Platinum and palladium complexes of tridentate ?C^N^N (phen-ide)-pyridine-thiazol ligands – A case study involving spectroelectrochemistry, photoluminescence spectroscopy and TD-DFT calculations

Article abstract of DOI:10.1016/j.ica.2020.120093

Four Pd(II) and Pt(II) complexes [M(C^N^N)Cl] (HC^N^N = 2-(6-phenylpyridin-2-yl)thiazoles) were synthesised, analysed and characterised using ¹H NMR and MS in solution, as well as single crystal XRD in the solid. Cyclic voltammetry of the square planar complexes showed reversible or partially reversible reductions and irreversible oxidations. DFT calculations allowed assigning them to essentially metal-centred oxidations and ligand-centred reductions. Absorption spectra of the complexes show intense absorption bands into π-π* states in the UV to visible spectral range and long-wavelength bands which were assigned to transitions into mixed metal-to-ligand charge transfer (MLCT)/π-π* states, based on TD-DFT calculations. Comparison of Pt and Pd derivatives showed that the energy of the (MLCT)/π-π* bands are increased for Pd over Pt. This was also observed for the phosphorescence at 77 K and is attributed to the higher oxidation potential for Pd and supported by spectroelectrochemical measurements. The photoluminescence quantum yield (Φ_L) drops drastically from Pt to Pd at room temperature, where only the two Pt(II) complexes are luminescent showing a broad unstructured phosphorescence from a ³MLCT state. At 77 K, the phosphorescence is blue-shifted and shows a clear vibrational progression, which is related to an enhanced ligand-centred character due to the lack of solvent stabilisation in the frozen matrix that otherwise increases the MLCT contribution. The Pd(II) complexes are not emissive at 298 K, but luminesce at 77 K. This is due to metal-centred dissociative d-d* states that facilitate radiationless deactivation, which cannot be thermally populated at low temperatures. Thus, similar Φ_L are observed in frozen glassy matrices for both metals. TD-DFT calculations provided insight into the excited states and showed that the substitution pattern does not affect the emission, due to the lack of participation of the phenyl unit in the orbitals that are relevant for the description of the emissive state.

Full text of DOI:10.1016/j.ica.2020.120093

Journal Pre-proofs
Research paper
Platinum and Palladium Complexes of Tridentate -C^N^N (Phen-ide)-pyri‐
dine-thiazol Ligands – A case study involving spectroelectrochemistry, photo‐
luminescence spectroscopy and TD-DFT calculations
Maren Krause, René von der Stück, Dana Brünink, Stefan Buss, Nikos L.
Doltsinis, Cristian A. Strassert, Axel Klein
PII:
DOI:
Reference:
S0020-1693(20)31293-7
https://doi.org/10.1016/j.ica.2020.120093
ICA 120093
To appear in:
Inorganica Chimica Acta
Received Date:
Revised Date:
Accepted Date:
30 July 2020
14 October 2020
17 October 2020
Please cite this article as: M. Krause, R. von der Stück, D. Brünink, S. Buss, N.L. Doltsinis, C.A. Strassert, A.
Klein, Platinum and Palladium Complexes of Tridentate -C^N^N (Phen-ide)-pyridine-thiazol Ligands – A case
study involving spectroelectrochemistry, photoluminescence spectroscopy and TD-DFT calculations, Inorganica
Chimica Acta (2020), doi: https://doi.org/10.1016/j.ica.2020.120093
This is a PDF file of an article that has undergone enhancements after acceptance, such as the addition of a cover
page and metadata, and formatting for readability, but it is not yet the definitive version of record. This version
will undergo additional copyediting, typesetting and review before it is published in its final form, but we are
providing this version to give early visibility of the article. Please note that, during the production process, errors
may be discovered which could affect the content, and all legal disclaimers that apply to the journal pertain.

Platinum and Palladium Complexes of Tridentate ‒C^N^N (Phen-ide)-pyridine-thiazol
Ligands – A case study involving spectroelectrochemistry, photoluminescence spectroscopy
and TD-DFT calculations
a
a
b
c
b,
Maren Krause, René von der Stück, Dana Brünink, Stefan Buss, Nikos L. Doltsinis, * Cristian A.
c,
a,
Strassert, * Axel Klein *
a
Universität zu Köln, Department für Chemie, Institut für Anorganische Chemie, Greinstraße 6, D-50939 Köln,
Germany
b
Westfälische Wilhelms-Universität Münster, Institut für Festkörpertheorie and Center for Multiscale Theory and
Computation, Wilhelm-Klemm-Straße 10, 48149 Münster, Germany
c
Westfälische Wilhelms-Universität Münster, Institut für Anorganische und Analytische Chemie, CiMIC,
CeNTech, SoN, Heisenbergstraße 11, D-48149 Münster, Germany
* to whom the correspondence should be addressed: e-mail: axel.klein@uni-koeln.de
th
Dedicated to Prof. Dr. Luisa De Cola on the occasion of her 60 birthday
Received [Inorg. Chim. Acta] - VSI Photofunctional complexes
Abstract:
Four Pd(II) and Pt(II) complexes [M(C^N^N)Cl] (HC^N^N = 2-(6-phenylpyridin-2-yl)thiazoles) were synthesised,
1
analysed and characterised using H NMR and MS in solution, as well as single crystal XRD in the solid. Cyclic
voltammetry of the square planar complexes showed reversible or partially reversible reductions and irreversible
oxidations. DFT calculations allowed assigning them to essentially metal-centred oxidations and ligand-centred
reductions. Absorption spectra of the complexes show intense absorption bands into π-π* states in the UV to
visible spectral range and long-wavelength bands which were assigned to transitions into mixed metal-to-ligand
charge transfer (MLCT)/π-π* states, based on TD-DFT calculations. Comparison of Pt and Pd derivatives showed
that the energy of the (MLCT)/π-π* bands are increased for Pd over Pt. This was also observed for the
phosphorescence at 77 K and is attributed to the higher oxidation potential for Pd and supported by
spectroelectrochemical measurements. The photoluminescence quantum yield (ΦL) drops drastically from Pt to
Pd at room temperature, where only the two Pt(II) complexes are luminescent showing a broad unstructured
3
phosphorescence from a MLCT state. At 77 K, the phosphorescence is blue-shifted and shows a clear vibrational
progression, which is related to an enhanced ligand-centred character related to the lack of solvent stabilisation in
the frozen matrix that otherwise increases the MLCT contribution. The Pd(II) complexes are not emissive at 298 K
but luminesce at 77 K. This is due to metal-centred dissociative d-d* states that facilitate radiationless
deactivation, which cannot be thermally populated at low temperatures. Thus, similar ΦL are observed in frozen
glassy matrices for both metals. TD-DFT calculations provided insight into the excited states and showed that the
substitution pattern does not affect the emission, due to the lack of participation of the phenyl unit in the orbitals
that are relevant for the description of the emissive state.
Keywords:
Platinum; Palladium; cyclometalating CNN ligands; electrochemistry, UV-vis absorption, photoluminescence
1

1. Introduction
The last two decades saw a tremendous development in the design and synthesis of cyclometalated Pt(II) and
8
Pd(II) complexes for their use as triplet emitting materials.[1-22] The combination of the d configured metal ions
and π accepting ligands (low lying π* orbitals) allows to generate and tune very long-lived metal-to-ligand
(MLCT) excited states.[1-27] Heteroaromatic structures have turned out to be very useful allowing the fine-tuning
of various mixed MLCT / π‒π* (IL) excited states.[1-27] Furthermore, rigidity of both the organic ligand and the
square planar coordination around the metal are very important for efficient triplet emission since this helps
avoiding effective radiationless decay.[7,10,16,18,19,21,22,25-30] Cyclometalated heteroaromatic ligands provide
rigidity, a strong ligand field and suitable intraligand (IL) excited states and are thus frequently used.[1-30]
Combined experimental / theoretical studies have related structural features with photoluminescence (PL)
properties.[13,14,19-31] While structural (substitution) effects on the emission energy are today well understood
through DFT modelling and emission energies can be almost deliberately tuned,[10,12,21,22,24,26,27,30] the PL
efficiency, expressed as PL quantum yield (ΦL) are less predictable.[10,21,22,27,28] This is due to the complex
composition and dynamic behaviour of the excited states of transition metal complexes.[21,22,32]
Out of all the parameters crucial for the ligand-field splitting, the position in the periodic table is the most
important one, but comparative studies with 4d and 5d metals from the same group are scarce.[4,6,11,15,32-47] In
the last few years, we and others have devoted some work to this challenge and have managed to isolate and
study isoleptic complexes of the group 10 metals Pt and Pd in their oxidation state +II.[33,35,37,39-47]
Herein, we report a study using the two metals and two different cyclometalating C^N^N ligands based on 2-(6-
phenylpyridin-2-yl)thiazoles (Scheme 1). They represent the variation of the central pyridine to phenylpyridine
and 3,5-(bis-tBu)phenylpyridine which had turned out to be beneficial for the ability of such cyclometalated
complexes for efficient triplet emission.[8,10,18,28-30] We studied the electrochemical and photophysical
properties of the isoleptic Pd and Pt complexes in comparison. Important insight into the excited states properties
and dynamics came from TD-DFT calculations.
2

Scheme 1. Schematic representation of the [M(C^N^N)Cl] complexes.
2. Experimental
2.1 General information
Commercially available reagents from Merck, abcr, Apollo or Alfa Aesar were used without further purification.
Acetone was dried over molecular sieves and distilled. THF for electrochemical experiments was dried over Na/K
alloy and distilled. All reactions and measurements involving metal complexes were conducted under argon,
using standard Schlenk techniques. The protoligands (ligands prior to deprotonation) and the complexes are air-
stable solids.
2.2 Syntheses
2.2.1 Syntheses of ligand precursors and protoligands
The synthesis and detailed characterisation of the ligand precursors and the protoligands is provided in the
Supplementary Material.
2.2.2 Synthesis of the complexes
Syntheses of the Pd complexes [Pd(C^N^N)Cl] - General description.
1 eq. of the HC^N^N protoligand was dissolved in MeCN and 1 eq. K2[PdCl4] was added. The resulting off-white
precipitate dissolved within a few seconds. The now brownish solution was heated to 90 °C. After the formation
of a bright yellow precipitate the mixture was stirred at 90 °C for another 30 min. After cooling to ambient
temperature, the solid was filtered off and washed with H2O and MeCN. The yellow product was dried under
reduced pressure for at least 3 h.
6-(phenyl-2-ide)-2-thiazolylpyridine-chlorido-palladium(II) [Pd(ph(py)tz)Cl]. From 238.3 mg (1 mmol) 6-
phenyl-2-thiazolylpyridine, 326.4 mg (1 mmol) K2PdCl4, 25 mL H2O + 25 mL MeCN. Yield: 346.6 mg (0.91 mmol,
91%) yellow solid. Anal. Calc. for C14H9ClN2PdS (379.17) C: 44.35, H 2.39, N: 7.39, S: 8.46. Found C: 44.38, H: 2.35,
3

1
N: 7.34, S 8.39%. H NMR: (600 MHz, DMSO-d6) δ = 8.21 (d, 1H, J = 3.2 Hz), 8.07 (t, 1H, J = 7.9 Hz), 8.01-7.89 (m,
13
2H), 7.84 (d, 1H, J = 3.2 Hz), 7.58 (dd, 1H, J = 7.2 Hz), 7.48 (dd, 1H, J = 7.2 Hz), 7.15-7.02 (m, 2H) ppm. C NMR:
(151 MHz, DMSO-d6) δ = 166.85 (q), 164.00 (q), 153.41 (q), 149.42 (q), 147.69 (q), 142.04, 141.22, 136.38, 130.23,
+
+
126.42, 125.46, 125.35, 120.35, 120.22 ppm. EI-MS(+) (70 eV) m/z = 381 [M+H] , 344 [M-Cl+H] .
6-(pheny-2-ide)-2-thiazolyl-4-(3,5-(di-t-butylphen-1-yl)pyridine-chlorido-palladium(II)
[Pd(ph(tbppy)tz)Cl].
From 426.6 mg (1 mmol) 6-phenyl-2-thiazolyl-4-(3,5-di-t-butylphen-1-yl)pyridine, 326.4 mg (1 mmol) K2PdCl4,
25 mL H2O + 55 mL MeCN. Yield: 436.6 mg (0.77 mmol, 77%) yellow solid. Anal. Calc. for C28H29ClN2PdS (567.48)
1
C: 59.26, H 5.15, N: 4.94, S: 5.65. Found C: 59.38, H: 5.25, N: 4.94, S 5.63%. H NMR: (600 MHz, DMSO-d6) δ = 8.21
(d, 1H, J = 3.2 Hz), 8.17 (d, 1H, J = 1.5 Hz), 8.09 (d, 1H, J = 1.5 Hz), 7.79 (dd, 2H, J = 7.0 Hz), 7.74 (d, 2H, J = 1.8 Hz),
7.59 (t, 1H, J = 1.7 Hz), 7.44 (dd, 1H, J = 7.6 Hz), 7.07 (td, 1H, J = 7.4 Hz), 6.99 (td, 1H, J = 7.4 Hz), 1.40 (s, 18H) ppm.
13
C NMR: (151 MHz, DMSO-d6) δ = 166.9 (q), 164.0 (q), 153.5 (q), 153.4 (q), 151.8 (q), 149.6 (q), 147.8 (q), 141.8, 136.4
(q), 136.2, 130.0, 126.3, 125.9, 125.0, 124.3, 122.5, 118.5, 118.0, 40.3, 35.4, 31.7 ppm. EI-MS(+) (70 eV): m/z = 569
+
+
[M+H] , 532 [M-Cl+H] .
Synthesis of 6-(phenyl-2-ide)-2-thiazolylpyridine-chlorido-platinum(II) [Pt(ph(py)tz)Cl]. 119 mg (0.5 mmol) 6-
phenyl-2-thiazolylpyridine (Hph(py)tz) was dissolved in 12.5 mL MeCN and added to a solution of 208 mg
(0.5 mmol) K2[PtCl4] in 12.5 mL H2O. The reaction mixture was heated up to 90 °C and stirred for 24 h leading to
an orange precipitate. After cooling to ambient temperature, the solid was filtered off and washed with H2O and
MeCN. The orange product was dried in vacuo. Yield: 148 mg (0.32 mmol, 63%). Anal. Calc. for C14H9ClN2PtS
1
(467.83) C: 35.94, H 1.94, N: 5.99, S: 6.85. Found C: 35.95, H: 1.95, N: 6.00, S 6.86%. H NMR (600 MHz, DMSO-d6) δ
= 8.37 (d, 1H, J = 3.2 Hz), 8.03 (t, 1H, J = 7.9 Hz), 7.98-7.96 (m, 2H), 7.86 (d, 1H, J = 7.9 Hz), 7.54 (dd, 1H, J = 0.8, 7.6
Hz), 7.42 (dd, 1H, J = 0.8, 7.5 Hz, JPt-H = 42.3 Hz), 7.11 (dt, 1H, J = 1.2, 7.4 Hz), 7.05 (t, 1H, J = 7.4 Hz) ppm. HR-ESI-
+
+
MS(+): m/z = 460.01905 [M-Cl+N2] (calc. 431.010759), 431.01055 [M-Cl] (calc. 460.019583).
Synthesis of 6-(pheny-2-ide)-2-thiazolyl-4-(3,5-di-t-butylphen-1-yl)pyridine-chlorido-platinum(II)
[Pt(ph(tbppy)tz)Cl]. A mixture of 208 mg (0.5 mmol) K2[PtCl4] and 256 mg (0.6 mmol) Hph(tbppy)tz were
suspended in acetic acid (60 mL). The mixture was heated up to 110 °C and stirring was continued for 3 d. After
cooling the reaction mixture, the precipitate was filtered off and washed with acetic acid, water and diethyl ether.
The orange product was dried in vacuo. Yield: 247 mg (0.4 mmol, 80%). Anal. Calc. for C28H29ClN2PtS (656.15) C:
1
51.25, H 4.46, N: 4.25, S: 4.89. Found C: 51.28, H: 4.44, N: 4.25, S 4.88%. H NMR (600 MHz, CD2Cl2) δ = 7.84 (d, 1H,
J = 3.2 Hz), 7.71 (d, 1H, J = 3.2 Hz), 7.64 (t, 1H, J = 1.7 Hz), 7.57-7.56 (m, 3H, J = 1.7 Hz), 7.43-7.42 (m, 2H, J = 2.7 Hz,
JPt-H = 45.3 Hz), 7.32 (dd, 1H, J = 1.4, 7.4 Hz), 7.05-6.99 (m, 2H, J = 3.2 Hz), 1.45 (s, 18H) ppm. EI-MS(+) (70 eV) m/z =
+
+
656 [M] , 426 [ph(tbppy)tz] .
2.3 Instrumentation
4

1
13
1
13
H and C NMR spectra were recorded on a Bruker Avance II 300 MHz ( H: 300.13 MHz, C: 75.47 MHz) -
1
double resonance (BBFO) 5 mm observe probehead with z-gradient coil, Bruker Avance 400 MHz ( H:
13
1
400.13 MHz, C: 100.61 MHz) using a triple resonance H, BB inverse probe head or Bruker Avance II 600 MHz
1
13
spectrometer ( H: 600.13 MHz, C: 150.93 MHz) with a triple resonance (TBI) 5 mm inverse probehead with z-
1
1
gradient coil using a triple resonance. The unambiguous assignment of the H resonances was obtained from H
1
NOESY and H COSY experiments. All 2D NMR experiments were performed using standard pulse sequences
from the Bruker pulse program library. Chemical shifts are relative to TMS respectively. UV-vis absorption
spectra were recorded with Varian Cary 05E or Cary 50 scan spectrophotometers. PicoQuant Fluo-Time 300
spectrometer was used for lifetime measurements. Lifetime analysis was performed using the commercial FluoFit
software. The quality of the fit was assessed by minimising the reduced chi-squared function. Luminescence
quantum yields were determined with a Hamamatsu Photonics absolute PL quantum yield measurement system
(C9920–02), equipped with a L9799-01 CW Xenon light source, monochromator, photonic multichannel analyser
and integrating sphere (uncertainty of roughly ± 2 % for ΦL is estimated). All solvents were of spectroscopic
grade. Elemental analyses were obtained using a HEKAtech CHNS EuroEA 3000 analyzer. EI-MS spectra were
measured with a Finnigan MAT 95, and HR-ESI-MS using a THERMO Scientific LTQ Orbitrap XL. MS
Simulations were performed using ISOPRO 3.0. IR spectra were measured in ATR mode using a Perkin Elmer 400
FT-IR spectrometer. Electrochemical measurements were carried out in 0.1 M nBu4NPF6/THF solution using a
three-electrode configuration (glassy carbon working electrode, Pt counter electrode, Ag/AgCl reference
electrode) and a Metrohm Autolab PGSTAT30 potentiostat and function generator or a SP-150 BioLogic
potentiostat. The ferrocene/ferrocenium couple served as internal reference. UV-vis-spectroelectrochemical
measurements (in 0.1 M nBu4NPF6/THF solution) were performed using an optically trans-parent thin-layer
electrode (OTTLE) cell [48,49] at room temperature.
2.3 Single Crystal X-ray Diffractometric Analysis
XRD single crystal structure analysis for [Pd(ph(py)tz)Cl] (P21/c, No. 14) was performed using graphite-
monochromated Mo-Kα radiation (λ = 7.1073 Å) with an IPDS II (STOE and Cie.) diffractometer. The structure
was solved by direct methods using SIR2014 [50] and refinement was carried out with SHELXL 2016 [51]
2
2
employing full-matrix least-squares methods on F0 ≥ 2(F0 ). The non-hydrogen atoms were refined with
anisotropic displacement parameters without any constraints. The hydrogen atoms were included by using
appropriate riding models, full data in the Supplementary Material or can be obtained free of charge at
https://summary.ccdc.cam.ac.uk/structures or from the Cambridge Crystallographic Data Centre, 12 Union Road,
Cambridge, CB2 1EZ UK (fax: +44-1223 336033 or e-mail: deposit@ccdc.cam.ac.uk), CCDC 2006642.
2.5 DFT calculations
5

The optimised geometries and the vibrational Franck–Condon spectra were determined with the quantum
chemistry package Gaussian 09 Rev. D.01 [52] using the CAM-B3LYP functional [53] together with Grimme‘s D3
dispersion correction with Becke-Johnson damping.[54] The SDD basis set applies an effective core potential for
the Pt and Pd atoms,[55] while the D95 basis set is used for H, C, N, and O atoms.[56]
To compute vibrational Franck–Condon spectra, the method of Barone et al.[57,58] with Kohn–Sham DFT-based
geometry optimisations in the S0 and T1 states followed by frequency analysis calculations was used.
All energy corrections were done by adding zero-point vibrational energies and thermal free energy
contributions. To calculate the overlap integrals for the vibronic spectra, the transitions are divided into classes
Cn, where n is the number of the excited normal modes in the final electronic state. The number of quanta per
mode was limited to 100 while the number of quanta for combinations of two modes was restricted to 65. The
8
maximum number of computed integrals was set to 1.5 × 10 . A maximum of 20 classes was calculated. The line
–1
spectrum was broadened with the aid of gaussian functions with a half-width at half-maximum of 400 cm .
The solvent CH2Cl2 was taken into account by the polarisable continuum model (PCM) in an integral equation
formalism framework [59] with atomic radii from the universal force field model (UFF).[60] To characterise the
emissive T1 state, the T1 geometry was first optimised with Kohn–Sham DFT with multiplicity 3 followed by TD-
DFT calculations of the T1 state. TD-DFT calculations of the 40 lowest excited singlet states were performed at the
optimised S0 geometry with the PBE0 functional [61] and the SDD basis set to obtain the UV–vis absorption
spectrum of the complexes [M(ph(py)tz)Cl] and [M(ph(tbppy)tz)Cl]. Finally, a Lorentzian broadening with a half-
width at half-maximum (HWHM) of 10 nm was used for each transition.
3. Results and Discussion
3.1 Synthesis and General Characterisation
The protoligands (ligand precursors prior to cyclometalation) HC^N^N were assembled from corresponding
Mannich bases or Chalcones using the versatile Kröhnke synthesis (details in the Supplementary Material). The
Pt and Pd complexes were synthesised from the HC^N^N protoligands and K2[MCl4] (M = Pt or Pd) and the
complexes were obtained in 63 to 91% yield as yellow to orange microcrystalline powders. The materials were
1
analysed and characterised through elemental analysis, H NMR spectroscopy, and MS. Single crystal XRD of the
complex [Pd(ph(py)tz)Cl] revealed the expected square planar geometry of these complexes and the binding
through the N atom of the thiazol ligand moiety (Figure S8 and more details in the Supplementary data). The
completely planar molecules stack in multiple ways in the crystal with π stacking interplanar distances of 3.89
…
…
and 3.98 Å, short Pd arene contacts of 3.64 Å. The Pd atoms show a zig-zag pattern with Pd Pd contacts of
4.7582(8) and 4.7561(8) Å (Figure S8)
6

3.2 Electrochemistry and DFT-calculated frontier orbitals of the complexes
On first view, all the cyclometalated complexes showed a first reversible one-electron reduction wave at around ‒
1.7 V (Figure 1 and Figures S11-S14). The potentials are higher (less negative) for the Pt complexes (Table 1)
compared with the Pd derivatives and slightly higher for the tBu-phenyl complexes. They are usually followed
by a second fully or partly reversible reduction wave at potentials around ‒2.45 V. These potentials are quite
invariant. Similar behaviour was observed for the protoligands HC^N^N at potentials lying about 0.7 V lower
than those of the complexes (Figure S2 and Table 1). We assume essentially ligand-centred reduction processes, in
line with reports of similar complexes.[8,10,62-67] Thus, the deprotonation, metal coordination and planarisation
of the ligand markedly shifts the reduction potentials by 0.7 V to 0.8 V. This is more pronounced for Pt(II) than
for Pd(II). On the anodic side, irreversible oxidations are recorded in the range 0.54 V to 0.87 V (Table 1). Since the
potentials for the Pt complexes lie somewhat lower than those of the Pd derivatives we can assume metal
II
III
(M /M ) based oxidation processes in line with previous reports.[8,10,62-67]
According to our DFT calculations, the LUMO is slightly more stable (by 0.06 eV) in the Pt complexes, while the
HOMO is considerably less stable by 0.23 eV than in the Pd complexes (see Table S6, for plots see Figure S15)
completely in line with the observed trend in the reduction potentials. This leads to the HOMO-LUMO gap in the
Pt complexes being smaller by 0.23 eV compared to the Pd complexes. The effect of the ligand (i.e. py vs. tbppy),
on the other hand, is found to be considerably smaller, the LUMO being lower by 0.01 eV and the HOMO by 0.02
eV with py. This is consistent with the small observed changes in the reduction potentials when changing from
py to tbppy.
5 µA
2 µA
1.5
-2.5
1
0
-0.5
-0.5
-1
-2
0.5
-1.5
E / V vs ferrocene/ferrocenium
E / V vs. ferrocene/ferrocenium
Figure 1. Cyclic voltammogramms of [Pd(ph(py)tz)Cl] in 0.1 M nBu4NPF6/solvent at 298 K and 0.1 V/s scan rate.
Oxidations (left) in MeCN, reductions (right) in THF.
a
Table 1. Redox potentials of HC^N^N protoligands and [M(C^N^N)Cl] (M = Pd or Pt) complexes.
7

Ox2 Epa
Ox1 Epa
Red1 E1/2
–2.43
–2.47
‒1.74
‒1.71
Red2 E1/2
–3.32
–3.37
‒2.44
‒2.45
ΔERed1‒EOx1
-
-
2.58
2.58
2.30
2.31
Hph(py)tz
Hph(tbppy)tz
[Pd(ph(py)tz)Cl]
[Pd(ph(tbppy)tz)Cl)]
[Pt(ph(py)tz)Cl]
-
-
-
-
b
b
1.38
1.10
> 1.3
0.84
0.87
0.64
b
b
c
c
‒1.66
‒1.65
‒2.39
‒2.35
c
c
c
c
[Pt(ph(tbppy)tz)Cl)]
1.14
0.66
a
From cyclic voltammetry, electrochemical potentials in V (uncertainties ~5 mV), half-wave potentials E1/2 for
reversible redox waves and anodic peak potentials Epa for irrevsible oxidation waves; measured in 0.1 M
b
c
nBu4NPF6/THF at 298 K, scan rate 100 mV/s. Measured in MeCN. Measured in CH2Cl2.
The DFT calculated lowest unoccupied molecular orbitals (LUMO) of the complexes (Figure S15, compare also
Figure 5) show contributions delocalised over the py-tz electron accepting part of the ligand and no contribution
from the tBu2-phenyl substitutent, which is in line with our assumptions for reductions. The calculated highest
occupied molecular orbitals (HOMO) of the complexes obtain their highest contributions from the phenyl group
and the metal, but also a small contribution from the central pyridyl moiety. The contribution of the metal atom
to this orbital is similar for both Pt and Pd. The difference in oxidation potential for the two Pd/Pt pairs can be
explained by the difference in HOMO energies (see Table S6). For the HOMO-1 similar contributions were found,
now with a marked contribution of the chloride coligand. The HOMO-2 is clearly centred on the metal and
chloride coligand.
3.3 UV-vis absorption / photoluminescence spectroscopy and TD-DFT calculations
The absorption spectra of the Pt and Pd complexes are dominated by intense absorption bands into π-π* states,
peaking in the UV to visible range (Figure 2). When comparing the absorption maxima, the bands of the Pt
complexes are slightly red-shifted compared with the Pd derivatives. Based on comparison with similar
complexes,[8-10,15,23,31,32] we attribute this to a marked MLCT character of the corresponding excited states,
which are energetically lowered for the less electronegative metal centre (Pt is easier to be oxidised than Pd).
Similar intense bands were also seen in the HC^N^N protoligands (Figure S1) and their overall appearance of the
vibrational progression depends strongly on the type of ligand.
8

22500
20000
17500
15000
12500
10000
7500
5000
2500
0
30000
25000
20000
15000
10000
5000
0
250
300
350
400
450
500
550
600
250
300
350
400
450
500
550
600
wavelength / nm
wavelength / nm
25000
20000
15000
10000
5000
0
25000
20000
15000
10000
5000
0
250
300
350
400
450
500
550
600
250
300
350
400
450
500
550
600
wavelength / nm
wavelength

/ nm
Figure 2. UV-vis absorption spectra (molar absorption coefficients as a function of wavelength) of the four
complexes in fluid CH2Cl2 at RT.
The long-wavelength absorption bands of the complexes reveal significant differences between the Pt and Pd
derivatives. While the spectra of the Pt complexes are characterised by broad bands peaking around 450 nm with
‒1.
‒1
molar absorption coefficients of around 3500 M cm , much weaker absorptions (shoulders) were observed for
the Pd derivatives with markedly blue-shifted energies, when compared with the analogous Pt complexes (Table
2). For the other maxima, similar blue-shifts were observed when comparing the peaks at 400 (Pd) vs. 420 nm (Pt)
and 340 (Pd) vs. 370 nm (Pt). This effect is consistent with the higher oxidation potentials observed in this report
and in previous studies [33,35] for the more electronegative Pd compared with Pt and the assumed partial MLCT
character of the excited states,[21,25,31,33,42,44] very probably with markedly different MLCT character when
two metals are exchanged. This is consistent with the different contributions of the metal to the HOMO as
outlined above. Higher MLCT character of the long-wavelenth band for the Pt complexes contrast probably with
higher L(Phenyl)L(py-tz)CT character for Pd. The same blue-shifts were observed also for the quite similar
complex pair [M(phbpy)Cl] (Hphbpy = 6-phenyl-2,2’-bipyidine) and further isoleptic pairs of Pd and Pt
9

complexes.[42,47,67-69] Interestingly, the absorption energies ot the phbpy complexes are very similar to the
corresponding [M(ph(py)tz)Cl] derivatives, thus the thiazol group does not differ largely from a pyridyl unit.
Table 2. Selected photophysical data of [M(C^N^N)Cl] complexes.
Complex
[Pt(ph(py)tz)Cl]
366 (11.1), 421
(2.76), 436b (2.80)
294, 336, 370, 445
605, 640 sh
0.2452 ± 0.0018
0.602 ± 0.018 [1.30 ±
0.16 (1); 0.594 ±
0.005 (99)]
[Pt(ph(tbppy)tz)Cl]
376 (10.8), 424 (3.66),
446b (4.21)
301, 340, 370, 446
608
[Pd(ph(py)tz)Cl]
344 (9.62), 401
(1.24), 423b (0.74)
n.d.
[Pd(ph(tbppy)tz)Cl]
346 (13.5), 402 (1.78),
λabs / nm (ε / 103 M-1 cm-1)a
427b (0.79)
n.d.
λexc / nm
λem / nm
n.d.
n.d.
n.d.
n.d.
Airc
0.275 ± 0.002
Fluid solution
(CH2Cl2, 298 K)
τ / µse
Ard
0.714 ± 0.006
n.d.
n.d.
Airc
Ard
< 0.02
0.05
0.03
0.07
n.d.
n.d.
n.d.
n.d.
ΦL (±
0.02)
λexc / nm
294, 327, 360, 422
300, 333, 360, 429
290, 327, 380, 422
520, 535, 558, 604,
(672 sh)
301, 325, 426
λem / nm
τ / µs
557, 605, 660 (sh)
557, 603, 662 sh
517, 557, 604, (660 sh)
Frozen glassy
matrix
(CH2Cl2/MeOH
1:1, 77 K)
3.17 ± 0.12 [3.65 ±
0.03 (44); 2.80 ± 0.03
(56)]f
4.01 ± 0.13 [7.1 ± 0.3
(5); 3.84 ± 0.04 (95)]f
95 ± 4 [105.9 ± 1.0
(74); 74 ± 3 (26)]g
94 ± 3 [107 ± 1.0 (61);
75 ± 2.0 (39)]g
0.18
0.22
0.13
0.19
ΦL (± 0.1)
a
b
c
d
Measured in CH2Cl2. Absorption maximum with the longest wavelength. Aerated sample. Deaerated sample
(Ar-purged by bubbling for 20 min). Photoluminescence decays measured detecting at 600 nm. At 560 nm or;
e
f
g
at 520 nm. For multiexponential decays, the amplitude-weighted average lifetimes are given as well as the
different components in square brackets with relative amplitudes as percentages in parentheses.
Figure 3 shows the photoluminescence (PL) spectra of the complexes, their photophysical properties are
summarised in Table 2 (the complete set of spectra and photoluminescence decay plots are shown in Figure S20 –
S31). For the complex [Pt(ph(py)tz)Cl] at room temperature, the emission spectrum shows a single broad
(unstructured) band with λmax = 605 nm. This suggests, together with an excited state lifetimes (τ) of τ = 0.2452 µs,
a clear overall MLCT character for the emissive state. The τ and ΦL increase in the deaerated solutions, pointing to
3
3
a quenching of the excited triplet state ( MLCT) by O2. At RT, the Pd(II) complexes are non-luminescent. At 77 K
in frozen glassy matrices, the λmax (557 nm) appeared strongly blue-shifted (Δλ = 48 nm) if compared with their
Pt(II) analogues and showed clear vibrational progressions (Figure 3; left). τ and ΦL rise to τ = 3.17 µs and
ΦL = 0.18. Due to the lack of solvent stabilisation, the excited states possess less MLCT character and a clear metal-
3
perturbed ligand-centred nature ( MP-LC) as an admixture of LC character with minor MLCT contributions,
which explains the structured vibrational progression and prolongued lifetimes.
10

Emission:
[Pt(ph(py)tz)Cl]:
298 K
1,0
0,8
0,6
0,4
0,2
0,0
1,0
0,8
0,6
0,4
0,2
0,0
Emission at 77K:
[Pt(ph(py)tz)Cl]
[Pd(ph(py)tz)Cl]
[Pd(ph(tbppy)tz)Cl]
77 K
[Pt(ph(tbppy)tz)Cl]:
298 K
77 K
400
500
600
700
800
900
500
600
700
800
wavelength / nm
wavelength / nm
Figure 3. Left: Photoluminescence spectra (λexc = 350 nm) of [Pt(ph(py)tz)Cl] (blue) and [Pt(ph(tbppy)tz)Cl] (red)
in fluid CH2Cl2 at 298 K (solid line) and in in a frozen glassy matrix (CH2Cl2/MeOH 1:1) at 77 K (dotted line).
Right: Photoluminescence spectra (λexc = 350 nm) of [Pt[ph(py)tz)Cl] (blue), [Pd(ph(py)tz)Cl] (black) and
[Pd(ph(tbppy)tz)Cl] (red) in a frozen glassy matrices (CH2Cl2/MeOH 1:1) at 77 K.
The change of the substitution pattern [Pt(ph(tbppy)tz)Cl] has no significant effect on the emission maxima as
well as on the radiative and radiationless deactivation rates, as the lifetimes and quantum yields remain invariant
within the experimental uncertainty, both at RT and at 77 K. In fact, the change upon sustitution is only marginal
at 77 K, reaching τ = 4.01 µs and ΦL = 0.22. Due to low-lying dissociative metal-centred d-d*-states related to a
lower ligand field splitting, none of the Pd complexes shows detectable emission in fluid solutions at room
temperature. On the other hand, at 77 K, the photoluminescence efficiency is comparable to the Pt complexes
(ΦL[Pt(ph(tbppy)tz)Cl] = 0.22 vs. ΦL[Pd(ph(tbppy)tz)Cl] = 0.19). As in the case of the analogous Pt complexes at 77 K, the
emission from the Pd complexes shows strong vibrational progressions (Figure 3; right). Due to the larger
HOMO-LUMO gap of the Pd complexes, the emission appears blue-shifted (Δλ ≈ 30 nm), if compared with the
emission of the corresponding Pt complexes. The extremely long excited state lifetime for the Pd complexes
(τ[Pd(ph(py)tz)Cl] = 95.0 µs and τ[Pd(ph(tbppy)tz)Cl] = 94.1 µs) can be attributed to the lower spin-orbit coupling of Pd
compared with Pt, which affects the radiative and radiationless deactivation rate constants to a similar extent,
thus prolonging the lifetimes while leaving the quantum yields unaffected.[31]
The different temperature-dependent photoluminescence behaviour of Pd and Pt complexes is in line with
similar observations for related pairs of Pd and Pt complexes, especially for the very similar complexes
[M(phbpy)Cl] (Hphbpy = 6-phenyl-2,2’-bipyidine) and derivatives.[42,47,67,68] In contrast to the absorption
energies, the emission energies of the phbpy complexes are markedly blue-shifted compared to the ph(py)tz
derivatives. E.g. [Pt(phbpy)Cl] shows a broad emission band with a maximum at 568 nm at 298 K in CH2Cl2
solution [67] compared with 602 nm for [Pt(ph(py)tz)Cl] and the high-energy maximum at 538 nm in glassy
11

frozen CH2Cl2 for the phbpy complex is shifted to 557 nm for the ph(py)tz complex. Thus, from the emission
experiments we conclude a red-shift of the bands when replacing the peripheral pyridine in phbpy through the
thiazol in ph(py)tz Pt and Pd complexes.
The left side of Figure 4 shows the TD-DFT calculated UV-vis absorption spectra of the complexes
[M(ph(py)tz)Cl] and [M(ph(tbppy)tz)Cl]. The most intense absorptions are in the range of 210 nm – 350 nm
which is in accord with the experimental data (Figure 2 and Table S4). The calculations also verify the
experimentally found red shift which occurrs by changing the metal from Pd to Pt. As already discussed, the
difference of absorption bands between Pt and Pd is particularly pronounced in the long wavelength range. For
the complexes [M(ph(py)tz)Cl] broad bands were found at 400 nm for Pd and 430 nm for Pt, respectively. A
closer look at the complexes [M(ph(tbppy)tz)Cl] reveals a peak at 408 nm for Pd and a peak at around 440 nm for
Pt. [M(ph(py)tz)Cl] exhibits a small blue shift when compared with [M(ph(tbppy)tz)Cl].
Figure 4. Normalised TD-DFT calculated UV−vis absorption (left) and emission (right) spectra of all four
complexes in CH2Cl2 at room temperature.
The right side of Figure 4 contains the vibrationally resolved emission spectra at room temperature in CH2Cl2.
First of all, the experimental result that the change of the ligand substitution pattern for Pt has no significant
effect on the emission maxima was confirmed by TD-DFT calculations. Both shape and position are nearly the
same for [Pt(ph(py)tz)Cl] and [Pt(ph(tbppy)tz)Cl]. For Pd the shape of the spectrum of [Pd(ph(py)tz)Cl] changes
in comparison with [Pd(ph(tbppy)tz)Cl] while the relative intensity of the main maxima stays similar. The
experimentally observed blue shift of the Pd complexes in comparison with the Pt derivatives is clearly
confirmed by our TD-DFT calculations.
12

The most important frontier orbitals of the four complexes at the optimised T1 geometry are depicted in Figure 5
(left: [M(ph(py)tz)Cl] and right: [M(ph(tbppy)tz)Cl]). All pictured orbitals have contributions from the ligands
and also from the metal centre. The most significant contribution of metal orbitals for all complexes was found at
the highest occupied molecular orbital (HOMO). A look at [M(ph(tbppy)tz)Cl] shows pronounced delocalisation
of the frontier orbitals over the luminophoric ligand, while the contributions on the auxiliary ligand are very
small. Furthermore, the HOMOLUMO excitation is the highest monoelectronic contribution to the T1 state in all
cases. Thus, the T1 state can be described as a combination of MLCT and IL character of the C^N^N ligand, with
some charge transfer character from the phenyl ring to the thiazol moiety. This assignment is consistent with the
spin density plots shown in Figure S32.
Figure 5. DFT calculated frontier orbitals at the optimised T1 geometry (a) [Pd(ph(py)tz)Cl], (b) [Pt(ph(py)tz)Cl],
(c) [Pd(ph(tbppy)tz)Cl] and (d) [Pt(ph(tbppy)tz)Cl] together with the contributions (>5%) to the T1  S0 state
obtained by TD-DFT.
13

Figure 6. Partitioning of the [M(ph(py)tz)Cl] (left) and [M(ph(tbppy)tz)Cl] (right) complexes for the numerical
analysis of MLCT, LMCT, LC and LLCT excitations shown in Fig. 7.
Figure 7. Decomposition into contributions from MLCT, LMCT, LC and LLCT of the first six excited states (in
energetical order from left to right) of complexes (a) [Pd(ph(py)tz)Cl], (b) [Pt(ph(py)tz)Cl], (c)
[Pd(ph(tbppy)tz)Cl] and (d) [Pt(ph(tbppy)tz)Cl] computed with the package TheoDORE [69].
With the aid of the package for Theoretical Density, Orbital Relaxation and Exciton analysis (TheoDORE) [69] a
more detailed investigation of the excited state character is possible. Figure 7 shows the decomposition into
contributions from MLCT, LMCT, LC and LLCT of the first six excited states according to the partitioning
defined in Figure 6. It is important to realize that if one treated the entire ligand as a single entity, both LC and
LLCT transitions would be described as IL transitions. From Figure 7 it becomes apparent that the Pd complexes
have a smaller MLCT character (13-16%) than the Pt derivatives (25-28%). When the [M(ph(py)tz)Cl] complex is
compared with [M(ph(tbppy)tz)Cl], the latter is the one with the slightly higher MLCT contribution (see Table
S7).
3.4 UV-vis spectroelectrochemistry
UV-vis absorption spectroscopy during electrochemical reductions (spectroelectrochemistry, SEC) showed
similar patterns for Pd and Pt complexes (Figure 7 and Figures S16-S19) as found for the corresponding
14

protoligands HC^N^N (Figures S4 and S17), which is in line with a ligand-centred reduction and in agreement
with the assignment of the HOMO and LUMO (Section 3.2) and the optical transitions (Section 3.3). Importantly,
for all complexes the first reduction occurs reversibly on the (slow) timescale of the SEC experiment, while the
second appeared only partly reversible.
initial spectrum
initial spectrum
1. reduction
2. reduction
initial spectrum
1. reduction
2. reduction
1. oxidation
300
400
500
600
700
800
900 1000
300
400
500
600
700
800
900 1000
250
300
350
400
450
500
550
600
wavelength / nm
wavelength / nm
wavelength / nm
Figure 7. Changes in UV-vis absorption of [Pd(ph(tbppy)tz)Cl] (left) and [Pt(ph(tbppy)tz)Cl] (middle) during
electrochemical reductions and [Pt(ph(tbppy)tz)Cl] during oxidations (right) in nBu4NPF6/THF
(spectroelectrochemistry, SEC).
During the oxidation of [Pt(ph(tbppy)tz)Cl], the long-wavelength bands at 370 nm and 450 nm disappeared
(Figure 7), while the UV bands from 250 to 350 nm were only slightly modified. This is consistent with a metal-
centred oxidation and the assignment of the long-wavelength bands of the parent complex at 370 and 450 nm to
pronounced MLCT bands and with the TD-DFT calculations (Section 3.3). Oxidation depletes the metal HOMO
by one electron, thus decreasing and blue-shifting the MLCT band.
4. Conclusions and outlook
Remarkable differences in the electronic properties were found for four new Pd(II) and Pt(II) complexes
[M(C^N^N)Cl] containing tridentate cyclometalating C(phen-ide)^N(py)^N(thiazole) ligands. The variation of
the central pyridine (py) to 3,5-(bis-tBu)phenylpyridine (tbppy) for the same central metal (Pd or Pt) resulted in
only marginal changes in the ligand-centred reductions, while changing from Pd to Pt led to a small anodic shift
of about 50 mV consistent with the largely ligand-centred lowest unoccupied molecular orbitals (LUMO)
resulting from DFT calculations. The oxidation potentials are again not very different when varying the ligand
but showed a cathodic shift of about 200 mV - 300 mV when going from Pd to Pt. This is consistent with high
metal contributions to the highest occupied molecular orbital (HOMO) and was confirmed through DFT.
Consquently, the electrochemical HOMO-LUMO gap is decreased from 2.58 eV (Pd) to 2.32 eV (Pt). The long-
wavelength absorptions are blue-shifted for the Pd complexes compared with the Pt derivatives consistent with
an enlarged HOMO-LUMO gap and thus in line with the electrochemical results. At ambient temperature the
15

two Pt complexes showed photoluminescence with broad unstructured bands centring at 600 nm. At 77 K in
glassy frozen CH2Cl2/MeOH all four complexes were luminescent with broad bands showing pronounced
vibrational progression. The emission energies of the Pd complexes are markedly blue-shifted compared with the
Pt derivatives. TD-DFT calculations were able to confirm this blue-shift for both absorption and emission and
showed that this shift goes along with a decreased MLCT contribution and an increased LLCT contribution for
the Pd complexes compared with the Pt derivatives. UV-vis absorption spectroelectrochchemistry strongly
support the assignments of ligand-centred reductions and a pronounce MLCT contribution to the long-
wavelenght absorption bands.
Acknowledgements
The Deutsche Forschungsgemeinschaft [DFG Priority Programme 2102 “Light-controlled Reactivity of Metal
Complexes”] DO 768/5-1, STR 1186/6-1, and KL1194/16-1 is acknowledged for funding of this project. We also like
to thank Prof. Dr. Mathias Schäfer, Department of Chemistry, University of Cologne for HR-ESI-MS
measurements and the Regional Computing Center of the University of Cologne (RRZK) for providing
computing time on the DFG-funded High Performance Computing (HPC) system CHEOPS as well as for the
support. Simon Schmitz, University of Cologne is acknowledged for the re-refinement of the crystal structures.
Furthermore, computer time at the HPC cluster PALMA II at WWU is gratefully acknowledged. CAS would like
to acknowledge the Cluster of Excellence Cells in Motion (DFG EXC 1003) for financial support.
Appendix A. Supplementary data
CCDC-2006642 for [Pd(ph(py)tz)Cl] contains the full crystallographic data for this paper. These data can be
obtained
free
of
charge
from
The
Cambridge
Crystallographic
Data
Centre
via
www.ccdc.cam.ac.uk/data_request/cif.
Appendix A. Supplementary data
Tables containing complete crystallographic and structural data were provided together with figures showing the
crystal and molecular structure of [Pd(ph(py)tz)Cl]. NMR, UV-vis absorption and cyclic voltammogramms of all
four complexes and the two protoligands were provided with data compiled in tables. Emission spectra with
time-resolved luminescence decay and DFT calculated LUMO and HOMO compositions were also available.
Supplementary data related to this article can be found at http://dx.doi.org/...
16

References
[1] J.A.G. Williams, S. Develay, D.L. Rochester, L. Murphy, Optimising the luminescence of platinum(II)
complexes and their application in organic light emitting devices (OLEDs), Coord. Chem. Rev. 252 (2008) 2596–
2611.
[2] J.A.G. Williams, The coordination chemistry of dipyridylbenzene: N-deficient terpyridine or panacea for
brightly luminescent metal complexes?, Chem. Soc. Rev. 38 (2009) 1783–1801.
[3] H. Yersin, A.F. Rausch, R. Czerwieniec, T. Hofbeck, T. Fischer, The triplet state of organo-transition metal
compounds. Triplet harvesting and singlet harvesting for efficient OLEDs, Coord. Chem. Rev. 255 (2011) 2622–
2652.
6
8
10
[4] V.W.-W. Yam, K.M.-C. Wong, Luminescent metal complexes of d , d and d transition metal centres, Chem.
Commun. 47 (2011) 11579–11592.
[5] S. Archer, J.A. Weinstein, Charge-separated excited states in platinum(II) chromophores: Photophysics,
formation, stabilization and utilization in solar energy conversion, Coord. Chem. Rev. 256 (2012) 2530–2561.
[6] P.K. Chow, C. Ma, W.-P. To, G.S.M. Tong, S.-L. Lai, S.C.F. Kui, W.-M. Kwok, C.-M. Che, Strongly
Phosphorescent Palladium(II) Complexes of Tetradentate Ligands with Mixed Oxygen, Carbon, and Nitrogen
Donor Atoms: Photophysics, Photochemistry, and Applications, Angew. Chem., Int. Ed. 52 (2013) 11775 –11779.
[7] J. Zhao, W. Wu, J. Sun, S. Guo, Triplet photosensitizers: from molecular design to applications, Chem. Soc.
Rev. 42 (2013) 5323‒5351.
[8] K. Li, G.S.M. Tong, Q. Wan, G. Cheng, W.-Y. Tong, W.-H. Ang, W.-L. Kwong, C.-M. Che, Highly
phosphorescent platinum(II) emitters: photophysics, materials and biological application, Chem. Sci. 7 (2016)
1653–1673.
[9] P.-K. Chow, G. Cheng, G.S.M. Tong, C. Ma, W.-M. Kwok, W.-H. Ang, C.Y.-S. Chung, C. Yang, F. Wang, C.-M.
Che, Highly luminescent palladium(II) complexes with sub-millisecond blue to green phosphorescent excited
states. Photocatalysis and highly efficient PSF-OLEDs, Chem. Sci. 7 (2016) 6083–6098.
II
[10] M. Krause, D. Kourkoulos, D. González-Abradelo, K. Meerholz, C. A. Strassert, A. Klein, Luminescent Pt
Complexes of Tridentate Cyclometalating 2,5-Bis(aryl)-pyridine Ligands, Eur. J. Inorg. Chem. 2017 (2017) 5215–
5223.
[11] T. Fleetham, G. Li, J. Li, Phosphorescent Pt(II) and Pd(II) Complexes for Efficient, High-Color-Quality, and
Stable OLEDs, Adv. Mater. 29 (2017) 1601861 (1‒16).
[12] Y. Zhang, Y. Wang, J. Song, J. Qu, B. Li, W. Zhu, W-Y. Wong, Near-Infrared Emitting Materials via
Harvesting Triplet Excitons: Molecular Design, Properties, and Application in Organic Light Emitting Diodes,
Adv. Optical Mater. 6 (2018) 1800466 (1‒19).
[13] C. Zou, J. Lin, S. Suo, M. Xie, X. Chang, W. Lu, Palladium(II) N-heterocyclic allenylidene complexes with
...
extended intercationic Pd Pd interactions and MMLCT phosphorescence, Chem. Commun. 54 (2018) 5319‒5322.
17

[14] Q. Wan, W.-P. To, C. Yang, C.-M. Che, The Metal–Metal-to-Ligand Charge Transfer Excited State and
II
Supramolecular Polymerization of Luminescent Pincer Pd –Isocyanide Complexes, Angew. Chem., Int. Ed. 57
(2018) 3089–3093.
[15] L. Liu, X. Wang, F. Hussain, C. Zeng, B. Wang, Z. Li, I. Kozin, S. Wang, Multiresponsive Tetradentate
Phosphorescent Metal Complexes as Highly Sensitive and Robust Luminescent Oxygen Sensors: Pd(II) Versus
Pt(II) and 1,2,3-Triazolyl Versus 1,2,4-Triazolyl, ACS Appl. Mater. Interfaces 11 (2019) 12666−12674
[16] Y. Yao, C.-L. Hou, Z.-S. Yang, G. Ran, L. Kang, C. Li, W. Zhang, J. Zhang, J.-L. Zhang, Unusual near infrared
(NIR) fluorescent palladium(II) macrocyclic complexes containing M–C bonds with bioimaging capability, Chem.
Sci. 10 (2019) 10170–10178.
[17] X. Wang, S. Wang, Phosphorescent Pt(II) Emitters for OLEDs: From Triarylboron-Functionalized Bidentate
Complexes to Compounds with Macrocyclic Chelating Ligands, Chem. Rec. 19 (2019) 1–18.
[18] G. Cheng, Y. Kwak, W.-P. To, T.-L. Lam, G.S.M. Tong, M.-K. Sit, S. Gong, B. Choi, W.i. Choi, C. Yang, C.-M.
Che, High-Efficiency Solution-Processed Organic Light-Emitting Diodes with Tetradentate Platinum(II) Emitters,
ACS Appl. Mater. Interfaces 11 (2019) 45161−45170.
[19] I.O. Koshevoy, M. Krause, A. Klein, Non-Covalent Intramolecular Interactions through Ligand-Design
Promoting Efficient Luminescence from Transition Metal Complexes, Coord. Chem. Rev. 405 (2020) 213094 (1‒
17).
8
[20] V.W.-W. Yam, A.S.-Y. Law, Luminescent d metal complexes of platinum(II) and gold(III): From
photophysics to photofunctional materials and probes, Coord. Chem. Rev. 414 (2020) 213‒298.
[21] J. Föller, D.H. Friese, S. Riese, J.M. Kaminski, S. Metz, D. Schmidt, F. Würthner, C. Lambert, C.M. Marian,
III
II
II
On the photophysical properties of Ir , Pt , and Pd (phenylpyrazole) (phenyldipyrrin) complexes, Phys. Chem.
Chem. Phys. 22 (2020) 3217‒3233.
[22] A. Heil, C.M. Marian, Structure−Emission Property Relationships in Cyclometalated Pt(II) β‑Diketonate
Complexes, Inorg. Chem. 58 (2019) 6123−6136.
[23] Y. Luo, Z. Chen, J. Hu, Z. Xu, Q. Meng, D. Tang, Small substituent groups as geometric controllers for
tridentate platinum(II) complexes to effectively suppress non-radiative decay processes, Phys. Chem. Chem.
Phys. 21 (2019) 2764‒2770.
[24] W. Cai, H. Zhang, X. Yan, A. Zhao, R. He, M. Li, Q. Meng, W. Shen, What accounts for the color purity of
tetradentate Pt complexes? A computational analysis, Phys. Chem. Chem. Phys. 21 (2019) 8073‒8080.
[25] Y.-T. Liu, Y.-R. Li, X. Wang, F.-Q. Bai, Theoretical investigation of N^C^N-coordinated Pt(II) and Pd(II)
complexes for long-lived two-photon photodynamic therapy, Dyes Pigm. 142 (2017) 55‒61.
[26] T.-T. Feng, F.-Q. Bai, L.-M. Xie, Y. Tang, H.-X. Zhang, Theoretical study and design of highly efficient
platinum(II) complexes bearing tetradentate ligands for OLED, RSC Adv. 6 (2016) 11648–11656.
[27] J. Sanning, L. Stegemann, P.R. Ewen, C. Schwermann, C.G. Daniliuc, D. Zhang, N. Lin, L. Duan, D. Wegner,
N.L. Doltsinis, C.A. Strassert, Colour-tunable asymmetric cyclometalated Pt(II) complexes and STM-assisted
stability assessment of ancillary ligands for OLEDs, J. Mater. Chem. C 4 (2016) 2560‒2565.
18

[28] L. Wang, J. Wen, H. He, J. Zhang, The reasons for ligand-dependent quantum yields and spectroscopic
properties of platinum(II) complexes based on tetradentate O^N^C^N ligands: a DFT and TD-DFT study, Dalton
Trans. 43 (2014) 2849–2858.
[29] S.C.F. Kui, F.-F. Hung, S.-L. Lai, M.-Y. Yuen, C.-C. Kwok, K.-H. Low, S.S.-Y. Chui, C.-M. Che, Luminescent
Organoplatinum(II) Complexes with Functionalized Cyclometalated C^N^C Ligands: Structures, Photophysical
Properties, and Material Applications, Chem.‒Eur. J. 18 (2012) 96–109.
[30] L. Wang, Y. Zhang, J. Li, H. He, J. Zhang, Influence of primary and auxiliary ligand on spectroscopic
properties and luminescent efficiency of organoplatinum(II) complexes bearing functionalized cyclometalated
C^N^C ligands, Dalton Trans. 43 (2014) 14029–14038.
[31] G. S.-M. Tong, C.-M. Che, Emissive or Nonemissive? A Theoretical Analysis of the Phosphorescence
Efficiencies of Cyclometalated Platinum(II) Complexes, Chem.‒Eur. J. 15 (2009) 7225–7237.
[32] Z. Wu, T. Xie, Y. Luo, W. Zhuo, J. Gu, X. Yan, X. Sun, K. Zuo, X. Liu, Y. Gan, L. Liang, G. He, W. Liu, X. Gou,
D. Tang, H. Shi, J. Hu, Theoretical insight into the photodeactivation pathway of the tetradentate Pt (II) complex
with different inductive substituents, Appl. Organometal. Chem. 33 (2019) e4879 (1‒12).
[33] S. Poirier, H. Lynn, C. Reber, Variation of M···H−C Interactions in Square-Planar Complexes of Nickel(II),
Palladium(II), and Platinum(II) Probed by Luminescence Spectroscopy and X‑ray Diffraction at Variable
Pressure, Inorg. Chem. 57 (2018) 7713−7723.
[34] S.S. Attar, F. Artizzu, L. Marchik, D. Espa, L. Pilia, M.F. Casula, A. Serpe, M. Pizzotti, A. Orbelli-Biroli, P.
II
Deplano, Uncommon Optical Properties and Silver-Responsive Turn-Off/On Luminescence in a Pt Heteroleptic
Dithiolene Complex, Chem.–Eur. J. 24 (2018) 10503–10512.
1
[35] A.M. Potocny, A.J. Pistner, G.P.A. Yap, J. Rosenthal, Electrochemical, Spectroscopic, and O2 Sensitization
Characteristics of Synthetically Accessible Linear Tetrapyrrole Complexes of Palladium and Platinum, Inorg.
Chem. 56 (2017) 12703−12711.
[36] P. Kar, M. Yoshida, A. Kobayashi, L. Routaboul, P. Braunstein, M. Kato, Colour tuning by the stepwise
synthesis of mononuclear and homo- and hetero-dinuclear platinum(II) complexes using a zwitterionic
quinonoid ligand, Dalton Trans. 45 (2016) 14080–14088.
[37] E.A. Katlenok, K.P. Balashev, Optical and Electrochemical Properties of Cyclometalated Pd(II) and Pt(II)
Complexes with a Metal–Metal Chemical Bond, Opt. Spectrosc. 116 (2014) 100–104.
[38] E.A. Katlenok, K.P. Balashev, Optical, Spectroscopic, and Electrochemical Properties of Cyclometalated
Complexes of Platinum Metals Based on 2-Tolylpyridine and Benzo[h]quinoline in Ethylenediamine, Opt.
Spectrosc. 115 (2013) 518–522.
[39] M.M. Nevdakh, M.V. Puzyk, Specific Features of Spectra of Cyclometalated Pt(II) and Pd(II) Complexes in
Polyvinyl Alcohol, Opt. Spectrosc. 96 (2004) 816–818.
[40] M.V. Puzyk, M.A. Ivanov, K.P. Balashev, Effect of the Nature of Heterocyclic Ligands on Spectral and
Luminescent Properties of Pt(II) and Pd(II) Complexes, Opt. Spectrosc. 95 (2003) 581–584.
19

[41] D. Song, Q. Wu, A. Hook, I. Kozin, S. Wang, Syntheses and Structures of New Luminescent Cyclometalated
Palladium(II) and Platinum(II) Complexes: M(Bab)Cl, M(Br-Bab)Cl (M = Pd(II), Pt(II)), and Pd3Cl4(Tab)2 (Bab =
1,3-bis(7-azaindolyl)phenyl, Br-Bab = 1-Bromo-3,5-bis(7-azaindolyl)phenyl, Tab = 1,3,5-tris(7-azaindolyl)phenyl),
Organometallics 20 (2001) 4683‒4689.
[42] S.-W. Lai, T.-C. Cheung, M. C. W. Chan, K.-K. Cheung, S.-M. Peng, C.-M. Che, Luminescent Mononuclear
and Binuclear Cyclometalated Palladium(II) Complexes of 6-Phenyl-2,2’-bipyridines: Spectroscopic and
Structural Comparisons with Platinum(II) Analogues, Inorg. Chem. 39 (2000) 255‒262.
[43] P. Jolliet, M. Gianini, A. von Zelewsky, G. Bernardinelli, H. Stoeckli-Evans, Cyclometalated Complexes of
Palladium(II) and Platinum(II): cis-Configured Homoleptic and Heteroleptic Compounds with Aromatic CN
Ligands, Inorg. Chem. 35 (1996) 4883‒4888.
[44] P.P. Phadnis, V.K. Jain, T. Schurr, A. Klein, F. Lissner, Th. Schleid, W. Kaim, Synthesis, spectroscopy,
structure and photophysical properties of dinaphthylmethylarsine complexes of palladium(II) and platinum(II),
Inorg. Chim. Acta 358 (2005) 2609−2617.
[45] S. Dey, L.B. Kumbhare, V.K. Jain, A. Klein, T. Schurr, W. Kaim, F. Belaj, Structural Varieties in 1-
Dimethylaminopropyl-2-chalcogenolate and 2-Dimethylaminopropyl-1-chalcogenolate (S, Se, Te) Complexes of
Palladium(II) and Platinum(II): Synthesis, Spectroscopy and Structures, Eur. J. Inorg. Chem. 2004 (2004)
4510−4520.
[46] P.P. Phadnis, V.K. Jain, A. Klein, M. Weber, W. Kaim, Configurational selectivity in benzyldimethylarsine
complexes of palladium(II) and platinum(II): Synthesis, spectroscopy and structures, Inorg. Chim. Acta 346 (2003)
119−128.
[47] F. Neve, A. Crispini, S. Campagna, Anisometric Cyclometalated Palladium(II) and Platinum(II) Complexes.
Structural and Photophysical Studies, Inorg. Chem. 36 (1997) 6150‒6156.
[48] W. Kaim. J. Fiedler, J. Spectroelectrochemistry: the best of two worlds, Chem. Soc. Rev. 38 (2009) 3373–3382.
[49] W. Kaim, A. Klein, Spectroelectrochemistry, Cambridge, UK, RSC Publishing, 2008.
[50] M.C. Burla, R. Caliandro, B. Carrozzini, G.L. Cascarano, C. Cuocci, C. Giacovazzo, M. Mallamo, A. Mazzone,
G. Polidori, G. Crystal structure determination and refinement via SIR2014, J. Appl. Crystallogr. 48 (2015) 306‒
309.
[51] G.M. Sheldrick, SHELXL 2016. A short history of SHELX, Acta Crystallogr., Sect. A: Found. Crystallogr. 64
(2008) 112‒122.
[52] M.J. Frisch, G.W. Trucks, H.B. Schlegel, G.E. Scuseria, M.A. Robb, J.R. Cheeseman, G. Scalmani, V. Barone, B.
Mennucci, G.A. Petersson, et al. Gaussian 09, Revision D.01. 2009; Gaussian Inc. Wallingford CT 2009.
[53] T. Yanai, D.P. Tew, N.C. Handy, A new hybrid exchange−correlation functional using the Coulomb-
attenuating method (CAM-B3LYP), Chem. Phys. Lett. 293 (2004) 51−57.
[54] S. Grimme, S. Ehrlich, L. Goerigk, Effect of the damping function in dispersion corrected density functional
theory, J. Comp. Chem. 32 (2011) 1456‒1465,
20

[55] D. Andrae, U. Häußermann, M. Dolg, H. Stoll, H. Preuß, Energy-adjusted ab initio pseudopotentials for the
second and third row transition elements, Theor. Chim. Acta 77 (1990) 123–141.
[56] T.H. Dunning, P.J. Hay, in H.F. Schaefer III (ed.), Modern Theoretical Chemistry; Plenum, New York, 1976;
Vol. 3, pp. 1–28.
[57] V. Barone, J. Bloino, M. Biczysko, Vibrationally-resolved electronic spectra in GAUSSIAN 09, GAUSSIAN 09
Revision A.02 (2009) 1–20.
[58] V. Barone, J. Bloino, M. Biczysko, F. Santoro, Fully Integrated Approach to Compute Vibrationally Resolved
Optical Spectra: From Small Molecules to Macrosystems, J. Chem. Theory Comput. 5 (2009) 540–554.
[59] J. Tomasi, B. Mennucci, R. Cammi, Quantum Mechanical Continuum Solvation Models, Chem. Rev. 105
(2005) 2999–3094.
[60] A. K. Rappé, C. J. Casewit, K. S. Colwell, W. A. Goddard III, W. M. Skiff, UFF, a Full Periodic Table Force
Field for Molecular Mechanics and Molecular Dynamics Simulations, J. Am. Chem. Soc. 114 (1992) 10024–10035.
[61] C. Adamo, V. Barone, Toward reliable density functional methods without adjustable parameters: The PBE0
model, J. Chem. Phys. (1999) 6158–6170.
[62] G.-J. Zhang, X. Gan, Q.-Q. Xu, Y. Chen, X.-J. Zhao, B. Qin, X.-J Lv, S.-W. Lai, W.-F. Fu, C.-M. Che,
Photophysical and electrochemical properties of platinum(II) complexes bearing a chromophore–acceptor dyad
and their photocatalytic hydrogen Evolution, Dalton Trans. 41 (2012) 8421–8429.
[63] M.-Y. Yuen, S.C.F. Kui, K.-H. Low, C.-C. Kwok, S.S.-Y. Chui, C.-W. Ma, N. Zhu, C.-M. Che Synthesis,
Photophysical and Electrophosphorescent Properties of Fluorene-Based Platinum(II) Complexes, Chem.‒Eur. J.
16 (2010) 14131–14141.
[64] M. Zvirzdinaite, S. Garbe, N. Arefyeva, M. Krause, R. von der Stück, A. Klein, Palladium(II) Complexes of
Ambidentate and Potentially Cyclometalating 5-Aryl-3-(2′-pyridyl)-1,2,4-triazine Ligands, Eur. J. Inorg. Chem.
2017 (2017) 2011–2022.
[65] V. Lingen, A. Lüning, C. Strauß, I. Pantenburg, G.B. Deacon, A. Klein, G. Meyer, Palladium Complexes with
the SC6F4H-4 Ligand – Synthesis, Spectroscopy, and Structures, Eur. J. Inorg. Chem. 2013 (2013) 4450–4458.
[66] K. Butsch, R. Gust, A. Klein, I. Ott, M. Romanski, Tuning the electronic properties of dppz-ligands and their
palladium(II) Complexes, Dalton Trans. 39 (2010) 4331–4340.
[67] A. Klein, M. Niemeyer, Synthesis, Coordination, and Spectroscopic Properties of 2,2'-
Bipyridyldimesitylpalladium(II) and 6-Mesityl-2,2'-bipyridyldimesitylpalladium(II), Z. Anorg. Allg. Chem. 626
(2000) 1191‒1195.
[67] T.-C. Cheung, K.-K. Cheung, S.-M. Peng, C.-M. Che, Photoluminescent cyclometallated diplatinum(II,II)
complexes: photophysical properties and crystal structures of [PtL(PPh3)]ClO4 and [Pt2L2(µ-dppm)][ClO4] (HL =
6-phenyl-2,2'-bipyridine, dppm = Ph2PCH2PPh2), J. Chem. Soc., Dalton Trans. (1996) 1645‒1651.
[68] F. Neve, A. Crispini, C. Di Pietro, S. Campagna, Light-Emitting Cyclopalladated Complexes of 6-Phenyl-2,2’-
bipyridines with Hydrogen-Bonding Functionality, Organometallics 21 (2002) 3511‒3518.
21

[69] F. Plasser, TheoDORE: A Toolbox for a Detailed and Automated Analysis of Electronic Excited State
Computations, J. Chem. Phys. 152 (2020) 084108 (1‒14).
Highlights:



Cyclometalated Pd(II) and Pt(II) complexes with tridentate C^N^N ligands (C = phenyl, N = pyridyl; N =
thiazol) were studied for their electronic properties in comparison
Pt(II) complexes showed orange photoluminescence at 298 K, while for Pd(II) emission is observed at 77
K. At 77 K, Pt(II) and Pd(II) complexes show similar quantum yields around 20%.
Quantum chemical TD-DFT allowed to trace these differences to different contributions of the three
ligand parts and higher 3IL character for Pd(II) compared with higher 3MLCT character for Pt(II).
Maren Krause: Investigation, Data curation, Visualisation. Rene von der Stück: Investigation, Data
curation, Visualisation. Dana Brünkink: Investigation, Data curation, Visualisation. Stefan Buss:
Investigation, Data curation, Visualisation. Nikos L. Doltsinis: Methodology, Validation, Writing-
Original draft preparation, Writing - Review & Editing, Supervision, Project Administration, Funding
acquisition. Cristian A. Strassert: Methodology, Validation, Formal analysis, Writing- Original draft
preparation, Writing - Review & Editing, Supervision, Project Administration, Funding acquisition.
Axel Klein: Methodology, Validation, Visualisation, Writing- Original draft preparation, Writing -
Review & Editing, Supervision, Project Administration, Funding acquisition.
22
