Catalytic enantioselective allylic amination of unactivated terminal olefins via an Ene reaction/[2,3]-rearrangement

Article abstract of DOI:10.1021/ja307851b

The enantioselective allylic amination of unactivated terminal olefins represents a direct and attractive strategy for the synthesis of enantioenriched amines. We have developed the first use of a nitrogen-containing reagent and a chiral palladium catalyst to convert unfunctionalized olefins into enantioenriched allylic amines via an ene reaction/[2,3]-rearrangement.

Full text of DOI:10.1021/ja307851b

Communication
pubs.acs.org/JACS
Catalytic Enantioselective Allylic Amination of Unactivated Terminal
Olefins via an Ene Reaction/[2,3]-Rearrangement
Hongli Bao and Uttam K. Tambar*
Department of Biochemistry, Division of Chemistry, The University of Texas Southwestern Medical Center at Dallas, 5323 Harry
Hines Boulevard, Dallas, Texas 75390-9038, United States
S
* Supporting Information
metal-nitrenoids9 (Scheme 1, path a).10 In theory, chiral
ABSTRACT: The enantioselective allylic amination of
unactivated terminal olefins represents a direct and
attractive strategy for the synthesis of enantioenriched
amines. We have developed the first use of a nitrogen-
containing reagent and a chiral palladium catalyst to
convert unfunctionalized olefins into enantioenriched
allylic amines via an ene reaction/[2,3]-rearrangement.
versions of these metal complexes could facilitate the
enantioselective formation of chiral amine products. Despite
recent progress in metal-catalyzed enantioselective aminations
of activated benzylic C−H bonds11 and intramolecular
enantioselective allylic aminations of olefins,12 there are no
general examples of intermolecular catalytic enantioselective
allylic amination of unactivated terminal olefins.13
We were drawn to a conceptually distinct allylic amination
strategy that is based on an uncatalyzed conversion of
unfunctionalized olefins into racemic chiral amines via an ene
reaction/[2,3]-rearrangement of reactive zwitterion 1 (Scheme
1, path b).14 In this approach, an imido-sulfur or imido-
selenium compound acts as the source of nitrogen.
Unfortunately, since its discovery over 30 years ago, this
protocol was thought to be incompatible with enantioselective
catalysis because of the propensity of reactive zwitterions such
as 1 to undergo facile thermal [2,3]-rearrangement in the
absence of a catalyst.15,16 We recently developed a palladium-
catalyzed enantioselective [2,3]-rearrangement of zwitterionic
amine N-oxides.17 We hypothesized that a similar catalytic
manifold may be applicable to the rearrangement of zwitterion
1, which would provide an opportunity to develop a catalytic
enantioselective allylic amination of terminal olefins.
Our initial experiments focused on the identification of a
high oxidation state nitrogen source that would couple with a
terminal olefin to form an ene adduct, such as 1, which would
not undergo a background [2,3]-rearrangement in the absence
of a chiral catalyst. This proved challenging, since most imido-
sulfur and imido-selenium oxidants that are suitable for allylic
amination strategies participate in uncatalyzed thermal ene
reactions followed by [2,3]-rearrangements. For example, the
early work of Sharpless and Kresze highlighted the racemic
allylic amination of terminal olefins at room temperature with
arylsulfonyl sulfurdiimide reagents through the two-step
pericyclic reaction sequence.14
he direct conversion of hydrocarbons into chiral function-
Talized molecules has remained an important goal in
chemistry for decades.1 Advances in this area provide more
efficient and practical strategies for designing and manipulating
molecular structures, with broad applications in fields such as
medicine and materials science.2 The stereoselective incorpo-
ration of nitrogen atoms into hydrocarbons, such as olefins, is
of particular interest, given the prevalence of chiral amines in
pharmaceutical drugs.3 Although many powerful chemical
methods have been developed for the incorporation of nitrogen
atoms into hydrocarbons,4 the catalytic enantioselective
conversion of hydrocarbons into chiral amines has to date
remained an unsolved problem.5,6 In this communication, we
describe a catalytic enantioselective intermolecular allylic
amination of unactivated terminal olefins for the synthesis of
chiral amines in high enantiomeric excess (Scheme 1).
The metal-catalyzed activation of inert C−H bonds has
emerged as one efficient strategy for transforming terminal
olefins into allylic amines via metal-π-allyl intermediates7,8 or
Scheme 1
Upon reexamination of these arylsulfonyl sulfurdiimide
oxidants, we discovered that benzenesulfonyl sulfurdiimide 3
and 1-octene 2a formed stable ene adduct 4a at 4 °C in high
yield (Table 1). This zwitterionic intermediate was purified by
simple filtration without any chromatography and did not
rearrange at temperatures below 0 °C, even after several days
(entry 1). Coupling between nitrogen-containing oxidant 3 and
terminal olefins at low temperatures was therefore selected as
Received: August 7, 2012
Published: October 29, 2012
© 2012 American Chemical Society
18495
dx.doi.org/10.1021/ja307851b | J. Am. Chem. Soc. 2012, 134, 18495−18498

Journal of the American Chemical Society
Communication
Table 1. Optimization of the Enantioselective Allylic
Amination
Table 2. Substrate Scope of the Enantioselective Allylic
Amination
the platform for our catalytic enantioselective allylic amination
of olefins.
In our early attempts to accelerate the [2,3]-rearrangement
of zwitterion 4a, palladium(II) salts such as Pd(OAc)2 were
promising catalysts for the desired rearrangement (entry 2).
After an extensive screening of reaction parameters (including
solvent, chiral ligand, and palladium source), we identified
Pd(TFA)2 and bisoxazoline ligand 6 as the optimal catalyst
complex for generating allylic sulfonamide product 5a in 89%
yield and 96% enantiomeric excess (ee) at −15 °C in
anhydrous methanol (entry 12).18 The overall two-step
protocol only requires one chromatographic purification,
which simplifies the operation of this reaction on large scale.
Having identified optimized reaction conditions for the
enantioselective conversion of olefins into allylic amines, we
explored the substrate scope of this process on a preparative
scale (2−4 mmol). Table 2 highlights the efficiency of this
enantioselective process in the absence of any directing
functional groups in the substrate. For example, allylic amines
were generated with linear hydrocarbon chains (entries 1−3) as
well as hindered branched hydrocarbons (entries 4−6). In all
these cases, the allylic sulfonamide products were obtained in
high yields with greater than 90% ee. Given the paucity of
enantioselective methods for converting achiral hydrocarbons
into chiral products, the success of the enantioselective allylic
amination reaction with substrates that lack directing groups is
noteworthy.
a
b
Isolated yield for 2 steps, based on sulfurdiimide 3. 3−5 equiv of
c
olefin. Reaction temperature was −5 °C.
such as free alcohols and carboxylic acids, were not tolerated in
the enantioselective allylic amination, presumably because of
competitive addition into the electrophilic benzenesulfonyl
sulfurdiimide 3 prior to the hetero-ene reaction. However, the
mild reaction conditions were compatible with protected
heteroatoms, including a benzyl ether (entry 9) and a
nitrogen-bearing phthalimide (entry 10). Reactive electrophilic
functional groups, such as nitriles (entry 11), aldehydes (entry
12), and primary alkyl chlorides (entries 13−15), could be
incorporated into the products without affecting the overall
efficiency of the allylic amination process. The absolute
stereochemistry of the allylic amination products was
determined by examining crystals of the product in entry 6
that were suitable for X-ray diffraction.
As a preliminary mechanistic proposal, we hypothesize that
the palladium(II)-bisoxazoline catalyst acts as a chiral π-acid to
activate zwitterion 4, which then undergoes aminopalladation
to generate heterocycle 7 as an intermediate (Scheme 2). Grob-
type fragmentation eventually reveals allylic amine 5 and the
palladium(II)-bisoxazoline catalyst, which can reenter the
The compatibility of this reaction with a wide range of
reactive functional groups was also examined. Polyunsaturated
terminal olefins selectively incorporated a single nitrogen atom
via a hetero-ene reaction with one molecule of benzenesulfonyl
sulfurdiimide 3 (entries 7−8). Nucleophilic functional groups,
18496
dx.doi.org/10.1021/ja307851b | J. Am. Chem. Soc. 2012, 134, 18495−18498

Journal of the American Chemical Society
Communication
Scheme 2
ASSOCIATED CONTENT
* Supporting Information
■
S
Complete experimental procedures and characterization data.
This material is available free of charge via the Internet at
http://pubs.acs.org.
AUTHOR INFORMATION
Corresponding Author
Uttam.Tambar@utsouthwestern.edu
■
Notes
The authors declare no competing financial interest.
ACKNOWLEDGMENTS
■
Financial support was provided by the W. W. Caruth, Jr.
Endowed Scholarship, the Robert A. Welch Foundation (Grant
I-1748), the American Cancer Society Petroleum Research
Fund (PRF# 51710-DNI1), and the National Institutes of
Health (1R01GM102604-01). We thank Dr. Vincent Lynch for
X-ray structural analysis. We also thank John T. Watson and
Tian Zhao for experimental assistance.
catalytic cycle. This cyclization-induced mechanism, which is
similar to Overman’s proposal for the [3,3]-rearrangement of
allylic trichloroacetimidates,19 is consistent with a crossover
experiment between two differentially substituted zwitterionic
substrates that only yield non-crossover products (see
Supporting Information).20
The utility of this enantioselective allylic amination reaction
in the synthesis of biologically active, nitrogen-containing chiral
molecules is exemplified by the conversion of commercially
available unsaturated ester 8 into enantioenriched antiepileptic
drug Vigabatrin (Scheme 3).21 The enantioselective allylic
amination protocol yielded chiral sulfonamide 9, which was
then deprotected to reveal the enantioenriched HCl salt of
Vigabatrin (10).
REFERENCES
■
(1) (a) Labinger, J. A.; Bercaw, J. E. Nature 2002, 417, 507.
(b) Bergman, R. G. Nature 2007, 446, 391.
(2) (a) Newhouse, T.; Baran, P. S. Angew. Chem., Int. Ed. 2011, 50,
3362. (b) Engle, K. M.; Mei, T.-S.; Wasa, M.; Yu, J.-Q. Acc. Chem. Res.
2012, 45, 788. (c) White, M. C. Science 2012, 335, 807.
(3) (a) Farina, V.; Reeves, J. T.; Senanayake, C. H.; Song, J. J. Chem.
Rev. 2006, 106, 2734. (b) Henkel, T.; Brunne, R. M.; Muller, H.;
Reichel, F. Angew. Chem., Int. Ed. 1999, 38, 643. (c) Hili, R.; Yudin, A.
K. Nat. Chem. Bio. 2006, 2, 284.
̈
(4) For reviews on the synthesis of nitrogen-containing molecules,
see: (a) Jiang, L.; Buchwald, S. L. In Metal-Catalyzed Cross-Coupling
Reactions, 2nd ed.; Wiley-VCH: Weinheim, 2004; Vol. 2, pp 699−760.
(b) Hartwig, J. F. In Handbook of Organopalladium Chemistry for
Organic Synthesis; Negishi, E., Ed.; Wiley-Interscience: New York,
2002; p 1051. (c) Davies, H. M. L.; Long, M. S. Angew. Chem., Int. Ed.
2005, 44, 3518. (d) Beccalli, E. M.; Broggini, G.; Martinelli, M.;
Sottocornola, S. Chem. Rev. 2007, 107, 5318. (e) Surry, D. S.;
Buchwald, S. L. Chem. Sci. 2011, 2, 27. (f) Collet, F.; Dodd, R. H.;
Dauban, P. Chem. Commun. 2009, 5061. (g) Davies, H. M.; Manning,
J. R. Nature 2008, 451, 417.
Scheme 3
(5) (a) Johannsen, M.; Jørgensen, K. A. Chem. Rev. 1998, 98, 1689.
(b) Ramirez, T. A.; Zhao, B.; Shi, Y. Chem. Soc. Rev. 2012, 41, 931.
(c) Collet, F.; Lescot, C.; Dauban, P. Chem. Soc. Rev. 2011, 40, 1926.
(d) Zalatan, D. N.; Du Bois, J. Top. Curr. Chem. 2010, 292, 347.
(6) For excellent discussions of the synthesis of allylic amines by
means of catalytic asymmetric allylic alkylation from functionalized
substrates, see: (a) Hartwig, J. F.; Stanley, L. M. Acc. Chem. Res. 2010,
43, 1461. (b) Trost, B. M.; Zhang, T.; Sieber, J. D. Chem. Sci. 2010, 1,
427. (c) Lafrance, M.; Roggen, M.; Carreira, E. M. Angew. Chem., Int.
Ed. 2012, 51, 3470 and references therein.
(7) For seminal references of aminopalladation of double bonds,
followed by β-hydride elimination, see: (a) Hedegus, L. S.; Allen, G.
F.; Bozell, J. J.; Waterman, E. L. J. Am. Chem. Soc. 1978, 100, 5800.
(b) Larock, R. C.; Hightower, T. R.; Hasvold, L. A.; Peterson, K. P. J.
Org. Chem. 1996, 61, 3584. (c) Brice, J. L.; Harang, J. E.; Timokhin, V.
I.; Anastasi, N. R.; Stahl, S. S. J. Am. Chem. Soc. 2005, 127, 2868.
(8) For some recent examples of allylic amination via palladium-π-
allyl intermediates, see: (a) Fraunhoffer, K. J.; White, M. C. J. Am.
Chem. Soc. 2007, 129, 7274. (b) Reed, S. A.; White, M. C. J. Am. Chem.
Soc. 2008, 130, 3316. (c) Rice, G. T.; White, M. C. J. Am. Chem. Soc.
2009, 131, 11701. (d) Yin, G.; Wu, Y.; Liu, G. J. Am. Chem. Soc. 2010,
132, 11978.
In conclusion, we have developed a practical method for
converting terminal olefins into enantioenriched allylic amines
with a chiral palladium catalyst. Our key discovery was the use
of a catalyst to accelerate the enantioselective [2,3]-rearrange-
ment of allylic zwitterion 4, a process that was traditionally
thought to be uncontrollable by chiral catalysts. This procedure
for generating allylic amines is compatible with a broad range of
functional groups. Moreover, the chiral rearrangement products
can be easily transformed into synthetically useful allylic
sulfonamides and primary amines. We are currently interested
in gaining more mechanistic insight into the mode of
stereoinduction in the enantioselective rearrangement step
while also increasing the functional group compatibility of the
transformation. We anticipate that this method will be useful
for the synthesis of nitrogen-containing pharmaceutical agents
from inexpensive and abundant unactivated olefins.
(9) For seminal examples of allylic amination via C−H insertion by
metal-nitrenoids, see: (a) Espino, C. G.; Fiori, K. W.; Kim, M.; Du
18497
dx.doi.org/10.1021/ja307851b | J. Am. Chem. Soc. 2012, 134, 18495−18498

Journal of the American Chemical Society
Communication
Bois, J. J. Am. Chem. Soc. 2004, 126, 15378. (b) Lebel, H.; Huard, K.;
Lectard, S. J. Am. Chem. Soc. 2005, 127, 14198. (c) Stokes, B. J.; Dong,
H.; Leslie, B. E.; Pumphrey, A. L.; Driver, T. G. J. Am. Chem. Soc.
2007, 129, 7500. (d) Thu, H.-Y.; Yu, W.-Y.; Che, C.-M. J. Am. Chem.
Soc. 2006, 128, 9048. (e) Harvey, M. E.; Musaev, D. G.; Du Bois, J. J.
Am. Chem. Soc. 2011, 133, 17207. (f) Paradine, S. M.; White, M. C. J.
Am. Chem. Soc. 2012, 134, 2036. (g) Fiori, K. W.; Du Bois, J. J. Am.
Chem. Soc. 2007, 129, 562. (h) Huard, K.; Lebel, H. Chem.Eur. J.
2008, 14, 6222.
NOTE ADDED AFTER ASAP PUBLICATION
■
Scheme 1 was incomplete in the version published ASAP
October 29, 2012. The corrected version was re-posted on
October 30, 2012.
(10) For mechanistically distinct Pd(0)-catalyzed asymmetric
diaminations of terminal olefins at allylic and homoallylic carbons,
see: (a) Du, H.; Yuan, W.; Zhao, B.; Shi, Y. J. Am. Chem. Soc. 2007,
129, 7496. (b) Du, H.; Zhao, B.; Shi, Y. J. Am. Chem. Soc. 2008, 130,
8590.
(11) (a) Reddy, R. P.; Davies, H. M. L. Org. Lett. 2006, 8, 5013.
(b) Yamawaki, M.; Tsutsui, H.; Kitagaki, S.; Anada, M.; Hashimoto, S.
Tetrahedron Lett. 2002, 43, 9561.
(12) (a) Milczek, E.; Boudet, N.; Blakey, S. Angew. Chem., Int. Ed.
2008, 47, 6825. (b) Zalatan, D. N.; Du Bois, J. J. Am. Chem. Soc. 2008,
130, 9220. (c) McDonald, R. I.; White, P. B.; Weinstein, A. B.; Tam,
C. P.; Stahl, S. S. Org. Lett. 2011, 13, 2830. (d) Ichinose, M.;
Suematsu, H.; Yasutomi, Y.; Nishioka, Y.; Uchida, T.; Katsuki, T.
Angew. Chem., Int. Ed. 2011, 50, 9884. (e) Lu, H.; Jiang, H.; Wojtas, L.;
Zhang, X. P. Angew. Chem., Int. Ed. 2010, 49, 10192. (f) Lu, H.; Jiang,
H.; Hu, Y.; Wojtas, L.; Zhang, X. P. Chem. Sci. 2011, 2, 2361.
(13) Stereoselective intermolecular C−H aminations have been
reported for the synthesis of enantioenriched amines via the
cooperative effect of chiral rhodium catalysts with chiral N-
tosyloxycarbamates or chiral sulfonimidamides: (a) Liang, C.;
Robert-Peillard, F.; Fruit, C.; Muller, P.; Dodd, R. H.; Dauban, P.
̈
Angew. Chem., Int. Ed. 2006, 45, 4641. (b) Liang, C.; Collet, F.;
Robert-Peillard, F.; Muller, P.; Dodd, R. H.; Dauban, P. J. Am. Chem.
̈
Soc. 2008, 130, 343. (c) Lebel, H.; Spitz, C.; Leogane, O.; Trudel, C.;
Parmentier, M. Org. Lett. 2011, 13, 5460. (d) Lescot, C.; Darses, B.;
Collet, F.; Retailleau, P.; Dauban, P. J. Org. Chem. 2012, 77, 7232.
Copper-catalyzed enantioselective intermolecular C−H aminations
have been reported for the synthesis of enantioenriched amines (up to
70% ee): (e) Clark, J. S.; Roche, C. Chem. Commun. 2005, 5175.
(14) (a) Sharpless, K. B.; Hori, T. J. Org. Chem. 1976, 41, 176.
(b) Sharpless, K. B.; Hori, T.; Truesdale, L. K.; Dietrich, C. O. J. Am.
Chem. Soc. 1976, 98, 269. (c) Kresze, G.; Munsterer, H. J. Org. Chem.
̈
1983, 48, 3561. (d) Katz, T. J.; Shi, S. J. Org. Chem. 1994, 59, 8297.
(e) Bruncko, M.; Khuong, T.-A. V.; Sharpless, K. B. Angew. Chem., Int.
Ed. 1996, 35, 454.
(15) (a) Bruckner, R. In Comprehensive Organic Synthesis; Trost, B.
̈
M., Fleming, I., Eds.; Pergamon Press: New York, 1991; Vol. 6, pp
873−908. (b) Hoffman, R. W. Angew. Chem., Int. Ed. Engl. 1979, 18,
563. (c) Sweeney, J. B. Chem. Soc. Rev. 2009, 38, 1027.
(16) Stereoselective versions of this strategy have relied on covalently
linked chiral auxiliaries: Whitesell, J. K.; Yaser, H. K. J. Am. Chem. Soc.
1991, 113, 3526.
(17) (a) Bao, H. L.; Qi, X.; Tambar, U. K. J. Am. Chem. Soc. 2011,
133, 1206. (b) Bao, H. L.; Qi, X.; Tambar, U. K. Synlett 2011, 1789.
(18) For a more complete account of the optimization of reaction
parameters, see Table S1.
(19) (a) Donde, Y.; Overman, L. E. J. Am. Chem. Soc. 1999, 121,
2933. (b) Overman, L. E.; Carpenter, N. E. In Organic Reactions;
Overman, L. E., Ed.; Wiley: Hoboken, NJ, 2005; Vol. 66, pp 1−107.
(c) Watson, M. P.; Overman, L. E.; Bergman, R. G. J. Am. Chem. Soc.
2007, 129, 5031 and references therein.
(20) Although we favor this stepwise mechanism, we cannot rule out
a concerted charge-induced rearrangement mechanism that avoids the
intermediacy of heterocycle 7 (signified by the dotted arrow in Scheme
2).
(21) A racemic version of the allylic amination process has been
reported for the synthesis of Vigabatrin: Deleris, G.; Dunogues, J.;
Gadras, A. Tetrahedron 1988, 44, 4243.
18498
dx.doi.org/10.1021/ja307851b | J. Am. Chem. Soc. 2012, 134, 18495−18498
