SCHEME 1
PtCl2-Catalyzed Cycloisomerization of 1,6-Enynes
for the Synthesis of Substituted Bicyclo[3.1.0]hexanes
Liu Ye,† Qian Chen,*,† Jiancun Zhang,*,†,‡ and
,§
ꢀ
Veronique Michelet*
†Guangzhou Institutes of Biomedicine and Health, Chinese
Academy of Sciences, International Business Incubator,
Guangzhou Science Park, Guangzhou 510663, P. R. China,
‡State Key Laboratory of Respiratory Diseases, Guangzhou
§
510120, P. R. China, and Laboratoire Charles Friedel, UMR
ꢀ
7223, Ecole Nationale Superieure de Chimie de Paris, 11, rue
P. et M. Curie, 75231 Paris Cedex 05, France
under mild conditions.3 For example, the 5-exo-dig cycliza-
tion of carbon-tethered 1,6-enynes afforded the 1-alkenylcy-
clopentene products II or III via the cyclopropyl metal
carbene intermediates (Scheme 1).4 Depending on the sub-
stituents on the alkene part, the cyclopropyl metal carbene
may undergo a 1,2-alkyl migration or fragmentation steps
leading to dienes II or III, the latter being generally observed
in the case of monosubstituted alkenes.1,4 On the other hand,
the O- or N-tethered 1,6-enynes underwent 6-endo-dig cycli-
zation to generate the metal carbenes, which led to the
corresponding bicyclo[4.1.0]heptenes IV via 1,2-hydride mi-
gration (Scheme 1).5 The difference in these two types of
cyclic products revealed that the presence of a heteroatom in
the tether might facilitate the 1,2-hydride migration of the
cyclopropyl metal carbenes.5
ustc_chenqian@hotmail.com; veronique-michelet@
chimie-paristech.fr
Received October 1, 2009
The mild and efficient PtCl2-catalyzed cycloisomeriza-
tion of 1,6-enynes containing a heteroatom substituent at
the propargylic position is described. The reactions led to
the formation of 1-alkenylbicyclo[3.1.0]hexanes in good
to excellent yields or 2-(bicyclo[3.1.0]hex-1-yl)acetalde-
hydes in moderate yields.
We have been interested in studying the heteroatom effect
when introduced into the cycloisomerization of carbon-
tethered 1,6-enynes. With the above background and keep-
ing in mind some recent reports,6,7 we envisioned that the
(4) (a) Trost, B. M.; Chang, V. K. Synthesis 1993, 824. (b) Chatani, N.;
Furukawa, N.; Sakurai, H.; Murai, S. Organometallics 1996, 15, 901.
(c) Trost, B. M.; Doherty, G. A. J. Am. Chem. Soc. 2000, 122, 3801.
(d) Mezailles, N.; Ricard, L.; Gagosz, F. Org. Lett. 2005, 7, 4133.
ꢀ
~
ꢀ
~
(e) Nieto-Oberhuber, C.; Lopez, S.; Munoz, M. P.; Cardenas, D. J.; Bunuel,
E.; Nevado, C.; Echavarren, A. M. Angew. Chem., Int. Ed. 2005, 44, 6146.
(5) (a) Blum, J.; Beer-Kraft, H.; Badrieh, Y. J. Org. Chem. 1995, 60, 5567.
Transition-metal-catalyzed cycloisomerization reactions
of enynes provide a rapid access to functionalized cyclic
structures.1 Such reactions are perfectly suited to meet the
high demands for atom economy2 in newly developed meth-
ods. It was well documented that the gold and platinum
complexes catalyzed the cycloisomerization reactions of 1,6-
enynes to allow the generation of a variety of cyclic products
€
(b) Furtsner, A.; Szillat, H.; Stelzer, F. J. Am. Chem. Soc. 2000, 122, 6785.
€
(c) Furtsner, A.; Szillat, H.; Stelzer, F. J. Am. Chem. Soc. 2001, 123, 11863.
(d) Nevado, C.; Ferrer, C.; Echavarren, A. M. Org. Lett. 2004, 6, 3191.
~
~
ꢀ
(e) Nieto-Oberhuber, C.; Munoz, M. P.; Bunuel, E.; Nevado, C.; Cardenas,
D. J.; Echavarren, A. M. Angew. Chem., Int. Ed. 2004, 43, 2402. (f) Brissy, D.;
Skander, M.; Retailleau, P.; Marinetti, A. Organometallics 2007, 26, 5782.
(g) Ferrer, C.; Raducan, M.; Nevado, C.; Claverie, C. K.; Echavarren, A. M.
Tetrahedron 2007, 63, 6306. (h) Brissy, D.; Skander, M.; Retailleau, P.;
Frison, G.; Marinetti, A. Organometallics 2009, 28, 140. (i) Brissy, D.;
Skander, M.; Jullien, H.; Retailleau, P.; Marinetti, A. Org. Lett. 2009, 11,
2137. (j) Chao, C.-M.; Beltrami, D.; Toullec, P. Y.; Michelet, V. Chem.
Commun. 2009, 6988.
(1) For selected reviews on metal-catalyzed cycloisomerization reactions,
see: (a) Li, Z.; Brouwer, C.; He, C. Chem. Rev. 2008, 108, 3239. (b) Michelet,
^
V.; Toullec, P. Y.; Genet, J.-P. Angew. Chem., Int. Ed. 2008, 47, 4268.
ꢀ
ꢀ
ꢀ~
(c) Nieto-Oberhuber, C.; Lopez, S.; Jimenez-Nunez, E.; Echavarren, A. M.
Chem.-Eur. J. 2006, 12, 5916. (d) Zhang, L.; Sun, J.; Kozmin, S. A. Adv.
Synth. Catal. 2006, 348, 2271. (e) Diver, S. T.; Giessert, A. J. Chem. Rev.
2004, 104, 1317. (f) Lloyd-Jones, G. C. Org. Biomol. Chem. 2003, 1, 215.
(2) (a) Trost, B. M. Angew. Chem., Int. Ed. 1995, 34, 259. (b) Trost, B. M.
Acc. Chem. Res. 2002, 35, 695.
(6) (a) Toullec, P. Y.; Blarre, T.; Michelet, V. Org. Lett. 2009, 11, 2888.
(b) Horino, Y.; Yamamoto, T.; Ueda, K.; Kuroda, S.; Toste, F. D. J. Am.
Chem. Soc. 2009, 131, 2809. (c) Chao, C.-M.; Vitale, M.; Toullec, P. Y.;
^
Genet, J.-P.; Michelet, V. Chem.;Eur. J. 2009, 15, 1319. (d) Leseurre, L.;
Chao, C.-M.; Seki, T.; Genin, E.; Toullec, P. Y.; Genet, J.-P.; Michelet, V.
^
Tetrahedron 2009, 65, 1911. (e) Lu, L.; Liu, X.-Y.; Shu, X.-Z.; Yang, K.; Ji,
K.-G.; Liang, Y.-M. J. Org. Chem. 2009, 74, 474. (f) Toyofuku, M.;
Fujiwara, S.; Shin-ike, T.; Kuniyasu, H.; Kambe, N. J. Am. Chem. Soc.
2008, 130, 10504. (g) Yeh, M. C. P.; Tsao, W. C.; Cheng, S. T. J. Org. Chem.
ꢀ
(3) For selected reviews on Au and/or Pt catalysis, see: (a) Jimenez-
ꢀ~
Nunez, E.; Echavarren, A. M. Chem. Rev. 2008, 108, 3326. (b) Muzart, J.
ꢀ
Tetrahedron 2008, 64, 5815. (c) Chianese, A. R.; Lee, S. J.; Gagne, M. R.
Angew. Chem., Int. Ed. 2007, 46, 4042. (d) Hashmi, A. S. K. Chem. Rev. 2007,
^
2008, 73, 2902. (h) Toullec, P. Y.; Chao, C.-M.; Chen, Q.; Genet, J.-P.;
€
ꢀ
Michelet, V. Adv. Synth. Catal. 2008, 250, 2401. (i) Barluenga, J.; Fernandez-
107, 3180. (e) Furstner, A.; Davies, P. W. Angew. Chem., Int. Ed. 2007, 46,
ꢀ
3410. (f) Hashmi, A. S. K.; Hutchings, G. J. Angew. Chem., Int. Ed. 2006, 45,
7896. (g) Ma, S.; Yu, S.; Gu, Z. Angew. Chem., Int. Ed. 2006, 45, 200.
(h) Bruneau, C. Angew. Chem., Int. Ed. 2005, 44, 2328. (i) Echavarren, A. M.;
Nevado, C. Chem. Soc. Rev. 2004, 33, 431.
Rodrı
130, 2764. (j) Nieto-Oberhuber, C.; Perez-Galan, P.; Herrero-Gomez, E.;
´
guez, M. A.; Garcıa-Garcıa, P.; Aguilar, E. J. Am. Chem. Soc. 2008,
ꢀ
´
´
ꢀ
ꢀ
ꢀ
Lauterbach, T.; Rodrıguez, C.; Cardenas, D. J.; Echavarren, A. M. J. Am.
´
Chem. Soc. 2008, 130, 269.
9550 J. Org. Chem. 2009, 74, 9550–9553
Published on Web 11/19/2009
DOI: 10.1021/jo902083r
r
2009 American Chemical Society

Ye et al.
JOCNote
SCHEME 2
TABLE 1. Cycloisomerization of 1,6-Enyne 1aa
entry catalyst [cat]
conditions
yieldb (%) ratio Z/Ec
1
2
3
4
5
6
7f
8
9
PPh3AuSbF6 CH2Cl2, rt, 10 min
traced
NR
n/a
n/a
n/a
n/a
2/1
2/1
3/1
2/1
n/a
PPh3AuCl
AgSbF6
PtCl2
PtCl2
PtCl2
PtCl2
PtCl2
PtCl2
CH2Cl2, rt, 12 h
CH2Cl2, rt, 2 h
toluene, rt, 12 h
toluene, 80 °C, 1 h
d
-
NR
99e
toluene, 80 °C, 12 h 88
toluene, 80 °C, 1 h
dioxane, 80 °C, 1 h
PhH, 80 °C, 12 h
96
35g
traceh
aThe reaction of 1a (0.2 mmol) was carried out in the presence of 5 mol
% of catalysts in solvents (2 mL). bYield based on 1a was determined by
1H NMR using an internal standard; NR = no reaction. Ratio was
c
1
d
determined by H NMR; n/a = not applicable. Most of the material
was decomposed. e95% isolated yield. fA stoichiometric amount of
CH3CN was introduced. g85% conversion. h<5% conversion.
SCHEME 3. Murai’s Cycloisomerization Reaction
carbon-tethered 1,6-enyne A with a heteroatom substituent
at the propargylic position might undergo 5-exo-dig cyclo-
propanation to produce the cyclopropyl metal carbene B,
which might undergo facile 1,2-hydride migration to give
zwitterion C.7 Subsequent elimination of the metal fragment
might produce 1-alkenylbicyclo[3.1.0]hexane D probably as
a mixture of Z- and E-isomers (Scheme 2). A 1,2-alkyl
migration step would be competitive and would give dienes
E or F according to a similar process for the formations of II
and III. Herein, we report that the utilization of PtCl2 as the
catalyst for the cyclization of 1,6-enynes provides a conve-
nient and general approach to substituted bicyclo[3.1.0]-
hexanes under mild conditions.
To test the hypothesis in Scheme 2, we prepared diethyl 2-
