Y.-L. Li et al. / Journal of Molecular Catalysis B: Enzymatic 64 (2010) 48–52
49
lysts, such as sec-alcohol [19], mandelic acid [20] and 1,2-octanediol
[21]. In the former case, the result was not satisfactory for the der-
acemization of 1a and the product (R)-1a was obtained in only 80%
yield and 85% ee [19].
In this paper, a tandem biocatalysts system was successfully
developed for the stereoinversion of (R)-1-phenylethanol and der-
acemization of various aryl secondary alcohols by using highly
selective biocatalyst for each step and mixed them in suitable forms
for efficient tandem transformation. A variety of enantiopure (S)-
alcohols were successfully prepared in a one-pot procedure in good
yield and excellent ee.
Tris–HCl buffer (10 mL, 50 mM, pH 8.5). The reaction mixtures
were incubated in a screw-capped 100-mL flask, shaken at 30 ◦C
and 180 rpm for time necessary to obtain an appropriate conver-
sion. The biotransformation was stopped by addition of the same
volume of ethyl acetate and extracted for two times. After cen-
trifugation at 12,000 rpm for 10 min, the organic phase was dried
over anhydrous Na2SO4. Chemical yield and ee of the products were
determined by GC or HPLC analysis. The product was identified
by 1H NMR analysis. The absolute configuration was determined
by the specific rotation and comparison with the literature or
by chiral GC or HPLC analysis and comparison with known race-
mates.
2. Experimental
2.4. Assignment of the absolute configuration of the alcohols
1a–1g
Gas chromatographic (GC) analyses were performed using a chi-
ral GC-column (Betadex-120, 30 m × 0.25 mm × 0.25 m, Supelco,
USA). HPLC analyses were performed using a chiral column (Chi-
ralcel OD, Ø0.46 cm × 25 cm, Daicel Chemical Industries, Japan).
Compound (S)-1a: [˛]D25 = −58.2 (c 1.03, CHCl3) {lit. [22] [˛]25
=
=
D
−55.1 (c 1.63, CHCl3), S}.
Compound (S)-1b: [˛]D25 = −31.9 (c 1.2, EtOH) {lit. [23] [˛]2D5
−29.7 (c 2.59, EtOH), S}.
2.1. Cultivation of microbes
Compound (S)-1c: [˛]D25 = −29.5 (c 1.11, CHCl3) {lit. [24] [˛]25
D
−39.5 (c 1.21, CHCl3), S}.
Microbacterium oxydans ECU2010, which was deposited in China
General Microbiological Culture Collection Center with an acces-
sion number of CGMCC No. 1875 was grown in a medium consisting
of glucose (15 g/L), beef extract (30 g/L), peptone (20 g/L), KH2PO4
(0.5 g/L), K2HPO4 (0.5 g/L), NaCl (1 g/L) and MgSO4 (0.5 g/L) while
Rhodotorula sp. AS2.2241, which was also deposited in China Gen-
eral Microbiological Culture Collection Center with an accession
number of CGMCC No. 1735 was grown in another medium consist-
ing of glucose (15 g/L), yeast extract (5 g/L), peptone (5 g/L), KH2PO4
(0.5 g/L), K2HPO4 (0.5 g/L), NaCl (1 g/L) and MgSO4 (0.5 g/L). After
adjusting to pH 7.0 using 2 M NaOH solution, 100 mL of the medium
was placed in a 500-mL Erlenmeyer flask, sterilized (121 ◦C, 20 min)
and inoculated with the preincubated culture, shaken at 30 ◦C and
180 rpm for 24 h.
Compound (S)-1d: [˛]D25 = −43.1 (c 1.15, CHCl3) {lit. [22] [˛]25
D
−37.9 (c 1.13, CHCl3), S}.
Compound (S)-1e: [˛]D25 = −30.6 (c 0.98, CHCl3) {lit. [25] [˛]25
D
−27.3 (c 0.53, CHCl3), S}.
Compound (S)-1f: [˛]D25 = −25.1 (c 0.41, CHCl3) {lit. [26] [˛]25
D
−30.3 (c 0.996, CHCl3), S}.
−37.2 (c 1.01, MeOH), S}.
The 1H NMR spectra of these compounds were in agreement
with those reported in the literatures [28–30].
3. Results and discussion
2.2. Selective oxidation of aryl secondary alcohols with M.
oxydans ECU2010
In our previous work, a novel microbial strain was isolated
from soil and identified as M. oxydans ECU2010 [31], which
could enantioselectively catalyze the dehydrogenation of (R)-
enantiomer of rac-1-phenylethanol rac-1a to acetophenone 2a
in an anti-Prelog mode via a NAD+-dependent (R)-alcohol dehy-
AS2.2241, was also successfully isolated from soil samples, which
could stereoselectively reduce 2a to yield (S)-1a in excellent ee
via a NADPH-dependent (S)-stereoselective ketoreductase (KER)
[30,32,33].
Fresh cells (0.02 g) of M. oxydans ECU2010 and substrate
(0.02 mM) were suspended in a screw-capped 10-mL test tube
containing Tris–HCl buffer (1 mL, 50 mM, pH 8.5) and shaken at
180 rpm for 24 h at 30 ◦C. Then the biotransformation was stopped
by addition of the same volume of ethyl acetate and extracted
for two times. After centrifugation at 12,000 rpm for 10 min, the
organic phase was dried over anhydrous Na2SO4. Conversion and
ee of products were determined by GC or HPLC analysis.
2.3. Deracemization of various aryl secondary alcohols by
combination of resting cells of M. oxydans ECU2010 and
Rhodotorula sp. AS2.2241
3.1. Deracemization of rac-1-phenylethanol by whole-cell
biotransformation
We attempted to put two kinds of biocatalysts together to real-
ize the stereoinversion of (R)-1a to (S)-1a via a cascade one-pot
process involving the enantioselective oxidation of (R)-1a to 2a
catalyzed by M. oxydans ECU2010 followed with the asymmetric
To obtain enantiopure aryl secondary alcohols (S)-1, rac-1
(20–40 mg) and resting cells of M. oxydans ECU2010 (wcw: 0.2 g)
and Rhodotorula sp. AS2.2241 (wcw: 1.8 g) were suspended in
Table 1
Biocatalytic stereoinversion or deracemization of (R)-1-phenylethanol through a tandem stereoselective oxidation–reduction sequence with fresh cells of Microbacterium
oxydans ECU2010 and Rhodotorula sp. AS2.2241.
Entry
Substrate
Concentration (mM)
M. oxydans ECU2010 (g L−1
)
Rhodotorula sp. AS2.2241 (g L−1
)
Time (h)
(S)-1aa (%)
eeb (%)
1
2
3
4
(R)-1a
(R)-1a
rac-1a
rac-1a
30
50
30
70
20
20
20
30
180
180
180
270
32
48
24
32
97.2
85.1
98.2
96.7
>99
92.9
>99
>99
a
The relative amount was determined by GC analysis.
The enantioselectivity was determined by GC analysis, ee = ([S] − [R]/[S] + [R]) × 100%, where [S] and [R] denote the concentrations of (S)-1a and (R)-1a.
b
