Dicyclohexylurea derivatives of amino acids as dye absorbent organogelsDOaI:n1d0.10a3V9ni/eiCwo9AOnrtBic0le0O0n1l4inCe
sensors
Karabi Roy,1 Suvankar Ghosh,2 Monikha Chetia,1 Priyadarshi Satpati2*and Sunanda
Chatterjee1*
1. Department of Chemistry,
Indian Institute of Technology, Guwahati
Guwahati, Assam, India 781039.
Email: sunanda.c@iitg.ac.in
Telephone: 0361-2583310
2. Department of Biosciences and Bioengineering
Indian institute of technology, Guwahati,
Guwahati, Assam, India 781039.
Email: psatpati@iitg.ac.in
Telephone: 0361-2583205
1

Organic & Biomolecular Chemistry
Page 2 of 36
View Article Online
DOI: 10.1039/C9OB00014C
Abstract:
Dicyclohexyl urea (DCU) derivatives of amino acids Fmoc-Phe-DCU (M1), Fmoc-Phg-DCU
(M2) and Fmoc-Gaba-DCU (M3) have been shown to form phase selective, thermoreversible
and mechanically robust gels in a large range of organic solvents. This is the first report of low
molecular weight gelators (LMWG) from DCU derivatives of amino acids. The self-assembly
mechanism of the organogels has been probed using concentration dependent 1H NMR, DMSO
titration 1H NMR, Fluorescence, FTIR, PXRD and FESEM techniques. Self-assembly leading
to gelation process is mainly driven by hydrophobicity and - stacking interactions in between
Fmoc groups. Interestingly, the gels can absorb several kinds of organic dyes efficiently and
can be reused for dye absorption for multiple cycles. Additionally, M1-M3 act as sensors for
anions like fluoride, acetate and hydroxide, for which they have specific fluorescence response.
Gel formation by M1-M3 is completely arrested in the presence of fluoride. The possible
binding mode of fluoride has been delineated using DFT studies. Calculations suggest,
involvement of urea NH in a six membered intramolecular hydrogen bond, rendering it
unavailable for fluoride binding. Backbone -NH of the amino acids of M1-M3 is responsible
for fluoride binding. The reported small, economically viable, synthetically facile molecules
not only enrich the repertoire of LMWG molecules, but can have multifaceted applications.
Keywords: Low molecular weight gelators, urea derivatives, organogels, - stacking, dye
absorption, water pollution, selective anion sensors, DFT calculations.
Abbreviations:
2

Page 3 of 36
Organic & Biomolecular Chemistry
View Article Online
DOI: 10.1039/C9OB00014C
DCU
Dicyclohexyl urea
Fmoc
Fluorenylmethyloxycarbonyl
FESEM
NMR
Field emission scanning electron microscopy
Nuclear magnetic resonance
FTIR
Fourier transform Infrared spectroscopy
Powder X-ray diffraction
PXRD
LMWG
Low molecular weight gelators
1, 2 DCB 1,2 Dichlorobenzene.
CV
Crystal Violet
RB
Rhodamine B
NR
Neutral red
MGC
Phe
Minimum gelation concentration
Phenylalanine
Phg
Gaba
RT
Phenyl glycine
 amino butyric acid
Room Temperature
Tetrahydrofuran
THF
DFT
Density functional theory
TDDFT
ANS
Time-dependent density function theory
8-Anilinonapthalene-1-sulfonic acid
DCC
ACN
Dicyclohexylcarbodiimide
Acetonitrile
3

Organic & Biomolecular Chemistry
Page 4 of 36
View Article Online
DOI: 10.1039/C9OB00014C
Introduction:
Low-molecular-weight gelators (LMWG) are small molecules that can immobilize solvents
through molecular self-assembly, and represent a novel class of supramolecular functional
materials1-3. There is a plethora of literature on the various applications2-3 of LMWG: as
templated materials,4 light harvesting materials,5stabilizers of organic photo chromic
materials,6enzyme-immobilization matrices for in situ formation and stabilization of
7
nanoparticles and clusters in preparation of dye sensitized solar cells,8dental composite
carriers,9controlled release of bioactive molecules and drugs;1038-45 in cell culture and tissue
engineering,11-12 phase selective gelation,13-15oil spill recovery,13-14,16waste treatment, dye
adsorption,17-22 and others23-24. Organogelators are molecules that create a three-dimensional
(3D) network in organic solvents by self-organization of the monomeric species to higher-order
structures. Gelation is driven by specific non-covalent intermolecular interactions, commonly
electrostatic, dipole–dipole, van der Waals, - stacking, hydrophobic, hydrogen bonding and
hydrophilic-lipophilic balance.25-27 The diverse applicability of the organogelators have
stimulated in the growth of rationally designed small molecules over the last few decades.28-
33Amino acids and peptides have emerged as one of the potential gelator molecules that are
easy to avail, cost effective, biocompatible and capable of forming gels in a wide variety of
organic solvents. Though there are a few studies which report gelation of small peptides and
single amino acid derivatives,34-36 there are no reports of dicyclohexyl urea (DCU) derivatives
of single amino acids forming organogels.
In this report, we have designed three single amino acid derivatives of DCU namely, Fmoc-
Phe-DCU (M1), Fmoc-Phg-DCU (M2) and Fmoc-Gaba-DCU (M3) (Figure 1a) and for the
first time reported their organogelation. We have also tried to understand their mechanism of
self-assembly and looked at their potential applications.
Water pollution is a matter of grave environmental concern in the modern day society and
4

Page 5 of 36
Organic & Biomolecular Chemistry
View Article Online
treatment of waste water is of primary importance. Dyes used in textile, paDpOeIr: ,10.l1e0a39t/hCe9rO,B00014C
cosmetics, pharmaceutical and food industries are major sources of water pollution37 and upon
reaching water bodies have adverse effect on all forms of life and on ecosystem as a whole.38
The dye effluents and their degradation products are toxic and carcinogenic exhibiting negative
impact on the immune system, reproductive system and possessing potential geno-toxicity and
cardio-toxicity.39-40 Conventional methods of treating dye effluents like incineration, biological
treatment, absorption upon solid matrices like activated carbon, chemical precipitation,
electrochemical techniques, ion exchange, and others, have their own limitations due to their
low sensitivity, incomplete removal, high-energy requirements, and production of toxic
sludge.41 Hydro/Organogel-based soft materials17 offer an appealing alternative for removal of
dyes from contaminated water due to their high water permeability, large surface area for
adsorption and simplicity in use along with reusability and proper biodegradability.
Though anions play a vital role in various environmental and health processes, overexposure
may lead to pathological problems. For example, fluoride is extremely important for dental
care and osteoporosis, while chronic exposure to high levels of fluoride anion can lead to dental
or skeletal fluorosis.42 Fluorine is also present in several chemical weapons like sarin, soman
etc.43 This makes anion detection, and hence design, synthesis and development of new sensors
of immense importance.44-45 Of the various responses generated upon ion sensing, optical
sensors (generating fluorescence response) are the most popular being highly sensitive.46 Urea
48
moiety is a well-known anion binder.47 There are several experimental and computational
49-50studies on urea based fluoride sensors. Development of anion, especially fluoride
responsive low molecular weight organogels is an area of active research.51-55
In a quest to find suitable applications for organogels M1-M3, we found them to be efficient
and recyclable organic dye absorbents. Additionally, molecules M1-M3 can act as sensors of
selective anions like fluoride, acetate and hydroxide. Anion sensing abilities of the molecules
5

Organic & Biomolecular Chemistry
Page 6 of 36
View Article Online
have been studied using spectroscopic techniques like UV absorption, fluorescence and NMR
DOI: 10.1039/C9OB00014C
on one hand and DFT studies on the other. Such simple, economically viable yet
multifunctional small molecules are of immense relevance in the recent times.
Results and discussions:
Aromatic amino acid Phenylalanine (Phe) derivative Fmoc-Phe-DCU (M1), forms gel in
various organic solvents like benzene, chlorobenzene, 1,2 dichlorobenzene (1,2 DCB),
tetrahydrofuran (THF), toluene, chloroform, dichloromethane (DCM) and 3-xylene upon
being heated and subsequently cooled (Minimum gelation concentration, MGC = 0.2-0.4 %,
w/v) (Table1, Figure 1). The gelation properties of M1 are documented in Table 1. M1 contains
aromatic side chains of the amino acid residue Phe and an aromatic N terminal protecting group
Fluorenylmethyloxycarbonyl (Fmoc). To investigate which if aromatic interactions between
any of these groups were involved in gelation, we replaced the Phe residue with two other
amino acid residues, a) aromatic Phenylglycine (Phg) to form Fmoc-Phg-DCU (M2) and b)
non aromatic gamma aminoisobutyric acid (Gaba) to generate Fmoc-Gaba-DCU (M3). Both
M2 and M3 formed gels like M1 and their gelation properties were same as that of M1 (Table
1, Figure 1). This observation indicates that the aromatic side chain of the amino acid residue
might not be a necessary factor in the gelation process. The aromatic moiety Fmoc most
probably plays an important role in the gelation process. To investigate the role of Fmoc group
in the gelation process we designed the control molecule Boc-Gaba-DCU (M4). This molecule
did not form gel under the experimental conditions (Figure 1b) suggesting that the - stacking
of the Fmoc moieties is one of the main drivers for the gelation process. Minimum gelation
concentration of most gels for the three gelators in different solvents lies within 0.2 to 0.45
(w/v %) (Table 1). All the molecules M1-M3 have a very low MGC in 1,2 DCB. Moreover,
the gels formed from 1,2 DCB were translucent and remained stable for a very long time. Thus
6

Page 7 of 36
Organic & Biomolecular Chemistry
most of the experiments to study the morphology of the organogels have been done inV1iew, A2rticle Online
DOI: 10.1039/C9OB00014C
DCB.
The thermal stability of the gel has been studied in different organic solvents by monitoring
the gel melting temperature (Tgel) at the minimum gelation concentration. The experiment was
performed by heating organogels in a thermostatic oil bath with an increment of temperature
of 1C/min until the organogels melted to sol. The Tgel values of the gels formed from various
solvents have been found to be ranging from 32 to 96 C (Table 1).
The gels formed by M1-M3 are of thermo reversible nature, i.e. the gel is reversibly converted
into sol upon heating. On cooling the sol, gel is formed once again (Figure 1c). M1 –M3 act as
phase selective gelators which can selectively gel the organic part from a mixture of water-
organic solvent as shown in the Figure 1d.
Morphological studies:
Morphological features of the gel formed by M1-M3 in 1,2 DCB at MGC has been studied by
Field Emission Scanning Electron Microscopy (FESEM) (Figure 2a-c). M1 forms aggregated
morphology which is distinctly different from M2 and M3. M2 adopts a fibre-like morphology
while M3 forms nano-tape like morphology. The morphology of M1-M3 in solution at 10 mM
concentration in 1,2 DCB is distinctly different from that in the gel state as shown in Figure
S1.
Rheological studies:
The mechanical strength and stability of the gel is revealed from the viscoelastic properties,
which has been studied using rheology (Figure 2d-f). For rheological studies, the storage
modulus (G´) and the loss modulus (G´´) were measured as a function of different parameters,
including strain sweep and angular frequency. The gels have been formed from M1, M2 and
M3 in 1, 2 DCB at 2.0 % w/v for this study. In strain sweep experiment where the storage
modulii (G´) and the loss moduli (G´´) for the three organogels have been plotted as a function
7

Organic & Biomolecular Chemistry
Page 8 of 36
of % strain (0.1-10%) (Figure S2) (Table S3), it was found that G´ was higher than G´´(oVfietwhAerticle Online
DOI: 10.1039/C9OB00014C
order of 104 Pa) till a particular strain (Linear viscoelastic region (LVR),  = 0.1-0.79% for
M1, 0.1-0.795% for M2 and 0.123-0.371% for M3), beyond which the two passed through a
crossover point (Table S3) which indicated that the materials no longer stayed in the gel state.
Beyond the LVR, the G value first increased with the increasing strain till the crossover point,
and then decreased, which is a characteristic feature of soft glassy materials.56 An angular
frequency sweep experiment was performed where Gʹ and Gʹʹ were plotted against the angular
frequency sweep at a constant strain of 0.1% at 25 °C. For the three organogels, the Gʹ was
found to be dominating over Gʹʹ till about 100 rad/s. Also, Gʹ and Gʹʹ were found to be
independent of angular frequency, in the region 1-100 rad/s which indicated the formation of
stable organogels. The storage modulii of the organogels were of the order of 104 Pa, in the
frequency sweep experiment which indicated a considerable mechanical strength of the three
organogels.
Non covalent drivers of self-assembly
The molecules designed have the following features: a) Fmoc moiety at the N terminus, b)
DCU moiety at the C terminus and c) an intervening amino acid residue which is hydrophobic
in nature. Amino acids Phe and Phg have aromatic side chains. Hence, the organogels formed
by these molecules have a high chance of being stabilized by the a) - interactions in between
the N terminal Fmoc groups and/or the side chains of the aromatic residues, b) intermolecular
hydrogen bonding in between the NH and CO of the urea groups and amino acids and c) the
vander waals interaction in between the hydrophobic amino acid residues. However formation
of organogel by M3 which contains the non-aromatic amino acid residue Gaba indicates that
aromatic side chains are not necessary for the gelation process. On the contrary, inability of
M4 (Boc-Gaba-DCU) to form organogel under similar experimental conditions is a direct proof
8

Page 9 of 36
Organic & Biomolecular Chemistry
View Article Online
that - stacking of the N terminal Fmoc moieties is of immense importance in formation of
DOI: 10.1039/C9OB00014C
gels. In order to probe the role of the Fmoc groups in the self-assembly process, we studied the
concentration dependent fluorescence emission of the Fmoc group. Concentration dependent
Nuclear Magnetic Resonance (NMR) and dimethyl sulfoxide (DMSO) solvent titration were
performed to study the role of hydrogen bonding in the gelation process. Fourier Transform
Infrared (FTIR) spectrum of powdered and xerogel samples were compared.
Fluorescence studies:
The fluorescence emission spectra for M1-M3 in 1, 2 DCB with varying concentrations is
shown in Figure 3a-c. The characteristic fluorescence emission peak for monomeric Fmoc
group appeared at around 350 nm at lower concentrations for all the three compounds. With
increase in the concentration, the peak at 350 nm is blue shifted to about 346 nm for all the
compounds. This was accompanied by quenching of the peak intensity in some of the cases. In
an earlier study, such blue shift in the fluorescence emission of ANS was reported upon
increasing the hydrophobicity of the microenvironment.57 In the present context, blue shift of
Fmoc emission maxima indicates, increase in the hydrophobicity of the microenviornment
around the Fmoc moieties, which might be a consequence of - stacking of the Fmoc moieties
upon progressive self-assembly. In the fluorescence spectra of M3, upon increasing the
concentration, additional broad peaks appear at 415 nm and 450 nm, which might be attributed
to the excimer peaks. Absence of side chains in Gaba used in M3, might lead to closer packing
of the molecules leading to appearance of excimer peaks. Blue shifting of the emission maxima
with increasing concentration, is an indication of the increasing hydrophobic environment,
which is a predictable consequence of increasing self-assembly. In brief, the concentration
dependent fluorescence emission spectra clearly indicate the presence of - stacking among
the Fmoc groups upon increasing the concentration. Hence aromatic - stacking may be one
9

Organic & Biomolecular Chemistry
Page 10 of 36
View Article Online
DOI: 10.1039/C9OB00014C
of the key factor in driving the gelation process.
FTIR Spectroscopy
Figure S3a-c shows the superimpositions of FTIR of M1-M3 respectively, from the powdered
sample and the xerogels obtained from 1,2 DCB. The molecules contain two NH protons and
two carbonyl moieties. Peaks for NH protons in molecules M1-M3 in the powdered state
appear at 3416/3319 cm-1, 3405/3321 cm-1 and 3358/3315 cm-1 respectively. These peaks get
significantly broadened in the xerogel state for all the compounds. Similarly the Fmoc
carbamate carbonyl, the amino acid carbonyl and the urea amide carbonyls which give distinct
peaks in the region of 1706-1650 cm-1in the molecules M1-M3 in the powdered state is
noticeably diminished in the xerogel state.
NMR Spectroscopy :
The role of intermolecular hydrogen bonds in formation of the self-assembly of the peptides is
1
probed by performing concentration dependent H NMR experiment and monitoring the
change in chemical shifts of the NH groups present in the molecules. Figure 4a shows the
overlay of the NH regions of the 1H NMR spectra obtained for M2 at different concentrations
(0.125 mM, 0.25 mM, 0.5 mM, 1 mM, 2 mM, 3.44 mM (MGC) and 5 mM) in
CDCl3.Concentrations less than MGC, MGC and higher than MGC were selected. There was
no visible change in the chemical shifts of the two amide protons of M2 across the entire
concentration range (0.125 mM - 5 mM) indicating that there was no change in the electron
density about the amide protons or in other words there was no change in the hydrogen bonding
status of the two amides in this concentration range. To find out the hydrogen bonding status
of the amide protons, we performed a DMSO titration experiment (Figure 4b). M2 was
dissolved in a non-polar and inert solvent CDCl3 and an NMR was recorded initially. CDCl3
being non polar was incapable of forming hydrogen bonds with the amide protons of M2. To
10

Page 11 of 36
Organic & Biomolecular Chemistry
this, increasing amounts of polar solvent DMSO-d6 was added, which formed hydDrOoIg: 1e0n.10b3V9oi/enCw9dAOsrtBic0le0O0n1l4inCe
with the non-hydrogen bonded amide protons of M2 leading to a downfield shift of the
concerned signals in the NMR. Signals of amide protons which were already intra or
intermolecularly (solute-solute) hydrogen bonded in CDCl3 did not show any change in the
chemical shifts. Amide proton of urea (N-Ha) did not show any change in its chemical shift
while the amide proton of the amino acid Phg (N-Hb) showed a considerable downfield shift
(δ =0.85 ppm) indicating that the N-Ha was hydrogen bonded unlike the Phg amide proton in
non polar solvent like CDCl3.
Powder X-ray Diffraction (PXRD)
PXRD studies have been carried out to obtain information about molecular packing of M1-M3
in gel state. PXRD pattern of the xerogels obtained from 1,2 DCB in the wide angle regions
for M1-M3 is shown in Figure S3d-f. The wide angle PXRD patterns of all the xerogels show
periodic diffraction patterns unlike the powdered samples and this indicates presence of
ordered structures in their xerogel form. PXRD pattern for xerogels of all the three molecules
M1-M3 looks identical suggesting that very similar packing pattern is present in all of them.
The peak at 2 = 21.88 (d = 4.08 Å), 21.78 (d = 4.08 Å) and 21.9 (d = 4.06 Å) for M1-M3
might correspond to the - stacking distance in between the aromatic moieties of the gelator
molecules.16 The peak at 2 =18.56 (d = 4.78 Å), 18.90 (d = 4.69 Å) and 18.94 (d = 4.68 Å)
for M1-M3 might correspond to the distance in between the C-terminal ends of the gelator
molecules.16
Dye absorption studies:
The organogels formed by the molecules M1-M3 were subjected to the dye absorption studies
with the aim to employ these organogels for purifying water contaminated with toxic dyes. We
checked the dye absorption by the gels with three dyes, namely crystal violet (CV), neutral red
(NR) and rhodamine B (RB). When the mixture of the organic solution of LMWG and aqueous
11

Organic & Biomolecular Chemistry
Page 12 of 36
View Article Online
solution of dye was heated and subsequently cooled, the organic phase with DtOhIe: 10L.10M39W/C9GOB00014C
molecule selectively formed gel and absorbed the dye from the aqueous solution within some
time. This was studied by monitoring UV of the aqueous phase (Figure 5a-c, S4) along with
the visible fading of the color of the aqueous phase as shown in the figure S5. All the
organogels acted as very efficient dye absorbents with about 90% efficiency for all the dyes
(Figure 5d, Table S2).
Reusability of the gel: In order to be efficiently used as a material for water purification, the
material should be economic and hence, recyclable. The organogels from M1-M3 could be
reused over three cycles for subsequent loading and release of the dye, after which the quality
of the dye degraded (Figure S6). Figure 6a shows the percentage efficiency of CV uptake in 24
hours in the three subsequent cycles and Figure 6b indicates percentage release of CV after 16
hours in the three subsequent cycles from M1 organogel. Figure 6c compares the diminishing
loading and release efficiencies of M1 organogel in the three subsequent cycles.
Ion sensing studies: As our molecules contain urea moiety which is known widely as a
fluoride ion sensor, we looked into anion sensing abilities of M1-M3. We first decided to look
at the UV-Vis absorption and fluorescence behavior of M1-M3 in the absence and the presence
of various anions like fluoride, chloride, bromide, iodide, bisulphate, phosphate, acetate and
hydroxide (as their Bu4N+salts) (Figure 7, S7, S8). The spectroscopic studies were performed
in acetonitrile (ACN) as the molecules did not form gel in this solvent. Secondly, ACN was
inert and did not have any absorption in the range 200-600 nm. UV absorption of M1-M3 was
only sensitive to fluoride, acetate and hydroxide (Figure 7a, S7a, S8a). In the absence of anions,
M2 (Figure 8a) and M1 (Figure S7a) contained peaks at 265 nm, 289 nm and 299 nm. Shoulders
were observed at 255 nm and 272 nm. Upon addition of fluoride, acetate and hydroxide, the
shoulder at 255 nm developed into a peak with appearance of another new peak at 245 nm. The
peak at 289 nm disappeared. Peaks at 265 and 299 nm remained unchanged (Figure 8a-c).In
12

Page 13 of 36
Organic & Biomolecular Chemistry
-
-
-
-
-
View Article Online
DOI: 10.1039/C9OB00014C
the presence of other anions (Cl , Br , I , HSO4 , PO4 ), there was no change in peak positions
and minor changes in peak intensities (Figure 7a, S7a). M3 had similar UV absorptions as M1
and M2, which did not change appreciably upon addition of any anions (Figure S8a).
In order to look at the effect of the anions on the excited state of the molecules, change of the
fluorescence signal in the presence of anions was studied (Figure 7b, S7b, S8b). In the absence
of anions, upon being excited at 301 nm, the fluorescence emission maxima for M1-M3 was at
332 nm. Upon addition of 0.1mM fluoride, acetate and hydroxide, the peak at 332 nm was
slightly blue shifted (for M1 and M3) (Figure S7b, S8b) and quenched (predominantly for M2)
(Figure 7b). A prominent new peak appeared at 459 nm for all the three molecules M1-M3.
There was negligible effect on the fluorescence spectra of M1-M3 in the presence of other ions
(Figure 7b, S7b and S8b). Thus it was concluded that molecules M1-M3 selectively sensed
fluoride, acetate and hydroxide anions. To find out the sensitivity of anion detection, the
fluorescence response was monitored as a function of anion concentration for a fixed
concentration of M1-M3 (Figure 8d-f, S9-13b). For all the three molecules, anions could be
detected at a minimum concentration level of about 0.02 mM. With increase in the
concentration of the anion, the intensity of the peak at 459 nm steadily increased.
In order to understand the interaction in between fluoride anion and M1-M3 in greater detail,
1H NMR titration experiment was carried out with M2 in the presence of fluoride ions (Figure
9). With increasing concentration of F-, the urea NH (N-Ha) shows no change in its chemical
shift value while the NH proton of the amino acid Phg (N-Hb) disappears quickly with a
downfield shift (δ = 0.24 ppm). This observation indicates that strong interaction via
hydrogen bonds exists between the amino acid NH (N-Hb) and the fluoride in the anion
complexed form. The urea NH does not seem to form any hydrogen bonds with the anions as
it is already intramolecularly hydrogen bonded as seen from the DMSO titration of M2 (Figure
4b).
13

Organic & Biomolecular Chemistry
Page 14 of 36
View Article Online
To study the effect of the anions on the ability of formation and the disruption (gel-sol
DOI: 10.1039/C9OB00014C
transition) of organogels, the anions were added a) to the organic solvent containing M1-M3,
heated together and cooled subsequently(Figure S14a-c, S15a-c, S16a-c) and b) to the
preformed gel (Figure 14d-f, 15d-f, 16d-f). This study was performed only with those anions
which had a fluorescence response. Fluoride prevented gel formation in all of the LMWG
molecules, while hydroxide prevented gel formation only in M2 and M3. Gel formation was
not prevented by acetate for any of the molecules M1-M3. None of the anions could disrupt
preformed gels formed by M1 to M3 (FigureS14d-f, S15d-f, S16d-f).The varying response
towards the anions might be associated with the varying strength of self-assembly of different
gels.
Electronic structure calculations
We performed DFT studies for understanding the mode of binding of fluoride to the M2
molecule at the atomic level. The optimized ground state structures of M2 monomer and its
fluoride bound M2:F- complex are shown in Figure 10. N-Ha (DCU) and N-Hb (amino acid
backbone) bond lengths are almost identical, former being slightly elongated for free M2
monomer (Figure 10a). Intramolecular hydrogen bond between N-Ha of DCU and carbonyl of
amino acid backbone in the six-membered ring is a characteristic feature of M2. The angle N-
Ha…O is 132.5 and Ha…O distance is 1.81Å respectively. This feature is supported by the 1H
NMR DMSO titration experiment discussed earlier (Figure 4b) in which N-Ha was shown to
be intramolecularly hydrogen bonded. Calculations suggest two possible fluoride binding
modes which are isoenergetic; single (M2:F-_S1, Figure 10b) and double (M2:F-_S2, Figure
10c) intermolecular hydrogen bonds between F- and M2. This suggests that the double
hydrogen bonded interaction between M2 and F- is offset by disruption of favorable
intramolecular hydrogen bonding between N-Ha and CO of amino acid. In M2:F-_S1 fluoride
14

Page 15 of 36
Organic & Biomolecular Chemistry
View Article Online
binding to the amino acid backbone N-Hb leads to elongation of the N-Hb bondDlOeIn: 1g0t.1h03f9r/Co9mOB00014C
1.01Å to 1.09Å (Figure 10b). F-…Hb distance is 1.43Å and the orientation of the six-membered
ring relative to N-Hb is altered upon fluoride binding (Figure 10b).. N-Hb, F-…Hb distances in
the double hydrogen bonded M2:F-_S2 are 1.06Å and 1.51-1.54Å respectively. The shorter
F ̄
…Hb and larger N-Hb in M2:F-_S1 with respect to M2:F-_S2 makes N-Hb of the former
more susceptible towards fluoride induced deprotonation. This observation is in lines with the
1H NMR titration experiment discussed above (Figure 9). However, fully deprotonated form
(M2-:HF) was not observed upon geometry optimization starting with different geometries with
varying F ̄…Hb and N-Hb distances in single intermolecular binding mode. Optimization with
different initial geometries always gave M2:F-_S1 (Figure 10b). Calculated normal model
frequencies of all the optimized geometries indicate that all the reported structures were true
minima on the potential energy hyper surface. The optimized geometries of M2:X- (X = Cl,
Br, I, OH, OAc) are given in the supporting information (Figure S17). The calculated
absorption spectra of M2 and M2:F-are shown in Figure 10c and calculated absorption peaks
are listed in Table 2. For M2 monomer, the first calculated absorption peak located at
265.64nm, is in excellent agreement with the experiment (Figure 7a). This absorption is
primarily assigned to the highest occupied molecular orbital (HOMO) to lowest unoccupied
molecular orbital (LUMO) transition (Figure 7a). Characteristic absorption peaks of fluoride
bound M2:F- at 255 nm and 246 nm were also reproduced by theoretical calculations (Table
2). The molecular orbitals relevant to the absorption peaks are shown in Figure S18.
Having understood now that the urea NH (N-Ha) is actually not involved in the fluoride binding
event we asked the question if the DCU moiety is important at all in the ion sensing abilities
of M1-M3. To probe this we considered the control molecule Fmoc-Phe-OH and studied its
ion sensing abilities. There is no UV absorption or fluorescence response in the presence of
any of the anions that were tested (Figure S19). This is a crucial evidence which indicates that
15

Organic & Biomolecular Chemistry
Page 16 of 36
View Article Online
the DCU moiety of the M1-M3 plays a significant role in their ion sensing. This might be due
DOI: 10.1039/C9OB00014C
to the role of DCU moiety in modulating the molecular orbitals in a specific manner that leads
to fluorescence response in the ion detection.
Self-Assembly mechanism and the anion sensing
Figure S20 summarizes the mechanism of self-assembly of M1-M3. From all the studies above
it can be concluded that - stacking of the Fmoc moieties and the hydrophobic effect are the
two most important forces driving the self-assembly of M1-M3. Hydrogen bonding seems
trivial in this process.
Involvement of the urea NH (N-Ha) in intra molecular hydrogen bond, forming the six
membered ring is supported by the NMR experiments and DFT studies (Figure 4b and 10a).
The backbone N-Hb of Phg is non-hydrogen bonded (Figure 4b) and remains so in the
hydrophobic pockets even at concentrations greater than MGC indicating that intermolecular
hydrogen bonds are not the driving forces for the self-assembly process. In the self-assembled
state, adjacent molecules come close and the Fmoc groups are stacked together at 180 degrees
to each other. This is supported by the PXRD data where the interplaner distance of about 4.07
 0.1 Å is obtained which is the ideal distance for aromatic stacking. However stacking of the
Fmoc moieties most probably occurs by approach of adjacent molecules from opposite sides
(Figure S18).This happens firstly as the C terminal end of the amino acid residue contains
dicyclohexyl urea moieties which impart non-planarity to the molecules, preventing adjacent
molecules to approach as close as 4Å from the same side. Secondly, side chains of Phe and
Phg contain bulky Ph groups, in a plane which is almost perpendicular to that of the Fmoc
moieties. This also prevents same side approach of molecules (Figure 9a). In an alternate
possibility, the adjacent molecules may approach each other orthogonally or at different other
angles, for Fmoc stacking. These different modes of assembly may account for the different
gel state morphology obtained for M1-M3 starting from aggregated-like to fibre-like to
16

Page 17 of 36
Organic & Biomolecular Chemistry
flattened nano-tapes (Figure 2a-c). In M3, amino acid Gaba does not contain anyDsOiId: 1e0.1c0h3V9ai/eiCwn9AsOr,tBic0le0O0n1l4inCe
which leads to better stacking of the molecules than in M1 and M2. This is supported by the
presence of excimer peaks only in the fluorescence spectra of M3 (Figure 3c).
Among the different anions screened, only F-, OAc- and OH- are specifically sensed, as these
are the strongest bases among all and hence have the greatest tendency to bind the acidic N-
Hb of M1-M3. As the NH of urea (N-Ha) is intramolecularly hydrogen bonded, the only NH
available for the anion complexation is the N-Hb from the amino acid. Upon complexation with
the anion, the backbone of the molecule gets distorted as seen from the DFT studies. This in
turn prevents the approach of the molecules close enough to let -- aromatic stacking possible
and thus prevents gelation process. This explains the inability of M1-M3 to form gels in the
presence of anions. Once the gelation occurs, the non-hydrogen bonded N-Hb that complexes
with the anions is housed deep in the hydrophobic pocket. This pocket is flanked by the Fmoc
stacking on one side and the non-planer DCU moiety on the other. Moreover, fluoride and
other anions being highly charged does not prefer to enter into the hydrophobic pocket to access
the non- hydrogen bonded NH. This explains why the anions have no effect on the organogels.
Experimental Section:
Materials and methods:
L-Phe, L-Phg, Gaba , N, N – dicyclohexyl urea and all other organic solvents used in gelation
were purchased from Spectrochem. Fmoc-OSu was purchased from G. L. Biochem Ltd.
Amino acid based DCU derivatives were synthesized by solution phase methodology. The N-
termini of the amino acids were protected by Fmoc group using Fmoc-OSu while the C-termini
were protected by dicyclohexylcarbodimide (DCC). All the compounds were purified using
column chromatography using silica gel (100-200 mesh size) as stationary phase and hexane
1
and ethyl acetate as eluent. Finally, compounds were characterized by analytical HPLC, H
NMR (400MHz), and mass spectrometry.
17

Organic & Biomolecular Chemistry
Page 18 of 36
View Article Online
DOI: 10.1039/C9OB00014C
General procedure for synthesis:
Synthesis of Fmoc-protected amino acids: The amino acid (5mmol, 1eq) (L-Phe, L-Phg and
Gaba ) was dissolved in water and sodium bicarbonate (10 mmol, 2 eq) was added with stirring.
The resulting solution was cooled to 5C and Fmoc-OSu (7.5 mmol, 1.5 eq) was added slowly
as a solution in 1, 4-dioxane (also cooled). The resulting mixture was stirred at 0 °C for 1 hour
and allowed to warm to room temperature overnight. Dioxane was evaporated and water was
added to the residue. The aqueous layer was extracted three times with ethyl acetate. The
aqueous layer was then acidified to pH 1 with 10% HCl and extracted three times with ethyl
acetate. The combined organic layers were dried over sodium sulphate and concentrated in
vacuo to obtain the product (Fmoc-AA-OH) which was then purified by column
chromatography using hexane and ethyl acetate as the eluent.
Yield: Fmoc-Gaba-OH, 4.32 mmol, 86.4%; Fmoc- Phe-OH, 3.98 mmol , 79.6% and Fmoc-
Phg-OH, 4.10 mmol, 82% .
Synthesis of Fmoc-AA-dicyclohexylurea carbamate: To a solution of Fmoc-AA-OH, (1 eq) in
DCM (15 ml), DCC, 2 eq. was added and the mixture was stirred for 48 h at room temperature.
50 ml of ethyl acetate was added to the reaction mixture and dicyclohexylurea (DCU) was
filtered off. The organic layer was washed three times with 1 M sodium carbonate (50 ml) and
two times with brine (50 ml), dried over anhydrous sodium sulfate and evaporated in vacuo
followed by purification using column chromatography to obtain a solid product.
Yield: M1: 2.10 mmol, 52.7 %; M2, 2.97 mmol, 72.5% and M3: 2.75 mmol, 63.6%.
M1-M4 were characterized using analytical HPLC (Figure S21-S24), ESI-HRMS (Figure S25-
S28), 1H NMR (S29-S32) and 13C NMR (S33-S36).
M1(Figure S29): 1H NMR (400 MHz, CDCl3) δ 7.73 (d, 2H, aromatic ring Hs), 7.50 (dt, 2H,
aromatic ring Hs), 7.39 – 7.24 (m, 7H, aromatic ring Hs), 7.19 – 7.14 (m, 2H, aromatic ring
Hs), 5.37 (d,1H, NH-CH), 4.68 (m, 1H, NH-CH,cyclohexyl), 4.27(d, 2H, -CH2-CH- of Fmoc-
18

Page 19 of 36
Organic & Biomolecular Chemistry
), 4.18– 4.02 (m, 2H, -CH2-CH- of Fmoc and –CH-, alpha H of Phe),), 3.67– 3.54(m,Vi1ewHAr,ticle Online
DOI: 10.1039/C9OB00014C
cyclohexyl CH-NH), 3.11-2.82(ddd, 2H, CH2, beta H of Phe), 1.93-1.02 (m, 21H, cyclohexyl
Hs).
M1(Figure S33): 13C NMR (101 MHz, CDCl3) δ 156.42, 152.85, 143.77, 143.61, 141.27,
136.03, 129.25, 128.76, 127.74, 127.24, 127.09, 127.05, 125.14, 120.00, 77.34, 77.03, 76.71,
67.36, 54.85, 47.01, 39.11, 32.51, 31.94, 31.32, 29.72, 26.00, 25.93, 25.37, 25.30, 24.71, 0.00.
M2 (Figure S30): 1H NMR (400 MHz, CDCl3) δ 7.72(d, 2H, aromatic ring Hs), 7.58 – 7.52 (m,
2H, aromatic ring Hs), 7.41-7.257.39 (m, 9H, aromatic ring Hs), , 5.88 (d, 1H, NH-CH), 5.63
(d, 1H, NH-CH,cyclohexyl ), 4.40 – 4.28 (m, 2H, -CH2-CH- of Fmoc-), 4.18(t, 1H, -CH2-CH-
of Fmoc), 4.00 (s broad, , 1H, -CH-NH, alpha H of Phg), 3.64 (dtd, 1H, cyclohexyl CH-NH),
2.00-1.04 (m, 21H, cyclohexyl Hs).
13
M2 (Figure S34): C NMR (101 MHz, CDCl3) δ 156.11, 153.08, 143.87, 143.60, 141.29,
129.17, 128.86, 127.75, 127.59, 127.09, 125.18, 125.10, 120.00, 77.34, 77.02, 76.70, 67.41,
57.75, 50.21, 47.08, 32.55, 32.25, 31.18, 29.59, 26.04, 25.43, 25.24, 24.68, 0.00.
M3(Figure S31): 1H NMR (600 MHz, CDCl3) δ 7.77 (d, 2H, aromatic ring Hs of Fmoc-), 7.59
(d, 2H, aromatic ring Hs of Fmoc-), 7.40 (t, 2H, aromatic ring Hs of Fmoc-), 7.32 (td, 2H,
aromatic ring Hs of Fmoc-), 5.16 (s, 1H, NH-CH2), 4.33 (d, 2H, -CH2-CH- of Fmoc-), 4.20 (t,
1H, -CH2-CH- of Fmoc), 3.96 (s, 1H, NH-CH, cyclohexyl), 3.72 – 3.63 (m, 1H, cyclohexyl
CH-NH), 3.28 (m, 2H, -CH2-CH2-CH2-CO), 3.15 (m, 2H, -CH2-CH2-CO), 2.48 (t, 2H, -CH2-
CH2-CO), 1.96-1.05 (m, 21H, cyclohexyl Hs);
M3 (Figure S35): 13C NMR (101 MHz, CDCl3) δ 143.93, 141.31, 127.73, 127.09, 125.10,
119.99, 77.33, 77.02, 76.70, 32.64, 30.95, 26.08, 25.51, 24.71, -0.00.
M4(Figure S32): 1H NMR (400 MHz, CDCl3) δ 1.42 {s, 9H, -(CH3)2 of Boc group}, 6.86 (s,
1H, NH-CH), 4.72(s, 1H, NH-CH,cyclohexyl), 3.93 (m, 2H, -CH2-CH2-CH2-CO), 3.71 – 3.64
19

Organic & Biomolecular Chemistry
Page 20 of 36
(m, 1H, cyclohexyl CH-NH), 3.17 (m, 2H, -CH2-CH2-CO), 2.44 (t, 2H, -CH2-CH2-CO),V2ie.w0A0rticle Online
DOI: 10.1039/C9OB00014C
– 1.04 (m, 21H, cyclohexyl Hs)
M4 (Figure S36): 13C NMR (101 MHz, CDCl3) δ 156.21, 154.08, 77.33, 77.01, 76.69, 49.95,
32.84, 32.68, 30.91, 28.43, 26.23, 25.61, 25.47, 25.35, 24.74, -0.01.
Gelation experiments:
To check the ability of the gelator molecules to form gel in different solvents, weighed amount
of the synthesized compounds (M1-M3) were taken in vials and 500 µL of different solvents
were added to them. Samples were heated in a heating block at temperatures ranging from 60
°C- 100 °C and subsequently cooled to room temperature. Gel was formed within 15 minutes
which was stable to inversion of the glass vials.
Determination of the gel-to-sol transition temperature:
The gel-to-sol transition temperature (Tgel) was determined by placing the gel containing vial
in an oil bath and slowly raising the temperature of the bath at the rate of 1C per minute. The
temperature was monitored using a thermometer. The (Tgel) was defined as the temperature at
which the gel melted and started to flow.
Rheology:
The viscoelastic properties of organogels were determined by rheology studies using Anton
Paar MCR102 Rheometer equipped with a 20 mm parallel-plate measuring system at 25 C at
a concentration of 2.0 w/v% in 1, 2 DCB. A strain sweep test was performed over a range from
0.1-10% strain at a fixed oscillatory frequency of 1 rad/s. Furthermore the mechanical strength
of the organogels were determined from the oscillatory test, ie. frequency sweep, which was
carried out under an appropriate strain of 0.1% with the frequency ranging from 1-100.
Rheological experiments measure two parameters; storage modulus (Gʹ) and loss modulus
20

Page 21 of 36
Organic & Biomolecular Chemistry
View Article Online
(Gʹʹ). A defining measure of gelation process is having a higher value of Gʹ than Gʹʹ which are
DOI: 10.1039/C9OB00014C
essentially independent of frequency.
FESEM :
FESEM images of the reported materials M1-M3 were obtained on a FESEM Sigma Zeiss
Gemini microscope. A drop of the solution of the gelator molecules in 1,2-DCB was casted on
a silicon wafer and was allowed to dry for a few hours under vacuum before imaging. For the
morphology of the organogel, it was casted on the silicon wafer and allowed to dry under
vacuum before imaging.
Fluorescence spectroscopy:
To gain an insight into the self-assembly behavior of M1-M3, fluorescence experiments were
performed by monitoring the fluorescence of the Fmoc moiety on a Fluoromax-4
spectrophotometer. Samples of different concentrations were prepared in 1,2-DCB and their
fluorescence emission was monitored keeping the fluorescence excitation wavelength fixed at
301 nm.
FTIR :
FT-IR spectroscopy measurements were recorded on a Spectrum Two Perkin Elmer FT-IR
Instrument using KBr pellets. Measurements were performed on powdered samples and on
the xerogel obtained for M1-M3 and the two were compared with each other.
NMR experiments:
1
NMR experiments were performed on a 400 MHz Bruker NMR spectrometer. H NMR
experiments were performed for routine characterization of the molecule. Concentration
1
dependent H NMR (0.25 mM, 0.5 mM, 1 mM, 2 mM, 3.44 mM (MGC) and 5 mM) was
recorded for the molecule M2 in CDCl3 at ambient temperature. DMSO titration was performed
at 5mM concentration of M2 and 0.5% to 15% DMSO concentrations in CDCl3 at ambient
temperature. 1H NMR experiments were conducted at different concentrations of fluoride ions
21

Organic & Biomolecular Chemistry
Page 22 of 36
View Article Online
to understand the mode of interaction between the molecules and fluoride ions DfoOrI: 1i0t.s103a9n/Cio9OnB00014C
sensing functions.
PXRD:
Wide angle X-ray diffraction analysis was done on a Bruker D2 Phaser X Ray diffractometer
(Cu-Kα radiation, χ=1.5406 Å) for both the powdered samples and the xerogels obtained from
drying the organogels of M1-M3 obtained from 1,2 DCB.
Dye absorption studies
2 mg of the gelator molecule was dissolved in 500 µL of 1,2 DCB. Into it the aqueous solution
of dye (500 µL) was added and the mixture was heated at 100 C for 10 minutes. Upon cooling
the mixture, the bottom layer i.e. the organic solvent 1, 2-DCB with the gelator formed the gel
while the aqueous phase formed a supernatant over the gel. This was allowed to stand for 24
hours at RT, after which the amount of unabsorbed dye in the supernatant was checked by
monitoring the UV of the supernatant aqueous solution and calculating the concentration from
a standard curve of the dye. The amount of dye loaded in the gel and the dye loading efficiency
were then calculated as follows:
Dye loaded = (Initial dye-Unabsorbed dye)
Loading efficiency: Dye loaded/Initial dye X 100
Recycling of the gel in dye absorption/release:
CV dye loading was in each cycle was calculated as described above. To the dye loaded gel,
500 µL of diethyl ether was added as the release medium. Diethyl ether layer was then taken
out after 1 hr and kept in a vial (V1), 500 µL of fresh ether was added to the gel for release
which was subsequently taken out after 3 hrs (V2). This was repeated for another three times
at time gaps of 6, 10 and 16 hours (V3, V4 and V5 respectively). Each time the diethyl ether
where the dye was released was taken out and kept in vials (V1-V5) for evaporation. After
22

Page 23 of 36
Organic & Biomolecular Chemistry
complete evaporation of ether, 500 µL of water was added to V1 and its absorbanceViwewaAsrticle Online
DOI: 10.1039/C9OB00014C
monitored. Then the contents of V1 were added to V2 for monitoring the UV. In this way the
contents of each vial was added to the next one for UV monitoring at time intervals of 1,3, 6,10
and 16 hours. From the UV data, amount of dye released at these different time points could
be easily calculated using a standard curve for the dye. Percentage of the amount of dye
released in cycle 1 was calculated with respect to the dye loaded.
Dye release efficiency was calculated as follows:
Release Efficiency: Dye released in a cycle/ Dye loaded in the cycle X 100
For the second cycle, 500 µL, 40µM dye solution was added to the gel again for dye loading
studies. The rest of the experiment was done as already described above. Amount of dye loaded
and released in each cycle was calculated. The gel could be reused effectively for three cycles
after which the quality of the gel degraded.
Anion sensing:
A stock solution of 1 mM of the gelator molecules in ACN was prepared. Stock solutions of
-
10 mM tetrabutylammonium salts of F-, Cl-, Br-, I-, H2PO4, OH-, ACO- and HSO4 were
prepared in ACN. Then a solution of 0.2 mM of the gelator molecules were prepared from the
stock solution. Also, 0.2 mM of all the anion solutions were prepared from the 10 mM stock
solution. For monitoring UV and fluorescence spectra 500 µL of 0.2 mM of the gelator solution
was taken and into it 500 µL of 0.2 mM anion solution was added so that the final concentration
of the gelator and the anion solution became 0.1 mM. The UV and fluorescence was monitored
for all the anions with the three gelators. Anion sensing was studied with Fmoc-Phe-OH as
control. For monitoring UV and fluorescence spectra 500 µL of 0.2 mM of the solution of
Fmoc-Phe-OH was taken and into it 500 µL of 0.2 mM anion solution was added so that the
final concentration of the molecule and the anion in solution became 0.1mM.
23

Organic & Biomolecular Chemistry
Page 24 of 36
View Article Online
DOI: 10.1039/C9OB00014C
Titration of the gelator molecules with specific anions:
500 µL of 0.2 mM of gelator solution in ACN was taken in different 1 ml volumetric flasks
and into it 500 µL of different concentration of the anion solution were added so that the final
concentration of the gelator solution becomes 0.1 mM. The UV and the fluorescence of these
solutions were then monitored as described above. UV was monitored using a wavelength scan
for 200-700 nm. The fluorescence emission was monitored for excitation wavelength of 301
nm.
Computational Details
DFT/TDDFT calculations were performed by the Gaussian 09 program package58 using 6-
31+G* basis set. Geometry optimizations of dicyclohexyl urea derivative (M2) in its free and
anion bound state was performed without symmetry constraints. Normal mode analysis has
been performed for ensuring true local minimum geometry. Polarizable continuum model
(PCM)59 with ACN as solvent was used to include the solvent effects in all the calculations. A
dielectric constant (ε) of 36.64 ACN was used for including solvent effect. Gas-phase
optimized geometries were subjected to further optimization in ACN solvent. Based on
optimized geometries of the ground states, the absorption spectra of free M2, and its complexes
M2:X- (X@F, Cl, Br, I, AcO, OH) were calculated by the TDDFT methods, at the same level
of theory. Several possible geometries of free M2 and anion bound M2:X- was studied.
Conclusions:
In our present study we have reported a new class of LMWG. Dicyclohexyl urea derivatives
of amino acids are extremely simple molecules that easily form organogels in a large range of
organic solvents. The mechanism of gelation has been analyzed in detail and it has been proved
that molecular self-assembly is driven by - interaction in between the Fmoc moieties and
24

Page 25 of 36
Organic & Biomolecular Chemistry
hydrophobic effect. The reported organogels are capable of absorbing different organic VdieyweAsrticle Online
DOI: 10.1039/C9OB00014C
highly efficiently and are recyclable in nature. M1-M3 can act as selective anion sensors for
fluoride, hydroxide and acetate. The mechanism of fluoride sensing has been clearly
understood and the mode of fluoride binding established both by experimental and
computational methods. We may conclude by saying that this new class of amino acid
derivatives of urea forms easily synthesizable and cost effective materials which can have
multiple applications like water purification by removal of toxic dyes effectively and as anion
sensors for selective anions like fluoride, acetate and hydroxide.
Author contributions:
SC designed the project, KR performed most of the experiments, MC performed PXRD, FTIR
and dye absorption experiments, SG did the electronic structure calculations. SC and PS
analyzed the data and wrote the paper.
Acknowledgements:
SC would like to acknowledge Department of Science and Technology, India (Fast Track
Project No: SB/FT/CS-070/2014) for the financial support required for this research. KR, MC
and SG acknowledge IIT Guwahati for Scholarship, and Central Instruments Facility, IITG for
the FESEM instrument facility. SC acknowledges Nilotpal Singha for performing the
Rheology experiment and Dr. D. Das for insightful discussions. Computing facility by
Biomolecular Simulation Lab (BSL, BSBE department, IIT Guwahati) and BIF, IIT Guwahati,
Central Instrument facility IIT Guwahati is gratefully acknowledged.
References:
1. P. Terech and R. G. Weiss, Chem. Rev., 1997, 97, 3133.
2. E. R. Draper and D. J. Adams, Chem , 2017, 3, 390.
25

Organic & Biomolecular Chemistry
Page 26 of 36
View Article Online
DOI: 10.1039/C9OB00014C
3. N. M. Sangeetha and U. Maitra, Chem. Soc. Rev., 2005, 34, 821.
4. P. Anilkumar and M. Jayakannan, J. Phys. Chem. B, 2010, 114, 728.
5. A. Ajayaghosh and V. K. Praveen, Acc. Chem. Res., 2007, 40, 644.
6. A. Shumburo and M. C. Biewer, Chem. Mater., 2002, 14, 3745.
7. S. Bhattacharya and S. K. Samanta, Chem.Rev., 2016, 116, 11967.
8. W. Kubo, T. Kitamura, K. Hanabusa, Y. Wada and S. Yanagida, Chem. Commun.,
2002, 374.
9. E. A. Wilder, K. S. Wilson, J. B. Quinn, D. Skrtic and J. M. Antonucci, Chem. Mater.,
2005,17, 2946.
10. C. L. Esposito, P. Kirilov and V. G. Roullin, J. Control Release, 2018, 271, 1.
11. W. Liyanage, K. Vats, A. Rajbhandary, D. S. W. Benoit and B. L. Nilsson, Chem.
Commun., 2015, 51, 11260
12. L. Szkolar, J.-B. Guilbaud, A. F. Miller, J. E. Gough and A. Saiani, J. Pept. Sci., 2014,
20, 578.
13. K. Basu, N. Nandi, B. Mondal, A. Dehsorkhi, I. W. Hamley and A. Bannerjee,
Interface Focus, 2017,7,1
14. M. Konda, I. Maity, D. B. Rasaleand A. K. Das, ChemPlusChem, 2014, 79, 1482.
15. X. Zhang, J. Song, W. Ji, N. Xu, N. Gao, X. Zhang and H. Yu, J. Mater. Chem. A,
2015,3, 18953.
16. S. Basak, J. Nanda and A. Banerjee, J. Mater. Chem., 2012, 22, 11658.
17. B. O. Okesola and D. K. Smith, Chem. Soc. Rev., 2016, 45, 4226.
18. S. Panja, S. Bhattacharya and K. Ghosh, Langmuir, 2017, 33, 8277.
19. S. Marullo, C. Rizzo, N. T. Dintcheva, F. Gianicci, F. D’ Anna, J. Coll. Interface Sci., 2018,
517, 182.
20. N. Cheng, Q. Hu, Y. Guo, Y. Wang, L. Yu, ACS Appl. Mater. Interfaces, 2015, 7, 10258.
26

Page 27 of 36
Organic & Biomolecular Chemistry
View Article Online
21. C. Rizzo, S. Marullo, P. R. Campodonico, I. Pibiri N. T. Dintcheva, R. Noto, D. Millan, F.
DOI: 10.1039/C9OB00014C
D’Anna ACS Sustainable Chem. Eng. 2018, 6, 12453.
22. C. Rizzo, R. Arrigo, N. T. Dintcheva, G. Gallo, F. Gianicci, R. Noto, A. Sutera, p. Vitale,
F. D’Anna, Chem. Eur. J., 2017, 23, 16297.
23. B. Adhikari, J. Nanda and A. Banerjee, Chem.Eur. J., 2011, 17, 11488.
24. C. Giansante, G. Raffy, C. Schafer, H. Rahma, M.-T. Kao, A. G. L. Olive and A. D.
Guerzo, J. Am. Chem. Soc., 2011, 133, 316.
25. N. Mohmeyer and H. W. Schmidt, Chem. Eur. J., 2005, 11, 863
26. M. Suzuki, T. Nigawara, M. Yumoto, M. Kimura, H. Shirai and K. Hanabusa, Org.
Biomol. Chem., 2003, 1, 4124.
27. M. Suzuki, Y. Nakajima, M. Yumoto, M. Kimura, H. Shirai and K. Hanabusa, Org.
Biomol. Chem. 2004, 2, 1155.
28. G. Wang and A. D. Hamilton, Angew. Chem. Int. Ed., 2000, 112, 2263.
29. M. Suzuki, Y. Sakakibara, S. Kobayashi, M. Kimura, H. Shirai and K. Hanabusa,
Polym. J., 2002, 34, 474.
30. F. Placin, J.-P. Desvergne and J.-C. Lassegues, Chem. Mater., 2001, 13, 117.
31. N. Basu, A. Chakraborty and R. Ghosh, Gels, 2018, 52, 1.
32. S. S. Babu, V.K.Praveen and A. Ajayghosh, Chem. Rev., 2014, 114, 2129.
33. B. Gioia, N. B. Ghalia and P. Kirilov, Journal of Pharmacy and Pharmaceutical
Science, 2018, 7, 1.
34. S. Samai, J. Dey and K. Biradha, Soft Matter, 2011, 7, 2121.
35. I.A. Coates, A.R. Hirst and D. K. Smith, J. Org. Chem., 2007, 72, 3937.
36. V. Singh, K. Snigdha, C. Singh, N, Sinhad and A. K. Thakur,Soft Matter, 2015, 11,
5353.
37. N. D. Lourenco, J. M. Novais, and H. M. Pinheiro, J. Biotechnol., 2001, 89, 163.
27

Organic & Biomolecular Chemistry
Page 28 of 36
View Article Online
38. A.H. Gemeay, I.A.Mansour, R.G.El-Sharkawy and A.B. Zaki, J. MoDl.OI:C10a.1t0a3l9./CA9O:B00014C
Chemical, 2003, 193, 109.
39. N. Daneshvar, H. Ashassi-Sorkhabi and A.Tizpar, Separ. Purif. Technol., 2003, 31,
153.
40. E. Rindle and W. J Troll, Journal of National Cancer Institute, 1975, 55, 181.
41. F.I. Hai, K.Yamamoto and K.Fukushi, Critical Reviews in Environmental Science and
Technology, 2007, 37, 315.
42. K L Kirk, Biochemistry of the Elemental Halogens and Inorganic Halides, 1st ed.,
Plenum Press, New York NY USA, 1991.
43. S. W. Zhang and T. M. Swager, J. Am. Chem. Soc., 2003, 125, 3420.
44. S. Kubik, Chem. Soc. Rev., 2010, 39, 3648.
45. P. A. Gale and C. Caltagirone, Chem. Soc. Rev., 2015, 44, 4212.
46. A. P. De Silva, H. Q. N. Gunaratne, T. Gunnlaugsson, A. J. M. Huxley, C. P. McCoy,
J. T. Rademacher and T. E. Rice, Chem. Rev., 1997, 97, 1515.
47. V. B. Bregovic, N. Basaric and K. Mlinaric-Majerski, Coord. Chem. Rev., 2015, 295,
9321.
48. J. Schiller, R. Pérez-Ruiz, D. Sampedro, E. Marqués-López, R. P. Herrera and D. Díaz
Díaz , Sensors, 2016, 16, 1.
49. T. Ghosh and B. G. Maiya, J. Phys. Chem. A, 2004, 108, 11249.
50. J. Y. Lee, E. J. Cho, S. Mukamel and K. C. Nam, J. Org. Chem., 2004, 69, 943.
51. J. Lee, J. E. Kwon, Y. You and S. Y. Park, Langmuir, 2014, 30, 2842.
52. P. Rajamalli and E. Prasad, Org. Lett., 2011, 13, 3714.
53. B. Bai and X. Mao, Sens. Actuators B, 2015, 211, 268.
54. P. Xue, J. Sun, Q. Xu, R. Lu, M. Takafuji and H. Ihara, Org. Biomol. Chem. 2013, 11,
1840.
28

Page 29 of 36
Organic & Biomolecular Chemistry
View Article Online
55. T. H. Kim, M. S. Choi, B. H. Sohn, S. Y. Park, W. S. Lyoo and T. S. Lee, DCOhI:e10m.10C39o/Cm9O.,B00014C
2008, 2364.
56. C Baudez, R K Gupta, N Eshtiaghi, R Parthasarathy, P Slatter, Chemeca 2011:
Engineering a Better World, NSW Australia, 2011.
57. M. Suzuki, M. Yumoto, M. Kimura, H. Shirai and K. Hanabusa, Chem. Eur. J., 2003,
9, 348.
58. M. J. Frisch et. al. Gaussian 09, Revision C.01; Gaussian, Inc.: Wallingford, CT, 2010.
59. J. Tomasi, B. Mennucci and R. Cammi, Chem. Rev., 2005, 105, 2999.
29
