Synthesis and reactivity of new aminophenolate complexes of nickel

Article abstract of DOI:10.3390/molecules190913603

New well-defined, paramagnetic nickel complexes have been prepared and characterized by X-ray crystallography. The complexes were found to be active for the cross-coupling of alkyl electrophiles (especially ethyl 2-bromobutyrate) with alkyl Grignard reagents. The ligand architecture in these new complexes could potentially be rendered chiral, opening up future possibilities for performing asymmetric cross-coupling reactions.

Full text of DOI:10.3390/molecules190913603

Molecules 2014, 19, 13603-13613; doi:10.3390/molecules190913603
OPEN ACCESS
molecules
ISSN 1420-3049
www.mdpi.com/journal/molecules
Article
Synthesis and Reactivity of New Aminophenolate Complexes
of Nickel
Siqi Yu 1, Huan Wang 1, Jill E. Sledziewski 1, Venkata N. Madhira 2, Cyrus G. Takahashi 2,
Michelle K. Leon 1, Yulia B. Dudkina 3, Yulia H. Budnikova 3 and David A. Vicic 1,*
1
Department of Chemistry, Lehigh University, 6 E. Packer Ave., Bethlehem, PA 18015, USA;
E-Mails: siy212@lehigh.edu (S.Y.); sanni.wangh@gmail.com (H.W.); jillsledz@yahoo.com (J.E.S.);
mkl215@lehigh.edu (M.K.L.)
2
Department of Chemistry, University of Hawaii, 2545 McCarthy Mall, Honolulu, HI 96822, USA;
E-Mails: sharma.madhira@gmail.com (V.N.M.); cyrus.takahashi@gmail.com (C.G.T.)
3
A.E. Arbuzov Institute of Organic and Physical Chemistry, Kazan Scientific Center of Russian
Academy of Sciences, 8 Arbuzov str., Kazan 420088, Russia;
E-Mails: dudkina.yu@gmail.com (Y.B.D.); yulia@iopc.ru (Y.H.B.)
* Author to whom correspondence should be addressed; E-Mail: dav512@lehigh.edu or
vicic@lehigh.edu; Tel.: +1-610-758-3466; Fax: +1-610-758-6536.
Received: 8 July 2014; in revised form: 27 August 2014 / Accepted: 28 August 2014 /
Published: 2 September 2014
Abstract: New well-defined, paramagnetic nickel complexes have been prepared and
characterized by X-ray crystallography. The complexes were found to be active for
the cross-coupling of alkyl electrophiles (especially ethyl 2-bromobutyrate) with alkyl
Grignard reagents. The ligand architecture in these new complexes could
potentially be rendered chiral, opening up future possibilities for performing asymmetric
cross-coupling reactions.
Keywords: nickel; cross-coupling; coordination chemistry; paramagnetic complexes
1. Introduction
The realization of efficient and transition metal catalyzed alkyl-alkyl cross-coupling reactions poses
significant challenges. A metal has to activate a bulky and electron rich alkyl electrophile (versus
sterically less encumbered and less electron rich aryl and vinyl substrates). Transition metal alkyl

Molecules 2014, 19
13604
complexes, which can be intermediates in alkyl-alkyl cross-coupling reactions, are also prone to
undesired β-hydrogen eliminations. Finally, it must be taken into account that alkyl halides can react
with transition metals by one-electron processes affording alkyl radicals, which then must be tamed to
participate in a selective reaction. Despite these inherent obstacles, much progress has been made in
recent years in identifying active catalysts for alkyl-alkyl cross-coupling reactions, especially based on
nickel [1–7]. Presently, much focus is dedicated to developing new catalysts for coupling secondary alkyl
electrophiles, with the hope that the coupling reactions could be rendered enantioselective [5,6,8–10].
One interesting development in the coupling of secondary alkyl electrophiles has been the
identification of well-defined amido complexes of nickel that mediate Kumada couplings with alkyl
Grignard reagents [1,11,12]. It was determined that the nickel pincer complex 1 (Scheme 1) can
catalytically couple primary alkyl halides with primary Grignard reagents in excellent yields [12].
However, when this same nickel pincer complex was used to carry out reactions with secondary alkyl
electrophiles (Equations (A) and (B) in Scheme 1), yields of cross-coupled product were only 4 and
46%, respectively. This prompted the design of the sterically less encumbered analogue 2 (Scheme 1),
which exhibited much higher activity towards secondary alkyl electrophiles [11].
Scheme 1. Comparison of amido complexes of nickel for the coupling of secondary alkyl electrophiles.
Based on Hu’s results with the second generation catalyst 2, we imagined that 1,2-aminophenolate
ligands (Figure 1) might also be active in alkyl cross-coupling reactions. There are a number of
attractive design features in the aminophenolate architecture. The oxygen atom in such a motif is
sterically less encumbered than the amido group in 2, which could afford better accessibility towards
secondary alkyl halide substrates. Moreover, the arene electronics of an aminophenolate ligand could
potentially be tuned by different substituents. Finally, the aryl amine group could easily be rendered
chiral, for instance as a 2,5-dimethylpyrrolidine ligand, for potential asymmetric reactions [13]. With

Molecules 2014, 19
13605
these considerations in mind, we explored the synthesis of new aminophenolate complexes of nickel in
order to test their competency in organic cross-coupling reactions.
Figure 1. The potential utility of aminophenolate ligands for cross-coupling reactions.
2. Results and Discussion
Our first efforts to attach an aminophenolate ligand to nickel involved reacting 2-(pyrrolidin-1-yl)
phenol with [(2,4-lutidine)2NiCl2] as described in Scheme 2. The reaction led to complex 4 plus large
amounts of the bis-ligated species 5. Complex 5 was undesired as it has already been shown by Hu that
bis-amido complexes like 3 were inactive in organic cross-coupling reactions (Scheme 1).
Scheme 2. Exploring the coordination chemistry of aminophenol ligands.
Poor solubility of [(2,4-lutidine)2NiCl2] most likely plays a role in the formation of 5 and the
attachment of two aminophenolate ligands to the nickel center. While dimer 4 was only formed in
minor amounts, red orange crystals of 4 could be separated from the yellow/beige 5 under a
microscope in order to investigate its structure by X-ray crystallography. The solid-state structure of 4
is provided in Figure 2. The X-ray data revealed that the environment around the oxygen atom of the
ligand is not bulky enough to prevent dimerization, even with coordinated lutidines remaining on both of
the nickel centers. Because we could not efficiently purify complexes 4 and 5 from the reaction mixture
in bulk, the method for attaching an aminophenolate ligand to nickel as described in Scheme 2 was
ultimately abandoned.
With the knowledge that another coordinating ligand may be necessary to prevent dimerization of
the nickel precatalysts, we explored the use of chelating amines to replace lutidine as the ancillary ligand
on the nickel complexes. We found that the most reliable method to generate a monomeric complex
bearing aminophenolates was by adding the aminophenol ligand to [(TMEDA)NiBr(Ar)] (Scheme 3).
In this way, the nickel product that is obtained is a five-coordinate monomer with good solubility in

Molecules 2014, 19
13606
organic solvents. Complex 6 exhibits a magnetic moment with µeff (Evan’s method) = 3.02 µB,
consistent with a paramagnetic S = 1 ground state. The electrochemistry of 6 in DMF is complicated,
having multiple irreversible oxidations beginning at −0.05 V (versus Ag/AgNO3) and irreversible
reductions beginning at −2.07 V. The latter value represents a redox potential more negative than that
seen for 1 [14]. Complex 6 crystallizes from THF/pentane, and the ORTEP diagram of 6 is provided
in Figure 3.
Figure 2. ORTEP diagram of 4. All hydrogens are removed for clarity. Selected bond
lengths (Å): Ni(1)-Ni(1A) 3.2057(6), Ni(1)-Cl(1) 2.3084(11), Ni(1)-O(1) 1.9652(20),
Ni(1)-O(1A) 2.065(2), Ni(1)- N(1) 2.211(3), Ni(1)-N(2) 2.053(3). Selected bond angles (°):
Ni(1A)-Ni(1)-Cl(1) 121.564(20), Ni(1A)-Ni(1)-O(1) 38.41(6), Ni(1A)-Ni(1)-O(1A)
36.24(5), Ni(1A)-Ni(1)-N(1) 119.26(7), Ni(1A)-Ni(1)-N(2) 110.21(8), Cl(1)-Ni(1)-O(1)
136.39(7), Cl(1)-Ni(1)-O(1A) 97.09(6), Cl(1)-Ni(1)-N(1) 99.93(8), Cl(1)-Ni(1)-N(2)
102.09(7), O(1)-Ni(1)-O(1A) 74.648(19), O(1)-Ni(1)-N(1) 80.86(9), O(1)-Ni(1)-N(2)
120.77(10), O(1A)-Ni(1)-N(1) 155.49(9), O(1A)-Ni(1)-N(2) 92.84(9), N(1)-Ni(1)-N(2)
100.64(10), Ni(1)-O(1)-Ni(1A) 105.35(8).
Scheme 3. Preparation of monomeric aminophenolate complexes of nickel.

Molecules 2014, 19
13607
Figure 3. ORTEP diagram of 6. All hydrogens are removed for clarity. Selected bond
lengths (Å): Ni(1)-O(1) 1.9692(6); Ni(1)-N(1) 2.1465(7); Ni(1)-N(2) 2.1088(8); Ni(1)-N(3)
2.1485(7); Ni(1)-Br(1) 2.48086(15). Selected bond angles (°): O(1)-Ni(1)-N(2) 101.01(3);
O(1)-Ni(1)-N(1) 87.10(3); O(1)-Ni(1)-Br(1) 157.01(2); N(1)-Ni(1)-N(3) 165.56(3);
O(1)-Ni(1)-N(3) 80.83(3).
Complex 7, where the arene ring of the aminophenolate ligand is derivatized with a tert-butyl
group, was also prepared. The protocol for the tert-butyl-substituted ligand synthesis is outlined in
Scheme 4. Although the tert-butyl-substituted aminophenol precursor B has been mentioned in the
literature [15–17], there are no reports of its spectral characterization. NMR data for B is provided in
this manuscript. Consistent with its classification as an anti-oxidant [15], B is air sensitive, and
solutions of B quickly turn to dark red upon exposure to air. We found that pure, colorless crystals of B
can be obtained through sublimation under high vacuum. The target ligand C was prepared in excellent
yields by reacting B with 1,4-dibromobutane under refluxing conditions in ethanol (Scheme 4). Ligand
C can be complexed to nickel to afford 7 as described in Scheme 3, and an X-ray crystal structure
(Figure 4) confirmed the nature of the bonding in the monomeric species.
Scheme 4. Synthesis of tert-butyl-substituted aminophenol ligand C.
With complexes 6 and 7 in hand, the aminophenolate complexes of nickel were screened for
activity in Kumada-like coupling reactions (Table 1) using n-octylmagnesium chloride as the Grignard
reagent in order to draw comparisons with the Hu system. Hu’s first generation catalyst 1 was reported
to couple the primary alkyl iodide [Ph-C2H4-I] with n-octylMgCl to afford [Ph-C2H4-oct] in 85% yield,
while his second generation catalysts afforded a maximum yield of 41% [11].

Molecules 2014, 19
13608
Figure 4. ORTEP diagram of 7. All hydrogens are removed for clarity. The one
non-disordered molecule of the asymmetric unit is shown. Selected bond lengths (Å):
Ni(1)-O(1) 1.9584(17); Ni(1)-N(1) 2.138(2); Br(1)-Ni(1) 2.4392(4); Ni(1)-N(2) 2.091(2);
Ni(1)-N(3) 2.198(2). Selected bond angles (°): O(1)-Ni(1)-N(2) 103.73(8); O(1)-Ni(1)-N(1)
79.73(7); O(1)-Ni(1)-Br(1) 156.03(5); N(1)-Ni(1)-N(3) 166.55(8); O(1)-Ni(1)-N(1) 79.73(7).
Table 1. Efficiency of alkyl-alkyl coupling reactions with aminophenolate complexes of nickel a.
Yield (%)
using 6
Yield (%)
using 7
Entry
Substrates
Product
Solvent
1
THF
75 b (78 c)
72 c
57 c
25 c
2
3
Dioxane
THF
68 b
34 b
4
5
6
THF
THF
THF
78 c
40 c
15 c
89 c
88 c
10 c
a Reaction conditions: organic halides (0.2 mmol), octylMgCl (0.24 mmol) and the nickel(II) catalyst (3 mol %),
THF (3 mL); b isolated yield; c GC yield.

Molecules 2014, 19
13609
Our catalysts 6 and 7 were able to couple similar primary alkyl iodides in 78% and 72%,
respectively (Table 1, entry 1). THF proved to be a slightly better solvent for the reaction that dioxane
(Table 1, entry 2). Primary alkyl bromides were not good substrates for our new catalysts (Table 1,
entry 3). Gratifyingly, catalysts 6 and 7 gave excellent yields for the coupling of ethyl 2-bromobutyrate
to cross-coupled product in 78% and 89%, respectively (Table 1, entry 4), suggesting that aminophenols
are promising ligand scaffolds for the cross-coupling of alpha-bromoketones. Complex 7 was also able
to efficiently cross-couple benzyl bromide (Table 1, entry 5) although moderate yields were obtained
with catalyst 6. Although Hu’s second generation catalyst 2 was able to cross-couple iodocyclohexane in
77% yield [11], our catalysts performed poorly with this substrate, only affording product in less than
15% yield (Table 1, entry 6).
3. Experimental Section
3.1. General Information
All manipulations were performed using standard Schlenk and high vacuum techniques or in a
nitrogen filled glovebox. Solvents were purified by passing through activated alumina and/or copper in
1
a solvent purification system supplied by Pure Process Technology. Solution H-NMR spectra were
recorded at ambient temperature on a Bruker DRX 500 MHz spectrometer and referenced to residual
13
proton solvent signals. C-NMR spectra were recorded on a Bruker NMR spectrometer operating at
125 MHz and referenced to solvent signals. 19F spectra were recorded on the Bruker NMR
spectrometer operating at 470 MHz and referenced to trifluorotoluene set at δ −63.7. A Bruker D8
Quest diffractometer was used for X-ray crystal structure determinations. Elemental Analyses were
performed at Midwest Microlab, LLC. Cyclic voltammograms were recorded with a BASi Epsilon
potentiostat (USA) at room temperature in DMF solution with [Bu4N][BF4] (0.1 M) as the supporting
electrolyte. The substrate concentration was 10−2 M. A glassy-carbon (3.0 mm dia.) electrode was used
as the working electrode. The auxiliary electrode was a platinum rod. The scan rate was 100 mV s−1.
Crystallographic data (excluding structure factors) for compounds 4, 6, and 7 have been deposited with
the Cambridge Crystallographic Data Centre as supplementary publication numbers CCDC 1003595,
1003594, and 1003589, respectively. Copies of the data can be obtained free of charge on
application to CCDC, 12 Union Road, Cambridge CB2 1EZ, UK [fax: +44 1223 336 033;
E-Mail: deposit@ccdc.cam.ac.uk].
3.2. Preparation of [(TMEDA)Ni(Br)(C6H4F)]
TMEDA (166 mg, 1.43 mmol) and 1-bromo-4-fluorobenzene (250.25 mg, 1.43 mmol) were
dissolved in toluene (8 mL). Ni(COD)2 (400 mg, 1.43 mmol) was then added and the resulting mixture
was stirred at room temperature for 3 h. A red orange solid precipitated and was washed with pentane.
The product was then dried under high vacuum line to yield an orange power (yield 75%). Anal.
1
Calcd. (found) for C12H20BrFN2Ni: C, 41.19 (40.90); H, 5.76 (5.82). H-NMR (500 MHz, THF, δ):
7.59 (d, J = 8.0 Hz, 2H), 7.47–7.39 (m, 2H), 6.60–6.39 (m, 2H), 2.77–1.94 (br, 16H). 19F-NMR
(500 MHz, THF, δ): −127.37.

Molecules 2014, 19
13610
3.3. Preparation of [(TMEDA)Ni(Br)(2-(1-pyrrolidinyl)phenol)] (6)
2-(1-Pyrrolidinyl)phenol (0.142 g, 0.87 mmol) and [(TMEDA)NiBr(C6H4Ph)] [18] (0.308 g,
0.75 mmol) were dissolved in THF (20 mL) and stirred at room temperature for 16 h. The mixture was
then filtered to give a clear red orange filtrate. The solvent was then removed on a high vacuum line
giving a green solid. The solid was washed using copious amounts of pentane and dried under vacuum.
Yield: (0.235 g, 75%). Anal. Calcd (found) for C16H28BrN3NiO: C, 46.08 (46.21); H, 6.77 (6.66).
Product is paramagnetic. µeff (Evan’s method) = 3.02 µB.
3.4. Preparation of 2-Amino-6-(tert-butyl)phenol
2-(tert-Butyl)-6-nitrophenol [19] (2 g, 10.2 mmol) was dissolved in anhydrous methanol (40 mL) in
a Parr hydrogenator glass vessel. To this, 10% Pd/C (0.10 g, 0.1 equiv.) was slowly added. The
hydrogen gas pressure was adjusted to 40 psi on the Parr hydrogenator. This reaction mixture was
allowed to shake for 16 h, and then the volatiles were removed under vacuum. The dried mixture was
then taken into glovebox, dissolved in THF, and filtered through Celite. The volatiles were removed
under vacuum to yield white powder, which could be sublimed under reduced pressure. Yield: 1.04 g,
62%. 1H-NMR (500 MHz, chloroform-d) δ 6.91 (d, J = 7.8 Hz, 1H), 6.81 (d, J = 7.6 Hz, 1H), 6.74 (t,
13
J = 7.8 Hz, 1H), 4.22 (s, 2H), 1.42 (s, 10H). C-NMR (500 MHz, toluene-d8) δ C, 34.82, CH, 146.7,
138.1, 134.1, 120.4, 118.4; CH3, 29.5.
3.5. Preparation of 2-(Tert-butyl)-6-(pyrrolidin-1-yl)phenol
2-Amino-6-(tert-butyl)phenol (0.165 g, 1.0 mmol) was dissolved in toluene (10 mL), followed by
addition of 1,4-dibromobutane (0.215 g, 1.0 mmol) and N,N-diisopropylethylamine (1.2 g, 3 equiv.).
The solution was then refluxed for 36 h under the protection of nitrogen gas. Then the reaction mixture
was cooled to room temperature, washed with water and brine solution, and dried over sodium sulfate.
The volatiles were removed under vacuum to yield the desired compound. Yield: 219 mg, 90%.
1H-NMR (500 MHz, chloroform-d) δ 7.09 (dt, J = 7.9, 1.4 Hz, 3H), 6.81 (td, J = 7.9, 1.3 Hz, 1H), 3.01
(s, 4H), 1.99 (s, 4H), 1.44 (s, 10H). 13C-NMR (500 MHz, chloroform-d) δ C, 34.74, CH, 151.58,
137.26, 134.91, 123.40, 119.04, 118.73; CH2, 50.02, 24.58; CH3, 29.53.
3.6. Preparation of Complex 7
2-(tert-Butyl)-6-(pyrrolidin-1-yl)phenol (109 mg, 0.5 mmol) was dissolved in THF (4 mL).
(TMEDA)NiBr(4-fluorobenzene) (175 mg, 0.5 mmol) was dispersed in THF (6 mL). The solution of
2-(tert-butyl)-6-(pyrrolidin-1-yl)phenol was then added slowly into the solution of (TMEDA)NiBr(4-
fluorobenzene), and the resulting mixture was allowed to stir for 5 h. All volatiles were then removed
on a high vacuum line. The residue was dissolved in a minimal amount of THF and solids were
precipitated with pentane. The solids were filtered with a fine frit and discarded. The yellow filtrate
was pumped dry to yield greenish yellow solid. Yield 40% of paramagnetic material. µeff (Evan’s
method) = 2.71 µB. Anal. Calcd (found) for C20H36BrN3NiO: C, 50.77 (48.91); H, 7.67 (7.99).

Molecules 2014, 19
13611
3.7. Typical Procedure for the Kumada Cross-Coupling Reactions in Table 1
A vial was charged with alkyl halide substrate (0.2 mmol) and nickel catalyst (3 mol %), and the
internal standard undecane (0.2 mmol) in THF (3 mL). OctylMgCl (0.24 mmol, 2 M in THF) was then
added dropwise at room temperature. The resulting solution was stirred at room temperature for 2 h.
The reaction mixture was then filtered through a plug of silica gel and analyzed by gas
chromatography. The response factor of ethyl undecanoate calibrated to the internal standard was used
to calculate product yields.
4. Conclusions
New well-defined, paramagnetic nickel complexes have been prepared and characterized by X-ray
crystallography. The complexes were found to be active for the cross-coupling of alkyl electrophiles
(especially ethyl 2-bromobutyrate) with alkyl Grignard reagents. No β-hydride elimination products
were observed in the cross-coupling reactions. The only other identifiable side-product in all reactions
was reduced alkane, suggestive of single electron radical pathways being operative under the reaction
conditions. The ligand architecture in these new complexes could potentially be rendered chiral,
opening up future possibilities for performing asymmetric cross-coupling reactions.
Acknowledgments
D.A.V. thanks the U.S. NSF (CHE-1124619) and Office of Basic Energy Sciences of the U. S.
Department of Energy (DE-FG02-07ER15885) for support of this work. Y.H.B. thanks Russian
Scientific Foundation grant 14-23-00016.
Author Contributions
Siqi Yu, Huan Wang, Jill E. Sledziewski, Venkata N. Madhira, Cyrus G. Takahashi, and
Michelle K. Leon synthesized and characterized ligands and nickel complexes. Yulia B. Dudkina and
Yulia H. Budnikova performed electrochemical studies on complex 3. David A. Vicic guided the
research, solved the crystal structures, and wrote the paper. All authors have given approval to the final
version of the manuscript.
Conflicts of Interest
The authors declare no conflict of interest.
References
1. Breitenfeld, J.; Ruiz, J.; Wodrich, M.D.; Hu, X. Bimetallic Oxidative Addition Involving Radical
Intermediates in Nickel-Catalyzed Alkyl-Alkyl Kumada Coupling Reactions. J. Am. Chem. Soc.
2013, 135, 12004–12012.
2. Hu, X. Nickel-catalyzed cross coupling of non-activated alkyl halides: A mechanistic perspective.
Chem. Sci. 2011, 2, 1867–1886.

Molecules 2014, 19
13612
3. Biswas, S.; Weix, D.J. Mechanism and Selectivity in Nickel-Catalyzed Cross-Electrophile
Coupling of Aryl Halides with Alkyl Halides. J. Am. Chem. Soc. 2013, 135, 16192–16197.
4. Everson, D.A.; Weix, D.J. Cross-Electrophile Coupling: Principles of Reactivity and Selectivity.
J. Org. Chem. 2014, 79, 4793–4798.
5. Choi, J.; Fu, G.C. Catalytic Asymmetric Synthesis of Secondary Nitriles via Stereoconvergent
Negishi Arylations and Alkenylations of Racemic α-Bromonitriles. J. Am. Chem. Soc. 2012, 134,
9102–9105.
6. Do, H.-Q.; Chandrashekar, E.R.R.; Fu, G.C. Nickel/Bis(oxazoline)-Catalyzed Asymmetric
Negishi Arylations of Racemic Secondary Benzylic Electrophiles to Generate Enantioenriched
1,1-Diarylalkanes. J. Am. Chem. Soc. 2013, 135, 16288–16291.
7. Jones, G.D.; Martin, J.L.; McFarland, C.; Allen, O.R.; Hall, R.E.; Haley, A.D.; Brandon, R.J.;
Konovalova, T.; Desrochers, P.J.; Pulay, P.; et al. Ligand Redox Effects in the Synthesis,
Electronic Structure, and Reactivity of an Alkyl-Alkyl Cross-Coupling Catalyst. J. Am. Chem. Soc.
2006, 128, 13175–13183.
8. Binder, J.T.; Cordier, C.J.; Fu, G.C. Catalytic Enantioselective Cross-Couplings of Secondary
Alkyl Electrophiles with Secondary Alkylmetal Nucleophiles: Negishi Reactions of Racemic
Benzylic Bromides with Achiral Alkylzinc Reagents. J. Am. Chem. Soc. 2012, 134, 17003–17006.
9. Wilsily, A.; Tramutola, F.; Owston, N.A.; Fu, G.C. New Directing Groups for Metal-Catalyzed
Asymmetric Carbon-Carbon Bond-Forming Processes: Stereoconvergent Alkyl-Alkyl Suzuki
Cross-Couplings of Unactivated Electrophiles. J. Am. Chem. Soc. 2012, 134, 5794–5797.
10. Oelke, A.J.; Sun, J.; Fu, G.C. Nickel-catalyzed enantioselective cross-couplings of racemic
secondary electrophiles that bear an oxygen leaving group. J. Am. Chem. Soc. 2012, 134,
2966–2969.
11. Ren, P.; Vechorkin, O.; von Allmen, K.; Scopelliti, R.; Hu, X. A Structure-Activity Study of
Ni-Catalyzed Alkyl-Alkyl Kumada Coupling. Improved Catalysts for Coupling of Secondary
Alkyl Halides. J. Am. Chem. Soc. 2011, 133, 7084–7095.
12. Vechorkin, O.; Hu, X. Nickel-catalyzed cross-coupling of non-activated and functionalized alkyl
halides with alkyl Grignard reagents. Angew. Chem. Int. Ed. 2009, 48, 2937–2940.
13. Short, R.P.; Kennedy, R.M.; Masamune, S. An improved synthesis of (−)-(2R,5R)-2,5-
dimethylpyrrolidine. J. Org. Chem. 1989, 54, 1755–1756.
14. Vechorkin, O.; Csok, Z.; Scopelliti, R.; Hu, X. Nickel Complexes of a Pincer Amidobis(amine)
Ligand: Synthesis, Structure, and Activity in Stoichiometric and Catalytic C-C Bond-Forming
Reactions of Alkyl Halides. Chem. Eur. J. 2009, 15, 3889–3899.
15. Endo, Y.; Murayama, M.; Ogawa, F.; Nishiyama, T. Antioxidant activity of intramolecularly
hydrogen bonded 2-aminophenols. Technol. Rep. Kansai Univ. 2005, 47, 31–37.
16. Musso, H.; Bantel, K.H. Hydrogen bonds. X. Inhibition and promotion of hydrogen bonds by
tert-butyl groups in o-nitrophenols and o-aminophenols. Chem. Ber. 1969, 102, 686–695.
17. Musso, H.; Kempmann, K. Perturbed methyl valency vibrations in tert-butylbenzene derivatives.
Chem. Ber. 1969, 102, 706–708.

Molecules 2014, 19
13613
18. Lee, E.; Hooker, J.M.; Ritter, T. Nickel-Mediated Oxidative Fluorination for PET with Aqueous [18F]
Fluoride. J. Am. Chem. Soc. 2012, 134, 17456–17458.
19. Dearden, J.C.; Forbes, W.F. The study of hydrogen bonding and related phenomena by ultraviolet
light absorption. VI. The effect of steric interactions on the intramolecular hydrogen bond in
o-nitrophenol. Can. J. Chem. 1960, 38, 1852–1864.
Sample Availability: Samples of the compounds are not available from the authors.
© 2014 by the authors; licensee MDPI, Basel, Switzerland. This article is an open access article
distributed under the terms and conditions of the Creative Commons Attribution license
(http://creativecommons.org/licenses/by/3.0/).
