PRACTICAL SYNTHETIC PROCEDURES
Ring Opening of Benzo-Fused Heterocycles
1117
trometer. NMR spectra were recorded with a Bruker AC-300 using
CDCl3 as the solvent. 13C NMR DEPT was used to assign the C at-
oms. LRMS and HRMS were measured with Shimadzu GC/HS QP-
5000 and Finingan MAT95 S spectrometers, respectively. The pu-
rity of volatile products and the chromatographic analyses (GC)
were determined with a Hewlett-Packard HP-5890 instrument
equipped with a flame ionisation detector and a 12 m capillary col-
umn (0.2 mm diam., 0.33 mm film thickness), using N2 (2 mL/min)
as carrier gas, Tinjector = 275 °C, Tdetector = 300 °C, Tcolumn = 60 °C (3
min) and 60–270 °C (15 °C/min), P = 40 kPa. Specific rotations
were determined with a Perkin Elmer 341 digital polarimeter.
H), 2.50 (d, J = 13.7 Hz, 1 H), 2.93–3.10 (m, 2 H), 3.40 (d, J = 13.7
Hz, 1 H), 3.81–3.87 (m, 2 H), 7.11–7.25 (m, 4 H).
13C NMR (75 MHz, CDCl3): d = 18.0 (CH3), 20.8 (CH2), 22.3
(CH3), 23.7 (CH3), 26.0 (CH), 27.6 (CH), 35.0 (CH2), 35.6 (CH2),
42.3 (CH2), 46.8 (CH2), 50.7 (CH), 63.3 (CH2), 75.2 (C), 125.8
(CH), 126.5 (CH), 129.6 (CH), 132.3 (CH), 136.6 (C), 138.2 (C).
MS (EI, 70 eV): m/z (%) = 272 [M+ – (H2O), 1], 155 (57), 137 (34),
136 (32), 118 (36), 117 (22), 115 (11), 106 (25), 105 (21), 95 (41),
91 (20), 81 (100), 79 (10), 77 (13), 69 (44).
HRMS (EI): m/z calcd for C19H28O (M – H2O): 272.2140; found:
272.2116.
(1R,2S,5R)-1-(2-Hydroxymethylbenzyl)-2-isopropyl-5-methyl-
cyclohexanol (4a)
Spiro Compound 5a
To a blue suspension of lithium powder (150 mg, 21.4 mmol) and a
catalytic amount of DTBB (130 mg, 0.5 mmol; 3 mol%) in anhyd
THF (25 mL) under argon was added dropwise phthalan (1a; 960
mg, 0.88 mL, 8.0 mmol) at 0 °C, and the resulting mixture was
stirred for 6 h (monitored by GC) at the same temperature. Then, the
temperature was cooled down to –78 °C and (–)-menthone (3; 1.23
g, 1.56 mL, 8.0 mmol) was added dropwise. After that, the reaction
mixture was allowed to warm to –20 °C for around 3 h, hydrolysed
with H2O (10 mL), and extracted with EtOAc (3 × 40 mL). The
combined organic layers were dried (Na2SO4) and evaporated (15
Torr). The residue was purified by column chromatography (hex-
ane–EtOAc, 20:1, 85 g Merck silica gel 60, 0.063–0.200 mm) to
give 4a as a colourless oil (1.67 g, 76%); [a]D20 –19.5 (c = 1.0,
CH2Cl2); Rf 0.13 (hexane–EtOAc, 5:1).
To a solution of the diol 4a (276 mg, 1.0 mmol) in anhyd CH2Cl2 (3
mL) under argon was added dropwise first methanesulfonyl chlo-
ride (252 mg, 0.17 mL, 2.2 mmol) and then Et3N (222 mg, 0.30 mL,
2.2 mmol) at 0 °C. The reaction mixture was stirred for 4 h (moni-
tored by GC) at the same temperature. The mixture was then hydrol-
ysed with aq 2 M HCl (5 mL), the organic layer was neutralised with
an aq sat. solution of NaHCO3, washed with H2O (10 mL), extracted
with EtOAc (3 × 15 mL), and the organic layer was dried (Na2SO4)
and evaporated (15 Torr). The residue was purified by column chro-
matography (hexane, 30 g Merck silica gel 60, 0.063–0.200 mm) to
yield 5a as a colourless oil (201 mg, 78%); [a]D20 –29 (c = 0.42,
CH2Cl2); Rf 0.39 (hexane).
IR (film): 2951, 2918, 2853, 1732, 1454, 1072 1363 cm–1.
1H NMR (300 MHz, CDCl3): d = 0.67 (dd, J = 12.5, 14.0 Hz, 1 H),
0.81 (d, J = 6.7 Hz, 3 H), 0.87 (d, J = 6.9 Hz, 3 H), 0.93 (d, J = 7.0
Hz, 3 H), 1.17–1.32 (m, 2 H), 1.50–1.68 (m, 3 H), 1.70–1.82 (m, 1
H), 1.95–2.05 (m, 1 H), 2.16–2.22 (m, 1 H), 2.17 (d, J = 16.0 Hz, 1
H), 3.33 (d, J = 16.0 Hz, 1 H), 4.60–4.72 (m, 2 H), 6.99–7.02 (m, 1
H), 7.07–7.16 (m, 3 H).
13C NMR (75 MHz, CDCl3): d = 18.3 (CH3), 20.9 (CH2), 22.3
(CH3), 24.0 (CH3), 26.2 (CH), 27.9 (CH), 35.5 (CH2), 35.9 (CH2),
42.0 (CH2), 50.3 (CH), 62.0 (CH2), 75.2 (C), 123.9 (CH), 125.4
(CH), 126.3 (CH), 129.2 (CH), 134.0 (C), 134.9 (C).
IR (film): 3350, 2951, 2863, 1701, 1640, 1448 cm–1.
1H NMR (300 MHz, CDCl3): d = 0.81 (d, J = 6.2 Hz, 3 H), 0.87–
1.04 (m, 2 H), 0.98 (d, J = 7.02 Hz, 6 H), 1.21–1.51 (m, 4 H), 1.59–
1.67 (m, 1 H), 1.73–1.78 (m, 1 H), 2.35–2.45 (m, 1 H), 2.43 (d,
J = 13.9 Hz, 1 H), 2.71 (br s, 2 H), 3.61 (d, J = 13.9 Hz, 1 H), 4.42
(d, J = 11.9 Hz, 1 H), 4.81 (d, J = 11.9 Hz, 1 H), 7.14–7.27 (m, 3 H),
7.33–7.38 (m, 1 H).
13C NMR (75 MHz, CDCl3): d = 18.0 (CH3), 21.0 (CH2), 22.3
(CH3), 23.8 (CH3), 25.9 (CH), 28.0 (CH), 34.8 (CH2), 42.4 (CH2),
46.8 (CH2), 51.1 (CH), 63.3 (CH2), 74.7 (C), 126.9 (CH), 127.3
(CH), 130.6 (CH), 133.0 (CH), 136.0 (C), 140.5 (C).
MS (EI, 70 eV): m/z (%) = 258 (M+, 27), 173 (54), 146 (17), 145
(23), 117 (10), 105 (16), 104 (100), 103 (12), 78 (15), 69 (27).
MS (EI, 70 eV): m/z (%) = 258 [M+ – H2O, 3], 104 (100), 95 (11),
81 (29), 69 (21).
HRMS (EI): m/z calcd for C18H26O (M): 258.1984; found:
258.1978.
HRMS (EI): m/z calcd for C18H26O (M – H2O): 258.1984; found:
258.1971.
Spiro Compound 5b
To a solution of the diol 4b (290 mg, 1.0 mmol) in anhyd CH2Cl2 (3
mL) under argon was added dropwise first methanesulfonyl chlo-
ride (252 mg, 0.17 mL, 2.2 mmol) and then Et3N (222 mg, 0.30 mL,
2.2 mmol) at 0 °C. The reaction mixture was stirred for 1 h (moni-
tored by GC) at the same temperature. The reaction mixture was
then hydrolysed with aq 2 M HCl (5 mL), the organic layer was neu-
tralised with an aq sat. solution of NaHCO3, washed with H2O (10
mL), extracted with EtOAc (3 × 15 mL), and the organic layer was
dried (Na2SO4) and evaporated (15 Torr). The residue was purified
by column chromatography (hexane, 30 g Merck silica gel 60,
0.063–0.200 mm) to yield 5b as a colourless oil (149 mg, 55%);
[a]D20 –87.5 (c = 0.76, CH2Cl2); Rf 0.50 (hexane).
(1R,2S,5R)-1-[2-(2-Hydroxyethyl)benzyl]-2-isopropyl-5-meth-
ylcyclohexanol (4b)
To a blue suspension of lithium powder (150 mg, 21.4 mmol) and a
catalytic amount of DTBB (130 mg, 0.5 mmol; 3 mol%) in anhyd
THF (25 mL) under argon was added dropwise isochroman (1b;
1.07 g, 1.00 mL, 8.0 mmol) at 20 °C, and the resulting mixture was
stirred for 4 h (monitored by GC) at the same temperature. Then, the
temperature was cooled down to –78 °C and (–)-menthone (3; 1.23
g, 1.56 mL, 8.0 mmol) was added dropwise. After that, the reaction
mixture was allowed to warm to –20 °C for around 3 h, hydrolysed
with H2O (20 mL), and extracted with EtOAc (3 × 40 mL). The
combined organic layers were dried (Na2SO4) and evaporated (15
Torr). The residue was purified by column chromatography (hex-
ane–EtOAc, 20:1, 85 g Merck silica gel 60, 0.063–0.200 mm) to
yield 4b as a colourless oil (1.57 g, 68%); [a]D20 –29.2 (c = 1.1,
CH2Cl2); Rf 0.37 (hexane–EtOAc, 2:1).
IR (film): 2940, 2864, 1733, 1493, 1454 cm–1.
1H NMR (300 MHz, CDCl3): d = 0.44 (dd, J = 12.2, 12.35 Hz, 1 H),
0.71 (d, J = 6.5 Hz, 3 H), 0.79–0.89 (m, 1 H), 0.94 (d, J = 7.0 Hz, 3
H), 0.98 (d, J = 6.8 Hz, 3 H), 1.0–1.15 (m, 1 H), 1.39–1.73 (m, 5 H),
2.30–2.38 (m, 1 H), 2.35 (d, J = 14.2 Hz, 1 H), 2.60 (dd, J = 4.7 Hz,
15.0 Hz, 1 H), 3.16–3.26 (m, 1 H), 3.56 (t, J = 11.6 Hz, 1 H), 3.67
(d, J = 14.2 Hz, 1 H), 3.77–3.83 (m, 1 H), 6.97–7.25 (m, 4 H).
IR (film): 3375, 3060, 2946, 1722, 1596, 1454 cm–1.
1H NMR (300 MHz, CDCl3): d = 0.76 (d, J = 6.55 Hz, 3 H), 0.82–
0.95 (m, 1 H), 0.98 (d, J = 7.0 Hz, 3 H), 1.00 (d, J = 7.1, 3 H), 1.18–
1.58 (m, 6 H), 1.71–1.75 (m, 1 H), 2.07 (br s, 2 H), 2.32–2.41 (m, 1
13C NMR (75 MHz, CDCl3): d = 18.4 (CH3), 20.7 (CH2), 22.4
(CH3), 24.1 (CH3), 25.9 (CH), 26.9 (CH), 35.5 (CH2), 39.2 (CH2),
Synthesis 2004, No. 7, 1115–1118 © Thieme Stuttgart · New York
