3326 J ournal of Medicinal Chemistry, 2001, Vol. 44, No. 20
Gao et al.
7-O-ω-Ca r boxyp en ta d ecyld a id zein (15) was synthesized
and purified according to the procedures described for 14 using
6-bromo-1-hexadecanoic acid (5.15 g, 15.36 mmol) as the
alkylating agent. Analyses (15): white amorphous powder;
Analyses (38): white amorphous powder; yield 13%; mp141-
142 °C;
1H NMR and 13C NMR spectra with the characteristic
features of those of 18 and consistent with the interpretation
that 38 is a 7,4′-disubstituted analogue of 18; MS m/z 539.8
(M + H)+. Anal, Calcd (C33H46O6): C, 73.58; H, 8.61. Found:
C, 73.68; H, 8.66.
1
yield 36%; mp151-152 °C; H NMR (DMSO-d6) δ 1.22-1.24
[m, 20H, (-CH2-)10], 1.40 (m, 2H, -CH2-), 1.46 (m, 2H,
-CH2-), 1.70 (m, 2H, -CH2-), 2.16 (t, 2H, -CH2-), 3.97 (t,
-CH2O-), 6.82 (dd, 2H, J ) 8.7, 1.7 Hz, H-3′, H-5′), 7.03 (dd,
1H, J ) 8.86, 1.9 Hz, H-6), 7.10 (d, 1H, J ) 1.9 Hz, H-8), 7.48
(dd, 2H, J ) 8.7, 1.7 Hz, H-2′, H-6′), 8.0 (d, 1H, J ) 8.86 Hz,
H-5), 8.34 (s, 1H, H-2), 9.5 (s, 1H, OH-4′); 13C NMR δ 24.5
(-CH2-), 25.4 (-CH2-), 25.5 (-CH2-), 28.9-29.0 [(-CH2-)10],
33.8 (-CH2-), 67.4 (-OCH2-), 100.9 (C-8), 114.1 (C-6), 114.9
(C-3′, C-5′), 117.5 (C-10), 122.4 (C-1′), 124.1 (C-3), 126.9 (C-5),
130.0 (C-2′, C-6′), 152.9 (C-2), 157.2 (C-9), 157.4 (C-4′), 162.9
(C-7), 174.6 (C-4, -COOH); MS m/z 509.7 (M + H)+. Anal.
Calcd (C31H40O6): C, 73.2; H, 7.93. Found: C, 73.41; H, 7.83.
7-O-ω-Hyd r oxyd od ecyld a id zein (19) was synthesized
and purified according to the procedures described for 18 using
12-bromo-1-dodecanol (5 g, 18.85 mmol) as the alkylating
agent. Analyses (19): white amorphous powder; yield 20.5%;
mp 142-144 °C; 1H NMR (DMSO-d6) δ 1.23 [m, 14H, (-CH2-)7],
1.37 (m, 4H, -CH2CH2-), 1.73 (m, 2H, -CH2-), 3.36 (m, 2H,
-CH2O-), 4.08 (t, -CH2O-), 6.81 (dd, 2H, J ) 8.69, 1.58 Hz,
H-3′, H-5′), 7.04 (dd, 1H, J ) 8.86, 1.9 Hz, H-6), 7.09 (d, 1H,
J ) 1.9 Hz, H-8), 7.40 (dd, 2H, J ) 8.69, 1.58 Hz, H-2′, H-6′),
7.98 (d, 1H, J ) 8.86 Hz, H-5), 8.34 (s, 1H, H-2), 9.55 (s,1H,
OH-4′); 13C NMR δ 25.4 [(-CH2-)2], 25.5 (-CH2-), 28.4
(-CH2-), 28.7 (-CH2-), 28.9 (-CH2-), 29.1 (-CH2-), 32.5
(-CH2-), 60.7 (-CH2O-), 68.4 (-OCH2-), 100.9 (C-8), 114.8
(C-6), 114.8 (C-3′, C-5′), 117.5 (C-10), 122.4 (C-1′), 123.7 (C-3),
126.9 (C-5), 130.0 (C-2′, C-6′), 153.0 (C-2), 157.2 (C-9), 157.4
(C-4′), 163.0 (C-7), 174.7 (C-4); MS m/z 439.6 (M + H)+. Anal.
Calcd (C27H34O5): C, 73.95; H, 7.81. Found: C, 74.20; H, 7.61.
7-O-ω-Hyd r oxyeth yld a id zein (16). To a suspension of 5.3
g of 2 (20.87 mmol) and 60 mL of acetone was added with
vigorous stirring 13 mL of 2 N KOH (26 mmol). After 2 was
completely dissolved, 2 mL of 2-bromoethanol (28.21 mmol)
was added, and the reaction mixture was refluxed with gentle
stirring for 72 h. Solvent was evaporated, and the residue was
partitioned in water and ethyl acetate. The ethyl acetate layer
was further purified on a silica gel column in petroleum ether/
ethyl acetate/methanol (6/3/1) followed by a Sephadex LH-20
column in methanol. Fractions that contained the major
product were pooled, dried, and recrystallized from acetone
to give 1.7 g of 16. Analyses (16): white amorphous powder;
yield 28.5%; mp 210-212 °C; MS m/z 299.1 (M + H)+. Anal.
Calcd (C17H14O5): C, 68.45; H, 4.73. Found: C, 67.86; H, 4.23.
7-O-ω-Hyd r oxyh exyld a id zein (17) was synthesized ac-
cording to the method described for 16 using 6-bromo-1-
hexanol (3 mL, 22.93 mmol) as the alkylating agent. After
reflux, the reaction mixture was refrigerated for 12 h, and the
precipitates were collected and fractionated on a Sephadex LH-
20 column in methanol. Fractions that contained pure product
were pooled, dried, and recrystallized from acetone to give 1.16
g of 17. Analyses (17): white amorphous powder; yield 16.4%;
mp177-178.5 °C; 1H NMR (DMSO-d6) δ 1.35 (m, 2H, -CH2-),
1.43 (m, 4H, -CH2CH2-), 1.75 (m, 2H, -CH2-), 3.40 (m, 2H,
-CH2-), 4.1 (t, -CH2O-), 6.81 (dd, 2H, J ) 8.7, 1.6 Hz, H-3′,
H-5′), 7.04 (dd, 1H, J ) 8.86, 1.98 Hz, H-6), 7.10 (d, 1H, J )
1.99 Hz, H-8), 7.40 (dd, 2H, J ) 8.7, 1.58 Hz, H-2′, H-6′), 8.0-
(d, 1H, J ) 8.86 Hz, 5-H), 8.34 (s, 1H, H-2), 9.53 (s, 1H, OH-
4′); 13C NMR δ 25.2 (-CH2-), 25.3 (-CH2-), 28.5 (-CH2-), 32.5
(-CH2-), 60.6 (-CH2O-), 68.4 (-OCH2-), 100.9 (C-8), 114.9
(C-6), 114.9 (C-3′, C-5′), 117.5 (C-10), 122.4 (C-1′), 123.7 (C-3),
126.9 (C-5), 130.1 (C-2′, C-6′), 153.1 (C-2), 157.2 (C-9), 157.4
(C-4′), 163.0 (C-7), 174.7 (C-4); MS m/z 355.3 (M + H)+. Anal.
Calcd (C21H22O5): C, 71.17; H, 6.26. Found: C, 70.82, H, 6.44.
7-O-ω-H yd r oxyet h yl-2-(2-oxyet h yl)oxyet h yld a id zein
(20). To a solution of 5.1 g of 2 (20.08 mmol) in 60 mL of DMF
were added 4.15 g of K2CO3 (30.03 mmol) and 6.74 g of 2-(2-
(2-chloroethoxy)ethoxy)ethanol (40.0 mmol), and the mixture
was refluxed (80 °C) with gentle stirring for 12 h. After reflux,
the reaction mixture was poured into 100 mL of ice/water
followed by ethyl acetate extraction. Ethyl acetate was evapo-
rated, and the residue was fractionated on a Sephadex LH-20
column in chloroform/ methanol (7/3). Fractions that contained
20 were pooled, dried, and recrystallized from acetone to yield
3.08 g of pure product. Analyses (20): colorless crystalline
1
needles; yield 39.9%; mp 149-150 °C; H NMR (DMSO-d6) δ
3.43 (m, 2H, -CH2-), 3.48 (m, 2H, -CH2-), 3.55 (m, 2H,
-CH2-), 3.60 (m, 2H, -CH2-), 3.79 (m, 2H, -CH2-), 4.25 (m,
2H, -CH2-), 6.81 (d, 2H, J ) 8.66 Hz, H-3′, H-5′), 7.08 (d, 1H,
J ) 8.86 Hz, H-6), 7.15 (d, 1H, J ) 1.77 Hz, H-8), 7.40 (d, 2H,
J ) 8.66 Hz, H-2′, H-6′), 8.01 (d, 1H, J ) 8.18 Hz, H-5), 8.35
(s, 1H, H-2), 9.54 (s, 1H, OH-4′); 13C NMR 60.2 (-CH2O-),
68.1 (-CH2O-), 68.6 (-CH2O-), 69.8 (-CH2O-), 69.9 (-CH2-
O-), 72.4 (-CH2O-), 101.1 (C-8), 114.9 (C-6), 115.0 (C-3′, C-5′),
117.6 (C-10), 122.4 (C-1′), 123.7 (C-3), 126.9 (C-5), 130.1 (C-
2′, C-6′), 153.1 (C-2), 157.2 (C-9), 157.3 (C-4′), 162.8 (C-7), 174.7
(C-4); MS m/z 387 (M + H)+. Anal. Calcd (C21H22O7): C, 65.28;
H, 5.74. Found: C, 65.15; H, 5.59.
7-O-ω-Eth oxyca r bon ylp en tyld a id zein (26) a n d 7,4′-Di-
O-ω-eth oxyca r bon ylp en tyld a id zein (44). To a solution of
7.7 g of 2 (30.31 mmol), 30 mL of 2 N KOH (60 mmol), and
120 mL of acetone was added 12.5 mL of ethyl-6-bromo-1-
hexanoate (70.60 mmol). The mixture was refluxed with gentle
stirring for 72 h, and the products were allowed to precipitate
under refrigeration. The precipitates were collected on a fritted
funnel and fractionated on a Sephadex LH-20 column in
chloroform/methanol (7/3). Fractions that contained 26 or 44
were pooled separately, dried, and recrystallized from acetone
to give 670 mg of 26 and 5.39 g of 44. Analyses (26): white
crystalline needles; yield 5.6%; mp 130-131 °C; 1H NMR
(DMSO-d6) δ 1.17 (t, 3H, -CH3), 1.45 (m, 2H, -CH2-), 1.58
(m, 2H, -CH2-), 1.74 (m, 2H, -CH2-), 2.31 (t, 2H, -CH2-),
4.04 (m, 2H, -CH2O-), 4.09 (m, 2H, -CH2O-), 6.82 (dd, 2H,
J ) 9.76, 2.7 Hz, H-3′, H-5′), 7.04 (dd, 1H, J ) 8.87, 2.79 Hz,
H-6), 7.09 (d, 1H, J ) 2.1 Hz, H-8), 7.40 (dd, 2H, J ) 9.76, 2.7
Hz, H-2′, H-6′), 8.0 (d, 1H, J ) 8.86 Hz, H-5), 8.34 (s, 1H, H-2),
9.55 (s, 1H, OH-4′); 13C NMR δ 14.1(-CH3), 24.2 (-CH2-), 24.9
(-CH2-), 28.1 (-CH2-), 33.4 (-CH2-), 59.7 (-CH2O-), 68.3
(-CH2O-), 100.9 (C-8), 114.9 (C-6), 115 (C-3′, C-5′), 117.5 (C-
10), 122.4 (C-1′), 123.7 (C-3), 126.9 (C-5), 130.1 (C-2′, C-6′),
153.1 (C-2), 157.2 (C-9), 157.4 (C-4′), 163.0 (C-7), 172.8
(-OCO-), 174.7 (C-4); MS m/z 397.3 (M + H)+. Anal. Calcd
(C23H24O6): C, 69.68; H, 6.10. Found: C, 69.84; H, 6.15.
Analyses (44): yield 50%; mp 99-101 °C; MS m/z 539.6 (M +
7-O-ω-Hyd r oxyn on yld a id zein (18) a n d 7,4′-d i-O-ω-h y-
d r oxyn on yld a id zein (38) were synthesized according to the
procedure described for 16 using 9-bromo-1-nonanol (5 g, 22.41
mmol) as the alkylating agent. After reflux, the reaction
mixture was refrigerated, and the precipitates formed were
collected on a fritted funnel and further purified on a Sephadex
LH-20 column in chloroform/methanol (7/3). Fractions that
contained 18 or 38 were pooled separately, concentrated, and
recrystallized from acetone to yield 305 mg of 18 and 1.4 g of
38, respectively. Analyses (18): colorless crystalline plates;
1
yield 3.8%; mp 165-167 °C; H NMR (DMSO-d6) δ 1.27 [m,
8H, (-CH2-)4], 1.40 (m, 4H, -CH2CH2-), 1.73 (m, 2H, -CH2-),
3.37 (m, 2H, -CH2-), 4.09 (t, -CH2O-), 6.81 (d, 2H, J ) 8.75,
1.58 Hz, H-3′, H-5′), 7.04 (dd, 1H, J ) 8.87, 2.1 Hz, H-6), 7.10
(d, 1H, J ) 2.1 Hz, H-8), 7.39 (d, 2H, J ) 8.75, 1.58 Hz, H-2′,
H-6′), 8.0 (d, 1H, J ) 8.86 Hz, H-5), 8.34 (s, 1H, H-2), 9.53 (s,
1H, OH-4′); 13C NMR δ 25.4 (-CH2-), 25.5 (-CH2-), 28.4
(-CH2-), 28.7 (-CH2-), 28.9 (-CH2-), 29.0 (-CH2-), 32.5
(-CH2-), 60.7(-CH2O-), 68.4 (-OCH2-), 100.9 (C-8), 114.9 (C-
6), 114.9 (C-3′, C-5′), 117.5 (C-10), 122.4 (C-1′), 123.7 (C-3),
126.9 (C-5), 130.0 (C-2′, C-6′), 153.0 (C-2), 157.2 (C-9), 157.4
(C-4′), 163.0 (C-7), 174.7 (C-4); MS m/z 397.5 (M + H)+. Anal.
Calcd (C24H28O5): C, 72.71, H, 7.12. Found: C, 73.11; H, 7.13.
