PAPER
www.rsc.org/dalton | Dalton Transactions
Solvent induced reactivity of 3,5-dimethylpyrazole towards zinc (II)
carboxylates†
Rupam Sarma, Dipjyoti Kalita and Jubaraj B. Baruah*
Received 19th March 2009, Accepted 15th June 2009
First published as an Advance Article on the web 23rd July 2009
DOI: 10.1039/b905534g
The reactions of 3,5-dimethylpyrazole with zinc(II)acetate dihydrate and varieties of aromatic
carboxylic acids led to formation of mono-nuclear zinc complexes of composition [Zn(HDMP)2-
(RCO2)2] (R = C6H5, p-CH3-C6H4, p-NO2-C6H4 etc. HDMP = 3,5-dimethylpyrazole) in methanol,
whereas the same reactants in dimethylformamide (DMF) gave binuclear 3,5-dimethylpyrazolato
bridged zinc carboxylate complexes containing monodentate 3,5-dimethylpyraozole ligands with
composition [Zn2(m-DMP)2(HDMP)2(RCO2)2]. The mononuclear complexes can be converted to the
corresponding binuclear complexes by simply dissolving in DMF. The reaction of zinc(II)acetate
dihydrate with p-nitrobenzoic acid and 3,5-dimethylpyrazole in different solvents gave solvated
mononuclear complexes of the corresponding solvent. All these solvated complexes having the core
[Zn(HDMP)2(p-NO2-C6H4CO2)2] contain two structurally independent molecules in the
asymmetric unit (Z¢ = 2).
bidentate 3,5-dimethylpyrazolato (DMP) ligand respectively that
are prepared just by changing the solvent condition.
Introduction
Ligands having pyrazole backbone are of interest in the field
of biology and co-ordination chemistry.1 The zinc complexes
containing pyrazole ligands are shown to mimic the biological
activity of carbonic anhydrase.1k,m The pyrazole as a ligand
shows versatility in co-ordination modes towards metals. While,
neutral monodentate pyrazole ligands are common,2 a number of
literatures are available on pyrazole as anionic monodentate and
bridging bidentate ligands.3 The bidentate bridging pyrazolato
ligand is a precursor for preparation of binuclear or polynuclear
Experimental
Synthesis of the complexes
Bis-3,5-dimethylpyrazole bis-benzoato zinc(2+). [Zn(C6H5-
COO)2(HDMP)2] (1):To a solution of benzoic acid (2 mmol,
0.244 g) in methanol (15 mL) Zn(OAc)2.2H2O (1 mmol, 0.219 g)
was added. After stirring this reaction mixture for about 30 min-
utes 3,5-dimethylpyrazole (2 mmol, 0.190 g) was added followed by
addition of toluene (5 mL) and stirred for another 30 minutes. The
reaction mixture was then kept for crystallization and good quality
colorless crystals of 1 were obtained after 3/4 days. Isolated yield
92%. IR (KBr, cm-1): 2927(m), 2850(m), 1614(s), 1553(s), 1481(m),
1448(m), 1385(s),1295(s), 1191(s), 1049(s), 1017(s), 834(s), 720(s),
679(s), 578(s).1H NMR (DMSO-d6, ppm): 7.9 (d, 4H J = 4 Hz),
7.5 (m, 6H), 5.7 (s, 2H), 2.1 (b, 12H). Elemental anal calcd for
C24H26N4O4Zn; C, 57.66, H, 5.24; found C, 58.08, H, 5.29.
metal complexes. Generally, in pyrazolato bridged complexes the
4
˚
metal-metal separations are in the range of 3.0–4.5 A. On the
other hand binuclear complexes having such a critical metal-
metal separation are of interest from their resemblance to the
various active sites of zinc containing enzymes.5 A good number
of literatures are available on pyrazole based ligands that act as
monodentate ligands under ambient conditions.1,3 Recently we
have shown that different types of zinc carboxylate complexes
can be prepared by varying either the solvent or substituent
on the ligands.6 Such structural changes under neutral reaction
conditions is of interest to understand the reactivity of ligand
and leaves enough scope to understand this simple yet important
chemistry in an organized manner to have variation in reactivity.
The deprotonation of N-H in amine containing ligands of zinc
complexes is of special interest for biological mimics and are
studied with great interest.7 Herein, we report the formation of
a number of mononuclear and binuclear zinc(2+) carboxylate
complexes with monodentate 3,5-dimethylpyrazole (HDMP) and
Bis-3,5-dimethylpyrazole di-l-3,5-dimethylpyrazolato bis-ben-
zoato di-zinc(2+). [Zn2(C6H5COO)2(DMP)2(HDMP)2] (2): To
a solution of benzoic acid (2 mmol, 0.244 g) in dimethylfor-
mamide (15 mL) Zn(OAc)2.2H2O (1 mmol, 0.219 g) was added.
After stirring this reaction mixture for about 30 minutes 3,5-
dimethylpyrazole (2 mmol, 0.190 g) was added and stirred for
another 30 minutes. The solution was then kept for crystallization.
Diffraction quality colorless crystals of 2 were obtained after
a week. Isolated yield 78%. IR (KBr, cm-1): 2923(m), 2853(m),
1608(s), 1552(s), 1529(s), 1483(w), 1390(s), 1345(s), 1298(s),
1191(m), 1048(s), 1014(s), 831(m), 721(s), 676(s), 572(s). 1H NMR
(DMSO-d6, ppm): 7.9 (d, 4H, J = 8 Hz), 7.4 (m, 6H), 5.7 (b,
4H), 2.2 (s, 6H), 2.1 (s, 12H), 1.7 (s, 6H). Elemental anal calcd for
C34H40N8O4Zn2; C, 54.05, H, 5.33; found C, 54.15, H, 5.33.
Department of Chemistry, Indian Institute of Technology Guwahati,
Guwahati, 781 039, Assam, India. E-mail: juba@iitg.ernet.in
† Electronic supplementary information (ESI) available: The PXRD
patterns for the complexes 1 and 2 and the UV-spectra of the complexes
3 and 6 are available. CCDC reference numbers 715018–715024. For ESI
and crystallographic data in CIF or other electronic format see DOI:
10.1039/b905534g
7428 | Dalton Trans., 2009, 7428–7436
This journal is
The Royal Society of Chemistry 2009
©

View Article Online
Aqua and ethanol solvate of bis-3,5-dimethylpyrazole bis-
p-methylbenzoato zinc(2+). [Zn(p-CH3-C6H4COO)2(HDMP)2].
H2O.CH3CH2OH (3): The complex 3 was synthesised by the same
procedure as complex 1 only difference being it’s recrystallization
solvent (ethanol). Isolated yield 87%. IR (KBr, cm-1): 3032(m),
2927(m), 2854(m), 1610(s), 1550(s), 1484(m), 1404(m), 1378(s),
1293(s), 1194(s), 1176(s), 1049(s), 1018(s), 847(s), 766(s), 624(s).
1H NMR (DMSO-d6, ppm): 7.8 (d, 4H, J = 8 Hz), 7.2 (d, 4H, J =
8 Hz), 5.8 (s, 2H), 2.3 (s, 6H), 2.1 (s, 12H). Elemental anal calcd
for C28H38N4O6Zn; C, 56.80, H, 6.47; found C, 57.00, H, 6.45.
527(s). 1H NMR (DMSO-d6, ppm): 8.1 (b, 8H), 5.8 (s, 2H), 3.2 (s,
3H), 2.1 (b, 12H). Elemental anal calcd for C25 H26 N6 O9Zn; C,
48.44, H, 4.22; found C, 48.65, H, 4.34.
The mononuclear complexes 6 and 7 were synthesised by the
same procedure as complex 5 only difference being the solvent. In
case of 6 the solvent is acetone whereas in case of 7 the solvent
used is dimethylformamide.
X-ray crystallography
The X-ray crystallographic data were collected at 296 K with Mo
Ka radiation (l = 0.71073 A◦) using a Bruker Nonius SMART
CCD diffractometer equipped with a graphite monochromator.
The SMART software was used for data collection and also for
indexing the reflections and determining the unit cell parameters;
the collected data were integrated using SAINT software.8 The
structures were solved by direct methods and refined by full-
matrix least-squares calculations using SHELXTL software.8 All
the non-H atoms except C49 and C50 of complex 5 were refined
in the anisotropic approximation against F2 of all reflections.
The C49 and C50 of complex 5 are refined isotropically. The
H-atoms, except those attached to N and O were placed at their
calculated positions and refined in the isotropic approximation;
those attached to hetero-atoms (N, O) were located in the
difference Fourier maps, and refined with isotropic displacement
coefficients. However, some of the hydrogen atoms attached to
solvent molecule could not be located for the structures 5 and 7.
The crystallographic parameters are given in Table 1.
Bis-3,5-dimethylpyrazole di-l-3,5-dimethylpyrazolato bis-p-
mehylbenzoato di-zinc(2+). [Zn2(p-CH3-C6H4COO)2(DMP)2-
(HDMP)2] (4): The complex 4 was synthesised by the same
procedure as complex 2. Isolated yield 84%. IR (KBr, cm-1):
2925(m), 2853(m), 1608(s), 1583(s), 1548(s), 1527(m), 1483(w),
1394(s), 1342(s), 1303(s), 1193(m), 1048(s), 1012(s), 846(m),
1
768(s), 694(m), 622(s). H NMR (DMSO-d6, ppm): 7.8 (b, 4H),
7.2 (b, 6H), 5.7 (b, 4H), 2.3 (s, 6H), 2.18 (s, 6H), 2.11 (s, 12H),
1.7 (s, 6H). Elemental anal calcd for C36H44N8O4Zn2; C, 55.18, H,
5.66; found C, 55.32, H, 5.75.
Methanol solvate of bis-3,5-dimethylpyrozle bis-p-nitrobenzoato
zinc(2+). [Zn(p-NO2-C6H4COO)2(HDMP)2].CH3OH (5): The
complex 5 was also synthesised by the same procedure as complex
1. Isolated yield 82%. IR (KBr, cm-1): 2960(m), 2926(m), 2854(m),
1626(s), 1592(s), 1563(s), 1525(m), 1476(w), 1385(s), 1342(s),
1319(w), 1284(m), 1190(s), 1158(s), 1046(s), 821(s), 726(s), 581(s),
