An efficient acid-catalyzed approach to the synthesis of functional 1,4-dihydropyridines from the reaction of readily available enaminones with aldehydes has been developed. This methodology was realized by a cascade reaction involving first formation of divinylmethanes and subsequent intramolecular cyclization.

Full text of DOI:10.1002/ejoc.201000607

SHORT COMMUNICATION
DOI: 10.1002/ejoc.201000607
Acid-Catalyzed Cascade Reactions of Enaminones with Aldehydes:
C–H Functionalization To Afford 1,4-Dihydropyridines
Jingyu Yang,[a] Chengyu Wang,[a] Xin Xie,[a] Hongfeng Li,[a] and Yanzhong Li*[a]
Keywords: Nitrogen heterocycles / Cyclization / Lewis acids / C–H activation / Domino reactions
An efficient acid-catalyzed approach to the synthesis of func-
tional 1,4-dihydropyridines from the reaction of readily avail-
able enaminones with aldehydes has been developed. This
methodology was realized by a cascade reaction involving
first formation of divinylmethanes and subsequent intramo-
lecular cyclization.
though much progress has been made in recent years in
devising new processes, especially for the synthesis of
heterocycles, that involve the use of enaminones, direct
carbon–carbon bond-forming reactions with carbon elec-
trophiles is still quite limited.[8] Herein, we would like to
report the stereoselective synthesis of enaminones and its
cascade addition/cyclization reactions with aldehydes cata-
lyzed by Brønsted or Lewis acids, in which a C–C bond is
formed directly at the α-carbon of the enaminone
(Scheme 1). This reaction offers an efficient and straightfor-
ward route to 1,4-dihydropyridines.
Introduction
1,4-Dihydropyridines (1,4-DHPs) are very attractive
heterocycles in medicinal chemistry and pharmacology due
to their wide range of biological activities.[1] For example,
these compounds are known as calcium channel blocker
drugs,[2] and they have also been reported to be vasodilators
and bronchodilators. They also possess antiatherosclerotic,
antitumor, antidiabetic, or photosensitizing activities.[3]
Furthermore, they are useful and versatile synthetic inter-
mediates in organic chemistry.[4] As a result, much effort
has been paid to their preparation. The Hantzsch reaction,
the condensation of a β-keto ester or a 1,3-dicarbonyl com-
pound with an aldehyde and ammonia, is one of the most
well-documented methods for the formation of 1,4-DHPs,
and improved procedures for the synthesis of 1,4-DHPs
have been reported.[5] For example, it is known that 1,4-
DHPs can be constructed through the condensation of en-
aminones with α,β-unsaturated aldehydes.[5b,6f] The reaction
of amines and 3-(2-formylphenoxy)propenoates to 1,4-
DHPs is also reported.[6e] Although these procedures are
efficient for the synthesis of 1,4-DHPs, the C–H function-
alization of enaminones to 1,4-DHPs remains a challenging
task. In recent years, the direct conversion of C–H bonds
into C–C bonds has emerged as a rapidly growing area in
organic chemistry, as the process is atom economic and en-
vironmentally benign for the synthesis of useful synthetic
intermediates and materials.[7] In this regard, enaminone
derivatives are considered to serve as a viable C–H compo-
nent for direct functionalization. Enaminones are versatile
reagents that combine the ambident nucleophilicity of en-
amines with the ambident electrophilicity of enones. Al-
Scheme 1.
Results and Discussion
It is known that enaminones are prepared by direct con-
densation of 1,3-dicarbonyl compounds with amines in re-
fluxing aromatic hydrocarbons, or by the addition of
amines to alkynones.[9] In recent years, transition-metal-me-
diated approaches have also been reported.[10] However,
many of these processes suffer from limitations such as
drastic reaction conditions, low yields, or lack of stereose-
lectivity. Here we found that N-substituted enaminones 2
were readily prepared through conjugate addition of an-
ilines or aliphatic amines with terminal alkynones or ethyl
propiolate (Table 1). The reaction could be carried out con-
veniently at room temperature or at 80 °C in toluene, and
the corresponding enaminones were formed in good to high
yields. It is noteworthy that the stereoselectivity of this reac-
tion is high except for 2h, and the Z-isomer was observed
[a] Institute of Medicinal Chemistry, Department of Chemistry,
East China Normal University,
3663 North Zhongshan Road, Shanghai, 200062, People’s
Republic of China
Fax: +86-21-62233969
E-mail: yzli@chem.ecnu.edu.cn
Supporting information for this article is available on the
WWW under http://dx.doi.org/10.1002/ejoc.201000607.
Eur. J. Org. Chem. 2010, 4189–4193
© 2010 Wiley-VCH Verlag GmbH & Co. KGaA, Weinheim
4189

J. Yang, C. Wang, X. Xie, H. Li, Y. Li
SHORT COMMUNICATION
as the major isomer, possibly due to the tendency to form idene)benzenamine byproduct was observed in these experi-
an intramolecular hydrogen bond. In the case of 2h, the ments. The Lewis acid FeCl3·6H2O afforded a moderate
ratio of Z/E changed greatly, as observed in the crude reac- yield (48%) of 3a (Table 2, Entry 8). In the absence of a
tion mixture and the isolated materials (Table 1, Entry 9). catalyst, no reaction occurred (Table 2, Entry 9). It is wor-
When a less nucleophilic amine such as 4-chlorobenzen- thy to note that the general and efficient approaches to 1,4-
amine was used, the addition of FeCl3 as a catalyst ac- DHPs without substituents in the 2- and 6-positions are
celerated the reaction, and desired 2b was obtained in 85% still limited,[5d,6] and most of the methods suffer from harsh
yield within 1 h. Without this catalyst, a longer reaction reaction conditions and relatively low yields of the prod-
time was required (Table 1, Entries 2 and 3). We can see ucts, or are specific to substituted substrates. It is reported
from Table 1 that the desired enaminones were obtained in that 1,4-DHPs without substitutes in the 2- and 6-positions
high yields and with excellent stereoselectivity within short exhibit important pharmaceutical activities; for example,
reaction time.
dimers of these compounds are potential inhibitors of HIV-
1 protease and possess anticancer activity.[11]
Table 1. Stereoselective formation of enaminones.
Table 2. Optimization studies for the formation of 1,4-dihydropyr-
idines.
[a] Isolated yields. Unless noted, all the reactions were carried out
for 0.5–1 h. The ratio of the Z/E isomers in the crude reaction
mixture is given in parentheses. [b] Reaction time was 5 h. [c] Reac-
tion time was 23 h. [d] Reaction time was 6 h. [e] The ratio is 100:23
in the isolated product. [f] Under solvent-free conditions.
[a] Isolated yields. [b] NR = no reaction.
With the optimized reaction conditions in hand, we next
We started our investigation with (Z)-3-(4-methoxyphen- examined the substrate scope of this catalytic method for
ylamino)-1-phenylprop-2-en-1-one (2a). The reaction of 2a the synthesis of 1,4-DHPs by using a variety of enaminones
with 4-nitrobenzaldehyde was selected as the prototypical 2 and aldehydes (Table 3). We first investigated the elec-
case to screen the experimental conditions (Table 2). To our tronic effects of the aromatic substituents on the aldehydes.
delight, it was found that in the presence of a catalytic It was found that an electron-withdrawing (-Cl) aryl group
amount of TsOH·H2O, TFA, or NaAuCl4·2H2O, 2a was afforded the corresponding product 3b in 78% yield
smoothly transformed into desired 1,4-DHP 3a in 75–79% (Table 3, Entry 1). Benzaldehyde also gave good yield of 3c
yield (Table 2, Entries 2–4). It is noteworthy that increasing (Table 3, Entry 2). However, an electron-donating (-Me)
the amount of aldehyde from 0.75 to 1.0 equiv. not only aryl group resulted in a longer reaction time of 4 d with
lessened the reaction time, but also enhanced the product 80% yield of 3d as a result of the lower reactivity of this
yield (Table 2, Entry 2 vs. 6). The best yields were achieved aldehyde (Table 3, Entry 3). The use of NaAuCl4·2H2O as
by employing TsOH·H2O as the catalyst (85–87%; Table 2, catalyst reduced the reaction time dramatically to 16 h, and
Entries 6 and 7). The results indicated that the use of an dihydropyridine 3d was formed in 83% yield (Table 3, En-
excess amount of aldehyde ensured efficient elimination of try 4). A heteroaryl aldehyde such as 2-thienylaldehyde was
amine. Actually, the imine 4-methoxy-N-(4-nitrobenzyl- also compatible under the reaction conditions, furnishing
4190
www.eurjoc.org
© 2010 Wiley-VCH Verlag GmbH & Co. KGaA, Weinheim
Eur. J. Org. Chem. 2010, 4189–4193

C–H Functionalization To Afford 1,4-Dihydropyridines
3f, 3g, and 3l in yields of 76–90% (Table 3, Entries 6–8, 13). through the reaction with p-nitrobenzaldehyde (Table 3, En-
The reaction also proceeded smoothly with N-alkyl-substi- try 14). However, the use of paraformaldehyde resulted in a
tuted enaminones 2d–f to produce desired 1,4-DHPs 3i–k complicated reaction mixture (Table 3, Entry 15). The
in yields of 48–81% (Table 3, Entries 10–12). Enaminone 2g structure of 1,4-DHP was further confirmed by X-ray crys-
with an alkyl substituent on the carbonyl carbon led to the tallographic analysis of 3c.[12]
formation of 3l in 90% yield (Table 3, Entry 13). The cycli-
To understand the reaction mechanism, we carried out
zation was also successfully extended to enaminoester 2h, the reaction of 2a with p-nitrobenzaldehyde at room tem-
and 77% yield of 3m bearing two ester groups was obtained perature. It was found that divinylmethane intermediate 4a
Table 3. Synthesis of various substituted 1,4-dihydropyridines.
[a] Conditions A: TsOH·H2O (10 mol-%), 80 °C in DCE. Conditions B: NaAuCl4·2H2O (10 mol-%), 80 °C in DCE. [b] Isolated yields.
[c] The reaction was not clean.
Eur. J. Org. Chem. 2010, 4189–4193
© 2010 Wiley-VCH Verlag GmbH & Co. KGaA, Weinheim
www.eurjoc.org
4191

J. Yang, C. Wang, X. Xie, H. Li, Y. Li
SHORT COMMUNICATION
was isolated in 53% yield along with 35% of desired 3a (Z)-4. Isomerization of (Z)-4 into (E)-4 followed by nucleo-
(Scheme 2). When TFA (20 mol-%) was used as the catalyst, philic attack of the amino group to the enone moiety leads
4a was obtained in a higher yield of 70% at room tempera- to cyclized product 3.
ture. Isolated 4a was subjected to standard conditions by
To make this overall approach more convenient, a one-
using p-nitrobenzaldehyde (1 equiv.) to afford 3a in 92% pot process proceeding through sequential reactions was
yield. Without p-nitrobenzaldehyde, 3a could also be also checked. Typically, alkynone 1a (1 equiv.) was first
formed in 73% yield; however, a longer reaction time of treated with furan-2-ylmethanamine (1 equiv.) in DCE for
19 h was required. The results indicated that an excess 0.5 h to form compound 2 in situ, and TsOH·H2O (10 mol-
amount of aldehyde could accelerate the reaction process %) was then added. The mixture was stirred at 80 °C for
by trapping the released amine. The formation of divin- 10 h to give 1,4-DHP 3i in 60% yield (Scheme 4).
ylmethane 4a might be the key step in this cascade reac-
tion. Interestingly, during the reaction, the double bond
configuration of the enaminone changed from the Z form
in 2a to exclusively the E form in 4a, which was verified by
its NOESY spectra. In addition, the reaction of 2a with
paraformaldehyde afforded divinylmethane 4b with the E
form in 81% yield; the structure of 4b was confirmed by X-
ray crystallography[12] (Scheme 2).
Scheme 4.
Conclusions
In conclusion, we have successfully developed an efficient
method for the synthesis of 1,4-DHPs without substituents
at the C-2 and C-6 positions through an acid-catalyzed vi-
nylation/cyclization cascade reaction, in which direct con-
version of the C–H bonds of enaminones to C–C bonds
was achieved. The 1,4-DHP products can also be con-
structed from alkynones, amines, and aldehydes by a se-
quential process that omits the isolation of the enaminone
intermediates. Further application of this novel acid-cata-
lyzed procedure and endeavors to extend the scope of the
reaction such as for the synthesis of unsymmetrical substi-
tuted 1,4-DHPs are under progress in our group.
Scheme 2.
On the basis of the above observations, a possible reac-
tion mechanism is proposed in Scheme 3. First, nucleophilic
addition of enaminone 2 to the carbonyl group of the alde-
hyde occurs to form 6. This process is different from the
Hantzsch reaction, which includes a Michael addition of
the enamine to the α,β-unsaturated carbonyl compound.
Compound 6 reacts with another enaminone molecule
through benzylic substitution to generate divinylmethane
Experimental Section
Typical Procedure for the TsOH·H2O- or NaAuCl4·2H2O-Catalyzed
Synthesis of 1,4-Dihydropyridines 3 from (Z)-Enaminones 2 and Al-
dehydes: To a solution of (Z)-enaminone 2 (0.4 mmol) and aldehyde
(0.4 mmol) in DCE (2 mL) was added TsOH·H2O (3.8 mg, 10 mol-
%) or NaAuCl4·2H2O (8.0 mg, 10 mol-%). The resulting solution
was stirred at 80 °C until the reaction was complete, as monitored
by thin-layer chromatography. The solvent was evaporated in
vacuo, and the residue was purified by chromatography on silica
gel to afford 1,4-dihydropyridine derivatives 3.
[1-(4-Methoxyphenyl)-4-(4-nitrophenyl)-1,4-dihydropyridine-3,5-diyl]-
bis(phenylmethanone) (3a): Yield: 88 mg (85%); yellow solid, m.p.
225–226 °C. 1H NMR (400 MHz, CDCl3, Me4Si): δ = 3.78 (s, 3 H,
OCH3), 5.78 (s, 1 H, 4-H), 6.89–6.93 (m, 2 H), 7.11–7.15 (m, 2 H),
7.30 (s, 2 H, 2-H), 7.36–7.40 (m, 4 H), 7.44–7.48 (m, 2 H), 7.51–
7.53 (m, 4 H), 7.70–7.73 (m, 2 H), 8.12–8.16 (m, 2 H) ppm. 13C
NMR (100 MHz, CDCl3, Me4Si): δ = 37.08, 55.52, 115.16, 118.67,
123.07, 123.56, 128.25, 128.32, 129.04, 131.23, 135.92, 138.51,
140.79, 146.37, 152.84, 158.68, 193.94 ppm. HRMS: calcd. for
C32H24N2O5 516.1685; found 516.1696.
Scheme 3.
4192
www.eurjoc.org
© 2010 Wiley-VCH Verlag GmbH & Co. KGaA, Weinheim
Eur. J. Org. Chem. 2010, 4189–4193

C–H Functionalization To Afford 1,4-Dihydropyridines
[7]
For selected papers, see: a) C.-H. Jun, J.-B. Hong, Y.-H. Kim,
K.-Y. Chung, Angew. Chem. Int. Ed. 2000, 39, 3440; b) M.
Bandini, A. Melloni, A. Umani-Ronchi, Angew. Chem. Int. Ed.
2004, 43, 550; c) R. K. Thalji, K. A. Ahrendt, R. G. Bergman,
J. A. Ellman, J. Am. Chem. Soc. 2001, 123, 9692; d) F. Kakiu-
chi, Y. Yamamoto, N. Chatani, S. Murai, Chem. Lett. 1995,
681; e) C. G. Jia, W. T. Lu, J. Oyamada, T. Kitamura, K. Mat-
suda, M. Irie, Y. Fujiwara, J. Am. Chem. Soc. 2000, 122, 7252;
f) N. Chatani, T. Fukuyama, F. Kakiuchi, S. Murai, J. Am.
Chem. Soc. 1996, 118, 493; g) S. Yang, B. Li, X. Wan, Z. Shi,
J. Am. Chem. Soc. 2007, 129, 6066; h) S. J. Pastine, D. Sames,
Org. Lett. 2003, 5, 4053; i) S. J. Pastine, S. W. Youn, D. Sames,
Org. Lett. 2003, 5, 1055; j) B. Sezen, D. Sames, Org. Lett. 2003,
5, 3607.
For reviews, see: a) G. Negri, C. Kascheres, A. J. Kascheres, J.
Heterocycl. Chem. 2004, 41, 461; b) A. A. Elassar, A. A. El-
Khair, Tetrahedron 2003, 59, 8463; for recent papers, see: c) V.
Magali, L. Vladimir, P. Gérard, S. André, G. Robert, Synthesis
2001, 2419; d) Y. K. Ramtohul, A. Chartrand, Org. Lett. 2007,
9, 1029; e) X. Li, Y. Du, Z. Liang, X. Li, Y. Pan, K. Zhao,
Org. Lett. 2009, 11, 2643; f) J. Wang, S. Liu, W. Yu, Synlett
2009, 2529; g) H. Ge, M. J. Niphakis, G. I. Georg, J. Am.
Chem. Soc. 2008, 130, 3708; h) W. Yu, Y. Du, K. Zhao, Org.
Lett. 2009, 11, 2417; i) S. Kramer, K. Dooleweerdt, A. T. Lind-
hardt, M. Rottländer, T. Skrydstrup, Org. Lett. 2009, 11, 4208.
a) D. F. Martin, G. A. Janusonis, B. B. Martin, J. Am. Chem.
Soc. 1961, 83, 73; b) S. S. Palimkar, V. S. More, K. V. Sriniva-
san, Synth. Commun. 2008, 38, 1456; c) S. Cacchi, G. Fabrizi,
E. Filisti, Org. Lett. 2008, 10, 2629–2632.
Supporting Information (see footnote on the first page of this arti-
cle): Experimental details and spectroscopic data of all new com-
pounds.
Acknowledgments
We are grateful to the National Natural Science Foundation of
China (No. 20572025 and 20872037) for financial support. We also
thank the Laboratory of Organic Functional Molecules, Sino-
French Institute of ECNU, for support.
[1] a) R. A. Janis, P. J. Silver, D. J. Triggle, Adv. Drug Res. 1987,
16, 309; b) N. Baindur, A. Rutledge, D. J. Triggle, J. Med.
Chem. 1993, 36, 3743; c) A. M. van Rhee, J. L. Jiang, N. Mel-
man, M. E. Olah, G. L. Stiles, K. A. Jacobson, J. Med. Chem.
1996, 39, 2980; d) R. Peri, S. Padmanabhan, A. Rutledge, S.
Singh, D. J. Triggle, J. Med. Chem. 2000, 43, 2906–2914; e) R.
Lavilla, J. Chem. Soc. Perkin Trans. 1 2002, 1141; f) D. J. Trig-
gle, Cell. Mol. Neurobiol. 2003, 23, 293.
[2] a) C. O. Kappe, Eur. J. Med. Chem. 2000, 35, 1043; b) T. God-
fraind, R. Miller, M. Wibo, Pharmacol. Rev. 1986, 38, 321.
[3] a) A. Sausinsˇ, G. Duburs, Heterocycles 1988, 27, 269; b) M. F.
Gordeev, D. V. Patel, B. P. England, S. Jonnalagadda, J. D.
Combs, E. M. Gordon, Bioorg. Med. Chem. 1998, 6, 883; c)
M. F. Gordeev, D. V. Patel, E. M. Gordon, J. Org. Chem. 1996,
61, 924.
[8]
[9]
[4] a) H. Rudler, A. Parlier, L. Hamon, P. Herson, J.-C. Daran,
Chem. Commun. 2008, 4150; b) H. Rudler, A. Parlier, C. Sando- [10] a) A. S. Karpov, T. J. J. Muller, Synthesis 2003, 18, 2815; b) F.
val-Chavez, P. Herson, J.-C. Daran, Angew. Chem. Int. Ed.
2008, 47, 6843.
Epifano, S. Genovese, M. Curini, Tetrahedron Lett. 2007, 48,
2717; c) A. Arcadi, G. Bianchi, S. Di Giuseppe, F. Marinelli,
Green Chem. 2003, 5, 64; d) A. R. Khosropour, M. M. Kho-
daei, M. Kookhazadeh, Tetrahedron Lett. 2004, 45, 1725; e)
R. Dal Pozzo, A. De Nino, M. Nardi, B. Russo, A. Procopio,
Synthesis 2006, 1127; f) V. Sridharan, C. Avendano, J. C.
Menendez, Synlett 2007, 6, 881.
[5] a) A. Hantzsch, Justus Liebigs Ann. Chem. 1882, 1, 215; b) R.
Kaur Vohra, C. Bruneau, J.-L. Renaud, Adv. Synth. Catal.
2006, 348, 2571; c) J. Moreau, A. Duboc, C. Hubert, J.-P. Hur-
vois, J.-L. Renaud, Tetrahedron Lett. 2007, 48, 8647; d) S. Ki-
kuchi, M. Iwai, H. Murayama, S.-I. Fukuzawa, Tetrahedron
Lett. 2008, 49, 114; e) J. Jiang, J. Yu, X.-X. Sun, Q.-Q. Rao,
L.-Z. Gong, Angew. Chem. Int. Ed. 2008, 47, 2458; for reviews
on Hantzsch 1,4-DHP synthesis, see: f) D. M. Stout, A. I. Mey-
ers, Chem. Rev. 1982, 82, 223; g) C. Simon, T. Constantieux, J.
Rodriguez, Eur. J. Org. Chem. 2004, 4957; h) P. Langer, Chem.
Eur. J. 2001, 7, 3858; i) P. Langer, Synthesis 2002, 441.
[6] a) T. Chennat, V. Eisner, J. Chem. Soc. Perkin Trans. 1 1975,
[11] a) A. Hilgeroth, U. Baumeister, F. W. Heinemann, Eur. J. Org.
Chem. 2000, 245; b) A. Hilgeroth, M. Wiese, A. Billich, J. Med.
Chem. 1999, 42, 4729; c) A. Hilgeroth, U. Baumeister, F. W.
Heinemann, Heterocycles 1999, 51, 2367; d) A. Hilgeroth, F. W.
Heinemann, J. Heterocycl. Chem. 1998, 35, 359; e) A. Hilger-
oth, U. Baumeister, F. W. Heinemann, Eur. J. Org. Chem. 1998,
1213.
926; b) V. K. Lusis, G. Y. Dubur, Khim Geterotsikl Soedin 1982, [12] CCDC-767582 (for 3c) and -767583 (for 4b) contain the supple-
8, 1068; c) F. Wille, W. Schwab, Monatsh. Chem. 1977, 108,
929; d) S. Balalaie, E. Kowsari, Monatsh. Chem. 2001, 132,
1551; e) S.-L. Cui, J. Wang, X.-F. Lin, Y.-G. Wang, J. Org.
Chem. 2007, 72, 7779; f) J. Wan, S. Gan, G. Sun, Y. Pan, J.
Org. Chem. 2009, 74, 2862.
mentary crystallographic data for this paper. These data can
be obtained free of charge from The Cambridge Crystallo-
graphic Data Centre via www.ccdc.cam.ac.uk/data_request/cif.
Received: May 2, 2010
Published Online: June 15, 2010
Eur. J. Org. Chem. 2010, 4189–4193
© 2010 Wiley-VCH Verlag GmbH & Co. KGaA, Weinheim
www.eurjoc.org
4193
