Alkyl aryl ether bond formation with phenofluor

Article abstract of DOI:10.1002/anie.201500902

An alkyl aryl ether bond formation reaction between phenols and primary and secondary alcohols with PhenoFluor has been developed. The reaction features a broad substrate scope and tolerates many functional groups, and substrates that are challenging for more conventional ether bond forming processes may be coupled. A preliminary mechanistic study indicates reactivity distinct from conventional ether bond formation. From fluorination to etherification: A method for the formation of alkyl aryl ethers directly from the corresponding alcohols and phenols with PhenoFluor has been developed. The reaction features a broad substrate scope, and substrates that are challenging for more conventional ether bond forming processes may be coupled. TMS=trimethylsilyl.

Full text of DOI:10.1002/anie.201500902

Angewandte
Chemie
DOI: 10.1002/anie.201500902
Ether Synthesis
Alkyl Aryl Ether Bond Formation with PhenoFluor**
Xiao Shen, Constanze N. Neumann, Claudia Kleinlein, Nathaniel W. Goldberg, and
Tobias Ritter*
Abstract: An alkyl aryl ether bond formation reaction between
phenols and primary and secondary alcohols with PhenoFluor
has been developed. The reaction features a broad substrate
scope and tolerates many functional groups, and substrates that
are challenging for more conventional ether bond forming
processes may be coupled. A preliminary mechanistic study
indicates reactivity distinct from conventional ether bond
formation.
E
thers are common,[1] yet their synthesis is often challenging.
Simple ethers are readily made through the Williamson ether
synthesis, which was developed more than 150 years ago,[2] but
even for moderately complex ethers, such as those derived
from secondary alcohols, the Williamson synthesis often fails
owing to low reactivity and undesired side reactions, such as
elimination.[2] Transition-metal-catalyzed or -mediated cross-
coupling reactions, exemplified by Ullmann,[3] Chan–Lam–
Evans,[4] and Buchwald–Hartwig couplings,[5] are powerful
methods for ether bond formation. Functionally complex
secondary alcohols, however, are challenging substrates for
these transition-metal-catalyzed reactions as well. The direct
coupling between phenols and alcohols for alkyl aryl ether
bond formation is appealing and orthogonal to other cross-
coupling approaches. The Mitsunobu reaction has been
developed for this purpose, and a large substrate scope has
been demonstrated.[6,7] However, several substrate classes,
such as salicylaldehydes, are not tolerated, and general
alcohol–alcohol cross-couplings are deemed challenging
owing to the high pKa values of typical alcohols.[8] Likewise,
the direct coupling of phenols and 2,2,2-trifluoroethanol in
a Mitsunobu reaction has not been reported. Herein, we
report a new approach to alkyl aryl ether formation through
the use of the reagent PhenoFluor (Scheme 1). The reaction
provides a conceptually different, promising reactivity profile,
possibly enabled by the tight ion pairing of key intermediates.
Our strategy distinguishes itself by operational simplicity—
phenols and alcohols can be used directly—and a large
substrate scope, which includes salicylaldehydes and 2,2,2-
trifluoroethanol. An example of selective glycosylation is also
Scheme 1. Fluorination and etherification reactions with PhenoFluor.
Boc=tert-butyloxycarbonyl, TMS=trimethylsilyl.
shown, further demonstrating the potential synthetic appli-
cations.
PhenoFluor is a commercially available deoxyfluorination
reagent for both alcohols and phenols, with a larger demon-
strated substrate scope than any other deoxyfluorination
reagent.[9] We speculated that instead of fluoride, phenolates
or alcoholates might act as nucleophiles to provide ethers if
the fluoride ions were effectively trapped by silanes.[10] The
reaction of an equimolar mixture of alcohol 2a and
4-fluorophenol with PhenoFluor and TMS-imidazole
(2 equiv) in dioxane at 608C for 21 hours afforded ether 3a
in 61% yield (Scheme 1; for reaction optimization, see the
Supporting Information). Without the addition of TMS-
imidazole, less than 1% of ether 3a was formed, and
deoxyfluorination of alcohol 2a was observed. The yield of
the ether bond formation could be increased by using the silyl
ethers of phenol 1a and alcohol 2a, but for operational
simplicity, we opted to develop the ether bond formation
directly from phenols and alcohols.
[*] Dr. X. Shen, C. N. Neumann, C. Kleinlein, N. W. Goldberg,
Prof. Dr. T. Ritter
Department of Chemistry and Chemical Biology
Harvard University
12 Oxford St., Cambridge, MA 02138 (USA)
E-mail: ritter@chemistry.harvard.edu
Homepage: http://www.rittergroup.org
[**] We thank Teppei Fujimoto for the synthesis of PhenoFluor, Filippo
Sladojevich for helpful discussions, and the NIH (NIH-NIGMS
GM088237) for financial support.
Supporting information for this article is available on the WWW
under http://dx.doi.org/10.1002/anie.201500902.
Angew. Chem. Int. Ed. 2015, 54, 1 – 5
ꢀ 2015 Wiley-VCH Verlag GmbH & Co. KGaA, Weinheim
1
These are not the final page numbers!

.
Angewandte
Communications
Table 1: Cross-coupling of phenols and alcohols.
[a] 1/2/PhenoFluor/TMS-imidazole=1.0:2.0:2.0:4.0. [b] 1/2/PhenoFluor/TMS-imidazole=1.5:1.0:1.5:3.0. [c] 1/2/PhenoFluor/TMS-imida-
zole=1.0:3.0:3.0:6.0. [d] TMSNEt2 was used instead of TMS-imidazole. [e] A yield of 85% was obtained when the reaction was carried out at 808C.
[f] Toluene was used as the solvent instead of dioxane. Bn=benzyl, Bz=benzoyl.
À
Ether bond formation proceeds at 238C, but higher yields
are obtained at elevated temperature. The reaction tolerates
a variety of functional groups, including aldehydes, alkenes,
alkynes, amines, amides, esters, halides, and ketones (Table 1).
Both electron-poor and -rich phenols are suitable substrates.
Substituted salicylaldehydes cannot be used to access ethers
with alcohols in Mitsunobu reactions owing to the condensa-
tion of the aldehyde with Huisgen zwitterions, the key
intermediates in Mitsunobu reactions.[8] However, under our
current cross-coupling reaction conditions, products (Æ)-3 f
and 3k were obtained in 60% and 81% yield, respectively.
Furthermore, pyridinols and quinolinols are also suitable
substrates (see 3e, 3l, 3m, 3r, and 3u).
PhenoFluor-mediated C O bond formation: 2,3,4,6-Tetra-
O-benzyl-d-galactose, for example, undergoes glycosylation
with 99:1 a/b selectivity (3x);[15] glycosylation under Mitsu-
nobu conditions afforded 3x in 30:70 a/b selectivity (see the
Supporting Information).
Mechanistically, we believe that the ether bond formation
reported here is distinct from conventional ether bond
forming reactions. For example, diaryl ether bond formation
was found to occur when 1 equivalent of PhenoFluor was
treated with 2.2 equivalents of the aryl silyl ether 1a’
(Scheme 2); diaryl ethers cannot be accessed through conven-
tional Mitsunobu reactions by an SN2 pathway. An 18O
labeling experiment established that the oxygen atom con-
Primary and secondary alcohols, including b,b-branched
alcohols, can be employed. Alkyl trifluoroethyl ethers can be
made through Mitsunobu reactions,[11] but the synthesis of
aryl trifluoroethyl ethers in Mitsunobu reactions has not been
reported.[12–14] As shown in Table 1, ether bond formation of
phenols and 2,2,2-trifluoroethanol proceeded with Pheno-
Fluor at 238C (3r–3u). Moreover, lactols also undergo
Scheme 2. Diaryl ether formation.
ꢀ 2015 Wiley-VCH Verlag GmbH & Co. KGaA, Weinheim Angew. Chem. Int. Ed. 2015, 54, 1 – 5
2
www.angewandte.org
These are not the final page numbers!

Angewandte
Chemie
tained in the ether product originates from the phenol
(Scheme 3). Moreover, we established that ether bond
formation proceeds with inversion at the carbinol center
(see the Supporting Information). In situ 19F NMR and
[1] a) S. Patai, The Chemistry of the Ether Linkage, Interscience
Publishers, London, 1967; b) J. Buckingham, Dictionary of
Natural Products, University Press, Cambridge, MA, 1994.
[2] a) A. Williamson, Justus Liebigs Ann. Chem. 1851, 77, 37; b) J.
March, Marchꢀs Advanced Organic Chemistry, Reaction, Mech-
anisms and Structure, 5th ed., Wiley, New York, 2001, p. 477.
[3] a) K. Kunz, U. Scholz, D. Ganzer, Synlett 2003, 2428; b) D. Ma,
Q. Cai, Acc. Chem. Res. 2008, 41, 1450; c) F. Monnier, M.
Taillefer, Angew. Chem. Int. Ed. 2009, 48, 6954; Angew. Chem.
2009, 121, 7088; d) Y. Wang, J. Zeng, X. Cui, Youji Huaxue 2010,
30, 181; e) A. B. Naidu, E. A. Jaseer, G. Sekar, J. Org. Chem.
2009, 74, 3675; f) M. Wolter, G. Nordmann, G. E. Job, S. L.
Buchwald, Org. Lett. 2002, 4, 973; g) F. Ullmann, Ber. Dtsch.
Chem. Ges. 1903, 36, 2382; h) F. Ullmann, Ber. Dtsch. Chem. Ges.
1904, 37, 853.
[4] a) J. X. Qiao, P. Y. S. Lam, Synthesis 2011, 829; b) K. S. Rao, T.-S.
Wu, Tetrahedron 2012, 68, 7735; c) D. M. T. Chan, K. L. Monaco,
R.-P. Wang, M. P. Winters, Tetrahedron Lett. 1998, 39, 2933;
d) D. A. Evans, J. L. Katz, T. R. West, Tetrahedron Lett. 1998, 39,
2937; e) P. Y. S. Lam, C. G. Clark, S. Saubern, J. Adams, M. P.
Winters, D. M. T. Chan, A. Combs, Tetrahedron Lett. 1998, 39,
2941; f) M. El Khatib, G. A. Molander, Org. Lett. 2014, 16, 4944.
[5] a) D. S. Surry, S. L. Buchwald, Chem. Sci. 2011, 2, 27; b) J. F.
Hartwig, Acc. Chem. Res. 2008, 41, 1534; c) X. Wu, B. P. Fors,
S. L. Buchwald, Angew. Chem. Int. Ed. 2011, 50, 9943; Angew.
Chem. 2011, 123, 10117; d) A. V. Vorogushin, X. Huang, S. L.
Buchwald, J. Am. Chem. Soc. 2005, 127, 8146; e) G. Mann, J. F.
Hartwig, J. Am. Chem. Soc. 1996, 118, 13109; f) G. Mann, C.
Incarvito, A. L. Rheingold, J. F. Hartwig, J. Am. Chem. Soc.
1999, 121, 3224; g) N. Kataoka, Q. Shelby, J. P. Stambuli, J. F.
Hartwig, J. Org. Chem. 2002, 67, 5553.
Scheme 3. The 18O label originates from phenol.
HRMS monitoring of the reaction revealed the presence of
ion pairs A and B, but not C, which leads us to propose a slow
formation of ion pair C, followed by fast nucleophilic
displacement to form the desired product (Scheme 4).
[6] For reviews on the Mitsunobu reaction, see: a) K. C. K. Swamy,
N. N. B. Kumar, E. Balaraman, K. V. P. P. Kumar, Chem. Rev.
2009, 109, 2551; b) T. Y. S. But, P. H. Toy, Chem. Asian J. 2007, 2,
1340; c) D. L. Hughes, Org. React. 1992, 42, 335.
[7] Several reductive etherifications of carbonyl compounds with
alcohols or phenols have been reported; see: a) M. B. Sassaman,
G. K. S. Prakash, G. A. Olah, P. Donald, K. B. Loker, Tetrahe-
dron 1988, 44, 3771; b) S. Hatakeyama, H. Mori, K. Kitano, H.
Yamada, M. Nishizawa, Tetrahedron Lett. 1994, 35, 4367; c) P. A.
Evans, J. Cui, S. J. Gharpure, R. J. Hinkle, J. Am. Chem. Soc.
2003, 125, 11456; d) W.-C. Yang, X.-A. Lu, S. S. Kulkarni, S.-C.
Hung, Tetrahedron Lett. 2003, 44, 7837; e) K. Iwanami, H. Seo,
Y. Tobita, T. Oriyama, Synthesis 2005, 183; f) J. Barluenga, M.
Tomas-Gamasa, F. Aznar, C. Valdes, Angew. Chem. Int. Ed.
2010, 49, 4993; Angew. Chem. 2010, 122, 5113; g) S. J. Gharpure,
J. V. K. Prasad, Eur. J. Org. Chem. 2013, 2076.
[8] M. Girard, P. Murphy, N. N. Tsou, Tetrahedron Lett. 2005, 46,
2449.
[9] a) P. Tang, W. Wang, T. Ritter, J. Am. Chem. Soc. 2011, 133,
11482; b) F. Sladojevich, S. I. Arlow, P. Tang, T. Ritter, J. Am.
Chem. Soc. 2013, 135, 2470; c) T. Fujimoto, F. Becker, T. Ritter,
Org. Process Res. Dev. 2014, 18, 1041; d) M. G. Campbell, T.
Scheme 4. Proposed mechanism. Ar=2,6-diisopropylphenyl.
Given the similarities between the PhenoFluor-mediated
deoxyfluorination[9a,b] and the ether bond formation reported
here, we believe that the formation of tight ion pairs is of
particular relevance for PhenoFluor-mediated reactivity, and
may be, at least in part, responsible for the efficient C O
bond formation and the large substrate scope.
In conclusion, we have developed a novel alkyl aryl ether
synthesis from alcohols and phenols with PhenoFluor. The
presented ether bond formation has a large substrate scope
and can provide ethers that are challenging to obtain with
conventional Mitsunobu reactions. We believe that the
distinct PhenoFluor-based reactivity shown here may con-
tribute to the development of more general ether bond
formation reactions.
À
Ritter, Org. Process Res. Dev. 2014, 18, 474.
À1
À
À
À
[10] The Si F bond is strong (BDEs: Si F: 135 kcalmol ; C F:
116 kcalmolÀ1; Si O: 110 kcalmolÀ1); see: R. T. Sanderson,
À
Chemical Bonds and Bond Energy, Academic Press, New
York, 1976.
[11] For examples, see: a) D. P. Sebesta, S. S. OꢀRourke, W. A.
Pieken, J. Org. Chem. 1996, 61, 361; b) D. Gueyrard, P. Rollin,
T. T. T. Nga, M. Ourꢁvitch, J.-P. Bꢁguꢁ, D. Bonnet-Delpon,
Carbohydr. Res. 1999, 318, 171; c) D. Szabꢂ, A.-M. Bonto, I.
Kçvesdi, ꢃ. Gçmçry, J. Rꢄbai, J. Fluorine Chem. 2005, 126, 641.
[12] For the importance of aryl trifluoroethyl ethers in medicinal
chemistry and synthetic chemistry, see: a) J.-P. Bꢁguꢁ, D.
Bonnet-Delpon, Bioorganic and Medicinal Chemistry of Fluo-
Received: January 30, 2015
Published online: && &&, &&&&
À
Keywords: alkyl aryl ethers · C O bond formation · fluorine ·
.
Mitsunobu reaction · PhenoFluor
Angew. Chem. Int. Ed. 2015, 54, 1 – 5
ꢀ 2015 Wiley-VCH Verlag GmbH & Co. KGaA, Weinheim
www.angewandte.org
3
These are not the final page numbers!

.
Angewandte
Communications
rine (translated from French to English by J. Legros), Wiley,
Hoboken, 2008; b) Q. Yang, J. T. Njardarson, Tetrahedron Lett.
2013, 54, 7080.
Lafont, J. M. Lluch, J. Marquet, J. Org. Chem. 2005, 70, 1718;
g) V. M. Vlasov, Russ. Chem. Rev. 2003, 72, 681. For the
Williamson synthesis of aryl trifluoroethyl ethers, see: h) A.
Kamal, T. B. Pratap, K. V. Ramana, A. V. Ramana, A. H. Babu,
Tetrahedron Lett. 2002, 43, 7353; i) Q. Yang, J. T. Njardarson, C.
Draghici, F. Li, Angew. Chem. Int. Ed. 2013, 52, 8648; Angew.
Chem. 2013, 125, 8810.
[13] For the direct coupling of phenols and trifluoroethanol, see:
a) H. Laatsch, Z. Naturforsch.
B 1985, 40B, 534; b) S. B.
Hawthorne, D. J. Miller, D. E. Nivens, D. C. White, Anal.
Chem. 1992, 64, 405.
[14] For the synthesis of aryl trifluoroethyl ethers with transition-
metal-catalyzed coupling reactions, see: a) D. Vuluga, J. Legros,
B. Crousse, D. Bonnet-Delpon, Eur. J. Org. Chem. 2009, 3513;
b) T. D. Quach, R. A. Batey, Org. Lett. 2003, 5, 1381; c) M. A.
Keegstra, T. H. A. Peters, L. Brandsma, Tetrahedron 1992, 48,
3633; and Ref. [4a]. For SNAr reactions of 2,2,2-trifluoroethanol
with electron-poor arenes, see: d) J. T. Gupton, J. P. Idoux, C.
Colon, R. Rampi, Synth. Commun. 1982, 12, 695; e) J. P. Idoux,
M. L. Madenwald, B. S. Garcia, D. L. Chu, J. T. Gupton, J. Org.
Chem. 1985, 50, 1876; f) I. Tejero, I. Huertas, A. Gonzalez-
[15] For examples of the glycosylation of phenols, see: a) Y. Li, H.
Mo, G. Lian, B. Yu, Carbohydr. Res. 2012, 363, 14; b) T.
Yamanoi, I. Yamazaki, Tetrahedron Lett. 2001, 42, 4009; c) T.
Yamanoi, A. Fujioka, T. Inazu, Bull. Chem. Soc. Jpn. 1994, 67,
1488; d) K. J. Jensen, M. Meldal, K. Bock, J. Chem. Soc. Perkin
Trans. 1 1993, 2119; e) K. Briner, A. Vasella, Helv. Chim. Acta
1990, 73, 1764; f) T. Matsumoto, M. Katsuki, K. Suzuki, Chem.
Lett. 1989, 437; g) W. D. Vaccaro, R. Sher, H. R. Davis, Jr.,
Bioorg. Med. Chem. Lett. 1998, 8, 35.
4
www.angewandte.org
ꢀ 2015 Wiley-VCH Verlag GmbH & Co. KGaA, Weinheim
Angew. Chem. Int. Ed. 2015, 54, 1 – 5
These are not the final page numbers!

Angewandte
Chemie
Communications
Ether Synthesis
X. Shen, C. N. Neumann, C. Kleinlein,
N. W. Goldberg, T. Ritter*
&&&& — &&&&
Alkyl Aryl Ether Bond Formation with
PhenoFluor
From fluorination to etherification: A
method for the formation of alkyl aryl
ethers directly from the corresponding
alcohols and phenols with PhenoFluor
has been developed. The reaction fea-
tures a broad substrate scope, and sub-
strates that are challenging for more
conventional ether bond forming pro-
cesses may be coupled. TMS=trime-
thylsilyl.
Angew. Chem. Int. Ed. 2015, 54, 1 – 5
ꢀ 2015 Wiley-VCH Verlag GmbH & Co. KGaA, Weinheim
www.angewandte.org
5
These are not the final page numbers!
