Vol. 25, No. 4 (2013)
Microwave Assisted Synthesis of α,β-Unsaturated Benzimidazole Derivatives 1855
HCl. The solid formed was washed, filtered and dried, recrys-
tallized from ethanol yield a product of (4a-f).
(KBr) 3379 (Ar-OH), 3231 (NH str). 1680 (C=O), 1562 (C=N)
1H NMR (DMSO d6 + CDCl3) in δ ppm: 9.1 (1H, s, NH benzi-
midazole), 8.4-8.8 (2H, s, pyrimidine NH), 6.4-8.5 (10H, m,
8ArH, 2 CH=CH), 5.62 (1H, s, ArOH) MS: 375.64 (M+1).
Calcd./Anal. (%) [C 61.17/61.25, H 3.77/3.79, N 14.97/14.86].
Antioxidant activity by DPPH method: The scavenging
activity of the synthesized candidates (5a-f) on DPPH radical
was determined according to the methods of Shimada et al.30.
Different concentration of the test compounds in 1.5 mL of
methanol were added to a 1.5 mL (0.2 mM) solution of DPPH
radical in methanol. The above solutions were allowed to react
at room temperature for 0.5 h.After 0.5 h the absorbance values
were measured at 517 nm and converted to percentage of scaven-
ging activity, which was calculated by using the following
formula. The IC50 and percentage inhibition of the newly
synthesized candidates were compared with standard ascorbic
acid and the values were shown in Table-2.
Synthesis of (5a-f): To a solution of (4a-g) (0.01 mol)
suspended in 7 mL acetic acid, barbituric acid (0.01 mol) was
added with constant stirring. The reaction mixture was then
refluxed for 7 h with occasional stirring. The resultant contents
were poured in to in to crushed ice. The crude product was
filtered and recrystallized from methanol.
Microwave assisted synthesis: Barbituric acid (0.01 mol)
was added to a mixture of chalcone (4a-g) (0.01 mol) in acetic
acid. The reaction mixture was irradiated for 2-3 min at 60 %
microwave power with 30 sec interval using a domestic
microwave oven. The reaction progress was monitored by TLC.
The resultant contents were poured in to in to crushed ice with
constant stirring. The isolated product was recrystallized from
methanol.
5-[(2E)-1-(1H-benzimidazol-2-yl)-3-phenylprop-2-en-
1-ylidene]pyrimidine-2,4,6-(1H, 3H, 5H)-trione (5a): Brown
solid, yield 77 %, m.p. 255-258 ºC; IR(KBr) :3230 (NHstr),
1693 (C=O), 1587 (C=N), 1H NMR (DMSO d6 + CDCl3) in δ
ppm: 9.1 (1H, s, NH benzimidazole) 8.0-8.4 (2H, s, pyrimidine
NH) 6.48.1 (11H, m, 9 ArH, 2CH=CH). MS: m/z = 359.21
(M++1). Calcd/Anal. (%) [C67.03/67.12, H3.94/3.81, N15.63/
15.59].
(Ab + As) − Am
×100
Percentage of scavenging activity =
Ab
where, [Ab: absorbance of 1.5 mL DPPH + 1.5 mL methanol,
Am: Absorbance of 1.5 mL DPPH + 1.5 mL drug solution,
As: Absorbance of 1.5 drug + 1.5 mL methanol solution].
RESULTS AND DISCUSSION
5[(2E)-1-(1H-benzimidazol-2-yl)-3-(4 chlorophenyl)-
prop-2-en-1-ylidene]pyrimidine2,4,6(1H,3H,5H)-trione
(5b): Yellow solid, yield 77 %, m.p. 265-267 ºC; IR (KBr):
3238 (NHstr), 1696 (C=O), 1584 (C=N), 1H NMR (DMSO d6
+ CDCl3) in δ ppm: 8.9 (1H, s, NH benzimidazole) 8.4-8.6
(2H, s, pyrimidine NH), 6.4-8.3 (10 H, m, 8ArH, 2CH=CH).
MS: m/z = 394.1 (M+1). Calcd/Anal. (%) [C 61.16/61.23, H
3.34/3.32, N 14.26/14.28].
The highly reactive acidic hydrogen present in the barbituric
acid has a tendency to react with ketone group in the, α,β-
unsaturated carbonyl system in presence of an acetic acid
medium. The structures of the final products were confirmed on
the basis of spectral studies.All the newly synthesized compounds
were characterized by IR, 1H NMR and mass spectroscopic
data. IR spectrum of the 5-[(2E)-1-(1H-benzimidazol-2-yl)-
3-(4-chlorophenyl)prop-2-en-1-ylidene]pyrimidine-2,4,6-
(1H,3H,5H)-trione (5b) showed a strong absorption band at
3238 cm-1 corresponding to benzimidazole NH. The absorption
at 2910 and 2878 cm-1 corresponds to pyrimidine NH/NH. A
sharp absorption at 1696 cm-1 corresponds to carbonyl stretching
and 1232 cm-1 due to aryl chloride. The 1H NMR spectra showed
the singlet peak at δ 8.4 and 8.6 were assigned to pyrimidine
NH/NH. The singlet peak at δ 9.1 corresponding to benzimi-
dazole NH. The doublet for vicinal protons along with the
aromatic multiplet between δ 6.4-8.2 ppm. Mass spectrum of
compound 5b revealed the molecular ion peak [M+2] at m/z
394 corresponding to the molecular mass of the compound.
Free radical scavenging properties of the synthesized
derivatives were evaluated by decrease in the absorption of
the stable DPPH radical at 517 nm. This bleaching of DPPH
absorption occurs when the odd electron of the radical is
paired30.All the newly synthesized barbitone derivatives incor-
porated with a α,β unsaturated benzimidazole derivatives were
showed a good DPPH free radical scavenging activity. In this
study we proposed that decrease in the DPPH absorption due
to the two NH group in the pyrimidine moiety, which can donate
hydrogen atom and exist in radical form and the electron
conjugation effect in the structure stabilizes the radical so that
it does not involved in a destructive biochemical reaction. The
highest activity is shown in the participation of electron
donating group in the aromatic nucleus of the final products.
5-[(2E)-1-(1H-benzimidazol-2-yl)-3-(4-methoxy-
phenyl)prop-2-en-1-ylidene]pyrimidine-2,4,6-(1H,3H,5H)-
trione (5c): Pale green solid, yield 67 %, m.p. 225-2228ºC;
IR (KBr): 3239 (N-H str), 1681 (C=O), 1576 (C=N), 1H NMR
(DMSO d6 + CDCl3) in δ ppm: 8.9 (1H, s, NH benzimidazole)
8.4-8.6 (2H, s, pyrimidine NH), 6.4-8.3 (10H, m, 8 ArH,
2CH=CH). 3.3 (3H, s, OCH3) MS: m/z = 390.12 (M+1). Calcd./
Anal. (%) [C61.16/61.23, H 3.34/3.32, N 14.26/14.28].
5-{(2E)-1-(1H benzimidazol-2-yl)-3-[4(dimethylamino)-
phenyl]prop-2-en-1-ylidene}pyrimidine-2,4,6-(1H,3H,5H)-
trione (5d): Brown solid, yield 76 %, m.p.-210-213 ºC; IR
1
(KBr) 3227 (N-H str). 1678 (C=O), 1569 (C=N), H NMR
(DMSO d6 + CDCl3) in δ ppm: 8.9 (1H, s, NH benzimidazole),
8.5-8.7 (2H, s, pyrimidine NH), 6.3-8.4 (10 H, m, 8Ar H,
2CH=CH). 3.3 (6H, s, N(CH3)2. MS: 402.56 (M+1). Calcd./
Anal. (%) [C 65.83/65.91, H 4.77/4.72, N 17.45/17.53].
5-[(2E)-1-(1H-benzimidazol-2-yl)-3-(3-nitrophenyl)-
prop-2-en-1-ylidene]pyrimidine-2,4,6-(1H,3H,5H)-trione
(5e): Pale brown solid, yield 66 %, m.p.-239-240 ºC; IR (KBr)
3227 (N-H str). 1678 (C=O), 1569 (C=N) 1310 (Ar-NO2), 1H
NMR (DMSO-d6 + CDCl3) in δ ppm: 8.5 (1H, s, NH benzimi-
dazole), 8.2-8.4 (2H, s, pyrimidine NH), 6.4-8.4 (10H, m,
8ArH, 2CH=CH). MS: 405.6 (M+2). Calcd./Anal. (%) [C
59.56/59.71, H 3.25/3.29, N 17.36/17.43].
5-[(2E)-1-(1H-benzimidazol-2-yl)-3-(2-hydroxy-
phenyl)prop-2-en-1-ylidene]pyrimidine-2,4,6-(1H,3H,5H)-
trione (5f): Yellow solid, yield 61 %, m.p. 200-203 ºC; IR
