4970 J ournal of Medicinal Chemistry, 2000, Vol. 43, No. 26
Brown et al.
manner similar to 14 but using 4-bromobenzoyl chloride as
starting material to give, as a colorless solid, 19 (74%): mp
214-215 °C; H NMR (DMSO-d6) δ 1.60(m, 4H), 2.86(t, J )
12.5 Hz, 3H), 3.50(m, 8H), 3.92(d, J ) 12.5 Hz, 2H), 6.80(d, J
) 7.4 Hz, 2H), 7.37(d, J ) 8.3 Hz, 2H), 7.61(d, J ) 8.3 Hz,
2H), 8.13(d, J ) 7.4 Hz, 2H); EI-MS m/z 457 (M + H). Anal.
(C22H25BrN4O2) C, H, N.
5-chloro-3-methyl-1,2,4-thiadiazole, to give, as a colorless solid
after crystallization from EtOH, 22 (64%): mp 173-174 °C;
1H NMR (CDCl3) δ 1.73(m, 2H), 1.85(m, 2H), 2.39(s, 3H), 3.02-
(m, 4H), 3.12(t, J ) 11.7 Hz, 2H), 3.27(m, 1H), 3.65(m, 4H),
3.92(d, J ) 11.7 Hz, 2H), 7.58(d, J ) 7.9 Hz, 2H), 7.68(d, J )
7.9 Hz, 2H); EI-MS m/z 514 (M + H). Anal. (C19H24BrN5O3S2)
C, H, N.
1
Exa m p les of Syn th etic Rou te B. 1-(4-Iod op h en ylsu l-
fon yl)-4-(1-(4-p yr id yl)p ip e r id in -4-ylca r b on yl)p ip e r a -
zin e (7). Thionyl chloride (0.21 mL, 2.86 mmol) was added to
a suspension of 27 (0.29 g, 1.42 mmol) in CH2Cl2 (5 mL) and
the mixture stirred for 0.5 h. The solvent was evaporated to a
give a solid, which was suspended in CH2Cl2 (5 mL) and added
to a suspension of N-4-iodophenylsulfonylpiperazine (0.5 g,
1.42 mmol) in CH2Cl2 (5 mL) and Et3N (1.4 mL, 10 mmol).
The mixture was stirred for 18 h and the organic phase washed
with H2O, dried and evaporated to give a solid. The solid was
purified by chromatography on silica gel in 5% MeOH/CH2Cl2
to give, as a colorless solid, 7 (0.235 g, 31%): mp 211-213 °C;
1H NMR (DMSO-d6) δ 1.52(m, 4H), 2.82(m, 1H), 2.95(m, 6H),
3.55(m, 4H), 3.92(d, J ) 13.1 Hz, 2H), 6.75(d, J ) 5.7 Hz, 2H),
7.48(d, J ) 8.3 Hz, 2H), 8.04(d, J ) 8.3 Hz, 2H), 8.11(d, J )
3.8 Hz, 2H); EI-MS m/z 541 (M + H). Anal. (C21H25IN4O3S) C,
H, N.
1-(4-P yr im id in yl)-4-(1-(4-br om op h en ylsu lfon yl)p ip er -
a zin -4-ylca r bon yl)p ip er id in e (25). 31 (170 mg, 0.4 mmol)
and 4-chloropyrimidine‚2HCl (78 mg. 0.41 mmol) in absolute
EtOH (10 mL) and Et3N (0.5 mL, 3.5 mmol) were heated under
reflux for 2 h. The solution was evaporated under vacuum and
H2O (50 mL) added. The aqueous mixture was extracted with
EtOAc (2 × 50 mL), washed with water, brine and dried. The
EtOAc was evaporated under vacuum to give an oil which was
dissolved in EtOAc and purified by flash column chromatog-
raphy on neutral alumina (ICN Alumina N 32-63) eluting with
an increasing concentration of MeOH/EtOAc (0-10%). The
resulting solid was recrystallized from a mixture of EtOAc/
THF/isohexane and then from MeCN to give, as a solid, 25
1
(155 mg, 75%): mp 197-198 °C; H NMR (DMSO-d6) δ 1.80-
(m, 4H), 2.70(m, 1H), 3.05(m, 6H), 3.65(bs, 4H), 4.40(m, 2H),
6.50(d, J ) 6.4 Hz, 1H), 7.65(d, J ) 8.0 Hz, 2H), 7.76(d, J )
8.0 Hz, 2H), 8.20(d, J ) 6.4 Hz, 1H), 8.60(s, 1H); EI-MS m/z
494 (M + H). Anal. (C20H24BrN5O3S) C, H, N.
4-(1-(4-Br om op h en ylsu lfon yl)p ip er a zin -4-ylca r bon yl)-
p ip er id in e (31). 2918 (1.30 g, 4 mmol) was added to 4-(4-
bromobenzenesulfonyl)piperazine (1.23 g, 4 mmol) in CH2Cl2
(50 mL) and the mixture stirred for 40 h. The CH2Cl2 solution
was washed with H2O, dried and evaporated to a foam which
crystallized on trituration with EtOAc. The solid was purified
by chromatography on a silica Bond Elut column, eluting with
2% MeOH/ CH2Cl2 to give, as a colorless solid, 30 (1.54 g,
1-(2-Meth yl-4-p yr im id in yl)-4-(1-(4-br om op h en ylsu lfo-
n yl)p ip er a zin -4-ylca r bon yl)p ip er id in e (26). 4-Chloro-2-
methylpyrimidine (135 mg, 1.07 mmol) was added to a solution
of 31 (415 mg, 1.0 mmol) in THF (15 mL) containing Et3N (0.2
mL, 1.5 mmol). The mixture was heated at reflux for 16 h,
allowed to cool and the THF evaporated. The residue was
treated with H2O (20 mL) and the aqueous phase extracted
with EtOAc (3 × 20 mL). The combined organic phases were
washed with saturated brine (1 × 20 mL) dried and evaporated
to give an oil which was purified by column chromatography
on silica gel. Elution with CH2Cl2/MeOH/0.88 NH4OH (96:3:
1) gave an oil on evaporation. Trituration with Et2O (10 mL)
gave, as a colorless solid, 26 (152 mg, 30%): mp 200-202 °C;
1H NMR (CDCl3) δ 1.70(m, 4H), 2.50(s, 3H), 2.67(m, 1H), 2.94-
(m, 2H), 3.05(m, 4H), 3.68(m, 4H), 4.41(d, J ) 12.4 Hz, 2H),
6.30(d, J ) 6.1 Hz, 1H), 7.62(d, J ) 8.3 Hz, 2H), 7.70(d, J )
8.3 Hz, 2H), 8.10(d, J ) 6.1 Hz, 1H); EI-MS m/z 508 (M + H).
Anal. (C21H26BrN5O3S) C, H, N.
Exa m p les of Syn th etic Rou te C. 4-(N-Boc-p ip er a zin -
4-ylca r bon yl)p ip er id in e (34). Na2CO3 (4.52 g, 42.6 mmol)
was stirred with isonipecotic acid (5.0 g, 38.7 mmol) in H2O
(80 mL) and benzyl chloroformate (6.82 g, 5.71 mL, 40 mmol)
added. The mixture was stirred for 18 h and acidified with 2
M HCl, before extraction with EtOAc. The organic phase was
washed with H2O, dried and evaporated to an oil. The oil was
purified by column chromatography on silica gel in CH2Cl2,
eluting with 5% MeOH/CH2Cl2 to give after evaporation, as a
colorless oil 32 (4.45 g, 44%): 1H NMR (CDCl3) δ 1.67(m, 2H),
1.92(m, 2H), 2.51(m, 1H), 2.96(m, 2H), 4.09(m, 2H), 5.13(s, 2H),
7.33(m, 5H),), exchangeable protons not observed; EI-MS m/z
264 (M + H).
1
75%): mp 209-210 °C; H NMR (CDCl3) δ 1.34(s, 9H), 1.65-
(m, 4H), 2.51(m, 1H), 2.72(m, 2H), 3.03(t, 4H), 3.63(m, 4H),
4.10(d, 2H), 7.58(d, 2H), 7.68(d, 2H); EI-MS m/z 516 (M + H).
30 (1.53 g, 2.96 mmol) was stirred in TFA (10 mL, 130 mmol)
for 1 h, and the TFA evaporated. H2O (25 mL) was added and
the mixture made basic with excess of Na2CO3 to pH 11. The
aqueous was extracted with EtOAc and the organic phase
washed with brine, dried and evaporated to give, as a colorless
1
solid, 31 (693 mg, 57%): mp 158-162 °C; H NMR (DMSO-
d6) δ 1.43(m, 4H), 2.47(m, 2H), 2.62(m, 1H), 2.90(m, 6H), 3.53-
(m, 4H), 7.65(d, 2H), 7.87(d, 2H), exchangeable protons not
observed; EI-MS m/z 416 (M + H). Anal. (C16H22BrN3O3S‚
0.75H2O) C, H, N.
1-(2-Oxazolin yl)-4-(1-(4-br om oph en ylsu lfon yl)piper azin -
4-ylca r bon yl)p ip er id in e (20). 31 (1.01 g, 2.4 mmol) was
dissolved in dry THF (50 mL) and 2-chloroethyl isocyanate
(0.225 mL, 2.6 mmol) was added. The reaction mixture was
stirred for 2 h. The solution was diluted with EtOAc, filtered
through a plug of neutral alumina and evaporated to dryness
to afford a colorless, waxy solid. This solid was dissolved in
H2O (100 mL) and heated to 100 °C for 0.5 h. The clear solution
was basified with excess of NH4OH (d ) 0.880) and extracted
with CH2Cl2 (3 × 30 mL). The extracts were washed with H2O,
brine and dried. The organic phase was evaporated to dryness
and the residue recrystallized from EtOAc/isohexane to give,
as a colorless solid, 20 (448 mg, 48%): mp 210-212 °C; 1H
NMR (DMSO-d6) δ 1.41(m, 4H), 2.70(m, 3H), 2.90(m, 4H), 3.55-
(m, 6H), 3.72(d, J ) 12.4 Hz, 2H), 4.18(t, J ) 7.9 Hz, 2H),
7.62(d, J ) 8.2 Hz, 2H), 7.83(d, J ) 8.2 Hz, 2H); EI-MS m/z
485 (M + H). Anal. (C19H25BrN4O4S) C, H, N.
1-Hydroxybenzotriazole (4.67 g, 34.5 mmol) and 1-(3-di-
methylaminopropyl)-3-ethylcarbodiimide hydrochloride (4.79
g, 25.3 mmol) were added to a solution of 32 (6.0 g, 23 mmol)
and Boc-piperazine (4.24 g, 23 mmol) in DMF (75 mL). The
mixture was stirred for 18 h and evaporated. Et2O was added
to the residue, and the organic layer washed with 2 M NaOH,
saturated citric acid and H2O. The organic phase was dried
and evaporated to give, as a colorless waxy solid, 33 (7.4 g,
76%): 1H NMR (CDCl3) δ 1.48(s, 9H), 1.73(m, 4H), 2.64(m,
1H), 2.87(m, 2H), 3.48(m, 8H), 4.23(d, 2H), 5.12(s, 2H), 7.33-
(m, 5H); EI-MS m/z 432 (M + H).
1-(2-Th ia zolin yl)-4-(1-(4-b r om op h en ylsu lfon yl)p ip er -
a zin -4-ylca r bon yl)p ip er id in e (21). Compound 21 was pre-
pared in a manner similar to 20 by using 2-chloroethyl
isothiocyanate as the starting material to give 21, as a colorless
1
solid, (71%): mp 208-210 °C; H NMR (DMSO-d6) δ 1.40(m,
2H), 1.49(m, 2H), 2.72(m, 1H), 2.95(m, 6H), 3.22(t, J ) 7.9 Hz,
2H), 3.52(m, 4H), 3.72(d, J ) 12.3 Hz, 2H), 3.82(t, J ) 7.9 Hz,
2H), 7.62(d, J ) 8.2 Hz, 2H), 7.83(d, J ) 8.2 Hz, 2H); EI-MS
m/z 501 (M + H). Anal. (C19H25BrN4O3S2) C, H, N.
1-(3-Meth yl-1,2,4-th ia d ia zin -5-yl)-4-(1-(4-br om op h en yl-
su lfon yl)p ip er a zin -4-ylca r b on yl)p ip er id in e (22). Com-
pound 22 was synthesized as for 25 below, but starting with
33 (3.71 g, 8.6 mmol) was hydrogenated over 5% Pd/C (120
mg) in EtOH (100 mL) at atmospheric pressure for 18 h. The
catalyst was filtered and the EtOH evaporated. Trituration
of the residue with Et2O gave, as a colorless solid, 34 (1.81 g,
71%): 1H NMR (CDCl3) δ 1.47(s, 9H), 1.67(m, 4H), 2.64(m,
3H), 3.14(m, 2H), 3.50(m, 8H); EI-MS m/z 298 (M + H). Anal.
(C15H27N3O3) C, H, N.
