SYNTHESIS OF 4-(ω-HYDROXYALKYL)-2,6-DI-tert-BUTYLPHENOLS
2005
NaOH, 19 g, and neopentyl glycol, 200 g, (molar ratio
1:1.3:5.3) was placed in a steel rotating 0.5 l autoclave
and maintained for 5 h at 220°C. The reaction mixture
was then cooled, neutralized with 10% hydrochloric
acid, and extracted with petroleum ether. 95 g of oil
was obtained that contained by the GLC data 40% of
3-(3,5-di-tert-butyl-4-oxyphenyl)-2,2-dimethylpropan-
1-ol, 35% of bis-(3,5-di-tert-butyl-4-hydroxyphenyl)
methane IIIa and 4.5% of the initial 2,6-di-tert-
butylphenol, as well as some other com-ponents. Com-
pound IIIa precipitated, 19.9 g, mp 152.5–153°C
(according to [15] mp 154°C). The filtrate after
separation of compound IIIa was distilled in a vacuum.
First fraction, 14.8 g of isobutanol, bp 60–95°C at
760 mm Hg. Second fraction, 11.2 g of neopentyl
glycol, bp 112–113°C at 2–3 mm Hg, mp 127°C. Third
fraction, 16.2 g (yield 15%), bp 160–173°C at 2–
3 mm Hg, oil, solidified on keeping. After crys-
tallization from n-heptane was isolated 13.2 g of 3-
(3,5-di-tert-butyl-4-hydroxyphenyl)-2,2-dimethyl-
propan-1-ol VI, mp 68–69°C. Found, %: C 79.07; H
10.67. M 292.5 (isothermal distillation). C19H22O2.
11.33. M 308.5. 1H NMR spectrum (100 MHz), δ, ppm
(CCl4): 1.40 s (18H, C4H9-tert), 1.3–1.8 m [8H, (CH2)4],
2.45 t (J = 7 Hz, ArCH2), 2.68 s (1H, OH), 3.5 t (J =
8 Hz, 2H, CH2OH), 4.89 s (1H, ArOH), 6.89 s (2H,
ArH).
1,6-Bis-(3,5-di-tert-butyl-4-hydroxyphenyl)hextane
(IIId), mp 152.5–153°C (from n-heptane), yield 7%.
Found, %: C 81.93, H 10.84. M 492 (by isothermal
distillation). Calculated, %: C 82.53, H 11.00. M
494.77. 1H NMR spectrum (100 MHz), δ, ppm (CCl4):
1.42 s (36 H, C4H9-tert), 1.1–1.9 m [8H, (CH2)4], 2.47
t (J = 7 Hz, 4H, ArCH2), 4.80 s (2H,OH), 6.85 s (4H,
Ar–H).
4-(7-Hydroxyheptyl)-2,6-di-tert-butylphenol (If),
mp 39–40°C (from n-heptane). Yield 40%. Found, %:
C 78.83 H 11.38. M 320 (by isothermal distillation).
1
C21H36O2. Calculated: C 78.70 H 11.26. M 320.5. H
NMR spectrum (100 MHz), δ, ppm (CCl4): 1.4 s (18H,
C4H9-tert), 2.45 t (J = 7 Hz, ArCH2), 4.89 s (ArOH),
6.85 s (2H, ArH), 1.2–1.8 m [10H, (CH2)5], 3.50 t (J =
8 Hz, CH2OH), 2.7 s( OH).
1
Calculated, %: C 79.02; H 11.02. M 292.44. H NMR
1,6-Bis-(3,5-di-tert-butyl-4-hydroxyphenyl)heptane
(IIIe), mp 97–98°C (from n-heptane), yield 5%.
Found: m/z 508.426 (mass spectrometry). C35H56O2.
Calculated: M 508.798. 1H NMR spectrum (100 MHz),
δ, ppm (CCl4): 1.40 s (36H, C4H9-tert), 1.1–1.9 m
(10H, (CH2)5), 2.40 t (J = 7 Hz, 4H, ArCH2), 4.80 s
(2H, OH), 6.80 s (4H, Ar–H).
spectrum (100 MHz), δ, ppm (CCl4): 0.85 s 6H, CH3),
1.43 s [8H, C(CH3)3] 2.44 s (ArCH2), 3.23 s (OH),
3.50 s (CH2OH), 4.92 s (OH), 6.87 s (2H, ArH).
General procedure for joint synthesis of 4-(ω-
hydroxyalkyl)-2,6-di-tert-butylphenol (Id–If) and
1,ω-bis-(3,5-di-tert-butyl-4-hydroxyphenyl)alkanes
(IIId–IIIf). In a glass reactor were placed 2,6-di-tert-
butylphenol, granulated NaOH, and 1,ω-alkandiol at
the reagent ratio 1:1.3:4 (mol), and the mixture was
stirred for 5 h in a flow of inert gas with heating at
220°C, with distilling off the reaction water. On
cooling, the product was neutralized with hydrochloric
acid and extracted with petroleum ether. The solvent
was evaporated, and the residue containing up to 60%
of alcohol I and 5% of a bis-alkane IIId–IIIf was
applied to a column with silica gel and eluted suc-
cessively with a mixture of petroleum ether–benzene
3:1, benzene and ethyl acetate. The evaporation of the
first fraction gave 1,ω-bis-(3,5-di-tert-butyl-4-hyd-
roxyphenyl)alkane IIId–IIIf (yield about 5%). The
evaporation of the third fraction resulted in 4-(ω-
hydroxyalkyl)-2,6-di-tert-butylphenol I, which was
purified by distillation in a vacuum, yield 45–60%.
4-(10-Hydroxydecyl)-2,6-di-tert-butylphenol (If).
Oil, bp176–180°C at 2–3mm Hg. Yield 39.3%. Found,
%: C 79.76. H 11.88. M 362 (by isothermal
distillation). C24H42O2. Calculated, %: C 79.49, H
1
11.67. M 362.57. H NMR spectrum (100 MHz), δ,
ppm (CCl4): 1.2–1.8 m (CH2)8, 1,4 s (18H, C4H9-tert),
2.45 t (J = 7 Hz, ArCH2), 2.67 s (OH), 3.50 t (J = 8
Hz, 2H,CH2OH), 4.9 s (1H, ArOH), 6.85 s (2H, ArH).
1,10-Bis-(3,5-di-tert-butyl-4-hydroxyphenyl)decane
(IIIf), mp 93–95°C (from n-heptane). Yield 5%.
Found: m/z 550.47510 (mass spectrometry). C38H62O2.
Calculated: M 550.47498. 1H NMR spectrum (100 MHz),
δ, ppm (CCl4): 1.1–1.9 m [10H, (CH2)5], 1.43 s (36H,
C4H9-tert), 2.47 t (J = 7 Hz, 4H, ArCH2), 4.82 s (2H,
OH), 6.85 s (4H, ArH).
REFERENCES
4-(6-Hydroxyhexyl)-2,6-di-tert-butylphenol (Id),
oil, bp 174–181°C at 2–3 mm Hg. Yield 46,5%.
Found, %: C 78.68, H 11.27. M 306 (by isothermal
distillation). C20H34O2. Calculated, %: C 78.74, H
1. Ershov, V.V., Volod’kin, A.A., Kudrina, L.I., and
Vol’eva, V.B., USSR Inventor’s Certificate no. 727614,
1978, Byul. Izobret., 1980, no. 14.
RUSSIAN JOURNAL OF GENERAL CHEMISTRY Vol. 80 No. 10 2010
