Communication
3g, in comparable yields. Strangely, there is no obvious steric
hindrance observed in this investigation (3b, 3h, and 3i vs.
3k). It is worth noting that hydroxyl group (HO) within a-keto
acid had little effect on the decarboxylative annulation, and
a moderate yield of 3j was achieved. Moreover, this reaction
was not limited to a-keto acids with phenyl groups. For exam-
ple, the reaction of 2-(naphthalen-1-yl)-2-oxoacetic acid and 2-
oxo-2-(thiophen-2-yl)acetic acid with 1,2-diphenylethyne still
produced the corresponding product 3l in 68% yield, and 3m
in 51% yield, respectively. Next, a number of symmetric inter-
nal alkynes were synthesized and tested in the above decar-
boxylative annulation. 1,2-Diarylethynes with Me and F at the
4,4’- or 3,3’-position of phenyl ring gave good yields of desired
products (3n, 3o, 3q and 3r), with the exception of Cl with
which a lower yield of 3p was obtained. Further investigation
regarding the reaction of oct-4-yne with 2-oxo-2-phenylacetic
acid was performed under similar conditions, and 3s was ob-
tained in 56% isolated yield. Gratifyingly, hex-3-yne could react
with 2-oxo-2-phenylacetic acid to produce 3t in higher yield.
As expected, several mono- or disubstituted phenylglyoxylic
acids were effective in this decarboxylative annulation and
generated the desired products (3u–3z) in moderate to good
yields (62–77%).
Scheme 5. Proposal reaction mechanism.
sults indicate that only a carboxyl or carbonyl group within the
substrate cannot start the annulation. In contrast, co-existence
of carboxyl group and carbonyl group within the a-keto acid is
beneficial to the occurrence of decarboxylative annulation. Ad-
ditionally, CO2 release from the catalytic system was clearly ob-
served by FT-IR (Figure S1 in the Supporting Information).
Hence, the COOH group within the a-keto acid might serve as
an effective directing group and leaving group in the Ru-cata-
lyzed decarboxylative annulation.
In order to determine the role of the carboxyl group within
a-keto acid, the following control experiments were carried
out under standard conditions, as shown in Scheme 3. It was
found that benzaldehyde or 2-phenylacetic acid did not react
with internal alkyne 2a. When benzoic acid was used as sub-
strate, only 7% yield of 3a was obtained. Compared with the
former substrates, 2-oxo-2-phenylacetic acid with 2a had high
activity and product 3a was isolated in 69% yield. These re-
In order to probe the possible mechanism, an intermolecular
competition experiment between proton and deuteron 1a
was performed under optimized conditions, and the KIE value
of 4.0 showed that CÀH bond cleavage might be involved in
the rate-limiting step [Scheme 4, Eq. (1)]. In addition, the Ru-
catalyzed decarboxylative annulation of 1a with a-keto acid
2a was carried out under an isotope-labeled oxygen (18O2) at-
mosphere. A significant molecular ion peak for product 3a
containing 18O was observed by HRMS (in the Supporting In-
formation) which indicated that the oxygen atom in product
3a came from O2 [Scheme 4, Eq. (2)].
According to our experimental results and previous re-
ports,[14] a possible mechanism is outlined in Scheme 5. The ini-
tial anion exchange of [Ru(p-cymene)Cl2]2 with Cu(OAc)2 afford-
ed the complex I, which then reacted with a-keto acid to form
intermediate intermediate II with
Scheme 3. Control experiments. [a] Reaction conditions: A (0.30 mmol), 1,2-
diphenylethyne (2a, 0.20 mmol), [Ru]=[Ru(p-cymene)Cl2]2 (0.01 mmol, con-
taining 5.0 mol% Ru), Cu(OAc)2 (0.20 mmol), PivOH (0.20 mmol), DMF
(0.50 mL) at 1208C in air for 12 h. [b] Isolated yields.
releasing HOAc. The coordina-
tion of internal alkyne 2 with II,
and subsequent migratory inser-
tion produced intermediate III,
which then released CO2 to form
the key intermediate IV with the
assistance of O2 in air.[4e] The
final reductive elimination of IV
led to the formation of prod-
uct 3 and realized the catalytic
Scheme 4. Kinetic isotope effect and oxygen labeling experiment.
cycle.
Chem. Eur. J. 2014, 20, 1 – 5
