acetate to wash out sulfur residues and product was obtained
following elution with 5% methanol in ethyl acetate) to afford
acetamide 18 as an oil (360 mg, 70%); a–b ratio approx 2 : 1 ratio
(by integration of the 1H NMR spectrum). dH (400 MHz, CDCl3)
2.08, 2.07, 2.07, 2.06 (12H, 4 × s, 3 × OAc a, 1 × NHAc a) 1.94,
1.95, 2.03, 2.06 (12H, 4 × s, 1 × OAc b, 1 × NHAc b), 3.31–3.38
(1H, m, H-5b), 3.42–3.49 (1H, m, H-5a), 3.56–3.62 (1H, m, H-5ꢀa),
2003, 59, 10239–10248; (c) X. Wen, D. C. Crick, P. J. Brennan and P. G.
Hultin, Bioorg. Med. Chem. Lett., 2003, 11, 3579–3587; (d) A. Burton,
P. Wyatt and G.-J. Boons, J. Chem. Soc., Perkin Trans. 1, 1997, 2375–
2382.
5 R. Danac, L. Ball, S. J. Gurr, T. Muller and A. J. Fairbanks,
ChemBioChem, 2007, 8, in press.
6 F. Sanger, S. Nicklen and A. R. Coulson, Proc. Natl. Acad. Sci. U. S. A.,
1977, 74, 5463–5467.
7 R. S. Goody, B. Mu¨ller and T. Restle, FEBS Lett., 1991, 291, 1–5.
8 (a) C. J. Dimitroff, R. J. Bernacki and R. Sackstein, Blood, 2003,
101, 602–610; (b) B. Woynarowska, C. J. Dimitroff, M. Sharma, K. L.
Matta and R. J. Bernacki, Glycoconjugate J., 1996, 13, 663–674; (c) B.
Woynarowska, D. M. Skrincosky, A. Haag, M. Sharma, K. L. Matta
and R. J. Bernacki, J. Biol. Chem., 1994, 269, 22797–22803; (d) R. J.
Bernacki and W. Korytnyk, Development of membrane sugar and
nucleotide sugar analogs as potential inhibitors or modifiers of cellular
glycoconjugates, Glycoconjugates, ed. M. I. Horowitz, Academic, New
York, N. Y., 1982, vol. 4, pp. 245–263.
9 (a) A. Berkin, W. A. Szarek and R. Kisilevsky, Glycoconjugate J., 2005,
22, 443–451; (b) R. Kisilevsky, W. A. Szarek, J. B. Ancsin, E. Elimova,
S. Marone, S. Bhat and A. Berkin, Am. J. Pathol., 2004, 164, 2127–2137;
(c) A. Berkin, W. A. Szarek and R. Kisilevsky, Carbohydr. Res., 2002,
337, 37–44; (d) S. S. Thomas, J. Plenkiewicz, E. R. Ison, M. Bols, W.
Zou, W. A. Szarek and R. Kisilevsky, Biochim. Biophys. Acta, 1995,
1272, 37–48.
3.66–3.72 (1H, m, H-5ꢀb), 4.02 (1H, dt, J3,4 5.3 Hz, J4,5 5.3 Hz, J4,5
ꢀ
ꢀ
7.8 Hz, H-4b), 4.23 (1H, dt, J3,4 4.8 Hz, J4,5 4.8 Hz, J4,5 6.3 Hz,
H-4a), 4.89 (1H, J2,3 1.7 Hz, dd, H-3a), 5.14 (1H, d, H-2a), 5.21
(1H, dd, J2,3 5.3 Hz, H-3b), 5.28 (1H, dd, J1,2 4.5 Hz, H-2b), 6.08
(1H, s, H-1a), 6.19–6.21 (2H, m, NHa, NHb), 6.31 (1H, d, H-1b);
dC (100.6 MHz, CDCl3) 20.6, 20.7, 21.0 (3 × s, 3 × OAc a), 20.4,
20.8, 21.1 (3 × s, 3 × OAc b), 23.1 (2 × s, NHAc a, NHAc b),
40.7, 42.6 (C5-a, C5-b), 75.4 (C3-b), 75.6 (C2-b), 77.5 (C3-a), 80.6
(C2-a, C4-b), 83.1 (C4-a), 93.6 (C1-a), 99.0 (C1-b), 169.2, 169.4,
=
169.4, 169.7, 170.1, 170.2, 170.4, 170.5 (4 × Ac C O a, 4 × Ac
+
+
+
=
C O b); m/z (ES ) 340 (M + Na , 50%), 376 (M + MeCN/NH4 ,
100%); HRMS (ES+) calculated NaC13H19NO6 340.1003. Found
=
=
340.1003; mmax (thin film) 1748 (s, C O ester), 1660 (s, C O amide),
10 There are some branch points in which further arabinose units are
added onto OH-3.
1547 (s, N-H bending) cm−1.
11 F. Pan, M. Jackson, Y. Ma and M. R. McNeil, J. Bacteriol., 2001, 183,
3991–3998.
Spot culture method for testing of anti-mycobacterial activity
12 For two recent approaches in which the C-5 and C-3 positions of di-
and trisaccharide acceptor substrates of arabinosyl transferases were
modified in order to develop inhibitors of these enzymes see: (a) O. M.
Cociorva and T. L. Lowary, Carbohydr. Res., 2004, 339, 853–865;
(b) O. M. Cociorva, S. S. Gurcha, G. S. Besra and T. L. Lowary, Bioorg.
Med. Chem., 2005, 13, 1369–1379.
13 M. S. Scherman, L. Kalbe-Bournonville, D. Bush, Y. Xin, L. Deng and
M. R. McNeil, J. Biol. Chem., 1996, 271, 29652–29658.
14 Subsequently it has been proposed that epimerisation actually takes
place after polyprenylation. See: K. Mikusova, H. Huang, T. Yagi, M.
Holsters, D. Vereecke, W. D’Haeze, M. S. Scherman, P. J. Brennan,
M. R. McNeil and D. C. Crick, J. Bacteriol., 2005, 187, 8020–
8025.
15 A. Liav and P. J. Brennan, Tetrahedron Lett., 2005, 46, 2937–2939.
16 (a) M. Joe and T. L. Lowary, Carbohydr. Res., 2006, 341, 2723–2730;
(b) M. Joe and T. L. Lowary, Abstracts of Papers, 23rd International
Carbohydrate Symposium, Whistler, July 2006, THU-PS.
17 G. Legler, A. E. Stutz and H. Immich, Carbohydr. Res., 1995, 272,
17–30.
18 (a) C. Genu-Dellac, G. Gosselin and J. L. Imbach, Carbohydr. Res.,
1991, 216, 249–255; (b) O. Dahlman, P. J. Garegg, H. Mayer and S.
Schramek, Acta Chem. Scand., 1986, B40, 15–20.
Purified test compounds 4a, 4b, 6a, 6b, 7a, 7b, 9a, 9b, 10, 14, 17
and 18 were prepared in DMSO at a range of concentrations up to
100 mg mL−1. These stock solutions were added into different wells
of 6-well plates, with 5 lL DMSO alone added to control wells
(0.1% v/v). Molten MB agar (5 mL) containing OADC (oleic acid-
albumin-dextrose-catalase, Difco) was poured immediately into
the wells of the 6-well plates containing the extracts with thorough
mixing. Once solidified, the MB agar containing test reagents and
controls was inoculated with 5 lL of a 105 dilution of a mid-
log phase culture (OD 1.0) of M. bovis BCG Pasteur containing
approximately 500 cells. The cells were allowed to soak onto MB
agar before the plates were covered, sealed with parafilm, inverted
and incubated at 37 ◦C for 7–14 days. The resulting circular
spot cultures were photographed using a BioRad Gel-Doc 2000
system.
Acknowledgements
19 (a) B. L. Kam and N. J. Oppenheimer, Carbohydr. Res., 1979, 69, 308–
310; (b) M. Izumi, O. Tsurata and H. Hashimoto, Carbohydr. Res.,
1996, 280, 287–302.
20 M. A. Mohamed, A. El-Rahman and U. Hornemann, Carbohydr. Res.,
1974, 38, 355–358.
We gratefully acknowledge financial support from the Leverhulme
Trust (Postdoctoral Fellowship to I.A.S.).
21 A. E. Lloyd, P. L. Coe, R. T. Walker and O. W. Howarth, J. Fluorine
Chem., 1993, 60, 239–250.
22 S. Cai, S. Hakomori and T. Tokoyuni, J. Org. Chem., 1992, 57, 3431–
3437.
References
1 See: http://www.taacf.org.
2 T. L. Lowary, Mini–Rev. Med. Chem., 2003, 3, 689–702.
23 H. S. Park, H. Y. Lee and Y. H. Kim, Org. Lett., 2005, 7, 3187–
3190.
3 For some leading references see: (a) J. A. Maddy, N. Bansal, L. E.
Bermudez, R. N. Comber, I. M. Orme, W. J. Suling, L. N. Wilson
and R. C. Reynolds, Bioorg. Med. Chem. Lett., 1998, 8, 237–242;
(b) C. A. Centrone and T. L. Lowary, J. Org. Chem., 2002, 67, 8862–
8870; (c) A. K. Pathak, V. Pathak, J. A. Madry, W. J. Suling, S. S.
Gurcha, G. S. Besra and R. C. Reynolds, Bioorg. Med. Chem. Lett.,
2002, 10, 923–928; (d) A. K. Pathak, V. Pathak, J. A. Madry, W. J.
Suling, S. S. Gurcha, G. S. Besra and R. C. Reynolds, Bioorg. Med.
Chem. Lett., 2002, 10, 3145–3151; (e) M. Chaumontet, V. Pons, K.
Marotte and J. Prandi, Tetrahedron Lett., 2006, 47, 1113–1116.
4 For some leading references see: (a) S. Cren, S. S. Gurcha, A. J. Blake,
G. S. Besra and N. R. Thomas, Org. Biomol. Chem., 2004, 2, 2418–
2420; (b) A. K. Pathak, V. Pathak, M. Kulshrestha, D. Kinnaird, W. J.
Suling, S. S. Gurcha, G. S. Besra and R. C. Reynolds, Tetrahedron,
24 P. J. Garegg and B. Samuelsson, J. Chem. Soc., Perkin Trans. 1, 1980,
2866–2869.
25 A. J. Fairbanks, N. C. Carpenter, G. W. J. Fleet, N. G. Ramsden, I. C. de
Bello, B. G. Winchester, S. S. Al-Daher and G. Nagahashi, Tetrahedron,
1992, 48, 3365–3376.
26 J. W. Gillard and M. Israel, Tetrahedron Lett., 1981, 22, 513–516.
27 The stereoselectivity of nucleophilic substitution of various arabinose
glycosyl bromides with dibenzyl phosphate has been reported. For
some leading references see: (a) B. E. Maryanoff, A. B. Reitz, G. F.
Tutweiler, S. J. Benkovic, P. A. Benkovic and S. J. Pilkis, J. Am. Chem.
Soc., 1984, 106, 7851; (b) B. E. Maryanoff, A. B. Reitz and S. O. Nortey,
Tetrahedron, 1988, 44, 3093; (c) A. Liav, E. Swiezewska, E. Ciepichal
and P. J. Brennan, Tetrahedron Lett., 2006, 47, 8781.
This journal is
The Royal Society of Chemistry 2007
Org. Biomol. Chem., 2007, 5, 2257–2266 | 2265
©
