Bicyclic 2-Pyridone Dipeptide Memetic
J . Org. Chem., Vol. 67, No. 3, 2002 745
(6-Bu t -3-en yl-2-m et h oxyp yr id in -3-yl)ca r b a m ic Acid
Ben zyl Ester (13). Allylmagnesium bromide (19.5 mL of a
1.0 M solution in Et2O, 19.5 mmol, 1.0 equiv) was added via
cannula over 10 min to a solution of 12 (6.84 g, 19.4 mmol, 1
equiv) in THF (200 mL) at 0 °C. Upon completion of the
addition, the reaction mixture was warmed to 50 °C where-
upon a second portion of allylmagnesium bromide (38.9 mL of
a 1.0 M solution in Et2O, 38.9 mmol, 2.0 equiv) was added.
The resulting orange solution was maintained at 50 °C for 30
min, then was cooled to 23 °C, and was partitioned between
0.5 M HCl (150 mL) and a 1:1 mixture of EtOAc and hexanes
(2 × 150 mL). The combined organic layers were dried over
Na2SO4 and were concentrated. Purification of the residue by
careful flash column chromatography (5% EtOAc in hexanes)
afforded 13 (2.24 g, 37%) as a pale yellow oil (containing minor
5.07 (m, 2H), 5.72-5.85 (m, 1H), 6.56 (d, 1H, J ) 7.5), 8.28 (d,
1H, J ) 7.5), 13.26 (s, br, 1H), 14.64 (s, br, 1H); 13C NMR
(DMSO-d6) δ 31.7, 32.0, 107.9, 113.7, 116.3, 136.5, 146.0, 156.5,
165.1, 165.1; Anal. Calcd for C10H11NO3‚0.10H2O: C, 61.59;
H, 5.79; N, 7.18. Found: C, 61.67; H, 5.71; N, 7.17.
(6-Bu t -3-en yl-2-h yd r oxyp yr id in -3-yl)ca r b a m ic Acid
Ben zyl Ester (17). Triethylamine (13.9 mL, 99.7 mmol, 2.0
equiv) and diphenylphosphoryl azide (16.1 mL, 74.7 mmol, 1.5
equiv) were added sequentially to a suspension of 16 (9.63 g,
49.8 mmol, 1 equiv) in 1,4-dioxane (450 mL) at 23 °C. The
resulting solution was heated to reflux for 7.5 h, then benzyl
alcohol (10.3 mL, 99.5 mmol, 2.0 equiv) was added, and reflux
was continued for an additional 16 h. The dark brown reaction
mixture was cooled to 23 °C, and the volatiles were removed
under reduced pressure. The resulting dark brown oil was
partitioned between water (300 mL) and EtOAc (2 × 250 mL)
and the combined organic layers were dried over Na2SO4 and
concentrated. The solid thus obtained was triturated with Et2O
(150 mL) and was filtered through a medium frit, washed with
Et2O (2 × 50 mL), and air-dried to give 17 (7.34 g, 49%) as an
off-white powder: mp ) 179-180 °C; Rf ) 0.34 (50% EtOAc
1
impurities by H NMR): Rf ) 0.84 (50% EtOAc in hexanes);
1
IR (cm-1) 3432, 1733; H NMR (CDCl3) δ 2.42-2.49 (m, 2H),
2.73 (t, 2H, J ) 7.6), 3.96 (s, 3H), 4.94-5.07 (m, 2H), 5.20 (s,
2H), 5.80-5.94 (m, 1H), 6.71 (d, 1H, J ) 7.9), 7.11 (s, br, 1H),
7.32-7.43 (m, 5H), 8.16 (s, br, 1H); 13C NMR (CDCl3) δ 33.3,
36.4, 53.3, 67.0, 114.7, 115.4, 120.0, 125.2, 128.3, 128.3, 128.6,
135.9, 138.2, 151.6, 152.1, 153.3; Anal. Calcd for C18H20N2O3:
C, 69.21; H, 6.45; N, 8.97. Found: C, 69.35; H, 6.44; N, 8.94.
6-Bu t -3-en yl-2-h yd r oxyn icot in on it r ile (14). n-Butyl-
lithium (100 mL of a 1.6 M solution in hexanes, 160 mmol,
2.5 equiv) was added via cannula over 10 min to a solution of
diisopropylamine (22.4 mL, 160 mmol, 2.5 equiv) in THF (600
mL) at -78 °C. The resulting pale yellow solution was stirred
at -78 °C for 5 min and then was warmed to 0 °C for an
additional 5 min. 2-Hydroxy-6-methylnicotinonitrile (8) (8.58
g, 64.0 mmol, 1 equiv) was added as a solid in small portions
over 15 min, and the deep orange solution thus obtained was
stirred for 1 h at 0 °C. Allyl bromide (8.31 mL, 96.0 mmol, 1.5
equiv) was then added, and the reaction mixture was warmed
to 23 °C, maintained at that temperature for 30 min, and
partitioned between 1.0 M HCl (300 mL) and EtOAc (2 × 250
mL). The combined organic layers were dried over Na2SO4 and
were concentrated. The resulting orange solid was triturated
with boiling Et2O (100 mL) and subsequently cooled to 23 °C
and then was filtered through a medium frit, washed with
Et2O (2 × 50 mL), and air-dried to give 14 (6.42 g, 58%) as a
tan solid: mp ) 122-125 °C; Rf ) 0.48 (10% CH3OH in CH2-
1
in hexanes); IR (cm-1) 3386, 1727, 1645; H NMR (CDCl3) δ
2.39-2.46 (m, 2H), 2.65 (t, 2H, J ) 7.5), 4.97-5.07 (m, 2H),
5.21 (s, 2H), 5.73-5.87 (m, 1H), 6.10 (d, 1H, J ) 7.5), 7.32-
7.44 (m, 5H), 7.68 (s, br, 1H), 8.06 (s, br, 1H), 12.74 (s, br,
1H); 13C NMR (CDCl3) δ 32.3, 32.9, 67.2, 105.8, 116.3, 123.1,
126.6, 128.4, 128.5, 128.8, 136.2, 136.7, 140.4, 153.5, 159.3;
Anal. Calcd for C17H18N2O3: C, 68.44; H, 6.08; N,. 9.39.
Found: C, 68.25; H, 6.20; N, 9.38.
(6-Bu t -3-en yl-2-m et h oxyp yr id in -3-yl)ca r b a m ic Acid
Ben zyl Ester (13) (Alter n a te P r ep a r a tion ). Trimethyloxo-
nium tetrafluoroborate (2.0 g, 13.5 mmol, 1.2 equiv) and 2,6-
di-tert-butylpyridine (1.52 mL, 6.76 mmol, 0.6 equiv) were
added to a solution of 17 (3.36 g, 11.26 mmol, 1 equiv) in CH2-
Cl2 (80 mL) at 23 °C. The reaction mixture was stirred at that
temperature for 65 h and then was partitioned between water
(100 mL) and CH2Cl2 (2 × 200 mL). The combined organic
layers were dried over Na2SO4 and were concentrated. The
residue was purified by flash column chromatography (5%
EtOAc in hexanes) to afford 13 (3.19 g, 91%) as colorless oil.
(3′R)-[6-(3′,4′-Dih yd r oxybu tyl)-2-m eth oxyp yr id in -3-yl]-
ca r ba m ic Acid Ben zyl Ester (18). To a 1:1 mixture of
t-BuOH and water (300 mL) at 0 °C was sequentially added
(DHQD)2-AQN (0.148 g, 0.164 mmol, 0.01 equiv), K3Fe(CN)6
(16.2 g, 49.2 mmol, 3.0 equiv), K2CO3 (6.8 g, 49.2 mmol, 3.0
equiv), and potassium osmate dihydrate (0.024 g, 0.066 mmol,
0.004 equiv), followed by a solution of 13 (5.13 g, 16.4 mmol,
1 equiv) in t-BuOH (25 mL). The resulting mixture was stirred
at 0 °C for 20 h, then was warmed to room temperature, and
Na2SO3 (30 g) was added carefully. The mixture was then
stirred at room temperature for 2 h, and the volatiles were
removed under reduced pressure. The residue was partitioned
between water (200 mL) and EtOAc (3 × 200 mL), and the
combined organic layers were dried over Na2SO4 and concen-
trated. The residue was purified by flash column chromatog-
raphy (2% CH3OH in CH2Cl2) to afford 18 (5.57 g, 98%) as
pale yellow oil. The enantiomeric purity of this material was
determined to be 83.4% (ee) by chiral HPLC analysis (see the
Supporting Information for additional details): Rf ) 0.20 (70%
EtOAc in hexanes); IR (cm-1) 3427 (br), 1731; 1H NMR (CDCl3)
δ 1.76-1.87 (m, 2H), 2.07-2.11 (m, 1H), 2.80-2.89 (m, 2H),
3.46-3.53 (m, 1H), 3.60-3.67 (m, 1H), 3.71-3.77 (m, 1H), 3.96
(s, 3H), 4.64 (d, 1H, J ) 3.2), 5.21 (s, 2H), 6.76 (d, 1H, J )
7.8), 7.12 (s, br, 1H), 7.34-7.43 (m, 5H), 8.22 (s, br, 1H); 13C
NMR (CDCl3) δ 32.3, 33.2, 53.9, 66.9, 67.3, 71.8, 116.0, 120.7,
126.0, 128.5, 128.6, 128.8, 136.0, 151.5, 152.3, 153.5; Anal.
Calcd for C18H22N2O5: C, 62.42; H, 6.40; N, 8.09. Found: C,
62.15; H, 6.47; N, 8.02.
1
Cl2); IR (KBr pellet, cm-1) 2223, 1654; H NMR (DMSO-d6) δ
2.32-2.37 (m, 2H), 2.62 (t, 2H, J ) 7.6), 4.96-5.06 (m, 2H),
5.69-5.83 (m, 1H), 6.23 (d, 1H, J ) 7.3), 8.03 (d, 1H, J ) 7.3),
12.55 (s, br, 1H); 13C NMR (DMSO-d6) δ 31.8, 31.9, 100.0,
104.6, 116.1, 116.7, 136.5, 148.9, 156.7, 160.8; Anal. Calcd for
C
10H10N2O‚0.10H2O: C, 68.24; H, 5.84; N, 15.92. Found: C,
68.07; H, 5.95; N, 15.66.
6-Bu t-3-en yl-2-h ydr oxyn icotin am ide (15). Hydrogen per-
oxide (30 wt % solution in water, 45 mL) was added to a
solution of 14 (12.1 g, 70.2 mmol) in a mixture of EtOH (150
mL) and 10% aqueous NaOH (280 mL) at 23 °C. The reaction
mixture was heated to 50 °C for 18 h and then was cooled to
23 °C, and the volatiles were removed under reduced pressure.
The residue was acidified with 12 M HCl to pH 2-3, and the
resulting precipitate was filtered, washed with water (2 × 50
mL), and air-dried to afford 15 as a yellow solid (13.4 g,
100%): mp ) 195-198 °C; Rf ) 0.24 (10% CH3OH in CH2Cl2);
IR (cm-1) 3329, 3134, 1688, 1642; 1H NMR (DMSO-d6) δ 2.31-
2.38 (m, 2H), 2.64 (t, 2H, J ) 7.6), 4.96-5.05 (m, 2H), 5.71-
5.84 (m, 1H), 6.29 (d, 1H, J ) 7.3), 7.45 (s, br, 1H), 8.21 (d,
1H, J ) 7.3), 9.00 (s, br, 1H), 12.37 (s, br, 1H); 13C NMR
(DMSO-d6) δ 31.4, 32.0, 105.1, 116.0, 117.9, 136.7, 144.3, 154.0,
162.9, 164.8; Anal. Calcd for C10H12N2O2‚0.15H2O: C, 61.61;
H, 6.28; N, 14.37. Found: C, 61.84; H, 6.18; N, 14.11.
6-Bu t-3-en yl-2-h yd r oxyn icotin ic Acid (16). A solution of
15 (13.4 g, 70.1 mmol) in 10% aqueous KOH (350 mL) was
refluxed for 20 h and subsequently cooled to room temperature.
The reaction mixture was acidified with 12 M HCl to pH 2-3,
and the resulting precipitate was filtered, washed with water
(2 × 50 mL), and dried under vacuum to afford 16 as a yellow
solid (12.4 g, 92%): mp ) 151-155 °C; Rf ) 0.20 (10% CH3-
OH in CH2Cl2); IR (cm-1) 2905 (br), 1736, 1652; 1H NMR
(DMSO-d6) δ 2.34-2.29 (m, 2H), 2.73 (t, 2H, J ) 7.6), 4.96-
(3′R)-{6-[4′-(ter t-Bu tyld im eth ylsila n yloxy)-3′-h yd r oxy-
bu tyl]-2-m eth oxyp yr id in -3-yl}ca r ba m ic Acid Ben zyl Es-
ter (19). Triethylamine (1.55 mL, 11.1 mmol, 2.5 equiv), tert-
butyldimethylsilyl chloride (1.07 g, 7.10 mmol, 1.6 equiv), and
4-(dimethylamino)pyridine (0.025 g, 0.20 mmol, 0.045 equiv)
were added sequentially to a solution of 18 (1.54 g, 4.45 mmol,
1 equiv) in CH2Cl2 (50 mL) at 23 °C. The reaction mixture was
