In vitro neuroprotective and anti-inflammatory activities of natural and semi-synthetic spirosteroid analogues

Article abstract of DOI:10.3390/molecules21080992

Two spirosteroid analogues were synthesized and evaluated for their in vitro neuroprotective activities in PC12 cells, against glutamate-induced excitotoxicity and mitochondrial damage in glucose deprivation conditions, as well as their anti-inflammatory potential in LPS/IFNγ-stimulated microglia primary cultures. We also evaluated the in vitro anti-excitotoxic and anti-inflammatory activities of natural and endogenous steroids. Our results show that the plant-derived steroid solasodine decreased PC12 glutamate-induced excitotoxicity, but not the cell death induced by mitochondrial damage and glucose deprivation. Among the two synthetic spirosteroid analogues, only the (25R)-5α-spirostan-3,6-one (S15) protected PC12 against ischemia-related in vitro models and inhibited NO production, as well as the release of IL-1β by stimulated primary microglia. These findings provide further insights into the role of specific modifications of the A and B rings of sapogenins for their neuroprotective potential.

Full text of DOI:10.3390/molecules21080992

molecules
Article
In Vitro Neuroprotective and Anti-Inflammatory
Activities of Natural and Semi-Synthetic
Spirosteroid Analogues
Laura García-Pupo 1, Armando Zaldo-Castro 2, Vassiliki Exarchou 3,
Juan Enrique Tacoronte-Morales 2,†, Luc Pieters 3, Wim Vanden Berghe 4,
Yanier Nuñez-Figueredo 1 and René Delgado-Hernández 5,
*
1
Centro de Investigación y Desarrollo de Medicamentos (CIDEM), Ave 26,
No. 1605 Boyeros y Puentes Grandes, CP 10600 La Habana, Cuba;
laura.garcia@cidem.cu (L.G.-P.); yanier.nunez@cidem.cu (Y.N.F.)
2
3
4
5
Centro de Estudios de Productos Naturales, Facultad de Química, Universidad de la Habana,
Zapata s/n entre G y Carlitos Aguirre, Vedado, Plaza de la Revolución, CP 10400 La Habana, Cuba;
zaldo@fq.uh.cu (A.Z.-C.); jetacoronte@yahoo.com (J.E.T.-M.)
Natural Products & Food Research & Analysis (NatuRA), Department of Pharmaceutical Sciences,
University of Antwerp, Universiteitsplein 1, PC 2610 Antwerp, Belgium;
vasiliki.exarchou@uantwerpen.be (V.E.); luc.pieters@uantwerpen.be (L.P.)
Protein Chemistry, Proteomics and Epigenetic Signaling (PPES), Department of Biomedical Sciences,
University of Antwerp, Universiteitsplein 1, PC 2610 Antwerp, Belgium;
wim.vandenberghe@uantwerpen.be
Centro de Estudios Investigaciones y Evaluaciones Biológicas (CEIEB), Instituto de Farmacia y Alimentos (IFAL),
Universidad de la Habana, Calle 222 #2317/23 y 31 La Coronela, La Lisa, CP 13600 La Habana, Cuba
Correspondence: rdelgado@infomed.sld.cu; Tel.: +53-7271-9531
*
†
Present Address: Centro de Biología, Universidad Central del Ecuador, Gato Sobral y Jerónimo Leiton,
Ciudadela Universitaria, Proyecto Prometeo-SENESCyT, CP17-10-7169 Quito, Ecuador.
Academic Editor: Derek J. McPhee
Received: 6 June 2016; Accepted: 12 July 2016; Published: 29 July 2016
Abstract: Two spirosteroid analogues were synthesized and evaluated for their in vitro
neuroprotective activities in PC12 cells, against glutamate-induced excitotoxicity and mitochondrial
damage in glucose deprivation conditions, as well as their anti-inflammatory potential in
LPS/IFNγ-stimulated microglia primary cultures. We also evaluated the in vitro anti-excitotoxic
and anti-inflammatory activities of natural and endogenous steroids. Our results show that
the plant-derived steroid solasodine decreased PC12 glutamate-induced excitotoxicity, but not
the cell death induced by mitochondrial damage and glucose deprivation. Among the two
synthetic spirosteroid analogues, only the (25R)-5
ischemia-related in vitro models and inhibited NO production, as well as the release of IL-1
α
-spirostan-3,6-one (S15) protected PC12 against
by
β
stimulated primary microglia. These findings provide further insights into the role of specific
modifications of the A and B rings of sapogenins for their neuroprotective potential.
Keywords: spirosteroids; excitotoxicity; neuroprotection; inflammatory mediators
1. Introduction
Cerebrovascular diseases, like cerebral ischemia, represent one of the first causes of mortality and
morbidity worldwide, which generate high cost by means of medical and social care [1]. Focal cerebral
ischemia occurs after the permanent or transient occlusion of a brain artery or its communicants, due to
blood thrombus or embolism, which immediately causes a decrease in blood flow and therefore
in oxygen and glucose to a defined brain region [
2,
3]. Consequently, brain tissue and neurons
Molecules 2016, 21, 992; doi:10.3390/molecules21080992
www.mdpi.com/journal/molecules

Molecules 2016, 21, 992
2 of 15
start to die because of glutamate-induced excitotoxicity signaling, ionic and oxidative imbalance,
mitochondrial damage and inflammatory response [ ]. Several in vitro models have been employed
for mimicking the ischemia conditions, especially glutamate-induced excitotoxicity, and to evaluate
therapeutic candidates [ ]. In PC12 cells, exposure to high doses of glutamate decrease their
survival [ ], and this toxic effect may occur via two different process. The classical pathway,
4,5
6,7
8,9
known as excitotoxicity, occurs through the activation of NMDA and non-NMDA glutamatergic
receptors [10] and subsequent calcium influx into the cell [11]. The oxidative glutamate toxicity
pathway is a transporter-mediated type of cell death [12], which requires the cellular expression of
the cystine/glutamate antiporter system [8]. This pathway has been described in primary neuronal
cultures, neuronal cell lines [13] and in brain tissue slices [14]. It has been extensively demonstrated
that mitochondria are involved in the control of neuronal Ca2+ homeostasis [15], neuronal Ca2+
signaling [16] and Ca2+-dependent exocytosis [17]. Mitochondrial Ca2+ overload and dysfunction,
due to excessive Ca2+ entry through over-activated glutamate receptors, is a crucial early event in the
excitotoxic cascade that follows ischemic ictus [18]. In isolated mitochondria, Ca2+ overload can evoke
sustained mtPTP (mitochondrial transient permeability transition pore) opening and cytochrome
c release. Opening of the mtPTP causes a massive swelling of mitochondria coupled with the collapse
of the mitochondrial membrane potential [18]. Despite the detailed description of mechanisms
and mediators related to the pathophysiology of cerebral ischemia and stroke, to date, almost all
neuroprotective candidates have failed in clinical trials [2,19].
Sex hormones are essential regulators of survival, differentiation, neurotransmitter synthesis and
the synaptic plasticity of neurons and glia in brain and spinal cord [20]. In the 1990s, several studies
demonstrated the neuroprotective effects of estrogens in animal models of cerebral ischemia [21].
In parallel, some estrogenic steroids, such as 17
β-estradiol (E2), showed neuroprotective properties
related to excitotoxicity antagonism by free radical scavenging and antioxidant activity [22
,
23].
The mechanisms involved in the neuroprotective effects of estrogen include intrinsic antioxidant
activities, as well as estrogen receptor (ER)-dependent genomic and fast non-genomic signaling
pathways. Almost two decades ago, the importance of E2 antioxidant activity for its neuroprotective
potential was demonstrated in cell-based in vitro models of glutamate-induced excitotoxicity and
associated with specific structural features [22,24,25]. This antioxidant potential relies on the
phenolic ring present in the structure of the estradiol molecule, which also affords the redox cycling
activity in neurons [26]. Concerning the ER-dependent pathways, it is currently being accepted
that several estrogen receptors are involved in the neuroprotective effects of estradiol and not only
ERα, as was initially thought (reviewed in [27,28]). It has been previously demonstrated that E2
prevents ischemia-induced downregulation of the pro-survival bcl-2 gene, while it attenuates c-fos
upregulation, promoting cell survival and decreasing neuronal programmed cell death. Furthermore,
E2 enhances the activation of Akt kinase, which is an important mediator of cell survival signaling
pathways [27]. On the other hand estrogens suppress neuroinflammation, which is a hallmark of many
neurodegenerative diseases, such as stroke, Parkinson’s and Alzheimer’s diseases. Physiological levels
of E2 suppress both microglial activation and iNOS upregulation, as well as several proinflammatory
cytokines, via ERα and suppression of the NFκB transcription factor [27,29]. Some other studies with
inhibitors for kinases involved in classical ER and membrane-coupled ER signaling in primary neuronal
cultures demonstrated that the activity of estrogens and some neuroprotective benzothiophene selective
estrogen receptor modulators is mediated via ER-independent and G-protein-coupled responses
through the PI3K, Src and ERK-dependent signaling pathways [30].
Furthermore, sulfated neurosteroids, like dehydroepiandrosterone sulfate and pregnenolone
sulfate, have been defined as allosteric regulators of ionotropic receptors activity [31
However clinical trials with post-menopausal women also showed an increase of cardiovascular risk,
as adverse effects in the use of estrogenic compounds [33 34]. Therefore, the design, characterization
,32].
,
and isolation or synthesis of molecular entities with neuroprotective activity is still an interesting topic
of drug research and development. Spiro compounds are widely distributed in nature as polyether
antibiotics, talaromycines, pheromones, milbemycines, avermectines and also steroidal spirostanes.

Molecules 2016, 21, 992
3 of 15
All of these compounds, having a spiroacetal moiety, show a high and diverse biological activity [35].
In addition, the neuroprotective potential of naturally-occurring sapogenins, such as solasodine,
as neuroprotective and neurogenic compounds has been described [36,37]. Owing to their peculiar
structural features, we synthesized various spirosteroids with diosgenin as the starting product,
and their synthetic sequence can be summarized in the reactions of the oxidation/dehydration of the
C3, C5 or C6 positions in the A and B rings.
The aim of the present investigation was an in vitro evaluation of the potential neuroprotective
and/or anti-inflammatory effects of a series of natural spirosteroids and their semi-synthetic analogues,
providing new insights into their potential as neuroactive molecules [6–8]. We followed a modified
Aburatani method and used Jones reagent to obtain two spirosteroids analogs, with different functional
groups at the C3 position, together with an oxygenated substituent at positions C5 and C6, in order to
test the hypothesis that modifications in those positions influences the neuroprotective potential of
the spirosteroid derivatives. We also aimed to study the in vivo estrogenic activity of the most active
spirosteroid analogue in the in vitro models, as a criterion for low potential hormonal side effects.
2. Results and Discussion
2.1. Chemistry
Several spirosteroid derivatives were prepared according to the synthetic pathway depicted in
Scheme 1. The common raw material for all of these compounds was diosgenin, a plant-derived and
commercially available compound (Phytomarker Ltd., Tianjin, China) with a purity of more than 95%
(Figure S1).
H3C
O
O
H3C
O
O
H3C
H3C
CH3
CH3
Chloroform
MCPA
6
AcO
H3C
O
O
7
AcO
O
H3C
Acetone
CrO3
CH3
H3C
H3C
O
O
O
Pyridine
H3C
H3
C
Ac2O
O
(Z)
HO
CH3
CH3
1
Methanol
NaHCO3
S9
AcO
HO
OH
OH
H3C
8
O
O
O
O
H3C
Acetone
CH3
Jones reagent
H2SO4
S15
O
OH
O
Scheme 1. Synthetic route of sapogenin derivatives. MCPA, meta-chloro-perbenzoic acid.
(25R)-5-Spirost-3 -ol-3-acetate, (25R)-5,6-Epoxy-spirost-3 -ol-3-acetate, (25R)-Spirost-3
1
,5
Diosgenin,
6
β
7
β
8
β
α-dihydroxy-
6-one-3-acetate, S9 (25R)-Spirost-3β,5α-dihydroxy-6-one, S15 (25R)-Spirost-5α-hydroxy-3,6-dione.
Considering previous evidence about the critical role of oxygenated functional groups at position
C3 in the A ring of steroids [38], we then move onto synthesized 3-oxo derivatives of diosgenin.
Treatment of diosgenin
yield. Subsequently, the reaction of diosgenin acetate
temperature, after several washes with sodium sulfate and carbonate salts, generated a mixture
of the 5,6-epoxy Compound with an 85% total yield. Aqueous CrO3 oxidative opening of
this mixture, without previous separation and dissolved in warm acetone, produced Compound
after re-crystallization from methanol, with an 80% yield, which is similar to previous results in the
1
with acetic anhydride in pyridine produced diosgenin acetate
6 with a 95%
6
with meta-chloroperbenzoic acid at room
α
/β
7
8,

Molecules 2016, 21, 992
4 of 15
literature [39]. Hydrolysis of
8
under basic conditions with refluxing NaHCO3 yielded the diol S9
with a 95% total yield. After normalization of the peak area detected by HPLC-DAD, the purity of
Compound S9 was determined to be more than 97% (Figure S2). On the other hand, 5-ol-diketone S15
was synthesized by oxidation of the secondary alcohol in position C3 of Compound S9, with Jones
reagent in the presence of sulfuric acid, which also caused the dehydration of S9 at the most reactive
tertiary alcohol in the C5 position. Therefore, we also obtained the minor product 4-en-3,6-dione, with
the double bond stabilized by the resonance with the carbonyl groups at the C3 and C6 positions.
Purification by column chromatography gave pure Compound S15 with an 81.5% yield and 90% purity
according to HPLC-DAD (Figure S3).
The structures of Compounds S9 and S15 were identified by spectroscopic analysis, including
1H-NMR spectra and distortionless enhancement by polarization transfer (DEPT)13C-NMR spectra.
In order to identify previous published information, concerning the chemical structures of the obtained
compounds, an extensive search was done in the SciFinder database [40]. The previously-reported
carbon NMR data for Compounds S9 [41] and S15 [42] are in concordance with the carbon
spectroscopic data we obtained (Figures S4 and S5).
2.2. Biological Activity
2.2.1. Treatments to PC12 Cell Cultures
It has been reported that 17β-estradiol and other estrogenic steroids are associated with
neuroprotective mechanisms in cerebral ischemia models [
6
,38,43]. Therefore, we studied the effects
of some naturally-occurring steroids, as well as the synthetic spirosteroid analogs, in two in vitro
models related to cerebral ischemia, by the MTT colorimetric assay [44]. The results are shown in
Figures 1 and 2.
As indicated in Figure 1, the treatment of PC12 cells with 20 mM of L-glutamate for 24 h caused
a reduction of cellular viability with respect to untreated cells (Figure 1A). PC12 is a cell line derived
from rat adrenal medulla pheochromocytoma, which synthesize glutamate and catecholamines and
can be differentiated by nerve growth factor (NGF) to a sympathetic phenotype expressing neurites and
excitability [45]. Glutamate exerts its toxic effects on differentiated and undifferentiated PC12 cells in
a dose- and time-dependent manner, through two proposed main mechanism involving excitotoxicity
and oxidative stress [46]. Although mRNA for NMDA receptor subunits are expressed by PC12 cells,
the protein expression and functionally of this receptor are still under debate [46]. However, it is
clear that PC12 cells express functional excitatory metabotropic glutamate receptor type I (mGluR1
and 5) [47], which could contribute to the glutamate-induced excitotoxicity. On the other hand,
high extracellular concentrations of glutamate induce in PC12 cells an NMDA receptor-independent
cytotoxicity caused by the inhibition of CySS uptake, which leads to GSH depletion and ultimately to
the oxidative glutamate toxicity [46]. With respect to the natural steroids tested in our experiments,
the treatment of glutamate-damaged PC12 cells with E3 (estriol), SL (solasodine) and T (testosterone)
significantly induced the recovery of cellular viability (Figure 1A), while other endogenous steroids,
E1 (estrone) and TDCA (taurodeoxycholic acid), did not show any effect in this model (Figure 1A).
The observed anti-excitotoxic activity of E3 is in accordance with previous observations related to
the neuroprotective properties of this estrogenic compound [48]. The potent antioxidant activity
of estrogens has been related to the presence of a hydroxyl group in position 3 of the A ring and
is also described as one of the main mechanism for its neuroprotective effects [22,49]. Taking into
account the remarkable structural similarities and antioxidant capacity between estriol and estrone,
we would expect a comparable anti-excitotoxic activity; however, our results show a lack of significant
anti-excitotoxic activity of E1 (Figure 1A). The neuroprotective and anti-ischemic activity of T is less
convincingly demonstrated, since some reports demonstrate neuroprotection induced by this sex
hormone, while other studies revealed detrimental effects [50,51]. One possible explanation may
involve the conversion of T to estrogen by aromatases and, therefore, the activation of neuroprotective
estrogen-related signals [52]. The treatment of our glutamate-damaged PC12 cells with T significantly

Molecules 2016, 21, 992
5 of 15
improves the viability of the cells (Figure 1A), which could be related to aromatase conversion in
PC12 cells.
Despite the great amount of evidence showing the neuroprotective activity of endogenous steroids,
the adverse effects of their uses in clinical trials has stimulated the research for new synthetic or natural
therapeutic candidates [38,53]. In this sense, solasodine (SL) has shown neurogenic potential in PC12
cells [37], as well as in vivo anti-convulsive activity [36]. In our PC12 glutamate-induced excitotoxicity
model, the treatment with SL significantly improved the cellular viability (Figure 1A). Furthermore,
when glutamate-damaged PC12 cells were co-treated with the synthetic spirosteroid analog S15
,
the cellular viability was significantly increased with an EC50 of 10.97 M (Figure 1A,B). In contrast,
µ
spirosteroid derivative S9 did not significantly affect the glutamate-induced cell death (Figure 1A).
These results suggest the importance and specificity of the substituent in position 3 in order to obtain
the in vitro anti-glutamatergic activity (Figures 1 and 2). Moreover, the carbonyl group at position 3
appears to be critical for this cellular activity, in combination with the hydroxyl and carbonyl groups
at positions 5 and 6, respectively (Figures 1 and 2).
A
B
150
EC50 = 10.97 0.5 μM
150
100
50
***
**
**
100
50
0
*
0
log(C)
Compounds (40 μM)
Figure 1. Anti-excitotoxic activity of compounds in glutamate-induced cell death. (A) PC12 cell
cultures were exposed to an established excitotoxic concentration of glutamate (Glu) (20 mM), and
some were also treated with each compound (S9 and S15 semi-synthetic derivatives; E3, estriol; SL,
solasodine; E1, estrone; T, testosterone; TDCA, taurodeoxycholic acid) or solvent control (DMSO).
After 24 h of exposition to the damage and treatment, cellular viability was determined by the MTT
assay; (B) Dose-response of Compound S15 in the same model of glutamate-induced excitotoxicity.
Data are represented as the percent with respect to the untreated cells, representing the highest cell
viability. * p < 0.05, ** p < 0.01 and *** p < 0.001, according to one-way ANOVA and Tukey’s post-hoc test.
100
***
80
60
40
20
0
Compounds (μM)
Figure 2. Neuroprotective activity of compounds against cell damage induced by chemical hypoxia and
glucose deprivation. PC12 cells were cultured in oxygen and glucose deprivation conditions (OGD),
specifically in the absence of glucose and in the presence of 600 µM of potassium cyanide (KCN) for 1 h,
and then, normal culture medium was reperfused to the cells. After 4 h of the reperfusion start, some
PC12 cells were treated with solvent control (DMSO), solasodine (SL) or different concentrations of the
S15 derivative. After 20 h of exposition to the reperfusion damage and treatment, cellular viability was
determined by the MTT assay. Data are represented as the percent with respect to the untreated cells,
representing the highest cell viability. Asterisks indicate statistical differences between the treatment
and respective control condition (*** p < 0.001) according to one-way ANOVA and Tukey’s post-hoc test.

Molecules 2016, 21, 992
6 of 15
Besides glutamate-induced excitotoxicity signaling, the mechanisms of oxidative imbalance
and mitochondrial damage are also involved in the ischemic neuronal cell death [ ]. Taking into
4,5
account that SL and S15 restored the cellular viability of glutamate-damaged PC12 cells, we further
evaluated the in vitro activity of those steroids in PC12 cells exposed to cyanide-induced mitochondrial
dysfunction. As indicated in Figure 2, among the two evaluated steroids, only the synthetic spirosteroid
analog S15 significantly protects PC12 cells from the mitochondrial damage induced by cyanide,
in a dose-dependent manner (Figure 2). One of the neuroprotective mechanisms described in
several nerve cells involves protein kinase B, PI3K and Akt kinases, which are known to be engaged
in antiapoptotic and prosurvival activities. Specifically, it has been suggested that the PI3K/Akt
pathway may regulate both NGF and BDNF-mediated neuronal survival [46,54]. However, in the
scenario of PC12 cells exposed to oxygen and glucose deprivation, previous results have shown that
overactivation of the antiapoptotic Akt kinase is detrimental rather than beneficial, highlighting the
relevance of a balance in the activation status of Akt [55]. In this context, it has been demonstrated
that adipose mesenchymal stem cells protect against glutamate-induced injury in PC12 cells by
secreting neurotrophic factors, such as BDNF, through the involvement of the PI3-K/Akt and MAPK
pathways [56]. In addition, smilagenin, a steroidal sapogenin from traditional Chinese medicinal
herbs, stimulates BDNF mRNA transcription and attenuates Aβ(25–35)-induced neurodegeneration
in primary cortical neurons and in a neuroblastoma cell line [57]. We could then hypothesize that
the S15 semi-synthetic sapogenin derivative exerts its protective effects on glutamate-damaged PC12
cells through the induction of neuroprotective signaling pathways, such as PI3-K/Akt, and probably
the induction of neurotrophic factors. It is worth keeping in mind that, although PC12 is one of
the most utilized cell lines for studies concerning the function of neurons, neuronal differentiation
and neurotoxicity, primary cultures of cortical neurons are also widely used because they present
all of the characteristics of living neurons activated by ionotropic glutamate receptor agonists [46].
Further studies in neuron primary cultures may provide more precise physiological information
regarding the neuroprotective potential of Compound S15 in excitotoxicity models. Altogether, this
observed in vitro neuroprotective activity of Compound S15 supports its role as a potential therapeutic
candidate for neurological diseases involving mitochondrial dysfunction and excitotoxicity.
2.2.2. Measurements of IL-1β and Nitric Oxide Levels
The inflammatory response after brain tissue damage and ischemic neuronal cell death has been
widely reported [
4
,
5
]. Therefore, we established a microglia primary culture, and we exposed the
(20 U/mL) in order to induce the release of pro-inflammatory
cells to LPS (1 g/mL) and IFN
µ
γ
molecules, as an experimental model of in vitro neuro-inflammation. The treatment with the synthetic
spirosteroid S15, or dexamethasone as the inhibition control, was applied to the cells 30 min before the
induction with LPS and IFN
in the culture medium by the Griess assay and ELISA. The primary microglia were able to release
significant levels of nitrite and IL-1 , in response to the stimulus with LPS/IFN and with respect to
untreated cells (Figure 3A,B). As expected, the treatment with dexamethasone (10 M) significantly
decreased the high levels of nitrite and IL-1 , induced by LPS/IFN stimulus (Figure 3). The treatment
with the analog S15 inhibited the LPS/IFN -induced production of nitric oxide and IL-1 by
γ. After 24 h of treatment, nitrite and IL-1β concentrations were measured
β
γ
µ
β
γ
γ
β
microglia cultures, in a dose-dependent fashion (Figure 3). In vitro studies involving inflammatory
stimulation with lipopolysaccharide, phorbol ester or interferon-gamma have demonstrated that
17
increased expression and superoxide release of activated microglia, through a mechanism involving
an estrogen receptor-dependent activation of MAP kinase [58 59]. Previous work has demonstrated
that pre-treatment of ovariectomized rats with 17 -estradiol attenuates the activation of NF- B and
iNOS expression during post-ischemic reperfusion [60 61]. Therefore the modulation of NF- B activity
β-estradiol dose-dependently decreases the phagocytic activity, inducible nitric oxide synthase
,
β
κ
,
κ
through hormone receptor-mediated signaling could be relevant for the mechanism of action of
Compound S15, in the context of neuroprotection for ischemia/reperfusion, a complex disease where

Molecules 2016, 21, 992
7 of 15
not only neuronal cell death, but also neuroinflammation takes place. On the basis of these in vitro
results, the effects exerted by the synthetic spirosteroid S15 on cell death and neuroinflammatory
response suggest a potential in vivo neuroprotective effect.
B
A
20
15
10
5
6000
4000
2000
0
**
*
**
**
***
0
γ
0
0
5
.
T
P
X
O
4
1
N
2
S
U
L
D
F
I
M
/
S
D
S15 (μM)
S15 (μM)
Figure 3. In vitro anti-inflammatory activity of the S15 derivative in activated primary microglia.
Microglia-enriched primary cultures were obtained from brains of adult male rats. Different concentrations
of the S15 derivative, solvent control (DMSO) or 10
of inhibition were applied to some microglia cultures, 30 min before the activation of microglia cells
with lipopolysaccharide (LPS, 1 g/mL) and murine recombinant interferon gamma (IFN , 20 U/mL).
Untreated (UT) microglia cells were included as the negative control of inhibition. After 24 h of
µM of dexamethasone (DX) as the positive control
µ
γ
exposition or not to the stimulus and treatment, the IL-1
β
level was quantified by ELISA (
A); and
the content of nitrite was determined by the Griess assay (
B). Asterisks indicate statistical differences
between the treatment and respective control condition (* p < 0.05, ** p < 0.01 and *** p < 0.001
according to one-way ANOVA and Tukey’s post-hoc test.
)
2.2.3. Rat Uterotrophic Assay
The estrogenic potential of a compound can be determined by the in vivo uterotrophic assay,
which includes two possible variants. It is based on the principle that estrogens regulate the growth
phase of the uterus in the physiological estrous cycle. We used one model that uses females in the
sexually immature state before the activation of the hypothalamic-pituitary-gonadal axis and the
synthesis of ovarian estrogens [24]. In order to evaluate the estrogenic potential according to OECD
guidelines, immature female rats were administered with E2 (positive control) or Compound S15
,
and the uterus wet weight was determined. As we expected, there was an increase in the uterus wet
weight of immature rats treated for three consecutive days with E2, in a dose-dependent manner
(Figure 4A), showing that the model was successful in our conditions. In the case of Compound
S15 we did not observe any significant increase in the uterus wet weight in any of the three applied
doses (Figure 4B). These results reveal a lack of estrogenic activity for Compound S15 concerning the
induction of uterine growth, which may represent a pharmacological advantage in terms of hormonal
adverse side effects. However, the interaction of S15 with classical nuclear or membrane-bound ER
needs to be further studied by in vitro ER binding and transactivation assays, as has been suggested
for several endocrine disrupting compounds [62]. The lack of a remarkable estrogenic effect of the
S15 analog, according to the uterotrophic assay in immature rats, may represent a pharmacological
advantage in terms of hormonal adverse side effects.

Molecules 2016, 21, 992
8 of 15
A
B
500
400
300
200
100
0
300
200
100
0
***
***
*
E2 (ug/kg)
S15 (mg/kg)
Figure 4. Uterine weight determined by the uterotrophic assay in immature female rats. Different doses
of ( ) E2 and ( ) Compound S15 or E2 (150 g/kg) were administered to Post-natal Day (PND)
A
B
µ
18 immature rats for three consecutive days. One day after the last dose, animals were sacrificed,
and the uterus wet weight was measured. Asterisks indicate statistical differences between the
treatment and respective control condition (* p < 0.05 and *** p < 0.001) according to one-way ANOVA
and Tukey’s post-hoc test.
3. Materials and Methods
3.1. Chemistry
All reagents were purchased from Merk Millipore and Panreac (Barcelona, Spain). The solvents,
with technical quality American Chemical Society (ACS)-certified, were dried and distilled before use.
The diosgenin was purchased from Sigma-Aldrich (Oakville, ON, Canada). Column chromatography
was performed on Merk silica gel 60 (70–230 mesh ASTM, Merck, Barcelona, Spain). Analytical
thin-layer chromatography (TLC) was carried out on silica pre-coated (0.25 mm) Merck silica gel
GF254 (50 mm
ˆ
100 mm, Merck). The samples were developed with a vanillin solution of 1% in
50% perchloric acid. Melting points (mp) were recorded using an oven with the Electrothermal 9100
capillary apparatus, and the temperatures were uncorrected. The FTIR spectra were recorded in
a Philips Analytical PU 9600 FTIR spectrophotometer in the 450–4500 cm´1 interval in KBr pellets
at room temperature. NMR spectra were recorded on a Bruker DRX-400 spectrometer (Rheinstetten,
Germany) operating at 400 MHz for 1H and 100 MHz for 13C. The samples were dissolved in deuterated
chloroform, and the chemical shifts are expressed in ppm. The separation and purification process of
the synthesized compounds by column chromatography (CC) was developed by using as the solvent
a mixture of n-hexane/ethyl acetate (v/v) according to the derivatives.
3.1.1. (25R)-5-Spirost-3β-ol-3-acetate (6)
Diosgenin 1 (10 g, 24 mmol) was dissolved in 20 mL of pyridine and 20 mL of Ac2O. After allowing
the mixture to settle at room temperature for 24 h, it was poured into ice-cold water. The product was
washed with diluted HCl and in the second step with abundant water to obtain 10.4 g of Compound
(95%). Physicochemical properties for this intermediary were reported in [39].
6
3.1.2. (25R)-5,6-Epoxy-spirost-3β-ol-3-acetate (7)
After dissolving 10 g of Compound
6 (10.96 mmol) in 20 mL of chloroform, 3 g (17.53 mmol)
of meta-chloro-perbenzoic acid were added at room temperature. The reaction mixture was stirred
for 30 min, diluted with 25 mL of chloroform and washed with aqueous Na2SO3, aqueous Na2CO3
and water. The organic layer was dried and concentrated under vacuum to afford 8.64 g of solid
Compound 7 (85%). Physicochemical properties for this intermediary were reported in [39].

Molecules 2016, 21, 992
9 of 15
3.1.3. (25R)-Spirost-3β,5α-dihydroxy-6-one-3-acetate (8)
Seven grams (14.1 mmol) of Compound
7 were dissolved in 92.5 mL of acetone. Then, a solution
of 7.5 g (74.7 mmol) of CrO3 in 16.2 mL of water was added with soft refluxing. After the reaction
was finished, the solution was poured in water. The resulting solid was filtered, washed with water
and re-crystallized from methanol. Five-point-eight grams of Compound
Physicochemical properties for this intermediary were reported in [39].
8 were obtained (80%).
3.1.4. (25R)-Spirost-3β,5α-dihydroxy-6-one (S9)
Five grams (10.2 mmol) of Compound
8 were dissolved in 390 mL of methanol. Subsequently,
a solution of 4.6 g of NaHCO3 in 60 mL of water was added while refluxing for 3 h. After allowing the
reaction mixture to settle at room temperature, it was poured in water, to obtain 4.35 g of Compound S9
(95%), mp 272 ˝C (methanol). IR (KBr):
ν
max 3396 ( OH), 2953 (
ν
ν CH), 1703 (ν C=O), 1449 and 1380
(δ
CH), 1055 (
ν
C=O), 977 (spiroketal); 1H-NMR (
δ, ppm): 1.97/1.30 (m, 2H, H-1), 1.80/1.45 (m, 2H,
H-2), 3.93 (m, 1H, H-3), 1.84/1.69 (m, 2H, H-4), 2.82/2.04 (m, 2H, H-7), 1.94 (m, 1H, H-8), 1.99 (m, 1H,
H-9), 1.51/1.36 (m, 2H, H-11), 1.81/1.28 (m, 2H, H-12), 1.47 (m, 1H, H-14), 1.96/1.29 (m, 2H, H-15),
4.44 (m, 1H, H-16), 1.83 (m, 1H, H-17), 0.82 (s, 3H, CH3-18), 0.83 (s, 3H, H-19), 1.90 (m, 1H, H-20), 0.99
(d, 3H, CH3-21), 1.70/1.60 (m, 2H, H-23), 1.65/1.46 (m, 2H, H-24), 1.64 (m, 1H, H-25), 3.48/3.40 (m, 2H,
H-26), 0.82 (d, CH3-27). 13C-NMR (
δ, ppm: 30.4 (C-1), 29.8 (C-2), 67.2 (C-3), 36.5 (C-4), 80.7 (C-5), 211.7
(C-6), 41.9 (C-7), 36.7 (C-8), 44.6 (C-9), 42.4 (C-10), 21.3 (C-11), 39.5 (C-12), 41.1 (C-13), 56.1 (C-14), 31.6
(C-15), 80.5 (C-16), 62.0 (C-17), 16.4 (C-18), 14.2 (C-19), 41.6 (C-20), 14.5 (C-21), 109.3 (C-22), 31.3 (C-23),
28.8 (C-24), 30.3 (C-25), 66.9 (C-26), 17.1 (C-27).
3.1.5. (25R)-Spirost-5α-hydroxy-3,6-dione (S15)
After dissolving 4 g (9 mmol) of Compound S9 in 500 mL of acetone, 4 mL of Jones reagent
(8 N-CrO3:5.33 g of CrO3 were dissolved in 4.4 mL of concentrate H2SO4, then water was added
to obtain a 20-mL solution) were included drop-wise at room temperature. When the reaction was
concluded, isopropanol was added until the mixture lost the orange color. After the solution was
filtered by gravity, it was poured in water. The solid product was purified by column chromatography
˝
ν
(1:1 hexane–EtOAc) affording 3.1 g of S15 (81.5%), mp 283 C (methanol). IR (KBr):
2953 ( CH), 1713 ( C=O), 1456 and 1376 ( CH), 1057 (
C-O), 980 and 899 (spiroketal); 1H-NMR
, ppm): 2.10/1.86 (m, 2H, H-1), 2.40 (m, 2H, H-2), 2.78/2.25 (m, 2H, H-4), 2.96/2.34 (m, 2H, H-7),
ν
3345 (ν OH),
max
ν
ν
δ
(δ
1.99 (m, 1H, H-8), 1.90 (m, 1H, H-9), 1.50 (m, 2H, H-11), 1.81/1.31 (m, 2H, H-12), 1.46 (m, 1H, H-14),
1.99/1.32 (m, 2H, H-15), 4.47 (m, 1H, H-16), 1.85 (m, 1H, H-17), 0.83 (s, 3H, CH3-18), 1.04 (s, 3H,
CH3-19), 1.90 (m, 1H, H-20), 1.01 (d, 3H, CH3-21), 1.69 (m, 2H, H-23), 1.50 (m, 2H, H-24), 1.66 (m, 1H,
H-25), 3.5/3.38 (m, 2H, H-26), 0.82 (d, 3H, CH3-27). 13C-NMR (
δ, ppm): 31.8 (C-1), 37.3 (C-2), 210.2
(C-3), 41.9 (C-4), 82.7 (C-5), 210.4 (C-6), 44.8 (C-7), 36.8 (C-8), 44.7 (C-9), 43.1 (C-10), 21.3 (C-11), 39.5
(C-12), 41.0 (C-13), 56.0 (C-14), 31.6 (C-15), 80.4 (C-16), 62.0 (C-17), 16.4 (C-18), 13.9 (C-19), 41.6 (C-20),
14.5 (C-21), 109.3 (C-22), 31.3 (C-23), 28.8 (C-24), 30.3 (C-25), 66.9 (C-26), 17.1 (C-27).
3.2. Biological Activity Assays
3.2.1. Treatments for PC12 Cell Cultures
The PC12 cell line was obtained from the American˝Type Culture Collection (Rockville, MD,
USA) and maintained in a controlled environment at 37 C and a 5% CO2 atmosphere. The cells
were grown in RPMI-1640 medium supplemented with 5% fetal bovine serum (FBS), 10% horse
serum and antibiotic/antimycotic solution (Sigma-Aldrich A5955). The culture medium was changed
every 2 days, and the cells were seeded at a cellular density of 15,000 cells/mL in 96-well plates.
To evaluate the effect of synthetic analogs of plant-derived spirosteroids, commercially available
spirosteroids and endogenous steroids, on neurotoxic cell death related to cerebral ischemia, PC12
cells were exposed to an excitotoxic concentration of L-glutamate (20 mM) and co-treated with each

Molecules 2016, 21, 992
10 of 15
natural and synthetic compound or vehicle (0.01% DMSO in culture medium) for 24 h. As another
damaging condition closely related to ischemic neuronal death, PC12 cells were exposed to chemical
hypoxia with potassium cyanide (KCN) (600 µM) in glucose-free culture medium for 1 h. Following 4 h
of restoring the normal culture medium, without KCN, PC12 cells were treated with each natural
and synthetic compound or vehicle (0.01% DMSO in culture medium) for 20 h. In our previous
work, cytotoxicity experiments in PC12 cells were done to determine the limit of the non-cytotoxic
dose for each compound [63]. A concentration below this value was chosen for the cyto-protective
activity studies, and for comparative experiments, we worked with the same concentration for all
compounds (40 µM or 4 µM of TDCA). In addition, the compound dose of 40 µM was selected for the
glutamate-induced excitotoxicity experiments taking into account previous recommendations in drug
discovery programs [64]. For the other in vitro experiments, the dose-response for each compound
was designed from 40 µM and 4-fold decreases. All experiments were performed in phenol red-free
medium and charcoal-stripped serum to remove steroids.
3.2.2. MTT Assay
Cellular viability was evaluated by the colorimetric assay based on the measurement of
the 3-(4,5-dimethylthiazol-2-yl)-2,5-diphenyltetrazolium bromide (MTT) reduction product [44].
MTT reagent can be converted to purple formazan crystals by mitochondrial dehydrogenases of
viable cells. The high optical density at 570 nm detected after the complete reduction of MTT correlates
with the fraction of viable cells [44]. After the desired incubation period with treatments and damaging
conditions, the cell cultures were analyzed for MTT reduction. In brief, MTT was dissolved in PBS at
5 mg/mL and was 10-fold diluted in serum-free RPMI 1640 medium. After incubation of the cells with
the compounds to be tested, the medium was aspirated, and MTT (0.5 mg/mL) containing serum-free
medium was added. After an additional 3 h of incubation at 37 ˝C, isopropanol/HCl was added to
each well, and the absorbance of solubilized MTT formazan products was measured at 570 nm.
3.2.3. Microglia-Enriched Primary Cultures
Taking into account that neuro-inflammation is a common hallmark of many neurological diseases,
such as cerebral ischemia, we established a microglia-enriched primary culture from adult rat brains,
according to the procedure described by Moussaud and colleagues, with minor modifications [65].
Briefly, the brain of anesthetized and transcardially perfused, 2-month-old male Wistar rats was
aseptically removed and carefully freed from the meninges. Only those brains properly exsanguinated
were finely minced with a scalpel in the presence of the enzymatic solution (116 mM NaCl, 5.4 mM
KCl, 26 mM NaHCO3, 1 mM NaH2PO4, 1.5 mM CaCl2, 1 mM MgSO4, 0.5 mM EDTA, 25 mM glucose,
1 mM cysteine and 20 U/mL of papain (all from Sigma-Aldrich)). After 90 min of incubation at
˝
37 C, 5% CO2 in continuous stirring, the enzymatic digestion was stopped with 20% heat-inactivated
fetal bovine serum (FBS) in Hank’s balanced salt solution (HBSS) (Invitrogen, Karlsruhe, Germany),
and the tissue suspension was centrifuged at 200
pellet was further digested with 0.5 mg/mL DNase I (Roche, Mannheim, Germany) in HBSS and
incubated for 5 min at room temperature. After gentle disruption of the tissue with polished Pasteur
ˆ
g for 7 min at room temperature. The resulting
pipettes of decreasing diameters, the homogenate was filtered through a 70-µm cell strainer (Becton
Dickinson, Heidelberg, Germany). Then, the resulting cell suspension was centrifuged, and the cell
pellet was resuspended in 20 mL of 20% stock isotonic Percoll (SIP) (GE Healthcare, Freiburg, Germany)
(
SIP = v/v ratio: 9/10 Percoll + 1/10 HBSS 10
ˆ
) in HBSS. The cell suspension was carefully overlaid
with 20 mL pure HBSS and centrifuged at 200
After this clarification step, the pellet with mixed glial cells was collected and washed once with HBSS.
Finally, the cell pellet was resuspended in DMEM medium supplemented with glutamine 2 mM,
ˆ
g for 20 min with slow acceleration and no brake.
10 % FBS, 100 U/mL penicillin, 100 µg/mL streptomycin (all from Sigma-Aldrich) and 5 ng/mL
of murine recombinant granulocyte and macrophage colony stimulating factor (GM-CSF) (315-03,
Peprotech, Hamburg, Germany). The cell suspension from the cortical region of one brain was plated

Molecules 2016, 21, 992
11 of 15
in one T75 flask (Greiner BioOne, Vilvoorde, Belgium), coated with poly-D-lysine (Sigma-Aldrich) and
˝
maintained in culture at 37 C, 95% air/5% CO2 humidified incubator. The medium was changed twice
a week until the cells became confluent (after approximately 2 weeks). Before the start of experiments,
microglia were collected from the supernatant of confluent flasks and cultured for at least 3 days in
medium without GM-CSF. The in vitro age of the cultures, in all of the experiments, was between
15 and 32 days in vitro (DIV).
For the NO and IL-1β induction experiments, the microglia cells were seeded at a density of
20,000 cells per well in 96-well plates, coated with poly-D-lysine (Sigma-Aldrich). Those cells were
incubated for 30 min in DMEM medium supplemented with glutamine 2 mM, 10% FBS, 100 U/mL
penicillin, 100
concentrations. Dexamethasone at 10
NO and IL-1 . After this pre-incubation with the compounds, microglia cells were stimulated with
g/mL of lipopolysaccharide (LPS) from Escherichia coli strain 055:B5 (Sigma-Aldrich) and 20 U/mL
µg/mL streptomycin, with or without S15 spirosteroid analogue at three different
µM was used as a positive control for the inhibition of induced
β
1
µ
˝
of murine recombinant interferon gamma (IFNγ) for 24 h at 37 C, 95% air/5% CO2.
3.2.4. IL-1β and Nitric Oxide Assay
The amount of IL-1
ELISA system with antibodies specifics for rat IL-1
AF-501-NA and Polyclonal Rat IL-1 /IL-1F2 Biotinylated Catalog Number BAF501, R&D Systems,
β
released into the culture medium was measured using a sandwich
β
(Polyclonal Rat IL-1 /IL-1F2 Catalog Number
β
β
Minneapolis, MN, USA), following the manufacturer’s i˝nstructions. Culture supernatants were
collected 24 h after LPS/IFNγ treatment and stored at ´80 C until assayed for IL-1β content.
NO production was assessed by the Griess reaction. Briefly, culture supernatants were collected
24 h after LPS/ IFNγ stimulation and incubated with equal volumes of Griess reagent for 10 min at
room temperature, in the dark. Optical density was measured at 540 nm using a microplate reader
(Polarstar Omega, BMG Labtech, Offenburg, Germany). Nitrite concentration was calculated from
a sodium nitrite standard curve.
3.2.5. Immature Rat Uterotrophic Assay
Post-natal day (PND) 11 female Wistar rats were purchased from CENPALAB (Havana, Cuba)
and allowed to acclimate for 7 days. Each group of six pups was housed in a polycarbonate cage
and fed ad libitum with standard CMO 1000 diet CENPALAB (Havana, Cuba). The temperature of
the environment was set at 20–24 ˝C with 40%–60% relative humidity and a 12-h light-dark cycle.
E2 (1–1000 µg/kg) and Compound S15 (0.4 or 10 mg/kg) were administered subcutaneously for 3 days
to immature rats at PND 18. All experimental protocols were approved by the ethics committee for
animal research, Havana University, Havana, Cuba.
3.3. Statistical Analysis
All experimental groups were analyzed with the D’Agostino and Pearson omnibus normality
test to determine the Gaussian distribution of the data. Significant differences between groups were
determined by 1-way ANOVA, followed by Tukey’s post hoc analysis with the GraphPad Instat
program, Version 5, for Windows
confidence interval, are expressed as the means
experiments. Asterisks indicate statistical differences between the treatment and respective control
©
(San Diego, CA, USA, www.graphpad.com). All data, at the 95%
standard error of the mean (SEM) from 3 independent
˘
condition (* p < 0.05, ** p < 0.01 and *** p < 0.001).
4. Conclusions
Several naturally-occurring steroids were biologically evaluated in a cellular model of
excitotoxicity. Among them, E3, T and SL showed a neuroprotective activity against excitotoxicity, but
not against the glucose deprivation and cyanide-induced cell death. In parallel, four semi-synthetic
spirosteroid analogues were synthesized and evaluated as therapeutic candidates in the same

Molecules 2016, 21, 992
12 of 15
two cellular models of damage (glutamate-induced excitotoxicity and glucose deprivation and
cyanide-induced cell death) and also in neuro-inflammation induced in primary microglia. The specific
chemical features of the synthetic spirosteroid S15 may provide information that could be useful for
the design of novel neuroprotective agents, using a sapogenin scaffold. Moreover, the S15 derivative
does not have a strong estrogenic effect, according to the uterotrophic assay in immature rats, which
may give further advantages in the pharmacological use of this family of compounds. Further studies
to improve and fully characterize the in vivo neuroprotective activity of this class of compounds need
to be investigated.
Supplementary Materials: Supplementary materials can be accessed at: http://www.mdpi.com/1420-3049/21/
8/992/s1.
Acknowledgments:
This work was partially supported by the Non-Governmental Organization
MEDICUBA-SPAIN and by Vlaamse Interuniversitaire Raad (VLIR)-Belgium/Ministerio de Educación Superior
(MES)-Cuba Project ZEIN2011PR383, which also covered the open access publication fees. We are grateful
to Luis Morier from Tropical Medicine Institute “Pedro Kourí” for his valuable assistance in cell cultures,
Vivian Montero and Rolando Perdomo for their helpful assistance in HPLC analysis and Piet Van Espen for the
critical review.
Author Contributions: L.G.-P. and Y.N.F. conceived of and designed the experiments. L.G.-P., A.Z.-C., V.E. and
J.E.T.-M. performed the experiments. L.G.-P. and V.E. analyzed the data. L.P., W.V.B. and R.D.-H. contributed
reagents/materials/analysis tools. L.G.-P. wrote the paper.
Conflicts of Interest: The authors declare no conflict of interest.
References
1.
2.
3.
4.
5.
6.
Mukherjee, D.; Patil, C.G. Epidemiology and the global burden of stroke. World Neurosurg. 2011, 76, S85–S90.
[CrossRef] [PubMed]
Dirnagl, U. Pathobiology of injury after stroke: The neurovascular unit and beyond. Ann. N. Y. Acad. Sci.
2012, 1268, 21–25. [CrossRef] [PubMed]
Dirnagl, U.; Iadecola, C.; Moskowitz, M.A. Pathobiology of ischaemic stroke: An integrated view.
Trends Neurosci. 1999, 22, 391–397. [CrossRef]
Brouns, R.; de Deyn, P.P. The complexity of neurobiological processes in acute ischemic stroke.
Clin. Neurol. Neurosurg. 2009, 111, 483–495. [CrossRef] [PubMed]
Iadecola, C.; Anrather, J. The immunology of stroke: From mechanisms to translation. Nat. Med. 2011, 17,
796–808. [CrossRef] [PubMed]
Chan, C.R.; Hsu, J.T.; Chang, I.T.; Young, Y.C.; Lin, C.M.; Ying, C. The effects of glutamate can be attenuated
by estradiol via estrogen receptor dependent pathway in rat adrenal pheochromocytoma cells. Endocrine
2007, 31, 44–51. [CrossRef] [PubMed]
7.
8.
9.
Choi, D.W.; Maulucci-Gedde, M.; Kriegstein, A.R. Glutamate neurotoxicity in cortical cell culture. J. Neurosci.
1987, 7, 357–368. [PubMed]
Pereira, C.F.; Oliveira, C.R. Oxidative glutamate toxicity involves mitochondrial dysfunction and
perturbation of intracellular Ca2+ homeostasis. Neurosci. Res. 2000, 37, 227–236. [CrossRef]
Pereira, C.M.; Oliveira, C.R. Glutamate toxicity on a PC12 cell line involves glutathione (GSH) depletion and
oxidative stress. Free Radic. Biol. Med. 1997, 23, 637–647. [CrossRef]
10. Olney, J.W. Brain lesions, obesity, and other disturbances in mice treated with monosodium glutamate.
Science 1969, 164, 719–721. [CrossRef] [PubMed]
11. Stanika, R.I.; Pivovarova, N.B.; Brantner, C.A.; Watts, C.A.; Winters, C.A.; Andrews, S.B. Coupling diverse
routes of calcium entry to mitochondrial dysfunction and glutamate excitotoxicity. Proc. Natl. Acad. Sci. USA
2009, 106, 9854–9859. [CrossRef] [PubMed]
12. Murphy, T.H.; Miyamoto, M.; Sastre, A.; Schnaar, R.L.; Coyle, J.T. Glutamate toxicity in a neuronal cell line
involves inhibition of cystine transport leading to oxidative stress. Neuron 1989, 2, 1547–1558. [CrossRef]
13. Davis, J.B.; Maher, P. Protein kinase C activation inhibits glutamate-induced cytotoxicity in a neuronal cell
line. Brain Res. 1994, 652, 169–173. [CrossRef]
14. Schubert, D.; Kimura, H.; Maher, P. Growth factors and vitamin E modify neuronal glutamate toxicity.
Proc. Natl. Acad. Sci. USA 1992, 89, 8264–8267. [CrossRef] [PubMed]

Molecules 2016, 21, 992
13 of 15
15. White, R.J.; Reynolds, I.J. Mitochondria and Na+/Ca2+ exchange buffer glutamate-induced calcium loads in
cultured cortical neurons. J. Neurosci. 1995, 15, 1318–1328. [PubMed]
16. Rizzuto, R. Intracellular Ca2+ pools in neuronal signalling. Curr. Opin. Neurobiol. 2001, 11, 306–311.
[CrossRef]
17. Tang, Y.; Zucker, R.S. Mitochondrial involvement in post-tetanic potentiation of synaptic transmission.
Neuron 1997, 18, 483–491. [CrossRef]
18. Szydlowska, K.; Tymianski, M. Calcium, ischemia and excitotoxicity. Cell Calcium 2010, 47, 122–129.
[CrossRef] [PubMed]
19. Dirnagl, U. Bench to bedside: The quest for quality in experimental stroke research. J. Cereb. Blood Flow Metab.
2006, 26, 1465–1478. [CrossRef] [PubMed]
20. Veiga, S.; García-Segura, L.M.; Azcoitia, I. The neuroprotective properties of sex steroids and neurosteroids.
Rev. Neurol. 2004, 39, 1043–1051. [PubMed]
21. Simpkins, J.W.; Rajakumar, G.; Zhang, Y.Q.; Simpkins, C.E.; Greenwald, D.; Yu, C.J.; Bodor, N.; Day, A.L.
Estrogens may reduce mortality and ischemic damage caused by middle cerebral artery occlusion in the
female rat. J. Neurosurg. 1997, 87, 724–730. [CrossRef] [PubMed]
22. Behl, C.; Skutella, T.; Lezoualc’h, F.; Post, A.; Widmann, M.; Newton, C.J.; Holsboer, F. Neuroprotection
against oxidative stress by estrogens: Structure-activity relationship. Mol. Pharmacol. 1997, 51, 535–541.
[PubMed]
23. Behl, C.; Widmann, M.; Trapp, T.; Holsboer, F. 17-β estradiol protects neurons from oxidative stress-induced
cell death in vitro. Biochem. Biophys. Res. Commun. 1995, 216, 473–482. [CrossRef] [PubMed]
24. Green, P.S.; Gordon, K.; Simpkins, J.W. Phenolic A ring requirement for the neuroprotective effects of steroids.
J. Steroid Biochem. Mol. Biol. 1997, 63, 229–235. [CrossRef]
25. Moosmann, B.; Behl, C. The antioxidant neuroprotective effects of estrogens and phenolic compounds are
independent from their estrogenic properties. Proc. Natl. Acad. Sci. USA 1999, 96, 8867–8872. [CrossRef]
[PubMed]
26. Prokai, L.; Prokai-Tatrai, K.; Perjesi, P.; Zharikova, A.D.; Perez, E.J.; Liu, R.; Simpkins, J.W. Quinol-based
cyclic antioxidant mechanism in estrogen neuroprotection. Proc. Natl. Acad. Sci. USA 2003, 100, 11741–11746.
[CrossRef] [PubMed]
27. Suzuki, S.; Brown, C.M.; Wise, P.M. Neuroprotective effects of estrogens following ischemic stroke.
Front. Neuroendocrinol. 2009, 30, 201–211. [CrossRef] [PubMed]
28. Simpkins, J.W.; Singh, M.; Brock, C.; Etgen, A.M. Neuroprotection and estrogen receptors. Neuroendocrinology
2012, 96, 119–130. [CrossRef] [PubMed]
29. Vegeto, E.; Ghisletti, S.; Meda, C.; Etteri, S.; Belcredito, S.; Maggi, A. Regulation of the lipopolysaccharide
signal transduction pathway by 17β-estradiol in macrophage cells. J. Steroid Biochem. Mol. Biol. 2004, 91,
59–66. [CrossRef] [PubMed]
30. Abdelhamid, R.; Luo, J.; VandeVrede, L.; Kundu, I.; Michalsen, B.; Litosh, V.A.; Schiefer, I.T.; Gherezghiher, T.;
Yao, P.; Qin, Z.; et al. Benzothiophene Selective Estrogen Receptor Modulators Provide Neuroprotection by
a novel GPR30-dependent Mechanism. ACS Chem. Neurosci. 2011, 2, 256–268. [CrossRef] [PubMed]
31. Ronnekleiv, O.K.; Malyala, A.; Kelly, M.J. Membrane-initiated signaling of estrogen in the brain.
Semin. Reprod. Med. 2007, 25, 165–177. [CrossRef] [PubMed]
32. Weaver, C.E., Jr.; Park-Chung, M.; Gibbs, T.T.; Farb, D.H. 17β-Estradiol protects against NMDA-induced
excitotoxicity by direct inhibition of NMDA receptors. Brain Res. 1997, 761, 338–341. [CrossRef]
33. Cushman, M.; Kuller, L.H.; Prentice, R.; Rodabough, R.J.; Psaty, B.M.; Stafford, R.S.; Sidney, S.; Rosendaal, F.R.
Estrogen plus progestin and risk of venous thrombosis. JAMA 2004, 292, 1573–1580. [CrossRef] [PubMed]
34. Inagaki, T.; Etgen, A.M. Neuroprotective action of acute estrogens: Animal models of brain ischemia and
clinical implications. Steroids 2013, 78, 597–606. [CrossRef] [PubMed]
35. Perron, F.; Albizati, K.F. Chemistry of spiroketals. Chem. Rev. 1989, 89, 1617–1661. [CrossRef]
36. Chauhan, K.; Sheth, N.; Ranpariya, V.; Parmar, S. Anticonvulsant activity of solasodine isolated from
Solanum sisymbriifolium fruits in rodents. Pharm. Biol. 2011, 49, 194–199. [CrossRef] [PubMed]
37. Lecanu, L.; Hashim, A.I.; McCourty, A.; Giscos-Douriez, I.; Dinca, I.; Yao, W.; Vicini, S.; Szabo, G.; Erdélyi, F.;
Greeson, J.; et al. The naturally occurring steroid solasodine induces neurogenesis in vitro and in vivo
.
Neuroscience 2011, 183, 251–264. [CrossRef] [PubMed]

Molecules 2016, 21, 992
14 of 15
38. Simpkins, J.W.; Yang, S.H.; Liu, R.; Perez, E.; Cai, Z.Y.; Covey, D.F.; Green, P.S. Estrogen-like compounds for
ischemic neuroprotection. Stroke 2004, 35, 2648–2651. [CrossRef] [PubMed]
39. Castro, A.Z.; Tacoronte, J.E.; Mancha, F. C.; de la Paz, L.A.; Cabrera, M.T. Ecdysteroid analogs based on
steroidal sapogenins I. Synthesis of bromo-derivatives from diosgenin. Preliminary study of their biological
activity. Rev. CENIC. Cienc. Quím. 2002, 33, 19–24.
40. SciFinder. Chemical Abstracts Service. Columbus 2015. Available online: https://scifinder.cas.org/scifinder/
(accesed on 30 January 2015).
41. Rivera, D.G.; León, F.; Coll, F.; Davison, G.P. Novel 5β-hydroxyspirostan-6-ones ecdysteroid antagonists:
Synthesis and biological testing. Steroids 2006, 71, 1–11. [CrossRef] [PubMed]
42. Shawakfeh, K.Q.; Al-Said, N.H. Synthesis of new symmetrical bis-steroidal pyrazine analogues from
diosgenin. Steroids 2011, 76, 232–237. [CrossRef] [PubMed]
43. Bhavnani, B.R.; Berco, M.; Binkley, J. Equine estrogens differentially prevent neuronal cell death induced by
glutamate. J. Soc. Gynecol. Investig. 2003, 10, 302–308. [CrossRef]
44. Mosmann, T. Rapid colorimetric assay for cellular growth and survival: Application to proliferation and
cytotoxicity assays. J. Immunol. Methods 1983, 65, 55–63. [CrossRef]
45. Greene, L.A.; Tischler, A.S. Establishment of a noradrenergic clonal line of rat adrenal pheochromocytoma
cells which respond to nerve growth factor. Proc. Natl. Acad. Sci. USA 1976, 73, 2424–2428. [CrossRef]
[PubMed]
46. Kritis, A.A.; Stamoula, E.G.; Paniskaki, K.A.; Vavilis, T.D. Researching glutamate—Induced cytotoxicity in
different cell lines: A comparative/collective analysis/study. Front. Cell. Neurosci. 2015, 9, 91. [CrossRef]
[PubMed]
47. Kane, M.D.; Vanden Heuvel, J.P.; Isom, G.E.; Schwarz, R.D. Differential expression of group I metabotropic
glutamate receptors (mGluRs) in the rat pheochromocytoma cell line PC12: Role of nerve growth factor and
ras. Neurosci. Lett. 1998, 252, 1–4. [CrossRef]
48. Kajta, M.; Budziszewska, B.; Marszał, M.; Lason´, W. Effects of 17-β estradiol and estriol on NMDA-induced
toxicity and apoptosis in primary cultures of rat cortical neurons. J. Physiol. Pharmacol. 2001, 52, 437–446.
[PubMed]
49. Behl, C. Estrogen can protect neurons: Modes of action. J. Steroid Biochem. Mol. Biol. 2002, 83, 195–197.
[CrossRef]
50. Sawada, H.; Ibi, M.; Kihara, T.; Urushitani, M.; Akaike, A.; Shimohama, S. Estradiol protects mesencephalic
dopaminergic neurons from oxidative stress-induced neuronal death. J. Neurosci. Res. 1998, 54, 707–719.
[CrossRef]
51. Yang, S.H.; Perez, E.; Cutright, J.; Liu, R.; He, Z.; Day, A.L.; Simpkins, J.W. Testosterone increases neurotoxicity
of glutamate in vitro and ischemia-reperfusion injury in an animal model. J. Appl. Physiol. 2002, 92, 195–201.
[PubMed]
52. Fanaei, H.; Sadeghipour, H.R.; Karimian, S.M.; Hassanzade, G. Flutamide Enhances Neuroprotective Effects
of Testosterone during Experimental Cerebral Ischemia in Male Rats. ISRN Neurol. 2013, 2013, 592398.
[CrossRef] [PubMed]
53. Macrae, I.M.; Carswell, H.V. Oestrogen and stroke: The potential for harm as well as benefit.
Biochem. Soc. Trans. 2006, 34, 1362–1365. [CrossRef] [PubMed]
54. Nguyen, T.L.; Kim, C.K.; Cho, J.-H.; Lee, K.-H.; Ahn, J.-Y. Neuroprotection signaling pathway of nerve
growth factor and brain-derived neurotrophic factor against staurosporine induced apoptosis in hippocampal
H19-7/IGF-IR [corrected]. Exp. Mol. Med. 2010, 42, 583–595. [CrossRef] [PubMed]
55. Hillion, J.A.; Li, Y.; Maric, D.; Takanohashi, A.; Klimanis, D.; Barker, J.L.; Hallenbeck, J.M. Involvement of
Akt in preconditioning-induced tolerance to ischemia in PC12 cells. J. Cereb. Blood Flow Metab. 2006, 26,
1323–1331. [CrossRef] [PubMed]
56. Lu, S.; Lu, C.; Han, Q.; Li, J.; Du, Z.; Liao, L.; Zhao, R.C. Adipose-derived mesenchymal stem cells protect
PC12 cells from glutamate excitotoxicity-induced apoptosis by upregulation of XIAP through PI3-K/Akt
activation. Toxicology 2011, 279, 189–195. [CrossRef] [PubMed]
57. Zhang, R.; Wang, Z.; Howson, P.A.; Xia, Z.; Zhou, S.; Wu, E.; Xia, Z.; Hu, Y. Smilagenin attenuates beta
amyloid (25-35)-induced degeneration of neuronal cells via stimulating the gene expression of brain-derived
neurotrophic factor. Neuroscience 2012, 210, 275–285. [CrossRef] [PubMed]

Molecules 2016, 21, 992
15 of 15
58. Bruce-Keller, A.J.; Keeling, J.L.; Keller, J.N.; Huang, F.F.; Camondola, S.; Mattson, M.P. Antiinflammatory
effects of estrogen on microglial activation. Endocrinology 2000, 141, 3646–3456. [CrossRef] [PubMed]
59. Vegeto, E.; Bonincontro, C.; Pollio, G.; Sala, A.; Viappiani, S.; Nardi, F.; Brusadelli, A.; Viviani, B.; Ciana, P.;
Maggi, A. Estrogen prevents the lipopolysaccharide-induced inflammatory response in microglia. J. Neurosci.
2001, 21, 1809–1818. [PubMed]
60. Brown, C.M.; Dela Cruz, C.D.; Yang, E.; Wise, P.M. Inducible nitric oxide synthase and estradiol exhibit
complementary neuroprotective roles after ischemic brain injury. Exp. Neurol. 2008, 210, 782–787. [CrossRef]
[PubMed]
61. Wen, Y.; Yang, S.; Liu, R.; Perez, E.; Yi, K.D.; Koulen, P.; Simpkins, J.W. Estrogen attenuates nuclear
factor-kappa B activation induced by transient cerebral ischemia. Brain Res. 2004, 1008, 147–154. [CrossRef]
[PubMed]
62. Marty, M.S.; O’Connor, J.C. Key learnings from the Endocrine Disruptor Screening Program (EDSP) Tier
1 rodent uterotrophic and Hershberger assays. Birth Defects Res. B Dev. Reprod. Toxicol. 2014, 101, 63–79.
[CrossRef] [PubMed]
63. García-Pupo, L.; Nuñez, F.Y.; Tacoronte, M.J.E.; Delgado, H.R. Efecto sobre la viabilidad celular de una nueva
serie de espirosteroides sintéticos en células PC12. Rev. Cuba. Farm. 2013, 47, 77–85.
64. Hughes, J.P.; Rees, S.; Kalindjian, S.B.; Philpott, K.L. Principles of early drug discovery. Br. J. Pharmacol.
2011, 162, 1239–1249. [CrossRef] [PubMed]
65. Moussaud, S.; Draheim, H.J. A new method to isolate microglia from adult mice and culture them for
an extended period of time. J. Neurosci. Methods 2010, 187, 243–253. [CrossRef] [PubMed]
Sample Availability: Samples of the compounds S9 and S15 are available from the authors.
©
2016 by the authors; licensee MDPI, Basel, Switzerland. This article is an open access
article distributed under the terms and conditions of the Creative Commons Attribution
(CC-BY) license (http://creativecommons.org/licenses/by/4.0/).
