5b,7b-Diaza-3b,9b-diborabenzo[ ghi ]perylenes
Michael J.D. Bosdet, Warren E. Piers, Ted S. Sorensen, and Masood Parvez
Abstract: Treatment of a precursor to the chelating Lewis acid 2,2’-diborabiphenyl with 2,6-bisalkynyl-substituted pyrida-
zines, leads to elimination of 2 equiv. of ClSiMe3; subsequent treatment of the mixture with PtCl2 catalyzes the cyclization
of observable intermediates to the title 5b,7b-diaza-3b,9b-diborabenzo[ghi]perylene compounds in low isolated yields. The
compounds were characterized by NMR and UV–vis spectroscopies, and in one case, by X-ray crystallography. NICS(1)
computations indicate that the inner ring is less aromatic than the outer rings.
Key words: polycyclic aromatic hydrocarbons, boron heterocycles, nitrogen heterocycles, X-ray structure.
´
´
´
´
´
