Cyclic Hydroborate Complexes of Metallocenes. IV. Weak Unsupported Single Hydrogen
Bridges in Cp2Zr{(µ-H)B(X)CH2Ph}{(µ-H)2BX} (X ) C5H10, C4H8)
Fu-Chen Liu, Jianping Liu, Edward A. Meyers, and Sheldon G. Shore*
Department of Chemistry, The Ohio State University, Columbus, Ohio 43210
ReceiVed NoVember 24, 1998
The compounds Cp2Zr{(µ-H)(BC5H10)CH2Ph}{(µ-H)2BC5H10}, 1, and Cp2Zr{(µ-H)(BC4H8)CH2Ph}{(µ-
H)2BC4H8}, 2, were prepared in yields of 59% and 51%, respectively, from the reactions of Cp2ZrCl{(µ-H)2BX}
(X ) C5H10, C4H8) with PhCH2MgCl. Single-crystal X-ray diffraction analyses indicate the presence of an
1
unsupported Zr-H-B bond in these complexes. In solution at low temperature H NMR spectra are consistent
with the presence of the unsupported Zr-H-B bridge in complexes 1 and 2. However, NMR spectra at room
temperature indicate that the hydrogen bridge is dissociated into Cp2ZrH{(µ-H)2BC5H10} and B(C5H10)CH2Ph in
the case of complex 1, and Cp2ZrH{(µ-H)2BC4H8} and B(C4H8)CH2Ph in the case of complex 2. It is possible
to pump away the B(C4H8)CH2Ph from solid 2 at room temperature, leaving behind Cp2ZrH{(µ-H)2BC4H8}.
These results suggest that the Zr-H bond acts as an electron pair donor to trivalent boron in the formation of 1
and 2. Crystal data for Cp2Zr{(µ-H)(BC5H10)CH2Ph}{(µ-H)2BC5H10}: monoclinic, P21/m (No. 11), a ) 9.392-
(5) Å, b ) 13.250(4) Å, c ) 9.841(6) Å, â ) 95.70(4)°, Z ) 2. Crystal data for Cp2Zr{(µ-H)(BC4H8)CH2Ph}-
{(µ-H)2BC4H8}: orthorhombic, Pbca (No. 61), a ) 18.1630(10) Å, b ) 19.0497(10) Å, c ) 13.0393(10) Å, Z
) 8.
Introduction
Chart 1
The M-H-B three-center, two-electron bond is present in
covalent hydroborate metal complexes in which the hydroborate
serves as a monodentate, bidentate, or tridentate ligand (Chart
1). Tridentate and bidentate linkages between metal and boron
atoms are more common than monodentate linkages.1 IR
spectroscopy has been applied as the principal technique for
the identification of monodentate interaction of a hydroborate
anion with a metal for most of the complexes that have been
reported to contain an unsupported M-H-B bond.1a,2 However,
there are some monodentate complexes that have been structur-
ally characterized by single-crystal X-ray or neutron diffraction
analyses. These are [Cu{(µ-H)BH3}(PMePh2)3],3 [Cu{(µ-H)-
BH3}{(PPh2CH2)3CMe}],4 [FeH{(µ-H)BH3}(dmpe)2] (dmpe )
bis(dimethylphosphino)ethane),5 [Hf2{N(SiMe2CH2PMe2)2}2H3-
(BH4)3],6 [V{(µ-H)BH3}2{dmpe}2],7 {Cr(Py)4{(µ-H)BH3}2} (Py
) pyridine),8 {Cr3(TMEDA)2(Py)4((µ-H)2BH2)4}{(µ-H)BH3}2}
(TMEDA ) N,N,N′,N′-tetramethylethylenediamine),8 and {RuH-
{(µ-H)BH3}(Me8[16]aneS4).9 Monodentate, unsupported M-H-B
bridges have also been observed in the following compounds:
{M(CO)5((µ-H)B2H3‚2PMe3)} (M ) Cr, W),10 and {Cp2Ta-
(PMe3){(µ-H)BH2(Si(t-Bu)2H)}.11
Described here is recent work that led to the preparation and
isolation of the following complexes with unsupported single
hydrogen bridges: Cp2Zr{(µ-H)B(X)CH2Ph}{(µ-H)2BX} (X )
C5H10 (1), C4H8 (2)). To our knowledge these are the first
demonstrated examples of the formation of a single M-H-B
bond in which the M-H bond acts as an electron pair donor to
a trivalent boron to form the hydrogen-bridged bond.12 In
previous examples3-11 the B-H bond serves as the electron
pair donor to the unsaturated metal center.
(1) (a) Marks, T. J.; Kolb, J. R. Chem. ReV. 1977, 77, 263. (b) Gilbert, K.
B.; Boocock, S. K.; Shore, S. G. Compounds with Bonds between a
Transition Metal and Boron. In ComprehensiVe Organometallic
Chemistry; Wilkinson, G., Stone, F. G. A., Abel, E. W., Eds.;
Pergamon Press Inc.: New York, 1982; pp 879-945.
(2) Marks, T. J.; Kennelly, W. J.; Kolb, J. R.; Shimp, L. A. Inorg. Chem.
1972, 11, 2540.
(3) (a) Takusagawa, F.; Fumagalli, A.; Koetzle, T. F.; Shore, S. G.;
Schmitkons, T.; Fratini, A. V.; Morse, K. W.; Wei, C.-Y.; Bau, R. J.
Am. Chem. Soc. 1981, 103, 5165. (b) Bommer, J. C.; Morse, K. W.
Inorg. Chem. 1980, 19, 587. (c) Kutal, C.; Grutsch, P.; Atwood, J. L.;
Rogers, R. D. Inorg. Chem. 1978, 17, 3558.
(4) (a) Ghilardi, C. A.; Midollini, S.; Orlandini, A. Inorg. Chem. 1982,
21, 4096. (b) Dapporto, P.; Midollini, S.; Orlandini, A.; Sacconi, L.
Inorg. Chem. 1976, 15, 2768.
(5) (a) Bau, R.; Yuan, H. S. H.; Baker, M. V.; Field, L. D. Inorg. Chim.
Acta 1986, 114, L27. (b) Baker, M. V.; Field, L. D. J. Chem. Soc.,
Chem. Commun. 1984, 996.
Results and Discussion
Formation of Cp2Zr{(µ-H)B(X)CH2Ph}{(µ-H)2BX} (X )
2
C5H10,1 C4H8 ). In an attempt to prepare the benzyl-substituted
cyclic hydroborate complex Cp2Zr(CH2Ph){(µ-H)2BC5H10}
from the reaction of Cp2ZrCl{(µ-H)2BC5H10}13 with PhCH2-
(8) Dionne, M.; Hao, S.; Gambarotta, S. Can. J. Chem. 1995, 73, 1126.
(9) Yoshida, T.; Adachi, T.; Ueda, T.; Akao, H.; Tanaka, T.; Goto, F.
Inorg. Chim. Acta 1995, 231, 95.
(10) Katoh, K.; Shimoi, M.; Ogino, H. Inorg. Chem. 1992, 31, 670.
(11) Jiang, Q.; Carroll, P. J.; Berry, D. H. Organometallics 1993, 12, 177.
(12) Ir-H‚‚‚B interaction in fac-[IrH(PMe3)3(η2-CH2BHC8H14)] has been
suggested. Baker, R. T.; Ovenall, D. W.; Calabrese, J. C.; Westcott,
S. A.; Taylor, N. J.; Williams, I. D.; Marder, T. B. J. Am. Chem. Soc.
1990, 112, 9399.
(6) Fryzuk, M. D.; Rettig, S. J.; Westerhaus, A.; Williams, H. D. Inorg.
Chem. 1985, 24, 4316.
(7) Jensen, J. A.; Girolami, G. S. Inorg. Chem. 1989, 28, 2107.
(13) Liu, J.; Meyers, E. A.; Shore, S. G. Inorg. Chem. 1998, 37, 496.
10.1021/ic981347u CCC: $18.00 © 1999 American Chemical Society
Published on Web 04/14/1999

2170 Inorganic Chemistry, Vol. 38, No. 9, 1999
Liu et al.
Figure 2. Molecular structure of Cp2Zr{(µ-H)BC4H8(CH2Ph)}{(µ-
H)2BC4H8} showing 25% probability ellipsoids.
Figure 1. Molecular structure of Cp2Zr{(µ-H)BC5H10(CH2Ph)}{(µ-
H)2BC5H10} showing 50% probability ellipsoids.
Table 1. Crystallographic Data for
Cp2Zr{(µ-H)BC5H10(CH2Ph)}{(µ-H)2BC5H10}, 1, and
MgCl, a complicated sequence of reactions occurred that resulted
in the isolation of Cp2Zr{(µ-H)B(C5H10)CH2Ph}{(µ-H)2BC5H10},
1, a compound that contains an unsupported single hydrogen
bridge in the solid state. The reaction produces a mixture of
several organoborate species. Boron-11 NMR spectra at room
temperature indicate that the initial major products are Cp2ZrH-
{(µ-H)2BC5H10}14 and an organoborate anion (δ ) -15.2 ppm)
that is believed to be [B(C5H10)(CH2Ph)2]MgCl,15 an intermedi-
ate that decreases in concentration with time. Minor initial
components Cp2Zr(CH2Ph){(µ-H)2BC5H10}16 and B(C5H10)CH2-
Ph increase in concentration as the concentration of the
intermediate species decreases. Similar competing reactions
resulting in complicated products are also observed in the direct
alkylation of the cyclic hydroborate complexes Cp2ZrCl{(µ-
H)2X} (X ) BC4H8, BC5H10).13,17 Crystallization from the
reaction mixture yielded two types of crystals that were manually
separated: Cp2Zr{(µ-H)B(C5H10)CH2Ph}{(µ-H)2BC5H10}, 1
(59% yield), colorless crystals identified from a single-crystal
X-ray diffraction analysis, and the previously reported com-
pound Cp2Zr(CH2Ph)218 (10% yield), orange crystals that were
Cp2Zr{(µ-H)BC4H8(CH2Ph)}{(µ-H)2BC4H8}, 2
empirical formula
fm, amu
C27H40B2Zr
477.44
C25H36B2Zr
449.38
space group
a, Å
b, Å
P21/m
Pbca
9.392(5)
13.250(4)
9.841(6)
95.70(4)
1218.7(11)
2c
18.1630(10)
19.0497(10)
13.0393(10)
c, Å
â, deg
vol, Å3
4511.6(5)
8
1.323
Z
F(calcd), g cm-3
cryst size, mm
T, °C
1.301
0.35 × 0.45 × 0.34
0.25 × 0.20 × 0.28
-60
-60
radiation (λ, Å)
Mo KR (0.710 73)
0.463
Mo KR (0.710 73)
0.495
µ, mm-1
scan mode
2θ limits, deg
(h
ω-2θ
4-45
-10, 10
0, 14
-10, 10
3430
1675
1336
ω-2θ
4-50
-21, 21
0, 22
0, 15
7926
3965
2558
(k
(l
no. of rflns measd
no. of unique rflns
no. of unique rflns
[I > 2.0σ(I)]
no. of variables
R1a [I > 2.0σ(I)]
wR2b (all data)
Rint
1
identified by H NMR spectroscopy and confirmed by single-
151
265
crystal X-ray diffraction analysis.19
0.0378
0.0894
0.0466
1.041
0.0341
0.0894
0.0298
1.015
The reaction of Cp2ZrCl{(µ-H)2BC4H8} with PhCH2MgCl
forms the complex Cp2Zr{(µ-H)B(C4H8)CH2Ph}{(µ-H)2BC4H8},
2 (51% yield, colorless crystals), in a sequence of steps, followed
by NMR spectroscopy, with intermediate species similar to those
in the formation of 1.
Molecular Structures of 1 and 2. The molecular structures
of 1 and 2 are shown in Figures 1 and 2. Crystallographic data
and selected positional parameters, bond distances, and bond
GOF
a R1 ) ∑||Fo| - |Fc||/∑|Fo|. b wR2 ) {∑w(Fo2 - Fc2)2/∑w(Fo )2}1/2
.
2
c The asymmetric unit for 1 is one half of a molecule. Therefore, there
are 4 asymmetric units in the unit cell.
angles are given in Tables 1-5. The X-ray analyses show that
the structures of complexes 1 and 2 are closely related. In the
solid state, each complex contains an unsupported single
hydrogen Zr-H-B bridge that connects the Cp2Zr{(µ-
H)2BC5H10} and BC5H10(CH2Ph) units in 1 and the Cp2Zr{(µ-
H)2BC4H8} and BC4H8(CH2Ph) units in 2. The Zr-H bond of
the parent zirconocene hydride organohydroborate acts as an
electron pair donor to the boron of the alkyl borane.
(14) Liu, F.-C.; Liu, J.; Meyers, E. A.; Shore, S. G. Inorg. Chem. 1998,
37, 3293.
(15) This chemical shift is consistent with chemical shifts reported for
tetraalkyl borate anions. No¨th, H.; Wrackmeyer, B. Nuclear Magnetic
Resonance Spectroscopy of Boron Compounds; Diehl, P., Fluck, E.,
Kosfeld, R., Eds.; Springer-Verlag: Berlin, 1978; p 384.
(16) Liu, F.-C. Ph.D. Dissertation, The Ohio State University, 1998.
(17) (a) Jordan, G. T., IV; Liu, F.-C.; Shore, S. G. Inorg. Chem. 1997, 36,
5597. (b) Jordan, G. T., IV; Shore, S. G. Inorg. Chem. 1996, 35, 1087.
(18) Fachinetti, G.; Floriani, C. J. Chem. Soc., Chem. Commun. 1972, 11,
654.
(19) The molecular structure, crystallographic data, positional parameters,
bond distances, and bond angles of Cp2Zr(CH2Ph)2 are provided in
the Supporting Information.

Cyclic Hydroborate Complexes of Metallocenes
Inorganic Chemistry, Vol. 38, No. 9, 1999 2171
