A convenient synthesis of 9H-thioxanthen-9-ones and their aza-analogues

Article abstract of DOI:10.3987/COM-13-12855

An efficient method for the preparation of 9H-thioxanthen-9-ones and their three aza-analogues has been developed. The reaction of (2-fluorophenyl)(2- halophenyl)methanones, derived from 1-bromo-2-fluorobenzenes and 2- halobenzaldehydes by an easy two-step sequence, with Na₂S· 9H₂O in DMF at 60 °C gives 9H-thioxanthen-9-ones. This procedure can be applied to the synthesis of 5H-[1]benzothiopyrano[2,3-b](or [2,3-c])pyridin-5-ones or 10H-[1]-benzothiopyrano[3,2-c]pyridin-10-ones starting from 2-, 3- or 4-chloropyridines, respectively.

Full text of DOI:10.3987/COM-13-12855

HETEROCYCLES, Vol. 87, No. 12, 2013
2577
HETEROCYCLES, Vol. 87, No. 12, 2013, pp. 2577 - 2587. © 2013ꢀ The Japan Institute of Heterocyclic Chemistry
Received, 8th October, 2013, Accepted, 30th October, 2013, Published online, 6th November, 2013
DOI: 10.3987/COM-13-12855
A CONVENIENT SYNTHESIS OF 9H-THIOXANTHEN-9-ONES AND
THEIR AZA-ANALOGUES
Kazuhiro Kobayashi,* Toshihide Komatsu, Kazuhiro Nakagawa, Erika Hara,
and Shohei Yuba
Division of Applied Chemistry, Department of Chemistry and Biotechnology,
Graduate School of Engineering, Tottori University, 4-101 Koyama-minami,
Tottori 680-8552, Japan; E-mail: kkoba@chem.tottori-u.ac.jp
Abstract – An efficient method for the preparation of 9H-thioxanthen-9-ones and
their three aza-analogues has been developed. The reaction of (2-fluorophenyl)(2-
halophenyl)methanones, derived from 1-bromo-2-fluorobenzenes and 2-
halobenzaldehydes by an easy two-step sequence, with Na2S·9H2O in DMF at 60
˚C gives 9H-thioxanthen-9-ones. This procedure can be applied to the synthesis of
5H-[1]benzothiopyrano[2,3-b](or
[2,3-c])pyridin-5-ones
or
10H-[1]-
benzothiopyrano[3,2-c]pyridin-10-ones starting from 2-, 3- or 4-chloropyridines,
respectively.
INTRODUCTION
A literature survey of the utility of 9H-thioxanthen-9-one derivatives indicated that a number of
compounds having this skeleton exhibit a variety of biological activities,1 and that some compounds are
useful for photosensitive materials.2 While 9H-thioxanthen-9-ones have been commonly prepared by the
intramolecular Friedel-Crafts acylation of 2-(arylsulfanyl)benzoic acids under harsh conditions,2,3 few
other general methods have been developed. We envisioned that the reaction of (2-fluorophenyl)(2-
halophenyl)methanones, which have been easily prepared from 1-bromo-2-fluorobenzenes and
2-halobenzaldehydes and used for the preparation of 10-substituted acridin-9(10H)-ones,4 with
Na2S·9H2O under mild conditions would provide 9H-thioxanthen-9-ones.5 In this paper, we wish to
describe the results of our investigation, which show that 9H-thioxanthen-9-ones (2) can be prepared by
the reaction of (2-fluorophenyl)(2-halophenyl)methanones (1) with Na2S·9H2O in DMF at 60 °C.
We also report that this method is applicable to the synthesis of three types of their aza-analogues,

2578
HETEROCYCLES, Vol. 87, No. 12, 2013
5H-[1]benzothiopyrano[2,3-b](or [2,3-c])pyridin-5-ones (6) (or 10) or 10H-[1]benzothiopyrano[3,2-c]-
pyridin-10-ones (14). These [1]benzothiopyranopyridinone derivatives are also of biological,6 material
scientific,7 and synthetic interests.8
RESULTS AND DISCUSSION
The precursor (2-fluorophenyl)(2-halophenyl)methanones (1) were prepared by the reaction of
1-fluoro-2-lithiobenzenes, generated from 1-bromo-2-fluorobenzenes according to the previously
reported method,9 with 2-halobenzaldehydes, followed by the PCC oxidation of the resulting alcohols, as
described previously.4 When these compounds (1) were treated with Na2S·9H2O in DMF at 60 °C,
substitution of the two halogens with the sulfur atom proceeded smoothly and cleanly to afford, after
addition of water followed by recrystallization of the precipitated crude products, the corresponding
9H-thioxanthen-9-ones (2) in good to excellent yields, as shown in Scheme 1.
O
O
R1
R2
R3
R4
R1
R2
R3
R4
Na2S 9H2O, DMF, 60 ˚C
S
a R1 = R2 = R3 = R4 = H, X = Cl
b R1 = R2 = R4 = H, R3 = Cl, X = Br
c R1 = R3 = R4 = H, R2 = X = Cl,
X
F
2a 94%
2b 95%
2c 93%
2d 80%
2e 77%
1
d R1 = H, R2 = Cl, R3 = R4 = OMe, X = Br
e R1 = Cl, R2 = H, R3 = R4 = OMe, X = Br
Scheme 1
Encouraged by the above results we applied this method to the synthesis of three aza-analogues of
9H-thioxanthen-9-ones, 5H-[1]benzothiopyrano[2,3-b](or [2,3-c])pyridin-5-ones (6) (or 10) or 10H-[1]-
benzothiopyrano[3,2-c]pyridine-10-ones (14) from 2-, 3- or 4-chloropyridines (3, 7, or 11), respectively.
We first conducted the synthesis of 5H-[1]benzothiopyrano[2,3-b]pyridin-5-ones (6) as illustrated in
Scheme 2. Thus, commercially available 2-chloropyridine (3) was treated with LDA in THF at –78 °C
according to the reported procedure10 to generate 2-chloro-3-lithiopyridine, which was allowed to react
with 2-halobenzaldehydes to give (2-chloropyridin-3-yl)(2-halophenyl)methanols (4) in fair to good
yields. The lower yield of 4c is likely due to the steric encumbrance of the two adjacent chloro groups.
Then, these alcohols were oxidized with PCC in CH2Cl2 at room temperature to give (2-
chloropyridin-3-yl)(2-halophenyl)methanones (5) in satisfactory yields. The final step, treatment of 5
with Na2S·9H2O, was carried out applying the same conditions described above to afford the desired
products (6) in excellent yields.

HETEROCYCLES, Vol. 87, No. 12, 2013
2579
Next, the synthesis of 5H-[1]benzothiopyrano[2,3-c]pyridin-5-ones (10) from commercially available
3-chloropyridine (7) was similarly carried out under the same conditions, as depicted in Scheme 3. The
precursor (3-chloropyridin-4-yl)(2-halophenyl)methanones (9) were also prepared in good yields from 7,
via the corresponding alcohols (8), by the same sequence used for the preparation of 5. However, when
compounds (9) were treated with Na2S·9H2O in the same way as described above, the expected products
(10) were obtained in somewhat diminished yields compared to those of 6 as summarized in Scheme 3 as
well. These disappointing results are presumably due to the low reactivity of the 3-chloro substituent of
the pyridine ring of 9 compared to the 2-chloro substituent of the pyridine ring of 5.
O
OH
R2
R2
1. LDA, THF, –78 ˚C
PCC, CH2Cl2, rt
R2
OHC
N
Cl
N
N
Cl
X
2.
, –78 ˚C
Cl
X
R1
R1
X
3
4a 75%
4b 71%
4c 59%
5a 70%
5b 87%
5c 75%
R1
a X = Cl, R1 = R2 = H
b X = Br, R1 = H, R2 = OMe
c X = R1 = Cl, R2 =H
O
S
R2
Na2S 9H2O, DMF, 60 ˚C
6a 88%
N
6b 94%
6c 99%
R1
Scheme 2
OH
O
R
R
1. LDA, THF, –78 ˚C
PCC, CH2Cl2, rt
N
N
N
Cl
R
OHC
X
X
Cl
Cl
X
2.
, –78 ˚C
7
8a 82%
8b 78%
8c 78%
9a 79%
9b 83%
9c 75%
a R = H, X = Cl
b R = Cl, X = Br
c R = OMe, X = Br
O
S
R
10a 62%
10b 63%
10c 57%
Na2S 9H2O, DMF, 60 ˚C
N
Scheme 3
Finally, the preparation of 10H-[1]benzothiopyrano[3,2-c]pyridin-10-ones (14) was also similarly
achieved as illustrated in Scheme 4. The reaction of 3-chloro-4-lithiopyridine,10 generated from
4-chloropyridine (11), with 2-halobenzaldehydes to furnish the corresponding alcohols (12) in good
yields, the PCC oxidation of which gave (4-chloropyridin-3-yl)(2-halophenyl)methanones (13). However,

2580
HETEROCYCLES, Vol. 87, No. 12, 2013
these ketones proved to be rather unstable under isolation conditions by SiO2 chromatography. So, these
compounds were not isolated and were subjected, after filtration through a small pad of SiO2, to the
treatment with Na2S·9H2O under the same reaction conditions described above to afford the desired
products (14) in moderate overall yields from 12.
OH
O
R2
R2
PCC, CH2Cl2, rt
1. LDA, THF, –78 ˚C
N
N
N
R2
OHC
Cl
X
Cl
Cl
X
R1
R1
2.
, –78 ˚C
11
X
12a 99%
12b 63%
12c 83%
13
R1
a R1 = R2 = H, X = Cl
b R1 = X = Cl, R2 = H
O
S
c R1 = H, R2 = OMe, X = Br
R2
N
Na2S 9H2O, DMF, 60 ˚C
14a 34%
14b 32%
14c 40%
R1
Scheme 4
In conclusion, we have developed an efficient synthetic approach for the construction of
9H-thioxanthen-9-ones via the reaction of (2-fluorophenyl)(2-halophenyl)methanones with Na2S·9H2O
under mild conditions. Their three aza-analogues were also synthesized starting with the respective
chloropyridines by an application of this sequence.
EXPERIMENTAL
All melting points were obtained on a Laboratory Devices MEL-TEMP II melting apparatus and are
1
uncorrected. IR spectra were recorded with a Perkin–Elmer Spectrum65 FTIR spectrophotometer. H
NMR spectra were recorded in CDCl3 using TMS as an internal reference with a JEOL ECP500 FT NMR
13
spectrometer operating at 500 MHz or JEOL LA400 FT NMR spectrometer operating at 400 MHz. C
NMR spectra were recorded in CDCl3 using TMS as an internal reference with a JEOL ECP500 FT NMR
spectrometer operating at 125 MHz. Low-resolution MS spectra (EI, 70 eV) were measured by a JEOL
JMS AX505 HA spectrometer. High-resolution MS spectra (DART, positive) were measured by a
Thermo Scientific Exactive spectrometer. TLC was carried out on Merck Kieselgel 60 PF254. Column
chromatography was performed using WAKO GEL C-200E. All of the organic solvents used in this study
were dried over appropriate drying agents and distilled prior to use.
Starting Materials. (2-Fluorophenyl)(2-halophenyl)methanones (1a-1d) were prepared as described
previously.4 n-BuLi was supplied by Asia Lithium Corporation. All other chemicals used in this study

HETEROCYCLES, Vol. 87, No. 12, 2013
2581
were commercially available.
(2-Bromo-4,5-dimethoxyphenyl)(5-chloro-2-fluorophenyl)methanone (1e): prepared from 1-bromo-5-
chloro-2-fluorobenzene and 2-bromo-4,5-dimethoxybenzaldehyde, via (2-bromo-4,5-dimethoxyphenyl)-
(5-chloro-2-fluorophenyl)methanol, under the conditions reported for the preparation of 1a-1d.4
(2-Bromo-4,5-dimethoxyphenyl)(5-chloro-2-fluorophenyl)methanol: yield: 62%; a colorless oil; Rf
1
0.20 (AcOEt/hexane 1:5); IR (neat) 3469, 1604 cm–1; H NMR (500 MHz) ! 2.42 (d, J = 3.4 Hz, 1H),
3.85 (s, 3H), 3.88 (s, 3H), 6.32 (d, J = 3.4 Hz, 1H), 7.02 (s, 1H), 7.05 (s, 1H), 7.09–7.12 (m, 2H), 7.20 (dd,
J = 8.6, 8.0 Hz, 1H). Anal. Calcd for C15H13BrClFO3: C, 47.96; H, 3.49. Found: C, 47.81; H, 3.74.
1
1e: yield: 62%; a colorless oil; Rf 0.29 (AcOEt/hexane 1:5); IR (neat) 1669, 1604 cm–1; H NMR (500
MHz) ! 3.88 (s, 3H), 3.94 (s, 3H), 7.01 (s, 1H), 7.05 (s, 1H), 7.15 (dd, J = 9.7, 1.1 Hz, 1H), 7.25 (d, J =
8.0 Hz, 1H), 7.65 (t, J = 8.0 Hz, 1H). Anal. Calcd for C15H11BrClFO3: C, 48.22; H, 2.97. Found: C, 48.34;
H, 2.87.
Typical Procedure for the Preparation of 9H-Thioxanthen-9-ones (2). 9H-Thioxanthen-9-one (2a).11
A mixture of 1a (0.12 g, 0.49 mmol) in DMF (4 mL) containing Na2S·9H2O (0.12 g, 0.49 mmol) was
heated at 60 °C until TLC analyses (SiO2; AcOEt/hexane 1:8) had revealed complete consumption of 1a
(ca. 1 h). The mixture was cooled to rt and H2O (20 mL) was added. The precipitate was collected by
filtration and recrystallized to give 2a (0.10 g, 94%); a white solid; mp 219–221 °C (hexane/CHCl3) (lit.,3
mp 219–220 °C). The spectral (IR and 1H-NMR) data for this compound were identical to those reported
previously.3
2-Chloro-9H-thioxanthen-9-one (2b);12 a white solid; mp 150–151 °C (hexane/CH2Cl2) (lit.,12b mp
150–151.5 °C); IR (KBr) 1635 cm–1; 1H NMR (400 MHz) ! 7.49–7.55 (m, 2H), 7.58–7.61 (m, 2H), 7.65
(ddd, J = 8.3, 6.8, 1.4 Hz, 1H), 8.60 (d, J = 2.4 Hz, 1H), 8.62 (dd, J = 7.3, 1.4 Hz, 1H).
3-Chloro-9H-thioxanthen-9-one (2c): a white solid; mp 171–173 °C (hexane/CH2Cl2) (lit.,13
168–172 °C); IR (KBr) 1645 cm–1; 1H NMR (500 MHz) ! 7.43 (ddd, J = 8.7, 1.8, 0.9 Hz, 1H), 7.50 (td, J
= 7.3, 0.9 Hz, 1H), 7.56–7.58 (m, 2H), 7.64 (dd, J = 8.7, 6.9 Hz, 1H), 8.54 (d, J = 8.7 Hz, 1H), 8.60 (d, J
= 7.3 Hz, 1H).
3-Chloro-6,7-dimethoxy-9H-thioxanthen-9-one (2d); a white solid; mp 218–220 °C (hexane/CH2Cl2).
IR (KBr) 1626 cm–1; 1H NMR (500 MHz) ! 4.01 (s, 3H), 4.02 (s, 3H), 6.92 (s, 1H), 7.42 (dd, J = 8.7, 2.3
Hz, 1H), 7.57 (d, J = 2.3 Hz, 1H), 8.03 (s, 1H), 8.55 (d, J = 8.7 Hz, 1H); 13C NMR ! 56.18, 56.35, 106.54,
110.06, 122.98, 125.00, 126.78, 127.03, 130.66, 131.25, 138.25, 138.37, 148.87, 153.59, 177.85; MS m/z
306 (M+, 100). Anal. Calcd for C15H11ClO3S: C, 58.73; H, 3.61. Found: C, 58.80; H, 3.69.
2-Chloro-6,7-dimethoxy-9H-thioxanthen-9-one (2e): a white solid; mp 218–220 °C (hexane/CH2Cl2).
IR (KBr) 1626 cm–1; 1H NMR (500 MHz) ! 4.015 and 4.022 (2s, combined 6H), 6.93 (s, 1H), 7.43 (dd, J
13
= 8.6, 2.3 Hz, 1H), 7.57 (d, J = 2.3 Hz, 1H), 8.04 (s, 1H), 8.56 (d, J = 8.6 Hz, 1H); C NMR ! 56.22,

2582
HETEROCYCLES, Vol. 87, No. 12, 2013
56.38, 106.54, 110.07, 122.99, 125.03, 126.77, 127.04, 130.66, 131.25, 138.26, 138.37, 148.88, 153.59,
177.86; MS m/z 306 (M+, 100). Anal. Calcd for C15H11ClO3S: C, 58.73; H, 3.61. Found: C, 58.64; H, 3.85.
Typical Procedure for the Preparation of Compounds (4, 8, and 12). (2-Chlorophenyl)(2-
chloropyridin-3-yl)methanol (4a). To a stirred solution of 2-chloro-3-lithiopyridine (10 mmol),
generated according to the reported method,10 in THF (30 mL) at –78 °C was added dropwise
2-ClC6H4CHO (1.7 g, 12 mmol). After 5 min, water (20 mL) was added, and the mixture was extracted
with AcOEt (3 " 20 mL). The combined extracts were washed with brine (10 mL), dried (Na2SO4), and
concentrated by evaporation. The residue was purified by column chromatography on SiO2 to give 4a (1.9
g, 75%); a yellow oil; Rf 0.30 (AcOEt/hexane 1:3); IR (neat) 3345 cm–1; 1H NMR (500 MHz) ! 2.82 (d, J
= 4.1 Hz, 1H), 6.48 (d, J = 4.1 Hz, 1H), 7.26–7.33 (m, 4H), 7.39 (m, 1H), 7.76 (dd, J = 7.8, 1.8 Hz, 1H),
8.34 (dd, J = 4.6, 1.8 Hz, 1H). Anal. Calcd for C12H9Cl2NO: C, 56.72; H, 3.57; N, 5.51. Found: C, 56.70;
H, 3.78; N, 5.70.
(2-Bromo-5-methoxyphenyl)(2-chloropyridin-3-yl)methanol (4b): a white solid; mp 135–137 °C
(hexane/CH2Cl2); IR (KBr) 3185 cm–1; 1H NMR (500 MHz) ! 2.74 (d, J = 4.1 Hz, 1H), 3.77 (s, 3H), 6.37
(d, J = 4.1 Hz, 1H), 6.77 (dd, J = 8.7, 2.8 Hz, 1H), 6.92 (d, J = 2.8 Hz, 1H), 7.25 (dd, J = 7.8, 4.6 Hz, 1H),
7.47 (d, J = 8.7 Hz, 1H), 7.67 (dd, J = 7.8, 1.8 Hz, 1H), 8.35 (dd, J = 4.6, 1.8 Hz, 1H). Anal. Calcd for
C13H11BrClNO2: C, 47.52; H, 3.37; N, 4.26. Found: C, 57.58; H, 3.60; N 4.10.
(2-Chloropyridin-3-yl)(2,3-dichlorophenyl)methanol (4c): a pale-yellow solid; mp 157–158 °C
(hexane/Et2O); IR (KBr) 3213 cm–1; 1H NMR (500 MHz) ! 2.22 (s, 1H), 6.48 (s, 1H), 7.23–7.31 (m, 3H),
7.47 (dd, J = 8.0, 1.7 Hz, 1H), 7.68 (dd, J = 7.4, 1.7 Hz, 1H), 8.36 (dd, J = 4.6, 1.7 Hz, 1H). Anal. Calcd
for C12H8Cl3NO: C, 49.95; H, 2.79; N, 4.85. Found: C, 59.83; H, 2.83; N, 4.71.
(2-Chlorophenyl)(3-chloropyridin-4-yl)methanol (8a): a white solid; mp 140–141 °C (hexane/Et2O);
IR (KBr) 3104 cm–1; 1H NMR (500 MHz) ! 2.75 (d, J = 4.0 Hz, 1H), 6.48 (d, J = 4.0 Hz, 1H), 7.19 (dd, J
= 7.4, 1.7 Hz, 1H), 7.24–7.31 (m, 2H), 7.42 (dd, J = 7.4, 1.7 Hz, 1H), 7.48 (d, J = 5.2 Hz, 1H), 8.53 (d, J
= 5.2 Hz, 1H), 8.55 (s, 1H). Anal. Calcd for C12H9Cl2NO: C, 56.72; H, 3.57; N, 5.51. Found: C, 56.78; H,
3.60; N, 5.32.
(2-Bromo-5-chlorophenyl)(3-chloropyridin-4-yl)methanol (8b): a white solid; mp 164.5–165 °C
(hexane/Et2O); IR (KBr) 3153 cm–1; 1H NMR (500 MHz) ! 2.99 (d, J = 4.0 Hz, 1H), 6.37 (d, J = 4.0 Hz,
1H), 7.20 (dd, J = 8.6, 2.3 Hz, 1H), 7.25 (d, J = 2.3 Hz, 1H), 7.38 (d, J = 5.2 Hz, 1H), 7.53 (d, J = 8.6 Hz,
1H), 8.53 (d, J = 2.3 Hz, 1H), 8.58 (s, 1H). Anal. Calcd for C12H8BrCl2NO: C, 43.28; H, 2.42; N, 4.21.
Found: C, 43.37; H, 2.66; N, 4.08.
(2-Bromo-5-methoxyphenyl)(3-chloropyridin-4-yl)methanol (8c): a white solid; mp 128–129 °C
(hexane/CH2Cl2); IR (KBr) 3186 cm–1; 1H NMR (500 MHz) ! 3.03 (d, J = 4.0 Hz, 1H), 3.74 (s, 3H), 6.37
(d, J = 4.0 Hz, 1H), 6.76–6.78 (m, 2H), 7.41 (d, J = 5.2 Hz, 1H), 7.48 (d, J = 9.2 Hz, 1H), 8.49 (d, J = 5.2

HETEROCYCLES, Vol. 87, No. 12, 2013
2583
Hz, 1H), 8.54 (s, 1H). Anal. Calcd for C13H11BrClNO2: C, 47.52; H, 3.37; N, 4.26. Found: C, 47.37; H,
3.50; N, 4.19.
(2-Chlorophenyl)(4-chloropyridin-2-yl)methanol (12a): a pale-yellow solid; mp 147–149 °C
(hexane/CH2Cl2) (lit.,14 mp 151 °C); IR (KBr) 3089 cm–1; 1H NMR (400 MHz) ! 2.80 (s, 1H), 6.54 (s, 1H),
7.29–7.34 (m, 3H), 7.39–7.43 (m, 2H), 8.45 (d, J = 5.4 Hz, 1H), 8.57 (s, 1H).
(4-Chloropyridin-2-yl)(2,3-dichlorophenyl)methanol (12b): a pale-yellow solid; mp 161–163 °C
(hexane/CH2Cl2); IR (KBr) 3091 cm–1; 1H NMR (400 MHz) ! 2.85 (br, 1H), 6.54 (s, 1H), 7.27 (t, J = 7.8
Hz, 1H), 7.35 (d, J = 4.9 Hz, 1H), 7.41 (d, J = 7.8 Hz, 1H), 7.47 (dd, J = 7.8, 2.0 Hz, 1H), 8.46 (d, J = 4.9
Hz, 1H), 8.49 (s, 1H). Anal. Calcd for C12H8Cl3NO: C, 49.95; H, 2.79; N, 4.85. Found: C, 49.90; H, 2.88;
N, 4.73.
(2-Bromo-5-methoxyphenyl)(4-chloropyridin-2-yl)methanol (12c):
a
pale-yellow solid; mp
162–163 °C (hexane/CH2Cl2); IR (KBr) 3100 cm–1; 1H NMR (500 MHz) ! 2.68 (d, J = 4.6 Hz, 1H), 3.78
(s, 3H), 6.43 (d, J = 4.6 Hz, 1H), 6.78 (dd, J = 8.6, 2.9 Hz, 1H), 7.01 (d, J = 2.9 Hz, 1H), 7.34 (d, J = 5.2
Hz, 1H), 7.46 (d, J = 8.6 Hz, 1H), 8.46 (d, J = 5.2 Hz, 1H), 8.50 (s, 1H). Anal. Calcd for C13H11BrClNO2:
C, 47.52; H, 3.37; N, 4.26. Found: C, 47.40; H, 3.18; N, 4.19.
Aryl(chloropyridinyl)methanones (5, 9, and 13) were prepared by the oxidation of 4, 8, and 12,
respectively, with PCC in CH2Cl2 as described previously.15 For compounds 13, after evaporation of the
solvent the residue was filtered through a small pad of SiO2 using THF as an eluent. The solution was
concentrated under reduced pressure and used in the next step without any other purification.
(2-Chlorophenyl)(2-chloropyridin-3-yl)methanone (5a): a pale-yellow oil; Rf 0.44 (AcOEt/hexane
1:3); IR (neat) 1682 cm–1; 1H NMR (500 MHz) ! 7.37–7.41 (m, 2H), 7.45 (d, J = 7.8 Hz, 1H), 7.50 (ddd,
J = 7.8, 7.3, 1.4 Hz, 1H), 7.60 (dd, J = 7.8, 1.4 Hz, 1H), 7.90 (dd, J = 7.8, 1.8 Hz, 1H), 8.54 (dd, J = 4.6,
1.8 Hz, 1H). Anal. Calcd for C12H7Cl2NO: C, 57.17; H, 2.80; N, 5.56. Found: C, 57.10; H, 2.91; N, 5.46.
(2-Bromo-5-methoxyphenyl)(2-chloropyridin-3-yl)methanone (5b): a pale-yellow oil; Rf 0.33 (AcOEt/
hexane 1:1); IR (neat) 1682 cm–1; 1H NMR (500 MHz) ! 3.83 (s, 3H), 6.95 (dd, J = 8.7, 3.2 Hz, 1H), 7.07
(d, J = 3.2 Hz, 1H), 7.37 (dd, J = 7.8, 4.6 Hz, 1H), 7.51 (d, J = 8.7 Hz, 1H), 7.90 (dd, J = 7.8, 1.8 Hz, 1H),
8.55 (dd, J = 4.6, 1.8 Hz, 1H). Anal. Calcd for C13H9BrClNO2: C, 47.81; H, 2.78; N, 4.29. Found: C,
47.66; H, 2.81; N, 4.25.
(2-Chloropyridin-3-yl)(2,3-dichlorophenyl)methanone (5c): a pale-yellow oil; Rf 0.23 (AcOEt/hexane
1:3); IR (neat) 1687 cm–1; 1H NMR (500 MHz) ! 7.34 (t, J = 8.0 Hz, 1H), 7.40 (dd, J = 8.0, 4.6 Hz, 1H),
7.45 (dd, J = 8.0, 1.7 Hz, 1H), 7.66 (dd, J = 8.0, 1.7 Hz, 1H), 7.94 (dd, J = 8.0, 1.7 Hz, 1H), 8.56 (dd, J =
4.6, 1.7 Hz, 1H). Anal. Calcd for C12H6Cl3NO: C, 50.30; H, 2.11; N, 4.89. Found: C, 50.08; H, 2.39; N,
4.85.
(2-Chlorophenyl)(3-chloropyridin-4-yl)methanone (9a): a pale-yellow oil; Rf 0.29 (AcOEt/hexane

2584
HETEROCYCLES, Vol. 87, No. 12, 2013
1:5); IR (neat) 1687 cm–1; 1H NMR (500 MHz) ! 7.36–7.42 (m, 2H), 7.45–7.51 (m, 2H), 7.59 (dd, J = 7.4,
1.7 Hz, 1H), 8.63 (d, J = 5.2 Hz, 1H), 8.70 (s, 1H). Anal. Calcd for C12H7Cl2NO: C, 57.17; H, 2.80; N,
5.56. Found: C, 57.13; H, 3.01; N, 5.51.
(2-Bromo-5-chlorophenyl)(3-chloropyridin-4-yl)methanone (9b): a colorless oil; Rf 0.31 (AcOEt/
1
hexane 1:5); IR (neat) 1693 cm–1; H NMR (500 MHz) ! 7.38–7.40 (m, 2H), 7.48 (d, J = 2.3 Hz, 1H),
7.59 (d, J = 8.6 Hz, 1H), 8.65 (d, J = 5.2 Hz, 1H), 8.72 (s, 1H). Anal. Calcd for C12H6BrCl2NO: C 43.54;
H, 1.83; N, 4.23. Found: C, 43.47; H, 2.06; N, 4.13.
(2-Bromo-5-methoxyphenyl)(3-chloropyridin-4-yl)methanone (9c):
a
colorless oil; Rf 0.38
(AcOEt/hexane 1:2); IR (neat) 1686 cm–1; 1H NMR (400 MHz) ! 3.83 (s, 3 H), 6.97 (dd, J = 8.8, 2.9 Hz,
1H), 7.06 (d, J = 2.9 Hz, 1H), 7.37 (d, J = 4.9 Hz, 1H), 7.53 (d, J = 8.8 Hz, 1H), 8.62 (d, J = 4.9 Hz, 1H),
8.71 (s, 1H). Anal. Calcd for C13H9BrClNO2: C, 47.81; H, 2.78; N, 4.29. Found: C, 47.63; H, 2.88; N,
4.06.
Typical Procedure for the Preparation of Benzothiopyranopyridinones (6, 10, and 14). 5H-
[1]Benzothiopyrano[2,3-b]pyridin-5-one (6a): A solution of 5a (0.20 g, 0.79 mmol) and Na2S·9H2O
(0.19 g, 0.79 mmol) in DMF (4 mL) was heated at 60 ˚C for 1 h under stirring. After cooling to rt, H2O
(20 mL) was added and the precipitate was collected by filtration. Recrystallization of the crude product
from hexane/CH2Cl2 gave 6a (0.15 g, 88%); a white solid; mp 232–234 °C (lit.,16 mp 234 °C); IR (KBr)
1
1651 cm–1; H NMR (500 MHz) ! 7.46 (dd, J = 7.3, 4.6 Hz, 1H), 7.53 (ddd, J = 7.8, 7.3, 0.9 Hz, 1H),
7.64–7.70 (m, 2H), 8.60 (dd, J = 7.8, 0.9 Hz, 1H), 8.80 (dd, J = 4.6, 1.8 Hz, 1H), 8.84 (dd, J = 7.8, 1.8 Hz,
1H).
7-Methoxy-5H-[1]benzothiopyrano[2,3-b]pyridin-5-one (6b): a yellow solid; mp 182–184 °C (hexane/
CHCl3); IR (KBr) 1634 cm–1; 1H NMR (500 MHz) ! 3.95 (s, 3H), 7.31 (dd, J = 8.7, 2.8 Hz, 1H), 7.44 (dd,
J = 8.2, 4.6 Hz, 1H), 7.56 (d, J = 8.7 Hz, 1H), 8.04 (d, J = 2.8 Hz, 1H), 8.80 (dd, J = 4.6, 1.8 Hz, 1H),
8.85 (dd, J = 8.2, 1.8 Hz, 1H); 13C NMR ! 55.73, 110.49, 121.41, 123.29, 125.71, 127.71, 129.30, 129.95,
137.84, 153.19, 158.72, 158.89, 180.34; MS m/z 243 (M+, 100). Anal. Calcd for C13H9NO2S: C, 64.18; H,
3.73; N, 5.76. Found: C, 64.14; H, 3.73; N, 5.71.
9-Chloro-5H-[1]benzothiopyrano[2,3-b]pyridin-5-one (6c): a pale-yellow solid; mp 194–196 °C
1
(hexane/CH2Cl2); IR (KBr) 1645 cm–1; H NMR (500 MHz) ! 7.47–7.51 (m, 2H), 7.78 (dd, J = 7.4, 1.1
Hz, 1H), 8.56 (dd, J = 8.0, 1.1 Hz, 1H), 8.82 (dd, J = 8.0, 1.7 Hz, 1H), 8.85 (dd, J = 4.6, 1.7 Hz, 1H); 13C
NMR ! 122.09, 125.49, 126.69, 128.42, 130.70, 130.85, 133.36, 136.86, 137.74, 153.67, 158.22, 180.40;
MS m/z 247 (M+, 100). Anal. Calcd for C12H6ClNOS: C, 58.19; H, 2.44; N, 5.65. Found: C, 58.17; H,
2.57; N, 5.50.
5H-[1]Benzothiopyrano[2,3-c]pyridin-5-one (10a):16 a pale-yellow solid; mp 172–172.5 °C (hexane/
CH2Cl2); IR (KBr) 1652 cm–1; 1H NMR (500 MHz) ! 7.56 (dd, J = 8.0, 6.9 Hz, 1H), 7.66 (d, J = 8.0 Hz,

HETEROCYCLES, Vol. 87, No. 12, 2013
2585
1H), 7.71 (dd, J = 8.0, 6.9 Hz, 1H), 8.34 (d, J = 5.2 Hz, 1H), 8.63 (d, J = 8.0 Hz, 1H), 8.70 (d, J = 5.1 Hz,
1H), 8.98 (s, 1H).
7-Chloro-5H-[1]benzothiopyrano[2,3-c]pyridin-5-one (10b): a pale-yellow solid; mp 210–212 °C
(hexane/CH2Cl2); IR (KBr) 1638 cm–1; 1H NMR (500 MHz) ! 7.62 (d, J = 8.6 Hz, 1H), 7.67 (dd, J = 8.6,
2.3 Hz, 1H), 8.33 (d, J = 4.6 Hz, 1H), 8.59 (d, J = 2.3 Hz, 1H), 8.71 (d, J = 5.2 Hz, 1H), 8.98 (s, 1H); 13C
NMR ! 121.44, 128.18, 129.39, 130.01, 132.20, 133.33, 133.47, 133.50, 134.76, 146.69, 148.55, 178.12;
MS m/z 247 (M+, 100). Anal. Calcd for C12H6ClNOS: C, 58.19; H, 2.44; N, 5.65. Found: C, 58.00; H,
2.69; N, 5.57.
7-Methoxy-5H-[1]benzothiopyrano[2,3-c]pyridin-5-one (10c): a yellow solid; mp 160–161 °C (hexane/
1
CH2Cl2); IR (KBr) 1630, 1604 cm–1; H NMR (500 MHz) ! 3.96 (s, 3H), 7.35 (dd, J = 8.8, 2.9 Hz, 1H),
7.58 (d, J = 8.8 Hz, 1H), 8.07 (d, J = 2.9 Hz, 1H), 8.36 (d, J = 4.9 Hz, 1H), 8.69 (d, J = 4.9 Hz, 1H), 8.99
13
(s, 1H); C NMR ! 55.74, 110.21, 121.42, 123.72, 128.03, 128.47, 130.13, 132.84, 132.99, 146.02,
148.62, 158.88, 178.81; MS m/z 243 (M+, 100). Anal. Calcd for C13H9NO2S: C, 64.18; H, 3.73; N, 5.76.
Found: C, 64.10; H, 3.79; N, 5.80.
10H-[1]Benzothiopyrano[3,2-c]pyridin-10-one (14a):16 a pale-yellow solid; mp 145–147 °C (hexane/
CH2Cl2); IR (KBr) 1643 cm–1; 1H NMR (500 MHz) ! 7.46 (d, J = 5.2 Hz, 1H), 7.56 (ddd, J = 8.0, 7.4, 1.1
Hz, 1H), 7.60 (d, J = 8.0 Hz, 1H), 7.69 (ddd, J = 8.0, 7.4, 1.1 Hz, 1H), 8.63 (dd, J = 8.0, 1.1 Hz, 1H), 8.67
(d, J = 5.2 Hz, 1H), 9.69 (s, 1H).
6-Chloro-10H-[1]benzothiopyrano[3,2-c]pyridin-10-one (14b): a pale-yellow solid; mp 194–196 °C
(hexane/CH2Cl2); IR (KBr) 1642 cm–1; 1H NMR (500 MHz) ! 7.52 (dd, J = 8.0, 7.4 Hz, 1 H), 7.54 (d, J =
4.9 Hz, 1H), 7.78 (dd, J = 7.4, 1.1 Hz, 1H), 8.58 (dd, J = 8.0, 1.1 Hz, 1 H), 8.71 (d, J = 4.9 Hz, 1H), 9.67
13
(s, 1H); C NMR ! 120.28, 123.01, 127.23, 128.27, 130.73, 132.04, 133.43, 135.28, 145.67, 150.61,
152.15, 179.01. HR MS. Calcd for C12H7ClNOS (M+H): 247.9937. Found: m/z 247.9927. Anal. Calcd for
C12H6ClNOS: C, 58.19; H, 2.44; N, 5.65. Found: C, 58.02; H, 2.49; N, 5.37.
8-Methoxy-10H-[1]benzothiopyrano[3,2-c]pyridin-10-one (14c): a pale-yellow solid; mp 201–203 °C
(hexane/CH2Cl2); IR (KBr) 1644, 1602 cm–1; 1H NMR (500 MHz) ! 3.96 (s, 3H), 7.32 (dd, J = 8.6, 2.9 Hz,
1H), 7.46 (d, J = 5.2 Hz, 1H), 7.51 (d, J = 8.6 Hz, 1H), 8.08 (d, J = 2.9 Hz, 1H), 8.64 (d, J = 5.2 Hz, 1H),
13
9.70 (s, 1H); C NMR ! 55.78, 110.45, 119.82, 123.27, 127.58, 131.33, 146.29, 146.56, 149.75 (2C),
152.27, 159.16, 179.10. HR MS. Calcd for C13H10NO2S (M+H): 244.0432. Found: m/z 244.0416. Anal.
Calcd for C13H9NO2S: C, 64.18; H, 3.73; N, 5.76. Found: C, 64.15; H, 3.76; N, 5.74.
ACKNOWLEDGEMENTS
The authors wish to thank Mrs. Miyuki Tanmatsu of our university for her support in recording mass
spectra and performing combustion analyses.

2586
HETEROCYCLES, Vol. 87, No. 12, 2013
REFERENCES AND NOTES
1. (a) M. O. Taha, A. M. Qandil, T. Al-Haraznah, R. Abu Khalaf, H. Zalloum, and A. G. Al-Bakri,
Chem. Biol. Drug. Design, 2011, 78, 391; (b) J. S. Carew, C. M. Espitia, J. A. Esquivel II, D.
Mahalingam, K. R. Kelly, G. Reddy, F. J. Giles, and S. T. Nawrocki, J. Biol. Chem., 2011, 286,
6602; (c) Y. H. Ma, Y. J. Kwon, H. J. Lee, S. W. Chae, S. W. Woo, and H. J. Cho, PCT Int. Appl.,
2011, WO 2011021864 (Chem. Abstr., 2011, 154, 259399); (d) S. T. Nawrocki, J. S. Carew, and G.
Reddy, PCT Int. Appl., 2011, WO 2011112623 (Chem. Abstr., 2011, 155, 423422); (e) D. S.
Peabody and B. Chackerian, PCT Int. Appl., 2011, WO 2011116226 (Chem. Abstr., 2011, 155,
476615); (f) A. Palmeira, M. H. Vasconcelos, A. Paiva, M. X. Fernandes, and M. Pinto, Biochem.
Pharmacol., 2012, 83, 57; (g) H.-S. Huang, US Patent, 2012, 20120088810 (Chem. Abstr., 2012,
156, 505353); (h) D. Verbanac, S. C. Jain, N. Jain, M. Chand, H. C. Paljetak, M. Matijasic, M. Peric,
V. Stepanic, and L. Saso, Bioorg. Med. Chem., 2012, 20, 3180.
2. (a) J. Fischer, G. Von Freymann, and A. M. Wegener, PCT Int. Appl., 2011, WO 2011089157
(Chem. Abstr., 2011, 155, 182493); (b) H. Kida, C. Sato, S. Miura, and T. Saito, PCT Int. Appl.,
2011, WO 2011195649 (Chem. Abstr., 2011, 155, 486456); (c) Y. Ohishi and T. Kato, Japan Patent,
2012, 2012007071 (Chem. Abstr., 2012, 156, 150398); (d) K. Suzuki, T. Ikeda, and T. Mukai, Japan
Patent, 2012, 2012051813 (Chem. Abstr., 2012, 156, 406819); (e) J. Loccufier, PCT Int. Appl., 2012,
WO 2012052288 (Chem. Abstr., 2012, 156, 534324); (f) J. Loccufier, PCT Int. Appl., 2012, WO
2012052291 (Chem. Abstr., 2012, 156, 536057); (g) A. Casiraghi, E. Meneguzzo, G. Norcini, E.
Bellotti, G. Floridi, and G. Li Bassi, PCT Int. Appl., 2012, WO 2012062691 (Chem. Abstr., 2012,
156, 613714).
3. J. Li, G. Can, and W. Su, Heterocycles, 2011, 83, 855.
4. K. Kobayashi, K. Nakagawa, S. Yuba, and T. Komatsu, Helv. Chim. Acta, 2013, 96, 389.
5. After completion of this work, we were aware that 9H-perfluorothioxanthen-9-one has been
synthesized by the reaction of perfluorobenzophenone with Na2S·9H2O: Z. R. Woydziak, L. Fu, and
B. R. Peterson, J. Org. Chem., 2012, 77, 473.
6. (a) E. J. Blanz, Jr. and F. A. French, J. Med. Chem., 1963, 6, 185; (b) A. P. Krapcho, PCT Int. Appl.,
1998, WO 1998984917 (Chem. Abstr., 1998, 129, 330719); (c) S. M. Haydar, PCT Int. Appl., 2003,
WO 2003078646 (Chem. Abstr., 2003, 139, 276881); (d) M. N. Khan, M. A. Khan, and M. A.
Munawar, Latin Am. J. Pharm., 2011, 30, 980.
7. P. Atkinson, K. S. Findlay, F. Kielar, R. Pal, D. Parker, R. A. Poole, H. Puschmann, S. L.
Richardson, P. A. Stenson, A. L. Amber, and J. Yu, Org. Biomol. Chem., 2006, 9, 1707.
8. (a) H. Fujiwara, Heterocycles, 1997, 45, 119; (b) A. Oliva, M. Ellis, L. Fiocchi, E. Menta, and A.
Krapcho, J. Heterocycl. Chem., 2000, 37, 47; (c) A. P. Krapcho, S. N. Haydar, S. Truong-Chiott, M.

HETEROCYCLES, Vol. 87, No. 12, 2013
2587
P. Hacker, E. Menta, and G. Beggiolin, Bioorg. Med. Chem. Lett., 2000, 10, 305; (d) H. Fujiwara
and K. Kitagawa, Chem. Pharm. Bull., 2000, 48, 1380; (e) S. M. Haydar, PCT Int. Appl., 2003, WO
2003078647 (Chem. Abstr., 2003, 139, 276893); (f) J. Li, C. Jin, and W. Su, Heterocycles, 2010, 81,
2555.
9. (a) H. C. Gilmann and R. D. Gorsich, J. Am. Chem. Soc., 1955, 77, 3919; (b) K. Kobayashi, T.
Komatsu, Y. Yokoi, and H. Konishi, Helv. Chim. Acta, 2011, 94, 67.
10. G. W. Gribble and M. G. Saulnier, Tetrahedron Lett., 1980, 21, 4137.
11. J. H. Ziegler, Ber., 1890, 23, 2469.
12. (a) H. Gilman and J. W. Diehl, J. Org. Chem., 1959, 24, 1914; (b) K. Sindelar, J. Metysova, J.
Holubek, E. Svatek, J. Protiva, and M. Protiva, Coll. Czech. Chem. Commun., 1982, 47, 3077.
13. J. O. Jilek, M. Rajsner, J. Pomykacek, and M. Protiva, Chesko-Slovenska Farmacie, 1965, 14. 294
(Chem. Abstr., 1966, 65, 12164).
14. R. Radinov, M. Khaimova, and E. Simova, Synthesis, 1986, 886.
15. K. Kobayashi and T. Suzuki, Heterocycles, 2012, 85, 403.
16. S. Kruger and F. G. Mann, J. Chem. Soc., 1955, 2755.
