Investigating the binding mode of reversible LSD1 inhibitors derived from stilbene derivatives by 3D-QSAR, molecular docking, and molecular dynamics simulation

Article abstract of DOI:10.3390/molecules24244479

Overexpression of lysine specific demethylase 1 (LSD1) has been found in many cancers. Newanticancer drugs targeting LSD1 have been designed. The research on irreversible LSD1 inhibitors has entered the clinical stage, while the research on reversible LSD1 inhibitors has progressed slowly so far. In this study, 41 stilbene derivatives were studied as reversible inhibitors by three-dimensional quantitative structure-activity relationship (3D-QSAR). Comparative molecular field analysis (CoMFA q2 = 0.623, r2 = 0.987, r2 pred = 0.857) and comparative molecular similarity indices analysis (CoMSIA q2 = 0.728, r2 = 0.960, r2 pred = 0.899) were used to establish the model, and the structure-activity relationship of the compounds was explained by the contour maps. The binding site was predicted by two different kinds of software, and the binding modes of the compounds were further explored. A series of key amino acids Val288, Ser289, Gly314, Thr624, Lys661 were found to play a key role in the activity of the compounds. Molecular dynamics (MD) simulations were carried out for compounds 04, 17, 21, and 35, which had different activities. The reasons for the activity differences were explained by the interaction between compounds and LSD1. The binding free energy was calculated by molecular mechanics generalized Born surface area (MM/GBSA). We hope that this research will provide valuable information for the design of new reversible LSD1 inhibitors in the future.

Full text of DOI:10.3390/molecules24244479

molecules
Article
Investigating the Binding Mode of Reversible LSD1
Inhibitors Derived from Stilbene Derivatives by
3D-QSAR, Molecular Docking, and Molecular
Dynamics Simulation
Yongtao Xu 1,2,3,
*
, Zihao He 1,2,3, Min Yang 1,2,3, Yunlong Gao 1,2,3, Linfeng Jin 4,
Meiting Wang 1,5, Yichao Zheng 6, Xiaoyuan Lu 1, Songjie Zhang 1,2,3, Chang Wang 1,
Zongya Zhao 1, Junqiang Zhao 7, Qinghe Gao 4,
*
and Yingchao Duan 4,
*
1
School of Medical Engineering, Xinxiang Medical University, Xinxiang 453003, China;
hezihao311@163.com (Z.H.); yangmin@xxmu.edu.cn (M.Y.); zezt113919@163.com (Y.G.);
wangmeitingbetter@163.com (M.W.); luxy@xxmu.edu.cn (X.L.); zsj2002@xxmu.edu.cn (S.Z.);
wangchang@xxmu.edu.cn (C.W.); zhaozongya_paper@126.com (Z.Z.)
Xinxiang Key Laboratory of Biomedical Information Research, Xinxiang 453003, China
Henan Engineering Laboratory of Combinatorial Technique for Clinical and Biomedical Big Data,
Xinxiang 453003, China
School of Pharmacy, Xinxiang Medical University, Xinxiang 453003, China; jlf1053296686@163.com
State Key Laboratory of Precision Spectroscopy, School of Physics and Materials Science, East China Normal
University, Shanghai 200062, China
Key Laboratory of Advanced Pharmaceutical Technology, Ministry of Education of China, Co-Innovation
Center of Henan Province for New Drug R & D and Preclinical Safety, Institute of Drug Discovery and
Development, School of Pharmaceutical Sciences, Zhengzhou University, 100 Kexue Avenue,
Zhengzhou 450001, China; yichaozheng@zzu.edu.cn
2
3
4
5
6
7
College of Sanquan, Xinxiang Medical University, Xinxiang 453003, China; 06061002@sqmc.edu.cn
Correspondence: yxu@xxmu.edu.cn (Y.X.); gao_qinghe@xxmu.edu.cn (Q.G.);
duanyingchao1986@163.com (Y.D.); Tel.: +0086-15560156065 (Y.X.); +0086-15893849927 (Q.G.);
+0086-13781977941 (Y.D.)
*
ꢀꢁꢂꢀꢃꢄꢅꢆꢇ
Academic Editor: Florenci V. González
Received: 10 October 2019; Accepted: 3 December 2019; Published: 6 December 2019
ꢀꢁꢂꢃꢄꢅꢆ
Abstract: Overexpression of lysine specific demethylase 1 (LSD1) has been found in many cancers.
New anticancer drugs targeting LSD1 have been designed. The research on irreversible LSD1 inhibitors
has entered the clinical stage, while the research on reversible LSD1 inhibitors has progressed slowly
so far. In this study, 41 stilbene derivatives were studied as reversible inhibitors by three-dimensional
quantitative structure–activity relationship (3D-QSAR). Comparative molecular field analysis (CoMFA
q2 = 0.623, r2 = 0.987, rp2red = 0.857) and comparative molecular similarity indices analysis (CoMSIA
q2 = 0.728, r2 = 0.960, rp2red = 0.899) were used to establish the model, and the structure–activity
relationship of the compounds was explained by the contour maps. The binding site was predicted by
two different kinds of software, and the binding modes of the compounds were further explored. A
series of key amino acids Val288, Ser289, Gly314, Thr624, Lys661 were found to play a key role in the
activity of the compounds. Molecular dynamics (MD) simulations were carried out for compounds
04, 17, 21, and 35, which had different activities. The reasons for the activity differences were
explained by the interaction between compounds and LSD1. The binding free energy was calculated
by molecular mechanics generalized Born surface area (MM/GBSA). We hope that this research will
provide valuable information for the design of new reversible LSD1 inhibitors in the future.
Keywords: LSD1; molecular inhibitors; stilbene derivatives; molecular docking; 3D-QSAR; molecular
dynamics simulations
Molecules 2019, 24, 4479; doi:10.3390/molecules24244479
www.mdpi.com/journal/molecules

Molecules 2019, 24, 4479
2 of 28
1. Introduction
Epigenetic post-transcriptional modifications of DNA or histone, such as methylation, acetylation,
and phosphorylation, can remodel the chromatin structure (heterochromatin or euchromatin) to
regulate the expression of genes [1,2]. Histone methylation has been considered irreversible. The
discovery of lysine-specific demethylase 1 (LSD1, also known as KDM1A) in 2004 revealed that histone
methylation was a dynamically adjustable process. LSD1 belongs to flavin adenine dinucleotide
(FAD)-dependent amine oxidase family [3], and LSD1 functions as an enzyme that demethylates mono-
and dimethylated histone 3 lysine 4 (H3K4me1, H3K4me2) and histone 3 lysine 9 (H3K9me1, H3K9me2)
by utilizing its noncovalently bound FAD cofactor, which requires a pair of lone pairs of electrons in the
substrate; therefore, LSD1 cannot act on trimethylated lysine [
factor corepressor 1 (CoREST) exist together in the form of transcriptional corepressor complexes.
When LSD1 is combined with chromatin, CoREST can keep the overall structure of LSD1 stable [ ].
4]. LSD1 and RE1-silencing transcription
5
LSD1 can also remove the methyl of nonhistone proteins, such as p53, signal transducer and activator
of transcription 3 (STAT3), E2F transcription factor 1 (E2F1), and DNA methyltransferase 1 (DNMT1),
which shows that LSD1 has an impact on the function of downstream cells [
of LSD1 has been detected in various solid tumors, including retinoblastoma, non-small cell lung
cancer, prostate cancer, breast cancer, acute myeloid leukemia, and colon cancer [11 16]. LSD1 is not
6–10]. The overexpression
–
only an important biological significance, but also a potential drug target for therapy of cancer.
Because LSD1 and monoamine oxidases (MAOs) A and B are homologous proteins, their sequence
similarity reaches 17.6%. Some MAO inhibitors bond covalently with FAD to inhibit the activity of
LSD1, such as tranylcypromine (TCPA), as seen in Figure 1A, phenelzine, as seen in Figure 1B, and
pargyline, as seen in Figure 1C. Unfortunately, these inhibitors had no significant inhibitory effect
on LSD1 and poor selectivity [17]. However, by optimizing the structure of these compounds, LSD1
inhibitors with high activity have been designed, such as ORY-1001, as seen in Figure 1D [18], and
GSK2879552, as seen in Figure 1E [19], which are both TCPA derivatives. At present, they have entered
clinical research and have shown good inhibition of LSD1: IC50 = 18 nM and IC50 = 20 nM, respectively.
These inhibitors mentioned above were irreversible inhibitors, which were characterized by covalent
binding with FAD. At the same time, many reversible LSD1 inhibitors have been reported, which can
be divided into two categories: FAD-competing inhibitors and substrate-competing inhibitors. The
IC50 of GSK-354, as seen in Figure 1F, was 90 nM [20]. In 2017, an inhibitor IC50 = 7.8 nM was reported
and the structure was provided, as shown in Figure 1G [21]. In 2017 and 2018, a series of stilbene
derivatives were reported and evaluated as potential inhibitors for the treatment of acute myelogenous
leukemia (AML). The most active inhibitor IC50 = 121.23 nM is shown in Figure 1H [22,23]. Nowadays,
there is no reversible inhibitor in clinical trials. Therefore, designing new efficient reversible inhibitors
is still a big challenge.
Figure 1.
(A–H) represent structures of several reported lysine specific demethylase 1 (LSD1) inhibitors.
Class H small molecules are the focus of this study.

Molecules 2019, 24, 4479
3 of 28
In recent years, the rapid development of new drug research depends on computer-aided drug
design (CADD) [24]. 3D-QSAR, molecular docking, and molecular dynamics (MD) are commonly used
in CADD methods. 3D-QSAR can predict the activity of new compounds which contain a common
skeleton. The key groups affecting the activity of compounds are found, which then provide guidance
for the design of new compounds [25]. Molecular docking is often used to explore the binding mode
of ligands and to study ligand–receptor interaction, but receptor flexibility cannot be determined
during molecular docking [26]. However, in the process of MD, ligand and receptor flexibility can
be taken into account, and the stability of the whole complex can also be observed [27]. Therefore,
molecular docking and MD are usually combined to investigate possible bonding modes and detailed
ligand–receptor interactions. At the same time, key amino acids which have important effects on
activity will be found.
This study was mainly focused on the small molecule inhibitor of LSD1. It has been reported
that stilbene derivatives have a significant effect on inhibiting LSD1 [22,23]. We hope to design and
synthesize better LSD1 inhibitors on this basis. We synthesized 11 new stilbene derivatives and tested
their activity using the same investigated enzyme inhibition experiment with LDS1 as the target.
Unfortunately, their activity was not as good as we expected, even lower than the reported small
molecules. In order to find out the reason for the difference of activity of these small molecules, we used
CADD to carry out a series of studies. To explore the structure–activity relationship of these inhibitors,
41 complexes (30 collected from literature [22,23] and 11 newly synthesized) were used for building
the 3D-QSAR model. In a series of stilbene derivatives reported in 2018, the optimal small molecule
binding site in this series was the FAD cavity of LSD1, as determined by enzyme kinetics studies [23].
However, the binding site of a series of compounds reported in 2017 was not found. Because there are
no reports on the crystal structures of such inhibitors, we combined molecular docking and MD to
explore the possible binding mode of such compounds. We hope that a series of studies could find the
key information affecting the activity of such inhibitors and help the development of reversible LSD1
inhibitors in the future.
2. Materials and Methods
2.1. Determination of LSD1 Inhibitor Activity
The IC50 testing of the 11 newly synthesized compounds was carried out in accordance with the
previously reported method [22,23]. Synthetic routes and the characterization data of the compounds
are shown in Supplementary Information S1. LSD1 demethylated its substrate H3K4me2 to form H3K4
and produced a molecule of hydrogen peroxide. In the presence of fluorescent dye Amplex Red and
horseradish peroxidase (HRP), hydrogen peroxide can oxidize Amplex Red under the action of HRP to
form a molecule of fluorescent Resorufin. Resorufin can be detected at an excitation wavelength of 530
nm and emits at 590 nm. When LSD1 inhibitors restrained the function of LSD1, the production of
hydrogen peroxide decreased, and the production of Resorufin also decreased. Therefore, the inhibition
ability of LSD1 could be judged by detecting the fluorescence intensity. LSD1 at a final concentration of
0.25
solution with final concentration of 50 mM pH = 7.5 for 10 min. Then the LSD1 substrate H3K4me2
at a final concentration of 25 M (composed of 21 amino acids, polypeptide modified by the fourth
lysine dimethyl group) was added and incubated at 37 ◦C for 10 min. Then, DMSO solution with a
final concentration of 10 M Amplex Red, and HEPES solution with 10 U/mL HRP were added and
µM, and drugs with different concentrations were incubated at room temperature in HEPES buffer
µ
µ
incubated at room temperature for 5 min. The fluorescence intensity was detected at 530 nm excitation
wavelength and 590 nm emission wavelength by an enzyme labeling instrument.
The fluorescence intensity of the tested pore and 100% active pore were compared, and the
inhibition rate of the compound at a specific concentration was calculated according to the following
Equation (1).

Molecules 2019, 24, 4479
4 of 28
Absorbance of control − Absorbance of the sample
Inhibition(%) =
× 100%
(1)
Absorbance of the control
All experiments were performed in triplicate.
2.2. Data Sets
The data set included 30 reported compounds [22
,
23] and 11 newly synthesized compounds.
The structure and activity data of these 41 compounds are shown in Table 1. The 3D structure of all
compounds was established by the Sketch module in SYBYL-X2.0. The range of pIC50 for data sets was
from 4.443 to 6.917, the active span was large, and the distribution was uniform, which are the basic
requirements of 3D-QSAR modeling. In the process of partitioning the training set and test set, the
value of pIC50 should be satisfied: Max (test)
≤
max (training) and min (test)
≥
min (training) [28]. At
the same time, the diversity of substituent groups of compounds in the test set should be considered.
The distribution of pIC50 in the test set should be uniform in the whole data set, as seen in Figure S1.
The number of test sets should be 20%–25% of the whole data set. Based on the above criteria, 32
training sets were used to build the 3D-QSAR model, and nine test sets (22% of the total data set) were
used to test the predictive ability of the model.
2.3. Alignment and Generation of the 3D-QSAR Models
The 3D-QSAR model was built using SYBYL-X2.0. Molecular alignment is generally considered
to be a key factor affecting the stability and predictability of the model. This study used a common
skeleton-based alignment approach. Firstly, Gastieger–Huckel charges were added to all small
molecules to minimize energy under Tripos force field. Using the Powell gradient algorithm, the
maximum number of iterations was set to 1000, and the convergence criterion was limited to
0.001 kcal mol−1
Å
−1. Secondly, compound 04 with the highest activity, as seen in Figure 2A, was
selected as the template molecule. Finally, the remaining small molecules were superimposed on the
common skeleton of the red part of Figure 2A. The alignment results of the training set based on the
common skeleton are shown in Figure 2B.
A
B
Figure 2.
(A) Structure of compound 04. The red color is the common framework for superposition.
(B) Overlapping results of training set compounds.

Molecules 2019, 24, 4479
5 of 28
Table 1. The structures and the actual and predicted activities of LSD1 inhibitors by comparative molecular field analysis (CoMFA) and comparative molecular
similarity indices analysis (CoMSIA).
IC50
(µM)
CoMFA
pred res
CoMSIA
pred res
Binding
Mode
pIC50
X1
R1
R2
R3
R4
R5
R6
No.
1 *
2 *
3
C
C
C
C
C
C
C
OH
F
OH
OH
H
H
H
H
H
H
Br
F
H
H
H
H
H
H
0.333
0.245
2.59
6.478 6.315 0.163 6.497
−
0.019
I
I
I
I
I
I
I
6.611 6.490 0.121 6.289 0.322
OH
OH
OH
H
OH
H
5.587 5.658
6.917 6.968
−
−
0.071 5.831
0.051 6.95
−
−
0.244
0.033
4
OH
OH
OH
OH
0.121
0.192
0.210
0.739
5
H
6.717 6.655 0.062 6.632 0.085
6.678 6.512 0.166 6.299 0.379
6
H
H
H
7 *
OH
H
H
H
H
H
6.131 6.404
6.308 6.322
6.408 6.514
−
−
−
0.273 6.518
−
0.387
8
9
C
C
C
F
H
OH
OH
OH
H
H
H
H
H
F
0.492
0.391
0.197
0.014 6.275 0.033
I
I
I
0.106 6.38
0.028
10 *
OH
6.706 6.438 0.268 6.717
−
0.011

Molecules 2019, 24, 4479
6 of 28
Table 1. Cont.
IC50
(µM)
CoMFA
pred res
CoMSIA
pred res
Binding
Mode
pIC50
X1
R1
R2
R3
R4
R5
R6
No.
11
12
13
C
C
C
OH
OH
OH
H
H
OH
H
Br
H
H
H
H
0.123
10.2
4.24
6.910 6.886 0.024
4.991 4.982 0.009
7.07
4.94
−
0.160
I
I
OH
H
0.051
OH
OH
5.373 5.383
−
0.010 5.526
−
0.153
II
14
15
16
17
18
19
C
C
C
C
C
C
OH
OH
OH
OH
OH
OH
H
H
H
H
H
H
H
H
H
H
H
H
H
H
0.72
1.29
0.92
3.57
0.859
1.47
6.143 6.107 0.036 6.065 0.078
5.889 6.188 0.299 6.121 0.232
II
II
II
II
II
II
−
−
H
H
6.036 6.006 0.030 5.838 0.198
5.447 5.432 0.015 5.557 0.110
6.066 5.884 0.182 5.788 0.278
NH2
H
−
NH2
NH2
H
5.833
5.88
−
0.047 5.945
−
−
0.112
0.183
20
N
-
H
H
H
0.364
6.439 6.382 0.057 6.622
II
21
22
N
N
N
-
-
-
H
H
H
H
H
H
H
H
0.764
0.283
2.96
6.117 6.078 0.039 6.022 0.095
II
II
II
H
6.548 6.566
5.529 5.901
−
−
0.018 6.361 0.187
23 *
NH2
0.372 5.667
−
0.138

Molecules 2019, 24, 4479
7 of 28
Table 1. Cont.
IC50
(µM)
CoMFA
pred res
CoMSIA
pred res
Binding
Mode
pIC50
X1
R1
R2
R3
R4
R5
R6
No.
24 *
25
C
C
C
C
OMe
OMe
OMe
OMe
OMe
OMe
H
H
H
H
F
H
H
H
H
4.161
3.315
5.185
3.979
5.381 5.429
−
0.048 5.388
−
0.007
III
III
III
III
5.480 5.466 0.014 5.438 0.042
26
OMe
H
H
Br
5.285 5.288
5.400 5.534
−
−
0.003 5.176 0.109
0.134 5.553 0.153
27 *
OMe
−
29
30
C
C
C
C
C
C
C
OMe
OMe
F
H
OMe
H
OMe
H
H
H
H
Br
F
H
H
H
H
H
H
H
0.692
0.816
1.298
0.701
0.891
16.21
29.58
6.160 6.195
6.088 6.089
−
−
0.035 6.038 0.122
III
III
III
III
III
I
0.001 6.095
−
0.007
31 *
32
F
5.887 5.875 0.012 5.837 0.050
OMe
OMe
F
OMe
OMe
F
H
6.154 6.105 0.049 6.271
−
−
−
−
0.117
0.080
0.035
0.002
34
H
6.050 6.117
4.790 4.812
−
−
0.067 6.13
0.022 4.825
35
H
H
H
36
OH
OH
H
4.529 4.513 0.016 4.531
4.443 4.464
4.696 4.674 0.022 4.796
I
38
39
C
C
OH
OH
H
H
H
H
OH
-H
H
36.09
20.14
−
0.021 4.405 0.038
0.100
II
II
NH2
−

Molecules 2019, 24, 4479
8 of 28
Table 1. Cont.
IC50
CoMFA
pred res
CoMSIA
pred res
Binding
Mode
pIC50
X1
R1
R2
R3
R4
R5
R6
No.
(µM)
18.96
9.03
40
41
C
-
-
OH
H
H
H
NH2
H
H
4.722 4.747
5.044 5.052
−
−
0.025 4.769
0.008 5.052
−
−
0.047
0.008
II
II
N
NH2
CoMFA
CoMSIA
pred Res
Binding
Mode
pIC50
IC50 (µM)
No.
pred
res
28
33
37 *
4.666
1.93
10.36
5.331
5.888
4.985
5.304
5.84
4.657
0.027 5.395
0.0482 5.927
0.3282 5.128
−
−
−
0.0635 III
0.0386 III
0.1426
I
* indicates the compound belongs to the test set. I, II, and III represent the binding modes of the compounds. Newly synthesized compounds have been underlined.

Molecules 2019, 24, 4479
9 of 28
In this study, comparative molecular field analysis (CoMFA) and comparative molecular similarity
indices analysis (CoMSIA) were used to establish 3D-QSAR models. CoMFA includes steric and
electrostatic fields, which are calculated by Lennard-Jones and Coulombic potential functions. The
superimposed molecule was placed in a three-dimensional space consisting of cube lattice (edge
length = 2 Å). The structure of molecule was calculated by using SP3 hybrid carbon atom (van der
Waals radius = 1.52 Å, net charge was + 1.0) as the probe atom. During the whole process, the energy
cut-off value was set to 30 kcal/mol [29]. CoMSIA described the structural characteristics of molecule
by calculating steric field, electrostatic field, hydrophobic field, hydrogen bond acceptor field, and
hydrogen bond donor field parameters. The best CoMSIA model can be obtained by combining
different fields. Like in CoMFA, a SP3 hybrid carbon atom is used as probe atom in the calculation
of steric and electrostatic fields. Hydrophobic parameters, hydrogen bond acceptor parameters, and
hydrogen bond donor parameters are set to +1 when calculating other fields. In the calculation
process, the attenuation factor was set to 0.3. There is no need to set an energy cut-off value, because a
Gaussian function is used to evaluate the distance between probe atom and each atom in molecule
in CoMSIA [30]. As mentioned above, CoMSIA is an extension of CoMFA, and the principles are
basically the same; both are forms of QSAR (quantitative structure analysis relationships). They differ
only in the implementation of the fields. The following assumptions should be satisfied in application:
1) There is no covalent bond between the small molecule and the receptor; 2) The change of binding
affinities of small molecules is related to molecular properties, represented by fields.
2.4. CoMFA and CoMSIA Statistical Analysis
Using partial least squares (PLS) regression analysis, we constructed linear a correlation between
descriptors (independent variables) of the 3D-QSAR model and the pIC50 (dependent variables).
Cross-validation correlation coefficient q2 and optimum number of components (ONC) were obtained
by leave-one-out (LOO) cross-validation [31]. q2 is used to evaluate the internal validation ability of
the model. Generally, q2 > 0.5 is acceptable. The calculation equation(2) is as follows [32]:
ꢀ
ꢁ
P
2
yi − ypred
q2 = 1 −
(2)
ꢀ
ꢁ
P
2
yi − y
where yi and ypred represent the experimental and predicted values in the training set, respectively.
y
is the average value of the whole training set. Based on obtained ONC, the noncross-validation
correlation coefficient
r
2, F-statistic values (F), standard error of estimate (SEE), and the contribution of
each field to the establishment of the model are further calculated by noncross-validation analysis. The
external prediction ability of the model can be preliminarily evaluated by calculating the predictive
correlation coefficient (r2pred). r2pred > 0.6 means the model may have good prediction ability. The
calculation equation(3) is as follows [25]:
PRESS
SD
r2pred = 1 −
(3)
The PRESS represents the sum of squares of the difference between the experimental value and
the predicted value in the test set. SD is the sum of squares of the difference between the experimental
values of compounds in the test set and the average values in the training set.
However, r2pred
>
0.6 is only the premise that the model has good external validation. The real
external prediction ability needs evaluation of some external validation parameters, such as R2, k,
k0, R02 R02, and rm2 R2 represents the correlation coefficients (not passing through the origin) between
, .
experimental values and the predicted values in the test set. R20 and k are the correlation coefficients of
the experimental value (X) and predicted value (Y) and the slope of regression line (passing through
the origin). R20 and k0 are the correlation coefficients of the predicted value (Y) and experimental value

Molecules 2019, 24, 4479
10 of 28
(X) and the slope of regression line (passing through the origin). The calculation equations(4-9) are as
follows [33]:
h ꢀ
P
ꢁꢀ
ꢁi
2
Yobs − Yobs Ypred − Ypred
R2
=
(4)
ꢀ
P
ꢁ
ꢀ
ꢁ
2
P
2
Ypred − Ypred
×
Yobs − Yobs
ꢀ
P
ꢁ
Yobs × Ypred
k =
(5)
ꢀ
ꢁ
P
2
Ypred
ꢀ
ꢁ
P
Yobs × Ypred
k’ =
(6)
(7)
P
2
(Yobs
)
ꢀ
ꢁ
P
2
Yobs − k × Ypred
R20 = 1 −
R’20 = 1 −
ꢀ
ꢁ
P
2
Yobs − Yobs
ꢀ
ꢁ
P
2
Ypred − k × Yobs
(8)
(9)
ꢀ
ꢁ
P
2
Ypred − Ypred
!
q
r2m = R2 × 1 − R2 − R20
In the above formulas, Yobs and Ypred represent the experimental and predicted values in the test
set. Yobs and Ypred are the average values of the experimental and predicted values in the test set.
The robustness of 3D-QSAR model can be verified by a Y-randomization test [34]. In the case of
independent variable X, matrix unchanged, and randomly shuffled dependent variable Y, this process
repeats many times, and new q2 and r2 values are recorded. If the values of q2 and r2 are very low,
then the establishment of the model is not accidental and has strong robustness.
2.5. Molecular Docking
Before molecular docking, it is important to select the appropriate crystal structure. LSD1-CoREST
complexes, including FAD and histone H3 (PDB ID: 2V1D, resolution: 3.1 Å), were used in this study.
In order to obtain more reliable results, we chose MOE.2015 [35] and Glide of Maestro (Schro..dinger
LLC, New York, NY, 2014-2) for docking. For Glide docking, firstly, we deleted crystal water from the
PDB file and added hydrogen atoms to the entire complex. Then, we performed energy minimization.
The stereochemical parameters of the model used for docking were evaluated using a Ramachandran
plot and the overall goodness factor (G-factor) was obtained by Procheck [36]. In addition, verify
3D [37] and ERRAT [38] were used to evaluate the model (http://services.mbi.ucla.edu/saves/). Then,
we used the prepared PDB file to generate the receptor-grid file. For the FAD site, we set FAD as
the center and generated a box with side lengths of 20 Å
×
20 Å
×
20 Å. For substrate site, we set
20 Å 20 Å. Finally, 41 small
histone H3 as the center and generate a bo with a side length of 20 Å
×
×
×
molecules after minimizing energy were docked to the FAD-binding site and substrate-binding site,
separately. The standard precision mode (SP) was chosen, considering docking accuracy. Each small
molecule was set to generate 20 poses, and the top ten poses by Glide score were saved for further
study. The detailed process of MOE2015 is described in Supplementary Information S2.
2.6. Molecular Dynamics Simulations
In order to further explore ligand–receptor interaction and binding modes, 50 ns MD was
performed on the docking results of compounds 04, 17, 21, and 35. MD was performed using AMBER
14 software package [39]. The antechamber module was used to generate ligand parameter files.
Amberff10 force field was used for protein and GAFF force field was used for small molecules. The

Molecules 2019, 24, 4479
11 of 28
TIP3P water model was added and the margin was set to 8 Å. We checked the total charge of the
whole system and added Cl− to make the system appear electrically neutral. The topology file of
the complex was generated in a water environment. After energy minimization, heating in an NVT
ensemble (from 0 K to 300 K in 250 ps) and balancing 50 ps in an NPT ensemble (300 K, 1 atm) were
carried out. Eventually, 50 ns MD was performed using the NPT ensemble (300 K, 1 atm).
2.7. Binding Free Energy Calculations
Binding affinity between small ligands and receptors can be evaluated by binding free energy. In
this study, the binding free energy is calculated by the molecular mechanics/generalized Born surface
area (MM/GBSA) method using AMBER 14 software. The structures were extracted from the last 2 ns
trajectory file every 10 ps, and a total of 200 conformations were extracted for the calculation of binding
free energy (∆Gbind). The calculation equations(10-12) are as follows [28]:
ꢀ
ꢁ
∆Gbind = ∆Gcomplex − ∆Gprotein + ∆Gligand
(10)
= ∆Egas + ∆Gsol − T∆S
∆Egas = ∆Evdw + ∆Eele
(11)
(12)
∆Gsol = ∆GGB + ∆GSA
where ∆Gcomplex, ∆Gprotein, and ∆Gligand represent the total binding energy of complex, protein, and
ligand in solvent. ∆Egas is the interaction energy between the protein and ligand in gas phase, which can
be further decomposed in to ∆Evdw(van der Waals energy) and ∆Eele(electrostatic energy). ∆Gsol stands
for free energy of solvation, and can be obtained by ∆GGB(polar solvation energy) and ∆GSA(nonpolar
solvation energy). Then, ∆GGB is calculated by the generalized Born (GB) approximation model. T∆S
is the entropy contribution. Because the calculation of this value is time-consuming and difficult to
obtain accurately, the calculation of this term is often discarded [40].
3. Results and Discussion
3.1. Statistical Results of CoMFA and CoMSIA
To obtain the statistically best QSAR model, it is often necessary to adjust different field
combinations (one or more) to establish multiple models, calculate their statistical parameters, and
select the best CoMFA and CoMSIA models. The stepwise development [41] of the CoMFA model and
several CoMSIA models using different combinations of fields are shown in Table 2. It is generally
believed that the model with q2 > 0.5 has good internal verification ability. The q2 = 0.33 of CoMFA-E
(only using electrostatic field to build the model) indicated that it did not have good internal verification
ability. The q2 = 0.547 and rp2red = 0.77 of CoMFA-S (only using stereo field to build models) showed
that CoMFA-S had good internal verification and external prediction ability. However, the q2 and
r2pred of CoMFA-SE (combined with stereo and electrostatic fields) was considerably improved. The
cross-validated coefficient q2 = 0.623, and the predictive correlation coefficient r2pred = 0.857. The model
also had larger noncross-validated coefficient r2 = 0.987, lower SEE = 0.091, and F = 265.466. The
contributions of electrostatic field and steric field were 38.6% and 61.4%, respectively. To sum up,
CoMFA-SE was chosen as the final CoMFA model.
The q
2 of CoMSIA-SHAD and CoMSIA-SEHA were close, 0.728 and 0.726, respectively, indicating
that they had good internal verification ability. However, the r2pred of CoMSIA-SHAD was higher
than that of CoMSIA-SEHA (0.899 and 0.835, respectively), which indicated that CoMSIA-SHAD had
stronger external prediction ability. The model had larger r2 = 0.960, lower SEE value = 0.154, and
F value = 126.052. The contributions of steric, hydrophobic, and H-bond acceptor and donor fields
were 9.7%, 26.6%, 29.9%, and 33.9%, respectively. It showed that the H-bond donor field played an
important role in this model. In conclusion, CoMSIA-SHAD was chosen as the final CoMSIA model.

Molecules 2019, 24, 4479
12 of 28
Table 2. Statistical parameters of CoMFA and CoMSIA models. S—Steric, E—Electrostatic,
H—Hydrophobic, A—H-bond acceptor, D—H-bond donor.
Contributions
H
r2pred
q2
r2
ONC
SEE
F Value
S
E
A
D
CoMFA-S
CoMFA-E
CoMFA-SE
CoMSIA-EHAD
CoMSIA-SHAD
CoMSIA-SEAD
CoMSIA-SEHD
CoMSIA-SEHA
CoMSIA-ALL
0.547
0.33
2
9
7
5
5
4
4
6
4
0.781
0.993
0.987
0.962
0.960
0.942
0.937
0.977
0.945
0.77
0.342
0.071
0.091
0.151
0.154
0.182
0.190
0.120
0.178
51.718
340.959
265.466
129.944
126.052
110.417
100.367
174.365
114.875
1
-
-
1
-
-
-
-
-
-
-
-
-
0.692
0.857
0.800
0.899
0.803
0.819
0.835
0.820
0.623
0.674
0.728
0.639
0.700
0.726
0.704
0.386
-
0.614
0.276
-
0.326
0.329
0.325
0.262
0.214
0.266
-
0.239
0.258
0.193
0.226
0.299
0.254
-
0.319
0.206
0.283
0.339
0.325
0.342
-
0.097
0.094
0.090
0.098
0.075
0.264
Although r2pred > 0.6 for CoMFA-SE (hereafter referred to as CoMFA) and CoMSIA-SHAD
(hereafter referred to as CoMSIA), according to Tropsha [42], good r2pred is only a prerequisite, and a
series of external prediction parameters are needed to evaluate the true external prediction ability. The
external predictive parameters of the model and the criteria to be met are shown in Table 3. When
the model satisfied condition 1, condition 2a or 2b, condition 3a or 3b, condition 4a or 4b, condition
5, and condition 6, it can be evaluated that the model has strong real external prediction ability. rm2
denotes the approximation degree of the experimental and predicted values in the test set. CoMFA fit
each criterion. CoMSIA did not meet condition 4b, but satisfied condition 4a and other conditions.
Therefore, both CoMFA and CoMSIA had good external prediction ability.
Table 3. Results of external validation parameters for CoMFA and CoMSIA.
Condition
Parameters
Threshold Value
CoMFA
CoMSIA
R2
1
>0.6
Close to value of R2
Close to value of R2
0.85 < k < 1.15
0.85 < k‘ < 1.15
<0.1
0.855
0.851
0.847
1.001
0.998
0.005
0.009
0.004
0.799
0.861
0.857
0.755
0.983
1.010
0.005
0.123
0.102
0.804
R02
2a
2b
3a
3b
4a
4b
5
R02
k
k
(R2 − R20)/R2
(R2 − R20)/R2
| R20 − R20 |
rm2
<0.1
<0.3
>0.5
6
The predicted values of CoMFA and CoMSIA models for training set and test set are shown in
Table 1. The scatter plots of actual pIC50 and predicted pIC50 are shown in Figure 3. It can be seen
from the figure that the black solid cubes and the red solid dots are close to the straight line Y = X. The
actual value of the whole data set had a good linear relationship with the predicted value.
In addition, the robustness of the model was evaluated by Y-randomization testing. With the
original independent variable X matrix unchanged, the dependent variable (pIC50) was randomly
shuffled 10 times, and the details of randomly shuffled pIC50 values are shown in Table S1. If the q2
and r2 of these new models are very low or negative, it is not accidental that the final models have
high q2 and r2. The Y-randomization test results of CoMFA and CoMSIA models are shown in Table 4.
The q2 and r2 of the new model were very low, which showed that the previous final model has
good robustness.

Molecules 2019, 24, 4479
13 of 28
A
B
Figure 3. Plots of experimental activities against predicted activities by the optimal CoMFA model (
and CoMSIA model (B).
A)
Table 4. q2 and r2 values after several Y-randomization tests.
CoMFA
CoMSIA
q2
0.040
0.158
0.258
r2
0.436
0.49
0.475
0.401
0.484
0.484
0.364
0.459
0.423
0.382
q2
−0.052
−0.003
0.163
r2
Iteration
Random_1
Random_2
Random_3
Random_4
Random_5
Random_6
Random_7
Random_8
Random_9
Random_10
0.466
0.435
0.419
0.35
0.465
0.505
0.459
0.497
0.377
0.454
0.086
0.071
−0.113
−0.227
0.262
0.317
0.003
0.093
−0.206
−0.131
−0.425
−0.271
−0.178
−0.627
3.2. CoMFA Contour Maps
The 3D-QSAR model not only has the ability of prediction, but also can provide contour maps.
It is more convenient to study the relationship between structure and activity of compounds to find
the key groups affecting the activity, and to provide guidance for the design of new inhibitors in
the future. The contour maps of each field are displayed using the StDev*Coeff function, and the
visualization contribution of favorable and unfavorable regions is 80% and 20%, respectively. To
explain the contour maps more clearly, the structure with the highest activity, compound 04, was
inserted into all contour maps.
In the steric contour maps of CoMFA, the yellow block showed that reducing the volume of
substituted groups contributed to the increase of activity, while the green color block showed that
increasing the volume of the substituted groups was beneficial to the increase of activity. As shown
in Figure 4A, a medium-sized green color block appeared at the R2 of compound 04, suggesting
that an appropriate addition of substituents here would be beneficial to the improvement of activity.
For example, compounds
substitution at R2, while compound
R3, so the activity of compound
1
and
3
had hydroxyl substitution at R1, and compound
1
had a hydroxyl
3
had no hydroxyl substitution at R2 and a hydroxyl substitution at
1
(pIC50 = 6.478) was higher than that of compound 3 (pIC50 = 5.587).
Compound 24 and compound 26 had methoxy substitution at R1, and compound 24 had methoxy at
R2, but for compound 26, there was no methoxy substitution at R2, methoxy substitution at R3, so the
activity of 24 (pIC50 = 5.381) was higher than that of 26 (pIC50 = 5.285). The presence of a green block
at R4 indicated that increasing the volume here would increase the activity; for example, the activities

Molecules 2019, 24, 4479
14 of 28
of compound 04 (R4 = Br, pIC50 = 6.917) and compound 05 (R4 = F, pIC50 = 6.717) were higher than
compound (R4 = H, pIC50 = 6.478). Compound 10 (R4 = F, pIC50 = 6.706) and compound 11 (R4 = Br,
pIC50 = 6.910) had higher activities than compound (R4 = H, pIC50 = 6.131). A larger green block
1
7
appeared at R5, indicating that the addition of larger substituents would improve the activity. For
example, R5 of compound 13 (pIC50 = 5.373) was a hydroxyl group, while the R5 of compound 14
(pIC50 = 6.143) was an amidoxime, so the activity of compound 14 was higher than that of compound
13. Compound 15 (pIC50 = 5.889) had amidoxime at R5, and compound 37 (pIC50 = 4.443) had hydroxyl
at R5, so the activity of compound 15 was higher than that of compound 37. A large yellow block
appeared around R1, which indicated that the substituents in R1 should not be too large, otherwise
the activity would be reduced. For example, the R1 of compound
compound 14 (pIC50 = 6.143) was pyridine, and the R1 of compound 15 (pIC50 = 5.889) was pyrimidine,
so the activity of compound was higher than that of compounds 14 and 15. The R1 substituents of 39
2 (pIC50 = 6.611) was F, the R1 of
2
(pIC50 = 4.696) and 40 (pIC50 = 4.722) were larger, so their activities were lower.
A
B
Figure 4. CoMFA contour maps were based on compound 04 as the reference. (
A
) Steric contour
map. The green and yellow indicate that bulky groups are favored and disfavored, respectively. (B)
Electrostatic contour map. The blue and red indicate that electropositive groups were favored and
disfavored, respectively.
The contour maps of CoMFA electrostatic field are shown in Figure 4B. Blue indicated that the
introduction of electropositive group was beneficial to the increase of activity, while the introduction
of an electronegative group in a red region was favorable for increasing activity. There was a large
blue block at R1, which indicated that the introduction of electropositive group could improve the
activity. For example, the R1 of compound 18 (pIC50 = 6.066) was replaced by pyrimidine, the two
N atoms of pyrimidine ring were covered by blue, and the R1 of compound 19 (pIC50 = 5.833) was
replaced by hydroxyl pyridine, a strong electronegative group, so the activity of compound 18 was
higher than compound 19. There was a blue block at R6, which indicated that introducing a strong
electropositive group here was beneficial to the increase of activity. The strong electronegative oxygen
atom on the carbonyl of R6 of 25 (pIC50 = 5.480), 26 (pIC50 = 5.285), and 27 (pIC50 = 5.400) touched the
blue block, so their activities were not high. There was a red block near R5, which indicated that the
introduction of electronegative groups here would increase the activity. For example, R5 of compound
41 (pIC50 = 5.044) was replaced by –H, and its activity was low. R5 of compound 22 (pIC50 = 6.548) was
replaced by amidoxime. The hydroxyl on amidoxime touched a red block, so the activity of compound
22 was higher than that of compound 41. The R5 of compounds
4 (pIC50 = 6.917), 5 (pIC50 = 6.717),
and (pIC50 = 6.678) with higher activity were replaced by amidoxime, and the hydroxyl groups on
6
the amidoxime were all near the red color block.
3.3. CoMSIA Contour Maps
The steric contour map of CoMSIA is shown in Figure 5A, which is similar to the conclusion of
CoMFA: the proper increase of the volume of R2 and R5 substituents was beneficial to the increase of
activity. The contour map of the CoMSIA hydrophobic field is shown in Figure 5B. The yellow part
indicates that hydrophobic substituents would improve the activity, while the white area indicates that

Molecules 2019, 24, 4479
15 of 28
hydrophilic substituents would be beneficial to the activity. A yellow color block around R1 indicates
that introducing hydrophobic substituents here is beneficial to the increase of activity; for example,
compound 2 (pIC50 = 6.611, R1 = F) had higher activity than compound 1 (pIC50 = 6.478, R1 = OH). The
R1 of compound 14 (pIC50 = 6.143) was a pyridine ring, and that of compound 15 (pIC50 = 5.889) was a
pyrimidine ring, so the activity of compound 14 was higher than that of compound 15. The presence of
a yellow block at R4 indicated that the introduction of hydrophobic groups could improve the activity,
such as 4 (pIC50 = 6.917, R4 = Br), 1 (pIC50 = 6.478, R4 = H), 25 (pIC50 = 5.480, R4 = F), 24 (pIC50 = 5.381,
R4 = H). A small white block appeared near R5 and R6, which indicated that adding hydrophilic
groups in these positions would be beneficial to increase activity. Hydroxyl and amino groups at
the end of amidoxime are hydrophilic groups. Therefore, when amidoxime was substituted at R5 or
R6, the activity was better, such as in compound
2 (pIC50 = 6.611) and compound 4 (pIC50 = 6.917),
which had amidoxime structure at their R5 sites, and compound 11 (pIC50 = 6.910) and compound 16
(pIC50 = 6.036), which had amidoxime structures at R6.
A
B
C
D
Figure 5. CoMSIA contour maps were based on compound 04 as a reference. (
and yellow blocks indicate that bulky groups are favored and disfavored, respectively. (
field. Yellow blocks indicate that hydrophobic groups increase activity; white blocks indicate that
hydrophilic groups increase activity. ( ) Hydrogen bond donor field (displayed as line). Cyan blocks
indicate that H-bond donor groups increase activity; purple blocks indicate that H-bond donor groups
decrease activity. ( ) Hydrogen acceptor field. Magenta blocks indicate that H-bond acceptor groups
A
) Steric field. The green
B) Hydrophobic
C
D
increase activity; red blocks indicate that H-bond acceptor groups decrease activity.
As shown in Figure 5C, the CoMSIA hydrogen bond donor contour map showed that adding
hydrogen bond donor groups in the cyan part was beneficial to improve the activity, while purple
indicated that hydrogen bond donor groups in this position would hinder the activity. Because the
cyan block was wrapped by the purple block, the display mode was set to line shape for convenience
of observation. A cyan block at R2 indicated that introducing a hydrogen bond donor group at this
position would be beneficial to improving activity. Compounds 5 (pIC50 = 6.717) and 14 (pIC50 = 6.143)
had no hydrogen bond donor group at R2, so their activities were not high. There was a cyan block
near R5, which indicated that introducing a hydrogen bond donor group at this position would be
beneficial to the improvement of activity. Compounds
(pIC50 = 6.678) with amidoxime structure are found at R5, so they had higher activity. The amino group
in amidoxime just touched the cyan block, which may be the reason why compounds and had
4 (pIC50 = 6.917), 22 (pIC50 = 6.548), and 6
4
6

Molecules 2019, 24, 4479
16 of 28
higher activity. The R1 and R6 were surrounded by a purple block, which indicated that introducing
a hydrogen bond donor field into these positions was not conducive to the increase of activity. For
example, compounds 35 (pIC50 = 4.790), 37 (pIC50 = 4.985), and 39 (pIC50 = 4.696) had H-bond donor
groups at R6, while the substituent of R1 and R6 in compound 36 (pIC50 = 4.529) had H-bond donor
groups. However, according to the H-bond donor field contour map, the presence of H-bond donor
groups at R1 or R6 was not conducive to the activity of the compound, so their activities were low.
These examples mean that if the positions of H-bond donor groups in the compounds conform to the
positions given by the H-bond donor field contour map, the activities of these compounds were very
high. On the contrary, if the H-bond donor groups appeared in the position which was not conducive
to the activity suggested by the H-bond donor field contour map, the activity of these compounds
would suddenly decline. These analyses explained why the contribution of H-bond donors was the
highest in Table 2, because the H-bond donor group had an important influence on the activity of
this series of compounds. As shown in Figure 5D, the magenta block indicated that the hydrogen
bond receptor group had a positive effect on this position, while the red block indicated that the
hydrogen bond receptor group had a negative effect on this position. One magenta block appeared at
R2, suggesting that the addition of hydrogen bond receptor groups here would increase activity. For
example, compound 26 (pIC50 = 5.285) had –H at R2, and compound 24 (pIC50 = 5.381) had a methoxy
group at R2, so the activity of compound 24 was higher than that of compound 26. A red color block
appeared around R6, which indicated that adding a hydrogen bond acceptor group was not conducive
to the improvement of activity. For example, the hydroxyl group at R6 of compound 12 (pIC50 = 4.991)
and carbonyl group at R6 of compound 28 (pIC50 = 5.331) touched red blocks, so their activities were
not high.
The main structure–activity relationship (SAR) information found in 3D-QSAR is summarized in
Figure 6. For R1, the electropositive groups with small volume and weak polarity should be introduced
in the future compounds. If a larger volume group is introduced to R2, the activity might increase. It
was found that H-bond donor groups and H-bond acceptor groups were encouraged at R2. Hydrogen
and oxygen in hydroxyl groups can be used as H-bond donors and acceptors. Therefore, it is a
good choice to introduce hydroxyl or carboxyl groups into R2. The optimization proposal of R4 is to
introduce hydrophobic groups with large volume. In the existing compounds, R4 is generally replaced
by a halogen. In the next design, we break this limitation and try esters and nitro structures. R5
should introduce large-volume, electronegative, hydrophilic H-bond donor groups. The amidoxime
structure of this series of compounds can meet these requirements very well, so we can retain this
structure in the future optimization, and try to introduce new structures, such as acylamide, carboxyl,
etc. For R6, it is recommended to introduce electropositive and hydrophilic groups, and amino groups
could be introduced. We hope that these suggestions for structural changes can provide new ideas for
drug designers.
Figure 6. Structure–activity relationship (SAR) information obtained from three-dimensional
quantitative structure–activity relationship (3D-QSAR) study.

Molecules 2019, 24, 4479
17 of 28
3.4. Bonding Site Prediction
Results and detailed analysis of the Ramachandran plot, verify 3D, and ERRAT used to test
protein structure are shown in Supplementary Information S3. Enzyme kinetics studies were carried
out on compound 22, which is the most active of a series of compounds reported in 2018 [23]. It was
proved that the binding site of these compounds was in the FAD region, while the binding sites of
other compounds are not clear. Therefore, we need to determine the binding site in the FAD region
or substrate region. The locations of these two regions are shown in Figure 7. Previous studies have
shown that it is unreliable to evaluate binding affinity of ligand and receptor by docking score, and the
correlation between them was very low [43]. However, it is reliable to predict the binding site of a
small molecule by its docking score, and ligand scores at the correct binding site are better than those
at the wrong site [44].
Figure 7. Binding site of flavin adenine dinucleotide (FAD) and histone H3 in LSD1.
In order to get more credible results, Glide and MOE2015 were selected for the docking work.
Before docking, FAD was extracted from the crystal structure (PDB: 2V1D), and then docked with two
kinds of software to observe whether docking results can reproduce the crystal pose. When Glide was
used, the root mean square deviation (RMSD) of the original crystal structure and docking result was
0.407 Å. When MOE2015 was used, the RMSD of the original crystal structure and docking result was
0.644 Å. Low RMSD indicated that the results were reasonable. The binding site of compound 22 in
the FAD region justified by enzyme kinetics studies was selected as a reference. Compound 22 was
docked in the FAD region and the substrate region using Glide and MOE2015, respectively. Among the
remaining compounds, compound 04, with the highest activity, was selected as the representative for
binding site prediction. Similarly, compound 04 was docked in the FAD region and substrate region
using two different kinds of software. Each docking result generated 20 poses, and the scores of the
top five were recorded. The docking scores are shown in Table 5. For compound 22, the top five scores
of compound 22 in the FAD region and substrate region were
respectively, by Glide. The top five scores of compound 22 in the FAD region and substrate region by
MOE2015 were 9.143 to 8.704 and 6.224 to 5.844, respectively. Both tools showed that compound
−
11.07 to
−
9.037 and
−
6.514 to 6.233,
−
−
−
−
−
22 displayed lower scores in the FAD region. The results illustrated that the FAD region was more
likely to be the binding site than the substrate region, which was also consistent with the results of
enzyme kinetics studies. For Glide, the top five scoring ranges of compound 04 in the FAD region and
substrate region were
scoring ranges of compound 04 in the FAD region and substrate region were
5.481 to 5.259, respectively. The two kinds of software showed that compound 04 scored lower in
−
9.132 to
−
8.724 and
−
6.364 to
−
5.315, respectively. For MOE2015, the top five
−
7.738 to 7.547 and
−
−
−
the FAD region. This indicated that for other compounds, the FAD region was more likely to be the
binding site. This prediction was validated by calculating the binding free energy.

Molecules 2019, 24, 4479
18 of 28
Table 5. Docking scores of compounds 04 and 22 in the FAD and substrate regions calculated by Glide
and MOE2015.
Glide
Top 5
FAD
Substrate
04
22
04
22
1
2
3
4
5
−9.132
−9.108
−8.967
−8.775
−8.724
−11.070
−9.503
−9.125
−9.102
−9.037
−6.364
−5.691
−5.459
−5.389
−5.315
−6.514
−6.406
−6.249
−6.234
−6.233
MOE2015
Top 5
FAD
Substrate
04
22
04
22
1
2
3
4
5
−7.738
−7.680
−7.611
−7.571
−7.547
−9.143
−8.922
−8.905
−8.894
−8.704
−5.481
−5.475
−5.434
−5.341
−5.259
−6.224
−6.040
−5.898
−5.856
−5.844
3.5. Exploration of Binding Mode
Based on the above analysis, all compounds were docked in the FAD region and their possible
binding modes were explored. In order to increase the reliability of the results, two kinds of software
were used. In all the docking results, there were mainly two opposite orientations, named type A and
type B, respectively, as shown in Figure 8. This series of small molecules all contained ring A and
ring B, as seen in Table 1. In order to be easy to express, compound 04 with the highest activity was
displayed and FAD was used as a reference. Figure 8A shows the orientation of type A, and ring A of
04 overlapped with the triple-ring structure of FAD. Figure 8B shows the orientation of type B, and
ring B of 04 overlapped with the triple-ring structure of FAD. Therefore, for all compounds, if ring
A and the FAD triple-ring structure overlap, they were classified as type A, and if ring B and FAD
triple-ring structure overlap, they were classified as type B.
A
B
Figure 8. Two different binding orientations, with FAD shown as a yellow stick as a reference. (
A)
Compound Type A:04 represented by green sticks. ( ) Compound Type B:04 represented by cyan sticks.
B
In order to determine which orientation to use for the next study, the docking results of the top
10 for all compounds were recorded. The results of Glide, as shown in Table 6, recorded the times of
occurrence of type A and type B, respectively, in the top 10, and recorded the highest scores belonging
to type A or type B. The total number of type A and type B of some compounds was less than 10. This
was because there were a few other orientations in the top 10, such as compounds 12 and 20. However,
these were rare orientations, so they were not recorded. In all 41 compounds, 31 compounds had more

Molecules 2019, 24, 4479
19 of 28
type A orientations in their top 10 conformations, and some compounds were all type A orientation in
their top 10 conformations, such as compounds 13 16, and 17. There were two compounds in the top
,
10 with the same frequency of type A and type B. Only eight compounds in the top 10 showed more
type B, but type A always appeared in the top 10. The top conformation of 30 compounds were in
type A orientation; moreover, type B was not found in the top 10 conformations of 19 compounds.
The docking results of compounds 04, 05, and 10 with high activity in type B are shown in Figure S5.
These compounds did not even form H-bonds with surrounding amino acids, which was difficult to
explain because they have high activity, indicating the irrationality of type B. It can be concluded that
type A is the favored orientation of the compounds. Therefore, when choosing the docking results
of all compounds for further research, one should ensure that the conformation with the best score
belongs to type A orientation. The result of docking using MOE2015 is shown in Table S3. Therein, the
top conformations of 30 compounds belonged to type A, the top conformations of five compounds
belonged to neither type A nor type B, and only the top conformations of six compounds belonged to
type B, which indicated that type A was most likely to be the true orientation of the compounds.
Table 6. Glide docking results. The second and third columns mean the number of type A and B in the
top 10 conformations of all compounds. The last column includes the best scores and the type.
No.
Type A
Type B
Best Score
1
2
3
4
5
6
7
8
3
2
2
7
4
6
6
6
6
6
9
4
10
9
7
8
8
3
6
4
4
4
4
4
1
5
0
1
2
0
0
6
8
0
0
3
0
0
0
0
0
0
0
0
1
0
1
0
0
5
0
0
9
5
0
B −9.220
A −9.400
B −9.658
A −9.454
A −9.490
A −9.093
B −9.237
B −9.137
B −8.444
B −9.333
A −9.093
B −9.173
A −9.995
A −10.978
A −10.873
A −10.325
A −9.473
A −9.370
B −9.784
A −11.204
A −10.870
A −11.07
A −9.919
A −9.153
A −10.109
A −9.887
A −9.427
A −9.223
A −9.147
A −9.538
A −8.953
A −9.461
A −9.628
A −9.741
A −8.568
B −8.977
A −9.563
A −9.709
B −9.164
B −8.675
A −9.281
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
8
10
10
4
2
8
10
7
9
10
10
10
10
10
10
10
9
10
9
10
10
5
10
10
1
5
10

Molecules 2019, 24, 4479
20 of 28
The best docking structures of all compounds selected according to the above criteria are shown
in Figure S6. They all entered FAD binding site well. The A ring was near the sheet region, and
the B ring was near the helical region, and the linker in the middle was located in the coil region.
β
α
However, by observing their overlap, it was found that although the orientations of these compounds
were identical, there were still some differences in their binding modes.
According to the superposition of all small molecules, the binding modes of these compounds
can be divided into three categories, expressed as I, II, and III, respectively. The categories of each
compound are indicated in Table 1. Figure 9B–D show the binding modes of categories I, II, and III,
respectively. For convenience of observation, the compounds with the highest activity (compounds
04
,
22, and 29) of the three binding modes are displayed in Figure 9A. The individual docking results
22, and 29 are shown in Figure S7. Although their orientations were identical, the
of compounds 04
,
locations of ring A and ring B were different, which also led to the formation of different interactions
between them and the protein. Ring A of compound 04 was surrounded by hydrophobic amino acids
Phe538, Leu659, Trp751, Tyr761, and the B ring was surrounded by hydrophobic amino acids Val 288,
Ala809, Val811. Oxygen and hydrogen on the amidoxime group formed H-bonds as H-bond acceptor
and donor with Val288 and Gly314, respectively. In addition, oxygen on the hydroxyl of ring A formed
an H-bond as a H-bond acceptor with Lys661. Compared with compound 04, phenol attached to
ring A of compound 22 and fluorine was added to para-position of the hydroxyl group. This new
structure occupied the cavity formed by Phe538, Leu659, Trp751, and Tyr761, which resulted in ring A
being squeezed into the vicinity of Ala331, Tyr761, and Ala809 in space. Thus, ring B also extended
near Val288, Ser289, Gly315, and Thr624 and formed H-bonds with Thr624. The volume of ring A in
compound 29 was larger than that of ring A of compound 04. Moreover, the substitution position on
ring B changed from the meta- to para-position, which indicated that more space was needed in the
hydrophobic pocket. Finally, the positions of ring A and ring B changed a lot, and the carbonyl on R6
formed an H-bond as an H-bond acceptor with Ser289. Another H-bond was formed between Thr624
and the hydrogen of the hydroxyl group, which acted as an H-bond donor.
Based on the above analysis, 15 compounds with substituent volume of ring A similar to that of
compound 04 and small substituent volume of ring B (e.g., amidoxime, hydroxyl) were classified as
Category I, as shown in Figure 9B. These compounds were easily formed H-bonds with Val288, Ser289,
Gly314, and Lys661. These amino acids may have an important effect on the activity. For example,
both 03 and 04 formed H-bonds with Val288 and Gly314. The hydroxyl groups at R2 of 04 formed
H-bonds with Lys661. There was no H-bond acceptor group at R2 of 03, which may be the reason why
the activity of 03 (pIC50 = 5.587) was lower than 04 (pIC50 = 6.917). Although the hydroxyl group at R3
of 12 formed an H-bond with Leu659, because of its long interaction distance (2.587 Å) and there were
no other H-bonds, the activity was not high (pIC50 = 4.991). The meta-substitution of amidoxime at
ring B usually formed two H-bonds with Val288 and Gly314, and the para-substitution of amidoxime
at B ring formed one H-bond with Ser289. This explained why the meta-substitution of amidoxime at
B ring was more active than the para-substitution of amidoxime at B ring; for example, compound 01
(meta-substitution of amidoxime at B ring) formed H-bonds with Val288 and Gly314, while compound
07 (para-substitution of amidoxime at B ring) did not form H-bonds with Val288 and Gly314, but
only one H-bond with Ser289. Therefore, the activity of 01 (pIC50 = 6.478) was higher than that of 07
(pIC50 = 6.131). For the same reason, the activity of compound
of compound (pIC50 = 6.308). Compounds 35 (pIC50 = 4.790) and 37 (pIC50 = 4.985) did not form
H-bonds with the surrounding amino acids, so their activity was very low.
2 (pIC50 = 6.611) was higher than that
8

Molecules 2019, 24, 4479
21 of 28
A
B
C
D
Figure 9.
29 is orange. (
Category II. (D) Superposition of 11 compounds in Category III.
(
A) Three binding modes for the three most active compounds; 04 is green, 22 is purple, and
B
) Superposition of 15 compounds in Category I. ( ) Superposition of 15 compounds in
C

Molecules 2019, 24, 4479
22 of 28
Fifteen compounds with new ring structures attached to the A ring were classified as category II
because they had similar interactions with proteins, as shown in Figure 9C. These compounds easily
formed H-bonds with Ser289, Gly314, and Thr624. It was found that the activities of the compounds
with para-substituted amino at B ring were not high. For example, compounds 17 (pIC50 = 5.447) and
23 (pIC50 = 5.529) had para-substituted amino groups on the B ring and formed only one H-bond with
Ser289. Therefore, their activities were low. More hydrogen bonds were formed when the compounds
were para-substituted at the B ring by amidoxime. For example, compounds 16 (pIC50 = 6.036) and
21 (pIC50 = 6.117) were para-substituted by aminoxime at ring B. Both of them formed H-bonds
with Ser289 and Thr624, which may be the reason why their activities increased. Compounds 39
(pIC50 = 4.696) and 40 (pIC50 = 4.722) had low activities, because their newly introduced pyridine rings
had extra structure, which was too large to enter the cavity formed by Phe538, Leu659, Trp751, and
Tyr761. This led to the rotation of the rotational bonds between the pyridine rings and the A rings, and
placed the pyridine near Ala331, Val333, and Lys661. The region was very close to the binding site,
indicating that compounds 39 and 40 were not closely bound to proteins, which may be the reason for
their poor activity. Therefore, when a new ring structure was introduced into the A ring, the addition
of more groups in the new ring structure was not conducive to the improvement of activity.
Eleven compounds with larger substituted groups on the A ring than compound 04 and larger
para groups at the B ring were classified as category III. As shown in Figure 9D, these compounds
easily formed H-bonds with Ser289 and Thr624. Compared with category I, the substituents on the
B ring of these compounds were larger, so they extended and formed H-bonds with Thr624. As
H-bond acceptors and donors, carbonyl and hydroxyl groups in R6 were very important. For example,
compound 32 (pIC50 = 6.154) not only formed H-bonds with Ser289 and Thr624, but also formed
an H-bond with Lys611, so compound 32 had high activity. This was because the position of R2
was replaced by a methoxy group. Oxygen, as an H-bond acceptor, formed an H-bond with Lys611.
Compound 28 (pIC50 = 5.331) formed H-bonds with Lys611, but not with Ser289 and Thr624, so its
activity was low.
By observing the docking results, the R5 of compounds 1, 2, 4, 5, and 6 with high activity were
aminoxime, and the hydroxyl, as an H-bond donor, formed H-bonds with Gly314. Similarly, R5 of
compounds 20 and 22 with higher activity were replaced by aminoxime, in which the hydroxyl and
amino groups formed H-bonds with Thr624 as H-bond donors. However, compounds 35 and 37
with lower activity did not have H-bond donor groups in R5, so they did not form H-bonds with the
surrounding amino acids. This showed that for the possible H-bonds predicted in the H-bond donor
field contour map, H-bonds were indeed formed in the molecular docking results, and the activities
of these compounds were relatively high, while those compounds that did not form H-bonds at the
predicted positions had relatively low activity. This evidence proves that H-bond donor groups have a
great influence on the activity of this series of compounds from the perspective of molecular docking,
and explains why H-bond donors had the highest contribution rate in the CoMSIA model.
3.6. MD Simulations and Binding Free Energy Calculation
In order to further study the detailed interaction between ligands and receptor, and to verify the
reliability of the results of molecular docking, compounds 04, 17, 21, 35 with large activity range were
selected for molecular dynamics simulation of 50 ns. The results of their docking were taken as the
initial conformations. From the 50 ns MD process, the RMSD values for Cα of each complex are shown
in Figure 10. After a short period of time, the four systems reached equilibrium. Compounds 04, 17,
and 21 fluctuated in the range of 1.3–2.3 Å until 50 ns, while compound 35 fluctuated in the range
of RMSD from 1.4 to 2.7 Å. The RMSD of compound 35 fluctuated around 36 ns. The superposition
of the initial conformation of compound 35 and the conformation at 36 ns is shown in Figure S8.
The surrounding residues only formed an H-bond (Glu801=O···HO, bond length 1.705Å) with the
amidoxime connected to the B ring in the ligand, which might not be able to fix the position of the
ligand, so the position of ring A changed greatly. At the same time, the polarity of compound 35 was

Molecules 2019, 24, 4479
23 of 28
strong, and there were polar amino acids around it, such as Thr, Ser, Asn, and Glu, which could also
change of the position of the ligand. The activity of compound 35 was lower than that of the other
three compounds, which could be the reason why the RMSD value of compound 35 fluctuated greatly.
The temperature versus time plot is shown in Figure S9.
Figure 10. Root mean square deviation (RMSD) values of the complexes during 50 ns molecular
dynamics (MD) simulations.
As shown in Figure 11, for a clearer comparison of ligand–receptor interactions before and after
MD, the docking conformations of compounds 04
, 17, 21, and 35, and the corresponding average
structure during the MD equilibrium stage were superimposed. The docking result of compound 04
,
seen in Figure 11A, showed that the small molecule formed H-bonds with Val288 (Val288–NH···O,
bond length 1.742 Å) and Gly314 (Gly314=O···HO, bond length 1.970 Å). Although these two H-bonds
disappeared during the MD process, new H-bonds were formed with Gly315 (Gly315=O···HO, bond
length 1.706 Å) and Glu801 (Glu801=O···HN, bond length 2.004 Å). In addition, Br on the A ring
formed a halogen bond with Ser760 (bond length 2.392 Å). The docking result of compound 17, seen in
Figure 11B, showed that no H-bond was formed between the small molecule and the surrounding
amino acids, while after MD, the result showed that compound 17 formed H-bonds with Val288
(Val288–NH···N, bond length 2.235 Å) and Ser289(Ser289–O···HN, bond length 1.884 Å). The docking
result for compound 21, as seen in Figure 11C, demonstrated that small molecule formed H-bonds with
Ser289 (Ser289–O···HN, bond length 2.047Å) and Thr624 (Thr624=O···HO, bond length 2.390Å). During
MD simulations, although compound 21 lost the H-bond with Thr624, it formed a shorter H-bond
with Gly315 (Gly315 = O···HN, bond length 1.956Å). In addition, the hydroxyl of amidoxime, as an
H-bond acceptor and donor, formed two H-bonds with Ser289. Compound 35 is shown in Figure 11D.
The small molecule did not form any H-bonds with the surrounding amino acids, and only formed
an H-bond with Glu801 (Glu801 = O···HO, bond length 2.089 Å) during the MD process. By MD
analysis, compounds 17 and 35 formed fewer H-bonds and longer bond lengths, which indicated that
the binding of these two small molecules with the protein was not close. However, compounds 04
and 21 formed more H-bonds and shorter bond lengths, and a halogen bond was formed between
compound 04 and Ser760. This result demonstrated that the binding of compounds 04 and 21 with the
protein was relatively stable.
From the above analysis, the binding affinity of compounds 04, 17, 21, and 35 with LSD1 can
be roughly judged. However, the binding affinity of small molecules with LSD1 was quantified by
calculating the binding affinity. Therefore, the MM/GBSA method was used to calculate the binding
free energy, as shown in Table 7.

Molecules 2019, 24, 4479
24 of 28
A
B
C
D
Figure 11. Superposition of the docking structures and MD average structures of compound 04
(A), 17
(
B
), 21 ), and 35 ). Carbon atoms of docking result and MD average structures are shown in green
(
C
(D
and cyan, respectively. H-bonds from docking and MD are shown as red dashed lines and purple
dashed lines, respectively. Halogen bonds are represented by orange dotted lines.
Table 7. Binding free energies of ligand–protein complexes.
∆Eele
∆Evdw
∆GGB
∆GSA
∆Gsol
∆Gbind
No.
pIC50
kcal mol−1
kcal mol−1
kcal mol−1
kcal mol−1
kcal mol−1
kcal mol−1
LSD1-04
LSD1-17
LSD1-21
LSD1-35
−28.5803
−14.5346
−16.5911
−15.5150
−51.8392
−45.4670
−50.1944
−38.2128
45.2379
34.5108
37.4930
30.7264
−6.0145
−5.5613
−6.2235
−5.0611
39.2235
28.9496
31.2696
25.6653
−41.1960
−31.0520
−35.5160
−28.0625
6.917
5.447
6.117
4.790
The binding free energies of compounds 04
,
17
,
21, and 35 with LSD1 were
−
41.196 kcal mol−1
,
−
31.052 kcal mol−1 35.516 kcal mol−1, and 28.063 kcal mol−1, respectively. The more negative the
,
−
−
binding free energies of compounds, the better the experimental activity of the compounds. The van
der Waals energy Evdw contributed most to the free energy, indicating that hydrophobic interaction
played an important role in the binding process. In addition, electrostatic interaction Eele also
contributed greatly to the binding free energy. The polar solvation energy GGB was positive, which
∆
∆
∆
indicated that it is disadvantageous to binding free energy, and the value of GGB was larger. This
may be due to the large binding pocket and the exposure of ligands to solvents. However, nonpolar
solvation energy ∆GSA was negative, which meant that it was good for binding free energy. Previous
studies have shown that there is a significant correlation between binding free energy and experimental
activity [45]. In this study, the binding free energies of the compounds were arranged in the same order
as pIC50: 04 (pIC50 = 6.917) > 21 (pIC50 = 6.117) > 17 (pIC50 = 5.447) > 35 (pIC50 = 4.790). The binding
free energy was calculated on the basis of the docking results. The pIC50 rank was consistent with the

Molecules 2019, 24, 4479
25 of 28
rank of binding free energy, which showed that the pose of ligands after docking was very close to the
real binding mode, and verified that the previous selection of binding site was correct.
4. Conclusions
In this study, 41 stilbene derivatives were collected and synthesized, and a series of 3D-QSAR
modeling, molecular docking, and molecular dynamics simulations were carried out. Firstly, CoMFA
(
q2 = 0.623,rp2red = 0.857) and CoMSIA (q2 = 0.728,rp2red = 0.899) models were constructed using the
lowest energy conformation. The models had good internal verification ability and external prediction
ability. In order to further evaluate the external prediction ability of the models, Tropsha and Roy
criteria were used to evaluate the models. Statistically, our model was reliable and could be used
to predict the unknown activity of stilbene derivatives to reduce experimental losses. At the same
time, the contour maps were obtained, which reasonably explained the relationship between the
structure and activity of the compounds, and summarized the key information. Secondly, the binding
site of compounds was predicted by double software docking. On this basis, the binding modes of
the compounds were explored and classified into three categories. Furthermore, the reasons for the
differences in activity were explained. The hydrophobic amino acids Phe538, Leu659, Trp751, Tyr761,
Ala809, and Val811 played important roles in the stability of small molecules in the binding pocket,
and amino acids Val288, Ser289, Gly314, Thr624, and Lys661 played key roles in the formation of
H-bonds. Finally, compounds 04, 17, 21, and 35, with a large activity range, were selected for MD. The
interactions between those compounds and LSD1 were observed before and after MD. The reason for
the poor activities of compounds 17 and 25 was explained. A halogen bond between compound 04
and Ser760 was also observed. The rank of binding free energies calculated by MM/GBSA coincided
well with experimental activity, which indicated that the predictions of the binding site and binding
mode were reasonable. We hope that this study will provide guidance and help for the design of new
reversible LSD1 inhibitors.
Supplementary Materials: The following are available online, S1: Compound Characterization Data, Figure S1:
3D-QSAR Histogram of activity data distribution, S2: MOE2015 docking process, Table S1: Randomizations
of biological activity for the Y-random test, S3: Structural validation, Figure S2: Ramachandran plot, Table S2:
Residues falling in the core region of the Ramachandran’s plot, Figure S3: Verify 3D plots for model, Figure
S4: ERRAT result for model, Figure S5: Docking results of the compound 04(A), 05(B) and 10(C) under type B,
Table S3: MOE2015 docking results, Figure S6: All compounds were docked into the FAD-binding site, Figure S7:
Docking results of the compound 04(A), 22(B) and 29(C) with LSD1, Figure S8: The superposition of the docking
structure and structure of compound 35 in 36ns MD, Figure S9: Temperature fluctuation plot in MD.
Author Contributions: Conceptualization, Y.X.; Data curation, Z.H.; Formal analysis, M.Y., Y.G., L.J., M.W., Y.Z.,
X.L., S.Z., C.W., Z.Z. and J.Z.; Supervision, Q.G. and Y.D.; Writing—original draft, Y.X. and Z.H.; Writing—review
& editing, Q.G. and Y.D.
Funding: The authors are grateful for the financial support from The National Natural Science Foundation of
China (Grant No.21603180, No. U1704184), China Scholarship Council (Grant No.201708410492), Science and
Technology Tackling Key Project of Henan Province (Grant No. 182102310124, 182102210122), the University Key
Research Projects of Henan Province (No. 19A350010), Research Project of Xinxiang Medical University (Grant
No.505060, 505144, 505212) and Open topic at School of Biomedical Engineering, Xinxiang Medical University
(Grant No.2018-BME-KFKT-01, 2018-BME-KFKT-10, 2018-BME-KFKT-11).
Acknowledgments: The authors also thank Zheng Jie from Guangdong University of Technology for offering
sybyl software support and Meilan Huang from Queens University Belfast helpful discussion.
Conflicts of Interest: The authors declare no conflict of interest.
References
1.
Cole, P.A. Chemical probes for histone-modifying enzymes. Nat. Chem. Biol. 2008, 4, 590. [CrossRef]
[PubMed]
2.
Shi, Y.; Wu, Y.R.; Su, M.B.; Shen, D.H.; Gunosewoyo, H.; Yang, F.; Li, J.; Tang, J.; Zhou, Y.B.; Yu, L.F. Novel
spirocyclic tranylcypromine derivatives as lysine-specific demethylase 1 (LSD1) inhibitors. Rsc Adv. 2018, 8,
1666–1676. [CrossRef]

Molecules 2019, 24, 4479
26 of 28
3.
4.
Shi, Y.; Lan, F.; Matson, C.; Mulligan, P.; Whetstine, J.R.; Cole, P.A.; Casero, R.A.; Shi, Y. Histone demethylation
mediated by the nuclear amine oxidase homolog LSD1. Cell 2004, 119, 941–953. [CrossRef] [PubMed]
Wang, J.; Hevi, S.; Kurash, J.K.; Lei, H.; Gay, F.; Bajko, J.; Su, H.; Sun, W.; Chang, H.; Xu, G. The lysine
demethylase LSD1 (KDM1) is required for maintenance of global DNA methylation. Nat. Genet. 2009, 41,
125–129. [CrossRef] [PubMed]
5.
6.
Lee, M.G.; Wynder, C.; Cooch, N.; Shiekhattar, R. An essential role for CoREST in nucleosomal histone 3
lysine 4 demethylation. Nature 2005, 437, 432–435. [CrossRef]
Garciabassets, I.; Kwon, Y.S.; Telese, F.; Prefontaine, G.G.; Hutt, K.R.; Cheng, C.S.; Ju, B.G.; Ohgi, K.A.;
Wang, J.; Escoubetlozach, L. Histone methylation-dependent mechanisms impose ligand dependency for
gene activation by nuclear receptors. Cell 2007, 128, 505–518. [CrossRef]
7.
8.
9.
Huang, J.; Sengupta, R.; Espejo, A.B.; Lee, M.G.; Dorsey, J.A.; Richter, M.; Opravil, S.; Shiekhattar, R.;
Bedford, M.T.; Jenuwein, T. p53 is regulated by the lysine demethylase LSD1. Nature 2007, 449, 105–108.
[CrossRef]
Jing, W.; Sarah, H.; Kurash, J.K.; Hong, L.; Frédérique, G.; Jeffrey, B.; Hui, S.; Weitao, S.; Hua, C.; Guoliang, X.
The lysine demethylase LSD1 (KDM1) is required for maintenance of global DNA methylation. Nat. Genet.
2009, 41, 125–129.
Qidong, H.; Young-Soo, K.; Esperanza, N.; Maria Dafne, C.; Hutt, K.R.; Ohgi, K.A.; Ivan, G.B.; Rose, D.W.;
Glass, C.K.; Rosenfeld, M.G. Enhancing nuclear receptor-induced transcription requires nuclear motor and
LSD1-dependent gene networking in interchromatin granules. Cell 2008, 105, 19199–19204.
10. Shi, Y.J.; Matson, C.; Lan, F.; Iwase, S.; Baba, T.; Shi, Y. Regulation of LSD1 histone demethylase activity by its
associated factors. Mol. Cell 2005, 19, 857. [CrossRef]
11. Yokoyama, A.; Takezawa, S.; Schüle, R.; Kitagawa, H.; Kato, S. Transrepressive function of TLX requires the
histone demethylase LSD1. Mol. Cell. Biol. 2008, 28, 3995–4003. [CrossRef] [PubMed]
12. Lv, T.; Yuan, D.; Miao, X.; Lv, Y.; Zhan, P.; Shen, X.; Song, Y. Over-expression of LSD1 promotes proliferation,
migration and invasion in non-small cell lung cancer. Plos One 2012, 7, e35065. [CrossRef] [PubMed]
13. Wissmann, M.; Yin, N.; Müller, J.M.; Greschik, H.; Fodor, B.D.; Jenuwein, T.; Vogler, C.; Schneider, R.;
Günther, T.; Buettner, R. Cooperative demethylation by JMJD2C and LSD1 promotes androgen
receptor-dependent gene expression. Nat. Cell Biol. 2007, 9, 347–353. [CrossRef] [PubMed]
14. Hayami, S.; Kelly, J.D.; Cho, H.S.; Yoshimatsu, M.; Unoki, M.; Tsunoda, T.; Field, H.I.; Neal, D.E.; Yamaue, H.;
Ponder, B.A. Overexpression of LSD1 contributes to human carcinogenesis through chromatin regulation in
various cancers. Int. J. Cancer J. Int. Du Cancer 2015, 128, 574–586. [CrossRef] [PubMed]
15. Wang, Y.; Zhang, H.; Chen, Y.; Sun, Y.; Yang, F.; Yu, W.; Liang, J.; Sun, L.; Yang, X.; Shi, L. LSD1 is a subunit of
the NuRD complex and targets the metastasis programs in breast cancer. Cell 2009, 138, 660–672. [CrossRef]
[PubMed]
16. Harris, W.J.; Huang, X.; Lynch, J.T.; Spencer, G.J.; Hitchin, J.R.; Li, Y.; Ciceri, F.; Blaser, J.G.; Greystoke, B.F.;
Jordan, A.M. The histone demethylase KDM1A sustains the oncogenic potential of MLL-AF9 leukemia stem
cells. Cancer Cell 2012, 21, 473–487. [CrossRef] [PubMed]
17. Schmidt, D.M.Z.; Mccafferty, D.G. trans-2-Phenylcyclopropylamine is a mechanism-based inactivator of the
histone demethylase LSD1. Biochemistry 2007, 46, 4408–4416. [CrossRef]
18. Mohammad, H.; Smitheman, K.; Aller, G.V.; Cusan, M.; Kamat, S.; Liu, Y.; Johnson, N.; Hann, C.; Armstrong, S.;
Kruger, R. 212 Novel anti-tumor activity of targeted LSD1 inhibition by GSK2879552. Eur. J. Cancer 2014, 50,
72. [CrossRef]
19. Maes, T.; Mascaró, C.; Tirapu, I.; Estiarte, A.; Ciceri, F.; Lunardi, S.; Guibourt, N.; Perdones, A.; Lufino, M.;
Somervaille, T. ORY-1001, a Potent and selective covalent KDM1A inhibitor, for the treatment of acute
leukemia. Cancer Cell 2018, 33, S1535610818300230. [CrossRef]
20. Wu, F.; Zhou, C.; Yao, Y.; Wei, L.; Feng, Z.; Deng, L.; Song, Y. 3-(Piperidin-4-ylmethoxy)pyridine containing
compounds are potent inhibitors of lysine specific demethylase 1. J. Med. Chem. 2016, 59, 253–263. [CrossRef]
21. Vianello, P.; Sartori, L.; Amigoni, F.; Cappa, A.; Fagá, G.; Fattori, R.; Legnaghi, E.; Ciossani, G.; Mattevi, A.;
Meroni, G. Thieno [3,2-b]pyrrole-5-carboxamides as new reversible inhibitors of histone lysine demethylase
KDM1A/LSD1. Part 2: Structure-based drug design and structure–activity relationship. J. Med. Chem. 2017
60, 1693. [CrossRef] [PubMed]
,

Molecules 2019, 24, 4479
27 of 28
22. Duan, Y.C.; Guan, Y.Y.; Zhai, X.Y.; Ding, L.N.; Qin, W.P.; Shen, D.D.; Liu, X.Q.; Sun, X.D.; Zheng, Y.C.;
Liu, H.M. Discovery of resveratrol derivatives as novel LSD1 inhibitors: Design, synthesis and their biological
evaluation. Eur. J. Med. Chem. 2017, 126, 246–258. [CrossRef] [PubMed]
23. Duan, Y.; Qin, W.; Suo, F.; Zhai, X.; Guan, Y.; Wang, X.; Zheng, Y.; Liu, H. Design, synthesis and in vitro
evaluation of stilbene derivatives as novel LSD1 inhibitors for AML therapy. Bioorganic Med.Chem. 2018, 26,
6000–60147. [CrossRef] [PubMed]
24. Ouyang, S.; Lu, J.; Kong, X.; Liang, Z.; Luo, C.; Jiang, H. Computational drug discovery. Acta Pharmacol. Sin.
2012, 33, 1131–1140. [CrossRef] [PubMed]
25. Jitender Verma, V.M.K.; Coutinho, E.C. 3D-QSAR in drug design—A review. Curr. Top. Med. Chem. 2010, 10.
26. Cerqueira, N.; Bras, N.; Ramos, M. MADAMM: A multistaged docking with an automated molecular
modeling protocol. Proteins-Struct. Funct. Bioinform. 2010, 74, 192–206. [CrossRef]
27. Mortier, J.; Rakers, C.; Bermudez, M.; Murgueitio, M.S.; Riniker, S.; Wolber, G. The impact of molecular
dynamics on drug design: Applications for the characterization of ligand–macromolecule complexes. Drug
Discov. Today 2015, 20, 686–702. [CrossRef]
28. Ping, P.Q.; Shuai, W.; Kai, R.F.; Yu, J.R. Molecular modeling studies of 1,2,4-triazine derivatives as novel
h-DAAO inhibitors by 3D-QSAR, docking and dynamics simulations. Rsc Adv. 2018, 8, 14311–14327.
29. Wang, Z.Z.; Ma, C.Y.; Yang, J.; Gao, Q.B.; Liu, H.M. Investigating the binding mechanism of
(4-Cyanophenyl)glycine derivatives as reversible LSD1 by 3D-QSAR, molecular docking and molecular
dynamics simulations. J. Mol. Struct. 2018, 1175, 698–707. [CrossRef]
30. Balasubramanian, P.K.; Balupuri, A.; Gadhe, C.G.; Cho, S.J. 3D QSAR modeling study on 7-aminofuro [2,3-c]
pyridine derivatives as TAK1 inhibitors using CoMFA and COMSIA. Med. Chem. Res. 2015, 24, 2347–2365.
[CrossRef]
31. Clark, M.; Iii, R.D.C.; Opdenbosch, N.V. Validation of the general purpose tripos 5.2 force field. J. Comput.
Chem. 2010, 10, 982–1012. [CrossRef]
32. Viviana, C.; Davide, B.; Roberto, T. Comments on the definition of the Q2 parameter for QSAR validation. J.
Chem. Inf. Modeling 2009, 49, 1669–1678.
33. Kunal, R.; Pratim, C.; Indrani, M.; Probir Kumar, O.; Supratik, K.; Rudra Narayan, D. Some case studies on
application of “r(m)2” metrics for judging quality of quantitative structure–activity relationship predictions:
Emphasis on scaling of response data. J. Comput. Chem. 2013, 34, 1071–1082.
34. Rucker, C.; Rucker, G.; Meringer, M. y-Randomization and its variants in QSPR/QSAR. J. Chem. Inf. Modeling
2007, 47, 2345–2357. [CrossRef] [PubMed]
35. Vilar, S.; Cozza, G.S. Medicinal chemistry and the molecular operating environment (MOE): Application of
QSAR and molecular docking to drug discovery. Curr. Top. Med. Chem. 2008, 8, 1555–1572. [CrossRef]
36. Laskowski, R.A.; Macarthur, M.W.; Moss, D.S.; Thornton, J.M. PROCHECK: A program to check the
stereochemical quality of protein structures. J. Appl. Crystallogr. 1993, 26, 283–291. [CrossRef]
37. Eisenberg, D.; Lüthy, R.; Bowie, J.U. [20] VERIFY3D: Assessment of protein models with three-dimensional
profiles. Nature 1992, 356, 83–85.
38. Hasan, M.A.; Khan, M.A.; Datta, A.; Mazumder, M.H.; Hossain, M.U. A comprehensive immunoinformatics
and target site study revealed the corner-stone toward Chikungunya virus treatment. Mol. Immunol. 2015
65, 189–204. [CrossRef]
,
39. Case, D.A.B.V.; Berryman, J.; Betz, R.; Cai, Q.; Cerutti, D.; Cheatham Iii, T.; Darden, T.; Duke, R.; Gohlke, H.
Amber 14. 2014.
40. Hou, T.; Wang, J.; Li, Y.; Wang, W. Assessing the performance of the MM/PBSA and MM/GBSA methods. 1.
The accuracy of binding free energy calculations based on molecular dynamics simulations. J. Chem. Inf.
Modeling 2011, 51, 69–82. [CrossRef]
41. Julio, C.; Michael, F.; Mario, S.; González-Nilo, F.D. 2D Autocorrelation, CoMFA, and CoMSIA modeling
of protein tyrosine kinases’ inhibition by substituted pyrido[2,3-d]pyrimidine derivatives. Bioorganic Med.
Chem. 2008, 16, 810–821.
42. Tropsha, A. Best practices for qsar model development, validation, and exploitation. Mol. Inform. 2010, 29,
476–488. [CrossRef] [PubMed]
43. Dariusz, P.; Micha, A.N.; Rafa, A.; Krzysztof, G. Can we trust docking results? Evaluation of seven commonly
used programs on PDBbind database. J. Comput. Chem. 2011, 32, 742–755.

Molecules 2019, 24, 4479
28 of 28
44. Fukunishi, Y.; Nakamura, H. Prediction of ligand-binding sites of proteins by molecular docking calculation
for a random ligand library. Protein Sci. 2011, 20, 95–106. [CrossRef] [PubMed]
45. Greenidge, P.A.; Christian, K.; Jean-Christophe, M.; Wolf, R.M. MM/GBSA binding energy prediction on the
PDBbind data set: Successes, failures, and directions for further improvement. J. Chem. Inf. Modeling 2013
,
53, 201–209. [CrossRef]
Sample Availability: Samples of all compounds involved in this paper are available from the authors.
©
2019 by the authors. Licensee MDPI, Basel, Switzerland. This article is an open access
article distributed under the terms and conditions of the Creative Commons Attribution
(CC BY) license (http://creativecommons.org/licenses/by/4.0/).
