 5676−5679.
(20) Bouisseau, A.; Gao, M.; Willis, M. C. Traceless Rhodium-
Catalyzed Hydroacylation Using Alkyl Aldehydes: The Enantiose-
lective Synthesis of beta-Aryl Ketones. Chem. - Eur. J. 2016, 22,
15624−15628.
(21) (a) Hooper, J. F.; Young, R. D.; Pernik, I.; Weller, A. S.; Willis,
M. C. Carbon-carbon bond construction using boronic acids and aryl
methyl sulfides: orthogonal reactivity in Suzuki-type couplings. Chem.
Sci. 2013, 4, 1568−1572. (b) Hooper, J. F.; Young, R. D.; Weller, A.
S.; Willis, M. C. Traceless Chelation-Controlled Rhodium-Catalyzed
Intermolecular Alkene and Alkyne Hydroacylation. Chem. - Eur. J.
2013, 19, 3125−3130. (c) Hooper, J. F.; Chaplin, A. B.; Gonzalez-
Rodriguez, C.; Thompson, A. L.; Weller, A. S.; Willis, M. C. Aryl
Methyl Sulfides as Substrates for Rhodium-Catalyzed Alkyne
Carbothiolation: Arene Functionalization with Activating Group
Recycling. J. Am. Chem. Soc. 2012, 134, 2906−2909.
(22) Jun, C.-H.; Hong, J.-B.; Kim, Y.-H.; Chung, K.-Y. The Catalytic
Alkylation of Aromatic Imines by Wilkinson’s Complex: The Domino
Reaction of Hydroacylation and ortho-Alkylation. Angew. Chem., Int.
Ed. 2000, 39, 3440−3442.
(23) (a) Suleymanov, A. A.; Severin, K. Vinyl and Alkynyl Triazenes:
Synthesis, Reactivity, and Applications. Angew. Chem., Int. Ed. 2021,
60, 6879−6889. (b) Bräse, S. The Virtue of the Multifunctional
Triazene Linkers in the Efficient Solid-Phase Synthesis of Heterocycle
Libraries. Acc. Chem. Res. 2004, 37, 805−816. (c) Kimball, D. B.;
Haley, M. M. Triazenes: A Versatile Tool in Organic Synthesis.
Angew. Chem., Int. Ed. 2002, 41, 3338−3351.
(24) (a) Wang, C.; Chen, H.; Wang, Z.; Chen, J.; Huang, Y.
Rhodium(III)-catalyzed C-H activation of arenes using a versatile and
removable triazene directing group. Angew. Chem., Int. Ed. 2012, 51,
7242−7245. (b) Wang, C.; Sun, H.; Fang, Y.; Huang, Y. General and
efficient synthesis of indoles through triazene-directed C-H
annulation. Angew. Chem., Int. Ed. 2013, 52, 5795−5798. (c) Sun,
H.; Wang, C.; Yang, Y. F.; Chen, P.; Wu, Y. D.; Zhang, X.; Huang, Y.
Synthesis of indolo[2,1-a]isoquinolines via a triazene-directed C-H
annulation cascade. J. Org. Chem. 2014, 79, 11863−11872. (d) Wang,
D.; Cui, S. Rh(III)-catalyzed aromatic C−H bond carbenoid
functionalization oftriazenes by α-diazomalonate. Tetrahedron 2016,
72, 2725−2730.
(25) Ando, S.; Burrows, J.; Koide, K. Synthesis of Violaceic Acid and
Related Compounds through Aryl Triazene. Org. Lett. 2017, 19,
1116−1119.
(26) Tan, J. F.; Bormann, C. T.; Perrin, F. G.; Chadwick, F. M.;
Severin, K.; Cramer, N. Divergent Synthesis of Densely Substituted
Arenes and Pyridines via Cyclotrimerization Reactions of Alkynyl
Triazenes. J. Am. Chem. Soc. 2019, 141, 10372−10383.
(27) (a) Nilova, A.; Campeau, L. C.; Sherer, E. C.; Stuart, D. R.
Analysis of Benzenoid Substitution Patterns in Small Molecule Active
Pharmaceutical Ingredients. J. Med. Chem. 2020, 63, 13389−13396.
(b) Taylor, R. D.; MacCoss, M.; Lawson, A. D. Rings in drugs. J. Med.
Chem. 2014, 57, 5845−5859.
(28) Hafner, A.; Brase, S. Ortho-trifluoromethylation of function-
alized aromatic triazenes. Angew. Chem., Int. Ed. 2012, 51, 3713−
3715.
(29) Reingruber, R.; Vanderheiden, S.; Wagner, A.; Nieger, M.;
Muller, T.; Es-Sayed, M.; Bräse, S. 1-Aryl-3,3-diisopropyltriazenes: An
Easily Accessible and Particularly Stable Class of Triazenes Towards
Strong Basic and Lewis Acid Conditions. Eur. J. Org. Chem. 2008,
2008, 3314−3327.
(30) Lormann, M.; Dahmen, S.; Bräse, S. Hydro-dediazoniation of
diazonium salts using trichlorosilane: new cleavage conditions for the
T1 traceless linker1. Tetrahedron Lett. 2000, 41, 3813−3816.
(31) (a) Galli, C. Radical reactions of arenediazonium ions: An easy
entry into the chemistry of the aryl radical. Chem. Rev. 1988, 88, 765−
792. (b) Zollinger, H. Nitrogen as Leaving Group: Dediazoniations of
(15) (a) Gonzalez-Rodriguez, C.; Pawley, R. J.; Chaplin, A. B.;
Thompson, A. L.; Weller, A. S.; Willis, M. C. Rhodium-Catalyzed
Branched-Selective Alkyne Hydroacylation: A Ligand-Controlled
Regioselectivity Switch. Angew. Chem., Int. Ed. 2011, 50, 5134−
5138. (b) Zhang, H.-J.; Bolm, C. Highly Regioselective Intermolecular
Hydroacylations of Enamides with Salicylaldehydes. Org. Lett. 2011,
13, 3900−3903. (c) Murphy, S. K.; Coulter, M. M.; Dong, V. M. β-
hydroxy ketones prepared by regioselective hydroacylation. Chem. Sci.
2012, 3, 355−358.
(16) Murphy, S. K.; Dong, V. M. Enantioselective hydroacylation of
olefins with rhodium catalysts. Chem. Commun. 2014, 50, 13645−
13649.
(17) (a) Phan, D. H. T.; Kou, K. G. M.; Dong, V. M.
Enantioselective Desymmetrization of Cyclopropenes by Hydro-
acylation. J. Am. Chem. Soc. 2010, 132, 16354−16355. (b) Osborne, J.
D.; Randell-Sly, H. E.; Currie, G. S.; Cowley, A. R.; Willis, M. C.
Catalytic Enantioselective Intermolecular Hydroacylation: Rhodium-
Catalyzed Combination of beta-S-Aldehydes and 1,3-Disubstituted
Allenes. J. Am. Chem. Soc. 2008, 130, 17232−17233. (c) Gonzalez-
Rodriguez, C.; Parsons, S. R.; Thompson, A. L.; Willis, M. C.
Rhodium-Catalysed Intermolecular Alkyne Hydroacylation: The
Enantioselective Synthesis of alpha- and beta-Substituted Ketones
by Kinetic Resolution. Chem. - Eur. J. 2010, 16, 10950−10954.
(18) (a) Straker, R. N.; Majhail, M. K.; Willis, M. C. Exploiting
rhodium-catalysed ynamide hydroacylation as a platform for divergent
heterocycle synthesis. Chem. Sci. 2017, 8, 7963−7968. (b) Gao, M.;
Willis, M. C. Enantioselective Three-Component Assembly of beta’-
Aryl Enones Using a Rhodium-Catalyzed Alkyne Hydroacylation/Aryl
Boronic Acid Conjugate Addition Sequence. Org. Lett. 2017, 19,
2734−2737. (c) Fernández, M.; Castaing, M.; Willis, M. C. Sequential
catalysis: exploiting a single rhodium(i) catalyst to promote an alkyne
hydroacylation−aryl boronic acid conjugate addition sequence. Chem.
Sci. 2017, 8, 536−540. (d) Majhail, M. K.; Ylioja, P. M.; Willis, M. C.
Direct Synthesis of Highly Substituted Pyrroles and Dihydropyrroles
Using Linear Selective Hydroacylation Reactions. Chem. - Eur. J.
2016, 22, 7879−7884. (e) Neuhaus, J. D.; Morrow, S. M.; Brunavs,
M.; Willis, M. C. Diversely Substituted Quinolines via Rhodium-
Catalyzed Alkyne Hydroacylation. Org. Lett. 2016, 18, 1562−1565.
(f) Du, X. W.; Stanley, L. M. Tandem Alkyne Hydroacylation and
Oxo-Michael Addition: Diastereoselective Synthesis of 2,3-Disub-
stituted Chroman-4-ones and Fluorinated Derivatives. Org. Lett. 2015,
17, 3276−3279. (g) von Delius, M.; Le, C. M.; Dong, V. M.
Rhodium-Phosphoramidite Catalyzed Alkene Hydroacylation: Mech-
anism and Octaketide Natural Product Synthesis. J. Am. Chem. Soc.
2012, 134, 15022−15032. (h) Lenden, P.; Entwistle, D. A.; Willis, M.
C. An Alkyne Hydroacylation Route to Highly Substituted Furans.
Angew. Chem., Int. Ed. 2011, 50, 10657−10660. (i) Willis, M. C.;
Sapmaz, S. Intermolecular hydroacylation of acrylate esters: a new
route to 1,4-dicarbonyls. Chem. Commun. 2001, 2558−2559.
6097
https://doi.org/10.1021/acscatal.1c01722
ACS Catal. 2021, 11, 6091−6098

ACS Catalysis
pubs.acs.org/acscatalysis
Letter
Aromatic Diazonium Ions. Angew. Chem., Int. Ed. Engl. 1978, 17,
141−150.
(32) Wang, M.; Zhang, Y.; Wang, T.; Wang, C.; Xue, D.; Xiao, J.
Story of an Age-Old Reagent: An Electrophilic Chlorination of Arenes
and Heterocycles by 1-Chloro-1,2-benziodoxol-3-one. Org. Lett. 2016,
18, 1976−1979.
(33) (a) Schroder, N.; Wencel-Delord, J.; Glorius, F. High-yielding,
versatile, and practical [Rh(III)Cp*]-catalyzed ortho bromination and
iodination of arenes. J. Am. Chem. Soc. 2012, 134, 8298−8301.
(b) Yang, L.; Lu, Z.; Stahl, S. S. Regioselective copper-catalyzed
chlorination and bromination of arenes with O2 as the oxidant. Chem.
Commun. 2009, 6460−6462. (c) Kalyani, D.; Dick, A. R.; Anani, W.
Q.; Sanford, M. S. A Simple Catalytic Method for the Regioselective
Halogenation of Arenes. Org. Lett. 2006, 8, 2523−2526.
(34) Feng, Z.; Xiao, Y.-L.; Zhang, X. Copper-catalyzed cross-
coupling of bromozinc-difluoromethylphosphonate with iodo/bromo-
aryl triazenes. Org. Chem. Front. 2014, 1, 113−116.
(35) Vanderheiden, S.; Bulat, B.; Zevaco, T.; Jung, N.; Bräse, S. Solid
phase synthesis of selectively deuterated arenes. Chem. Commun.
2011, 47, 9063−9065.
6098
https://doi.org/10.1021/acscatal.1c01722
ACS Catal. 2021, 11, 6091−6098
