10.1002/ejoc.201901755
European Journal of Organic Chemistry
COMMUNICATION
vessel during NMR experiments. In agreement with the results
from Table 1, it was found that the rate of reaction was higher for
the reactions carried out in FEP compared to reactions in regular
glass NMR tubes (see SI). Furthermore, the addition of crushed
glass (from an NMR tube) to the FEP tube was found to lower the
reaction rate to almost resemble that in glass. In the FEP NMR-
tube, the formation of HF was obvious from 19F-NMR as the
reaction progressed (see SI). Interestingly, the distinct HF-peak
was never detected during the reactions in glass NMR tubes. In
the glass NMR tube, however, a broad singlet at ‒162 ppm was
observed to increase (and shift slightly) as the reaction
progressed. Furthermore, this peak was not detectable when the
NMR tube was washed and a blank sample was recorded, ruling
out a glass-bound species.
Furthermore, it seemed that the use of an electron-poor
electrophile such as fluorobenzene (product 7) gave rise to almost
identical yields as with p-xylene (product 8). As the reactions in
glassware (round bottom flask with nitrogen balloon) did not lead
to the formation of the desired product, the experiments were
conducted under identical conditions as reported by Paquin and
co-workers[15] using sealed glass vials rather than conventional
round bottom flasks.
Scheme 3. Friedel-Crafts alkylations using benzyl fluorides under similar
conditions as reported by Paquin and co-workers. Yields from glass vessel in
red, yield in blue in PTFE vessel. HFIP = hexafluoroisopropanol. [a] Solvent was
CH2Cl2. [b] Solvent was fluorobenzene.
Scheme 2. Summary of NMR-observations.
The peak at ‒162 ppm has recently been reported as SiF4,[32]
a species that has previously been reported to be formed as HF
reacts with a glass surface.[33–39] The identity of SiF4 in glass
vessels was confirmed by headspace GC-MS (see SI for
chromatogram and control experiments) of the reaction mixture.
This explains why the reaction was so strongly influenced by the
choice of reaction vessel as SiF4 has been reported by Noyori as
an efficient catalyst for activation of glycosyl fluorides[40] and
related fluorosilicates have previously been employed as Lewis
acids in glycosylation chemistry.[41] Furthermore, the formation of
large amounts of α/α- and α/β-trehalose is a consequence of the
reaction between HF with the glass surface which results in the
release of water into solution, thus explaining the absence of
trehalose in PTFE vessels. This can also explain why the
consumption of glycosyl fluoride was much faster in glass vessels
when weaker glycosyl nucleophiles (Table 2, entries 5 and 7)
were used as water simply outcompeted the 4-OH glycosyl
nucleophile and resulted in trehalose formation. One can
speculate whether this was also the primary reason why the
Mukaiyama group and others added molecular sieves in order to
obtain acceptable yields in catalytic glycosylations with glycosyl
fluorides.[25–27,31,42–46] The effect of adding drying agents to this
particular glycosylation seems highly important as Toshima has
reported an increase in yield from 32% to 99% of the desired
glycoside when 100 wt% 5Å molecular sieves were added.[47]
As there was a clear difference in the reactivity of the glycosyl
fluoride dependent on the vessel material, it was investigated
whether this would also be the case for the H-bond mediated
Friedel-Crafts alkylations with benzyl fluorides that have been
reported by Paquin and co-workers.[15] As this reaction is reported
to be catalyzed by HF formed in situ,[15,16] it was likely to be
influenced by the vessel material as well.
Furthermore, it was investigated whether the vessel surface
had an effect on the reaction, as three identical vials were
subjected to different conditions prior to reaction; One was pre-
treated with TMSCl to TMS-protect all free OH-groups of the glass
surface, one was pre-treated with HF in CH2Cl2 and one glass vial
was used as purchased. Furthermore, an experiment using
identical conditions in a PTFE-vessel was also conducted. It was
found that all four reactions ran to completion within 24h, yielding
the desired product in yields of >95% in all four cases, ruling out
this hypothesis and confirming the high yields reported by Paquin.
As the reactions in round bottom flasks did not lead to formation
of the desired product, we speculated that the headspace volume
could be influencing the reaction as SiF4 diffuses out of solution.
Two parallel experiments, one in a regular glass NMR tube and
another in an FEP liner were then conducted. Both ran to
completion, albeit HF was only observed, by 19F-NMR, in the FEP
liner, whereas SiF4 was observed in the glass NMR tube (see SI).
Scheme 4. Glycosylations using the Paquin procedure[15] employing
HFIP/CH2Cl2 and HF as reaction initiators.
Next, it was investigated whether the conditions for benzyl
fluoride activation were applicable for glycosylations (Scheme 4).
It was found that the CH2Cl2/HFIP solvent mixture was not able to
efficiently activate the glycosyl fluoride and no conversion was
observed after three days. However, when adding 10 mol% HF,
formed in situ in CH2Cl2, the reaction was found to take place in
the glass vessel, whereas the reaction in PTFE showed no
conversion after three days. This can be explained by the reaction
of HF with the glass surface, resulting in the formation of SiF4
Four reactions involving the benzyl fluorides were performed
(Scheme 3). Surprisingly, there was no conversion of benzyl
fluoride 5 in regular round bottom flasks after 24h. After 20h, all
four reactions showed no conversion by TLC, but after 24h, the
starting material in the two reactions in a PTFE flask were fully
converted, which confirmed the autocatalytic kinetic profile
reported by Paquin and co-workers.
