10.1002/anie.202005138
Angewandte Chemie International Edition
COMMUNICATION
complexes and overall, complex 3 adopts a distorted octahedral
geometry.[13] The four equatorial U-C distances of 2.449(5) Å and
2.452(5) Å and the shorter axial U-C distances of 2.415(5) Å
reflect this symmetry. Due to the increased difficulty of obtaining
enough material for NMR analysis, the 10 K EPR spectrum of a
solid sample of 3 was instead obtained and displayed a
resonance at a g-value of 1.49 consistent with the U(V) oxidation
state (Figure S5).[20] We hypothesize that the formation of 3 under
these highly reducing conditions is consistent with
disproportionation of two U(IV) centers. However, a homolytic U-
CH3 cleavage and subsequent oxidation of a U(IV) center to yield
U(V) could not be ruled out.
Figure 2. X-ray crystal structure of [Li(THF)4][Li(THF)2U(CH3)6] (1) with
thermal ellipsoids drawn at 50% probability level. Hydrogen atoms are omitted
for clarity. Selected bond lengths (Å) and angles (deg): U1-C1 = 2.533(5), U1-
C2 = 2.510(5), U1-C3 = 2.500(5), U1-C4 = 2.504(5), U1-C5 = 2.615(5), U1-
C6 = 2.591(6), U1…Li1 = 3.136(8), C3-U1-C4 = 96.27(19), C3-U1-C2 =
85.60(19), C3-U1-C5 = 178.5(2), C2-U1-C1 = 173.63(18), C1-U1-C6 =
89.9(2).
The accessibility of similar monomeric species in Et2O was
explored as challenges to identify organouranium products were
reported in this solvent as well.[12] Similar to our efforts in THF, 6
equiv of MeLi was added to UCl4 in Et2O at -70 °C. After stirring
for 10 min, pentane was added, and the mixture was filtered over
a cold Celite plug. In addition to the dark filtrate, unreacted UCl4
was observed in the filtrate. The resultant light-yellow solution was
stored at -80 °C. After several days the heptamethyluranium(IV)
complex, {Li(OEt2)Li(OEt2)2UMe7Li}n (2), formed as a pale-green
crystalline material (ca. trace) (Figure 3). Complex 2 crystallized
in the monoclinic space group, P21. Comparison of complex 2 to
a previously reported thorium analog shows a similar distribution
of An–CH3 (An = Th or U) bond lengths (2.519(6)–2.779(5) Å vs.
2.571(9)–2.765(9) Å, respectively).[18] The carbon atoms C1, C3,
C4, and C7 in complex 2 form a plane in which U1, C5 and C6
are positioned below and C2 above. Furthermore, unlike its
thorium analog, 2 oligomerizes in the solid state in which C7
coordinates to Li1 of another molecule of 2 in the extended
crystalline network (Figure S4). To the best of our knowledge,
Figure 3. X-ray crystal structure of {Li(OEt2)Li(OEt2)2UMe7Li}n (2) with thermal
ellipsoids drawn at 50% probability level. Hydrogen atoms are omitted for
clarity. Selected bond lengths (Å) and angles (deg): U1-C1 = 2.588(5), U1-C2
= 2.692(5), U1-C3 = 2.779(5), U1-C4 = 2.593(5), U1-C5 = 2.554(5), U1-C6 =
2.594(5), U1-C7 = 2.519(6), C7-U1-C5 = 116.0(2), C7-U1-C1 = 76.65(19), C1-
U1-C2 = 80.88(16), C1-U1-C4 = 144.96(15), C5-U1-C2 = 156.51(18). Note:
Li1 is coordinated to C7 of another molecule of 2 in the extended crystalline
network (Figure S4).
The modest change in reaction conditions which led to the
isolation of 2 and 3 motivated us to explore the crystallization
conditions previously utilized to isolate 1 to determine whether
other uranium-methyl species were accessible. To our surprise,
the modification of the crystallization conditions used for complex
1, by the significant decrease in the volume of hexane used as
co-solvent (1.0 mL vs. 2.5 mL), led to the formation of an
unexpected uranium-methyl dimer, [Li(THF)4]2[U2(CH3)10] (4) as
dark orange crystalline material in 20% isolated yield (Figure 5).
Complex 4 crystallized in the trigonal space group R-3c. The
asymmetric unit consists of one-sixth of the dinuclear uranium
dianion and one-third of a [Li(THF)4]+. The orientation of the
hydrogen atoms could not be determined from the difference
Fourier map, hence, no agostic interaction could be determined
from the solid-state structure. The dianion of 4 consists of two
uranium centers bound to seven and six methyl groups with
capped octahedral and octahedral geometries, respectively. The
asymmetric coordination environment of the dimer is reflected in
the difference between the terminal U–CH3 bonds of the two
uranium centers with the 7-coordinate U center displaying a
significantly shorter terminal U–CH3 bond length of 2.481(6) Å for
three of the four -CH3 groups compared to that of the 6-coordinate
U center of 2.524(5) Å. The unique methyl substituent, C4, has a
distinctly shorter bond length of 2.438(10) Å. This distance is
reminiscent of previously reported homoleptic U(V)-C bond
lengths.[13] The bridging U–CH3 bonds were expectedly the
longest 2.658(3) Å. The U–U separation is comparable to other
reported alkyl bridged complexes (3.6089(3) Å compared to the
complex
2 also represents an unprecedented coordination
environment for homoleptic U(IV) alkyls. Previous attempts to
generate such species proved unsuccessful and coordination of
six alkyl ligands was hypothesized to be an upper limit to the U(IV)
coordination number.[12] The formation of the 7-coordinate
complex 2 may result from the high effective concentration of
MeLi due to the inherent heterogeneity of the reaction in Et2O.
Unfortunately, due to low conversions from UCl4, sufficient
amounts of crystalline material were unable to be produced,
limiting any further characterization.
Due to the intractability of reactions in Et2O even with low
temperature synthetic techniques, the use of crown ethers as
complexants to facilitate the isolation of uranium-methyl species
was explored.[19] The common Li+ complexant, 12-crown-4 was
added to the reaction following addition of MeLi to UI4(1,4-
dioxane)2. Orange microcrystalline material not suitable for XRD
was obtained. Thus, 18-crown-6, was utilized instead. Upon
addition of a solution of 18-crown-6, a light-yellow precipitate
immediately formed. The reaction mixture was filtered, and the
filtrate was re-dissolved in THF. After storage at -80 °C for a week,
a dark red crystalline material formed which was identified as the
hexamethyluranium(V) complex, [Li(18-crown-6)(THF)2][UMe6]
(3) (<10% yield, Figure 4).
closest of 3.616 and 3.629
Å
of previously reported
complexes).[21,22] The 1H NMR of complex 4 in methylenechloride-
d2 is associated with two broad singlet resonances centered at
4.29 and 1.90 ppm, consistent with the two distinct chemical
Complex 3 crystallizes in the triclinic space group P-1, and the
Li atom disorder is modeled over three positions. The U-C
distances are consistent with other reported homoleptic U(V)-alkyl
