Efficient Method for the Synthesis of Michael
Adducts Using Kaolin Preloaded with KOH
G. Srihari and M. Marthanda Murthy
Organic Chemistry Division II, Indian Institute of Chemical Technology,
Hyderabad, India
Abstract: Michael addition of various active methylene compounds to
b-nitrostyrenes is efficiently catalyzed by using Kaolin preloaded with KOH in
acetonitrile at room temperature with moderate to good yields.
Keywords: Active methylene compounds, kaolin=KOH, Michael reaction,
nitrostyrenes
INTRODUCTION
Michael addition products have a wide range of applications in synthetic
organic chemistry. In particular, Michael addition of active methylene
compounds to nitro styrenes afforded nitro alkanes. The nitro group is
converting into different functionalities[1] such as Nef reaction, Meyer
reaction, reduction to amino group, and conversion into the nitrile oxide
for 1,3-dipolar cycloaddition reactions. These nitrogen-containing com-
pounds are much more useful in pharmaceutical and agrochemical
sectors.[2] The Michael reactions have numerous applications in the elegant
synthesis of fine chemicals and are classically catalyzed by bases or suitable
combinations of amines and carboxylic or Lewis acids under homogeneous
conditions. The employment of these bases in the reactions encounters
environmental problems. There has been increasing attention on the design
and use of environmentally compatible solid base catalysts.[3]
Received June 23, 2008.
Address correspondence to M. Marthanda Murthy, Organic Chemistry
Division II, IICT, Tarnaka 500007, India. E-mail: marthanda52@yahoo.com
896

Michael Addition Reaction
897
Different groups reported the Michael addition under homogeneous
conditions, like AgoTf-PPh3 complex in water[4] and polymer-anchored
metal catalyst in different solvents,[5] and workup procedures are typical
in homogeneous medium. Nowadays, heterogeneous catalyst plays an
important role in various organic transformations. Recently the Michael
[6]
reaction was reported by using acidic Al2O3 and different chiral
catalysts.[7]
There are several advantages of engaging a supported reagent in
organic synthesis. They offer remarkable ease of handling and use.
Alumina, silica, and aluminosilicates (clays and zeolites) are some of
the most widely employed supports, where surface hydroxyl groups play
a major role in these reactions. Surface acidity of clays can be reduced
substantially by introducing inorganic bases such as NaOH and KOH.
These modified clays are highly basic and can be employed for base-
catalyzed reactions. Recent years have witnessed a phenomenal growth
in the use of high-surface-area inorganic solids as reaction media for
organic transformations.[8]
In our ongoing research on heterogeneous systems, we found that
Kaolin preloaded with potassium hydroxide (KOH)[9] is an efficient cat-
alyst for Michael reactions in acetonitrile. This method is very simple,
efficient, and suitable for large-scale operations.
RESULTS AND DISCUSSIONS
In general, the reaction has been carried by taking the two components
(nitrostyrenes and active methylene compound in acetonitrile) and
adding a catalytic amount of Kaolin=KOH. The mixture was stirred at
room temperature (Scheme 1), which afforded the corresponding Michael
adducts in moderate to good yields.
Scheme 1. Synthesis of Michael adducts.

898
G. Srihari and M. M. Murthy
Entry a was taken as a representative example for comparing
reaction rates in various solvents such as dichloromethane (DCM),
acetonitrile (CH3CN), N,N-dimethyl formamide (DMF), dimethylsulfoxide
(DMSO), methanol (MeOH), and water. No product formation was
observed in DCM, DMF, DMSO, and water even under reflux condi-
tions. The reaction progressed smoothly in the case of methanol and acet-
onitrile, and better yields were observed in acetonitrile. After optimizing
the condition, we next applied the generality of addition of various
nitrostyrens to active methylene compounds and results obtained are
listed in Table 1. The products obtained are diastereomers (1:1 mixture)
in the case of ethyl acetoacetate and ethyl benzoylacetate, whereas in the
case of malanonitrile the products are racemic.
We screened various nitrostyrenes with malanonitrile, ethyl acetoace-
tate, and ethyl benzoylacetate. Electron-donating groups on aryl nitrostyr-
enes take longer than unsubstituted nitrostyrenes. The products were
identified by spectroscopy [1H NMR, infrared (IR), and mass spectroscopy
(MS)] or otherwise compared with known compounds. The procedure
described in this article was found to be more effective than those described
in earlier reports.
CONCLUSION
In conclusion, we have developed a simple, convenient, and practical method
for the synthesis of Michael adducts by using Kaolin preloaded with KOH.
EXPERIMENTAL
General Procedure for Synthesis of Michael Adducts
A mixture of nitro styrenes (1 mmol), active methylene compounds
(1.2 mmol), and a catalytic amount of Kaolin=KOH taken in acetonitrile
(2 mL) was stirred at room temperature for the appropriate time as men-
tioned in Table 1. The reaction was monitored by thin-layer chromato-
graphy (TLC). The product was filtered, and the crude product was
purified by column chromatography.
General Procedure for the Preparation of Solid Support Preloaded
with Base
Kaolin clay (3 g) was added to 4 ml of 25% KOH solution, and the mix-
ture was sonicated for a period of 4 h, then dried in a rotary evaporator

Michael Addition Reaction
899
Table 1. Conjugate addition of active methylene compounds to nitrostyrenes
Nitro styrene
R
Active methylene
compound
Entry
a
Producta Time (h) Yieldb (%)
1
3a
2.5
79
b
c
1
1
1
3b
3c
3d
4.0
3.2
3.8
82
80
80
d
e
f
1
3e
4f
3.0
2.6
77
82
2a
g
2a
2a
4g
4h
2.8
3.5
81
77
h
i
j
2a
2a
4i
4j
3.3
3.0
85
76
(Continued )

900
G. Srihari and M. M. Murthy
Table 1. Continued
Nitro styrene
R
Active methylene
compound
Entry
k
Producta Time (h) Yieldb (%)
2a
4k
3.2
68
l
2b
4l
2.0
73
m
n
2b
2b
4m
4n
2.5
3.0
71
70
1
aAll products were characterized by IR, H NMR, and mass spectroscopy.
bUnoptimized, isolated yields.
for several hours (obtaining solid support with suitable residual water).
Residual traces of water were removed from the support by irradiating
with microwaves for 15 min. The solid was ground to a powder. The solid
support thus prepared contains about 6 mmol of KOH per gram.
Spectral Data of Compounds
Compound 3a
Viscous oil. IR (KBr): 2930, 2225, 1610, 1560, 1455; 1H NMR (200 MHz,
CDCl3): d ¼ 7.49–7.30 (m, 5H), 4.98–4.88 (m, 2H), 4.40 (d, 1H), 4.10–4.02
(m, 1H); ESI-MS: 215 ([M]þ).

Michael Addition Reaction
901
Compound 3b
Viscous oil. IR (KBr): 2919, 2228, 1611, 1557, 1514, 1256, 1181; 1H NMR
(300 MHz, CDCl3): d ¼ 7.25–6.90 (m, 4H), 4.95–4.75 (m, 2H), 4.35 (d,
1H), 4.05–3.98 (m, 1H), 3.82 (s, 3H); ESI-MS: 245 ([M]þ).
Compound 3c
1
Solid. Mp 99–101 ꢀC; IR (KBr): 2921, 2253, 1611, 1555, 1514, 1435; H
NMR (300 MHz, CDCl3): d ¼ 7.30–7.20 (m, 4H), 5.01–4.80 (m, 2H),
4.38 (d, 1H), 4.05–3.95 (m, 1H), 2.40 (s, 3H); ESI-MS: 229 ([M]þ).
Compound 3d
Solid. Mp 95–97 ꢀC; IR (KBr): 2919, 2257, 1604, 1556, 1495, 1436, 1252;
1H NMR (300 MHz, CDCl3): d ¼ 7.45–7.40 (m, 1H), 7.28–7.20 (m, 1H),
7.09–6.95 (m, 2H); ESI-MS: 245 ([M]þ).
Compound 3e

902
G. Srihari and M. M. Murthy
1
Solid. Mp 115–117 ꢀC; IR (KBr): 2923, 2202, 1645, 1554, 1410, 1376; H
NMR (200 MHz, CDCl3): d ¼ 7.40–7.01 (m, 3H), 4.95–480 (m, 2H), 4.55–
4.40 (m, 2H); ESI-MS: 244 ([M þ Na]þ).
Compound 4f
1
Solid. Mp 93–94 ꢀC; IR (KBr): 2925, 1736, 1632, 1562, 1493, 1381; H
NMR (300 MHz, CDCl3): d ¼ 7.30–7.20 (m, 3H), 7.18–7.12 (m, 2H),
4.78–4.68 (m, 2H), 4.25–4.09 (m, 2.5H), 3.90–4.01 (m, 1.5H), 2.30 (s,
1.5H), 2.04 (s, 1.5H), 1.28 (t, 1.5H), 1.01 (t, 1.5H); ESI-MS: 279 ([M]þ).
Compound 4g
Viscous oil. IR (KBr): 2922, 1739, 1718, 1556, 1374; 1H NMR (200 MHz,
CDCl3): d ¼ 7.35 (s, 1H), 6.28 (s, 1H), 6.18 (d, 1H), 4.81–4.68 (m, 2H),
4.38–4.02 (m, 4H), 2.30 (s, 1.5H), 2.15 (s, 1.5H), 1.28 (t, 1.5H), 1.18 (t,
1.5H); ESI-MS: 269 ([M]þ).
Compound 4h
1
Viscous oil. IR (KBr): 2980, 1741, 1717, 1611, 1555, 1514; H NMR
(300 MHz, CDCl3): d ¼ 7.09 (d, 2H), 6.78 (d, 2H), 4.77–4.63 (m, 2H),

Michael Addition Reaction
903
4.25–3.90 (m, 4H), 3.75 (s, 3H), 2.28 (s, 1.5H), 2.05 (s, 1.5H), 1.25 (t,
1.5H), 1.05 (t, 1.5H); ESI-MS: 309 ([M]þ).
Compound 4i
Viscous oil. IR (KBr): 2983, 1739, 1717, 1554, 1375; 1H NMR (200 MHz,
CDCl3): d ¼ 7.15–7.02 (m, 4H), 4.76–4.64 (m, 2H), 4.25–3.95 (m, 4H),
2.32 (s, 3H), 2.26 (s, 1.5H), 2.02 (s, 1.5H), 1.25 (t, 1.5H), 1.05 (t, 1.5H);
ESI-MS: 316 ([M þ Na]þ).
Compound 4j
Solid. Mp 107–108 ꢀC; IR (KBr): 2924, 1738, 1561, 1375; 1H NMR
(200 MHz, CDCl3): d ¼ 7.85–7.67 (m, 4H), 7.53–7.42 (m, 2H), 7.35–7.27
(m, 1H), 4.92–4.81 (m, 2H), 4.40–4.31 (m, 3H), 3.98–3.89 (m, 1H), 2.30 (s,
1.5H), 2.07 (s, 1.5H), 1.28 (t, 1.5H), 0.91 (t, 1.5H); ESI-MS: 352 ([M þ Na]þ).
Compound 4k
Viscous oil. IR (KBr): 2981, 1717, 1597, 1553; 1H NMR (300 MHz,
CDCl3): d ¼ 7.29–7.19 (m, 1H), 7.15–7.01 (m, 1H), 6.91–6.84 (m, 2H),

904
G. Srihari and M. M. Murthy
4.95– 4.69 (m, 2H), 4.35– 4.19 (m, 4H), 3.90 (s, 1.5H), 3.85 (s, 1.5H), 2.30
(s, 1.5H), 2.02 (s, 1.5H), 1.28 (t, 1.5H), 0.98 (t, 1.5H), ESI-MS: 309
([M]þ).
Compound 4l
1
Solid. Mp 79–80 ꢀC; IR (KBr): 2924, 1726, 1686, 1597, 1551; H NMR
(200 MHz, CDCl3): d ¼ 8.05–7.89 (m, 2H), 7.61–7.45 (m, 4H), 7.31–7.18
(m, 4H), 4.95–4.88 (m, 2H), 4.76 (d, 1H), 4.50–4.38 (m, 1H), 4.20–4.06 (q,
1H), 3.90–3.79 (q, 1H), 1.21 (t, 1.5H), 0.92 (t, 1.5H); ESI-MS: 341 ([M]þ).
Compound 4m
Viscous oil. IR (KBr): 2923, 1735, 1685, 1555; 1H NMR (200MHz, CDCl3):
d ¼ 8.08–7.95 (m, 2H), 7.65–7.35 (m, 4H), 6.30–6.09 (m, 2H), 5.05–4.85 (m,
2H), 4.80–4.75 (m, 1H), 4.60–4.48 (m, 1H), 4.20–4.11 (q, 1H), 4.08–3.95 (q,
1H), 1.18 (t, 1.5H), 1.07 (t, 1.5H); ESI-MS: 354 ([M þ Na]þ).
Compound 4n
Viscous oil. IR (KBr): 2924, 1735, 1684, 1611, 1553; 1H NMR (200 MHz,
CDCl3): d ¼ 8.07–7.98 (m, 1H), 7.86–7.78 (m, 1H), 7.65–7.40 (m, 3H),

Michael Addition Reaction
905
7.20–7.08 (m, 2H), 6.85–6.70 (m, 2H), 4.90–4.82 (m, 2H), 4.75–4.68 (m,
1H), 4.40–4.30 (m, 1H), 4.20– 4.10 (q, 1H), 3.95–3.82 (q, 1H), 3.75 (s,
1.5H), 3.68 (s, 1.5H), 1.19 (s, 1.5H), 0.92 (s, 1.5H); ESI-MS: 394 ([M]þ).
ACKNOWLEDGMENT
We thank Dr. J. S. Yadav (director) and Dr. V. V. N. Reddy (head of
department) of the Indian Institute of Chemical Technology, Hyderabad,
for constant encouragement and financial support.
REFERENCES
1. (a) Ballini, R.; Petrini, M. Recent synthetic developments in the nitro to
carbonyl conversion. Tetrahedron 2004, 60, 1017; (b) Tamura, R.; Kamimura,
A.; Ono, N. Displacement of aliphatic nitro groups by carbon and heteroatom
nucleophiles. Synthesis 1991, 423; (c) Poupart, M. A.; Fazal, G.; Goulet, S.;
Mar, L. T. Solid phase synthesis of peptidyl trifluoromethyl ketone. J. Org.
Chem. 1999, 64, 1356; d) Kamlet, M. J.; Kaplan, L. A.; Dacons, J. C. Reac-
tions of polynitroalkanes with hot mineral acids. J. Org. Chem. 1961, 26,
4371; (e) Mukayama, T.; Hoshino, T. The Reactions of primary nitro paraffins
with isocyanates. J. Am. Chem. Soc. 1960, 82, 5339.
2. (a) Barnes, D. M.; Ji, J. G.; Fickes, M. G.; Fitzgerald, M. A.; King, S. A.;
Morton, H. E.; Plagge, F. A.; Preskill, M.; Wagaw, S. H.; Wittenberger, S.
J.; Zhang, J. Development of a catalytic enantioselective conjugate addition
of 1,3-dicarbonyl compounds to nitroalkenes for the synthesis of endothelin-
A antagonist ABT-546: Scope, mechanism, and further application to the
synthesis of the antidepressant rolipram. J. Am. Chem. Soc. 2002, 124,
13097; (b) Hoashi, Y.; Yabuta, T.; Takemoto, Y. Bifunctional thiourea-
catalyzed enantioselective double Michael reaction of c,d-unsaturated
b-ketoesters to nitroalkanes: Asymmetric synthesis of (ꢁ)-epibatidine.
Tetrahedron Lett. 2004, 45, 9185.
3. Choudary, B. M.; Lakshmi Kantam, M.; Kavita, B.; Venkat Reddy, C.;
Figueras, F. Catalytic C-C bond formation promototed by Mg-Al-O-tBu
hydrotalcite. Tetrahedron 2000, 56, 9357.
4. Shirakava, S.; Kobayashi, S. Ag(I)-catalyzed Michael additions of b-ketoesters
to nitroalkenes in water: Remarkable effect of water as a reaction medium on
reaction rates. Synlett 2006, 1410.
5. Fei, C. P.; Chan, T. H.; Chan, T. H. Michael reaction catalysed by polymer-
anchored metal acetylacetonates. Synthesis 1982, 467.
6. Ballini, R.; Maggi, R.; Palmieri, A.; Sartori, G. Acidic alumina as a useful het-
erogeneous catalyst in the Michael reaction of b-dicarbonyl derivatives with
conjugated nitroalkenes. Synthesis 2007, 3017.
7. (a) Chen, F.; Shao, C.; Wang, Q.; Gong, P.; Zhang, D.; Zhang, B.; Wang, R.
An enantioselective Michael addition of malonate to nitroalkenes catalyzed by

906
G. Srihari and M. M. Murthy
low loading demethylquinine salts in water. Tetrahedron Lett. 2007, 48, 8456;
(b) Okino, T.; Hoashi, Y.; Furukawa, T.; Xu, X.; Takemoto, Y. Enantio- and
diastereoselective Michael reaction of 1,3-dicarbonyl compounds to nitroole-
fins catalyzed by a bifunctional thiourea. J. Am. Chem. Soc. 2005, 127, 119;
(c) Kotrusz, P.; Toma, S.; Schmalz, H. G.; Adler, A. Michael additions of alde-
hydes and ketones to b-Nitrostyrenes in an ionic liquid. Eur. J. Org. Chem.
2004, 1577.
8. Varma, R. S. Clay and clay-supported reagents in organic synthesis. Tetrahe-
dron 2002, 58, 1235.
9. (a) Yu, H.; Koshima, H. A convenient method for asymmetric alkylation of
glycine imine esters using solid supports. Tetrahedron Lett. 2003, 44, 9209;
(b) Yu, H.; Takigawa, S.; Koshima, H. Asymmetric alkylation of glycineimine
esters using solid supports preloaded with base. Tetrahedron 2004, 60, 8405.
