Synthesis and characterization of a host (A new
thiol based dendritic polymer)ꢀguest (Pd
nanoparticles) nanocomposite material: An
efficient and reusable catalyst for C‒C coupling
reactions
sCite this: DOI: 10.1039/x0xx00000x
Received 00th January 2012,
Accepted 00th January 2012
DOI: 10.1039/x0xx00000x
Maryam Zakeri, Majid Moghadam,* Valiollah Mirkhani,* Shahram
Tangestaninejad, Iraj Mohammadpoor−Baltork, Zari Pahlevanneshan
www.rsc.org/
The catalytic activity of a new thiol based dendritic polymer immobilized on nano silica containing
palladium nanoparticles was studied in CꢀC coupling reactions. In this manner, functionalized
silica nanoparticles were reacted with 1,3,5ꢀbenzenetricarbonyl and then with 1,2ꢀethanedithiol.
Finally, this new dendritic material was used as host for carrying of Pd nanoparticles.
Thermogravimetric and elemental analyses are in a proper correlation and confirm the
successful synthesis of the dendritic polymer. The characterization of the catalyst by
transmission electron microscopy, EDX and elemental mapping, show a uniform dispersed,
nano−scaled Pd particles in denderimer's cavities and also on the surface functional groups. This
insoluble nanosilica thiolated dendritic polymerꢀsupported Pd nanoparticles, showed a set of
favorable properties to be used as a heterogeneous and reusable catalyst in the Suzuki−Miyaura
and Heck CꢀC coupling reactions.
for the encapsulated particles by different methods such as
covalent bond formation, electrostatic interactions, hydrogen
Introduction
Dendrimers are a group of nanosized, three dimensional
polymers and a class of macromolecules having highly
branched architecture.1 This family of polymers is considered as
bonding and etc.9,25
Palladium nanoparticles (Pd−NPs), consisting of only several or
tens of atoms, are novel catalytic materials, also have a number
one of the best synthetic molecules, which suggest perfect of other applications, including hydrogen storage,26 sensing,27
coatings, polymer membranes,28 and fuel cells.29
properties, such as high degree of branching units, high density
Pd nanoparticles are excellent catalysts for hydrogenation,30
of facial functional group, nanosized scale, internal cavities and
dehydrogenation31 and also coupling reactions such as
also high ability of monodispersion of metallic nanoparticles.2−5
Due to these specific characteristics, dendrimers have potential
applications in various high technologies, such as
pharmaceutical, biomedical and industrial uses.6, 7
Dendrimers are synthesized by stepwise growth from core to
first and second or maybe more generations,8 thus designing a
new dendrimer with new interior and surface functional groups
is a tricky and challenging issue. Dendrimer bearing higher
generations are almost spherical and the cavities inside the
dendrimers are approximately in the range of nanometer,9,
which can be used as a host for encapsulation of nanoparticles,
mostly transition metals, such as Pd,11−13 Cu,14−16 Au,17−19 Ag,20
Pt,21, 22 and Ru.23, 24
Multiple internal and external functional groups enable the
dendrimer to act as proper host for a various range of ions and
molecules. These functional groups can easily act as a stabilizer
Department of Chemistry, Catalysis Division, University of
Isfahan, Isfahan, 81746–73441 (Iran) Fax: +98–31–36689732;
Tel: +98–31–37934920. E–mail: moghadamm@sci.ui.ac.ir,
mirkhani@sci.ui.ac.ir
carbon−carbon,32 carbon−sulfur33 and carbon‒nitrogen.34
The recovery and reusability of this precious metal catalyst
represent a key issue for the sustainable development of any
catalytic applications. For this purpose, palladium nanoparticles
have been supported by a variety of conventional and
non−conventional
metal−organic frameworks,39 anthracene derivatives,40 ion
exchange and
resins,41 ligands,42 surfactants,43,44
supports,
such
as,
polymers,35−38
dendrimers.45,46 The strong interactions between the palladium
and soft sulfur based donors, make sulfur−containing supports
highly efficient stabilizers for nanoparticles.47−49 The size and
morphology of the resulting palladium nanoparticles depend on
several different reaction conditions. These conditions include
the surfactant used, the type and amount of reducing agent
employed, the reaction time and the properties of stabilizing
agent.50, 51
10
In continuation of our previous works on the application of
dendriticꢀbased catalysts in organic synthesis,11,14,52ꢀ57, here we
wish to report the synthesis of a host (a new thiol based
dendritic polymer)ꢀguest (Pd nanoparticles) nanocomposite
material and its application as catalyst for the Suzuki–Miyaura
and Heck CꢀC coupling reactions (Scheme 1).
This journal is © The Royal Society of Chemistry 2013
J. Name., 2013, 00, 1-3 | 1

RSC Advances
Page 2 of 13
VJieowuArrtnicalelONnlainme e
ARTICLE
DOI: 10.1039/C6RA16704G
was cooled to 0 °C and stirred overnight. The solid material was
filtered, washed overnight with hot tetrahydrofuran (THF) in a
Soxhlet extractor. Then dried in a vacuum oven at 60 °C.
Nano−Silica Supported Thiolated Dendritic Polymer (G1)
BCC1−nSiO2 (1 g) in dimethylformamide (DMF) (12 mL) was
treated with 1,2−ethanedithiol (8.11 mmol, 0.7 mL) and DIPEA
°
(8 mmol, 1.4 mL) at 80 C for 16 h. The solid material was
filtered and washed overnight with hot ethanol in a Soxhlet
extractor and dried in a vacuum oven at 60 °C.
Scheme 1. Suzuki–Miyaura cross−coupling and Heck reacꢀons catalyzed by Pdnp−nSTDP
BCC2−nSiO2
Experimental
G1 (1 g) was added slowly to
a
solution of
Materials and reagents
1,3,5−benzenetricarbonyl trichloride (2.4 g, 9 mmol) and
DIPEA (9 mmol, 1.55 mL) in THF (20 mL). The reaction
All commercially available reagent grade chemicals were
purchased from Merck, Fluka and Sigma–Aldrich. All reagents
and solvents were used without further purification. FT−IR
spectra were recorded on a Jasco 6300D instrument in the range
of 400–4000 cm−1. Thermal gravimetric analysis (TGA) was
recorded on a Mettler TG50, under air flow at a consistent
heating of 5 °C min−1 in the range of 0ꢀ600 °C. Elemental
analysis was obtained on LECO CHNS−932 analyzer. The
X−ray photo−electron spectroscopy (XPS) measurements were
performed on XPS–Auger Perkin Elmer 8025ꢀBesTec electron
°
mixture was cooled and stirred at 0 C for 16 h. The reaction
mixture was filtered and the solid was washed overnight with
hot THF in a Soxhlet extractor. The BCC2−nSiO2 was dried in
a vacuum oven at 60 °C.
Nano−Silica Supported Thiolated Dendritic Polymer (G2 or
nSTDP)
To a solution of BCC2−nSiO2 (1 g) in DMF (20 mL),
1,2−ethanedithiol (9.5 mmol, 0.8 mL) and DIPEA (9.5 mmol,
1.65 mL) were added slowly and the reaction mixture was
spectrometer, using
a
Gammadata−scienta ESCA200
hemispherical analyzer equipped with an Al (Kα = 1486.6 eV)
X−ray source. The Pd content of the catalyst was measured by
an inductively coupled plasma optical emission spectrometry
(ICP−OES), via a Jarrell−Ash 1100 ICP analyzer. Scanning
electron microscopy images were performed on a Hitachi
S−4700 field emission−scanning electron microscope
(FE−SEM). Transmission electron microscopy (TEM)
measurements were carried out on a Philips CM10 analyzer
operating at 100 kV. Substances were identified and quantified
by gas chromatography (GC) on an Agilent GC 6890 equipped
with a 19096C006 80/100 WHP packed column and a flame
ionization detector (FID). In GC experiments anisole was used
as internal standard.
°
stirred at 80 C for 16 h. The resulting nano−silica supported
dendritic polymer (G2 or nSTDP) was filtered and washed with
hot ethanol overnight in a Soxhlet extractor and dried in a
vacuum oven at 60 °C.
Nano−Silica Thiolated Dendritic Polymer Supported Palladium
Nanoparticles (Pdnp−nSTDP)
Initially, Na2PdCl4 solution was prepared by mixing and
dissolving of PdCl2 (240 mg, 1.36 mmol) and NaCl (176 mg, 3
mmol) in methanol (10 mL), under stirring at room temperature
for 24 h and then filtered. Methanol (40 mL) and nSTDP (1 g)
°
was added to this solution. The slurry was then stirred at 60 C
for 24 h. After cooling the mixture to room temperature,
sodium acetate (0.76 g, 9.28 mmol) was added and stirred for 1
h. The solid was filtered, washed with methanol, water and
acetone continuously, to remove the unreacted precursors, and
finally dried in vacuum and Pdnp−nSTDP catalyst (1.09 g) as a
dark brown solid was prepared. Palladium analysis (ICP): 0.14
mmol Pd/ g catalyst. Average particle diameter: 3.6 ± 0.5 nm
(based on TEM and particle size analyses).
The procedure for the preparation of nanosilica thiolated
dendritic polymerꢀsupported Pd particles (Pdnp−nSTDP) was as
follows:
Propylthiol−Functionalized Nano−Silica (PT−nSiO2)
(
3−Mercaptopropyl)trimethoxysilane (8.5 mL) was added
dropwise via a syringe to a stirred solution of activated nano‒
silica (3 g) in dried toluene (50 mL) under reflux conditions for
12 h. The reaction medium was cooled to room temperature and
filtered. The solid was washed overnight with dried toluene by
soxhlet extractor to remove the unreacted starting materials.
The white solid was dried in a vacuum oven at 110 °C.
Typical Procedure for Suzuki–Miyaura Cross−Coupling
Catalyzed by Pdnp−nSTDP
Aryl halide (1 mmol), phenylboronic acid (1.1 mmol), K2CO3
(1.5 mmol) and the Pdnp−nSTDP catalyst (5 mg, 0.07 mol%)
were added to 3 ml of DMF/H2O (2:1). The reaction mixture
was stirred at desired temperature under air atmosphere. The
results are summarized in Table 3. The yields were quantified
by GC analysis. After the end point, the solution was filtered
and the products were extracted with ethyl acetate (3×10 mL).
BCC1−nSiO2
To a solution of 1,3,5−benzenetricarbonyl trichloride (2.65 g,
10 mmol) and diisopropylethylamine (DIPEA) (10 mmol, 1.7
mL) in anhydrous THF (10 mL) was slowly added the
previously synthesized PT−nSiO2 (2 g).The reaction mixture
2 | J. Name., 2012, 00, 1-3
This journal is © The Royal Society of Chemistry 2012

Page 3 of 13
Journal Name
RSC Advances
View Article Online
ARTICLE
DOI: 10.1039/C6RA16704G
The organic phase was washed with water (2×10 mL), dried the characteristic bands for C─Haliph appear at 1450 and 2950
over anhydrous Na2SO4 and concentrated in vacuum to afford cm−1.11 In the FT−IR spectra of BCC1−nSiO2, G1,
the pure product.
BCC2−nSiO2 and G2 (Fig. 1b–e), in addition to the above
mentioned vibrations, the bands at 1690–1710 cm−1 (C=O) is a
good indication for the presence of carbonyl groups on the
nano−silica.59
Typical Procedure for Heck Reaction Catalyzed by Pdnp−nSTDP
Aryl halide (1 mmol), styrene (1.1 mmol), K2CO3 (1.5 mmol)
and Pdnp−nSTDP (10 mg, 0.14 mol% Pd) were added in 3 mL
of DMF/H2O (1:2). The reaction mixture was stirred at 95 C
°
under an air atmosphere for desired time summarized in Table
5. The progress of the reaction was tracked by GC. After
completion, the reaction mixture was cooled, poured in water
and extracted by diethyl ether (2×10 mL). The organic phase
was washed with water (3×10 mL) and dried over anhydrous
MgSO4. After evaporation of the solvent the pure product was
afforded.
Results and discussion
Preparation and characterization of nanosilica thiolated
dendritic polymerꢀsupported Pd particles (Pdnp−nSTDP)
The first step for the synthesis of nanosilica thiolated dendritic
polymer was modification of the activated nanosilica with
(3−mercaptopropyl)trimethoxysilane, to obtain the thiol
functionalized nanosilica (PT−nSiO2).58 The addition of 1,3,5ꢀ
benzenetricarbonyl trichloride (BCC) to the surface−attached
propylthiol nanosilica was carried out at 0 °C, to substitute only
one of the chlorine atoms to achieve BCC1−nSiO2. In the next
step, BCC1−nSiO2 was thiolated via addition of
1,2−ethanedithiol to prepare G1. The G2 was achieved by
Fig. 1. FT-IR spectrum of: a) PT−nSiO2, b) BCC1− nSiO2, c) G1, d) BCC2−nSiO2 and
e) G2
The TGA survey scan was run at 5 °C per minute. The TGA
curve of PT−nSiO2, BCC1−nSiO2, G1, BCC2−nSiO2 and G2,
over the temperature range from 0 to 600 °C shows a double
steps descending, which indicates a weight loss occurred. The
first step is due to loss of residual water in the porous sample
and the second step reflects the removal of organic moieties on
the surface. The TGA features are imaged in Figure 2.
addition
of
1,3,5ꢀbenzenetricarbonyl
trichloride
and
1,2−ethanedithiol, successively (Scheme 2).
Fig. 2. TGA spectra of: a) PT−nSiO2; b) BCC1−nSiO2; c) G1; d) BCC2−nSiO2 and e)
G2 (nSTDP)
Elemental analysis calculation is in a good relevance with TGA
data (Table 1).60 The elemental analysis results for sulfur
content showed a decrease from PT−nSiO2 to BCC1−nSiO2 and
also from G1 to BCC2−nSiO2 due to addition of 1,3,5ꢀ
benzenetricarbonyl trichloride. Consequently, this amount
increased via further addition of 1,2−ethanedithiol. As it is
shown in Table 1, the nitrogen content was also investigated.
The presence of nitrogen in the CHNS is due to utilization of
DIPEA as a base trapped in the pores of nanosilica.
Scheme 2. Synthesis of nano−silica Thiolated dendriꢀc polymer (G2 or nSTDP).
Synthesis of dendritic polymer was step by step monitored by
FT−IR spectroscopy, TGA and also elemental analysis. FTꢀIR
spectra were recorded neat and only significant absorption in
cm−1 are indicated. The FT−IR spectrum of PT−nSiO2 (Fig. 1a)
showed a broad O─H stretching band at 3200–3400 cm−1 and a
strong Si─O─Si stretching band about 1000 –1100 cm−1. Also,
This journal is © The Royal Society of Chemistry 2012
J. Name., 2012, 00, 1-3 | 3

RSC Advances
Page 4 of 13
View Article Online
DOI: 10.1039/C6RA16704G
Journal Name
RSCPublishing
Table 1. TGA and elemental analysis (EA) results for the synthesis of nano−silica thiolated dendritic material
C
H
N
−
−
−
1.72
−
0.38
−
1.43
−
S
9.07
9.01
3.69
O
−
−
6.23
−
7.96
−
12.50
−
12.15
−
Cl
−
−
8.07
−
−
−
10.80
−
−
−
Total
21.26
21.01
35.65
24.36
53.26
47.81
68.92
48.55
84.41
75.46
PT−nSiO2
BCC1−nSiO2
G1
TGA (wt%)
EA (wt%)
TGA (wt%)
EA (wt%)
TGA (wt%)
EA (wt%)
TGA (wt%)
EA (wt%)
TGA (wt%)
EA (wt%)
10.20
10.04
16.61
17.81
28.32
29.66
31.49
32.21
37.81
39.17
1.98
1.96
1.03
1.08
2.80
2.93
1.77
1.97
3.22
3.85
3.72
14.16
14.83
12.35
12.94
31.21
32.19
BCC2−nSiO2
G2
0.25
After synthesis and characterization of nSTDP, the dendritic are also clearly observed in XPS elemental survey of the
polymer was used as host for carrying the palladium catalyst (Figure 6).
nanoparticles. The supported Pd nanoparticles were obtained by
the reaction of Na2PdCl4 with nSTDP in the presence of sodium
acetate as reducing agent (Scheme 3).61 As mentioned in the
literature, the Pd nanoparticles can be trapped by the cavities
and also by the surface functional groups.25 Based on three
dimensional structure of dendrimers, internal sulfides and
oxygenes, and also external thiol groups of this dendritic
material are capable to be as host for a Pd nanoparticles.
The presence of palladium in the catalyst was confirmed by
ICP, which showed a value of about 0.14 mmol Pd per gram of
catalyst.
Figures 3a, b and c present the field emission scanning electron
microscopy (FE−SEM) images of nanosilica, nSTDP and
Pdnp−nSTDP. The size and surface morphologies of the
nSTDP and Pdnp−nSTDP are uniform, as shown in the images,
the nSiO2 particles are spherical and the average diameters are
in the range of 50 to 70 nm.
The energy dispersive X−ray (EDX) results, collected from
SEM analysis, proved the presence of S and Si elements in the
nSTDP and also Pd element in the Pdnp−nSTDP (Figures 3d
and e). Elemental mapping of Pdnp−nSTDP depicted in Figure
4, in which the uniform and homogenous dispersion of C, Si, O,
S and Pd elements can be visualized.
Figure 5A shows the transmission electron microscopy (TEM)
image of the Pdnp−nSTDP. The picture verifies that the particles
are well dispersed and almost no agglomeration was observed.
Also, the catalyst composed of spherical, nanosized Pd particles
range from 2 to 5.5 nm (Figure 5B).
Xꢀray photoelectron spectroscopy (XPS) is a powerful tool to
investigate the electron properties of the species formed on the
surface, such as the electron environment, oxidation state, and
the binding energy of the core electron of the metal. Figure 6
shows the XPS spectrum of catalyst. The calibration was
Scheme 3. Synthesis of the Pdnp−nSTDP catalyst
performed with the C1s peak (E= 284.5 eV). As shown in this
Figure, the peaks at 335.85 (3d5/2) and 340.98 eV (3d3/2),
All these observations confirm that this new thiolated dendritic
correspond to Pd with zero oxidation state.62 The peaks
polymer is an appropriate host and ligand for palladium
corresponding to silicon, oxygen, carbon, sulfur and palladium
nanoparticles.
This journal is © The Royal Society of Chemistry 2013
J. Name., 2013, 00, 1-3 | 4

Page 5 of 13
Journal Name
RSC Advances
View Article Online
ARTICLE
DOI: 10.1039/C6RA16704G
Fig. 3. FE−SEM images of: a) nanosilica, b) nSTDP and c) Pdnp−nSTDP. SEM−EDX
spectra of: d) nSTDP and e) Pdnp−nSTDP.
Catalytic experiments
The catalytic activity of the prepared catalyst was investigated
in the SuzukiꢀMiyaura and Heck CꢀC coupling reactions.
Suzuki–Miyaura Coupling of Aryl Halides with Arylboronic
Acids
The Suzuki–Miyaura cross−coupling reactions typically require
careful optimization of base and solvent types, temperature,
amount of catalyst and substrates molar ratios (Table 2). In this
manner, the Suzuki–Miyaura cross−coupling of 4−iodoanisole
with phenylboronic acid in the presence of Pdnp−nSTDP
catalyst was selected as a model for optimization of reaction
parameters such as the base and solvent types, temperature,
amount of catalyst and substrates molar ratios (Table 2).
To optimize the solvent, different types of single and mixed
solvents were employed. The mixture of DMF/H2O (1:2) was
proved to be the optimum reaction medium (Table 2, entries 1ꢀ
7). Several organic and inorganic bases were screened (i.e.,
NEt3, DBU, Na2CO3, K3PO4, NaOH, piperidine and K2CO3), of
which K2CO3 gave the best yield (Table 2, entries 8ꢀ14). A
1:1.1:1.5 ratio of 4−iodoanisole to phenylboronic acid and base
was optimal for product formation. The catalytic loading could
This journal is © The Royal Society of Chemistry 2012
J. Name., 2012, 00, 1-3 | 5

RSC Advances
Page 6 of 13
View Article Online
ARTICLE
Journal Name
DOI: 10.1039/C6RA16704G
be lowered to 0.07 mol% Pd (5 mg) with shorter reaction times However, decreasing the catalyst loading, led to longer reaction
and up to 98% yield.
time and lower yield (Table 2, entry 17).
The effect of reaction temperature was also investigated and the
60 °C was suitable for evaluation of the scope of Suzuki–
Miyaura cross−coupling reaction.
Fig. 4. Elemental mapping (S, Si, C, O and Pd) of Pdnp−nSTDP.
Fig. 6. The XPS spectra of catalyst: (a) showing Pd 3d5/2 and Pd 3d3/2 binding
energies, (b) the elemental survey scan, (c) Reused Pdnp−nSTDP
To determine the substrate scope for the Suzuki–Miyaura
cross−coupling reaction, different aryl halides were employed
in the reaction (Table 3). In this case, different substituted aryl
chloride, bromide and iodides were reacted with phenylboronic
acid and 4−methoxyphenylboronic acid in the presence of 0.07
mol% (5 mg) of Pdnp−nSTDP as catalyst, K2CO3 as base and
DMF/H2O (2:1) as solvent. The experimental data showed that
reactions proceeded extremely well and the electronic
properties of the substituents and functional groups on the
aromatic rings had almost negligible effect on the results.
Fig. 5. (A) TEM image for Pdnp−nSTDP and (B) Particle size distribution results for
Pdnp−nSTDP catalyst
.
6 | J. Name., 2012, 00, 1-3
This journal is © The Royal Society of Chemistry 2012

Page 7 of 13
Journal Name
RSC Advances
View ArticAle ROnTliInCeLE
DOI: 10.1039/C6RA16704G
Further investigation also revealed that aryl iodides were more was investigated in the Suzuki–Miyaura cross−coupling
reactive than aryl bromides and aryl chlorides in these catalytic reaction of 4−iodoanisole with phenylboronic acid and Heck
reactions. Although, aryl chlorides have less reactivity than aryl reaction of 4−bromoacetophenone with styrene under the
iodides and aryl bromides, but they are economically more optimized conditions. After completion of each catalytic cycle,
available. Due to less reactivity, the coupling reactions with the catalyst was separated by simple filtration and reused. The
aryl chlorides have been performed at 90 °C (Table 3, entries results showed that the catalyst could be reused five
14−18).63,64
consecutive times without significant loss of its catalytic
activity in both reactions (Table 6). The analysis of palladium
leaching from Pdnp−nSTDP catalyst by ICP indicated that only
Heck Reaction of Aryl Halides with Styrenes
The high catalytic activity of this catalyst in the Suzuki– a negligible amount of palladium has been leached in the first
Miyaura cross−coupling reaction prompted us to investigate the two runs in the SuzukiꢀMiyaura reaction and in the first three
catalytic capability of our new designed dendritic polymerꢀ runs in the Heck reaction. The hot filtration test was also
supported palladium particles in the Heck reaction.
carried out in both reactions. In this manner, the hot reaction
For identifying the exact optimized conditions for the coupling mixtures were centrifuged at about 45% conversion to remove
reaction detailed in Table 4, the reaction of the solid particles. The filtrates continue to catalyze the
4−bromoacetophenone and styrene was selected as a model reactions. Compared to the unfiltered reaction (after 15 min for
reactin using Pdnp−nSTDP as catalyst under thermal conditions. SuzukiꢀMiyaura and 12 h for Heck reaction), no further
The
optimized
conditions
were
gained
applying progress was observed.
4−bromoacetophenone (1 mmol), styrene (1.1 mmol), K2CO3 The XPS studies on the recycled catalyst prove the presence of
(1.5 mmol) and Pdnp−nSTDP 0.14 mol% Pd (10 mg) in Pd nanoparticles in the texture. However the spectra shows the
DMF/H2O (1:2) at 95 °C.
existence of small amounts of Pd(II) which was not observed in
The substrate scope of the coupling reaction was investigated freshly prepared catalyst. This indicates that some Pd
using various structurally different aryl halides (Table 5). As it nanoparticles were oxidized to Pd(II) (Fig. 6c).65
is mentioned in Table 5, the yield were decreased from aryl The results of the present study were compared with some
halides to bromides and chlorides. While the nature of results reported in the SuzukiꢀMiyaura crossꢀcoupling and Heck
substituents of R1 and R2 has almost no specific effect on the reaction catalyzed by different Pd containing catalysts. As can
reaction.
be seen, this catalytic system is more efficient than the others in
the SuzukiꢀMiyaura crossꢀcoupling reaction by comparison of
their TOFs (Table 7). Also, in the case Heck reaction, the TOFs
Catalyst Recycling and Reuse
From industrial and economic points of view, the catalyst show that this catalytic system is one of the best catalytic
recycling is the most important issue for a heterogeneous systems (Table 8).
catalyst. Therefore, the reusability of the Pdnp−nSTDP catalyst
Table 2. Optimization of the Suzuki–Miyaura cross−coupling of 4−iodoanisole (IA) with phenylboronic acid (PBA) catalyzed by Pdnp−nSTDP.
Entry
1
2
3
4
5
6
7
8
Base
K2CO3
K2CO3
K2CO3
K2CO3
K2CO3
K2CO3
K2CO3
NEt3
Ba:PBA:Base (mmol)
1:1.1:1.5
1:1.1:1.5
1:1.1:1.5
1:1.1:1.5
1:1.1:1.5
1:1.1:1.5
1:1.1:1.5
1:1.1:1.5
1:1.1:1.5
1:1.1:1.5
1:1.1:1.5
1:1.1:1.5
1:1.1:1.5
1:1:1
Catalyst (mol% Pd)
0.07
Solventa
Toluene
EtOH
EtOH/H2O (1:1)
DMF
T (°C)
60
60
60
60
60
60
60
60
60
60
60
60
60
60
60
60
60
60
25
40
Time (min)
45
Yield (%)b
50
0.07
0.07
0.07
0.07
0.07
0.07
0.07
0.07
0.07
0.07
0.07
0.07
0.07
0.07
0.07
0.04
70
50
80
80
25
10
50
50
30
45
50
50
25
25
30
20
63
75
65
59
85
98
54
46
50
50
54
30
80
85
85
90
H2O
DMF/H2O (1:1)
DMF/H2O (2:1)
DMF/H2O (2:1)
DMF/H2O (2:1)
DMF/H2O (2:1)
DMF/H2O (2:1)
DMF/H2O (2:1)
DMF/H2O (2:1)
DMF/H2O (2:1)
DMF/H2O (2:1)
DMF/H2O (2:1)
DMF/H2O (2:1)
DMF/H2O (2:1)
DMF/H2O (2:1)
DMF/H2O (2:1)
9
DBUc
10
11
12
13
14
15
16
17
18
19
20
Na2CO3
K3PO4
NaOH
Piperidine
K2CO3
K2CO3
K2CO3
K2CO3
K2CO3
K2CO3
K2CO3
1:1:1.2
1:1:1.5
1:1.1:1.5
1:1.1:1.5
1:1.1:1.5
1:1.1:1.5
0.014
0.07
0.07
10
30
25
98
65
80
a) Reaction was performed using 3 ml of solvent.
b) GC yield
c) 1,8ꢀDiazabicyclo [5.4.0] undecꢀ7ꢀene
This journal is © The Royal Society of Chemistry 2012
J. Name., 2012, 00, 1-3 | 7

RSC Advances
Page 8 of 13
View Article Online
DOI: 10.1039/C6RA16704G
Journal Name
RSCPublishing
Table 3. Suzuki–Miyaura cross−coupling of aryl halides with arylboronic acids catalyzed by Pdnp−nSTDP.a
Entry
R1
R2
X
Time (min)
Yield (%)b
TOF (h−1)
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
H
H
4−Ac
4−Ac
4−Me
H
H
4−MeO
H
4−MeO
H
4−MeO
H
4−MeO
H
4−MeO
H
4−MeO
H
4−MeO
H
4−MeO
H
I
I
I
I
10
10
15
13
10
30
25
30
28
32
30
35
32
40
38
65
55
65
95
98
92
95
95
94
95
93
96
91
93
91
93
81
82
85
87
90
8143
8400
5257
6263
8143
2685
3257
2657
2939
2437
2657
2228
2491
1735
1849
1120
1355
1186
I
Br
Br
Br
Br
Br
Br
Br
Br
Cl
Cl
Cl
Cl
Cl
H
4−MeO
4−MeO
4−Ac
4−Ac
4−CHO
4−CHO
Hc
Hc
4−Acc
4−Acc
4−CHOc
H
a) Reaction conditions: Aryl halide (1 mmol), phenylboronic acid (1.1 mmol), K2CO3 (1.5 mmol), Pdnp−nSTDP (0.005 g, 0.07 mol% Pd), H2O/
DMF (1 mL/2 mL) at 60 °C.
b) GC yield
c) The reaction was performed at 90 °C
Table 4. Optimization of the Heck reaction of 4−bromoacetophenone (BA) with styrene (Sty) catalyzed by Pdnp−nSTDP.a
Entry
1
2
3
4
5
6
7
8
Base
K2CO3
K2CO3
K2CO3
K2CO3
K2CO3
K2CO3
K2CO3
NEt3
BA:Sty:Base (mmol)
1:1.1:1.5
1:1.1:1.5
1:1.1:1.5
1:1.1:1.5
1:1.1:1.5
1:1.1:1.5
1:1.1:1.5
1:1.1:1.5
1:1.1:1.5
1:1.1:1.5
1:1.1:1.5
1:1.1:1.5
1:1:1
Catalyst (mol% Pd)
Solventa
Toluene
EtOH
H2O
T (°C)
95
95
95
95
95
95
95
95
95
95
95
95
95
95
95
95
Time (h)
22
25
15
18
14
12
8
Yield (%)b
55
0.14
0.14
0.14
0.14
0.14
0.14
0.14
0.14
0.14
0.14
0.14
0.14
0.14
0.14
0.07
0.21
0.14
0.14
50
65
60
65
68
94
50
55
60
60
55
45
70
75
94
85
EtOH/H2O (1:1)
DMF
DMF/H2O (1:1)
DMF/H2O (2:1)
DMF/H2O (2:1)
DMF/H2O (2:1)
DMF/H2O (2:1)
DMF/H2O (2:1)
DMF/H2O (2:1)
DMF/H2O (2:1)
DMF/H2O (2:1)
DMF/H2O (2:1)
DMF/H2O (2:1)
DMF/H2O (2:1)
DMF/H2O (2:1)
20
22
14
18
15
18
14
10
8
9
DBU
10
11
12
13
14
15
16
17
18
Na2CO3
K3PO4
NaOH
K2CO3
K2CO3
K2CO3
K2CO3
K2CO3
K2CO3
1:1.1:1.2
1:1.1:1.5
1:1.1:1.5
1:1.1:1.5
1:1.1:1.5
80
110
12
8
94
a) The reaction was performed using 3 ml of solvent.
b) GC yield
This journal is © The Royal Society of Chemistry 2013
J. Name., 2013, 00, 1-3 | 8

Page 9 of 13
Journal Name
RSC Advances
View ArticAle ROnTliInCeLE
DOI: 10.1039/C6RA16704G
Table 5. Heck reaction of aryl halides with styrenes catalyzed by Pdnp−nSTDP.a
Entry
R1
R2
X
Time (h)
Yield (%)b
TOF (h−1)
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
H
H
4−Ac
4−Ac
4−Me
H
H
4−Me
H
4−Me
H
H
4−Me
H
H
4−Me
H
4−Me
H
4−Me
H
I
I
I
I
7.5
8
8
8
8
11
10
11
12
11
12
12
16
16
15
16
96
94
95
94
95
93
91
92
94
93
91
92
91
89
88
88
91.43
83.93
84.82
83.93
84.82
60.39
65
59.74
55.95
60.39
54.16
54.76
40.62
39.73
41.90
39.28
I
Br
Br
Br
Br
Br
Br
Br
Cl
Cl
Cl
Cl
H
4−F
4−Ac
4−Ac
4−CHO
4−MeO
H
4−Ac
4−Ac
4−CHO
H
a) Reaction conditions: Aryl halide (1 mmol), styrenes (1.1 mmol), K2CO3 (1.5 mmol), Pdnp−nSTDP (0.01 g, 0.14 mol% Pd), H2O/DMF (1 mL/2 mL) at 95
°C.
b) GC yield
Table 6. Recycling of the Pdnp−nSTDP catalyst in the SuzukiꢀMiyaura cross−coupling of 4−bromoacetophenone with phenylboronic acid in 15 mina and Heck
reaction of 4−bromoacetophenone with styrene after 12 h.b
Run
Yield (%)c
Pd leached (%)d
SuzukiꢀMiyaura
Heck reaction
SuzukiꢀMiyaura
Heck reaction
1
2
3
4
5
92
90
88
88
88
94
90
86
86
86
2
1
0
0
0
4
2
1.5
0
0
a) Reaction conditions: 4−bromoacetophenone (1 mmol), phenylboronic acid (1.1 mmol), K2CO3 (1.5 mmol), Pdnp−nSTDP (0.005 g, 0.07 mol% Pd),
H2O/DMF (1 mL/2 mL) at 60 °C.
b) Reaction conditions: 4−bromoacetophenone (1 mmol), styrene (1.1 mmol), K2CO3 (1.5 mmol), Pdnp−nSTDP (0.01 g, 0.14 mol% Pd), H2O/DMF (1 mL/2
mL) at 95 °C.
c) GC yield.
d) Determined by ICP analysis
Table 7. Comparison of the results obtained in the SuzukiꢀMiyaura coupling
reaction of bromobenzene with phenylboronic acid catalyzed by Pdnp−nSTDP
Conclusion
with those obtained by some recently reported catalysts.
This paper describes the synthesis and characterization of a new
Catalyst
Reaction conditions
TOF
(hꢀ1)
Ref
37
67
66
48
64
11
thiol based dendritic material as a host for carrying of
palladium nanoparticles. The new synthesized nanosilica
thiolated dendritic polymerꢀsupported Pd particles has proven
to be highly effective heterogeneous catalyst for carbon−carbon
couplings in both SuzukiꢀMiyaura and Heck reactions.
Although palladium as a precious metal is quite expensive, we
have shown that they can be easily recovered and reused for
several times, without any significant loss of its catalytic
activity. Therefor it would be possible to use them in further
real−world applications.
Pd(0)/UiOꢀ66ꢀNH2
Pd(PyBNHC)@nSiO2
Pd(0)/MCoSꢀ1
PdTN
DMF/H2O, K2CO3, 60 °C, 697.7
30 min
DMF/H2O, K2CO3, 65 °C, 438
100 min
H2O, K2CO3, 70 °C, 300 98
min
THF/H2O,NaOH, 63 °C, 80
150 min
DMF/H2O, K2CO3, 100 16.6
°C, 1440 min
DMF/H2O, K2CO3, RT, 2666
360 min
Pd Schiff base complex
Pd−nSTDP
Pdnp−nSTDP
DMF/H2O, K2CO3, 60 °C, 3257
25 min
This
work
This journal is © The Royal Society of Chemistry 2012
J. Name., 2012, 00, 1-3 | 9

RSC Advances
Page 10 of 13
VJieowuArrtnicalelONnlainme e
ARTICLE
DOI: 10.1039/C6RA16704G
for Suzuki–Miyaura CrossꢀCoupling and Heck Reactions. Adv. Synth.
Catal. 2013, 355, 957–972.
Table 8. Comparison of the results obtained in the Heck reaction of 4ꢀ
bromobenzenel with styrene catalyzed by Pdnp−nSTDP with those obtained
by some reported catalysts.
12 J. H. Noh, R. Patala and R. Meijboom, Catalytic evaluation of
dendrimer and reverse microemulsion template Pd and Pt
nanoparticles for the selective oxidation of styrene using TBHP.
Catalyst
Reaction conditions
TOF
(hꢀ1)
15.5
Ref
Pd(OAc)2/(LHX)
Palladacycle
Pd/USY
Pd(OAc)2/NHC
Pd@PANI
Pd−nSTDP
PEPSIꢀPd NHC
Pdnp−nSTDP
DMF/H2O, K2CO3, 80 °C, 4 h
[nꢀBu4N]Br, Na(OAc), 120 °C, 16 h 62.5
68
69
70
71
72
11
73
This
work
Appl. Catal. A: Gen. 2016, 514, 253–266.
13 J. H and Noh, R. Meijboom, Dendrimerꢀtemplated Pd nanoparticles
an Pd nanoparticles synthesized by reverse microemulsions as
efficient nanocatalyst for the Heck reaction: A comparative study. J.
Colloid Interface Sci. 2014, 415, 57–69.
DMF, NaOAc, H2, 140 °C, 20 h
DMF/H2O, K2CO3, 80 °C, 2 h
DMF, N2, EtN(iꢀPr)2, 120 °C, 48 h
DMF/H2O, K2CO3, 85 °C, 14 h
DMF, K2CO3, TBAB, 140 °C, 2 h
DMF/H2O, K2CO3, 95 °C, 11 h
48
24
14.5
642
100
60.4
14 M. Nasr−Esfehani, I. Mohammadpoor−Baltork, A. R. Khosropour,
M. Moghadam, V. Mirkhani and S. Tangestaninejad, Synthesis and
characterization of Cu(II) containing nanosilica triazine dendrimer: A
recyclable nanocomposite material for the synthesis of
Acknowledgement
benzimidazoles, benzothiazoles, bisꢀbenzimidazoles and bis
ꢀ
Partial support of this work by the Research Council of the
University of Isfahan is acknowledged.
benzothiazoles. J. Mol. Catal. A: Chem. 2013, 379, 243−259.
15 Z. V. Feng, J. L. Lyon, J. S. Croley, R. M. Crooks, D. A. Vanden
Bout and K. J. Stevenson, Synthesis and catalytic evaluation of
References
dendrimerꢀencapsulated Cu nanoparticles. J. Chem. Educ. 2009, 86
,
1
2
3
4
D. A. Tomalia and J. M. J. Frechet, Discovery of dendrimers and
368–372.
dendritic polymers: a brief historical perspective. J. Polym. Sci. A: 16 N. C. Beck Tan, L. Balogh, S. F. Trevino, D. A. Tomalia and J. S.
Polym. Chem. 2002,
9
, 2719–2728.
Lin, A small angle scattering study of dendrimer–copper sulfide
F. Vögtle, G. Richardt and N. Werner, Dendrimer Chemistry
nanocomposites. Polymer 1999, 40, 2537−2545.
Concepts, Synthesis, Properties, Applications, Wiley−VCH, 17 P. Kracke, T. Haas, H. Saltsburg and M. FlytzaniꢀStephanopoulos,
Weinheim, 2009.
CO Oxidation on Unsupported DendrimerꢀEncapsulated Gold
A. W. Bosman, H. M. Janssen and E. W. Meijer, About Dendrimers:
Nanoparticles. J. Phys. Chem. C, 2010, 114, 16401–16407.
Structure, Physical Properties, and Applications. Chem. Rev. 1999, 18 T. Mandal, C. Dasgupta and P. K. Maiti, Engineering Gold
99, 1665–1688.
Nanoparticle Interaction by PAMAM Dendrimer. J. Phys. Chem. C,
2013, 117, 13627–13636.
D. Astruc, E. Boisselier and C. Ornelas, Dendrimers Designed for
Functions: From Physical, Photophysical, and Supramolecular 19 M. Stemmler, F. D. Stefani, S. Bernhardt, R. E. Bauer, M. Kreiter, K.
Properties to Applications in Sensing, Catalysis, Molecular
Müllen and W. Knoll, OneꢀPot Preparation of Dendrimer−Gold
Nanoparticle Hybrids in a Dipolar Aprotic Solvent. Langmuir 2009,
25, 12425–12428.
Electronics, Photonics, and Nanomedicine. Chem. Rev. 2010, 110
,
1857–1959.
5
G. R. Newkome and C. N. Moorefield, Suprasupermolecules with 20 X. Yuan, S. Wen, M. Shen and X. Shi, Dendrimerꢀstabilized silver
Novel Properties: Metallodendrimers. Chem. Rev. 1999, 99
,
1689–
nanoparticles enable efficient colorimetric sensing of mercury ions in
aqueous solution; Anal. Methods, 2013, , 5486–5492.
1746.
5
6
7
8
G. M. Dykes, Dendrimers: a review of their appeal and applications
J. Chem. Technol. Biotechnol. 2001, 76 903 918
.
21 M. Zhao and R. M.Crooks, DendrimerꢀEncapsulated Pt
Nanoparticles: Synthesis, Characterization, and Applications to
,
–
.
B. Klajnert and M. Bryszewska, Dendrimers: properties and
applications. Acta Biochim. Pol. 2001, 48, 199−208.
Catalysis. Adv. Mater. 1999, 11, 217−220.
22 K. Esumi, A. Suzuki, A. Yamahira and K. Torigoe, Role of
Poly(amidoamine) Dendrimers for Preparing Nanoparticles of Gold,
Platinum, and Silver. Langmuir 2000, 16, 2604−2608.
S. M. Grayson and J. M. J. Frechet, Convergent dendrons and
dendrimers: From synthesis to applications. Chem. Rev. 2001, 101
,
3819−3867.
23 N. C. Antonels and R. Meijboom, Preparation of wellꢀdefined
dendrimer encapsulated ruthenium nanoparticles and their application
as catalyst and enhancement of activity when utilised as SCILL
9
V. S. Myers, M. G. Weir, E. V. Carino, D. F. Yancey, S. Pande and
R. M. Crooks, Dendrimerꢀencapsulated nanoparticles: New synthetic
and characterization methods and catalytic applications. Chem. Sci.
catalysts in the hydrogenation of citral. Catal. Commun. 2014, 57
,
2011,
2, 1632−1646.
148–152.
10 M. A. Herrero, J. Guerra, V. S. Myers, M. V. Gomez, R. M. Crooks 24 N. C. Antonels and R. Meijboom, Preparation of wellꢀdefined
and M. Prato, Gold Dendrimer Encapsulated Nanoparticles as
Labeling Agents for Multiwalled Carbon Nanotubes. ACS Nano.
2010, 4, 905−912.
dendrimer encapsulated ruthenium nanoparticles and their evaluation
in the reduction of 4ꢀnitrophenol according to the Langmuirꢀ
Hinshelwood approach. Langmuir 2013, 29, 13433–13442.
11 A. Landarani Isfahani, I. Mohammadpoor−Baltork, V. Mirkhani, A. 25 R. M. Crooks, M. Zhao, L. Sun, V. Chechik and L. Yeung, Dendrimerꢀ
R. Khosropour, M. Moghadam, S. Tangestaninejad and R. Kia,
Palladium Nanoparticles Immobilized on NanoꢀSilica Triazine
Dendritic Polymer (PdnpꢀnSTDP): An Efficient and Reusable Catalyst
Encapsulated Metal Nanoparticles: Synthesis, Characterization, and
Applications to Catalysis, Acc. Chem. Res. 2001, 34, 181ꢀ190.
10 | J. Name., 2012, 00, 1-3
This journal is © The Royal Society of Chemistry 2012

Page 11 of 13
Journal Name
RSC Advances
View ArticAle ROnTliInCeLE
DOI: 10.1039/C6RA16704G
26 T. Liu, L. Xie, Y. Li, X. Li, S. Pang and T. Zhang,
Hydrogen/deuterium storage properties of Pd nanoparticles. J. Power
Sources, 2013, 237, 74–79.
catalyst for Suzuki crossꢀcoupling reaction. J. Organomet. Chem.
2014, 761, 127−133.
40 P. Lan, D. Berta, J. A. Porco, M. S. South and J. J. Parlow, Polymerꢀ
Assisted SolutionꢀPhase (PASP) Suzuki Couplings Employing an
27 D. Gupta, D. Dutta, M. Kumar, P. B. Barman, C. K. Sarkar, S. Basu
and S. K. Hazra, A low temperature hydrogen sensor based on
palladium nanoparticles. Sensors Actuat. B: Chem. 2014, 196, 215–
222.
AnthraceneꢀTagged Palladium Catalyst. J. Org. Chem. 2003, 68
,
9678–9686.
41 Z. Pahlevanneshan, M. Moghadam, V. Mirkhani, S. Tangestaninejad,
I. Mohammadpoor−Baltork and A. R. Khosropour, Immobilization of
palladium(II)ꢀcontaining bis(imidazolium) ligand on ionꢀexchange
resins: efficient and reusable catalysts for C‒C coupling reactions.
Appl. Organomet. Chem. 2015, 29, 346–352.
28 J. Yu, R. Y. F. Liu, B. Poon, S. Nazarenko, T. Koloski, T. Vargo, A.
Hiltner and E. Baer, Polymers with palladium nanoparticles as active
membrane materials. J. Appl. Polym. Sci. 2004, 92, 749−756.
29 I. Feliciano−Ramos, B. Casañas−Montes, M. M. García−Maldonado,
C. L. Menéndez, A. R. Mayol, L. M. Díaz−Vázquez and C. R. 42 D. J. Gavia and Y. S. Shon, Controlling Surface Ligand Density and
Cabrera, Assembly of a CostꢀEffective Anode Using Palladium
Core Size of AlkanethiolateꢀCapped Pd Nanoparticles and Their
Effects on Catalysis. Langmuir, 2012, 28, 14502ꢀ14508.
Nanoparticles for Alkaline Fuel Cell Applications. J. Chem. Edu
2015, 92, 360–363.
.
43 C. M. A. Parlett, D. W. Bruce, N. S. Hondow, A. F. Lee and K.
Wilson, SupportꢀEnhanced Selective Aerobic Alcohol Oxidation over
30 J. Huang, T. Jiang, B. Han, H. Gao, Y. Chang, G. Zhao and W. Wu,
Hydrogenation of olefins using ligandꢀstabilized palladium
Pd/Mesoporous Silica. ACS Catal., 2011, 1, 636−640.
nanoparticles in an ionic liquid. Chem. Commun. 2003, 14
,
44 M. Ruta, N. Semagina and L. Kiwi−Minsker, Monodispersed Pd
Nanoparticles for Acetylene Selective Hydrogenation: Particle Size
and Support Effects. J. Phys. Chem. C 2008, 112, 13635−13641.
1654−1655.
31 X. Gu, Z. H. Lu, H. L. Jiang, T. Akita and Q. Xu, Synergistic
catalysis of metalꢀorganic frameworkꢀimmobilized AuꢀPd 45 J. C. GarciaꢀMartinez, R. Lezutekong and R. M. Crooks, Dendrimerꢀ
nanoparticles in dehydrogenation of formic acid for chemical Encapsulated Pd Nanoparticles as Aqueous, Room Temperature
hydrogen storage. J. Am. Chem. Soc. 2011, 133 11822–11825.
32 M. Moreno−Mañas and R. Pleixats, Formation of Carbon−Carbon
,
Catalysts for the stille Reaction. J. Am. Chem. Soc. 2005, 127,
5097−5103.
Bonds under Catalysis by TransitionꢀMetal Nanoparticles. Acc. 46 E. V. Carino, M. R. Knecht and R. M. Crooks, Quantitative Analysis
Chem. Res. 2003, 36, 638–643.
of the Stability of Pd DendrimerꢀEncapsulated Nanoparticles.
33 M. K. Chung and M. Schlaf, A Catalytic Synthesis of Thiosilanes
Langmuir 2009, 25, 10279−10284.
and Silthianes:ꢁ Palladium NanoparticleꢀMediated CrossꢀCoupling of 47 X. Zhang, J. Zhu, C. S. Tiwary, Z. Ma, H. Huang, J. Zhang, Z. Lu,
Silanes with Thio Phenyl and Thio Vinyl Ethers through Selective
W. Huang and Y. Wu. Palladium Nanoparticles Supported on
Nitrogen and Sulfur DualꢀDoped Graphene as Highly Active
Electrocatalysts for Formic Acid and Methanol Oxidation. ACS Appl.
Carbon−Sulfur Bond Activation. J. Am. Chem. Soc. 2004, 126, 7386–
7392.
34 V. Kogan, Z. Aizenshtat, R. Popovitz−Biro and R. Neumann,
Mater. Interfaces, 2016, 8, 10858−10865.
Carbonꢀcarbon and carbonꢀnitrogen coupling reactions catalyzed by 48 F. Lu, J. Ruiz and D. Astruc, Palladium–dodecanethiolate
palladium nanoparticles derived from
Kegginꢀtype polyoxometalate. Org. Lett. 2002,
35 B. J. Gallon, R. W. Kojima, R. B. Kaner and P. L. Diaconescu,
a
palladium substituted
nanoparticles as stable and recyclable catalysts for the Suzuki–
Miyaura reaction of aryl halides under ambient conditions.
Tetrahedron Lett. 2004, 45, 9443−9445.
4, 3529–3532.
Palladium Nanoparticles Supported on Polyaniline Nanofibers as 49 J. Alvarez, J. Liu, E. Román and A. E. Kaifer, WaterꢀSoluble
SemiꢀHeterogeneous Catalysts in Water, Angew. Chem. Int. Ed.
2007, 46 7251ꢀ7254.
Platinum and Palladium Nanoparticles Modified with Thiolated βꢀ
,
Cyclodextrin, Chem. Commun. 2000, 13, 1151ꢀ1152.
36 S. Harish, J. Mathiyarasu, K. L. N. Phani and V. Yegnaraman, 50 Xiong, Y.; Xia, Y. ShapeꢀControlled Synthesis of Metal
Synthesis of Conducting Polymer Supported Pd Nanoparticles in
Aqueous Medium and Catalytic Activity Towards 4ꢀNitrophenol
Reduction. Catal. Lett. 2009, 128, 197−202.
Nanostructures: The Case of Palladium. Adv. Mater. 2007, 19,
3385−3391.
51 B. Lim, M. Jiang, J. Tao, P. H. C. Camargo, Y. Zhu and Y. Xia,
ShapeꢀControlled Synthesis of Pd Nanocrystals in Aqueous
37 E. Groppo, G. Agostini, E. Borfecchia, L. Weit, F. Giannici, G.
Portale, A. Longo and C. Lamberti, Formation and Growth of Pd
Solutions. Adv. Funct. Mater. 2009, 19, 189−200.
Nanoparticles Inside a Highly CrossꢀLinked Polystyrene Support: 52 A. Daneshvar, M. Moghadam, S. Tangestaninejad, V. Mirkhani, I.
Role of the Reducing Agent. J. Phys. Chem. C, 2014, 118
,
MohammadpoorꢀBaltork, A. Khalili, Ruthenium Hydride Complex
Supported on Gold Nanoparticle Cored Triazine Dendrimers for C−C
Coupling Reactions. Organometallics 2016, 35, 1747−1755.
8406−8415.
38 J. Mondal, A. Modak and A. Bhaumik, Oneꢀpot efficient Heck coupling
in water catalyzed by palladium nanoparticles tethered into mesoporous
organic polymer, J. Mol, Catal A: Chem, 2011, 350, 40ꢀ48.
53 B. Asadi, I. MohammadpoorꢀBaltork, S. Tangestaninejad, M.
Moghadam, V. Mirkhani, A. LandaraniꢀIsfahani, Synthesis and
characterization of Bi(III) immobilized on triazine dendrimerꢀ
stabilized magnetic nanoparticles: a reusable catalyst for synthesis of
aminonaphthoquinones and bisꢀaminonaphthoquinones. New J.
Chem. 2016, DOI:10.1039/C5NJ03050A
39 R. Kardanpour, S. Tangestaninejad, V. Mirkhani, M. Moghadam, I.
Mohammadpoor−Baltork, A. R. Khosropour and F. Zadehahmadi,
Highly dispersed palladium nanoparticles supported on amino
functionalized metalꢀorganic frameworks as an efficient and reusable
This journal is © The Royal Society of Chemistry 2012
J. Name., 2012, 00, 1-3 | 11

RSC Advances
Page 12 of 13
VJieowuArrtnicalelONnlainme e
ARTICLE
DOI: 10.1039/C6RA16704G
54 A. Landarani Isfahani, I. MohammadpoorꢀBaltork, V. Mirkhani, A. 65 S. Gao, N. Zhao, M. Shu and S. Che, Palladium nanoparticles supported
R. Khosropour, M. Moghadam, S. Tangestaninejad, Pd Nanoparticles
Immobilized on Nanosilica Triazine Dendritic Polymer: A Reusable
on MOFꢀ5: A highly active catalyst for a ligandꢀ and copperꢀfree
Sonogashira coupling reaction. Appl. Catal A: Gen. 2010, 388, 196ꢀ201.
Catalyst for the Synthesis of Monoꢀ, Diꢀ, and Trialkynylaromatics by 66 A. S. Roy, J. Mondal, B. Banerjee, P. Mondal, A. Bhaumik and S. M.
Sonogashira CrossꢀCoupling in Water. Eur. J. Org. Chem. 2014, Islam, Pdꢀgrafted porous metal–organic framework material as an
2014 5603–5609. efficientand reusable heterogeneous catalyst for C–C
55 A. Landarani Isfahani, I. MohammadpoorꢀBaltork, V. Mirkhani, M. couplingreactions in water. Appl. Catal A: Gen. 2014, 469, 320−327.
Moghadam, A. R. Khosropour, S. Tangestaninejad, M. Nasrꢀ 67 Z. Pahlevanneshan, M. Moghadam, V. Mirkhani, S. Tangestaninejad,
,
Esfahani, H. Amiri Rudbari, Palladium Nanoparticles Immobilized
on Nanosilica Triazine Dendritic Polymer (PdnpꢀnSTDP) as Catalyst
in the Synthesis of Monoꢀ, Diꢀ, and Trisulfides through C–S Crossꢀ
Coupling Reactions. Synlett, 2014, 25, 645−652.
I. Mohammadpoor−Baltork and S. Rezaei, Suzuki–Miyaura C–C
coupling reactions catalyzed by a homogeneous and nanosilica
supported palladium(II)
Nꢀheterocyclic carbene complex derived
from 3,5ꢀdi(1ꢀimidazolyl)pyridine. New J. Chem. 2015, 39, 9729ꢀ
56 I. MohammadpoorꢀBaltork, M. Moghadam, M. NasrꢀEsfahani, A. R.
9734.
Khosropour, S. Tangestaninejad, V. Mirkhani, A. Agabekov, H. 68 S. Yasar, E. O. Ozcan, N. Gubuz, B. Cetinkaya and I. Ozdemir.
Amiri Rudbari, Copper immobilized on nanoꢀsilica triazine
dendrimer (Cu(II)ꢀTD@nSiO2) catalyzed synthesis of symmetrical
and unsymmetrical 1,3ꢀdiynes under aerobic conditions and ambient
PalladiumꢀCatalyzed Heck Coupling Reaction of Aryl Bromides in
Aqueous Media Using Tetrahydropyrimidinium Salts as Carbene
Ligands. Molecules, 2020, 15, 649−659.
temperature. RSC Adv. 2014,
4, 14291−14296.
69 W. A. Herrmann and V. P. W. Bohm, Heck reaction catalyzed by
57 M. NasrꢀEsfahani, I. MohammadpoorꢀBaltork, A. R. Khosropour, M.
Moghadam, V. Mirkhani, S. Tangestaninejad, H. Amiri Rudbari,
phosphaꢀpalladacycles in nonꢀaqueous ionic liquids. J. Organomet.
Chem. 1999, 572. 141−145.
Copper Immobilized on Nanosilica Triazine Dendrimer (Cu(II)ꢀ 70 K. Okumura, T. Tomiyama, S. Moriyama, A. Nakamichi and M.
TD@nSiO2)ꢀCatalyzed Regioselective Synthesis of 1,4ꢀDisubstituted
1,2,3ꢀTriazoles and Bisꢀ and TrisꢀTriazoles via OneꢀPot
Niwa, Enhancement in the Catalytic Activity of PD/USY in the Heck
a
Reaction Induced by H2 Bubbling. Molecules, 2011, 16, 38−51.
Multicomponent Click Reaction. J. Org. Chem., 2014, 79, 1437– 71 M. Yigit, G. Bayam, B. Yigit and I. Ozdemir, The Synthesis of 1,3ꢀ
1443.
dialkylꢀ4ꢀmethylimidazolinium Salts and Their Application in
58 N. Tsubokawa, H. Ichioka, T. Satoh, S. Hayashi, K. Fujiki, Grafting
of ‘dendrimerꢀlike’ highly branched polymer onto ultrafine silica
surface. React. Funct. Polym. 1998, 37, 75–82.
Palladium Catalyzed Heck Coupling. Turkish J. Chem. 2015, 39,
281−289.
72 L. Yu, Y. Huang, Z. Wei, Y. Ding, C. Su and Q. Xu, Heck Reactions
Catalyzed by Ultrasmall and Uniform Pd Nanoparticles Supported on
Polyaniline. J. Org. Chem. 2015, 80, 8677−8683.
59 V. I. Kovalenko, V. L. Furer, A. E. Vandyukov, R. R. Shagidullin, J.
P. Majoral and A. M. Caminade, The vibrational spectra of
elementoorganic starburst dendrimers. J. Mol. Struct. 2002, 604
,
73 Y. C. Lin, H. H. Hsueh, S. Kanne, L. K. Chang, F. C. Liu and I. J. B.
Lin. Efficient PEPPSIꢀThemed Palladium NꢀHeterocylic Carbene
Precatalysts for the MizorokiꢀHeck Reaction. Organometallics, 2013,
32, 3859ꢀ3869.
45−56.
60 S. Yoo, J. D. Lunn, S. Gonzalez, J. A. Ristich, E. E. Simanek and F.
Shantz, Engineering Nanospaces: OMS/Dendrimer Hybrids
Processing Controllable Chemistry and Porosity. Chem. Mater. 2006,
18, 2935ꢀ2942.
61 R. Bernini, S. Cacchi, G. Fabrizi, G. Forte, F. Petrucci, A. Prastaro,
S. Niembro, A. Shafird and A. Vallribera, Perfluoroꢀtagged,
phosphineꢀfree palladium nanoparticles supported on silica gel:
application to alkynylation of aryl halides, Suzuki–Miyaura crossꢀ
coupling, and Heck reactions under aerobic conditions. Green Chem
.
2010, 12, 150–158.
62 Moulder, J. F.; Stickle, W. F.; Sobol, P. E.; Bomben, K. D.;
Handbook of Xꢀray Photoelectron Spectroscopy, PerkinꢀElmer Corp.,
Eden Prairie, M. N., 1992, p. 118.
63 C. L. Deng, S. M. Guo, Y. X. Xie and J. H. Li, Mild and LigandꢀFree
PalladiumꢀCatalyzed CrossꢀCouplings between Aryl Halides and
Arylboronic Acids for the Synthesis of Biaryls and Heterocycleꢀ
Containing Biaryls. Eur. J. Org. Chem. 2007, 1457–1462.
64 I. D. Kostas, B. R. Steele, A. Terzis, S. V. Amosova, A. V. Martynov
and N. A. Makhaeva, New Palladium Complexes with Sꢀ or Seꢀ
Containing SchiffꢀBase Ligands as Efficient Catalysts for the
Suzuki–Miyaura CrossꢀCoupling Reaction of Aryl Bromides with
Phenylboronic Acid under Aerobic Conditions. Eur. J. Inorg. Chem
.
2006, 2642–2646.
12 | J. Name., 2012, 00, 1-3
This journal is © The Royal Society of Chemistry 2012

Page 13 of 13
RSC Advances
View Article Online
DOI: 10.1039/C6RA16704G
199x66mm (144 x 144 DPI)
