FULL PAPER
DOI: 10.1002/cjoc.201100351
Environmental Friendly Synthesis of Novel Isatin Ketal and
Isatin Schiff Base Derivatives Using Michael Addition Reaction
under Solvent-Free Conditions
Imanzadeh, Gholamhassan*
Zamanloo, Mohammadreza
Soltanizadeh, Zahra
Mansoori, Yagoub
Khodayari, Ali
Salehzadeh, Jaber
Department of Chemistry, Faculty of Science, University of Mohaghegh Ardabili, 56199-11367, Ardabil, Iran
An efficient and simple procedure for the synthesis of novel isatin derivatives is described. Michael addition of
aniline Schiff bases of isatin or p-toluidine Schiff bases of isatin to fumaric esters affords the Michael adduct com-
pounds in good to high yields in the presence of K2CO3 and tetrabutylammonium bromide (TBAB) under sol-
vent-free conditions. Repeating of this reaction about spiro[1,3-dioxolane-2,3'-indol]-2'(1'H)-one, as a Michael do-
nor, in the presence of 1,4-diazabicyclo[2.2.2]octane (DABCO) gives Michael adducts in remarkable yields under
the same conditions.
Keywords Michael addition, isatin ketal, isatin Schiff base, fumaric ester, acrylic ester, solvent-free conditions
Introduction
this reaction. However, to the best of our knowledge, no
datum is available on the addition of the Schiff base of
isatin 2 or 3 and dioxolane ketal 4 to α,β-unsaturated
esters. Having the above points in mind and also in con-
tinuing our previous studies on aza-Michael reac-
tion,[42,43] this work investigates the aza-Michael addi-
tion reaction of isatin Schiff bases 2, 3 and isatin ketal 4
with α,β-unsaturated esters under solvent-free condi-
tions (Schemes 1 and 2).
Isatin 1 (1H-indol-2,3-diones) is a versatile molecule
in the synthesis of many products with pharmacologic
activity.[1] In 1841, this compound was obtained by oxi-
dation of Indigo with nitric and chromic acid.[2] In na-
ture, isatin has been identified in blood and urine of
mammalian,[3] in rat brain,[4] in plants of genus Isatis[5]
and in coal tar.[6] Studies show that isatin readily crosses
the blood-brain barrier and acts on the central nervous
system (CNS).[7] This compound has been identified as
a selective inhibitor of monoamine oxidas B (MAOB)[8]
and therefore it has been suggested to be an alternative
for the treatment of Parkinson’s disease, by increasing
dopamine levels in the striatum.[9,10] Numerous investi-
gations show isatin has anxiogenic effects.[11-16] Schiff
bases and Mannich bases of isatin are reported to show
a variety of biological activities like antibacterial,[17-19]
antifungal,[20-22] antiviral,[23-25] anti-HIV,[26-28] antipro-
tozoal[29,30] and antihelimithic properties.[31,32] Some of
Schiff bases of isatin show that they have a potent anti-
cancer activity against human cancer.[33] Isatin ketals
have anxiolytic,[34] psychotropic,[35] and anticonvulsant
activity.[36] For instance spiro[1,3-dioxolane-2,3'-indol]-
2'(1'H)-one 4 (as a dioxolane ketal) has sedative, hyp-
notic and anesthetic properties.[37]
Scheme 1 Addition of isatin Schiff bases to α,β-unsaturated
esters
R
O
N
R = Tol
2
R
NH2
+
N
H
O
N
H
O
R = Ph
3
1
O
OR'
R'O
O
N
R
R = Tol
2a - 2e
N
O
R = Ph
Aza-Micheal addition reaction is one of the most
famous methods for forming a carbon-nitrogen bond in
organic synthesis.[38] Different Michael donors such as
amines,[39] amides,[40] and imides[41] have been used in
O
3a - 3d
O
OR'
OR'
*
E-mail: Imanzad2000@yahoo.com
Received September 16, 2011; accepted November 27, 2011.
Supporting information for this article is available on the WWW under http://dx.doi.org/10.1002/cjoc.201100351 or from the author.
Chin. J. Chem. 2012, 30, 891—899 © 2012 SIOC, CAS, Shanghai, & WILEY-VCH Verlag GmbH & Co. KGaA, Weinheim
891

Imanzadeh et al.
FULL PAPER
Scheme 2 Addition of isatin ketal to α,β-unsaturated esters
troscopy. The progress of the reactions was followed by
TLC using silica gel SILIG/UV 254 plates. H NMR
1
O
OH
(400 MHz) and 13C NMR (100 MHz) spectra were re-
corded on a Bruker 300 MHz instrument. FT-IR spectra
were recorded on a Perkin-Elmer RX-1 instrument.
Mass spectra were recorded on a Shimadzu GC-MS-QP
1000PX. Elemental analysis for C, H, and N were per-
formed using a Heraeus CHN-O-Rapid analyzer. The
melting points were determined in open capillaries with
a Stuart Melting Point Apparatus and are uncorrected.
HO
N
O
H
O
O
1
O
O
OR
RO
O
N
O
OR
O
OR
O
O
General procedure for addition of isatin Schiff bases
2 or 3 to symmetrical fumaric esters
5a - 5f
N
O
To a well ground mixture of isatin Schiff base (1.0
mmol), K2CO3 (1.0 mmol), and TBAB (0.5 mmol), fu-
maric ester (1.2 mmol) was added and mixed thor-
oughly with a glass rod. The resulting mixture was kept
in an oil bath at 90—100 ℃ for appropriate time (Ta-
ble 1). The progress of reaction was monitored by TLC.
After the completion of reaction the mixture was sus-
pended in chloroform (30 mL), filtered and the filtrate
was washed with water (10 mL×3) and dried with
MgSO4. The solvent was removed under reduced pres-
sure and the resulting crude material was purified on
short silica-gel column with ethyl acetate∶n-hexane
(1∶9) as the eluent.
H
O
O
N
O
O
OR
4
OR
O
6a - 6f
Experimental
Spiro[1,3-dioxolane-2,3'-indol]-2'(1'H)-one 4, and all
α,β-unsaturated esters were synthesized in our labora-
tory according to the literature procedures[37,45] and their
1
structures were confirmed by IR and H NMR spec-
Table 1 Michael addition of isatin Schiff bases 2, 3 to fumaric esters in the presence of K2CO3
Entry
Ester
Product
Time/min
Yielda/%
N
O
O
O
O
1
40
85
O
N
O
O
O
H
H
H
O
2a
N
O
O
O
O
2
60
85
O
N
O
O
O
H
H
H
O
2b
N
O
O
O
O
4
300
75
N
O
O
O
O
H
H H
O
2d
892
www.cjc.wiley-vch.de
© 2012 SIOC, CAS, Shanghai, & WILEY-VCH Verlag GmbH & Co. KGaA, Weinheim
Chin. J. Chem. 2012, 30, 891—899

Environmental Friendly Synthesis of Novel Isatin Ketal and Isatin Schiff Base Derivatives
Continued
Yielda/%
Entry
Ester
Product
Time/min
N
O
O
O
O
5
60
85
80
80
80
O
N
O
O
O
H
H H
3a
O
N
O
O
O
O
6
7
8
120
100
150
O
N
O
O
O
H
H H
3b
O
N
O
O
O
O
O
N
O
O
O
H
H H
O
3c
N
O
O
O
O
O
N
8
8
O
O
O
6
H
6
H H
3d
O
a Isolated yields.
General procedure for addition isatin ketal 4 to
symmetrical fumaric ester and acrylic esters
Physical and spectroscopic data of isolated products
Diethyl 2-(3-(p-tolylimino)-2-oxoindolin-1-yl)-
1
A mixture of isatin ketal 4 (1.0 mmol), DABCO (1.0
mmol), TBAB (0.5 mmol), fumaric esters or acrylic es-
ter (1.2 mmol) was kept in the oil bath for the stipulated
time (Table 2) at 80—90 ℃. The progress of the reac-
tion was monitored by TLC. After completion of reac-
tion the reaction mixture was cooled to room tempera-
ture and dissolved in chloroform (40 mL). TBAB was
recovered by the addition of water (15 mL), then col-
lected and dried under vacuum. The chloroform layer
was washed with water (15 mL×3). The organic layer
was dried over anhydrous Na2SO4. The solvent was re-
moved under reduced pressure and the resulting crude
material was purified on short silica-gel column with
ethyl acetate∶n-hexane (2∶8) as the eluent.
succinate (2a) Orange oil; H NMR (400 MHz,
