Photochromic Spirotetrahydroazafluorenes: Part V. Why
Photochromic Molecules with Rigid Region B Exhibiting
Extremely Fast Bleaching Process?
Saleh A. Ahmed
Chemistry Department, Faculty of Science, Assiut University,
Assiut=Egypt
Heinz Du¨ rr
¨
Fachbereich 11.2, Organische Chemie, Universitat des Saarlandes,
Saarbru¨cken, Germany
Spirotetrahydroindolizines (THIs) 1a-g and Spirotetrahydroazafluorenes (THF)
2a-g were previously synthesized. The high reaction rate of the thermal 1,5-electro-
cyclization results in the half-lives of the colored betaines 20a-g range from 3.9 to
5.4 ns, thus showing the existence of the shortest lived colored form observed so far
for pyrazoline based photochromes. However, laser flash spectroscopy was success-
fully used for the determination of both the half-life and absorption maxima of the
colored betaines 20a-g. Time resolved transient spectroscopy shows the geometry of
the betaines 20a-g to be related to one of the two detectable intermediates 10a-g or
100a-g.
Keywords: flash photolysis; short-lived photochromes; spirotetrahydroazafluorenes
INTRODUCTION
Photochromic dihydroindolizines DHIs and tetrahydroindolizines
THIs undergo a photo-induced change of color in solutions and in
polymer matrices when exposed to UV radiation or direct sunlight
exposure.
Many thanks are due to Prof. Dr. Aboel-Magd A. Abdel-Wahab for his help-
ful discussions and Dr. Thomas Hartmann for his assistance with the laser
measurements.
Address Correspondence to Saleh A. Ahmed, Chemistry Department, Faculty
of Science, Assiut University, 71516 Assiut=Egypt. E-mail: saleh 63@hotmail.com
275=[575]

276=[576]
S. A. Ahmed and H. Du¨rr
The thermal back reaction- the 1,5-electrocyclization- from the ring-
open betaine to DHI shows rates extending from milliseconds to sev-
eral weeks [1,2–5] depending on the substituents and structure of
the involved molecule. This manuscript will shed light on the different
intermediates controlling the photochromic behavior of the ultra-fast
bleaching process of the cis-fixed betaine forms of THFs 2.
RESULT AND DISCUSSIONS
Photochromic THIs 1a-g and THF 2a-g were previously prepared [6].
The kinetic of the 1,5-electrocyclization of betaine forms of THIs 1a-f
was measured using UV=VIS in CH2Cl2 at ambient temperature
(Table 1). The colored betaine forms of THIs 1a-f showed half-lives
(t1=2) between 10–96s depending on the subsitutents in the 100b-
phenyl ring. Millisecond (ms) flash photolysis (Table 1) was success-
fully used to determine, in addition to kmax of betaine form of THI
1g, the kinetics of the thermal back reaction. In the case of the
betaines 20a-g, the extremely fast bleaching process hindered the
measurement of both half-lives and absorption maxima of the ultrafast
electrocyclization process of the betaine 20a-g to the 2a-g.
The kinetic of the thermal 1,5-electrocylization of 20a-g were mea-
sured with a laser flash absorption apparatus described earlier [7–9].
The absorption spectra were recorded by time resolved spectroscopy.
The time domaines from 10ꢀ3 to 10ꢀ9 were monitored. Thus only
half-lives for 20a-g in the range of a few nanoseconds (t1=2 ¼ 3.1–
5.4 ns were found (Table 1, Figure 1). So ring fusion in region B of
2a-g results in an acceleration of the thermal 1,5-electrocyclization
of 20a-g to 2a-g. A stabilization of 20a-g by protonation in position 10
with mineral acids that has been shown previously [1,10,11] was not
possible in this case.

277=[577]

278=[578]
S. A. Ahmed and H. Du¨rr
FIGURE 1 Time-resolved fluorescence emission of 2c measured with a Nd-
Yag-laser at 500, 550, 600, 650 and 700 nm in CH2Cl2 and by the single photon
counting method (t4c < 0.30 ns).
According to Fromm et al. [12], these results are explained as fol-
lows: The electron withdrawing 30-acetyl is stabilized the ring-open
form 1000a-g by reducing the negative charge at C10; which has sp2
character. However, the ring closure is only initiated in the case of
a sp3-hybridization of C10. Dorweiler [13] showed that this is borne
out by MINDO3 calculations. So the electrocyclization is slowed down
by a low electron density at C10. The transoid betaine conformer
1000a-g is formed from the cisoid 10a-g by rotations around the axes
C20-C30 and C30-N40. The energy barriers between the conformers
10a-g, 100a-g and 1000a-g are small. Collet [14] could determine a rota-
tional barrier C10-C20 (with double bond character) to be 36 KJ=mol.
The geometry of 1000a-g was proved by x-ray of a stable betaine by
Mu¨nzamy [15]. According to this result, the most stable relaxed
transoid betaine 1000a-g is not totally planar but slightly twisted
between C10 and N40. The dihederal angle found is of the order of
116.5 between the axis R42-C2 and C3-R430 (R4: methyl ester). The
geometry of 100a-g is not exactly known whereas 10a-g must be close
to the one of THIs 1a-g.
In contrast to these results in betaine 20a-g the rotation between
C20 and C30 is impossible because of the annulated heterocyclic ring.

Photochromic Spirotetrahydroazafluorenes
279=[579]
The molecule 20a-g is cis-fixed. There are only rotations possible
around the C10-C20 and C3-N4 axis and the ring systems are inter-
acting during the rotation. The sp3 character of C10 is maintained to
a large extent because of decreasing withdrawal of charge by the
aromatic isoquinoline ring (C20 and C30). Thus the geometry of the
betaine 20a-g is similar to the starting material, the THF 2a-g.
Therefore, this structure is favorable for fast thermal disrotatory
[9] 1,5-electrocyclization of 20 (obtained by irradiation of 2a-g). It
is demonstrated that in the carbocyclic analogue the ring-opening
mechanism of the cyclopentenyl anion, the transitions state comes
close to the possible transition state of the reaction 20!1. The rate
constant k (ln 2=k ¼ t1=2) is much smaller than k and k Now
ꢀ3
ꢀ2
ꢀ1
the different steps and intermediates involved in the ring opening
of 2 and cyclization of 20a-g can explained with the following reac-
tion sequence (for the structure of 10, 100, 1000, 20, 200, 2000 see
reference 6):
In conclusion, novel type of photochromic THF 2a-g showed a fast
1,5-electrocyclization process, which cannot be detected by UV=Vis
or millisecond flash photoylsis technique. Ring annulation in the cis-
fixed 20a-g molecules suppresses rotation and thus produces colored
transients in the nanosecond domain. The new system is an inte-
resting candidate for pattern recognition system and it will find its
application.
REFERENCES
[1] Du¨rr, H. & Bouas-Laurent. H. (1990, 2003). Photochromism: Molecules and
Systems. Vol l,2., Elsevier: Amsterdam.
[2] Ahmed, S. A., Hartmann, T., Huch, V., Du¨rr, H., & Abdel-Wahab, A. A. (2000).
J. Phys. Org. Chem., 13, 539.
[3] Tan, Y. S., Ahmed, S. A., Du¨rr, H., Huch, V., & Abdel-Wahab, A. A. (2001). Chem.
Commun., 14, 1246.
[4] Fromm, R., Ahmed, S. A., Hartmann, T., Huch, V., Abdel-Wahab, A. A., & Du¨rr, H.
(2001). Eur. J. Org. Chem., 21, 4077.
[5] Ahmed, S. A., Abdel-Wahab, A. A., & Du¨rr, H. (2003). J. Photochem. Photobiol. A.,
154, 131.
[6] Ahmed, S. A. (2005). Mol. Cry. & Liq. Cry., 430, 295.

280=[580]
S. A. Ahmed and H. Du¨rr
[7] Ahmed, S. A. (2002). J. Phys. Org. Chem., 15, 392.
[8] Tan, Y. S., Hartmann, Th., Huch, V., Du¨rr, H., & Kossanyi, K. (2001). J. Org.
Chem., 66, 1130.
[9] Fromm, R., Born, R., Du¨rr, H., Kannengiesser, J., Breuer, H.-D., Valat, P., &
Kossanyi, J. (2000). J. Photochem. & Photobiol., 135, 85.
[10] Weber, C., Rustemeyer, F., & Du¨rr, H. (1998). Adv. Mater., 10, 1348.
[11] Du¨rr, H. (1989). Angew. Chem., 101, 427. Angew. Chem. Int. Ed. Engl. 28, 413.
[12] Dorweiler, C., Mu¨nzmay, T., Spang, P., Holderbaum, M., Du¨rr, H., Raabe, E., &
Ku¨rger, K. (1988). Chem Ber., 121, 843.
¨
[13] Collet, C. (1994). Master Thesis, Universitat des Saarlands, Saarbru¨cken.
[14] Mu¨nzamy, T. (1986). Ph. D Thesis, Universita¨t des Saarlands, Saarbru¨cken.
