DOI: 10.1002/chem.201200992
Highly Enantioselective Epoxidation of Multisubstituted Enones Catalyzed
by Non-Heme Iron Catalysts
Bin Wang,[a, b] Shoufeng Wang,[a] Chungu Xia,[a] and Wei Sun*[a]
Asymmetric epoxidation of olefins is one of the most im-
portant transformations in organic synthesis because the re-
sulting enantiomerically enriched epoxides are highly useful
intermediates and building blocks.[1] Over the past decades,
numerous efforts have been devoted to the development of
efficient catalysts for this reaction. Many catalyst systems in-
cluding chiral metal complexes[2,3] and organocatalysts[4,5]
have been successfully established. In light of the increasing
demand for green and sustainable chemistry, the develop-
ment of iron-based catalysts with considerable enantioselec-
tivity and activity is desirable due to their low toxicity, lower
price, and the benign environmental character of iron com-
pounds.[6] In this regard, only a few successful examples
have been published on the iron-catalyzed asymmetric epox-
idation of olefins (generally >90% enantiomeric excess
(ee)).[7] In 1999, the first approach of the enantioselective
epoxidation of styrene derivatives with iron-porphyrin com-
plexes was reported.[8] Later, Beller and co-workers have de-
scribed an iron-catalyzed methodology for the asymmetric
epoxidation of stilbene derivatives with 10 mol% catalyst
loading.[9] Yamamoto et al. recently developed the iron-cata-
lyzed asymmetric epoxidation of b,b-disubstituted enones in
fins.[13] We recently reported the enantioselective epoxida-
tion of a,b-enones (up to 87% ee) using non-heme iron
complexes of mcp derivatives (mcp=N,N’-dimethyl-N,N’-
bis(2-pyridylmethyl)-cyclohexane-1,2-diamine).[14] Common
features of these tetradentate ligands are that they contain
two pyridine donors as well as two sp3 N donors.[15] On the
basis of our previous studies, we reasoned that the fine
tuning of the rigidity of the ligands and nitrogen donors
might enhance the chiral induction. Herein, we report the
elaborate design of non-heme iron catalysts for the highly
enantioselective epoxidation of a broad range of multisubsti-
tuted enones with up to 98% ee.
The C1-symmetric tetradentate N ligands (N4) consisted of
more rigid chiral diamine template derived from l-proline
and two benzimidazole donors. The ligands were readily
prepared by the direct alkylation of (S)-N-methyl-2-amino-
methylpyrrolidine with 2-chloromethyl-benzoimdazole de-
rivatives (Figure 1).[16] Iron complexes were synthesized by
the presence of 5 mol% of FeACHTNUTRGNENG(U OTf)2 and 2 equiv of chiral
phenanthroline ligand. X-ray crystallography revealed that
a pseudo-C2-symmetric iron–ligand complex was responsible
for epoxidation.[10]
Iron(II) complexes containing linear tetradentate ligands
such as mep (mep=N,N’-dimethyl-N,N’-bis(2-pyridylmethyl)
ethylene-1,2-diamine) are typical non-heme model com-
pounds.[11] These model complexes have proven to be prom-
ising catalysts for the selective oxidation of organic sub-
strates.[12] Pioneering studies by Jacobsen and co-workers
have demonstrated that iron(II)-mep complex could effi-
ciently promote epoxidation of a variety of aliphatic ole-
Figure 1. New non-heme iron(II) catalysts used in this study.
treating N4 ligands with FeCl2 in CH3CN, then the anion
could be changed to OTf (OTf=CF3SO3) by the addition of
AgOTf. Solid-state X-ray analysis of a single crystal of com-
plex C1, containing 1-ethyl-benzoimdazoles donors, revealed
that the ligand coordinated the iron center in a cis-a topolo-
À
gy (Figure 2). The Fe N bond distances between the iron
and benzimidazole donors (complex C1: 2.141(5) and
[a] B. Wang, S. Wang, Prof. Dr. C. Xia, Prof. Dr. W. Sun
State Key Laboratory for Oxo Synthesis and Selective Oxidation
Lanzhou Institute of Chemical Physics
Chinese Academy of Sciences
À
2.156(6) ꢀ, respectively) are both shorter than Fe N distan-
ces between the iron and pyridyl donors (complex C4:
2.155(7) and 2.174(8) ꢀ, respectively).[17]
Lanzhou, 730000 (P.R. China)
Fax : (+86)931-827-7088
The preliminary screening of the catalysts was carried out
with chalcone as a model substrate using the H2O2/AcOH
protocol.[14,18] The complex C1 containing 1-ethylbenzimida-
zole donors gave the epoxide product with 82% ee using
1.0 mol% of catalyst loading at room temperature (Table 1,
entry 1). Further lowering of the temperature to À208C did
[b] B. Wang
Graduate School of the Chinese Academy of Sciences
Beijing, 100039 (P.R. China)
Supporting information for this article is available on the WWW
7332
ꢁ 2012 Wiley-VCH Verlag GmbH & Co. KGaA, Weinheim
Chem. Eur. J. 2012, 18, 7332 – 7335
