condensations are highly challenging, since usually lead to
larger oligomers,[19] interlocked structures,[20] polymeric ma-
terials,[21] or dynamic mixtures.[22] Besides, in our case, the
overall process comprises the formation of six covalent
bonds in two steps each, which should be equivalent to
carry out twelve reactions in one pot. Accordingly, in order
to obtain a good selectivity towards the intended D3 sym-
metric cage, the starting material must be appropriately pre-
organized.
The key step for the success of the reaction is the forma-
tion of the hexaimine intermediate (3), through a dynamic
covalent process that is able to self-correct the wrong spe-
cies in the dynamic equilibrium. Initially, we used the bis-
the Ca H, as obtained by molecular modeling. Other addi-
tional nOes were consistent with a diequatorial chair confor-
mation of the cyclohexane moiety (Figure 1A).[23] To our de-
light, the in situ reduction of this intermediate led to the
pseudopeptidic hexamine cage 4a in very good overall iso-
lated yield from 1a (47%) considering the number of bonds
formed in a one-pot two-steps process, the necessary acidic
hydrolysis, the work-up and a reverse-phase chromatograph-
ic purification to obtain an analytically pure material.[24] Re-
markably, no other cyclic oligomers were isolated, support-
ing the excellent selectivity of the reaction. Further studies
showed that the reaction is also efficient with aromatic (4b,
R=Bn, 30% isolated yield) and polar (4c, R=CH2OH,
59% isolated yield) side chains on the pseudopeptidic
moiety.[23,24] The yield obtained with the Ser cage (4c) is
highly remarkable, especially considering that it includes the
ACHTUNGTRENNUNG(amidoamine) derived from the (R,R)-1,2-diaminocyclohex-
ane (chx) spacer and l-Valine (R=iPr) amino acid (1a).
Based on previous studies, this compound is preorganized in
a U-shaped conformation when the right combination of
chiral centers ((R,R)-diamine and (S)-amino acid) is imple-
mented in the molecule.[14] Thus, we monitored the reaction
À
step for the deprotection of the O tBu groups, performed
on the crude reaction before the final chromatographic pu-
rification.
1
between 1a and 2 by H NMR (500 MHz, RT, 10 mm of 1a
With the aim of generalizing our synthetic procedure, the
less rigid derivative with an ethylene (et) spacer and l-Val
(R=iPr) as the starting amino acid (1d) was also studied.
Despite the flexibility of 1d, the use of the suitable anion
template during the imine formation had largely improved
the process in the case of macrocycles.[15] Accordingly, we
also aimed to study the anion template effect in the synthe-
sis of the pseudopeptidic cages. Molecular modeling studies
showed that benzene-1,3,5-tricarboxylate (5) should be
a suitable template for the formation of the hexaimine cage
3d, perfectly filling the macrobicyclic cavity and forming up
to six hydrogen bonds between the carboxylate anions and
the amide groups of the pseudopeptidic moieties (Fig-
ure 1B). Taking into account these results, we monitored
in CD3OD).[23] We observed the decrease of the aldehyde
methyne signals (at 10.0–10.2 ppm) and the raise of the
imine-type protons (at ca. 8.3 ppm), until reaching an almost
complete conversion to a D3 symmetric imine compound.
1
The H and 13C NMR signals of this species were consistent
with the proposed hexaimine cage (3a), and also in full
agreement with the model structure (Figure 1A).[23] For in-
stance, the NOESY spectrum showed a cross peak between
À
the imine methyne and both the aromatic CH and the Ca
H of the pseudopeptide moiety (see double-headed arrows
in Figure 1A). These data imply the connectivity between
the fragments with an S-trans arrangement of the conjugated
À
imines, and a syn disposition between the imine C H and
1
the condensation between 1d and 2 by H NMR (500 MHz,
RT, 10 mm of 1d in CDCl3/CD3OH=9:1) in the absence
and in the presence of the trianion 5 as its tris(tetrabuthyl-
AHCTUNGTREGaNNNU mmonium) salt (5TBA). The evolution of the correspond-
ing spectra showed marked differences due to the presence
of the template (Figure 2A).[23]
Strikingly, in the presence of 5TBA, the system rapidly
evolved towards the formation (>80% as observed by
1H NMR)[23] of a highly symmetric imine compound in only
3 h of reaction. The chemical shifts and nOes (Figure 1B.)
are consistent with the presence of the D3 symmetric hexa-
AHCTUNGTRENNUNG
imine cage 3d.[23] Moreover, DOSY NMR spectra (Fig-
ure 2B) showed the same self-diffusion rate (D=6.49ꢄ
10À6 cm2 sÀ1) for the signals corresponding to the pseudopep-
tidic cage and those assigned to the template (both the aro-
matic tricarboxylate and the TBA cation) suggesting that
they are forming part of the same non-covalent species. Esti-
mation of the molecular volume of this supramolecular spe-
cies by DOSY[23] rendered a value of 2210 ꢅ3, in reasonably
good agreement with the one obtained for [3d+5+3TBA]
by modeling (2183 ꢅ3). A definitive proof for the formation
of this supramolecular complex was obtained by ESI-TOF
mass spectrometry (Figure 2C).[23] The mass spectrum of the
reaction mixture in the anion detection mode showed the
Figure 1. Optimized geometries for: A) the hexaimine cage 3a, B) the
supramolecular complex formed by 3d and 5 (in CPK representation).
Observed nOes are shown in curved double-headed arrows. C,D) Hypo-
thetical amino aldehyde intermediate previous to the macrobicycle for-
mation (for 3d) in the absence C) and in the presence D) of the template.
For simplicity, in C and D, nonpolar hydrogen atoms have been omitted.
