Triazole-Stabilized Allenic Anions
J . Org. Chem., Vol. 62, No. 3, 1997 719
were heated under reflux in toluene (30 mL) for 30 h. The
solvent was evaporated under reduced pressure, and the
residues were chromatographed on silica gel (hexane/ethyl
acetate 5 :1).
1-(1,2,4-Tr ia zol-1-yl)-3-p h en ylp r op a r gyl et h yl et h er
(11): obtained as a brown oil; yield 82%; 1H NMR δ 1.25 (t, 3
H, J ) 7.0 Hz), 3.63-3.80 (m, 2 H), 6.47 (s, 1 H), 7.34-7.41
(m, 3 H), 7.51-7.54 (m, 2 H), 8.02 (s, 1 H), 8.59 (s, 1 H); 13C
NMR δ 14.6, 63.9, 78.4, 80.9, 88.3, 120.5, 128.4, 129.6, 131.9,
142.6, 152.0. Anal. Calcd for C13H13N3O: C, 68.71; H, 5.77;
N, 18.49. Found: C, 68.50; H, 5.69; N, 18.50.
appropriate electrophile (EtBr, C5H11Br, allyl bromide or
N-benzylidineaniline; 5 mmol; for C6H13I, 10 mmol) was then
added. After the solution was stirred at -78 °C for an
additional 5 to 10 min, the reaction was quenched at this
temperature with water (50 mL). The mixture was extracted
with diethyl ether (3 × 100 mL). Evaporation of the solvent
gave a residue, which was hydrolyzed in a mixture of ethanol
(15 mL), water (15 mL), and HCl (2 mL) at room temperature
for 2 h. The resulting solution was extracted with diether (3
× 100 mL), washed with water (100 mL), and dried over
anhydrous MgSO4. Evaporation of the solvent gave a residue
which was separated by column chromatography (hexane/ethyl
acetate, 25:1).
1-(1,2,4-Tr ia zol-1-yl)-2-n on yn yl eth yl eth er (33): ob-
1
tained as a colorless oil; yield 86%; H NMR δ 0.91 (t, 3 H, J
Eth yl 3-p h en yl-2-p en ten oa te (9b): Obtained as two
) 7.2 Hz), 1.21 (t, 3 H, J ) 7.1 Hz), 1.28-1.44 (m, 6 H), 1.53-
1.63 (m, 2 H), 2.31-2.36 (m, 2 H), 3.52-3.60 (m, 1 H), 3.62-
3.72 (m, 1 H), 6.24 (t, 1 H, J ) 1.9 Hz), 7.98 (s, 1 H), 8.51 (s,
1 H); 13C NMR δ 13.8, 14.6, 18.5, 22.3, 27.8, 28.4, 31.1, 63.4,
72.7, 78.1, 90.1, 142.4, 151.8. Anal. Calcd for C13H21N3O: C,
66.35; H, 8.99; N, 17.86. Found: C, 66.60; H, 9.20; N, 18.00.
Gen er a l P r oced u r e for th e P r ep a r a tion of Allen es 10
a n d 19, r,â-Un sa tu r a ted Ester 9a , a n d Bu ten olid e 20. To
a solution of 1-(1,2,4-triazol-1-yl)propargyl ethyl ether (11) (5
mmol) in THF (70 mL) at -78 °C was added n-butyllithium
(2.5 M in cyclohexane, 4 mL, 10 mmol). The solution was
stirred at this temperature for 5 min, and the appropriate
electrophile (MeI or cyclohexanone; 10 mmol) was then added.
After the solution was stirred at -78 °C for an additional 5 to
10 min, the reaction was quenched at this temperature with
water (50 mL) and the solution was extracted with diethyl
ether (3 × 100 mL). Evaporation of the solvent gave a residue.
In the case of 10. The pure (>95%) compound was obtained.
In the case of 19, pure compound was obtained after column
chromatography (hexane/ethyl acetate 20:1). Hyd r olysis. In
the case of 9a , the compound 10 was dissolved in a mixture of
ethanol (15 mL), water (15 mL), and HCl (2 mL) and kept for
2 h. In the case of 20, compound 19 was dissolved in a mixture
of ethanol (15 mL), water (15 mL), and HCl (2 mL) and heated
under reflux for 2 h. The resulting solution was extracted with
diether (3 × 100 mL), washed with water (100 mL), and dried
over anhydrous MgSO4. Evaporation of the solvent gave a
residue which was separated by column chromatography
(hexane/ethyl acetate 25:1).
diastereoisomers. E-isom er : a colorless oil, lit.20 bp 91-94.5
1
°C/1 mmHg; yield 23%; H NMR δ 1.08 (t, 3 H, J ) 7.5 Hz),
1.32 (t, 3 H, J ) 7.1 Hz), 3.11 (q, 2 H, J ) 7.5 Hz), 4.21 (q, 2
H, J ) 7.1 Hz), 6.02 (s, 1 H), 7.35-7.39 (m, 3 H), 7.42-7.46
(m, 2 H); 13C NMR δ 13.5, 14.3, 24.3, 59.8, 116.8, 128.6, 128.8,
1
141.2, 162.0, 166.4. Z-isom er : a colorless oil; yield 70%; H
NMR δ 1.03-1.09 (m, 6 H), 2.45 (q, 2 H, J ) 7.2 Hz), 3.98 (q,
2 H, J ) 7.1 Hz), 5.88 (s, 1 H), 7.13-7.17 (m, 2 H), 7.29-7.36
(m, 3 H); 13C NMR δ 12.0, 13.9, 33.3, 59.6, 116.3, 126.9, 127.4,
127.7, 140.4, 160.8, 166.1.
Eth yl 3-p h en yl-2-octen oa te (9c): obtained as two dia-
stereoisomers. E isom er : a colorless oil; yield 15%; 1H NMR
δ 0.86 (t, 3 H, J ) 7.1 Hz), 1.25-1.50 (m, 9 H), 3.10 (t, 2 H, J
) 7.4 Hz), 4.22 (q, 2 H, J ) 7.1 Hz), 6.03 (s, 1 H), 7.34-7.48
(m, 5 H); 13C NMR δ 14.0, 14.3, 22.4, 28.7, 31.0, 31.9, 59.8,
117.3, 126.7, 128.5, 128.7, 141.5, 160.8, 166.5. Z isom er : a
1
colorless oil; yield 64%; H NMR δ 0.85 (t, 3 H, J ) 7.1 Hz),
1.05 (t, 3 H, J ) 7.2 Hz), 1.24-1.30 (m, 4 H), 1.31-1.41 (m, 2
H), 2.42 (t, 2 H, J ) 6.9 Hz), 3.97 (q, 2 H, J ) 7.2 Hz), 5.87 (s,
1 H), 7.12-7.18 (m, 2 H), 7.28-7.36 (m, 3 H); 13C NMR δ 13.9,
22.3, 26.9, 31.2, 40.3, 59.6, 117.1, 127.0, 127.4, 127.7, 140.3,
159.7, 166.0. Anal. Calcd for C16H22O2: C, 78.01; H, 9.00.
Found: C, 77.89; H, 9.36.
Eth yl 3-p h en yl-2,5-h exa d ien oa te (9d ): obtained as two
diastereoisomers. E isom er : a colorless oil; yield 28%; 1H
NMR δ 1.31 (t, 3 H, J ) 7.1 Hz), 3.87-3.90 (m, 2 H), 4.21 (q,
2 H, J ) 7.1 Hz), 4.99-5.14 (m, 2 H), 5.83-5.92 (m, 1 H), 6.15
(s, 1 H), 7.33-7.36 (m, 3 H), 7.44-7.49 (m, 2H); 13C NMR δ
14.2, 35.3, 59.8, 116.1, 117.9, 126.7, 128.4, 128.9, 135.2, 141.0,
156.7, 166.1. Anal. Calcd for C14H16O2: C, 77.75; H, 7.46.
Found: C, 78.13; H, 7.66. Z isom er : a colorless oil; yield 52%;
1H NMR δ 1.07 (t, 3 H, J ) 7.2 Hz), 3.16-3.19 (m, 2 H), 3.99
(q, 2 H, J ) 7.2 Hz), 5.07-5.13 (m, 2 H), 5.76-5.85 (m, 1 H),
5.90 (s, 1 H), 7.17-7.20 (m, 2 H), 7.30-7.37 (m, 3 H); 13C NMR
δ 13.8, 44.1, 59.6, 117.9, 118.0, 127.0, 127.5, 127.7, 133.6, 140.0,
157.0, 165.8. Anal. Calcd for C14H16O2: C, 77.75; H, 7.46.
Found: C, 78.03; H, 7.64.
E t h yl (Z)-3,4-d ip h en yl-4-(p h en yla m in o)-2-b u t en oa t e
(24): yield 70%; mp 128-130 °C; 1H NMR δ 1.03 (t, 3 H, J )
7.1 Hz), 3.96 (q, 2 H, J ) 7.1 Hz), 4.14 (d, 1 H, J ) 4.1 Hz),
5.08 (d, 1 H, J ) 4.1 Hz), 6.41 (s, 1 H), 6.67 (d, 2 H, J ) 8.5
Hz), 6.77 (t, 1 H, J ) 7.2 Hz), 6.98-7.02 (m, 2 H), 7.18-7.30
(m, 10 H); 13C NMR δ 13.8, 59.9, 65.8, 113.4, 118.2, 118.5,
127.6, 127.7, 127.9, 128.1, 128.8, 129.2, 138.1, 139.1, 146.5,
156.8, 166.1. Anal. Calcd for C24H23NO2: C, 80.64; H, 6.49;
N, 3.92. Found: C, 81.03; H, 6.62; N, 3.84.
1-E t h oxy-1-[5-m e t h yl-1,2,4-t r ia zol-1-yl]-3-m e t h yl-3-
p h en yla llen e (10): obtained as a colorless oil; yield 100%; 1H
NMR δ 1.40 (t, 3 H, J ) 7.1 Hz), 2.39 (s, 3 H), 2.50 (s, 3 H),
3.88 (q, 2 H, J ) 7.1 Hz), 7.30-7.42 (m, 3 H), 7.56-7.60 (m, 2
H), 7.89 (s, 1 H); 13C NMR δ 12.8, 14.2, 19.7, 64.9, 120.4, 126.5,
128.4, 128.6, 128.7, 135.7, 151.0, 152.9, 185.0.
1-Eth oxy-1-[5-(1-h yd r oxycycloh exyl)-1,2,4-tr ia zol-1-yl]-
3-(1-h yd r oxycycloh exyl)-3-p h en yla llen e (19): yield 52%;
mp 127-129 °C; 1H NMR δ 1.10-2.15 (m, 23 H), 3.55 (s, 1 H),
3.86-4.00 (m, 3 H), 7.30-7.45 (m, 5 H), 7.34 (s, 1 H); 13C NMR
δ 14.4, 21.4, 21.5, 21.6, 21.7, 25.0, 25.1, 36.2, 36.8, 65.2, 71.1,
74.2, 127.8, 128.1, 128.6, 130.5, 134.0, 135.6, 149.9, 160.7,
185.1. Anal. Calcd for C25H33N3O3: C, 70.89; H, 7.85; N, 9.92.
Found: C, 71.12; H, 8.10; N, 10.13.
Eth yl 3-p h en yl-2-bu ten oa te (9a ): obtained as two dia-
stereoisomers. E isom er : a colorless oil, lit.20 bp 115-116 °C/5
mmHg; yield 17%; 1H NMR δ 1.34 (t, 3 H, J ) 7.1 Hz), 2.61 (s,
3 H), 4.23 (q, 2 H, J ) 7.1 Hz), 6.16-6.17 (m, 1 H), 7.37-7.40
(m, 3 H), 7.47-7.51 (m, 2 H); 13C NMR δ 14.3, 17.9, 59.7, 117.1,
Eth yl 3-h exyl-2-n on en oa te (39): obtained as a colorless
1
126.2, 128.4, 128.6, 128.9, 133.0, 142.2, 155.4, 166.8.
Z
oil; yield 65%; H NMR δ 0.88-0.97 (m, 6 H), 1.26-1.50 (m,
isom er : a colorless oil; yield 70%; 1H NMR δ 1.07 (t, 3 H, J )
7.1 Hz), 2.17 (s, 3 H), 3.99 (q, 2 H, J ) 7.1 Hz), 5.90 (s, 1 H),
7.18-7.21 (m, 2 H), 7.29-7.34 (m, 3 H); 13C NMR δ 13.9, 27.1,
59.7, 117.8, 126.8, 127.6, 127.8, 140.8, 155.2, 165.9.
19 H), 2.14 (t, 2 H, J ) 7.4 Hz), 2.60 (t, 2 H, J ) 7.4 Hz), 4.15
(q, 2 H, J ) 7.1 Hz), 5.63 (s, 1 H); 13C NMR δ 14.0, 14.3, 22.5,
22.6, 27.6, 28.7, 29.0, 29.6, 31.6, 31.7, 32.2, 38.4, 59.4, 115.0,
164.8, 166.6. Anal. Calcd for C17H32O2: C, 76.06; H, 12.02.
Found: C, 75.89; H, 12.21.
3′-P h en ylcycloh exa n espir o-4′-r,â-bu ten olid e (20): yield
98%; mp 77-79 °C; 1H NMR δ 1.22-2.07 (m, 10 H), 6.17 (s, 1
H), 7.45-7.55 (m, 5 H); 13C NMR δ 22.0, 24.4, 34.4, 89.3, 115.5,
127.4, 128.8, 130.2, 130.8, 171.6, 172.7. Anal. Calcd for
C15H16O2: C, 78.92; H, 7.06. Found: C, 78.95; H, 7.30.
Gen er a l P r oced u r e for th e P r ep a r a tion of 9b-d , 24,
a n d 39. To a solution of 1-(1,2,4-triazol-1-yl)propargyl ethyl
ethers 11 or 33 (5 mmol) in THF (70 mL) at -78 °C was added
n-butyllithium (2.5 M in cyclohexane, 4 mL, 10 mmol). The
solution was stirred at this temperature for 5 min, and the
Gen er a l P r oced u r e for th e P r ep a r a tion of 16a -c. To
a solution of 1-(1,2,4-triazol-1-yl)propargyl ethyl ethers 11 (5
mmol) in THF (70 mL) at -78 °C was added n-butyllithium
(2.5 M in cyclohexane, 2 mL, 10 mmol). The solution was
stirred at this temperature for 5 min, and the appropriate
electrophile (benzaldehyde, 4-tolualdehyde, or octanal; 10
mmol) was then added. After the solution was stirred at -78
°C for an additional 5 to 10 min, the reaction was quenched
at this temperature with water (50 mL). HCl (2 M, 8 mL) was
