Scheme 1. SPC C–C coupling of phenoxyacetic acid (9 mM) and N-methylmaleimide (18 mM) using P25 (1 mg mL−1) in a 75 mL reaction solution [7].
clear coating of anatase titania (ca. 1.4 mg cm−2, thickness ∼4 m,
1 mL of reaction solution is exposed to ∼11 cm−2) on the inside of an
otherwise conventional glass NMR tube (500 MHz Wilmad® NMR
tubes 5 mm o.d., length = 20.3 cm). XRD revealed that the annealed
TiO2 film is in its anatase crystal form [12].
most other SPC mediated organic reactions, such as that illustrated
in Scheme 1. In such scaled-down SPC work, usually conducted in an
NMR tube using either a dispersion or coating of the semiconductor,
the kinetics of the overall process are usually much (>10×) faster.
This approach is also very convenient with regard to monitoring
the progress of the SPC reaction since it allows the use of NMR
to monitor the reactions and avoids the need for reaction solution
sampling and filtration of the semiconductor, before analysis (by,
for example, NMR, HPLC or GC) which is typical of most large scale
SPC mediated organic synthesis reactions.
This paper builds on the initial study of Manley et al. [7] and
aims to assess the C–C coupling process of phenoxyacetic acid
with maleimide and N-methylmaleimide in more detail, with the
additional assessment of the homogeneous photochemical and het-
erogeneous photocatalytic processes associated with the individual
components, PAA and NMI or MI. The progress of the reactions is
monitored by NMR, using usually a sol–gel titania coated NMR tube.
2.2. NMR tube irradiations
In situ NMR tube irradiations were carried out using a titania
sol–gel coated NMR tube. A photoreactor, consisting of two lots of
6 × 8 W black light UV lamps (ꢀmax (emission) 365 nm), arranged in
a hemispherical cylinder with an aluminium reflector, were used to
irradiate the contents of the NMR tube. The two photoreactor hemi-
spheres were brought together to surround the NMR tube as shown
in Fig. 1. Unless otherwise stated, the irradiance of each hemisphere
of the photoreactor was 3.5 mW cm−2. For a typical reaction, a 5 mL
stock reaction solution was prepared comprising: the reactant(s)
i.e. 10 mM of the phenoxyacetic acid (PAA) and/or 20 mM of the
for 5 min, to remove any dissolved oxygen, prior to pipetting 1 mL
of it into an argon flushed sol–gel coated NMR tube. The cap was
then quickly replaced on the tube and sealed with Parafilm. The
loaded NMR tube was then placed in the overhead stirrer (turned
on its side), which was then spun at 250 rpm. The tube was held at
a slight angle to horizontal in the ‘chuck’ of the overhead stirrer so
that when it was rotated it described a small (ca. 2 cm) circle at its
non-chuck-held end so as to agitate the reaction solution. Once the
NMR tube, filled with reaction solution, was in place, the irradia-
tion was started and, periodically, the tube was removed from the
chuck and placed into the NMR for analysis, before being returned
for further irradiation.
2. Experimental
Unless otherwise stated, all chemicals used in this project were
purchased from Sigma–Aldrich and were used as supplied. The P25
titania was provided by Evonik Degussa Corporation. P25 has a
surface area of ca. 50 m2 g−1 and is 80% anatase and 20% rutile [11].
2.1. Preparation of TiO2 coated Pyrex® NMR tubes
A paste of titania nanoparticles was prepared using the sol–gel
method described by Mills et al. [12]. Briefly, the precursor, tita-
nium(IV) isopropoxide (20 mL), was modified by the addition of
glacial acetic acid (4.65 g) under argon. The titania was then syn-
thesised via the sol–gel process by the addition to the solution of
120 mL of deionised water containing 1.08 g of nitric acid, thus
initiating the hydrolysis reaction, which leads to a condensation
reaction, that produces the hydrous oxide. The colloidal titania
particles were then grown via Ostwald ripening using an auto-
clave (220 ◦C for 720 min). The resulting precipitated particles
were dispersed using an ultrasonic probe and the solution was
rotary evaporated until a weight percent of titania of 10–12% was
achieved. At this stage 50 wt% of polyethylene glycol was added as
a binder to help prevent the formation of cracks in the cast films.
In order to coat an NMR tube with titania, a few drops of the
titania paste were pipetted into the NMR tube and shaken with
the NMR tube’s cap in place until the paste completely covered the
inside of the tube. The cap was then removed and the NMR tube
placed in the chuck of an overhead mechanical stirrer turned on
its side, and rotated horizontal to the floor at 1000 rpm for 5 min
to ensure an even thickness of the paste film on the sides of the
NMR tube. The tube was then placed under vacuum using a rotary
evaporator to remove all the solvent; the use of vacuum ensured
no bubbles were present in the paste, which could lead to poor
adhesion on the sides of the tube and result in flaking when dry. The
tube was then placed in a furnace and heated to 450 ◦C for 90 min
with an initial ramp rate of 10 ◦C min−1. The tube was then left
overnight to cool slowly inside the furnace to create a final robust
2.3. Large scale irradiations
In order to effect comparison with the work of Manley et al.
[7], 40 mL scale irradiations were also performed for the PAA-NMI
carbon–carbon coupling reaction (Scheme 1) using a 50 mL test
tube with either a sol–gel titania coating or a dispersion of tita-
nia. The sol–gel coated test tubes were prepared by first, pipetting
a line of the titania paste down the length of the inside of the tube.
Using a glass rod, the paste was then spread around the inside of
the tube as evenly as possible. The paste was allowed to dry com-
pletely before placing in a furnace for 90 min at 450 ◦C to anneal
(1.2 mg cm−2). The 40 mL reaction solutions were prepared using
HPLC grade acetonitrile, to which 10 mM of PAA acid and 20 mM of
NMI were added. For the titania dispersion work, a 1 mg mL−1 load-
ing of the semiconductor (P25, PC500 (Millennium Chemicals), or
Rutile nanopowder (Sigma–Aldrich (637262-100G))) was used in
the reaction solution, with the dispersion placed in a sonic bath for
5–10 min before being transferred inside the tube. A Suba-Seal®
cap was used to seal the tube, through which the reaction disper-
sion was then purged with argon for 10 min prior to irradiation.
The tubes were irradiated using the same 12 × 8 W BLB cylindri-
cal photoreactor illustrated in Fig. 1(a) but this time being held
