molecules
Article
Synthesis of Chromeno[3,4-b]piperazines by an
Enol-Ugi/Reduction/Cyclization Sequence
Ana Bornadiego , Ana G. Neo * and Carlos F. Marcos *
Laboratory of Bioorganic Chemistry & Membrane Biophysics (L.O.B.O.), Department of Organic and Inorganic
Chemistry, University of Extremadura, 10003 Cáceres, Spain; bornadiegos@unex.es
* Correspondence: aneo@unex.es (A.G.N.); cfernan@unex.es (C.F.M.); Tel.: +34-9-2725-7158 (C.F.M.)
Abstract: Keto piperazines and aminocoumarins are privileged building blocks for the construction
of geometrically constrained peptides and therefore valuable structures in drug discovery. Combining
these two heterocycles provides unique rigid polycyclic peptidomimetics with drug-like properties
including many points of diversity that could be modulated to interact with different biological
receptors. This work describes an efficient multicomponent approach to condensed chromenopiper-
azines based on the novel enol-Ugi reaction. Importantly, this strategy involves the first reported
post-condensation transformation of an enol-Ugi adduct.
Keywords: multicomponent reactions; isocyanides; peptidomimetics; heterocycles; piperazines;
pyrazines; chromones; coumarins; enols; Ugi reaction
ꢀꢁꢂꢀꢃꢄꢅꢆꢇ
ꢀꢁꢂꢃꢄꢅꢆ
1. Introduction
Citation: Bornadiego, A.; Neo, A.G.;
Marcos, C.F. Synthesis of
Peptidomimetics are molecules structurally related to peptides that can interact at the
same receptors of their prototypes [1,2]. They have attracted an enormous medical interest
Chromeno[3,4-b]piperazines by an
Enol-Ugi/Reduction/Cyclization
Sequence. Molecules 2021, 26, 1287.
https://doi.org/10.3390/
as they present similar, or sometimes opposite, effects to the equivalent peptide, but display
more favorable pharmacological properties. Geometrically constrained peptidomimetics
are an important class of peptide analogues containing cyclic structures that result in
reduced conformational flexibility and usually well-defined secondary structures [
frequently results in enhanced affinities for biological receptors, leading to improved
biological activities [ ]. In fact, many biologically active natural products present rigid
3]. This
molecules26051287
4
Academic Editor: Vincenzo Piccialli
peptide-like motives able to strongly bind to their target biomolecules.
Heterocycles are valuable building blocks to introduce defined structural constrains
Received: 15 February 2021
Accepted: 23 February 2021
Published: 27 February 2021
in peptide sequences [
3,4
]. Among the most attractive rigid peptidic scaffolds for drug
10], which are present in many alkaloids and pharmaceuticals
discovery are piperazines [
5
–
that can bind to a wide range of receptors [11]. Additionally, 3-aminocoumarins are consid-
ered privileged structures, present in various biologically active natural didepsipeptides,
such as bacterial antibiotics novobiocin [12–14], coumermycines [15] and cacibiocins [16],
Publisher’s Note: MDPI stays neutral
with regard to jurisdictional claims in
published maps and institutional affil-
iations.
and marine-derived fungal metabolites trichodermamides [17–19].
Conventional methods for the synthesis of these compounds commonly consist in
multi-step procedures, including several protection and deprotection reactions. In recent
years, more convenient multicomponent approaches have been developed to straight-
forwardly generate diversely substituted constrained peptidomimetics in one or a few
reaction steps. Thus, piperazines and pyrazines have been synthesized by modified Ugi
Copyright:
© 2021 by the authors.
condensations [20] and post-condensation transformations of Ugi [
products [24 25]. Different multicomponent strategies have also been used in the synthesis
of polycyclic coumarins [26].
7,21–23] or Ugi–Smiles
Licensee MDPI, Basel, Switzerland.
This article is an open access article
distributed under the terms and
conditions of the Creative Commons
Attribution (CC BY) license (https://
creativecommons.org/licenses/by/
4.0/).
,
Both condensed polycyclic piperazines [27] and coumarins [28] (Figure 1) are unique in
terms of structure and properties, reaching larger areas of the chemical space of biologically
relevant compounds, as well as a wider diversity of target proteins. Pharmacologically
relevant polycyclic pyrazines include praziquantel (
1), used as the primary medication for
Molecules 2021, 26, 1287. https://doi.org/10.3390/molecules26051287
https://www.mdpi.com/journal/molecules

Molecules 2021, 26, 1287
2 of 18
human schistosomiasis [29], trabectedin (
2
), a marine-derived orphan drug that has been
approved for the treatment of soft tissue sarcomas [30], and antidepressant mirtazapine
) [31]. On the other hand, many polycyclic coumarins have distinct biological activities.
Notable examples are phytoestrogen coumestrol ( ) [32], antioxidant and anticancer ellagic
acid ( ) [33], antimalarial dioncolactone ( ) [34], cannabinoid agonists cannabilactones
) [35] and neo-tanshinlactone ( ), a natural compound known for its specificity and
(
3
4
5
6
(
7
8
selectivity towards the breast cancer cells [36]. Thus, combining the coumarin and pyrazino
scaffolds in the same structure opens new opportunities to develop molecules with novel
and selective biological activities [37].
Figure 1. Some bioactive polycyclic pyrazines and coumarins.
Reports on chromenopyrazines are scarce, but some interesting examples have been
described. Thus, chromeno[3,4-b]pyrazines (9) [38] and the structural related pyrazino[2,3-
c]quinolin-5(6H)-ones (10) [39] are known to have antimicrobial and anticancer activities.
Additionally, furochromenopyrazines (11) present similar photobiological activities than
psoralens (Figure 2) [40]. Although some syntheses of pyrazino[2,3-c]quinolin-5(6H)-
ones have been reported [41
,
42], literature review reveals a limited number of known
synthesis of chromenopyrazines (Scheme 1) [43
,44]. For example, Pal and co-workers used
an AlCl3-induced C–C bond formation followed by transition metal mediated coupling-
cyclization to synthesize chromeno[4,3-b]quinoxalines [43]. More recently, the group
of Balci reported a synthesis of chromenopyrazinone derivatives in four reaction steps,
starting from salicylaldehyde [44]. These syntheses require the use of environmentally
noxious transition metals and permit a limited diversity of products. Consequently, the
development of simple and efficient synthetic methods is indispensable to further explore
the chromenopyrazine structure.
Figure 2. Some bioactive chromenopyrazines and quinolinopyrazines.

Molecules 2021, 26, 1287
3 of 18
Scheme 1. Representative syntheses of chromenopyrazines.
We have previously used multicomponent reactions of isocyanides for the synthesis
of peptide and pseudopeptide derivatives [45 48]. As part of this research line, here we
–
report the multicomponent synthesis of chromeno[3,4-b]pyrazin-5-ones as geometrically
restricted peptidomimetics.
2. Results and Discussion
We have recently reported the effective multicomponent enol-Ugi condensation of
enols (15), aldehydes (12), amines (13) and isocyanides (14) leading to polysubstituted
heterocyclic enamines (17; Scheme 2) [49
3-nitro-coumarin (15) and cyclohexyl isocyanide (14a) with different amines (13a
aldehydes (12a ) or the corresponding preformed imines (16a ) leads to aminoacyl-
coumarins (17a–k) in good to excellent yields (Table 1).
–
51]. The enol-Ugi condensation of 4-hydroxy-
–d) and
–
e
–k
Scheme 2. Enol-Ugi condensation of 4-hydroxycoumarin.

Molecules 2021, 26, 1287
4 of 18
Table 1. Synthesis of enol-Ugi adducts 17 and chromenopyrazines 19 a,b,d
.
a
Procedure for the synthesis of 17a
–
k
: Isocyanide 14 (1 equiv) and enol 15 (1 equiv) were added to a solution
of imine 16 (1 equiv) in CH2Cl2 and stirred at 20 ◦C for 3 h. Procedure for the synthesis of 19a
–
i
and 18j
,
k:
b
Enol-Ugi adduct 17 (1 equiv) and iron powder (24 equiv) were stirred at rt for 2–4 h. c The reaction was performed
at 150 ◦C. d All yields refer to isolated yields.

Molecules 2021, 26, 1287
5 of 18
Reduction of the nitro group in the enol-Ugi adducts (17a
–k) with iron in acetic acid
takes place smoothly at room temperature to afford amino intermediates (18a
are usually not isolated. In the case of enol-Ugi adducts derived from aliphatic amines
17a ) the spontaneous intramolecular attack of the amine on the amide group generates
a pyrazine ring (19a ) with loss of cyclohexylamine (Scheme 3). Conversely, enol-Ugi
–k) that
(
–i
–
i
adducts derived from aromatic amines (17j,k) give stable aminocoumarins (18j,k) that
can be isolated. However, when the reduction/cyclization was carried out at 150 ◦C the
corresponding chromenopyrazines (19j,k) were directly obtained (Table 1).
Scheme 3. Postcondensation synthesis of chromenopyrazinones. Dipeptidic structure is shaded in light blue colour.
A rigid dipeptidic structure is comprised in the pyrazine and pyranone rings of
chromenopyrazines (19; Scheme 3). In order to extend the peptidic skeleton of these
geometrically constrained dipeptides, we decided to use esters of amino acids as amino
components of the enol-Ugi reaction (Scheme 4). Accordingly, the four-component reaction
of 4-hydroxy-3-nitro-coumarin (15), different isocyanides (14a
–d
) and aldehydes (12a
,c,d)
with glycine methyl ester (13e) gave the corresponding adducts (17l
–
r) in good yields. The
analogous condensation of β-alanine (13f) similarly gave adduct 17s (Table 2).
Scheme 4. Synthesis of chromenopyrazine tripeptides. Tripeptidic structure is shaded in light blue colour.
Interestingly, in this case, reduction of the nitro group does not lead to cyclization by
the attack on the amide, as with adducts 17a . The attack of the amine occurs instead on
the more reactive ester group derived from the glycine methyl ester, affording pyrazines
20l (Scheme 4; Table 2). The amide group brought by the isocyanide component is thus
–k
–r
preserved in the product delivering a new element of diversity, as different isocyanides
can be used (Table 2). Rigid retropeptidic tripeptides are obtained in this manner. The
peptide sequence could theoretically be grown from the isocyanide-derived amide to obtain
peptides with an inverted rigid N-terminus.

Molecules 2021, 26, 1287
6 of 18
Table 2. Synthesis of enol-Ugi adducts of amino acids (17) and chromenopyrazines 19 and 20 a,b,c
.
a
Procedure for the synthesis of 17l
–
s
: A solution of amine 13 (1 equiv) and aldehyde 12 (1 equiv) in of dry
acetonitrile was stirred for 15 min at rt; isocyanide 14 (1 equiv) and enol 15 (1 equiv) were successively added and
b
the reaction mixture was stirred 4 days at rt. Procedure for the synthesis of 19s and 20l
–
r
: Enol-Ugi adduct 17 (1
c
equiv) and iron powder (24 equiv) were stirred at rt in acetic acid for 2–4 h. All yields refer to isolated yields.
On the other hand, the β-alanine-derived adduct (17s) cyclizes again by attack on the
amide to give pyrazine 19s. This reaction is more favorable than cyclization on the ester, as
this would involve the formation of a seven-membered, instead of a six membered ring.
3. Materials and Methods
3.1. Starting Materials
Acetonitrile was dried by distillation over P2O5, immediately prior to use. Glacial
acetic acid was purchased from commercial sources and used as received. Aldehydes
(
12a
powder are commercially available and were used without purification. 4-Hydroxy-3-
nitrocoumarin (15) was prepared by nitration of 4-hydroxycoumarin [52]. Imines (16a
–e), amines (13a–f), isocyanides (14a–d; S.I. Figure S1), 4-hydroxycoumarin and iron
–k;
S.I. Figure S2) were synthesized using the standard procedure of mixing equimolar amounts
of the corresponding aldehydes (12), amines (13) and anhydrous Na2SO4 in dry CH2Cl2 at
room temperature for 24 h. [53
,54] Evaporation of the solvent quantitatively yielded the
imines (16) that were used in the Ugi reaction without further purification.

Molecules 2021, 26, 1287
7 of 18
3.2. General Synthetic Techniques
Liquid reagents were measured using positive-displacement micropipettes with dis-
posable tips and pistons. Thin layer chromatography was performed on aluminum plates,
using 254 nm UV light or a mixture of p-anisaldehyde (2.5%), acetic acid (1%) and H2SO4
(3.4%) in 95% ethanol as developer.
3.3. Instrumentation
Melting points are uncorrected. IR spectra were recorded as KBr pellets. Proton and
carbon-13 nuclear magnetic resonance (1H-NMR or 13C-NMR) spectra were obtained on a
500 MHz spectrometer. The assignments of signals in 13C-NMR were made by DEPT. High
resolution mass spectra (HRMS) were recorded using a 6520 Accurate Mass QTOF LC/MS
Spectrometer.
3.4. Synthesis and Characterization of the Ugi-Aducts
3.4.1. Three-Component Condensation
Our previously reported procedure [51] was followed. Briefly, isocyanide (14, 0.5
mmol) and enol (15, 0.5 mmol) were successively added to a solution of imine (16, 0.5
mmol) in CH2Cl2 (1 mL), and the resulting mixture was stirred at 20 ◦C for 3 h. Removal
of the solvent and purification by column chromatography (SiO2, gradient from 100%
hexanes to hexanes–EtOAc, 7:3) gave the corresponding enamines 17a–k (Table 1).
2-(Benzyl(3-nitro-2-oxo-2H-chromen-4-yl)amino)-2-(2-bromophenyl)-N-cyclohexyl acetamide
(
17b). Obtained from isocyanide 14a, enol 15 and imine 16b, from isocyanide 14a, enol 15
and imine 16b, as a yellow solid (260 mg, 88%); m.p. 165–167 ◦C; IR (cm−1) 3341, 3064,
2933, 2854, 1714, 1677, 1600, 1549, 1465, 1350, 1278, 1116, 1054, 925, 760; 1H-NMR (500 MHz,
CDCl3)
δ 8.14 (d, J = 8.0 Hz, 1H), 7.63–7.57 (m, 3H), 7.42 (dt, J = 7.5, 0.9 Hz, 1H), 7.40 (dt, J
= 3.7, 1.0 Hz, 1H), 7.38–7.36 (m, 1H), 7.31 (dd, J = 8.3, 0.8 Hz, 1H), 7.28 (dd, J = 7.8, 1.4 Hz,
1H), 7.25–7.18 (m, 5H), 5.87 (s, 1H), 5.56 (d, J = 8.0 Hz, 1H), 4.77 (d, J = 14.8 Hz, 1H), 3.99
(d, J = 14.8 Hz, 1H), 3.82–3.73 (m, 1H), 1.93–1.54 (m, 5H), 1.39–0.97 (m, 5H); 13C-NMR (126
MHz, CDCl3) δ 167.45 (C), 155.12 (C), 153.00 (C), 152.48 (C), 135.14 (C), 134.33 (C), 133.96
(CH), 133.82 (CH), 130.99 (CH), 130.13 (CH), 129.02 (CH), 128.61 (CH), 128.44 (CH), 128.24
(CH), 127.49 (CH), 126.33 (C), 125.12 (CH), 118.45 (C), 117.90 (CH), 68.92 (CH), 54.76 (CH2),
49.26 (CH), 32.73 (CH2), 32.71 (CH2), 24.82 (CH2), 24.74 (CH2); MS (qTOF) m/z (%) 592
(M+ + 3, 28), 590 (M+ + 1, 30), 574 (42), 572 (44), 510 (98), 508 (100); HRMS (qTOF) Calcd for
C30H29BrN3O5: 590.1296. Found: 590.1285.
2-(Benzyl(3-nitro-2-oxo-2H-chromen-4-yl)amino)-N-cyclohexyl-2-(p-tolyl)acetamide (17c).
Obtained from isocyanide 14a, enol 15 and imine 16c, as a yellow solid (208 mg, 79%); m.p.
141–143 ◦C; IR (cm−1) 3369, 2928, 2853, 1729, 1681, 1601, 1549, 1451, 1403, 1350, 1116, 1054,
791; 1H-NMR (500 MHz, CDCl3)
δ 8.04 (d, J = 8.1 Hz, 1H), 7.56 (dt, J = 7.3, 1.4 Hz, 1H),
7.31–7.26 (m, 2H), 7.24–7.11 (m, 9H), 5.78 (d, J = 8.1 Hz, 1H), 5.16 (s, 1H), 4.64 (d, J = 14.9 Hz,
1H), 4.19 (d, J = 14.9 Hz, 1H), 3.76–3.67 (m, 1H), 2.33 (s, 3H), 1.87–1.53 (m, 5H), 1.36–0.95
(m, 5H); 13C-NMR (126 MHz, CDCl3)
δ 168.30 (C), 155.08 (C), 153.26 (C), 152.49 (C), 139.50
(C), 135.31 (C), 133.89 (CH), 131.78 (C), 129.90 (CH), 129.16 (CH), 129.04 (CH), 128.57 (C),
128.45 (CH), 128.39 (CH), 124.93 (CH), 118.38 (C), 117.65 (CH), 71.15 (CH), 55.96 (CH2),
48.99 (CH), 32.79 (CH2), 32.70 (CH2), 27.07 (CH2), 24.87 (CH2), 24.79 (CH2), 21.32 (CH3);
MS (qTOF) m/z (%) 526 (M+ + 1, <5), 479 (10), 347 (100), 146 (54); HRMS (qTOF) Calcd for
C33H32N3O5: 526.2326. Found: 526.2326.
2-(Benzyl(3-nitro-2-oxo-2H-chromen-4-yl)amino)-N-cyclohexyl-2-(4-(trifluoromethyl) phenyl)
acetamide (17d). Obtained from isocyanide 14a, enol 15 and imine 16d, as a yellow solid
(226 mg, 78%), m.p. 135–137 ◦C; IR (cm−1) 3365, 2932, 2855, 1730, 1684, 1603, 1550, 1324,
1168, 1127, 1068, 761, 699; 1H-NMR (500 MHz, CDCl3)
δ 7.90 (d, J = 7.3 Hz, 1H), 7.61–7.57
(m, 3H), 7.52 (d, J = 8.2 Hz, 2H), 7.30 (d, J = 7.7 Hz, 2H), 7.24–7.18 (m, 3H), 7.10 (dd, J = 6.5,
1.6 Hz, 2H), 5.88 (d, J = 8.1 Hz, 1H), 5.16 (s, 1H), 4.63 (d, J = 14.7 Hz, 1H), 4.23 (d, J = 14.7 Hz,
1H), 3.71–3.61 (m, 1H), 1.84–1.55 (m, 5H), 1.35–0.93 (m, 5H); 13C-NMR (126 MHz, CDCl3)
δ
167.30 (C), 154.79 (C), 153.12 (C), 152.48 (C), 139.01 (C), 134.71 (C), 134.23 (CH), 131.76 (C),

Molecules 2021, 26, 1287
8 of 18
131.50 (C), 129.35 (CH), 129.29 (CH), 128.75 (CH), 128.70 (CH), 128.28 (CH), 126.15 (CH),
126.12 (CH), 125.05 (CH), 122.73 (C), 118.21 (C), 117.80 (CH), 70.56 (CH), 56.77 (CH2), 49.15
(CH), 32.68 (CH2), 32.60 (CH2), 25.41 (CH2), 24.82 (CH2), 24.75 (CH2); MS (qTOF) m/z (%)
580 (M+ + 1, 100), 391 (13), 309 (28); HRMS (qTOF) Calcd for C31H29F3N3O5: 580.2059.
Found: 580.2059.
2-((Benzo[d][1,3]dioxol-5-ylmethyl)(3-nitro-2-oxo-2H-chromen-4-yl)amino)-N-cyclohexyl-2-
phenylacetamide (17e). Obtained from isocyanide 14a, enol 15 and imine 16e, as a yellow
solid (217 mg, 78%); m.p. 135–136 ◦C; IR (cm−1) 3369, 2930, 2853, 1728, 1681, 1601, 1549,
1504, 1489, 1446, 1401, 1347, 1249, 929, 761; 1H-NMR (500 MHz, CDCl3)
δ 8.07 (dd, J = 8.1,
1.3 Hz, 1H), 7.56 (dt, J = 6.9, 1.4 Hz, 1H), 7.38–7.28 (m, 7H), 6.74 (d, J = 1.4 Hz, 1H), 6.61 (d, J
= 7.9, Hz, 1H), 6.57 (dd, J = 8.0, 1.5 Hz, 1H), 5.89 (s, 2H), 5.78 (d, J = 8.1 Hz, 1H), 5.19 (s,
1H), 4.56 (d, J = 14.8 Hz, 1H), 4.09 (d, J = 14.8 Hz, 1H), 3.76–3.67 (m, 1H), 1.89–1.53 (m, 5H),
1.37–0.95 (m, 5H); 13C-NMR (126 MHz, CDCl3)
δ 168.11 (C), 155.06 (C), 152.50 (C), 147.83
(C), 147.73 (C), 134.78 (C), 134.00 (CH), 129.52 (CH), 129.23 (CH), 129.12 (CH), 128.91 (C),
128.31 (CH), 125.06 (CH), 122.90 (CH), 118.25 (C), 117.71 (CH), 109.38 (CH), 108.16 (CH),
101.22 (CH2), 71.29 (CH), 55.71 (CH2), 49.04 (CH), 32.76 (CH2), 32.67 (CH2), 27.05 (CH2),
24.85 (CH2), 24.77 (CH2); MS (qTOF) m/z (%) 556 (M+ + 1, 672), 457 (20), 353 (100); HRMS
(qTOF) Calcd for C31H30N3O7: 556.2084. Found: 556.2089.
2-((Benzo[d][1,3]dioxol-5-ylmethyl)(3-nitro-2-oxo-2H-chromen-4-yl)amino)-N-cyclohexyl-2-
(p-tolyl)acetamide (17f). Obtained from isocyanide 14a, enol 15 and imine 16f, as a yellow
solid (202 mg, 71%); m.p. 145–146 ◦C; IR (cm−1) 3424, 2929, 2853, 1728, 1679, 1601, 1549,
1489, 1446, 1249, 1039, 929, 761; 1H-NMR (500 MHz, CDCl3)
δ 8.09 (d, J = 7.2 Hz, 1H), 7.58
(dt, J = 6.4, 1.3 Hz, 1H), 7.35–7.27 (m, 2H), 7.21 (d, J = 8.0 Hz, 2H), 7.14 (d, J = 7.9 Hz, 2H),
6.75 (s, 1H), 6.63–6.55 (m, 2H), 5.88 (s, 2H), 5.72 (d, J = 8.1 Hz, 1H), 5.16 (s, 1H), 4.55 (d, J
= 14.8 Hz, 1H), 4.08 (d, J = 15.0 Hz, 1H), 3.77–3.68 (m, 1H), 2.33 (s, 3H), 1.88–1.54 (m, 5H),
1.35–0.95 (m, 5H); 13C-NMR (126 MHz, CDCl3)
δ 168.36 (C), 153.15 (C), 152.55 (C), 147.84
(C), 147.71 (C), 139.54 (C), 133.92 (CH), 131.77 (C), 130.54 (C), 129.93 (CH), 129.07 (CH),
128.36 (CH), 125.02 (CH), 122.90 (CH), 118.36 (C), 118.32 (C), 117.69 (CH), 109.43 (CH),
108.15 (CH), 101.20 (CH2), 71.14 (CH), 55.58 (CH2), 49.04 (CH), 32.82 (CH2), 32.73 (CH2),
27.07 (CH2), 24.88 (CH2), 24.80 (CH2), 21.32 (CH3); MS (qTOF) m/z (%) 570 (M+ + 1, 70),
353 (100); HRMS (qTOF) Calcd for C32H32N3O7: 570.2240. Found: 570.2236.
2-((Benzo[d][1,3]dioxol-5-ylmethyl)(3-nitro-2-oxo-2H-chromen-4-yl)amino)-N-cyclohexyl-2-
(4-(trifluoromethyl)phenyl)acetamide (17g). Obtained from isocyanide 14a, enol 15 and imine
16g, as a yellow solid (250 mg, 80%); m.p. 129–131 ◦C; IR (cm−1) 3362, 2931, 2854, 1727,
1
1683, 1603, 1550, 1490, 1447, 1324, 1250, 1167, 1127, 1068, 930, 761; H-NMR (500 MHz,
CDCl3)
δ 7.96 (dd, J = 8.1, 1.1 Hz, 1H), 7.64–7.56 (m, 3H), 7.52 (d, J = 8.2 Hz, 2H), 7.35–7.29
(m, 2H), 6.67 (d, J = 1.5 Hz, 1H), 6.62 (d, J = 7.9 Hz, 1H), 6.52 (dd, J = 8.0, 1.5 Hz, 1H), 5.90
(s, 2H), 5.82 (d, J = 8.0 Hz, 1H), 5.16 (s, 1H), 4.55 (d, J = 14.6 Hz, 1H), 4.16 (d, J = 14.6 Hz,
1H), 3.72–3.63 (m, 1H), 1.87–1.52 (m, 5H), 1.35–0.94 (m, 5H); 13C-NMR (126 MHz, CDCl3)
δ
167.34 (C), 154.78 (C), 153.00 (C), 152.53 (C), 148.00 (C), 147.96 (C), 138.97 (C), 134.28 (CH),
129.35 (CH), 128.39 (C), 128.20 (CH), 126.17 (CH), 126.14 (CH), 125.14 (CH), 123.07 (CH),
118.16 (C), 117.85 (CH), 109.48 (CH), 108.28 (CH), 101.34 (CH2), 70.52 (CH), 56.42 (CH2),
49.19 (CH), 32.71 (CH2), 32.64 (CH2), 27.07 (CH2), 24.83 (CH2), 24.76 (CH2); MS (qTOF) m/z
(%) 624 (M+ + 1, 35), 353 (100); HRMS (qTOF) Calcd for C32H29F3N3O7: 624.1958. Found:
624.1942.
N-Cyclohexyl-2-(cyclohexyl(3-nitro-2-oxo-2H-chromen-4-yl)amino)-2-(p-tolyl)acetamide (17h).
Obtained from isocyanide 14a, enol 15 and imine 16h, as a pale orange solid (205 mg, 79%);
m.p. 68–70 ◦C; IR (cm−1) 3415, 2931, 2855, 1736, 1662, 1605, 1540, 1451, 1374, 1276, 1111, 1055,
762; 1H-NMR (500 MHz, CDCl3)
δ 7.98 (bs, 1H), 7.53 (dt, J = 7.2, 1.3 Hz, 1H), 7.32–7.28 (m,
3H), 7.21 (d, J = 7.6 Hz, 1H), 6.90 (d, J = 8.0 Hz, 2H), 6.53 (d, J = 5.8 Hz, 1H), 5.07 (s, 1H),
3.72–3.61 (m, 1H), 3.32 (tt, J = 11.6, 3.4 Hz, 1H), 2.17 (s, 3H), 2.10–0.81 (m, 20H); 13C-NMR (126
MHz, CDCl3) δ 170.63 (C), 154.63 (C), 153.53 (C), 151.63 (C), 138.79 (C), 133.82 (CH), 132.54
(C), 129.27 (CH), 129.21 (CH), 129.12 (CH), 128.70 (C), 127.78 (CH), 127.12 (CH), 124.57 (CH),
120.12 (C), 117.24 (CH), 72.17 (CH), 66.58 (CH), 48.60 (CH), 32.73 (CH2), 32.63 (CH2), 32.45

Molecules 2021, 26, 1287
9 of 18
(CH2), 32.28 (CH2), 27.06 (CH2), 26.09 (CH2), 26.08 (CH2), 24.97 (CH2), 24.94 (CH2), 21.14
(CH3); MS (qTOF) m/z (%) 518 (M+ + 1, 30), 517 (35), 447 (100); HRMS (qTOF) Calcd for
C30H36N3O5: 518.2655. Found: 518.2648.
N-Cyclohexyl-2-(cyclohexyl(3-nitro-2-oxo-2H-chromen-4-yl)amino)-2-(4-(trifluoromethyl)
phenyl)acetamide (17i). Obtained from isocyanide 14a, enol 15 and imine 16i, as a pale
orange solid (243 mg, 85%); m.p. 133–135 ◦C; IR (cm−1) 3386, 2933, 2856, 1737, 1681, 1606,
1541, 1325, 1167, 1127, 1068, 762; 1H-NMR (500 MHz, CDCl3)
δ 7.93 (bs, 1H), 7.59 (d, J = 8.2
Hz, 2H), 7.54 (t, J = 7.3 Hz, 1H), 7.40 (d, J = 8.2 Hz, 2H), 7.32 (t, J = 7.7 Hz, 1H), 7.24 (d, J
= 8.3 Hz, 1H), 6.55 (bs, 1H), 5.16 (s, 1H), 3.68–3.57 (m, 1H), 3.30 (tt, J = 11.6, 3.4 Hz, 1H),
2.09–1.53 (m, 10H), 1.37–0.95 (m, 10H); 13C-NMR (126 MHz, CDCl3)
δ 169.44 (C), 154.32 (C),
152.78 (C), 151.79 (C), 140.01 (C), 134.25 (CH), 128.81 (CH), 125.58 (CH), 125.55 (CH), 124.86
(CH), 119.84 (C), 117.56 (CH), 72.08 (CH), 66.63 (CH), 48.84 (CH), 32.66 (CH2), 32.58 (CH2),
32.49 (CH2), 32.30 (CH2), 27.07 (CH2), 26.07 (CH2), 25.47 (CH2), 25.23 (CH2), 24.92 (CH2),
24.89 (CH2); MS (qTOF) m/z (%) 572 (M+ + 1, 69), 473 (100), 383 (17), 301 (171); HRMS
(qTOF) Calcd for C30H33F3N3O5: 572.2372. Found: 572.2367.
N-Cyclohexyl-2-(3,4-dimethoxyphenyl)-2-((3-nitro-2-oxo-2H-chromen-4-yl)(phenyl)amino) ac-
etamide (17k). Obtained from isocyanide 14a, enol 15 and imine 16k, as an orange solid (112
mg, 40%); m.p. 129–130 ◦C; IR (cm−1) 3403, 2931, 2853, 1740, 1681, 1604, 1517, 1451, 1373,
1265, 1148, 761; 1H-NMR (500 MHz, CDCl3)
δ 7.67 (d, J = 7.0 Hz, 1H), 7.55 (dt, J = 6.1, 1.5
Hz, 1H), 7.29–7.20 (m, 5H), 7.03 (t, J = 7.4 Hz, 1H), 6.99 (d, J = 8.0 Hz, 2H), 6.76 (dd, J = 8.3,
2.1 Hz, 2H), 6.67 (d, J = 1.9 Hz, 2H), 6.61 (d, J = 8.4 Hz, 2H), 6.37 (d, J = 8.2 Hz, 2H), 5.50
(s, 2H), 3.87–3.78 (m, 2H), 3.77 (s, 3H), 3.58 (s, 3H), 1.94–1.52 (m, 5H), 1.39–0.94 (m, 5H);
13C-NMR (126 MHz, CDCl3)
δ 168.15 (C), 153.89 (C), 152.90 (C), 150.26 (C), 149.83 (C), 148.68
(C), 144.87 (C), 134.24 (CH), 129.75 (CH), 128.78 (CH), 125.29 (CH), 124.44 (C), 123.13 (CH),
123.04 (CH), 118.23 (C), 117.81 (CH), 117.60 (CH), 112.72 (CH), 110.84 (CH), 69.97 (CH), 55.90
(CH3), 55.65 (CH3), 48.64 (CH), 32.83 (CH2), 32.43 (CH2), 25.43 (CH2), 24.71 (CH2), 24.58
(CH2); MS (qTOF) m/z (%) 558 (M+ + 1, <5), 478 (35), 328 (57); HRMS (qTOF) Calcd for
C31H32N3O7: 558.2240. Found: 558.2234.
3.4.2. Four-Component Condensation
Amine 13 (0.5 mmol) was added to a solution of aldehyde 12 (0.5 mmol) in of dry
acetonitrile (1 mL). The resulting mixture was stirred for 15 min at rt and then isocyanide
14 (0.5 mmol) and enol 15 (0.5 mmol) were successively added. After 4 days stirring at
room temperature, the reaction went to completion, as judged by tlc. Then 10% HCl (2
mL) was added, the mixture was washed with H2O (15 mL), extracted with CH2Cl2 (3
×
20 mL) and dried over Na2SO4. Removal of the solvent and purification by column
chromatography (SiO2, gradient from 100% hexanes to hexanes–EtOAc, 7:3) gave the
corresponding enamines 17l–s (Table 2).
Methyl N-(2-(cyclohexylamino)-2-oxo-1-phenylethyl)-N-(3-nitro-2-oxo-2H-chromen-4-yl)glycinate
(
17l). Obtained from aldehyde 12a, amine 13e, isocyanide 14a and enol 15, as a pale orange
solid (141 mg, 57%); m.p. 132–134 ◦C; IR (cm−1) 3359, 2931, 2854, 1730, 1681, 1606, 1554, 1452,
1212, 760; 1H-NMR (500 MHz, CDCl3)
8.12 (d, J = 8.1 Hz, 1H), 7.63 (t, J = 7.7 Hz, 1H), 7.44–7.33
(m, 5H), 5.90 (d, J = 8.0 Hz, 1H), 5.39 (s, 1H), 4.10 (d, J = 18.0 Hz, 1H), 3.80 (d, J = 18.0 Hz, 1H),
3.74–3.66 (m, 1H), 3.64 (s, 3H), 1.91–0.93 (m, 10H); 13C-NMR (126 MHz, CDCl3)
169.12 (C),
δ
δ
167.52 (C), 152.60 (C), 152.42 (C), 134.39 (C), 133.94 (CH), 129.57 (CH), 129.24 (CH), 128.91 (CH),
127.89 (CH), 125.15 (CH), 117.77 (CH), 70.24 (CH), 52.37 (CH3), 51.80 (CH2), 48.85 (CH), 32.60
(CH2), 32.53 (CH2), 26.94 (CH2), 25.33 (CH2), 24.73 (CH2), 24.66 (CH2); MS (qTOF) m/z (%)
494 (M+ + 1, 26), 423 (10), 305 (100); HRMS (qTOF) Calcd for C26H28N3O7: 494.1927. Found:
494.1915.
Methyl N-(2-(cyclohexylamino)-2-oxo-1-(p-tolyl)ethyl)-N-(3-nitro-2-oxo-2H-chromen-4-yl)glycinate
(
17m). Obtained from aldehyde 12c, amine 13e, isocyanide 14a and enol 15, as a pale yellow
solid (122 mg, 48%); m.p. 114–116 ◦C; IR (cm−1) 3383, 2930, 2854, 1728, 1680, 1604, 1551, 1451,
1209, 1119, 1057, 759; 1H-NMR (500 MHz, CDCl3)
8.09 (dd, J = 6,99, 1.5 Hz, 1H), 7.64 (dt, J = 7.0,
1.4 Hz, 1H), 7.40–7.33 (m, 3H), 7.26–7.17 (m, 3H), 5.81 (d, J = 8.1 Hz, 1H), 5.70 (s, 1H), 4.23 (d, J =
δ

Molecules 2021, 26, 1287
10 of 18
18.3 Hz, 1H), 3.82–3.71 (m, 1H), 3,74 (d, J = 18.3 Hz, 1H), 3.66 (s, 3H), 2.32 (s, 3H), 1.95–1.54 (m,
5H), 1.38–0.95 (m, 5H); 13C-NMR (126 MHz, CDCl3)
δ 169.15 (C), 168.14 (C), 155.19 (C), 152.67
(C), 152.61 (C), 137.90 (C), 134.06 (CH), 132.85 (C), 131.83 (CH), 129.58 (CH), 128.33 (CH), 127.79
(CH), 126.85 (CH), 125.21 (CH), 118.07 (CH), 117.30 (C), 66.50 (CH), 52.62 (CH3), 51.42 (CH2),
49.00 (CH), 32.78 (CH2), 32.69 (CH2), 25.43 (CH2), 24.87 (CH2), 24.81 (CH2), 19.81 (CH3); MS
(qTOF) m/z (%) 508 (M+ + 1, 67), 319 (100); HRMS (qTOF) Calcd for C27H30N3O7: 508.2084.
Found: 508.2071.
Methyl N-(2-(cyclohexylamino)-2-oxo-1-(4-(trifluoromethyl)phenyl)ethyl)-N-(3-nitro-2-oxo-
2H-chromen-4-yl)glycinate (17n). Obtained from aldehyde 12d, amine 13e, isocyanide 14a
and enol 15, as a pale yellow solid (146 mg, 52%); m.p. 113–115 ◦C; IR (cm−1) 3368, 2933,
2855, 1734, 1605, 1554, 1325, 1169, 1127, 1069, 760; 1H-NMR (500 MHz, CDCl3)
δ 8.09 (dd, J
= 8.1, 1.3 Hz, 1H), 7.68–7.62 (m, 3H), 7.57 (d, J = 8.2 Hz, 2H), 7.43–7.37 (m, 2H), 5.98 (d, J =
8.1 Hz, 1H), 5.42 (s, 1H), 4.14 (d, J = 17.9 Hz, 1H), 3.80 (d, J = 17.9 Hz, 1H), 3.73–3.63 (m,
1H), 3.66 (s, 3H), 1.90 –0.92 (m, 10H); 13C-NMR (126 MHz, CDCl3)
δ 169.08, 166.89, 154.89,
152.76, 152.24, 138.60, 134.35, 132.66, 131.95, 131.69, 129.39, 127.70, 126.26, 125.47, 124.88,
122.71, 118.05, 117.39, 69.62, 52.62, 52.09, 49.17, 32.68, 32.63, 25.41, 24.83, 24.77; MS (qTOF)
m/z (%) 568 (M+ + 1, 100), 373 (25); HRMS (qTOF) Calcd for C27H27F3N3O7: 562.1801.
Found: 562.1793.
Methyl N-(2-(tert-butylamino)-2-oxo-1-phenylethyl)-N-(3-nitro-2-oxo-2H-chromen-4-yl)glycinate
(
17o). Obtained from aldehyde 12a, amine 13e, isocyanide 14b and enol 15, as a yellow solid
(140 mg, 60%); m.p. 139–141 ◦C; IR (cm−1) 3378, 2969, 1685, 1605, 1554, 1456, 1365, 1213, 759;
1H-NMR (500 MHz, CDCl3)
8.10 (dd, J = 8.1, 1.2 Hz, 1H), 7.62 (t, J = 7.0 Hz, 1H), 7.44–7.29
(m, 7H), 5.84 (bs, 1H), 5.31 (s, 1H), 4.16 (d, J = 18.1 Hz, 1H), 3.78 (d, J = 18.1 Hz, 1H), 3.65 (s,
3H), 1.25 (s, 9H); 13C-NMR (126 MHz, CDCl3)
169.19 (C), 167.67 (C), 155.18 (C), 152.70 (C),
δ
δ
152.65 (C), 134.63 (C), 134.04 (CH), 129.63 (CH), 129.36 (CH), 129.04 (C), 128.96 (CH), 128.70 (C),
128.00 (CH), 125.24 (CH), 117.90 (CH), 70.68 (CH), 52.51 (CH3), 52.21 (C), 51.89 (CH2), 28.78
(CH3), 28.72 (CH3), 28.47 (CH3); MS (qTOF) m/z (%) 468 (M+ + 1, 15), 279 (100); HRMS (qTOF)
Calcd for C24H26N3O7: 468.1771. Found: 468.1751.
Methyl N-(3-nitro-2-oxo-2H-chromen-4-yl)-N-(2-oxo-2-(pentylamino)-1-phenylethyl) glyci-
nate (17p). Obtained from aldehyde 12a, amine 13e, isocyanide 14c and enol 15, as a yellow
solid (92 mg, 38%); m.p. 72–74 ◦C; IR (cm−1) 3333, 2956, 1740, 1736, 1650, 1606, 1556, 1454,
1374, 1280, 1209, 1060, 761; 1H-NMR (500 MHz, CDCl3)
δ 8.11 (dd, J = 8.1, 1.3 Hz, 1H), 7.63
(dt, J = 6.2, 1.4 Hz, 1H), 7.42–7.35 (m, 7H), 5.95 (t, J = 5.5 Hz, 1H), 5.40 (s, 1H), 4.16 (d, J = 17.9
Hz, 1H), 3.81 (d, J = 18.0 Hz, 1H), 3.65 (s, 3H), 3.25–3.17 (m, 2H), 1.45–1.36 (m, 2H), 1.28–1.20
(m, 2H), 1.20–1.11 (m, 2H), 0.83 (t, J = 7.2 Hz, 3H); 13C-NMR (126 MHz, CDCl3)
δ 169.19
(C), 168.56 (C), 155.14 (C), 152.76 (C), 152.41 (C), 134.45 (C), 134.05 (CH), 129.75 (CH), 129.39
(CH), 129.06 (CH), 127.88 (CH), 125.34 (CH), 117.93 (CH), 117.60 (C), 70.23 (CH), 52.50 (CH3),
51.95 (CH2), 40.04 (CH2), 28.99 (CH2), 22.34 (CH2), 14.03 (CH3); MS (qTOF) m/z (%) 482 (M+
+ 1, 100), 395 (37); HRMS (qTOF) Calcd for C25H28N3O7: 482.1927. Found: 482.1916.
Methyl N-(2-(benzylamino)-2-oxo-1-phenylethyl)-N-(3-nitro-2-oxo-2H-chromen-4-yl)glycinate
(
17q). Obtained from aldehyde 12a, amine 13e, isocyanide 14d and enol 15, as a yellow solid
(118 mg, 47%); m.p. 145–147 ◦C; IR (cm−1) 3296, 2946, 1744, 1722, 1651, 1602, 1556, 1532,
1454, 1410, 1215, 1179, 1054, 759, 698; 1H-NMR (500 MHz, CDCl3)
8.10 (d, J = 7.2 Hz, 1H),
δ
7.62 (dt, J = 7.1, 1.4 Hz, 1H), 7.42–7.36 (m, 5H), 7.34 (d, J = 7.8 Hz, 2H), 7.27–7.23 (m, 3H),
7.08 (dd, J = 6.4, 3.0 Hz, 2H), 6.32 (t, J = 5.6 Hz, 1H), 5.47 (s, 1H), 4.38 (dd, J = 5.8, 1.3 Hz, 2H),
4.14 (d, J = 18.0 Hz, 1H), 3.81 (d, J = 18.0 Hz, 1H), 3.62 (s, 3H); 13C-NMR (126 MHz, CDCl3)
δ
1169.19 (C), 168.52 (C), 155.05 (C), 152.68 (C), 152.37 (C), 137.43 (C), 134.23 (C), 134.05 (CH),
129.82 (CH), 129.44 (CH), 129.07 (CH), 128.87 (CH), 127.81 (CH), 125.35 (CH), 117.93 (CH),
117.52 (C), 70.09 (CH), 52.49 (CH3), 51.93 (CH2), 43.97 (CH2); MS (qTOF) m/z (%) 502 (M+ +
1, 100), 415 (24), 299 (17); HRMS (qTOF) Calcd for C27H24N3O7: 502.1614. Found: 502.1602.
Methyl N-(2-(benzylamino)-2-oxo-1-(p-tolyl)ethyl)-N-(3-nitro-2-oxo-2H-chromen-4-yl)glycinate
(
17r). Obtained from aldehyde 12c, amine 13e, isocyanide 14d and enol 15, as a yellow solid
◦
(124 mg, 48%); m.p. 146–148 C; IR (cm−1) 3294, 1747, 1720, 1655, 1601, 1554, 1530, 1452, 1436,
1368, 1209, 1178, 1053, 794; 1H-NMR (500 MHz, CDCl3)
δ
8.05 (d, J = 7.4 Hz, 1H), 7.62 (t, J =

Molecules 2021, 26, 1287
11 of 18
7.3 Hz, 1H), 7.38–7.20 (m, 10H), 7.14–7.11 (m, 2H), 6.26 (t, J = 5.6 Hz, 1H), 5.78 (s, 1H), 4.41
(d, J = 5.9 Hz, 2H), 4.23 (d, J = 18.3 Hz, 1H), 3.74 (d, J = 18.3 Hz, 1H), 3.64 (s, 3H), 2.29 (s,
3H); 13C-NMR (126 MHz, CDCl3)
δ 169.11 (C), 169.04 (C), 155.06 (C), 152.66 (C), 152.49 (C),
137.93 (C), 137.51 (C), 134.03 (C), 132.57 (C), 131.89 (CH), 129.70 (CH), 128.92 (CH), 128.48
(CH), 127.87 (CH), 127.66 (CH), 126.9 (CH)3, 125.30 (CH), 118.09 (CH), 117.25 (C), 66.23 (CH),
52.58 (CH3), 51.45 (CH2), 44.00 (CH2), 19.77 (CH3); MS (qTOF) m/z (%) 516 (M+ + 1, 17), 429
(100), 299 (10); HRMS (qTOF) Calcd for C28H26N3O7: 516.1771. Found: 516.1782.
Ethyl3-((2-(cyclohexylamino)-2-oxo-1-phenylethyl)(3-nitro-2-oxo-2H-chromen-4-yl)amino)propanoate
(
17s). Obtained from aldehyde 12a, amine 13f, isocyanide 14a and enol 15, as a yellow solid (131
mg, 50%); m.p. 130–131 ◦C; IR (cm−1) 3367, 2931, 2854, 1732, 1682, 1603, 1553, 1451, 1200, 1052,
762; 1H-NMR (500 MHz, CDCl3)
8.05 (dd, J = 8.1, 1.2 Hz, 1H), 7.65 (d, J = 7,3, 1.3 Hz, 1H),
δ
7.45–7.34 (m, 7H), 5.99 (d, J = 8.0 Hz, 1H), 5.02 (s, 1H), 4.01 (q, J = 7.1 Hz, 2H), 3.83 (dt, J = 14.6,
7.2 Hz, 1H), 3.70–3.62 (m, 1H), 3.43–3.36 (m, 1H), 2.62 (dt, J = 17.0, 7.1 Hz, 1H), 2.44 (dt, J = 17.1,
6.2 Hz, 1H), 1.91 (d, J = 10.9 Hz, 1H), 1.75–1.52 (m, 5H), 1.36–1.16 (m, 3H), 1.13 (t, J = 9.0 Hz, 3H),
0.98 (ddd, J = 23.4, 12.1, 3.4 Hz, 1H); 13C-NMR (126 MHz, CDCl3)
δ 171.43 (C), 167.65 (C), 155.05
(C), 153.46 (C), 152.85 (C), 134.86 (C), 134.03 (CH), 132.08 (C), 129.61 (CH), 129.32 (CH), 128.97
(CH), 127.89 (CH), 125.25 (CH), 118.04 (C), 117.89 (CH), 70.02 (CH), 61.03 (CH2), 49.14 (CH), 47.30
(CH2), 32.63 (CH2), 32.54 (CH2), 32.52 (CH2), 27.05 (CH2), 25.49 (CH2), 24.94 (CH2), 24.83 (CH2),
14.12 (CH3); MS (qTOF) m/z (%) 522 (M+ + 1, 100), 481 (17), 333 (20); HRMS (qTOF) Calcd for
C28H32N3O7: 522.2240. Found: 522.2231.
3.4.3. General Procedure for the Reduction of Nitro Derivatives 17a–s
To a vigorously stirred solution of enol-Ugi adduct 17a–s (0.4 mmol) in glacial acetic
acid (8 mL), iron powder (9.6 mmol, 24 equiv) was added in one portion. The reaction
mixture was stirred at rt for 2–4 h. Then water (50 mL) and dichloromethane (25 mL)
were added. The unreacted iron was removed by filtration and the filtrate transferred to
a separatory funnel. The phases were separated, and the aqueous layer extracted again
with dichloromethane (25 mL). The combined organic extracts were washed with water
(25 mL), saturated NaHCO3 (10 mL) and water again (25 mL), and then dried (Na2SO4)
and evaporated to dryness. The residue was purified by flash column chromatography
(SiO2, gradient from 100 % hexanes to hexanes–AcOEt 7:3) to give, depending on the case,
chromeno[3,4-b]piperazines 19a
20l–r (Tables 1 and 2).
–i,s, aminocoumarins 18j,k or chromeno[3,4-b]piperazines
Synthesis and Characterization of chromeno[3,4-b]piperazines 19a–i,s
1-Benzyl-2-phenyl-1,4-dihydro-2H-chromeno[3,4-b]pyrazine-3,5-dione (19a). Obtained from
◦
17a as a pale yellow solid (130 mg, 85%); m.p. 183–185 C; IR (cm−1) 3254, 1677, 1620,
1567, 1495, 1465, 1427, 1357, 1182, 1101, 1046, 746, 701; 1H-NMR (500 MHz, CDCl3)
δ 7.98
(dd, J = 8.0, 1.3 Hz, 1H), 7.84 (bs, 1H), 7.53 (dt, J = 7.3, 1.5 Hz, 1H), 7.41 (t, J = 7.3 Hz, 2H),
7.39–7.30 (m, 8H), 7.28–7.23 (m, 2H), 4.98 (s, 1H), 4.87 (d, J = 15.2 Hz, 1H), 4.71 (d, J = 15.2
Hz, 1H); 13C-NMR (126 MHz, CDCl3)
δ 163.37 (C), 156.63 (C), 150.85 (C), 135.88 (C), 135.67
(C), 130.46 (CH), 129.33 (CH), 129.02 (CH), 128.75 (CH), 128.47 (CH), 127.93 (CH), 126.04
(CH), 125.15 (CH), 123.34 (CH), 118.01 (CH), 116.55 (C), 112.25 (C), 63.91 (CH), 58.03 (CH2);
HRMS (qTOF) Calcd for C24H19N2O3: 383.1396. Found: 383.1381.
1-Benzyl-2-(2-bromophenyl)-1,4-dihydro-2H-chromeno[3,4-b]pyrazine-3,5-dione (19b). Ob-
tained from 17b as a pale yellow solid (155 mg, 84%); m.p. 240–242 ◦C; IR (cm−1) 3195,
1
3085, 2938, 1700, 1688, 1625, 1495, 1467, 1392, 1346, 1094, 755, 699; H-NMR (500 MHz,
CDCl3)
= 6.9, 1.3 Hz, 1H), 7.41–7.28 (m, 5H), 7.20–7.10 (m, 4H), 7.04 (dd, J = 7.5, 1.8 Hz, 1H), 5.33
(s, 1H), 5.03 (d, J = 14.7 Hz, 1H), 4.87 (d, J = 14.7 Hz, 1H); 13C-NMR (126 MHz, CDCl3)
δ 7.89 (bs, 1H), 7.74 (dd, J = 8.0, 1.1 Hz, 1H), 7.61 (dd, J = 7.7, 1.3 Hz, 1H), 7.48 (dt, J
δ
162.69 (C), 156.79 (C), 150.85 (C), 136.26 (C), 135.91 (C), 135.69 (C), 133.90 (CH), 130.47 (CH),
130.30 (CH), 129.21 (CH), 128.91 (CH), 128.33 (CH), 128.16 (CH), 128.08 (CH), 124.93 (CH),
124.53 (C), 124.12 (CH), 117.82 (CH), 116.47 (C), 111.90 (C), 64.07 (CH2), 59.43 (CH); HRMS
(qTOF) Calcd for C24H18BrN2O3: 461.0501. Found: 461.0473.

Molecules 2021, 26, 1287
12 of 18
1-Benzyl-2-(p-tolyl)-1,4-dihydro-2H-chromeno[3,4-b]pyrazine-3,5-dione (19c). Obtained
◦
from 17c as a white solid (124 mg, 78%); m.p. 170–172 C; IR (cm−1) 3396, 3272, 1692, 1619,
1
1495, 1363, 1206, 1113, 755; H-NMR (500 MHz, CDCl3)
δ 7.96 (dd, J = 8.0, 1.3 Hz, 1H),
7.79 (bs, 1H), 7.52 (dt, J = 7.4, 1.4 Hz, 1H), 7.43–7.30 (m, 7H), 7.23 (d, J = 8.1 Hz, 2H), 7.06
(d, J = 8.0 Hz, 2H), 4.93 (s, 1H), 4.86 (d, J = 15.2 Hz, 1H), 4.69 (d, J = 15.2 Hz, 1H), 2.26 (s,
3H); 13C-NMR (126 MHz, CDCl3)
δ 163.50 (C), 156.63 (C), 150.86 (C), 138.32 (C), 135.97
(C), 135.86 (C), 132.76 (C), 130.38 (CH), 129.71 (CH), 129.32 (CH), 128.71 (CH), 127.95 (CH),
125.99 (CH), 125.09 (CH), 123.37 (CH), 117.98 (CH), 116.65 (C), 112.29 (C), 63.79 (CH), 57.99
(CH2), 21.12 (CH3); MS (qTOF) m/z (%) 397 (M+ + 1, 100), 337 (30); HRMS (qTOF) Calcd
for C25H21N2O3: 397.1552. Found: 397.1544.
1-Benzyl-2-(4-(trifluoromethyl)phenyl)-1,4-dihydro-2H-chromeno[3,4-b]pyrazine-3,5-dione (19d).
Obtained from 17d as a pale yellow solid (160 mg, 89%); m.p. 172–174 ◦C; IR (cm−1) 3438,
3260, 1684, 1620, 1498, 1469, 1414, 1361, 1327, 1169, 1115, 1069, 752, 732; 1H-NMR (500 MHz,
CDCl3)
7.39–7.30 (m, 5H), 5.02 (s, 1H), 4.84 (d, J = 15.1 Hz, 1H), 4.70 (d, J = 15.1 Hz, 1H); 13C-NMR
(126 MHz, CDCl3) 162.77 (C), 156.50 (C), 150.88 (C), 139.60 (C), 135.56 (C), 135.42 (C), 130.73
δ 7.99 (d, J = 6.8 Hz, 1H), 7.84 (bs, 1H), 7.57–7.48 (m, 5H), 7.44 (d, J = 8.5 Hz, 2H),
δ
(CH), 129.45 (CH), 128.97 (CH), 128.00 (CH), 126.53 (CH), 126.06 (CH), 126.03 (C), 125.38 (CH),
123.11 (CH), 118.16 (CH), 116.42 (C), 112.72 (C), 63.64 (CH), 58.15 (CH2); MS (qTOF) m/z
(%) 451 (M+ + 1, 95), 391 (100); HRMS (qTOF) Calcd for C25H18F3N2O3: 451.1270. Found:
451.1264.
1-(Benzo[d][1,3]dioxol-5-ylmethyl)-2-phenyl-1,4-dihydro-2H-chromeno[3,4-b]pyrazine-3,5-dione
(
19e). Obtained from 17e as a pale yellow solid (147 mg, 86%); m.p. 174–176 ◦C; IR (cm−1
)
3264, 1692, 1626, 1500, 1445, 1375, 1354, 1319, 1253, 1180, 1106, 1039, 926, 851, 747, 704; 1H-
NMR (500 MHz, CDCl3) 7.97 (d, J = 4.0 Hz, 1H), 7.95 (d, J = 1.2 Hz, 1H), 7.53 (dt, J = 7.0 Hz,
δ
1.4 Hz, 1H), 7.41 (d, J = 7.8 Hz, 2H), 7.36 (dd, J = 7.0, 1.5 Hz, 2H), 7.28–7.22 (m, 3H), 6.80–6.75
(m, 3H), 5.96 (s, 2H), 5.00 (s, 1H), 4.79 (d, J = 14.9 Hz, 1H), 4.59 (d, J = 14.9 Hz, 1H); 13C-NMR
(126 MHz, CDCl3) δ 163.44 (C), 156.59 (C), 150.80 (C), 148.52 (C), 148.02 (C), 135.73 (C), 135.65
(C), 130.41 (CH), 129.55 (C), 128.99 (CH), 128.42 (CH), 125.99 (CH), 125.09 (CH), 123.32 (CH),
121.76 (CH), 117.98 (CH), 116.48 (C), 112.21 (C), 108.78 (CH), 108.06 (CH), 101.46 (CH2), 63.46
(CH), 57.69 (CH2); MS (qTOF) m/z (%) 427 (M+ + 1, 100), 427 (15), 274 (18); HRMS (qTOF)
Calcd for C25H19N2O5: 427.1294. Found: 427.1293.
1-(Benzo[d][1,3]dioxol-5-ylmethyl)-2-(p-tolyl)-1,4-dihydro-2H-chromeno[3,4-b]pyrazine-3,5-
dione (19f). Obtained from 17f as a pale yellow solid (151 mg, 86%); m.p. 213–215 ◦C; IR
(cm−1) 3408, 3192, 1715, 1677, 1625, 1502, 1419, 1326, 1298, 1109, 1036, 805, 751; 1H-NMR
(500 MHz, CDCl3)
δ 7.93 (dd, J = 8.0, 1.2 Hz, 1H), 7.76 (bs, 1H), 7.52 (dt, J = 7.3, 1.5 Hz, 1H),
7.43–7.36 (m, 2H), 7.23 (d, J = 8.0 Hz, 2H), 7.06 (d, J = 8.0 Hz, 2H), 6.77 (d, J = 0.8 Hz, 2H),
6.76 (s, 1H), 5.96 (d, J = 0.9 Hz, 2H), 4.94 (s, 1H), 4.77 (d, J = 14.9 Hz, 1H), 4.57 (d, J = 14.9 Hz,
1H); 13C-NMR (126 MHz, CDCl3)
δ 163.52 (C), 156.64 (C), 150.85 (C), 148.57 (C), 148.06 (C),
138.34 (C), 135.77 (C), 132.68 (C), 130.42 (CH), 129.73 (CH), 129.64 (C), 125.94 (CH), 125.09
(CH), 123.38 (CH), 121.78 (CH), 118.02 (CH), 116.57 (C), 112.16 (C), 108.82 (CH), 108.08
(CH), 101.50 (CH2), 63.35 (CH), 57.69 (CH2), 21.14 (CH3); MS (qTOF) m/z (%) 441 (M+ + 1,
100), 400 (20), 281(30); HRMS (qTOF) Calcd for C26H21N2O5: 441.4630. Found: 441.1449.
1-(Benzo[d][1,3]dioxol-5-ylmethyl)-2-(4-(trifluoromethyl)phenyl)-1,4-dihydro-2H-chromeno[3,4-
b]pyrazine-3,5-dione (19g). Obtained from 17g as a pale yellow solid (148 mg, 75%); m.p. 190-192
◦
C; IR (cm−1) 3080, 2918, 1685, 1619, 1493, 1412, 1329, 1241, 1114, 1068, 1041, 998, 756; 1H-NMR
(500 MHz, CDCl3) 7.96 (dd, J = 6.8, 1.6 Hz, 1H), 7.81 (bs, 2H), 7.58–7.48 (m, 5H), 7.46–7.41 (m,
2H), 6.80–6.75 (m, 3H), 5.97 (dd, J = 2.5, 1.3 Hz, 2H), 5.03 (s, 1H), 4.75 (d, J = 14.8 Hz, 1H), 4.58
(d, J = 14.8 Hz, 1H); 13C-NMR (126 MHz, CDCl3)
162.80 (C), 156.49 (C), 150.87 (C), 148.71
δ
δ
(C), 148.29 (C), 139.61 (C), 135.30 (C), 130.72 (CH), 129.22 (C), 126.51 (CH), 126.07 (CH), 126.04
(CH), 125.35 (CH), 123.11 (CH), 121.91 (CH), 118.18 (CH), 116.38 (C), 112.69 (C), 108.92 (CH),
108.10 (CH), 101.59 (CH2), 63.28 (CH), 57.89 (CH2); MS (qTOF) m/z (%) 495 (M+ + 1, 100), 339
(30), 353 (65); HRMS (qTOF) Calcd for C26H18F3N2O5: 495.1168. Found: 495.1157.
1-Cyclohexyl-2-(p-tolyl)-1,4-dihydro-2H-chromeno[3,4-b]pyrazine-3,5-dione (19h). Obtained
◦
from 17h as a pale yellow solid (107 mg, 69%); m.p. 249–251 C; IR (cm−1) 3444, 2931, 2853,

Molecules 2021, 26, 1287
13 of 18
1692, 1622, 1495, 1406, 1335, 1102, 999, 757; 1H-NMR (500 MHz, CDCl3)
δ
7.90 (bs, 1H), 7.74
(dd, J = 7.9, 1.4 Hz, 1H), 7.49 (dt, J = 6.0, 1.5 Hz, 1H), 7.42–7.36 (m, 2H), 7.28 (d, J = 8.0 Hz,
2H), 7.05 (d, J = 8.0 Hz, 2H), 5.17 (s, 1H), 3.77 (tt, J = 12.0, 3.7 Hz, 1H), 2.31 (d, J = 13.3 Hz,
1H), 2.25 (s, 3H), 1.95 (d, J = 13.2 Hz, 1H), 1.83–1.09 (m, 8H); 13C-NMR (126 MHz, CDCl3)
δ
164.43 (C), 156.66 (C), 150.87 (C), 138.08 (C), 136.15 (CH), 133.12 (C), 130.15 (C), 129.60 (CH),
125.84 (CH), 124.98 (CH), 123.36 (CH), 117.92 (CH), 117.05 (C), 112.33 (C), 62.44 (CH), 58.98
(CH), 31.92 (CH3), 31.76 (CH3), 26.07 (CH3), 25.98 (CH3), 25.24 (CH3), 21.10 (CH3); MS
(qTOF) m/z (%) 389 (M+ + 1, 100), 348 (31), 255 (29); HRMS (qTOF) Calcd for C24H25N2O3:
389.1865. Found: 389.1866.
1-Cyclohexyl-2-(4-(trifluoromethyl)phenyl)-1,4-dihydro-2H-chromeno[3,4-b]pyrazine-3,5-dione
(
19i). Obtained from 17i as a pale yellow solid (127 mg, 72%); m.p. 113–115 ◦C; IR (cm−1
)
3427, 2932, 2856, 1692, 1622, 1411, 1326, 1165, 1125, 1069, 755; 1H-NMR (500 MHz, CDCl3)
8.00 (bs, 1H), 7.75 (dd, J = 7.9, 1.2 Hz, 1H), 7.57–7.50 (m, 6H), 7.45–7.36 (m, 2H), 5.24 (s,
1H), 3.79 (tt, J = 12.0, 3.6 Hz, 1H), 2.30 (d, J = 12.6 Hz, 1H), 1.96 (d, J = 13.1 Hz, 1H), 1.85–1.58
(m, 5H), 1.29–1.11 (m, 3H); 13C-NMR (126 MHz, CDCl3)
163.73 (C), 156.52 (C), 150.91
δ
δ
(C), 140.21 (C), 135.73 (C), 130.46 (CH), 126.42 (CH), 125.96 (CH), 125.93 (CH), 125.20 (CH),
123.11 (CH), 118.10 (CH), 116.80 (C), 112.54 (C), 62.62 (CH), 59.06 (CH), 31.86 (CH2), 31.73
(CH2), 27.07 (CH2), 25.95 (CH2), 25.21 (CH2); MS (qTOF) m/z (%) 443 (M+ + 1, 100), 301 (<5);
HRMS (qTOF) Calcd for C24H22F3N2O3: 443.1583. Found: 443.1578.
Ethyl 3-(3,5-dioxo-2-phenyl-3,4-dihydro-2H-chromeno[3,4-b]pyrazin-1(5H)-yl)propanoate
(
19s). Obtained from 17s as a white solid (133 mg, 85%); m.p. 145–147 ◦C; IR (cm−1) 3231,
1733, 1680, 1619, 1498, 1460, 1372, 1188, 1126, 1021, 757; 1H-NMR (500 MHz, CDCl3)
δ 7.99
(s, 1H), 7.89 (dd, J = 7.9, 1.1 Hz, 1H), 7.52 (dt, J = 7.3, 1.2 Hz, 1H), 7.43–7.36 (m, 4H), 7.29–7.24
(m, 3H), 5.09 (s, 1H), 4.17–4.06 (m, 3H), 3.89 (ddd, J = 14.7, 8.2, 6.4 Hz, 1H), 2.79 (ddd, J =
14.6, 8.1, 6.4 Hz, 1H), 2.73–2.63 (m, 1H), 1.19 (t, J = 7.1 Hz, 3H); 13C-NMR (126 MHz, CDCl3)
δ
170.71 (C), 163.61 (C), 156.53 (C), 150.72 (C), 135.51 (C), 135.15 (C), 130.45 (CH), 129.06
(CH), 128.57 (CH), 125.81 (CH), 125.15 (CH), 123.39 (CH), 117.98 (CH), 116.43 (C), 112.23
(C), 64.73 (CH), 61.31 (CH2), 50.18 (CH2), 33.96 (CH2), 14.15 (CH3); HRMS (qTOF) Calcd
for C22H21N2O5: 393.1450. Found: 393.1444.
Synthesis and Characterization of Aminocoumarins 18j,k
2-((3-Amino-2-oxo-2H-chromen-4-yl)(phenyl)amino)-N-cyclohexyl-2-phenylacetamide (18j).
Obtained from 17j as a white solid (99 mg, 53%); m.p. 203–205 ◦C; IR (cm−1) 3466, 2933,
2852, 1719, 1635, 1600, 1556, 1497, 1455, 1177, 746; 1H-NMR (500 MHz, CDCl3)
δ 7.27–7.18
(m, 4H), 7.11–7.05 (m, 3H), 7.04–6.96 (m, 4H), 6.83 (t, J = 7.3 Hz, 1H), 6.64 (d, J = 8.1 Hz,
2H), 6.21 (bs, 2H), 5.65 (d, J = 8.1 Hz, 1H), 5.51 (s, 1H), 3.93–3.83 (m, 1H), 2.15–0.92 (m,
10H); 13C-NMR (126 MHz, CDCl3)
δ 171.49 (C), 160.18 (C), 147.29 (C), 145.30 (C), 134.85 (C),
132.81 (C), 129.70 (CH), 129.48 (CH), 129.42 (CH), 128.12 (CH), 125.71 (CH), 123.94 (CH),
122.65 (CH), 121.88 (C), 119.66 (C), 118.93 (CH), 115.93 (CH), 112.72 (CH), 68.52 (CH), 49.44
(CH), 33.19 (CH2), 32.69 (CH2), 25.55 (CH2), 24.98 (CH2), 24.84 (CH2); MS (qTOF) m/z (%)
468 (M+ + 1, 5, 407 (18), 369 (100); HRMS (qTOF) Calcd for C29H30N3O3: 468.2287. Found:
468.2285.
2-((3-Amino-2-oxo-2H-chromen-4-yl)(phenyl)amino)-N-cyclohexyl-2-(3,4-dimethoxyphenyl)
acetamide (18k). Obtained from 17k as a white solid (163 mg, 77%); m.p. 243–245 ◦C; IR
(cm−1) 3439, 3326, 2938, 2850, 1715, 1637, 1599, 1539, 1518, 1464, 1253, 1176, 1152, 1028, 763,
749; 1H-NMR (500 MHz, CDCl3)
δ 7.20 (t, J = 7.9 Hz, 2H), 7.11–7.06 (m, 2H), 6.98 (d, J = 3.5
Hz, 2H), 6.82–6.78 (m, 2H), 6.74 (s, 1H), 6.61 (d, J = 8.2 Hz, 2H), 6.50 (d, J = 8.3 Hz, 1H), 6.20
(bs, 2H), 5.60 (d, J = 8.1 Hz, 1H), 5.44 (s, 1H), 3.90–3.80 (m, 1H), 3.71 (s, 3H), 3.52 (s, 3H),
2.08–0.79 (m, 10H); 13C-NMR (126 MHz, CDCl3)
δ 171.68 (C), 160.15 (C), 149.69 (C), 148.24
(C), 147.43 (C), 145.24 (C), 134.75 (C), 129.71 (CH), 125.75 (CH), 124.96 (CH), 123.95 (CH),
122.57 (CH), 121.99 (C), 119.86 (CH), 118.89 (CH), 116.26 (CH), 112.65 (CH), 110.32 (CH),
68.09 (CH), 55.87 (CH3), 55.79 (CH3), 49.43 (CH), 33.21 (CH2), 32.77 (CH2), 29.84 (CH2),
24.98 (CH2), 24.86 (CH2); MS (qTOF) m/z (%) 528 (M+ + 1, 100), 369 (25), 276 (13); HRMS
(qTOF) Calcd for C31H34N3O5: 528.2498. Found: 528.2490.

Molecules 2021, 26, 1287
14 of 18
Synthesis and Characterization of chromeno[3,4-b]piperazines 20l-r
N-cyclohexyl-2-(3,5-dioxo-3,4-dihydro-2H-chromeno[3,4-b]pyrazin-1(5H)-yl)-2-phenyl ac-
etamide (20l). Obtained from 17l as a pale yellow solid (121 mg, 70%); m.p. 240–242 ◦C; IR
(cm−1) 3268, 2931, 2854, 1703, 1818, 1544, 1496, 1451, 1382, 1111, 752; 1H-NMR (500 MHz,
CDCl3)
(m, 4H), 7.34–7.29 (m, 3H), 5.79 (d, J = 8.0 Hz, 1H), 5.37 (s, 1H), 3.98–3.90 (m, 1H), 3.92 (s,
3H), 2.03–1.90 (m, 2H), 1.74–1.57 (m, 4H), 1.45–1.07 (m, 4H.; 13C-NMR (126 MHz, CDCl3)
δ 7.63 (dd, J = 8.0, 1.2 Hz, 1H), 7.54 (bs, 1H), 7.51 (dt, J = 7.1, 1.4 Hz, 1H), 7.43–7.39
δ
167.85 (C), 163.00 (C), 156.92 (C), 150.63 (C), 135.72 (C), 135.01 (C), 130.32 (CH), 129.52 (CH),
128.50 (CH), 125.06 (CH), 122.96 (CH), 118.02 (CH), 116.33 (C), 114.08 (C), 69.14 (CH), 49.49
(CH2), 49.05 (CH), 33.17 (CH2), 33.10 (CH2), 25.51 (CH2), 24.89 (CH2), 24.85 (CH2); MS
(qTOF) m/z (%) 432 (M+ + 1, 100), 305 (<5), 234 (<5); HRMS (qTOF) Calcd for C25H26N3O4:
432.1923. Found: 432.1914.
N-cyclohexyl-2-(3,5-dioxo-3,4-dihydro-2H-chromeno[3,4-b]pyrazin-1(5H)-yl)-2-(p-tolyl)
acetamide (20m). Obtained from 17m as a pale yellow solid (98 mg, 55%); m.p. 245–247 ◦C
(dec.); IR (cm−1) 3400, 3280, 2930, 2849, 1701, 1651, 1618, 1561, 1439, 1412, 1347, 1108, 751,
732; 1H-NMR (500 MHz, CDCl3)
δ 7.67 (bs, 1H), 7.47 (t, J = 7.2 Hz, 1H), 7.44–7.37 (m, 3H),
7.35–7.31 (m, 2H), 7.26–7.19 (m, 2H), 5.72 (d, J = 8.1 Hz, 1H), 5.59 (s, 1H), 4.09 (d, J = 16.7 Hz,
1H), 3.98 (d, J = 16.7 Hz, 1H), 3.95–3.87 (m, 1H), 1.98–0.95 (m, 10H); 13C-NMR (126 MHz,
CDCl3)
δ 168.26 (C), 162.61 (C), 156.91 (C), 150.61 (C), 137.43 (C), 136.82 (C), 133.84 (C),
131.87 (CH), 130.36 (CH), 129.58 (CH), 128.28 (CH), 127.23 (CH), 124.88 (CH), 123.08 (CH),
118.05 (CH), 116.39 (C), 111.84 (C), 67.33 (CH), 49.97 (CH), 49.08 (CH2), 33.00 (CH2), 25.47
(CH2), 24.81 (CH2), 19.44 (CH3); MS (qTOF) m/z (%) 446 (M+ + 1, 11), 319 (100); HRMS
(qTOF) Calcd for C26H28N3O4: 446.2080. Found: 446.2074.
N-cyclohexyl-2-(3,5-dioxo-3,4-dihydro-2H-chromeno[3,4-b]pyrazin-1(5H)-yl)-2-(4-(trifluoromethyl)
◦
phenyl)acetamide (20n). Obtained from 17n as a pale yellow solid (162 mg, 81%); m.p. 249–251 C
(dec.); IR (cm−1) 3313, 3266, 2930, 2855, 1704, 1688, 1620, 1549, 1497, 1487, 1326, 1167, 1126, 1068,
824, 1H-NMR (500 MHz, CDCl3)
δ 7.68 (d, J = 8.2 Hz, 1H), 7.60 (bs, 1H), 7.58 (dd, J = 8.1, 1.2 Hz,
1H), 7.53 (t, J = 7.8 Hz, 1H), 7.45–7.34 (m, 3H), 7.39–7.34 (m, 1H), 5.88 (d, J = 4.7 Hz, 1H), 5.37 (s,
1H), 3.98–3.88 (m, 1H), 3.91 (d, J = 2.9 Hz, 2H), 2.04–1.09 (m, 10H); 13C-NMR (126 MHz, CDCl3)
δ
167.11 (C), 162.84 (C), 156.76 (C), 150.56 (C), 138.72 (C), 134.97 (C), 130.56 (CH), 128.98 (CH),
127.12 (C), 126.43 (CH), 125.26 (CH), 122.53 (CH), 118.18 (CH), 116.04 (C), 114.70 (C), 68.39 (CH),
49.41 (CH2), 49.20 (CH), 33.18 (CH2), 33.11 (CH2), 25.44 (CH2), 24.88 (CH2); MS (qTOF) m/z
(%) 522 (M+ + Na+, 100), 500 (M+ + 1, 54), 429 (10); HRMS (qTOF) Calcd for C26H25F3N3O4:
500.1797. Found: 500.1782.
N-(tert-butyl)-2-(3,5-dioxo-3,4-dihydro-2H-chromeno[3,4-b]pyrazin-1(5H)-yl)-2-phenylacetamide
◦
−1
)
(
20o). Obtained from 17o as a pale yellow solid (94 mg, 58%); m.p. 258–260 C (dec.); IR (cm
3328, 3269, 2966, 2931, 1680, 1619, 1561, 1496, 1466, 1365, 1288, 1111, 750; 1H-NMR (500 MHz,
CDCl3) .59 (dd, J = 8.0, 1.2 Hz, 1H), 7.53–7.49 (m, 2H), 7.44–7.40 (m, 4H), 7.34–7.29 (m, 3H),
5.71 (bs, 1H), 5.31 (s, 1H), 3.96 (q, J = 16.9 Hz, 2H), 1.41 (s, 9H); 13C-NMR (126 MHz, CDCl3)
δ
δ
168.11 (C), 163.00 (C), 156.94 (C), 150.63 (C), 135.98 (C), 135.19 (C), 130.34 (CH), 129.54 (CH),
129.50 (CH), 128.40 (CH), 125.04 (CH), 123.00 (CH), 118.01 (CH), 116.32 (C), 113.75 (C), 69.53
(CH), 52.50 (C), 49.54 (CH2), 28.85 (CH3); MS (qTOF) m/z (%) 406 (M+ + 1, 60), 321 (27), 279
(100); HRMS (qTOF) Calcd for C23H24N3O4: 406.1767. Found: 406.1761.
2-(3,5-Dioxo-3,4-dihydro-2H-chromeno[3,4-b]pyrazin-1(5H)-yl)-N-pentyl-2-phenylacetamide
(20p). Obtained from 17p as a white solid (92 mg, 55%); m.p. 206–208 ◦C (dec.); IR (cm−1
)
3310, 3276, 2929, 1687, 1616, 1567, 1496, 1471, 1380, 1115, 999, 931, 748, 726; 1H-NMR (500
MHz, CDCl3) 7.63 (dd, J = 8.0, 1.2 Hz, 1H), 7.51 (dt, 6.9, J = 1.3 Hz, 2H), 7.43–7.37 (m, 4H),
δ
7.35–7.28 (m, 4H), 6.04 (t, J = 5.4 Hz, 1H), 5.39 (s, 1H), 3.92 (d, J = 1.7 Hz, 2H), 3.37 (dd, J =
13.2, 7.0 Hz, 2H), 1.57–1.50 (m, 2H), 1.37–1.25 (m, 4H), 0.90 (t, J = 7.1 Hz, 3H); 13C-NMR
(126 MHz, CDCl3)
δ 168.65 (C), 162.80 (C), 156.78 (C), 150.47 (C), 135.51 (C), 134.77 (C),
130.21 (CH), 129.44 (CH), 129.39 (CH), 128.38 (CH), 124.94 (CH), 122.83 (CH), 117.87 (CH),
116.16 (C), 114.07 (C), 69.04 (CH), 49.40 (CH2), 40.00 (CH2), 29.19 (CH2), 29.04 (CH2), 22.27
(CH2), 13.97 (CH3); MS (qTOF) m/z (%) 420 (M+ + 1, 14), 293 (100); HRMS (qTOF) Calcd
for C24H26N3O4: 420.1923. Found: 420.1918.

Molecules 2021, 26, 1287
15 of 18
N-benzyl-2-(3,5-dioxo-3,4-dihydro-2H-chromeno[3,4-b]pyrazin-1(5H)-yl)-2-phenylacetamide
◦
−1
)
(
20q). Obtained from 17q as a white solid (118 mg, 67%); m.p. 238–240 C (dec.); IR (cm
3280, 1686, 1618, 1496, 1379, 1113, 751, 700; 1H-NMR (500 MHz, CDCl3)
δ
7.59 (dd, J = 8.0,
1.1 Hz, 1H), 7.52–7.44 (m, 2H), 7.42–7.33 (m, 6H), 7.33–7.25 (m, 6H), 6.33 (t, J = 5.5 Hz, 1H),
5.42 (s, 1H), 4.56 (qd, J = 14.6, 5.8 Hz, 2H), 3.92 (d, J = 1.7 Hz, 2H); 13C-NMR (126 MHz,
CDCl3)
δ 168.90 (C), 162.97 (C), 156.87 (C), 150.57 (C), 137.66 (C), 135.55 (C), 134.61 (C),
130.39 (CH), 129.63 (CH), 129.52 (CH), 129.06 (CH), 128.55 (CH), 128.06 (CH), 128.01 (CH),
125.10 (CH), 122.89 (CH), 118.00 (CH), 116.18 (C), 114.29 (C), 69.11 (CH), 49.43 (CH2), 44.15
(CH2); MS (qTOF) m/z (%) 440 (M+ + 1, 100), 282 (40), 169 (15); HRMS (qTOF) Calcd for
C26H22N3O4: 440.1610. Found: 440.1585.
N-benzyl-2-(3,5-dioxo-3,4-dihydro-2H-chromeno[3,4-b]pyrazin-1(5H)-yl)-2-(p-tolyl)acetamide
(
20r). Obtained from 17r as a white solid (141 mg, 78%); m.p. 221–223 ◦C (dec.); IR (cm−1
)
3369, 1711, 1665, 1649, 1559, 1495, 1113, 754, 703; 1H-NMR (500 MHz, CDCl3)
δ 7.79 (bs, 1H),
7.58 (dt, J = 7.2, 1.2 Hz, 1H), 7.54 (dd, J = 8.1, 1.2 Hz, 1H), 7.51–7.54 (m, 5H), 7.42–7.38 (m, 5H),
7.36–7.23 (m, 2H), 6.38 (t, J = 6.4 Hz, 1H), 5.79 (s, 1H), 4.75 (dd, J = 14.6, 6.2 Hz, 1H), 4.57 (dd,
J = 14.6, 5.5 Hz, 1H), 4.21 (d, J = 16.7 Hz, 1H), 4.09 (d, J = 16.7 Hz, 1H), 2.14 (s, 3H); 13C-NMR
(126 MHz, CDCl3) δ 169.46 (C), 162.69 (C), 156.85 (C), 150.57 (C), 137.65 (C), 137.27 (C), 136.89
(C), 133.46 (C), 131.91 (CH), 130.43 (CH), 129.69 (CH), 129.06 (CH), 128.65 (CH), 128.12 (CH),
128.06 (CH), 127.18 (CH), 124.95 (CH), 123.05 (CH), 118.07 (CH), 116.26 (C), 112.10 (C), 66.93
(CH), 49.79 (CH2), 44.24 (CH2), 19.44 (CH3); MS (qTOF) m/z (%) 454 (M+ + 1, 27), 369 (73),
327 (100); HRMS (qTOF) Calcd for C27H24N3O4: 454.1767. Found: 454.1761.
3.4.4. General Procedure for the Synthesis of Chromeno[3,4-b]piperazines 19j,k
Enol-Ugi adduct 17j–k (0.4 mmol) and iron powder (9.6 mmol, 24 equiv) in glacial
acetic acid (8 mL), were subjected to a procedure identical to the one used for the reduction
◦
of nitro derivatives 17a
b]piperazines 19j
–
s
, except that the reaction was performed at 150 C. Chromeno[3,4-
,
k
were obtained after flash column chromatography purification (SiO2,
gradient from 100 % hexanes to hexanes–AcOEt, 7:3).
1,2-Diphenyl-1,4-dihydro-2H-chromeno[3,4-b]pyrazine-3,5-dione (19j). Obtained from 18j
as a pale yellow solid (103 mg, 70%); m.p. 243–245 ◦C; IR (cm−1) 3423, 3075, 1716, 1679,
1631, 1492, 1470, 1407, 1369, 1234, 1131, 998, 754, 593; 1H-NMR (500 MHz, CDCl3)
δ 8.15
(bs, 1H), 7.51 (dd, J = 6.3, 1.7 Hz, 2H), 7.43–7.30 (m, 7H), 7.22 (t, J = 7.4 Hz, 1H), 7.15 (dd, J =
8.1, 1.2 Hz, 1H), 7.09 (d, J = 8.0 Hz, 2H), 7.06 (d, J = 7.3 Hz, 1H), 5.64 (s, 1H); 13C-NMR (126
MHz, CDCl3) δ 162.88 (C), 156.74 (C), 150.88 (C), 145.76 (C), 135.81 (C), 131.77 (C), 130.07
(CH), 130.00 (CH), 129.41 (CH), 128.86 (CH), 125.89 (CH), 125.63 (CH), 124.99 (CH), 124.40
(CH), 122.53 (CH), 117.80 (CH), 115.63 (C), 111.31 (C), 69.02 (CH); MS (qTOF) m/z (%) 369
(M+ + 1, 100), 288 (<5); HRMS (qTOF) Calcd for C23H17N2O3: 369.1239. Found: 369.1228.
2-(3,4-Dimethoxyphenyl)-1-phenyl-1,4-dihydro-2H-chromeno[3,4-b]pyrazine-3,5-dione (19k).
Obtained from 18k as a pale yellow solid (120 mg, 70%); m.p. 209–211 ◦C; IR (cm−1) 3423,
1
3072, 1712, 1678, 1632, 1604, 1514, 1403, 1260, 1140, 1024, 999, 757; H-NMR (500 MHz,
CDCl3)
1H), 7.12–7.04 (m, 4H), 6.98 (dd, J = 8.4, 2.1 Hz, 1H), 6.79 (d, J = 8.4 Hz, 1H), 5.59 (s, 1H),
3.83 (s, 3H), 3.72 (s, 3H); 13C-NMR (126 MHz, CDCl3)
163.24 (C), 156.70 (C), 150.79 (C),
δ 8.12 (bs, 1H), 7.44–7.31 (m, 4H), 7.22 (t, J = 7.4 Hz, 1H), 7.15 (dd, J = 8.1, 1.1 Hz,
δ
149.64 (C), 149.40 (C), 145.48 (C), 131.68 (C), 130.10 (CH), 129.97 (CH), 127.65 (C), 125.76
(CH), 124.73 (CH), 124.35 (CH), 122.25 (CH), 117.86 (CH), 117.44 (CH), 115.53 (C), 111.63
(CH), 111.28 (C), 108.67 (CH), 68.31 (CH), 56.07 (CH3), 55.91 (CH3); MS (qTOF) m/z (%) 429
(M+ + 1, 75), 369 (100), 276 (45); HRMS (qTOF) Calcd for C25H21N2O5: 429.1450. Found:
429.1454.
4. Conclusions
Multicomponent functionalization of 4-hydroxy-3-nitro-coumarin by an enol-Ugi
condensation permits to introduce a peptidic chain that is subsequently cyclized in reducing
conditions to build the fused piperazino ring. In this way, rigid polyheterocyclic di- and
tri-peptides comprising a wide chemical diversity are easily accessible. This strategy,

Molecules 2021, 26, 1287
16 of 18
involving the first reported post-condensation transformation of an enol-Ugi adduct, opens
new opportunities for the discovery of novel pharmacologically active compounds.
Supplementary Materials: The following are available online: Figure S1: Aldehydes, amines, and
isocyanides used as starting materials, Figure S2: Imines used as starting materials, Experimental
data for imine 16g, Copies of the NMR spectra for all new compounds.
Author Contributions: Conceptualization, A.G.N. and C.F.M.; methodology, A.B. and A.G.N.;
writing—original draft preparation, C.F.M. All authors have read and agreed to the published
version of the manuscript.
Funding: This research was funded by Junta de Extremadura and FEDER (IB16095).
Institutional Review Board Statement: Not applicable.
Informed Consent Statement: Not applicable.
Data Availability Statement: The data presented in this study is available in this article and in the
supplementary material.
Acknowledgments: COMPUTAEX for granting access to supercomputer LUSITANIA.
Conflicts of Interest: The authors declare no conflict of interest.
Sample Availability: Samples of the compounds are available from the authors.
References
1.
Giannis, A.; Kolter, T. Peptidomimetics for Receptor Ligands—Discovery, Development, and Medical Perspectives. Angew. Chem.
Int. Ed. 1993, 32, 1244–1267. [CrossRef]
2.
3.
Gante, J. Peptidomimetics—Tailored Enzyme-Inhibitors. Angew. Chem. Int. Ed. 1994, 33, 1699–1720. [CrossRef]
Hanessian, S.; McNaughton-Smith, G.; Lombart, H.-G.; Lubell, W.D. Design and synthesis of conformationally constrained amino
acids as versatile scaffolds and peptide mimetics. Tetrahedron 1997, 53, 12789–12854. [CrossRef]
4.
5.
6.
7.
Gopalakrishnan, R.; Frolov, A.I.; Knerr, L.; Drury, W.J., 3rd; Valeur, E. Therapeutic Potential of Foldamers: From Chemical Biology
Tools To Drug Candidates? J. Med. Chem. 2016, 59, 9599–9621. [CrossRef] [PubMed]
Usmanova, L.; Dar’in, D.; Novikov, M.S.; Gureev, M.; Krasavin, M. Bicyclic Piperazine Mimetics of the Peptide beta-Turn
Assembled via the Castagnoli-Cushman Reaction. J. Org. Chem. 2018, 83, 5859–5868. [CrossRef]
Limbach, M.; Lygin, A.V.; Korotkov, V.S.; Es-Sayed, M.; de Meijere, A. Facile synthesis of structurally diverse 5-oxopiperazine-2-
carboxylates as dipeptide mimics and templates. Org. Biomol. Chem. 2009, 7, 3338–3342. [CrossRef]
Golebiowski, A.; Jozwik, J.; Klopfenstein, S.R.; Colson, A.-O.; Grieb, A.L.; Russell, A.F.; Rastogi, V.L.; Diven, C.F.; Portlock, D.E.;
Chen, J.J. Solid-Supported Synthesis of Putative Peptide β-Turn Mimetics via Ugi Reaction for Diketopiperazine Formation. J.
Comb. Chem. 2002, 4, 584–590. [CrossRef] [PubMed]
8.
9.
Kim, H.-O.; Nakanishi, H.; Lee, M.S.; Kahn, M. Design and Synthesis of Novel Conformationally Restricted Peptide Secondary
Structure Mimetics. Org. Lett. 2000, 2, 301–302. [CrossRef]
Golebiowski, A.; Klopfenstein, S.R.; Shao, X.; Chen, J.J.; Colson, A.-O.; Grieb, A.L.; Russell, A.F. Solid-Supported Synthesis of a
Peptide β-Turn Mimetic. Org. Lett. 2000, 2, 2615–2617. [CrossRef]
10. Belov, V.N.; Funke, C.; Labahn, T.; Es-Sayed, M.; de Meijere, A. An Easy Access to Bicyclic Peptides with an Octahydro[2H]pyrazino[1,2-
a]pyrazine Skeleton. Eur. J. Org. Chem. 1999, 2, 1345–1356. [CrossRef]
11. Gigant, N.; Claveau, E.; Bouyssou, P.; Gillaizeau, I. Diversity-oriented synthesis of polycyclic diazinic scaffolds. Org. Lett. 2012
14, 844–847. [CrossRef]
,
12. Zhao, J.; Zhao, H.; Hall, J.A.; Brown, D.; Brandes, E.; Bazzill, J.; Grogan, P.T.; Subramanian, C.; Vielhauer, G.; Cohen, M.S.;
et al. Triazole Containing Novobiocin and Biphenyl Amides as Hsp90 C-Terminal Inhibitors. Medchemcomm 2014, 5, 1317–1323.
[CrossRef] [PubMed]
13. Heide, L. New aminocoumarin antibiotics as gyrase inhibitors. Int. J. Med. Microbiol. 2014, 304, 31–36. [CrossRef]
14. Gunaherath, G.M.K.B.; Marron, M.T.; Wijeratne, E.M.K.; Whitesell, L.; Gunatilaka, A.A.L. Synthesis and biological evaluation of
novobiocin analogues as potential heat shock protein 90 inhibitors. Biorg. Med. Chem. 2013, 21, 5118–5129. [CrossRef] [PubMed]
15. Cele, F.N.; Kumalo, H.; Soliman, M.E. Mechanism of Inhibition of Hsp90 Dimerization by Gyrase B Inhibitor Coumermycin A1
(C-A1) Revealed by Molecular Dynamics Simulations and Thermodynamic Calculations. Cell Biochem. Biophys. 2016, 74, 353–363.
[CrossRef] [PubMed]
16. Zettler, J.; Xia, H.; Burkard, N.; Kulik, A.; Grond, S.; Heide, L.; Apel, A.K. New aminocoumarins from the rare actinomycete
Catenulispora acidiphila DSM 44928: Identification, structure elucidation, and heterologous production. Chembiochem 2014, 15,
612–621. [CrossRef] [PubMed]
17. Jans, P.E.; Mfuh, A.M.; Arman, H.D.; Shaffer, C.V.; Larionov, O.V.; Mooberry, S.L. Cytotoxicity and Mechanism of Action of the
Marine-Derived Fungal Metabolite Trichodermamide B and Synthetic Analogues. J. Nat. Prod. 2017, 80, 676–683. [CrossRef]

Molecules 2021, 26, 1287
17 of 18
18. Doens, D.; Valiente, P.A.; Mfuh, A.M.; Vo, A.X.T.; Tristan, A.; Carreno, L.; Quijada, M.; Nguyen, V.T.; Perry, G.; Larionov, O.V.;
et al. Identification of Inhibitors of CD36-Amyloid Beta Binding as Potential Agents for Alzheimer’s Disease. ACS Chem. Neurosci.
2017, 8, 1232–1241. [CrossRef]
19. Sun, J.; Pei, Y.; Li, E.; Li, W.; Hyde, K.D.; Yin, W.B.; Liu, X. A new species of Trichoderma hypoxylon harbours abundant secondary
metabolites. Sci. Rep. 2016, 6, 37369. [CrossRef]
20. Illgen, K.; Nerdinger, S.; Fuchs, T.; Friedrich, C.; Weber, L.; Herdtweck, E. A Versatile Synthesis of 6-Oxo-1,4,5,6-tetrahydro-
pyrazine-2-carboxylic Acid Methyl Esters via MCR Chemistry. Synlett 2004, 1, 53–56. [CrossRef]
21. Faggi, C.; Garcia-Valverde, M.; Marcaccini, S.; Pepino, R.; Pozo, M.C. Studies on Isocyanides and Related Compounds: A Facile
Synthesis of 1,6-Dihydro-6-Oxopyrazine-2-Carboxylic Acid Derivatives Via Ugi Four-Component Condensation. Synthesis 2003
10, 1553–1558. [CrossRef]
,
22. Jovanovic´, M.; Zhukovsky, D.; Podolski-Renic´, A.; Domracˇeva, I.; Žalubovskis, R.; Senc´anski, M.; Glišic´, S.; Sharoyko, V.;
Tennikova, T.; Dar’In, D.; et al. Novel electrophilic amides amenable by the Ugi reaction perturb thioredoxin system via
thioredoxin reductase 1 (TrxR1) inhibition: Identification of DVD-445 as a new lead compound for anticancer therapy. Eur. J. Med.
Chem. 2019, 181, 111580. [CrossRef] [PubMed]
23. Hulme, C.; Ma, L.; Cherrier, M.P.; Romano, J.J.; Morton, G.; Duquenne, C.; Salvino, J.; Labaudiniere, R. Novel applications of
convertible isonitriles for the synthesis of mono and bicyclic gamma-lactams via a UDC strategy. Tetrahedron Lett. 2000, 41,
1883–1887. [CrossRef]
24. El Kaïm, L.; Oble, J.; Gizzi, M.; Grimaud, L. Ugi-Smiles Access to Quinoxaline Derivatives. Heterocycles 2007, 73. [CrossRef]
25. Iordanidou, D.; Zarganes-Tzitzikas, T.; Neochoritis, C.G.; Domling, A.; Lykakis, I.N. Application of Silver Nanoparticles in the
Multicomponent Reaction Domain: A Combined Catalytic Reduction Methodology to Efficiently Access Potential Hypertension
or Inflammation Inhibitors. ACS Omega 2018, 3, 16005–16013. [CrossRef] [PubMed]
26. Ligia, S.d.S.P.; Mara, R.C.C.; Marcus, V.N.d.S. Multicomponent Reactions in the Synthesis of Complex Fused Coumarin Derivatives.
Curr. Org. Synth. 2018, 15, 21–37. [CrossRef]
27. Huang, Y.; Khoury, K.; Dömling, A. The Piperazine Space in Isocyanide-based MCR Chemistry. In Synthesis of Heterocycles via
Multicomponent Reactions I; Springer Science & Business Media: Berlin, Germany, 2010; pp. 85–127.
28. Medina, F.G.; Marrero, J.G.; Macias-Alonso, M.; Gonzalez, M.C.; Cordova-Guerrero, I.; Teissier Garcia, A.G.; Osegueda-Robles, S.
Coumarin heterocyclic derivatives: Chemical synthesis and biological activity. Nat. Prod. Rep. 2015, 32, 1472–1507. [CrossRef]
29. Domling, A.; Khoury, K. Praziquantel and schistosomiasis. ChemMedChem 2010, 5, 1420–1434. [CrossRef]
30. Demetri, G.D.; Chawla, S.P.; von Mehren, M.; Ritch, P.; Baker, L.H.; Blay, J.Y.; Hande, K.R.; Keohan, M.L.; Samuels, B.L.; Schuetze,
S.; et al. Efficacy and safety of trabectedin in patients with advanced or metastatic liposarcoma or leiomyosarcoma after failure of
prior anthracyclines and ifosfamide: Results of a randomized phase II study of two different schedules. J. Clin. Oncol. 2009, 27,
4188–4196. [CrossRef]
31. Croom, K.F.; Perry, C.M.; Plosker, G.L. Mirtazapine: A review of its use in major depression and other psychiatric disorders. CNS
Drugs 2009, 23, 427–452. [CrossRef] [PubMed]
32. Baker, M.E.; Lathe, R. The promiscuous estrogen receptor: Evolution of physiological estrogens and response to phytochemicals
and endocrine disruptors. J. Steroid. Biochem. Mol. Biol. 2018, 184, 29–37. [CrossRef] [PubMed]
33. Ceci, C.; Lacal, P.M.; Tentori, L.; De Martino, M.G.; Miano, R.; Graziani, G. Experimental Evidence of the Antitumor, Antimetastatic
and Antiangiogenic Activity of Ellagic Acid. Nutrients 2018, 10, 1756. [CrossRef] [PubMed]
34. François, G.; Timperman, G.; Holenz, J.; Assi, L.A.; Geuder, T.; Maes, L.; Dubois, J.; Hanocq, M.; Bringmannj, G. Naphthyliso-
quinoline alkaloids exhibit strong growth-inhibiting activities against Plasmodium falciparum and P. berghei in vitro—Structure—
activity relationships of dioncophylline C. Ann. Trop. Med. Parasit. 2016, 90, 115–123. [CrossRef]
35. Khanolkar, A.D.; Lu, D.; Ibrahim, M.; Duclos, R.I., Jr.; Thakur, G.A.; Malan, T.P., Jr.; Porreca, F.; Veerappan, V.; Tian, X.; George,
C.; et al. Cannabilactones: A novel class of CB2 selective agonists with peripheral analgesic activity. J. Med. Chem. 2007, 50,
6493–6500. [CrossRef]
36. Lin, W.; Huang, J.; Liao, X.; Yuan, Z.; Feng, S.; Xie, Y.; Ma, W. Neo-tanshinlactone selectively inhibits the proliferation of estrogen
receptor positive breast cancer cells through transcriptional down-regulation of estrogen receptor alpha. Pharmacol. Res. 2016
111, 849–858. [CrossRef] [PubMed]
,
37. Ostrowska, K. Coumarin-piperazine derivatives as biologically active compounds. Saudi Pharm. J. 2020, 28, 220–232. [CrossRef]
38. Kotharkar, S.A.; Shinde, D.B. Synthesis of antimicrobial 2,9,10-trisubstituted-6-oxo-7,12-dihydro-chromeno[3,4-b]quinoxalines.
Bioorg. Med. Chem. Lett. 2006, 16, 6181–6184. [CrossRef]
39. Hamama, W.S.; Hassanien, A.E.; El-Fedawy, M.G.; Zoorob, H.H. Synthesis and Antimicrobial Evaluation of Novel Polyfused
Heterocycles-Based Quinolone. J. Heterocycl. Chem. 2015, 52, 492–496. [CrossRef]
40. Han, G.S.; Yook, D.J.; Kim, S.K.; Shim, S.C.; Kang, H.K. Photophysical properties of pyrazinopsoralen, a new monofunctional
psoralen. Photochem. Photobiol. 1996, 64, 525–530. [CrossRef]
41. Hu, C.; Zhang, Z.; Gao, W.; Zhang, G.; Liu, T.; Liu, Q. PIFA-promoted intramolecular oxidative C(aryl)-H amidation reaction:
Synthesis of quinolino[3,4-b]quinoxalin-6(5 H )-ones. Tetrahedron 2018, 74, 665–671. [CrossRef]
42. Li, Y.; Lei, J.; Xu, J.; Tang, D.-Y.; Chen, Z.-Z.; Zhu, J.; Xu, C. A facile method for building fused quinoxaline-quinolinones via an
acidless post-Ugi cascade reaction. Chin. Chem. Lett. 2017, 28, 541–545. [CrossRef]

Molecules 2021, 26, 1287
18 of 18
43. Shiva Kumar, K.; Rambabu, D.; Prasad, B.; Mujahid, M.; Krishna, G.R.; Basaveswara Rao, M.V.; Malla Reddy, C.; Vanaja, G.R.;
Kalle, A.M.; Pal, M. A new approach to construct a fused 2-ylidene chromene ring: Highly regioselective synthesis of novel
chromeno quinoxalines. Org. Biomol. Chem. 2012, 10, 4774–4781. [CrossRef] [PubMed]
44. Hoplamaz, E.; Keskin, S.; Balci, M. Regioselective Synthesis of Benzo[h][1,6]-naphthyridines and Chromenopyrazinones through
Alkyne Cyclization. Eur. J. Org. Chem. 2017, 2017, 1489–1497. [CrossRef]
45. Neo, A.G.; López-García, L.; Marcos, C.F. Allylic amination of Passerini adducts. Application to the selective synthesis of
chromone-substituted α-and γ-amino acid peptidic and retropeptidic units. RSC Adv. 2014, 4, 40044–40053. [CrossRef]
46. Neo, A.; Carrillo, R.; Delgado, J.; Marcaccini, S.; Marcos, C.F. A multicomponent approach to the synthesis of 1,3-dicarbonylic
compounds. Mol. Divers. 2011, 15, 529–539. [CrossRef] [PubMed]
47. Carrillo, R.M.; Neo, A.G.; Lopez-Garcia, L.; Marcaccini, S.; Marcos, C.F. Zinc catalysed ester solvolysis. Application to the
synthesis of tartronic acid derivatives. Green Chem. 2006, 8, 787–789. [CrossRef]
48. Neo, A.G.; Delgado, J.; Polo, C.; Marcaccini, S.; Marcos, C.F. A new synthesis of beta-keto amides by reduction of Passerini
adducts. Tetrahedron Lett. 2005, 46, 23–26. [CrossRef]
49. Castellano, T.G.; Neo, A.G.; Marcaccini, S.; Marcos, C.F. Enols as feasible Acid components in the ugi condensation. Org. Lett.
2012, 14, 6218–6221. [CrossRef]
50. Neo, A.G.; Castellano, T.G.; Marcos, C.F. An easy synthesis of diversely functionalized 2H-chromenes and amido amines by an
enol-Ugi reaction. Arkivoc 2017, 21–31. [CrossRef]
51. Neo, A.G.; Castellano, T.G.; Marcos, C.F. Enol-Ugi Reaction of Hydroxycoumarins: Straightforward Synthesis of Amino Acid
Derived Coumarin Enamines. Synthesis 2015, 47, 2431–2438. [CrossRef]
52. Savel’ev, V.L.; Artamonova, O.S.; Troitskaya, V.S.; Vinokurov, V.G.; Zagorevskii, V.A. Investigations of pyrans and related
compounds. Chem. Heterocycl. Compd. 1973, 9, 816–820. [CrossRef]
53. Schiff, H. Mittheilungen aus dem Universitätslaboratorium in Pisa: Eine neue Reihe organischer Basen. Justus Liebigs Ann. Chem.
1864, 131, 118–119. [CrossRef]
54. Qin, W.; Long, S.; Panunzio, M.; Biondi, S. Schiff bases: A short survey on an evergreen chemistry tool. Molecules 2013, 18,
12264–12289. [CrossRef] [PubMed]
