New 2-phenylthiazoles as potential sortase a inhibitors: Synthesis, biological evaluation and molecular docking

Article abstract of DOI:10.3390/molecules22111827

Sortase A inhibition is a well establish strategy for decreasing bacterial virulence by affecting numerous key processes that control biofilm formation, host cell entry, evasion and suppression of the immune response and acquisition of essential nutrients. A meta-analysis of structures known to act as Sortase A inhibitors provided the starting point for identifying a new potential scaffold. Based on this template a series of new potential Sortase A inhibitors, that contain the 2-phenylthiazole moiety, were synthesized. The physicochemical characterisation confirmed the identity of the proposed structures. Antibacterial activity evaluation showed that the new compounds have a reduced activity against bacterial cell viability. However, the compounds prevent biofilm formation at very low concentrations, especially in the case of E. faecalis. Molecular docking studies performed estimate that this is most likely due to the inhibition of Sortase A. The new compounds could be used as add-on therapies together with known antibacterial agents in order to combat multidrug-resistance enterococcal infections.

Full text of DOI:10.3390/molecules22111827

molecules
Article
New 2-Phenylthiazoles as Potential Sortase A
Inhibitors: Synthesis, Biological Evaluation and
Molecular Docking
Smaranda Dafina Oniga 1,† ID , Cătălin Araniciu 1, ,†
*
ID , Mariana Doina Palage 1,
*
,
ID
Marcela Popa 2,3, Mariana Carmen Chifiriuc 2,3 ID , Gabriel Marc 1 ID , Adrian Pirnau 4,
Cristina Ioana Stoica 1, Ioannis Lagoudis 1, Theodoros Dragoumis 1
and Ovidiu Oniga 1
ID
1
Faculty of Pharmacy, “Iuliu Hatieganu” University of Medicine and Pharmacy, 8 Victor Babes St,
,
400012 Cluj-Napoca, Romania; smaranda.oniga@umfcluj.ro (S.D.O.); Marc.Gabriel@umfcluj.ro (G.M.);
Stoica.Cristina@umfcluj.ro (C.I.S.); lagoudisjohn@yahoo.gr (I.L.); theodorosdragoumis@icloud.com (T.D.);
ooniga@umfcluj.ro (O.O.)
Department of Microbiology, Faculty of Biology, University of Bucharest, 1-3 Portocalelor Street,
60101 Bucharest, Romania; bmarcelica@yahoo.com (M.P.); carmen_balotescu@yahoo.com (M.C.C.)
Research Institute of the University of Bucharest-ICUB, 91-95 Independentei Street,
050095 Bucharest, Romania
National Institute for Research and Development of Isotopic and Molecular Technologies,
67-103 Donat Street, 400293 Cluj-Napoca, Romania; apirnau@yahoo.com
Correspondence: araniciu.catalin@umfcluj.ro (C.A.); mpalage@umfcluj.ro (M.D.P.);
Tel.: +40374-834-851 (M.D.P.)
2
3
4
*
†
These authors contributed equally to this work.
Received: 5 October 2017; Accepted: 22 October 2017; Published: 27 October 2017
Abstract: Sortase A inhibition is a well establish strategy for decreasing bacterial virulence by affecting
numerous key processes that control biofilm formation, host cell entry, evasion and suppression of the
immune response and acquisition of essential nutrients. A meta-analysis of structures known to act
as Sortase A inhibitors provided the starting point for identifying a new potential scaffold. Based on
this template a series of new potential Sortase A inhibitors, that contain the 2-phenylthiazole moiety,
were synthesized. The physicochemical characterisation confirmed the identity of the proposed
structures. Antibacterial activity evaluation showed that the new compounds have a reduced activity
against bacterial cell viability. However, the compounds prevent biofilm formation at very low
concentrations, especially in the case of E. faecalis. Molecular docking studies performed estimate
that this is most likely due to the inhibition of Sortase A. The new compounds could be used as
add-on therapies together with known antibacterial agents in order to combat multidrug-resistance
enterococcal infections.
Keywords: 2-phenylthiazole; thiazole; antimicrobial; anti-biofilm activity; Sortase A inhibitor;
enteroccocus
1. Introduction
Preventing antibiotic resistance and identifying new antibiotics that are active against the
multidrug resistant bacteria are major current concerns [1,2]. Particularly, Gram-positive bacteria are
common causes of nosocomial bloodstream and other infections. Methicillin-resistant Staphylococcus
aureus (MRSA) and vancomycin-resistant enterococci (VRE) are the most imperative concern [3].
Gram-positive bacteria have a thick cell wall that surrounds the plasma membrane. This cell wall
is composed of peptidoglycan that serves as a matrix for the covalent attachment of wall teichoic acid,
surface proteins and polysaccharide capsule [
4
,
5]. Sortases are cysteine transpeptidases that are able to
Molecules 2017, 22, 1827; doi:10.3390/molecules22111827
www.mdpi.com/journal/molecules

Molecules 2017, 22, 1827
2 of 18
join proteins bearing an appropriate sorting signal to strategically positioned amino groups on the cell
surface. Sortases are not essential for bacterial viability, but they become important virulence factors
because the surface proteins that they help display mediate biofilm formation, bacterial adhesion
to host tissues, host cell entry, evasion and suppression of the immune response and acquisition of
essential nutrients [6].
From the study of the nearly a thousand sortase homologues identified so far in different
Gram-positive bacterial strains it is apparent that they share similar structures, catalytic attributes and
substrates. The prototypical Sortase A enzyme, the best understood and most studied, is the one from
S. aureus (Sa-SrtA). At least twenty different S. aureus surface proteins that carry a C-terminal LPXTG
(leucine, proline, X, theronine, and glycine, where X is any amino acid) motif have been described as
being anchored via Sa-SrtA. Some of the LPXTG surface proteins, including Spa, FnbpA, FnbpB, ClfA,
ClfB and other microbial surface components recognizing adhesive matrix molecules (MSCRAMMs),
are directly linked with biofilm formation [7–11]. Bacterial ability to form biofilms allows them to
colonize inert substrates (e.g., implantable medical devices) thus causing infections that are difficult to
treat because the biofilm matrix and phenotypic characteristics of the bacteria confer resistance to both
the host immune response and the action of antimicrobial drugs [9,12–15].
Selecting Sortase A as a target for the development of new antibacterial drugs is supported
primarily by the key role this enzyme has in Gram-positive bacterial virulence and also by the fact that
no sortase homologs are present in eukaryota, which could lead to specific toxicity against bacteria with
a good pharmaco-toxicological profile in humans. In the same time, the fact that these enzymes are
found in the membrane/cell-wall implies that inhibitors do not have to penetrate inside the bacterial
cell, which diminishes the pharmacokinetic requirements for a new inhibitor. Another potential benefit
of Sortase A inhibitors would be the fact that they will act only by reducing virulence and biofilm
formation, thus exerting no selective pressure that could eventually lead to development of resistant
bacteria strains [14,16,17].
The effort to discover a Sortase A inhibitor has identified various structural scaffolds as
potentially clinical useful solutions. These include: 2-phenylbenzofuran-3-carboxamide [18],
2-phenylbenzo[d]oxazole-7-carboxamide [19], 2-(2-phenylhydrazinylidene)alkanoic acids [20],
benzisothiazolinone
[
21], indolethiazolidine
[
22], rhodanines
[23], diarylacrylonitriles,
triazolo-thiadiazole [24], and other structures as presented in the reviews of these fields [16,25,26].
Although many of the chemical classes rely on covalent interactions with the active site some
have proved to have a non-covalent inhibition process [25,27]. Based on our previous research
experience [28 31] and considering the molecular scaffolds used by other research groups and the
–
general pharmacophore requirements described in the computational studies [23,25,32] we decided to
synthesize a series of 2-phenyl-thiazole derivatives.
The proposed structures are in agreement with the Bemis-Murcko scaffolding results obtained by
the analysis of 156 small compounds that are known inhibitors of Sortase A [25]. The new compounds
have a scaffold characterised by five aromatic rings linked directly which allows for limited free
rotation of the bonds, as shown in Figure 1. This ensures low molecular flexibility with a number of
rotatable bonds less or equal to 4 thus complying with the most relevant descriptor for SrtA affinity [25].
The requirement for the presence of at least two hydrophobic regions, with molecular LogP values
above 2, is also met by this scaffold. The inclusion of the two thiazole rings within the scaffold ensures
the potential for hydrogen bond formation with 2 or 3 hydrogen bond acceptor atoms [23,25].
In order to validate the biological potential of the synthesized structures as Sortase A inhibitors we
performed a biological determination of the antibacterial and anti-biofilm effect. If the new compounds
act by inhibiting sortases, cell viability should not be influenced, while the ability to colonize inert
substrates by biofilm formation should be heavily decreased. The hypothesis of sortase inhibition was
further verified by a series of molecular docking studies to estimate the binding potential and mode of
the new synthesized compounds to different subtypes of Sortase A (e.g., sortase from S. aureus and
E. faecalis).

Molecules 2017, 22, 1827
3 of 18
Figure 1. The design strategy for the target compounds.
2. Results and Discussion
2.1. Chemistry
Using the reaction route described in Figure 2, eight final compounds were obtained. The two key
intermediates, the nitrile derivative and the thioamide derivative , were also characterized in order
to establish identity and purity. The thioamide moiety in intermediate allowed for various subsequent
Hantzsch condensations with α-bromocarbonyl compounds that yielded a new thiazole ring.
1
2
2
C1
C2
C3
C4
C5
4-CN- C
H
C6
1- C10
H
C7
3-CONH2, 4-OH - C
H
C8
4-Cl- C
H
Ar
C
6H
5
C
6H
5
4-NO
2
–C
6H4
4-OCH3–C
6H4
6
H5
H7
6H3
6H4
R
1
CH
3
H
H
H
Figure 2. The synthesis of the 2-phenylthiazole derivatives (C1–8).
All structural analysis data proved that the structures of the obtained compounds are in
1
accordance with the proposed structures. The H-NMR spectra of compounds C1
–
8
showed the
disappearance of the 2H singlet from the thioamide intermediate
2 and the presence of a new 1H
corresponding to the proton in the position 5 of the newly formed thiazole ring (C2
corresponding to the methyl group in C1.
–8) or 3H singlet
The IR spectra of the final compounds C1
–8 showed the presence of a sharp signal between
3111–3103 cm−1 characteristic of the
ν
C5-H stretching vibration from the thiazole ring, as well as

Molecules 2017, 22, 1827
4 of 18
absorbance bands characteristic of aromatic rings. Specific signals for each final compound can also be
identified, such as a 2920 cm−1 νC-H alkane stretching vibration for C1, two strong signals at 1519 and
1346 cm−1 characteristic to the asymmetric and symmetric stretching vibration due to the N-O bonds
from the nitro group in C3, 1251 cm−1 and 1030 cm−1 bands characteristic of the asymmetric and
symmetric stretching vibrations due to the C-O bonds in the ether group in C4, a strong absorption
−1
−1
band at 2225 cm−1 due to the nitrile group in C5, and a high intensity absorption band at 826 cm
characteristic of the νC-Cl in C8. Compound C7 showed a wide absorption band centred at 3443 cm
corresponding to the O-H stretching vibration from the phenol group, two strong absorption bands at
3326 and 3230 cm−1 due to the
νN-H vibrations from the amide, a high intensity absorption band at
1666 cm−1 characteristic of the C=O bond, and a bending signal at 1619 cm−1 due to the N-H bond.
Mass spectra was recorded for the intermediates as well as for all final compounds and revealed
the molecular ion peaks as expected from their formulas.
2.2. Biological Assays
The antimicrobial activity was evaluated using five Gram-positive bacterial strains and two
Gram-negative bacterial strains.
2.2.1. Antimicrobial Activity—Initial In Vitro Qualitative Screening Study
The results of the initial qualitative antimicrobial screening revealed that most of the tested
compounds showed a good activity against most Gram-positive bacteria strains and a total lack of
activity against B. subtillis and the Gram-negative bacteria strains, as shown in Table 1. The best
antibacterial activity was against E. faecalis and S. saprophyticus, with microbial growth inhibition
zone diameter values comparable with those of the standard ciprofloxacin. The solvent used, DMSO,
did not produce any inhibition of bacterial growth.
Table 1. The antimicrobial activity of the tested compounds expressed as microbial growth inhibition
diameters (mm).
Enterococcus
faecalis
ATCC 29212
Staphylococcus
aureus ATCC
6538
Staphylococcus Staphylococcus
Bacillus
Escherichia
coli ATCC
8739
Pseudomonas
aeruginosa
ATCC 27853
Compound
aureus BAA
saprophyticus subtilis ATCC
ATCC 15305
1026
6633
C1
C2
C3
C4
C5
C6
C7
14
13
14
12
13
14
10
12
15
0
9
8
8
8
9
10
0
9
14
0
10
8
7
8
8
0
0
10
15
0
10
11
13
10
12
0
0
0
0
0
0
0
0
0
14
0
0
0
0
0
0
0
0
0
14
0
0
0
0
0
0
0
0
0
16
0
0
C8
10
16
0
Ciprofloxacin
DMSO
2.2.2. Antimicrobial Activity—In Vitro Quantitative Assay
The quantitative assay of the antimicrobial activity was performed only for the compounds that
showed antimicrobial activity in the initial preliminary qualitative screening. As such, the compounds
were only tested against four Gram-positive bacteria strains. The minimum inhibitory concentrations
(MIC) for the compounds are shown in Table 2. They reveal modest antibacterial activity when
compared with the standard ciprofloxacin. Direct antibacterial activity against S. aureus ATCC 6538
is not significant while against S. aureus BAA1026 compound C4 has a modest activity (32
The strongest antibacterial activity was noticed against E. faecalis and S. saprophyticus, although it is
generally modest when compared with the standard. The lowest MIC, 2 g/mL, was determined for
µg/mL).
µ
the chloro-derivative C8 against S. saprophyticus, and it is the only antibacterial activity comparable
with that of the standard.

Molecules 2017, 22, 1827
5 of 18
Table 2. The minimum inhibitory concentrations MIC (mg mL−1) values of the tested compounds
against the tested microbial strains.
Enterococcus faecalis
Compound
Staphylococcus aureus Staphylococcus aureus
Staphylococcus
saprophyticus ATCC 15305
ATCC 29212
ATCC 6538
BAA 1026
C1
C2
C3
C4
C5
C6
C7
C8
0.25
0.125
0.062
0.062
0.062
0.016
0.25
>1
>1
>1
>1
>1
>1
-
>1
0.0005
>1
0.125
>1
0.032
>1
>1
0.032
0.032
0.125
0.016
-
-
-
-
0.032
0.002
>1
0.001
0.002
0.0005
Ciprofloxacin
2.2.3. Anti-Biofilm Activity Assay
Biofilm formation was used as a measure of Sortase A inhibition potential, as it is generally
accepted that biofilm formation is strictly dependent on the many molecules anchored by sortases
at the surface of the cells. The anti-biofilm activity evaluation was performed against all bacterial
species: Gram-positive and Gram-negative. Results, presented in Table 3, showed that the synthesized
compounds are not active against Gram-negative bacteria biofilm formation. In the same time,
when analyzing effects against Gram-positive bacteria, the effect against E. faecalis was prominent with
MBEC values between 2–16 µg/mL. A modest activity was observed for compounds C4–7 against
S. aureus BAA1026.
Table 3. The minimal biofilm eradication concentration MBEC (mg mL−1) values of the tested
compounds against the tested microbial strains.
Enterococcus
faecalis
ATCC 29212
Staphylococcus
aureus ATCC
6538
Staphylococcus Staphylococcus
Bacillus
Escherichia Pseudomonas
Compound
aureus BAA
saprophyticus subtilis ATCC coli ATCC
ATCC 15305
aeruginosa
1026
6633
8739
ATCC 27853
C1
C2
C3
C4
C5
C6
C7
C8
0.004
0.002
0.002
0.004
0.002
0.004
0.008
0.016
1
1
>1
>1
1
1
1
>1
1
1
>1
0.062
0.25
0.25
0.25
>1
>1
>1
>1
>1
>1
>1
>1
>1
1
1
1
1
1
>1
>1
>1
1
1
>1
>1
1
1
1
1
1
1
1
1
>1
>1
1
1
2.3. Molecular Docking
Because of the high interest in antibacterial agents active against Staphylococcus aureus, a highly
pathogenic, virulent and drug resistant bacteria, the catalytic process of sortases is best characterized for
Sa-SrtA. Structural characterisation studies have shown that Sa-SrtA adopts an eight-stranded β-barrel
structure that houses there essential active site residues: His120, Cys184 and Arg197. Transpeptidation
proceeds by the binding of the LPXTG sorting signal to a large groove adjacent to the active site,
through an induced-fit mechanism [6,33]. The active site thiol of Cys184 then nucleophilically attacks
the carbonyl group of the substrate threonine residue forming a transient intermediate stabilized by
Arg197. This intermediate rearranges into a thioacyl enzyme-substrate complex with the cleavage of
the theronine-glycine peptide bond. The terminal amine group from the pentaglycine branch of lipid
II then nuclepphilically attacks the carbonyl moiety of the theronine, thus completing the transfer of
the initial LPXTG signal protein to the cell wall [6].
Due to the structural similarity of the active site of different sortases A, it is assumed that this
catalytic process is similar for most sortases A. A phylogenetic analysis of SrtA reveals that these
enzymes are closely related with various degrees of homology [17,34].
The tested compounds were docked into the catalytic site of E. faecalis Sortase A and S. aureus
Sortase A enzymes. The predicted best binding affinity of conformation of each compound to the

Molecules 2017, 22, 1827
6 of 18
catalytic site of enzymes and the inhibition constant (Ki) of the best pose are presented in Table 4.
Inhibition constant (Ki) was calculated based on the computed binding affinity energy (∆G) using the
formula: Ki = e∆G×1000 , where R represents the Regnault constant = 198,719 and T = 298.15 K.
R×T
Table 4. Binding energies and Inhibition constants for the C1–8—Sortase A complexes.
E. faecalis Sortase A
S. aureus Sortase A
Compound
Binding Energy
Inhibition
Binding Energy
Inhibition
(kcal/mol)
Constant (nM)
(kcal/mol)
Constant (nM)
C1
C2
C3
C4
C5
C6
C7
C8
−9.54
−9.46
101.64
116.34
18.80
51.75
15.88
18.17
81.62
45.98
−8.16
−7.25
−9.00
−7.28
−8.50
−7.90
−8.37
−8.61
1043.84
4849.25
252.88
4609.83
588.05
1618.89
732.32
488.41
−10.54
−9.94
−10.64
−10.56
−9.67
−10.01
2.3.1. Sequence Alignment and Validation of the Generated Model for E. faecalis ATCC 29212 Sortase A
Because no three dimensional structure corresponding to Sortase A from E. faecalis ATCC 29212
was available in Protein Data Bank, a homology modelling operation was performed. Considering the
DR75_168 sequence, that represents the primary amino acid sequence of the E. faecalis ATCC 29212
Sortase A target, a sequence alignment process was performed. This process provided PDB 3TBE
´
(X-ray structure, 2.85 Å resolution) as a good template for modelling, with 53.46% identity match.
In addition, a supplementary alignment was performed on EMBOSS Stretcher. The comparison of
template and target sequence revealed that many amino acids seem to be conserved. One to five
amino acids groups randomly appear to be conserved and two large blocks with a high degree of
conservation were found between 163–170, 190–201 amino acid positions, as shown in Figure 3.
Figure 3. Sequence alignment between E. faecalis Sortase A (DR75_168) and the template structure (3TBE).

Molecules 2017, 22, 1827
7 of 18
Root mean square deviation (RMSD) between the template and newly generated Sortase A
´
structure (further referred to as EfSRT_29212) structures was found to be equal to 0.129 Å. z-Score
computed for the template was found to be equal to
−
4.96 kcal/mol while the one for the EfSRT_29212
structure was found to be equal to −5.8 kcal/mol, as shown in Figure 4.
In the Ramachandran plot, 92.9% of the amino acid residues were found in the favoured region,
4.5% of the residues were found in the allowed region while only 2.6% of the residues were found
in the disallowed region. Based on these data, the constructed structure of Sortase A of E. faecalis
EfSRT_29212 is considered qualitative.
(a)
(b)
Figure 4. The plot representing Z score for the template (3TBE) (
for E. faecalis EfSRT_29212 (b).
a) and for the new generated Sortase A
E. feacalis Sortase A EfSRT_29212 is made of 156 amino acids while S. aureus Sortase A contains
148 amino acids. Sequence alignment of the two enzymes is depicted in Figure 5. Secondary structure
of both enzymes of E. faecalis and S. aureus contains two β-sheets one above the other, made of four
strands each, one of the strands being common.
Figure 5. Sequence alignment of the E. feacalis Sortase A (EfSRT_29212) and the S. aureus Sortase A
(PDB 1IJA). The catalytic amino acid residues are depicted in red.
In addition, the secondary structure of the Sortase A enzyme of E. faecalis has two
(Thr35-Asn40 and Pro68-Ala78). Close to it, a supplementary strand (Val43-Phe45) is found, partially
enlarging to the side one of the -sheets. More than that, a small -sheet (Tyr129-Asn130 and
α-helices
β
β

Molecules 2017, 22, 1827
8 of 18
Val135-Glu137) is present, creating a distal region in the protein close to the catalytic site of the
enzyme, which is important for binding the potential ligands.
The secondary structure of the Sortase A enzyme of S. aureus (PDB 1IJA) has three small α-helices
and a long loop in the N-terminus part of the protein (Pro79-Gly105), part of it (Asp82-Lys89)
surrounding the catalytic site of the enzyme and a smaller one (His153-Asp164). Located near
the catalytic site are one of the helices (Ala124-Glu128) and two strands (Thr146-Gly152 and
Asp208-Asn221). The structures alignment process found 38 amino acids identical (23.3%), 65 amino
acids similar (39.9%) and 22 gaps (13.5%). This two proteins have some degree of similarity, but they
have significant differences that are likely to greatly influence their properties.
2.3.2. Binding Mode of the C1–8 2-Phenylthiazoles to the Catalytic Site of Sortases
The analysis of the proposed binding mode of the investigated compounds to the active sites of
the two sortases revealed a totally different interaction manner. When taking into consideration the
binding energy and subsequent inhibition constant Ki values obtained for corresponding compounds,
it became obvious that the binding to the Sortase A of E. faecalis (EfSRT_29212) is far superior to the
binding towards the S. aureus Sortase A (PDB 1IJA), as shown in Table 4.
Moreover, the overall binding potential to EfSRT_29212 is greater than the overall binding
potential to PDB 1IJA. This is supported by the fact that the lowest value predicted for the binding
energies corresponding to the C1
than highest value predicted for the binding energies corresponding to the C1
–
8
: EfSRT_29212 complexes ( 9.46 kcal/mol for C2) is more elevated
−
–8: PDB 1IJA complexes
(−9.00 kcal/mol for C3).
Considering the top binding conformations of C1–8 to the active site of the Sortase A of E. faecalis
(EfSRT_29212) we further focused on specific AA binding interactions. The main AA-inhibitor interactions
and the predicted bond length values for the top binding conformation are presented in Table 5.
The binding pattern generally involves hydrogen bonds between the thiazole nucleus nitrogen
(N1 or N2) atom and the hydroxyl group from Thr122 and polar contacts between thiazole nucleus
nitrogen (N1 or N2) atom and the amide carbonyl group from Thr122, as shown in Figure 6.
Figure 6. Compound C3’s predicted binding mode to the active site of EfSRT_29212 E. faecalis Sortase A.
Active site and the ligands are depicted as sticks. The hydrogen bonds are depicted as dashed redlines.

Molecules 2017, 22, 1827
9 of 18
Table 5. Predicted polar contacts between C1–8 and Sortase A from E. faecalis (EfSRT_29212).
Compound
Ligand Atom ID
Interacting AA Residue
Bond Length (Å)
N1
N1
Thr122-OH
Thr122-C=O
2.9
3.1
C1
C2
N1
Thr122-OH
3.1
N1
N2
O-nitro
O-nitro
O-nitro
Thr122-OH
Ser85-C=O
Arg224-C=NH
Arg224-C-NH2
Asn221-C-NH2
2.8
3.0
2.8
3.5
2.5
C3
C4
N1
N2
O-methoxy
O-methoxy
Thr122-OH
Ser85-C=O
Arg224-C=NH
Arg224-C-NH2
2.9
2.9
3.0
3.3
N1
N-cyano
Thr122-OH
Asn221-C=O
2.8
3.5
C5
C6
N1
N1
Thr122-OH
Thr122-C=O
2.9
3.1
N2
N2
Thr122-OH
Thr122-C=O
2.9
3.1
C7
C8
OH
NH2
Glu135-COOH
Asp82-COOH
2.8
3.0
N1
N1
Thr122-OH
Thr122-OH
2.9
3.0
Furthermore, the binding affinity is augmented by a supplementary interaction that involves
2 claws that enclose the docked compounds. The claws are made up of Lys121, Thr122, Asn123 on one
side and Glu86, Thr87, Gln88, Lys89, Thr90, Thr91 on the other side, as depicted in Figure 7.
Figure 7. 3D-surface representation of the predicted binding mode of C1–8 to the active site of E. faecalis
Sortase A (EfSRT_29212). All compounds cause a steric hindrance that prevents access to the catalytic
AA triad while binding is strengthen by the two distal claws that enclose the compounds.

Molecules 2017, 22, 1827
10 of 18
Additional particular bonding is possible in the case of the compounds that have a polar
substituent on the third phenyl ring. For example, due to the nitro substituent compound C3 is
able to also interact via hydrogen bonds with the guanidine moiety from Arg224 and the –NH2 from
the amide group of Asn 221(see Figure 6). Compound C3 seems to bind to the active site of Sortase A
of E. faecalis (EfSRT_29212) by anchoring to the Asn221, Arg224, Ser85 and Thr 122 amino acid residues.
These interactions are polar contacts that assure the binding of C3 at the level of the catalytic site’s
cavity, as depicted in Figures 6 and 7. This binding causes a steric hindrance that prevents access of the
substrate to the His153-Cys215-Arg224 catalytic triad.
Similarly, compound C4 is able to form hydrogen bonds between the methoxy substituent and
the guanidine moiety from Arg224. A specific interaction is possible for the salicylamide derivative C7
which is capable of hydrogen bond interaction with the carboxyl groups of Glu135 and Asp82.
These potential interactions highlight the fact that most compounds, except C3 and C4, lack direct
interaction with the His153-Cys215-Arg224 catalytic triad, thus supporting the claim of a non-competitive
inhibition mechanism.
The predicted binding affinities of C1–8 to S. aureus Sortase A (PDB 1IJA) are weaker than the
binding to E. faecalis Sortase A (EfSRT_29212). The active site of PDB 1IJA is characterised by a more
lipophilic lining of the pocket caused by the dominance of lipophilic AA residues as shown in Table 6.
In the same time, the site has fewer hydrogen bonds donors and fewer hydrogen bond acceptors,
while the internal surface and volume of the active site pocket are smaller than those from EfSRT_29212.
These characteristics render the active site of S. aureus Sortase A less “druggable”, especially
when considering the fact that the tested compounds are lengthy molecules. The molecular scaffold of
our derivatives does not fit into this active site mainly because due to their length, only part of the
molecule can be accommodated within the active site, as depicted in Figure 8.
Another inconvenience is represented by the presence of the Trp136 residue in the proximity
of the catalytic site that hinders the access of the compounds towards the catalytic triad
His62-Arg139-Cys126 [5].
When considering the binding profile of compound C3, shown in Figure 9, it is apparent that
due to the active site characteristics only one polar interaction is possible (between the nitro group of
C3 and the terminal amine group from Lys115). This enables a very weak anchoring process with no
interactions with the AA residues of the catalytic site.
Figure 8. 3D-surface representation of the predicted binding mode of C1–8 to the active site of
S. aureus Sortase A (PDB 1IJA). The small active site pocket does not seem able to accommodate the
pentacyclic compounds.

Molecules 2017, 22, 1827
11 of 18
Figure 9. Compound C3’s predicted binding mode to the active site of S. aureus Sortase A (PDB 1IJA).
Active site and the ligands are depicted as sticks. No hydrogen bonds are predicted; one polar contact
(red dashes) between Lys 115 and the nitro group is anticipated.
Table 6. Comparative description of the characteristic parameters of the 2 sortases A active sites.
Parameter
E. faecalis
S. aureus
´
´
580.03 Å3
387.65 Å3
Volume
´
´
1022.95 Å2
654.68 Å2
Internal surface
H bond donor AA
H bond acceptor AA
Non polar AA
Polar non-ionic AA
Cationic AA
23
56
29%
34%
21%
16%
9
24
52%
14%
24%
10%
Anionic AA
3. Materials and Methods
3.1. General Information
Chemicals used for the synthesis, isolation and purification were purchased from Merck
(Darmstadt, Germany), Sigma-Aldrich (Taufkirchen, Germany) and Alfa Aesar (Karlsruhe, Germany).
All chemicals were of analytical reagent grade purity.
Thin-layer chromatography was performed on silica gel sheets, with UV-light visualization.
The melting points are uncorrected and were obtained by using an Electrothermal 9100 melting
point apparatus (Cole-Parmer, Stone, Staffordshire, UK). IR spectra were recorded on a FT/IR 6100
spectrometer (Jasco, Cremella, Italy) after compression in anhydrous KBr pellets under vacuum.
Water and carbon dioxide signals were removed from the recorded IR spectrum using the computer
interface software Spectra Manager and assignment of signals was assisted by Know It All 7.8 by
Bio-Rad Laboratories (Hercules, CA, USA).
MS spectra were obtained by using a Mat 111, 70 eV instrument (Varian, Bremen, Germany) by
directly introduction of the solid samples. The 1H-NMR and 13C-NMR were recorded on an Avance
NMR spectrometer (Bruker, Karlsruhe, Germany) operating at 500 MHz or 125 MHz, in DMSO-d6 as
solvent. Chemical shift values are reported in
δ units, relative to TMS as internal standard. All spectral
data were in accordance with the proposed chemical structures. Elemental analysis was performed by
Vario El CHNS analyzer (Hanau, Germany). The results obtained for all synthesized compounds were
in agreement with the calculated values ±0.4%.

Molecules 2017, 22, 1827
12 of 18
Intermediate compounds
1
and
2
as well as final compounds C2
,
C3 and C8 have been previously
reported [35] and have been re-synthesized as a part of a series based on the generated scaffold.
3.2. Chemistry
Synthesis of 4-(2-phenylthiazol-4-yl)benzonitrile (1). A mixture of thiobenzamide (10 mmol) and the
4-(2-bromoacetyl)benzonitrile (10 mmol) was dissolved in anhydrous acetone (50 mL) and stirred at
room temperature for 24 h. The resulting solid was filtered and washed with a solution of NaHCO3
5% until free of acid. The solid was then recrystallized from methanol to yield the pure compound.
4-(2-Phenylthiazol-4-yl)benzonitrile (
thiazole str), 3061 (C-H str arom), 2224 (str CN), 1606, 1575, 1506, 1438 (Ar ring str), 976 (C-H
bend arom), 852 (C-H def arom). 1H-NMR (DMSO-d6, ppm):
8.4 (s, 1H, H-thiazole), 8.10 (m,
2H, Ph2), 8 (m, 2H, Ph2), 7.9 (m, 2H, Ph1), 7.55 (m, 3H, Ph1). 13C-NMR (DMSO-d6)
(ppm): 118.6
1
). White powder. m.p. 137 ◦C. IR (KBr)
ν
cm−1: 3103 (C-H
max
δ
δ
CN, 158.62 (thiazole C2), 148.76 (thiazole C4), 129.12 (thiazole C5), 128.2–131.3 (12 C, 2 phenyl rings).
Anal. calcd. (%) for C16H10N2S (262.06): C, 73.26; H, 3.84; N, 10.68; S, 12.22. Found: C, 73.21; H, 3.89;
N, 10.65; S, 12.25. MS (EI, 70 eV): m/z 262 (M+).
Synthesis of the 4-(2-phenylthiazol-4-yl)benzothioamide (2). A solution of 4-(2-phenylthiazol-4-yl)benzonitrile
(8 mmol) in ethanol (10 mL) and triethylamine (1 mL) was maintained at room temperature while
hydrogen sulfide gas was bubbled into the solution for 8 h. The reaction mixture was then poured in
cold water and the solid formed was filtered out, washed with water and recrystallized from ethanol.
◦
4-(2-Phenylthiazol-4-yl)benzothioamide (
2
). Light-yellow powder. m.p. 179 C. IR (KBr)
ν
cm−1
:
max
3408, 3384 (N-H str), 3104 (C-H thiazole str), 3086 (C-H str arom), 1625 (N-H bend), 1603, 1570, 1506,
1459 (Ar ring str), 1133 (C=S str), 975 (C-H bend arom), 850 (C-H def arom). 1H-NMR (DMSO-d6,
ppm):
δ
8.55 (s, 2H, thioamide), 8.45 (s, 1H, H-thiazole), 8 (m, 2H, Ph2), 7.9 (m, 2H, Ph1), 7.55 (m, 3H,
(ppm): 188.2 C=S, 158.92 (thiazole C2), 148.96 (thiazole
Ph1), 7.45 (m, 2H, Ph2). 13C-NMR (DMSO-d6)
δ
C4), 128.38 (thiazole C5), 128.2–143.3 (12 C, 2 phenyl rings). Anal. calcd. (%) for C16H12N2S2 (296.04):
C, 64.83; H, 4.08; N, 9.45; S, 21.64. Found: C, 64.88.21; H, 4.03; N, 9.41; S, 21.69. MS (EI, 70 eV):
m/z 296 (M+).
General Procedure for the Synthesis of the 4-Aryl-2-(4-(2-phenylthiazol-4-yl)phenyl)thiazoles (C1
–8).
A mixture of 4-(2-phenylthiazol-4-yl)benzothioamide (1 mmol) and the corresponding -bromoketone
α
(1 mmol) was dissolved in anhydrous acetone (5 mL) and stirred at room temperature for 24 h.
The resulting solid was filtered and washed with a solution of NaHCO3 5% until free of acid.
The compounds were then recrystallized from methanol to yield the pure compounds.
◦
5-Methyl-4-phenyl-2-(4-(2-phenylthiazol-4-yl)phenyl)thiazole (C1). Off-white powder. m.p. 235 C.
IR (KBr)
ν
cm−1: 3106 (C-H thiazole str), 3080 (C-H str arom), 2920 (C-H str CH3), 1602, 1572,
max
1
1503, 1439 (Ar ring str), 978 (C-H bend arom), 851 (C-H def arom). H-NMR (DMSO-d6, ppm):
δ 8.33
(s, 1H, H-thiazole), 8.23 (m, 2H, Ph2), 8.18 (m, 2H, Ph2), 8.05–7.5 (m, 10H, Ph1,3), 2.75 (s, 3H, CH3).
13C-NMR (DMSO-d6)
δ
(ppm): 166.32 (thiazole-1 C2), 158.5 (thiazole-2 C2), 152.96 (thiazole-1 C4),
152.1 (thiazole-2 C4), 129.8 (thiazole-1 C5), 120.81 (thiazole-2 C5), 17.45 (CH3 thiazole), 126–130.9 (18C,
3 phenyl rings). Anal. calcd. (%) for C25H18N2S2 (410.09): C, 73.14; H, 4.42; N, 6.82; S, 15.62. Found: C,
73.01; H, 4.45; N, 6.89; S, 15.65. MS (EI, 70 eV): m/z 410 (M+).
◦
−1
:
2-Phenyl-4-(4-(4-phenylthiazol-2-yl)phenyl)thiazole (C2). Off-white powder. m.p. 205 C. IR (KBr)
νmax cm
3108 (C-H thiazole str), 3069 (C-H str arom), 1599, 1576, 1502, 1458 (Ar ring str), 980 (C-H bend arom),
1
851 (C-H def arom). H-NMR (DMSO-d6, ppm):
δ
8.53 (s, 1H, H-thiazole), 8.35 (s, 1H, H-thiazole),
(ppm): 166.1
8.25 (m, 2H, Ph2), 8.15 (m, 2H, Ph2), 8.02–7.4 (m, 10H, Ph1,3). 13C-NMR (DMSO-d6)
δ
(thiazole-1 C2), 159 (thiazole-2 C2), 152.66 (thiazole-1 C4), 152.3 (thiazole-2 C4), 129.2 (thiazole-1 C5),
121.11 (thiazole-2 C5), 126.4–130 (18C, 3 phenyl rings). Anal. calcd. (%) for C24H16N2S2 (396.53): C,
72.70; H, 4.07; N, 7.06; S, 16.17. Found: C, 72.55; H, 4.12; N, 7.13; S, 16.2. MS (EI, 70 eV): m/z 396 (M+).

Molecules 2017, 22, 1827
13 of 18
4-(4-Nitrophenyl)-2-(4-(2-phenylthiazol-4-yl)phenyl)thiazole (C3). Yellow powder. m.p. 238 ◦C. IR (KBr)
ν
max cm−1: 3110 (C-H thiazole str), 3081 (C-H str arom), 1597, 1577 (Ar ring str), 1519 (N-O NO2 str),
1
1448 (Ar ring str), 1346 (N-O NO2 str), 980 (C-H bend arom), 842 (C-H def arom). H-NMR (DMSO-d6,
ppm):
δ
8.6 (s, 1H, H-thiazole), 8.4 (s, 1H, H-thiazole), 8.33 (dd, 2H, Ph-NO2), 8.25 (dd, 2H, Ph-NO2),
(ppm):
8.2 (m, 2H, Ph2), 8.10 (m, 2H, Ph2), 8 (m, 2H, Ph1), 7.55 (m, 3H, Ph1). 13C-NMR (DMSO-d6)
δ
165.82 (thiazole-1 C2), 158.7 (thiazole-2 C2), 153.26 (thiazole-1 C4), 151.8 (thiazole-2 C4), 127.8 (thiazole-1
C5), 119.81 (thiazole-2 C5), 126–147.2 (18C, 3 phenyl rings). Anal. calcd. (%) for C24H15N3O2S2 (441.06):
C, 65.29; H, 3.42; N, 9.52; S, 14.52. Found: C, 65.33; H, 3.40; N, 9.54; S, 14.49. MS (EI, 70 eV): m/z 441(M+).
4-(4◦-Methoxyphenyl)-2-(4-(2-phenylthiazol-4-yl)phenyl)thiazole (C4). Yellowish—brown powder. m.p.
223 C. IR (KBr)
ν
max cm−1: 3109 (C-H thiazole str), 3057 (C-H str arom), 1608, 1578, 1503, 1460 (Ar ring str),
1
1251 (C-O-C assym str), 1030 (C-O-C sym str), 981 (C-H bend arom), 838 (C-H def arom). H-NMR
(DMSO-d6, ppm):
δ 8.65 (s, 1H, H-thiazole), 8.38 (s, 1H, H-thiazole), 8.3 (m, 2H, Ph2), 8.20 (m, 2H,
Ph2), 8 (m, 2H, Ph-OCH3) 8.06 (m, 2H, Ph1), 7.60 (m, 3H, Ph1), 7.05 (dd, 2H, Ph-OCH3), 3.85 (s, 3H,
OCH3). 13C-NMR (DMSO-d6) δ (ppm): 166.92 (thiazole-1 C2), 157.9 (thiazole-2 C2), 152.66 (thiazole-1
C4), 152.18 (thiazole-2 C4), 128.2 (thiazole-1 C5), 120.21 (thiazole-2 C5), 56.92 (OCH3), 126–159.04 (18C,
3 phenyl rings). Anal. calcd. (%) for C25H18N2OS2 (426.09): C, 70.39; H, 4.25; N, 6.57; S, 15.03. Found:
C, 70.44; H, 4.21; N, 6.59; S, 15.13. MS (EI, 70 eV): m/z 426 (M+).
4-(2-(4-(2-Phenylthiazol-4-yl)phenyl)thiazol-4-yl)benzonitrile (C5). Yellow powder. m.p. 242 ◦C. IR (KBr)
ν
cm−1: 3110 (C-H thiazole str), 3061 (C-H str arom), 2225 (str CN), 1605, 1575, 1503, 1448 (Ar ring
max
1
str), 980 (C-H bend arom), 844 (C-H def arom). H-NMR (DMSO-d6, ppm):
δ 8.55 (s, 1H, H-thiazole),
8.45 (dd, 2H, Ph-CN), 8.30 (s, 1H, H-thiazole), 8.25 (m, 2H, Ph2), 8.15 (m, 2H, Ph2), 7.9 (m, 2H, Ph1),
7.77 (dd, 2H, Ph-CN), 7.50 (m, 3H, Ph1). 13C-NMR (DMSO-d6) δ (ppm): 165.62 (thiazole-1 C2), 157.85
(thiazole-2 C2), 152.91 (thiazole-1 C4), 151.81 (thiazole-2 C4), 128.8 (thiazole-1 C5), 118.6 CN, 119.91
(thiazole-2 C5), 126–130.8 (18C, 3 phenyl rings). Anal. calcd. (%) for C25H15N3S2 (421.07): C, 71.23; H,
3.59; N, 9.97; S, 15.21. Found: C, 71.4; H, 3.64; N, 9.70; S, 15.26. MS (EI, 70 eV): m/z 421 (M+).
◦
4-(Naphthalen-1-yl)-2-(4-(2-phenylthiazol-4-yl)phenyl)thiazole (C6). Off-white powder. m.p. 237 C. IR (KBr)
ν
cm−1: 3109 (C-H thiazole str), 3061 (C-H str arom), 1603, 1571, 1504, 1455 (Ar ring str), 979 (C-H
max
1
bend arom), 839 (C-H def arom). H-NMR (DMSO-d6, ppm):
δ 8.6 (s, 1H, H-thiazole), 8.42 (s, 1H,
H-thiazole), 8.25 (m, 2H, Ar2), 8.15 (m, 2H, Ph2), 8.06–8.03 (m, 2H, naph), 7.9 (m, 2H, Ph1), 7.56–7.53
(m, 4H, naph), 7.45 (m, 3H, Ph1). 13C-NMR (DMSO-d6)
δ
(ppm): 166.32 (thiazole-1 C2), 158.5 (thiazole-2
C2), 152.96 (thiazole-1 C4), 152.1 (thiazole-2 C4), 128.8 (thiazole-1 C5), 120.61 (thiazole-2 C5), 126–140.6
(22 C, 2 phenyl and 1 naphtyl rings). Anal. calcd. (%) for C28H18N2S2 (446.09): C, 75.30; H, 4.06; N, 6.27;
S, 14.36. Found: C, 75.26; H, 4.18; N, 6.31; S, 14.25. MS (EI, 70 eV): m/z 446 (M+).
◦
2-Hydroxy-5-{2-[4-(2-phenyl-1,3-thiazol-4-yl)phenyl]-1,3-thiazol-4-yl}benzamide (C7) Light-grey. m.p. 225 C.
IR (KBr)
ν
max
cm−1: 3443 (O-H str phenol), 3326, 3230 (N-H str amide), 3108 (C-H thiazole str),
3059 (C-H str arom), 1666 (C=O str amide), 1619 (N-H bend amide), 1601, 1505, 1447 (Ar ring str),
1
983 (C-H bend arom), 840 (C-H def arom). H-NMR (DMSO-d6, ppm):
δ 13.2 (s, 1H, OH), 8.63 (s, 1H,
H-thiazole), 8.56 (d, 1H, Ph3), 8.35 (s, 1H, H-thiazole), 8.23 (m, 2H, Ph2), 8.18 (m, 2H, Ph2), 8.13 (m, 1H,
Ph3), 8.06 (m, 2H, Ph1), 8.02 (s, 2H, CONH2), 7.55 (m, 3H, Ph1), 7.02 (d, 1H, Ph3). 13C-NMR (DMSO-d6)
δ
(ppm): 167.66 (amide C=O), 166.32 (thiazole-1 C2), 158.5 (thiazole-2 C2), 152.96 (thiazole-1 C4),
152.1 (thiazole-2 C4), 129.8 (thiazole-1 C5), 120.41 (thiazole-2 C5), 126-159.6 (18 C, 3 phenyl rings).
Anal. calcd. (%) for C25H17N3O2S2 (455.08): C, 65.91; H, 3.76; N, 9.22; S, 14.08. Found: C, 65.8; H, 3.6;
N, 9.3; S, 14.4. MS (EI, 70 eV): m/z 455 (M+).
◦
4-(4-Chlorophenyl)-2-(4-(2-phenylthiazol-4-yl)phenyl)thiazole (C8) Off-white powder. m.p. 232 C. IR (KBr)
ν
cm−1: 3111 (C-H thiazole str), 3059 (C-H str arom), 1597, 1572, 1503, 1462 (Ar ring str),
max
981 (C-H bend arom), 843 (C-H def arom), 826 (C-Cl str). 1H-NMR (DMSO-d6, ppm):
(s, 1H, H-thiazole), 8.35 (s, 1H, H-thiazole), 8.30 (m, 2H, Ph2), 8.20 (m, 2H, Ph2), 7.9 (m, 2H, Ph1),
7.60 (dd, 2H, Ph-Cl), 7.55 (dd, 2H, Ph-Cl), 7.45 (m, 3H, Ph1). 13C-NMR (DMSO-d6)
(ppm): 165.32
δ 8.56
δ

Molecules 2017, 22, 1827
14 of 18
(thiazole-1 C2), 159.5 (thiazole-2 C2), 151.96 (thiazole-1 C4), 151.1 (thiazole-2 C4), 128.38 (thiazole-1
C5), 120.81 (thiazole-2 C5), 126–132.89 (18 C, 3 phenyl rings). Anal. calcd. (%) for C24H15 ClN2S2
(430.04): C, 66.89; H, 3.51; N, 6.50; S, 14.88. Found: C, 66.80; H, 3.55; N, 6.52; S, 14.91. MS (EI, 70 eV):
m/z 430 (M+).
3.3. Biological Assays
The antimicrobial activity assessment was performed using 3 different methods: an initial qualitative
screening, a quantitative assay and also an assessment of the antibiofilm activity that aims at determining
the antipathogenic potential. The quantitative assays were performed only for the compounds that
showed a promising activity in the initial qualitative screening.
The antibiofilm activity was assessed for all compounds due to the fact that the mechanisms for
antibiofilm activity can be different and independent from those involved in bactericidal activity.
3.3.1. Antimicrobial Activity—Initial In Vitro Qualitative Screening Study
The antimicrobial activity of the synthesized compounds was assayed on Gram-negative
bacteria (Escherichia coli ATCC 8739, Pseudomonas aeruginosa ATCC 27853) and Gram-positive bacteria
(Enterococcus faecalis ATCC 29212, Staphylococcus aureus ATCC 6538, Staphylococcus aureus BAA 1026,
Staphylococcus saprophyticus ATCC 15305, Bacillus subtilis ATCC 6633). Microbial suspensions of
1.5
×
108 CFU mL−1 (0.5 McFarland density) obtained from 15 to 18 h bacterial cultures developed
on solid media were used. The antimicrobial activity was tested on Mueller–Hinton Agar (MHA)
medium. The analyzed compounds and the reference substance, ciprofloxacin, were solubilized in
DMSO. The starting stock solution was of 10 mg/mL concentration. The qualitative screening was
performed by an adapted disc diffusion method as previously reported [36]. The inoculated plates were
incubated for 24 h at 37 ◦C for bacterial strains. Growth inhibition zones diameters were measured
(mm) as an assessment of antimicrobial activity.
3.3.2. Antimicrobial Activity—In Vitro Quantitative Assay
The quantitative assay of the antimicrobial activity was performed by liquid medium
microdilution method in 96 multi-well plates. Two-fold serial dilutions of the compounds solutions
(ranging between 1000
well seeded with 50 L microbial inoculum. Reference antimicrobial agents were used as standard
µg and 2 µ µL volume of broth, and each was
g mL−1) were performed in a 200
µ
(ciprofloxacin). Culture positive controls (wells containing culture medium seeded with the microbial
inoculum) were used. The influence of the DMSO solvent was also quantified in a series of wells
containing DMSO, diluted accordingly with the dilution scheme. The plates were incubated for 24 h
at 37 ◦C for bacterial strains. The minimal inhibitory concentration (MIC) values were considered as
the lowest concentration of the tested compound that inhibited the growth of the microbial cultures,
as compared to the positive control, revealed by a decreased value of absorbance at 600 nm (Apollo LB
911 ELISA Absorbance Reader, Berthold Technologies, Bad Wildbad, Germany) [28,29,37].
3.3.3. Anti-Biofilm Activity Assay
For the evaluation of the influence of the tested compounds on the ability of the tested bacterial
strains to colonize the inert substratum, a microtiter plate method was used. The microplates used for
the MIC assay were emptied and washed three times by phosphate buffered saline. The biofilm formed
on the plastic wells wall was fixed for 5 min with cold methanol, coloured for 15 min by violet crystal
solution and resuspended with a 33% acetic acid solution. Cell density was measured by reading the
optical density of the coloured solution at 490 nm. The minimal biofilm eradication concentration
(MBEC) values were considered as the lowest concentration of the tested compound that inhibited the
development of biofilm on the plate wells [37].

Molecules 2017, 22, 1827
15 of 18
3.4. Molecular Docking Study
In order to understand the mechanism of action of the synthesized 2-phenylthiazole compounds
a molecular docking study was performed using AutoDock 4.2 [38]. Our compounds were tested
against Sortase A from E. faecalis and Sortase A from S. aureus, to evaluate the binding affinity and
possible interactions with the two proteins. Dataset of the 3D compounds was designed using
HyperChem 6, with geometry optimization and minimized energy conformation. Further, all ligand
input files preparation was performed using AutoDock Tools 1.5.6 [38]. Ligand preparation included
addition of Gasteiger charges and merging non-polar hydrogen atoms. For each ligand AutoDock
searched for 50 conformers. 9
mutation, 0.8 rate of crossover and 2 Å step size for translations.
×
104 was set as the maximum number of evaluation, 0.02 rate of
´
The three dimensional structure of Sortase A from E. faecalis ATCC 29212 was built by homology
modeling using Swiss-Model service, based on its 224 amino acids sequence (DR75_168) taken from
KEGG (Kyoto Encyclopedia of Genes and Genomes) and PDB 3TBE as template. The obtained three
dimensional structure was checked with ProSA [39,40], in order to search potential errors in prediction
of the structure of the modelled protein. Numbering of amino acids in the resulted structure was left
as given, first amino acid in structure EfSRT_29212 being Pro79 and the last one Tyr234. The three
dimensional structure of S. aureus Sortase A used was PDB 1IJA.
Using AutoDock Tools, proteins were prepared for docking: addition of polar hydrogen atoms,
deprotonation of carboxylic moieties and assignation of Gasteiger partial charges. Grid boxes size
´
was defined as x = y = z = 74 Å in dimension for both enzymes. Center coordinates of the cubic
search space in Sortase A docking was centered to x = 21.385, y = 1.318, z =
−
3.296 in E. faecalis and
x = −1.244, y = 3.910, z = 4.892 in S. aureus. Cartesian parameters for search space were chosen in order
to include the amino acids from the catalytic site of the enzymes inside. Catalytic triad is composed
by His153, Cys215 and Arg224 in E. faecalis Sortase A, respectively His62, Cys126 and Arg139 for
S. aureus Sortase A. Catalytic sites were identified using BLASTP 2.6.1 [41]. A sequence comparison and
alignment was performed, in order to evaluate supplementary the two studied enzymes: PDB 1IJA and
EfSRT_29212. Sequence alignment of the proteins was performed using EMBOSS Stretcher 6.0, based on
EBLOSUM62, with pairing output format. Analyses of binding sites of sortases A were performed
using DoGSiteScorer [42]. Ramachandran plot was generated by RAMPAGE [43]. Visualization and
analysis of the docking results were performed using PyMol and UCSF Chimera [44].
4. Conclusions
Starting from the general scaffold of sortase inhibitors obtained from the literature review [25
]
we synthesized and characterized eight compounds containing a phenylthiazole within a pentacyclic
system. All physicochemical parameters and analysis confirmed the identity of the structures.
The antimicrobial activity assays performed showed that the compounds have a weak
antimicrobial effect and as such do not markedly impact bacterial cell viability. This mild antimicrobial
effect is however focused against Gram-Positive bacteria, mainly E. faecalis and S. aureus. These results
are in accordance with the initial goal of obtaining Sortase inhibitors that decrease bacterial virulence
but do not cause selective pressure by bacteriostatic or bactericidal effects.
When considering the anti-biofilm formation activity result showed an excellent activity against
E. faecalis biofilm and a moderate activity against S. aureus. In order to understand this phenomenon
molecular docking studies were performed against Sortase A from the 2 bacterial species. Results from
the in silico binding prediction correlate with the in vitro anti-biofilm assays. As such, we obtained
a series of new compounds capable of disturbing biofilm formation especially in the case of E. faecalis.
This selectivity can be explained by the differences between active site conformations of the sortases
from the 2 bacterial strains. Most of the compounds act as a non-competitive inhibitor of the E. faecalis
sortase by binding to the active site and creating a steric hindrance, with little or no interaction with the
catalytic residues. This binding is not favoured in the case of S. aureus Sortase A, which has a narrower

Molecules 2017, 22, 1827
16 of 18
active site that cannot accommodate our inhibitors. The importance of inhibiting Sortase A in order
to inhibit biofilm formation in E. faecalis has been previously reported [10,11] and is confirmed by
our findings.
Obtaining compounds active against E. faecalis is of major interest as most sortase inhibitors
obtained so far focused on S. aureus. E. faecalis is a microorganism associated with endodontic
infections [45], chronic periradicular lesions, endocarditis [13], nosocomial infections and potentially
even colorectal neoplasm [12]. Multidrug-Resistant E. faecalis infections are very common [
2,14] and
are enabled by the biofilm formation properties of these bacteria [10 15]. In these circumstances
,
the need for novel therapies is stringent and the use of anti-biofilm agents to decrease virulence,
in a combination with known antibacterial agents, could become a feasible strategy.
Acknowledgments: This project was financially supported by the “Iuliu Hatieganu” University of Medicine and
Pharmacy Cluj–Napoca, Romania through the internal research grant no. 4944/18/08.03.2016.
Author Contributions: O.O. and M.D.P. supervised the experiments and assured the high quality of the scientific
content. S.D.O., I.L. and C.A. were involved in the synthesis, isolation, purification and physic-chemical
characterization of compounds; A.P. performed the NMR spectral analysis; G.M. and C.I.S. performed the
molecular docking. M.P., M.C.C. and T.D. performed the biological assay. C.A. wrote the paper.
Conflicts of Interest: The authors declare no conflict of interest.
References
1.
World Health Organisation. Global Priority List of Antibiotic-Resistant Bacteria to Guide Research, Discovery,
and Development of New Antibiotics. Available online: http://www.who.int/medicines/publications/
global-priority-list-antibiotic-resistant-bacteria/en/ (accessed on 15 August 2017).
Laxminarayan, R.; Duse, A.; Wattal, C.; Zaidi, A.K.M.; Wertheim, H.F.L.; Sumpradit, N.; Vlieghe, E.; Hara, G.L.;
Gould, I.M.; Goossens, H.; et al. Antibiotic resistance-the need for global solutions. Lancet Infect. Dis. 2013, 13,
1057–1098. [CrossRef]
2.
3.
4.
5.
6.
7.
Rice, L.B. Antimicrobial resistance in gram-positive bacteria. Am. J. Infect. Control 2006, 34, 11–19. [CrossRef]
[PubMed]
Schneewind, O.; Fowler, A.; Faull, K.F. Structure of the cell wall anchor of surface proteins in Staphylococcus
aureus. Science 1995, 268, 103–106. [CrossRef] [PubMed]
Schneewind, O.; Missiakas, D. Sec-secretion and sortase-mediated anchoring of proteins in Gram-positive
bacteria. Biochim. Biophys. Acta Mol. Cell Res. 2014, 1843, 1687–1697. [CrossRef] [PubMed]
Spirig, T.; Weiner, E.M.; Clubb, R.T. Sortase enzymes in Gram-positive bacteria. Mol. Microbiol. 2011, 82,
1044–1059. [CrossRef] [PubMed]
Tsompanidou, E.; Denham, E.L.; Sibbald, M.J.J.B.; Yang, X.; Seinen, J.; Friedrich, A.W.; Buist, G.; Van Dijl, J.M.
The Sortase A Substrates FnbpA, FnbpB, ClfA and ClfB Antagonize Colony Spreading of Staphylococcus
aureus. PLoS ONE 2012, 7, 1–7. [CrossRef] [PubMed]
8.
9.
O’Neill, E.; Pozzi, C.; Houston, P.; Humphreys, H.; Robinson, D.A.; Loughman, A.; Foster, T.J.; O’Gara, J.P. A
novel Staphylococcus aureus biofilm phenotype mediated by the fibronectin-binding proteins, FnBPA and
FnBPB. J. Bacteriol. 2008, 190, 3835–3850. [CrossRef] [PubMed]
McCarthy, H.; Rudkin, J.K.; Black, N.S.; Gallagher, L.; O’Neill, E.; O’Gara, J.P. Methicillin resistance and the
biofilm phenotype in Staphylococcus aureus. Front. Cell. Infect. Microbiol. 2015, 5, 1. [CrossRef] [PubMed]
10. Dunny, G.; Hancock, L.; Shankar, N. Enterococcal Biofilm Structure and Role in Colonization and Disease.
In Enterococci: from Commensals to Leading Causes of Drug Resistant Infection; Gilmore, M., Clewell, D.,
Ike, Y., Eds.; Massachusetts Eye and Ear Infirmary: Boston, MA, USA, 2014.
11. Guiton, P.S.; Hung, C.S.; Kline, K.A.; Roth, R.; Kau, A.L.; Hayes, E.; Heuser, J.; Dodson, K.W.; Caparon, M.G.;
Hultgren, S.J. Contribution of autolysin and sortase A during Enterococcus faecalis DNA-dependent biofilm
development. Infect. Immun. 2009, 77, 3626–3638. [CrossRef] [PubMed]
12. Pericàs, J.M.; Corredoira, J.; Moreno, A.; García-País, M.J.; Falces, C.; Rabuñal, R.; Mestres, C.A.; Alonso, M.P.;
Marco, F.; Quintana, E.; et al. Relationship Between Enterococcus faecalis Infective Endocarditis and
Colorectal Neoplasm: Preliminary Results From a Cohort n Rabun. Rev. Española Cardiol. 2017. [CrossRef]

Molecules 2017, 22, 1827
17 of 18
13. Nallapareddy, S.R.; Singh, K.V.; Sillanpää, J.; Garsin, D.A.; Höök, M.; Erlandsen, S.L.; Murray, B.E.
Endocarditis and biofilm-associated pili of Enterococcus faecalis. J. Clin. Investig. 2006, 116, 2799–2807.
[CrossRef] [PubMed]
14. Van Harten, R.M.; Willems, R.J.L.; Martin, N.I.; Hendrickx, A.P.A. Multidrug-Resistant Enterococcal
Infections: New Compounds, Novel Antimicrobial Therapies? Trends Microbiol. 2017, 25, 467–479. [CrossRef]
[PubMed]
15. Holmberg, A.; Rasmussen, M. Mature biofilms of Enterococcus faecalis and Enterococcus faecium are highly
resistant to antibiotics. Diagn. Microbiol. Infect. Dis. 2016, 84, 19–21. [CrossRef] [PubMed]
16. Cascioferro, S.; Totsika, M.; Schillaci, D. Sortase A: An ideal target for anti-virulence drug development.
Microb. Pathog. 2014, 77, 105–112. [CrossRef] [PubMed]
17. Si, L.; Li, P.; Liu, X.; Luo, L. Chinese herb medicine against Sortase A catalyzed transformations, a key role
in gram-positive bacterial infection progress. J. Enzym. Inhib. Med. Chem. 2016, 31, 184–196. [CrossRef]
[PubMed]
18. He, W.; Zhang, Y.; Bao, J.; Deng, X.; Batara, J.; Casey, S.; Guo, Q.; Jiang, F.; Fu, L. Synthesis, biological
evaluation and molecular docking analysis of 2-phenyl-benzofuran-3-carboxamide derivatives as potential
inhibitors of Staphylococcus aureus Sortase A. Bioorg. Med. Chem. 2017, 25, 1341–1351. [CrossRef] [PubMed]
19. Zhang, Y.; Bao, J.; Deng, X.-X.; He, W.; Fan, J.-J.; Jiang, F.-Q.; Fu, L. Synthesis, biological evaluation and
molecular docking of 2-phenyl-benzo[d]oxazole-7-carboxamide derivatives as potential Staphylococcus
aureus Sortase A inhibitors. Bioorg. Med. Chem. Lett. 2016, 26, 4081–4085. [CrossRef] [PubMed]
20. Maggio, B.; Raffa, D.; Raimondi, M.V.; Cascioferro, S.; Plescia, F.; Schillaci, D.; Cusimano, M.G.; Leonchiks, A.;
Zhulenkovs, D.; Basile, L.; et al. Discovery of a new class of sortase a transpeptidase inhibitors to tackle
gram-positive pathogens: 2-(2-phenylhydrazinylidene)alkanoic acids and related derivatives. Molecules
2016, 21, 241. [CrossRef] [PubMed]
21. Zhulenkovs, D.; Rudevica, Z.; Jaudzems, K.; Turks, M.; Leonchiks, A. Discovery and structure-activity
relationship studies of irreversible benzisothiazolinone-based inhibitors against Staphylococcus aureus
sortase A transpeptidase. Bioorg. Med. Chem. 2014, 22, 5988–6003. [CrossRef] [PubMed]
22. Raj, K.K.; Ganesh Kumar, V.; Leela Madhuri, C.; Pardhasaradhi, M.; Durga Lakshmi, R.; Ravi, M.;
Sri Ramudu, B.; Venkata Rao, S.V.; Ramachandran, D. Designing of potential inhibitors against
Staphylococcus aureus sortase A: Combined analogue and structure based approach with in vitro validation.
J. Mol. Graph. Model. 2015, 60, 89–97. [CrossRef] [PubMed]
23. Uddin, R.; Lodhi, M.U.; Ul-Haq, Z. Combined Pharmacophore and 3D-QSAR Study on A Series of
Staphylococcus aureus Sortase A inhibitors. Chem. Biol. Drug Des. 2012, 80, 300–314. [CrossRef] [PubMed]
24. Zhang, J.; Liu, H.; Zhu, K.; Gong, S.; Dramsi, S.; Wang, Y.-T.; Li, J.; Chen, F.; Zhang, R.; Zhou, L.; et al.
Antiinfective therapy with a small molecule inhibitor of Staphylococcus aureus sortase. Proc. Natl. Acad.
Sci. USA 2014, 111, 13517–13522. [CrossRef] [PubMed]
25. Nitulescu, G.; Zanfirescu, A.; Olaru, O.T.; Nicorescu, I.M.; Nitulescu, G.M.; Margina, D. Structural analysis
of sortase A inhibitors. Molecules 2016, 21. [CrossRef] [PubMed]
26. Cascioferro, S.; Raffa, D.; Maggio, B.; Raimondi, M.V.; Schillaci, D.; Daidone, G. Sortase A Inhibitors: Recent
Advances and Future Perspectives. J. Med. Chem. 2015, 58, 9108–9123. [CrossRef] [PubMed]
27. Gao, C.; Uzelac, I.; Gottfries, J.; Eriksson, L.A. Exploration of multiple Sortase A protein conformations in
virtual screening. Sci. Rep. 2016, 6, 20413. [CrossRef] [PubMed]
28. Araniciu, C.; Maru¸tescu, L.; Oniga, S.; Oniga, O.; Chifiriuc, M.C.; Palage, M. Evaluation of the antimicrobial
and anti-biofilm activity of some 4,2 and 5,2 bisthiazoles derivatives. Dig. J. Nanomater. Biostruct. 2014
9, 123–131.
,
29. Araniciu, C.; Oniga, S.; Oniga, O.; Palage, M.; Chifiriuc, M.-C.; Marutescu, L. Antimicrobial and
Anti-Pathogenic Activity Evaluation of Some 2-(Trimethoxyphenyl)-4-Ar 1-5-R 2-Thiazoles. Farmacia 2015
,
63, 40–45.
30. Oniga, S.; Duma, S.; Oniga, O.; Tiperciuc, B.; Pirnau, A.; Araniciu, C.; Palage, M. Synthesis of some new
4-methyl-2-(4-pyridyl)-thiazole-5-yl-azoles as potential antimicrobial agents. Farmacia 2015, 63, 171–178.
31. Oniga, S.; Araniciu, C.; Palage, M.; Stoica, C.; Chifiriuc, M.C.; Marutescu, L. Synthesis and bioevaluation of
the antimicrobial features of some new thiazolyl-Azoles. Rev. Chim. 2016, 67, 426–429.
32. Nitulescu, G.; Olaru, O.; Nitulescu, G.M.; Ungurianu, A.; Margina, D. Toxicity assessment of sortases
inhibitors. Toxicol. Lett. 2016, 258, S75. [CrossRef]

Molecules 2017, 22, 1827
18 of 18
33. Suree, N.; Yi, S.W.; Thieu, W.; Marohn, M.; Damoiseaux, R.; Chan, A.; Jung, M.E.; Clubb, R.T. Discovery and
structure-activity relationship analysis of Staphylococcus aureus sortase A inhibitors. Bioorg. Med. Chem.
2009, 17, 7174–7185. [CrossRef] [PubMed]
34. Dramsi, S.; Trieu-Cuot, P.; Bierne, H. Sorting sortases: A nomenclature proposal for the various sortases of
Gram-positive bacteria. Res. Microbiol. 2005, 156, 289–297. [CrossRef] [PubMed]
35. Okamiya, J. The Preparation and the Rates of the Reaction of Heterocyclic (Thiophen and Thiazole)
Bromoketones with Thioamides. Nippon Kagaku Zasshi 1966, 87, 594–600. [CrossRef]
36. Balaure, P.C.; Andronescu, E.; Grumezescu, A.M.; Ficai, A.; Huang, K.S.; Yang, C.H.; Chifiriuc, C.M.; Lin, Y.S.
Fabrication, characterization and in vitro profile based interaction with eukaryotic and prokaryotic cells of
alginate-chitosan-silica biocomposite. Int. J. Pharm. 2013, 441, 555–561. [CrossRef] [PubMed]
37. Limban, C.; Chifiriuc, M.C. Antibacterial activity of new dibenzoxepinone oximes with fluorine and
trifluoromethyl group substituents. Int. J. Mol. Sci. 2011, 12, 6432–6444. [CrossRef] [PubMed]
38. Morris, G.M.; Huey, R.; Lindstrom, W.; Sanner, M.F.; Belew, R.K.; Goodsell, D.S.; Olson, A.J. AutoDock4
and AutoDockTools4: Automated Docking with Selective Receptor Flexibility. J. Comput. Chem. 2009, 30,
2785–2791. [CrossRef] [PubMed]
39. Wiederstein, M.; Sippl, M.J. ProSA-web: Interactive web service for the recognition of errors in
three-dimensional structures of proteins. Nucleic Acids Res. 2007, 35, W407–W410. [CrossRef] [PubMed]
40. Sippl, M.J. Recognition of errors in three-dimensional structures of proteins. Proteins Struct. Funct. Genet.
1993, 17, 355–362. [CrossRef] [PubMed]
41. Altschul, S.F.; Madden, T.L.; Schaffer, A.A.; Zhang, J.; Zhang, Z.; Miller, W.; Lipman, D.J. Gapped BLAST and
PSI-BLAST: A new generation of protein database search programs. Nucleic Acids Res. 1997, 25, 3389–3402.
[CrossRef] [PubMed]
42. Volkamer, A.; Kuhn, D.; Grombacher, T.; Rippmann, F.; Rarey, M. Combining Global and Local Measures for
Structure-Based Druggability Predictions. J. Chem. Inf. Model. 2012, 52, 360–372. [CrossRef] [PubMed]
43. Lovell, S.C.; Davis, I.W.; Arendall, W.B.; De Bakker, P.I.W.; Word, J.M.; Prisant, M.G.; Richardson, J.S.;
Richardson, D.C. Structure validation by Cα geometry: φ, ψ and Cβ deviation. Proteins Struct. Funct.
Bioinform. 2003, 50, 437–450. [CrossRef] [PubMed]
44. Pettersen, E.F.; Goddard, T.D.; Huang, C.C.; Couch, G.S.; Greenblatt, D.M.; Meng, E.C.; Ferrin, T.E. UCSF
Chimera—A visualization system for exploratory research and analysis. J. Comput. Chem. 2004, 25, 1605–1612.
[CrossRef] [PubMed]
45. Jain, H.; Mulay, S.; Mullany, P. Persistence of endodontic infection and Enterococcus faecalis: Role of
horizontal gene transfer. Gene Rep. 2016, 5, 112–116. [CrossRef]
Sample Availability: Samples of all the compounds are available from the authors.
©
2017 by the authors. Licensee MDPI, Basel, Switzerland. This article is an open access
article distributed under the terms and conditions of the Creative Commons Attribution
(CC BY) license (http://creativecommons.org/licenses/by/4.0/).
