Highly stereoselective synthesis of (2R,3R)-2-amino-3-cyclohexyl-3-hydroxypropionic acid using asymmetric hydrogenation

Article abstract of DOI:10.3987/COM-08-S(F)46

(2R,3R)-2-Amino-3-cyclohexyl-3-hydroxypropionic acid, a β-hydroxy-α-amino acid in a new CCR5 antagonist, was efficiently synthesized by the Noyori asymmetric hydrogenation of α-benzoylamino-β-keto ester (6) and intramolecular S_N2-type inversion as the key steps.

Full text of DOI:10.3987/COM-08-S(F)46

HETEROCYCLES, Vol. 77, No. 1, 2009
629
HETEROCYCLES, Vol. 77, No. 1, 2009, pp. 629 - 634. © The Japan Institute of Heterocyclic Chemistry
Received, 17th July, 2008, Accepted, 18th August, 2008, Published online, 21st August, 2008.
DOI: 10.3987/COM-08-S(F)46
HIGHLY
STEREOSELECTIVE
SYNYHESIS
OF
(2R,3R)-2-AMINO-3-CYCLOHEXYL-3-HYDROXYPROPIONIC
ACID
USING ASYMMETRIC HYDROGENATION†
Kazuishi Makino, Takayuki Goto, Junpei Ohtaka, and Yasumasa Hamada*
Graduate School of Pharmaceutical Sciences, Chiba University, Yayoi-cho,
Inage-ku, Chiba 263-8522, Japan. E-mail address : hamada@p.chiba-u.ac.jp
Abstract
(2R,3R)-2-Amino-3-cyclohexyl-3-hydroxypropionic
acid,
a
β-hydroxy-α-amino acid in a new CCR5 antagonist, was efficiently synthesized
by the Noyori asymmetric hydrogenation of α-benzoylamino-β-keto ester (6) and
intramolecular SN2-type inversion as the key steps.
INTRODUCTION
(2R,3R)-2-Amino-3-cyclohexyl-3-hydroxypropionic acid is a chiral core of a new CCR5 antagonist
(ONO-4128/GW873140) as shown in Figure 1. The CCR5 antagonist has attracted attention as a new
agent for the anti-HIV chemotherapy.1 In the course of our studies on the synthesis of natural
cyclodepsipeptides, we have demonstrated the development of enantio- and diastereoselective synthesis
of β-hydroxy-α-amino acids.2,3 Using this methodology, we succeeded in stereoselective and concise
synthesis of the (2R,3R)-2-amino-3-cyclohexyl-3-hydroxypropionic acid.2a We report here an alternative
approach for the synthesis of
O
(2R,3R)-2-amino-3-cyclohex
O
N
OH
yl-3-hydroxypropionic acid
using the Noyori’s
NH2
HN
O
OH
N
asymmetric hydrogenation
through dynamic kinetic
resolution.4,5
OH
O
OH
O
1
ONO-4128/GW873140
Figure 1. (2R,3R)-2-Amino-3-cyclohexyl-3-hydroxypropionic acid
† This paper is dedicated to Professor Emeritus Keiichiro Fukumoto on the occasion of his 75th birthday.

630
HETEROCYCLES, Vol. 77, No. 1, 2009
RESULTS AND DISCUSSION
CNCH2CO2Me
CO2Me
O
OH
DBU (1 eq)
DMF, 23°C, 11 h
N
O
O
O
O
2
3
4
NH2•HOTs
OMe
NHCOPh
OMe
TsOH
PhCOCl
MeOH, reflux, 18 h
Et3N, THF
O
O
O
O
6
5
(A) SOCl2, THF
60°C, 10 h
H2 (100 atm)
(S)-BINAP-Ru (0.5 mol%)
NHCOPh
OMe
HCl (1 mol%), CH2Cl2
55°C, 48 h
(B) MeO2CSO2NEt3
THF, 70°C, 3 h
OH
O
7
NHCOPh
OMe
NH2
OH
CO2Me
6 M HCl (0.025 M)
reflux 9.5 h
N
O
Cl
O
OH
O
Ph
9
1
8
Scheme 1. Synthesis of (2R,3R)-2-Amino-3-cyclohexyl-3-hydroxypropionic acid
Synthesis of the required substrate, an α-amino-β-keto ester, commenced with preparation of
cyclohexanecarboxylic anhydride. Treatment of the obtained anhydride with methyl isocyanoacetate in
the presence of diazabicyclo[4.3.0]undecene (DBU) afforded oxazole (4) in 80% yield. Acid-catalyzed
cleavage of 4 with p-toluenesulfonic acid (TsOH) proceeded cleanly under reflux in methanol to give
α-amino-β-keto ester (5) in quantitative yield.6 Protection of 5 using benzoyl chloride and triethylamine
in
tetrahydrofuran
(THF)
at
the
nitrogen
function
provided
methyl
2-benzoylamino-3-cyclohexyl-3-oxopropionate (6) in 86% yield in two steps. The key hydrogenation of 6
using RuCl2((S)-binap)7 (0.5 mol%) in the presence of hydrogen chloride (1 mol%) in methylene chloride
was found to be sluggish and required higher temperature. Finally, the reaction at 55 °C for 48 h gave the
(2R, 3S)-2-N-benzoylamino-3-cyclohexyl-3-hydroxypropionic acid methyl ester ((-)-7) in 95% yield. The

HETEROCYCLES, Vol. 77, No. 1, 2009
631
enantiomeric excess (ee) of 7 was shown to be 98% ee by HPLC analysis using a chiral column. The
absolute stereostructure of 7 was unambiguously determined by comparison with authentic sample.2a The
product 7 has 2,3-syn stereochemistry and can be convert to the desired 2,3-anti-β-hydroxy-α-amino acid
using an intramolecular SN2-type inversion. Thus, the SN2-type inversion of the C(3) stereochemistry of
(-)-7 was carried out but, compared with that of the isopropyl counterpart,6a was unexpectedly sluggish
and difficult due to generating the side product 9.8 Finally, the reaction by treatment with thionyl chloride
in THF at 0 °C and then heating to 60 °C for 10 h furnished the cis-oxazoline ((-)-8) with
(2R,3R)-stereochemistry in 60% yield. In order to prevent the formation of the byproduct, we examined
several alternative approachs for this cyclization. Among them, only the Burgess reagent9 in THF at 70°C
for 3 h afforded a comparable result. The thus obtained (-)-8 was hydrolyzed with 6 M hydrochloric acid
under reflux to afford (2R,3R)-2-amino-3-cyclohexyl-3-hydroxypropionic acid ((-)-1) in 85% yield. The
overall yield of (-)-1 are 38% yield from 3.
The above reaction sequences comprise a facile synthesis of (2R,3R)-2-amino-3-cyclohexyl-3-
hydroxypropionic acid in seven steps with a good overall yield, which is comparable with that of the
reported method.2a
EXPERIMENTAL
Melting points are uncorrected. IR spectra were recorded on a JASCO FT/IR-230 spectrometer. NMR
spectra were recorded on JEOL JNM GSX400A, JNM GSX500A, and JNM ECP400 spectrometers. FAB
mass spectra were obtained with a JEOL JMS-HX-110A spectrometer. Optical rotations were determined
on a JASCO DIP-140 polarimeter. Column Chromatography was carried out with silica gel BW-820MH
(Fuji silysia).
Cyclohexanecarboxylic anhydride
To a stirred solution of cyclohexanecarboxylic acid (53.6 g, 0.418 mol) and triethylamine (58.3 mL, 0.418
mol) in THF (418 mL) at 0 °C was added dropwise cyclohexanecarboxylic acid chloride (56 mL, 0.419
mol) and the reaction mixture was stirred at 23 °C for 24 h. After removal of the precipitates by filtration
using Celite, the filtrate was diluted with Et2O (1 L), washed with 5 % aqueous sodium hydrogen
carbonate and saturated brine, dried over sodium sulfate, and filtered. The filtrate was concentrated in
vacuo to give the anhydride (3, 102g, quant) as a colorless oil: IR (neat) 2933, 2669, 1811, 1740, 1450
cm-1; 1H NMR (400 MHz, CDCl3) δ 1.19-1.36 (4H, m), 1.43-1.67 (4H, m), 1.72-1.81 (6H, m), 1.93-1.98
(4H, m), 2.37-2.45 (2H, m); 13C NMR (100 MHz, CDCl3) δ 25.07, 28.31, 43.86, 67.83, 171.76.
5-Cyclohexyloxazole-4-carboxylic acid methyl ester (4)
To a stirred solution of 3 (8.20 g, 34.4 mmol) and methyl isocyanoacetate (3.11 g, 31.3 mmol) in DMF
(10 mL) at 0 °C was added dropwise DBU (4.68 mL, 31.3 mmol) and the reaction mixture was stirred at

632
HETEROCYCLES, Vol. 77, No. 1, 2009
23 °C for 11 h. The mixture was diluted with EtOAc/n-hexane (5/1, 48 mL), washed with saturated brine,
1M hydrochloric acid, saturated aqueous sodium hydrogen carbonate, and saturated brine, and dried over
sodium sulfate. After filtration, the filtrate was condensed in vacuo to give the crude oxazole (4, 7.22 g),
which was recrystallized from n-hexane/EtOAc to give pure 4 (5.0 g, 75 %): mp 97.5-101 °C; IR (KBr)
1
2931, 2852, 1719, 1599, 1199 cm-1; H NMR (400 MHz, CDCl3) δ 1.26-1.89 (10H, M), 3.45-3.48 (1H,
m), 3.91 (3H, s), 7.74 (1H, s); 13C NMR (100 MHz, CDCl3) δ 25.65, 25.93, 30.64, 35.42, 51.91, 125.23,
148.56, 162.64, 164.07; EI-LRMS 209 (M+). Anal. Calcd for C11H15NO3: C, 63.14; H, 7.23; N, 6.69.
Found: C, 62.92; H, 7.11; N, 6.52.
2-Benzoylamino-3-cyclohexyl-3-oxopropionic acid methyl ester (6)
To a stirred solution of 4 (3.94 g, 18.8 mmol) in MeOH (94 mL) at 23 °C was added in one portion
p-toluenesulfonic acid hydrate (8.95 g, 47 mmol) and the reaction mixture was heated at reflux for 18 h.
After cooling the mixture to rt, the mixture was concentrated in vacuo to give the white solids which were
triturated with Et2O and filtered. The obtained solids (8.64 g) were used as such for next reaction.
The above solids were suspended in THF (37.6 mL) and cooled to 0 °C. Benzoyl chloride (2.18 mL, 18.8
mmol) followed by triethylamine (7.86 mL, 56.4 mmol) were added dropwise. After stirring the mixture
at 23 °C for 12 h, the reaction mixture was diluted with water and a mixture of EtOAc and n-hexane (5/1)
and the mixture was separated. The organic layer was washed with 1M hydrochloric acid, water, saturated
aqueous sodium hydrogen carbonate, and saturated brine, dried over sodium sulfate, and filtered. The
filtrate was concentrated in vacuo to give the residue (5.47 g) as a yellow oil, which was
chromatographed on silica gel (n-hexane/EtOAc = 3/1) to afford the benzamide (6, 4.90 g, 86 %) as
colorless solids: IR (KBr) 3319, 1757, 1707, 1639 cm-1; 1H NMR (400 MHz, CDCl3) δ 1.21-2.09 (10 H,
m), 2.87-2.88 (1H, m), 3.84 (3H, s), 5.59 (1H, d, J = 6.6 Hz), 7.32 (1H, d, J = 5.6 Hz), 7.84-7.86 (2H, m);
13C NMR (100 MHz, CDCl3) δ 25.09, 25.59, 25.70, 27.80, 29.18, 48.56, 61.14, 127.25, 128.64, 132.08,
133.07, 166.70, 166.97, 204.09; EI-LRMS 303 (M+). Anal. Calcd for C17H21NO4: C, 67.31; H, 6.98; N,
4.62. Found: C, 67.12; H, 6.71; N, 4.53.
(2R, 3S)-2-Benzoylamino-3-cyclohexyl-3-hydroxypropionic acid methyl ester (7)
The (S)-BINAP-Ru catalyst was prepared from [RuCl2(C6H6)]2 (10.3 mg, 0.0206 mmol) and (S)-BINAP
(28.3 mg, 0.0453 mmol) according to the Noyori’s procedure.7 A degassed solution of N-benzoyl
α-amino-β-keto ester (6, 2.52 g, 8.31 mmol) in CH2Cl2 (5.1 mL) followed by 4 M HCl-dioxane (21.0 μL,
0.0840 mmol) was added via cannula to the obtained catalyst under an argon atmosphere. The reaction
mixture was hydrogenated under 100 atm of hydrogen at 55°C for 48 h in an autoclave. After releasing
the pressure and removal of volatiles, the residue was chromatographed on silica gel (n-hexane/EtOAc =
2/1) to give the amino acid (7, 2.41 g, 95 %) as a colorless oil, which was judged to be 98 % ee by HPLC
analysis (CHIRALCEL OD-H, n-hexane/i-PrOH = 85/15, flow rate = 0.5 mL/min, retention time: 10.5

HETEROCYCLES, Vol. 77, No. 1, 2009
633
min for 2R,3S-isomer, 17.6 min for 2S,3R-isomer). 7: [α]D24 -16.2 (c 1.18, CHCl3); IR (neat) 3446, 1735,
1
1654 cm-1; H NMR (400 MHz, CDCl3) δ 1.00-2.00 (1H, m), 2.12-2.13 (1H, m), 3.78 (3H, s), 3.79-3.93
13
(1H, m), 5.03 (1H, d, J = 9.3 Hz), 6.83 (1H, d, J = 9.3 Hz), 6.86-7.86 (5H, m); C NMR (100 MHz,
CDCl3) δ 25.66, 25.73, 26.13, 28.75, 29.19, 40.15, 52.65, 54.00, 127.20, 128.62, 131.84, 133.88, 167.53,
172.40. HRMS (FAB) calcd for C17H23NO4: 306.1706(M++1). Found: 306.1718.
(4R,5R)-5-Cyclohexyl-2-phenyl-4,5-dihydrooxazole-4-carboxylic acid methyl ester (9)
Mehod (A): To a cooled stirred solution of 7 (300 mg, 0.982 mmol) in THF (10 mL) at 0 °C was added
dropwise thionyl chloride (79μL, 1.08 mmol) and the mixture was heated to 60 °C for 10 h. After cooling
the mixture to 0 °C, the mixture was carefully quenched with saturated aqueous sodium hydrogen
carbonate. The whole was extracted with EtOAc and the organic layer was washed with water and
saturated brine. After filtration, the filtrate was concentrated in vacuo to give the residue, which was
chromatographed on silica gel (n-hexane/EtOAc = 4/1) to afford the cis-oxazoline (8, 169 mg, 60 %) as a
colorless oil along with the byproduct 9. 8: [α]D20 -75.4 (c 1, CHCl3); IR (neat) 2928, 1746, 1644 cm-1; 1H
NMR (400 MHz, CDCl3) δ 1.09-2.00 (1H, m), 3.79 (1H, m), 4.55 (1H, dd, J = 7.7, 9.7 Hz), 4.94 (1H, d, J
= 9.7 Hz), 7.40-7.53 (3H, m), 7.98-8.00 (2H, m); EI-LRMS 287 (M+); 13C NMR (CDCl3) δ 170.6, 166.6,
131.7, 128.4, 128.2, 127.2, 86.5, 70.4, 52.0, 38.8, 29.8, 28.9, 26.0, 25.7, 25.4. HRMS (FAB) calcd for
C17H21NO3: 288.1593(M++1). Found: 288.1605. The crude 9 was a ca.3:1 mixture of diastereomers and
was chromatographed on silica gel (n-hexane/EtOAc = 2/1) to give the major isomer as a colorless oil. 9
25
1
(major): [α]D -55.5 (c 1.1, CHCl3); IR (neat) 2926, 2853, 1603, 1580 cm-1; H NMR (CDCl3) δ
1.03-2.16 (11H, m), 3.80 (3H, s), 4.33 (1H, dd, J = 2.0 Hz, 9.6 Hz), 5.43 (1H, dd, J = 2.0 Hz, 9.8 Hz),
6.76 (1H, d, J = 10 Hz), 7.47-7.58 (3H, m), 7.82-7.86 (2H, m); 13C NMR (CDCl3) δ 170.6, 166.6, 131.7,
128.4, 128.2, 127.2, 86.5, 70.4, 52.0, 38.8, 29.8, 28.9, 26.0, 25.7, 25.4; HRMS (FAB) calcd for
C17H23ClNO3: 324.1366(M++1). Found: 324.1379.
Method (B): A mixture of 7 (59 mg, 0.193 mmol) and the Burgess reagent (110 mg, 0.46 mmol) in THF
(2.5 mL) was heated to 70 °C for 3 h. After cooling the mixture to rt, the residue was chromatographed on
silica gel (n-hexane/EtOAc = 4/1) to give the cis-oxazoline (9, 34 mg, 62 %) as a colorless oil.
(2R,3R)-2-Amino-3-cyclohexyl-3-hydroxypropionic acid (1)
6 M Aqueous hydrochloric acid (15 mL) was added to 9 (101.5 mg, 0.353 mmol) and the mixture was
heated at reflux for 9.5 h. After cooling the mixture to rt, the mixture was extracted with Et2O. The
aqueous layer was concentrated in vacuo to give the amino acid hydrochloride (1, 105 mg). This crude
hydrochloride was charged on Dowex 50W-X4 ion-exchange resin (20 mL, H+ form). The resin was
eluted with water and then 2 M pyridine aqueous solution. The combined aqueous pyridine fractions were
condensed in vacuo to give the pure amino acid (1, 68 mg, quant) as white powder. The analytical sample
was obtained by precipitation from aqueous MeOH.

634
HETEROCYCLES, Vol. 77, No. 1, 2009
mp 179-183 ℃ (decomp.); [α]D25 -38.1 (c 0.78, 1M HCl); IR (neat) 3342, 3316, 2919, 2849, 1601 cm-1;
1H NMR (D2O, 55 ℃) δ 1.03-2.16 (11H, m), 3.50 (1H, dd, J =3.2 Hz, 9.2 Hz), 3.81 (1H, d, J=3.2 Hz);
13C NMR (D2O, 55 ℃) δ 172.5, 75.8, 58.0, 40.4, 29.9, 29.7, 26.7, 26.2, 26.1. HRMS (FAB) calcd for
C9H18NO3: 188.1287 (M++1). Found: 188.1281.
ACKNOWLEDGEMENTS
This work was financially supported in part by a Grant-in-Aid for Scientific Research (B) from the
Ministry of Education, Culture, Sports, Science and Technology, Japan.
REFERENCES AND NOTES
1. (a) K. Maeda, H. Nakata, H. Ogata, Y. Koh, T. Miyakawa, and H. Mitsuya, Current Opinion in
Pharmacology, 2004, 4, 447. (b) K. Maeda, H. Nakata, Y. Koh, T. Miyakawa, H. Ogata, Y. Takaoka,
S. Shibayama, K. Sagawa, D. Fukushima, J. Moravek, Y. Koyanagi, and H. Mitsuya, J. Virol. 2004,
78, 8654.
2. (a) K. Makino, T. Goto, Y. Hiroki, and Y. Hamada, Angew. Chem. Int. Ed., 2004, 43, 882. (b) K.
Makino, T. Fujii, and Y. Hamada, Tetrahedron: Asymmetry, 2006, 17, 481. (c) K. Makino, Y. Hiroki,
and Y. Hamada, J. Am. Chem. Soc., 2005, 127, 5784. (d) K. Makino, M. Iwasaki, and Y. Hamada,
Org. Lett., 2006, 8, 4573.
3. For a review on synthesis of β-hydroxy-α-amino acids, see: K. Makino and Y. Hamada, J. Synth.
Org. Chem. Jpn, 2005, 63, 1198.
4. R. Noyori, T. Ikeda, T. Ohkuma, M. Widhalm, M. Kitamura, H. Takaya, S. Akutagawa, N. Sayo, T.
Saito, T. Taketomi, and H. Kumobayashi, J. Am. Chem. Soc., 1989, 111, 9134.
5. For reviews on dynamic kinetic resolution, see: (a) R. Noyori, M. Tokunaga, and M. Kitamura, Bull.
Chem. Soc. Jpn., 1995, 68, 36. (b) R. S. Ward, Tetrahedron: Asymmetry, 1995, 6, 1475. (c) H.
Pellissier, Tetrahedron, 2003, 59, 8291. (d) E. Vedejs and M. Jure, Angew. Chem. Int. Ed., 2005, 44,
3974.
6. (a) K. Makino, N. Okamoto, O. Hara, and Y. Hamada, Tetrahedron: Asymmetry, 2001, 12, 1757. (b)
O. Hara, M. Ito, and Y. Hamada, Tetrahedron Lett., 1998, 39, 5537.
7. M. Kitamura, M. Tokunaga, T. Ohkuma, and R. Noyori, Org. Synth., Coll. Vol. 9, 589 (1998).
8. This byproduct was obtained as a ca.3:1 mixture of diastereomers. See experimental.
9. P. Wipf and C. P. Miller, Tetrahedron Lett., 1992, 33, 907.
