JOURNAL OF CHEMICAL RESEARCH 2018 245
Conclusion
4′-Hydroxy-2′-(3-chlorophenyl)-4′,5′-dihydro-2′H-spiro[oxindole-
3,3′-thiophen]-2-ones (2c): White powder; yield 71.7%; m.p.
176–177 °C; IR (KBr) (ν cm−1): 3434, 3292, 3014, 2920, 1699, 1618,
1469, 1398, 1087; 1H NMR (500 MHz, DMSO): δ 10.45 (s, 1H,
NH), 7.57 (d, J = 7.5 Hz, 1H, ArH), 7.15–7.07 (m, 5H, ArH), 6.97 (t,
J = 7.5 Hz, 1H, ArH), 6.63 (d, J = 7.5 Hz, 1H, ArH), 5.61 (d, J = 6.0
Hz, 1H, OH), 4.94 (s, 1H, CH), 4.70–4.66 (m, 1H, CH–OH), 3.32 (dd,
J = 10.0, 6.0 Hz, 1H, CH2), 3.21 (t, J = 10.0 Hz, 1H, CH2); 13C NMR
(125 MHz, DMSO): δ 176.77, 142.28, 138.33, 132.32, 129.56, 128.16,
127.88, 127.60, 126.81, 126.42, 125.16, 121.06, 109.24, 79.40, 65.14,
52.02, 34.22. HRMS (ESI) m/z calcd for [C17H15ClNO2S]+ (M + H)+:
332.0507; found: 332.0502.
4′-Hydroxy-2′-(4-chlorophenyl)-4′,5′-dihydro-2′H-spiro[oxindole-
3,3′-thiophen]-2-ones (2d): White powder; yield 81.3%; m.p.
176–177 °C; IR (KBr) (ν cm−1): 3294, 3019, 2926, 1689, 1619, 1467,
1399, 1326, 1171, 1082, 1017; 1H NMR (500 MHz, DMSO): δ 10.40 (s,
1H, NH), 7.57 (d, J = 7.0 Hz, 1H, ArH), 7.17–7.13 (m, 4H, ArH), 7.09 (t,
J = 7.5 Hz, 1H, ArH), 6.96 (t, J = 7.5 Hz, 1H, ArH), 6.62 (d, J = 8.0 Hz,
1H, ArH), 5.58 (d, J = 6.0 Hz, 1H, OH), 4.94 (s, 1H, CH), 4.70–4.65
(m, 1H, CH–OH), 3.32 (dd, J = 10.0, 6.0 Hz, 1H, CH2), 3.20 (t, J = 10.0
Hz, 1H, CH2); 13C NMR (125 MHz, DMSO): δ 176.79, 142.30, 134.81,
132.09, 129.84, 128.10, 127.70, 126.40, 125.24, 121.09, 109.19, 79.45,
65.15, 52.00, 34.20. HRMS (ESI) m/z calcd for [C17H15ClNO2S]+ (M +
H)+: 332.0507; found: 332.0515.
4′-Hydroxy-2′-(4-methylphenyl)-4′,5′-dihydro-2′H-spiro[oxindole-
3,3′-thiophen]-2-ones (2e): White powder; yield 89.5%; m.p.
185–186 °C; IR (KBr) (ν cm−1): 3294, 3012, 2930, 1691, 1619, 1469,
1395, 1329, 1174, 1078; 1H NMR (500 MHz, DMSO): δ 10.33 (s, 1H,
NH), 7.60 (d, J = 7.0 Hz, 1H, ArH), 7.08 (t, J = 7.5 Hz, 1H, ArH),
7.01 (d, J = 8.0 Hz, 2H, ArH), 6.96 (t, J = 7.5 Hz, 1H, ArH), 6.87 (d,
J = 8.0 Hz, 2H, ArH), 6.61 (d, J = 7.5 Hz, 1H, ArH), 5.53 (d, J = 5.5
Hz, 1H, OH), 4.91 (s, 1H, CH), 4.69–4.64 (m, 1H, CH–OH), 3.30 (dd,
J = 10.0, 7.5 Hz, 1H, CH2), 3.17 (t, J = 10.0 Hz, 1H, CH2); 13C NMR
(125 MHz, DMSO): δ 176.98, 142.37, 136.71, 132.63, 128.29, 128.04,
127.90, 126.46, 125.63, 120.97, 109.09, 79.54, 65.12, 52.50, 34.04,
20.47. HRMS (ESI) m/z calcd for [C18H18NO2S]+ (M + H)+: 312.1053;
found: 312.1055.
A facile and green synthesis of spiro compounds was
accomplished by the Michael-aldol cascade of (E)-3-
arylideneindole-2-one and 1,4-dithiane-2,5-diol under solvent-
free reaction conditions. Simplicity of operation, high yields
and easy work-up are the key advantages of this method.
Experimental
Compound 1 ((E)-3-arylideneindole-2-ones) was prepared according
to the literature method.15 All of the reagents were from commercial
suppliers and used without further purification. All of the solvents
were freshly distilled from the appropriate drying agents before use.
The analytical TLCs were performed with silica gel 60 F254 plates.
Column chromatography was carried out by using silica gel 60
(200–300 mesh). All NMR spectra were recorded on a Bruker AV-II
1
500 MHz NMR spectrometer, operating at 500 MHz for H, and 125
MHz for 13C. TMS was used as an internal reference for H and 13C
1
chemical shifts and CDCl3 was used as solvent. Mass spectra were
collected on a Waters Xevo Q-TOF HRMS instrument. IR spectra were
recorded on a PerkinElmer spectrometer (Spectrum One). Melting
points were measured with a Yanaco MP500 melting point apparatus
and are uncorrected. X-ray analysis was performed on a Bruker
Apex-II CCD diffractometer. A single crystal of 2d was obtained by
slow evaporation of a CH2Cl2/CH3OH solution of 2d. Crystal data for
2d: C17H14ClNO2S, Mr = 331.80 g mol1, triclinic space group P21/c,
a = 13.6768(16) Å, b = 12.4921(15)Å, c = 8.9120(11) Å, β = 104.395(4),
V = 1474.8(3) Å3, T = 296(2) K, Z = 4, Dc = 1.494 g m–3, μ = 0.407 mm–1,
F(000) = 688, Rint = 0.0467, 9048 reflections, 2588 with I > 2σ(I) for
200 parameters, GOF = 1.068, R1 = 0.0338, wR2 = 0.0908 [I > 2σ(I)]
and R1 =0.0387, wR2 = 0.0960 (all data). CCDC 1814629 contains the
supplementary crystallographic data for this paper. These data can be
obtained free of charge from The Cambridge Crystallographic Data
Synthesis of 4′-hydroxy-2′-aryl-4′,5′-dihydro-2′H-spiro[oxindole-
3,3′-thiophen]-2-ones (2); general procedure
(E)-3-arylideneindole-2-ones 1 (1.0 mmol) and 1,4-dithiane-2,5-
diol (1.0 mmol) was added into a mortar containing the triethylamine
(3 mmol). The resulting reaction mixture was ground at room
temperature. After completion of the reaction as monitored by TLC,
the mixture was purified by column chromatography on silica gel
using petroleum ether and ethyl acetate (3:1, V/V) as eluent and
recrystallised from ethyl alcohol to afford the corresponding product 2.
4′-Hydroxy-2′-phenyl-4′,5′-dihydro-2′H-spiro[oxindole-3,3′-
thiophen]-2-ones (2a): White powder; yield 82.3%; m.p. 181–182 °C;
IR (KBr) (ν cm−1): 3458, 3183, 3060, 2939, 2888, 1687, 1621, 1469,
1404, 1345, 1188, 1089; 1H NMR (500 MHz, DMSO): δ 10.38 (s, 1H,
NH), 7.60 (d, J = 7.5 Hz, 1H, ArH), 7.15–7.13 (m, 2H, ArH), 7.08–7.06
(m, 4H, ArH), 6.96 (t, J = 7.5 Hz, 1H, ArH), 6.60 (d, J = 7.5 Hz, 1H,
ArH), 5.58 (d, J = 5.0 Hz, 1H, OH), 4.96 (s, 1H, CH), 4.71–4.67 (m,
1H, CH–OH), 3.32 (dd, J = 10.5, 7.5 Hz, 1H, CH2), 3.20 (t, J = 10.0
Hz, 1H, CH2); 13C NMR (125 MHz, DMSO): δ 176.96, 142.32, 135.68,
128.11, 127.93, 127.68, 127.57, 126.46, 125.53, 120.99, 109.08, 79.54,
65.14, 52.69, 34.08. HRMS (ESI) m/z calcd for [C17H16NO2S]+ (M +
H)+: 298.0896; found: 298.0905.
4′-Hydroxy-2′-(3-methylphenyl)-4′,5′-dihydro-2′H-spiro[oxindole-
3,3′-thiophen]-2-ones (2f): White powder; yield 87.8%; m.p.
174–175 °C; IR (KBr) (ν cm−1): 3422, 3221, 2929, 3015, 1704, 1617,
1
1466, 1402, 1328, 1094; H NMR (500 MHz, DMSO): δ 10.37 (s,
1H, NH), 7.60 (d, J = 7.5 Hz, 1H, ArH), 7.08 (t, J = 7.5 Hz, 1H, ArH),
6.98–6.87 (m, 5H, ArH), 6.61 (d, J = 7.5 Hz, 1H, ArH), 5.56 (d, J = 6.0
Hz, 1H, OH), 4.90 (s, 1H, CH), 4.69–4.65 (m, 1H, CH-OH), 3.31 (dd,
J = 10.0, 7.5 Hz, 1H, CH2), 3.18 (t, J = 10.0 Hz, 1H, CH2); 13C NMR
(125 MHz, DMSO): δ 176.99, 142.35, 136.61, 135.62, 128.88, 128.22,
127.90, 127.52, 126.52, 125.61, 125.26, 120.88, 109.09, 79.55, 65.09,
52.66, 34.06, 20.84. HRMS (ESI) m/z calcd for [C18H18NO2S]+ (M +
H)+: 312.1053; found: 312.1062.
4 ′- Hydrox y-2 ′- (4 - methox yphenyl) - 4 ′, 5′- dihydro -2 ′ H-
spiro[oxindole-3,3′-thiophen]-2-ones (2g): Yellow powder; yield
61.3%; m.p. 196–197 °C; IR (KBr) (ν cm−1): 3391, 3225, 3016, 2932,
1704, 1510, 1401, 1248, 1176, 1060, 1028; 1H NMR (500 MHz,
DMSO): δ 10.33 (s, 1H, NH), 7.61 (d, J = 7.5 Hz, 1H, ArH), 7.09 (t,
J = 7.0 Hz, 1H, ArH), 7.04 (d, J = 8.5 Hz, 2H, ArH), 6.97 (t, J = 7.5 Hz,
1H, ArH), 6.64–6.62 (m, 3H, ArH), 5.52 (d, J = 6.0 Hz, 1H, OH), 4.89
(s, 1H, CH), 4.68–4.63 (m, 1H, CH–OH), 3.60 (s, 3H, CH3), 3.30 (dd,
J = 10.5, 7.5 Hz, 1H, CH2), 3.17 (t, J = 10.0 Hz, 1H, CH2); 13C NMR
(125 MHz, DMSO): δ 176.98, 158.52, 142.40, 129.30, 127.90, 127.36,
126.48, 125.66, 120.98, 113.03, 109.10, 79.42, 65.16, 54.84, 52.29,
34.09. HRMS (ESI) m/z calcd for [C18H18NO3S]+ (M + H)+: 328.1002;
found: 328.1008.
4′-Hydroxy-2′-(2-chlorophenyl)-4′,5′-dihydro-2′H-spiro[oxindole-
3,3′-thiophen]-2-ones (2b): White powder; yield 85.6%; m.p.
182–183 °C; IR (KBr) (ν cm−1): 3379, 3229, 3012, 2934, 1713, 1621,
1
1468, 1402, 1353, 1322, 1240, 1080; H NMR (500 MHz, DMSO): δ
10.34 (s, 1H, NH), 8.05 (d, J = 8.0 Hz, 1H, ArH), 7.40 (t, J = 7.5 Hz,
1H, ArH), 7.25–7.16 (m, 2H, ArH), 7.02 (t, J = 7.5 Hz, 1H, ArH), 6.69
(d, J = 7.5 Hz, 1H, ArH), 6.52 (t, J = 7.5 Hz, 1H, ArH), 6.00 (d, J = 7.5
Hz, 1H, ArH), 5.61 (d, J = 5.0 Hz, 1H, OH), 5.13 (s, 1H, CH), 4.51–4.47
(m, 1H, CH–OH), 3.48 (t, J = 10.0 Hz, 1H, CH2), 3.15 (dd, J = 10.0,
6.0 Hz, 1H, CH2); 13C NMR (125 MHz, DMSO): δ 178.09, 143.30,
136.90, 134.21, 131.42, 129.10, 128.83, 128.24, 127.79, 126.80, 124.00,
120.40, 108.69, 80.76, 61.53, 48.50, 33.37. HRMS (ESI) m/z calcd for
[C17H15ClNO2S]+ (M + H)+: 332.0507; found: 332.0512.
4′-Hydroxy-2′-(2-bromophenyl)-4′,5′-dihydro-2′H-spiro[oxindole-
3,3′-thiophen]-2-ones (2h): White powder; yield 70.1%; m.p.
175–176 °C; IR (KBr) (ν cm−1): 3354, 3227, 3029, 2934, 1712, 1620,
1
1466, 1433, 1403, 1352, 1238, 1080; H NMR (500 MHz, DMSO): δ
10.34 (s, 1H, NH), 8.08 (d, J = 8.0 Hz, 1H, ArH), 7.45 (t, J = 7.5 Hz, 1H,
ArH), 7.35 (d, J = 8.0 Hz, 1H, ArH), 7.16 (t, J = 7.5 Hz, 1H, ArH), 7.02
